ADDING EXPERT KNOWLEDGE TO TAN-BASED INTRUSION

DETECTION SYSTEMS

S. Benferhat

CRIL-CNRS, Faculté Jean Perrin, Rue Jean Souvraz

Lens, France

A. Boudjelida, H. Drias

Institut National d’Informatique (INI), Alger, Algérie

Keywords: Intrusion detection, TAN.

Abstract: Bayesian networks are important knowledge representation tools for handling uncertain pieces of

information. The success of these models is strongly related to their capacity to represent and handle

(in)dependence relations. A simple form of Bayesian networks, called naive Bayes has been successively

applied in many classification tasks. In particular, naive Bayes have been used for intrusion detection.

Unfortunately, naive Bayes are based on a strong independence assumption that limits its application scope.

This paper considers the well-known Tree Augmented Naïve Bayes (TAN) classifiers in the context of

intrusion detection. In particular, we study how additional expert information such that “it is expected that

80% of traffic will be normal” can be integrated in classification tasks. Experimental results show that our

approach improves existing results.

1 INTRODUCTION

Intrusion detection is an essential part of a complete

security policy in information systems. Its function

consists in analyzing information collected by

security audit mechanisms in order to find possible

attacks. Two main approaches are used to seek

intrusions trace: Misuse detection and Anomaly

detection.

Misuse detection approach uses attacks

signatures knowledge. These systems are very

precise to detect known attacks. Though, their

detection capacities are limited to attacks which

appear in their signatures data base. Thus,

continuous updates are required each time new

attacks are discovered.

Anomaly detection systems adopt an opposed

approach. It first defines a profile for normal traffic,

then checks deviations from this normal behaviour.

Thus, attacks, including new ones, are detected

when they deviate from the normal profile.

However, attacks having a profile close or similar to

the normal one can not be detected. Then often

legitimate users change their manners, the normal

behaviour should be redefined.

IDS have three common problems: temporal

complexity, correctness and adaptability. The

temporal complexity problem results from the

extensive quantity of data that the system must

supervise in order to perceive whole situation.

Positive false rate and negative false rate are

usually used to evaluate the correctness of IDS.

Positive false can be defined as alarms which are

triggered from legitimate activities. Negative false

are attacks, which are not detected by the system. An

IDS is more precise if it detects more attacks and

gives few false alarms. In case of misuse detection

systems, security experts must examine new attacks

to add their corresponding signatures. In anomaly

detection systems, human experts are necessary to

define relevant attribute for defining the normal

behaviour.

This leads us to the adaptability problem. The

currents IDS aptitudes to be adapted are very

limited. This makes them ineffective for new or

Benferhat S., Boudjelida A. and Drias H. (2009).

ADDING EXPERT KNOWLEDGE TO TAN-BASED INTRUSION DETECTION SYSTEMS.

In Proceedings of the International Conference on Security and Cryptography, pages 61-64

DOI: 10.5220/0002262200610064

 SciTePress

unknown attacks detection or to be adapted to an

evolutionary environment.

Machine learning approaches provide a potential

solution to adaptation and correctness problems in

intrusion detection context. Many classification

approaches try to construct an explicit function from

common set of features values to obtain instances

labels (category of attacks or normal).

Since (Denning D. E., 1987), several approaches

based on statistical learning were proposed for

intrusion detection. Among works which use TCP

packets analysis that of (Bykova, M. et al., 2001)

who have used simple statistics and (Ben Amor et

al., 2004) who have compared performances of

Bayesian networks and decision trees. (Valdes, A.,

Skinner, K., 2000) have used directly Bayesian

networks to model attacks and their temporal

evolution. Concerning Bayesian networks learning

for systems resources and users logs analyses we can

mention works of (Kruegel, C. et al, 2003, Scott, S.

L., 2004, John G., 1997).

The most adapted Bayesian classification model

for intrusion detection is naive Bayes. They present

several advantages due to their simple structure.

Bayesian naive networks construction is very

simple; it is always easy to consider new scenarios

(updates facility). Inference is polynomial, while

inference in Bayesian networks with general

structures is known to be a hard problem (Cooper,

G. F., 1990). However, naive Bayes networks

consider a very strong features independence

assumption: detection features are independent in a

session class context. Such hypothesis is not always

true in real applications.

This paper proposes an event classification

which uses TAN classifiers. This will enable us to

represent dependences between variables and to

integrate additional data, in order to improve

decision and detection process performances.

Section 2 shows how general expert information

can help in improving the detection rate of attacks,

while Section 3 presents comparative studies

between TAN and other classification approaches.

Finally, section 4 concludes the paper.

2 HANDLING EXPERT

INFORMATION

This section suggests a new procedure to deal with

this problem is to use additional information on

connections type. For example, we have information

that, on normal connections, usually there is X % of

these connections which are actually attacks and we

have to determine these connections.

In Bayesian networks, in order to determine

these connections, we need to sort classified

connections as normal according to probability that

they represent attacks (or according to another sort

function such difference between probability that

they represent attacks and probability that they are

normal), then the X % first connections will be taken

in order to be considered as attacks.

This information can be also related to several

attacks classes (Normal, Dos, R2L, U2R and

Probing in KDD’99 data set case), by making for

example assumption that on obtained normal

connections, there is X % of connections which are

actually DOS attacks and Y % which are R2L

attacks, thus it remains to determine normal

connections who represent these attacks. To do this

operation, we precede similarly, by sorting classified

connections as normal according to the probability

that they represent DOS attacks, then we take X %

first connexions.

The same thing for R2L attacks, but the sorting

function will be related to the probability that they

represent R2L attacks then the first Y % connections

will be taken.

The main remark drawn from the additional

information experiments results Table 1 is the

considerable PCC improvement, because this rate

have reached 96.69 % for five connections classes

case against 92 90 % without using additional

information and 97.40 % for two connections classes

case against 94.07 % without using additional

information.

As in (Ben Amor et al., 2004) we have used 10%

of KDD' 99 set (KDD cup 99, 1999), which

corresponds to 494019 training connections and

311029 test connections, with 18729 new attacks

which do not appear in training set.

Each connection is described by 41 discrete and

continuous features (for example connection

duration, protocol type, etc.) and marked to be

normal, or an attack, with only one attack type per

line (for example Smurf, Perl, etc.).

Attacks are grouped in four classes:

Denial of Service (DOS).

Make some machine

resources unavailable or too busy to answer to

legitimate users requests.

User to Root (U2R).

Exploit vulnerability on a

system to obtain a root access.

SECRYPT 2009 - International Conference on Security and Cryptography

Remote to Local (R2L).

Use vulnerability in order

to obtain a local access like a machine user.

Probing.

Collect useful information or known

vulnerabilities about a network or a system.

A more detailed study of preceding results, more

precisely negative false, shows that rest of selected

connections (which have incorrect classification

result) represent in their majorities another attacks

class than the considered class, which reduces

significantly number of negative false.

Table 1: TAN + Supplementary information results.

Five classes

Normal Dos R2L U2R Probing PCC

99.16% 99.46% 53.60% 31.43% 78.11%

96.69%

Two Classes

Normal Abnormal PCC

98.80% 97.07%

97.40%

3 COMPARATIVE STUDY

A comparative study presented in Table 2 gathering

tests results leaded by (Ben Amor et al., 2004),

which have used the same experimental conditions

as those used in our study, and results obtained

previously, based on PCC, shows that considering

all attacks, five attacks classes or only two attacks

classes do not affect TAN classification quality.

We can also note that TAN results are generally

better than those of the other strategies.

Table 2: PCC Comparison between Decision trees, Naive

Bayes, TAN, TAN + Supplementary Information.

All Attacks

Five Attacks

Classes

Two Attacks

Classes

Decision

91.41 % 92.28 % 93.02 %

Naive Bayes 91.20 % 91.47 % 91.45 %

TAN 91.27 % 92.90 % 94.07 %

TAN +

- 96.69 % 97.40 %

Another comparative study presented in Table 3

shows that TAN are competitive with the winning

strategy in KDD' 99 and also share with this latter it

failure to well classify R2L and U2R connections.

We can even note that TAN give better results than

the other strategy for Dos and R2L attacks detection.

The principal remark that we can draw from this

table remains the significant improvements given by

exploiting additional information with TAN.

This strategy has increased considerably R2L

and U2R attacks detection rate and it has minimized

false negative rate.

If we consider the global PCC, we can say that

TAN + Supplementary information is better than the

wining strategy in KDD' 99.

Table 3: Comparison between the wining strategy, TAN

and TAN + Supplementary Information.

Winning

Strategy

TAN

TAN+

Suppl. Info.

Normal 99.50 % 98.10 % 99.16 %

Dos 97.10 %

97.86 %

99.46 %

R2L 8.40 % 18.57 % 53.60 %

U2R 13.20 % 9.11 % 31.43 %

Probing 83.30 % 73.28% 78.11 %

PCC 92.70 % 92.90 % 96.69%

4 CONCLUSIONS

Performances evaluation results of TAN strategy

showed that it is better than naive Bayes. These

results also showed that PCC obtained by TAN is

better than that obtained by decision trees for the

five connexions class case. Details of these results

showed also that TAN is very competitive with the

winning strategy in KDD competition.

This paper has also shown how to use a new

procedure which exploits additional information.

Evaluation results of this new approach showed that

this approach provides better results than previous

approaches.

REFERENCES

Ben Amor, N., Benferhat, S., Elouedi, Z.: Naive Bayes vs

Decision Trees in Intrusion Detection Systems, ACM

Symposium on Applied Computing. SAC’04 (2004)

Benferhat, S., Tabia, K.: On the combination of Naive

Bayes and decision trees for intusion detection. The

International Conference of Intelligencecontrol and

Automation. CIMCA (2005)

Bykova, M., Ostermann, S., Tjaden, B.: Detecting network

intrusions via a statistical analysis of network packet

characteristics. In Proceedings of the 33rd South

Eastern Symposium on System Theory (2001)

ADDING EXPERT KNOWLEDGE TO TAN-BASED INTRUSION DETECTION SYSTEMS

Chow, C. K., Liu, C. N.: Approximating discrete

probability distributions with dependence trees. IEEE

Trans on Info Theory 14. pp 462—467 (1968)

Cooper, G. F.: Computational complexity of probabilistic

inference using Bayes belief networks. Artificial

Intelligence. Vol. 42, pp. 393--405 (1990)

Denning D. E.: An intrusion-detection model. IEEE

Transactions on software engeneering, SE-13. pp. 222-

-232 (1987)

Friedman, N., Geiger, D., Goldszmidt, M.: Bayesian

network classifiers. Machine Learning, 29(2-3):131--

163 (1997)

Geiger, D.: An entropy-based learning algorithm of

Bayesian conditional trees. In UAI ’92. pp. 92--97

(1992)

Hamine, V., Helman, P.: Learning Optimal Augmented

Bayes Networks. Dept. of Computer Science.

University of New Mexico. Albuquerque. New

Mexico 87131 USA (2004)

John, G., Enhancements to the Data Mining Process. PhD

thesis, Stanford University (1997)

KDD cup 99, intrusion detection dataset task description.

University of California Department of Information

and Computer Science,

http://kdd.ics.uci.edu/databases/kddcup99/task.html

(1999)

Kruegel, C., Mutz, Robertson, W., Valeur, F.: Bayesian

Event Classification for Intrusion Detection” Reliable

Software Group. University of California, Santa

Barbara (2003)

Langley, P., Iba, W., Thompson, K.: An Analysis of

Bayesian Classifiers. In Proceedings of the Tenth

National Conference on Artificial Intelligence, pp.

223--228, AAAI Press and MIT Press (1992)

Scott, S. L.: A bayesian paradigm for designing intrusion

detection system. Computational Statistics and Data

Analysis (special issue on network intrusion

detection). 45: 69--83 (2004)

Valdes, A., Skinner, K.: Adaptive Model-based

Monitoring for Cyber Attack Detection. In

proceedings of Recent Advances in Intrusion

Detection (RAID). pp. 80--92. Toulouse, France

(2000)

SECRYPT 2009 - International Conference on Security and Cryptography
