Early Creation of Cross Toolkits for Embedded Systems

Nikolay Pakulin and Vladimir Rubanov

Institute for System Programming of the Russian Academy of Sciences, Moscow, Russia

Abstract. Cross toolkits (assembler, linker, debugger, simulator, proﬁler) play a

key role in the development cycle of embedded systems. Early creation of cross

toolkits and possibility to quickly adapt them allows using them as early as at

the hardware/software codesign stage, which becomes an important success fac-

tor for the entire project. Challenging issues for cross toolkits development is

efﬁciency of simulation and CPU instruction set alterations at the design phase.

Developing cross toolkits in C/C++ produces highly efﬁcient tools but requires

extensive rework to keep up with instruction set changes. Approaches based on

automatic toolkit generation from some top level speciﬁcations in Architecture

Description Languages (ADLs) are less sensitive to this problem but they produce

inefﬁcient tools, especially simulators. This paper introduces a new approach to

cross toolkits development that combines the ﬂexibility of ADL and efﬁciency

of C/C++ based approaches. This approach was implemented in the MetaDSP

framework, which was successfully applied in several industrial projects.

1 Introduction

Nowadays we witness emerging of various embedded systems with rather tough con-

straints (chip size, power consumption, performance) not only for aerospace and mil-

itary applications but also for industry and even consumer electronics. The constant

trend of cost and schedule reduction in microelectronics hardware design and devel-

opment makes it reasonable to develop customized computing systems for particular

applications and gives new momentum to the market of embedded systems. Such sys-

tems consist of a dedicated hardware platform developed for a particular application

and a problem-speciﬁc software optimized for that hardware.

The process of simultaneous design and development of hardware and software

components of an embedded system is usually referred to as hardware/software code-

sign and codevelopment. This broad term covers a number of subprocess or activities

related to embedded system creation:

1. design phase, including functional design, when requirements are studied and trans-

formed into functional architechture, and hardware/software partitioning, when func-

tions are divided between hardware and software components;

2. development phase or software/hardware codevelopment when both hardware and

software teams develop their components; both development activities may inﬂu-

ence each other;

3. veriﬁcation; it spans from unit and module tests to early integration testing in sim-

ulator/emulator.

Pakulin N. and Rubanov V. (2009).

Early Creation of Cross Toolkits for Embedded Systems.

In Proceedings of the International Workshop on Networked embedded and control system technologies: European and Russian R&D cooperation,

pages 108-119

 SciTePress

Hardware/software codesign and codevelopment are crutial factors for success of

embedded systems. They reduce time-to-market by better parallelization of the devel-

opment wrokﬂows, and improve the quality by enabling early identiﬁcation of design

ﬂaws and optimization the performance of the product.

Cross toolkits play an important role in hardware/software codesign and codevel-

opment. Primary components of such cross toolkits are assembler, linker, simulator,

debugger, and proﬁler. Unlike chip production, development of cross toolkits does not

require precise hardware design description; it is sufﬁcient to have just a high-level

deﬁnition of the target hardware platform: the memory/register architecture and the in-

struction set with timing speciﬁcation. This allows developing cross tools as soon as

the early design stages even if the detailed VHDL/Verilog speciﬁcation is not ready yet.

Cross tools could be used in the following scenarios:

– Hardware prototyping and design space exploration (e.g. [4] and [15]) – early

development, execution and proﬁling of sample programs allows study and esti-

mation of the overall design adequacy as well as efﬁciency of particular design

ideas such as adding/removing instructions, functional blocks, registers or whole

co-processors.

– Early software development including development, debugging and optimizing the

software before the target hardware production.

– Hardware design validation. The developed cross-simulator could be used to run

test programs against VHDL/Verilog-based simulators. This capability could not

be overestimated for the quality assurance before the actual silicon production.

1.1 Paper Overview

In this paper, we present a new approach to cross toolkit development to be used in

hardware/software co-development environments. The method enables software devel-

opers to create the cross tools as early as the system design phase, to follow rapidly

hardware design changes, most notably instruction set modiﬁcations, thus reducing the

overall time frame of the design phase.

The article is organized as follows. Section 2 discusses generic requirements to

cross toolkit develpment that hardware/software codevelopment imposes. Section 3

presents the new ADL language for deﬁning instruction set called ISE. Section 4 in-

troduces MetaDSP framework for cross toolkit development that uses hybrid hardware

description with both high-level ADL part and efﬁcient C/C++ part. Section 5 brieﬂy

overviews several industrial applications of ISE and MetaDSP framework. Conclusion

summarizes the lessons learned and gives some perspectives for future development.

2 Hardware/Software Codesign and Codevelopment

Requirements to Cross Toolkit Development

Let’s consider a typical co-development process depicted at the ﬁg. 1. The development

process involves at least two teams - one is working on the hardware part of the system

while another one focuses on software development.

109

2.1 Related Work

Efﬁcient cross toolkit development process requires automation to minimize time and

effort necessary to update the toolkit to match new requirements. Such automation is

built around a machine-readable deﬁnition of the target hardware platform. There are

three groups of languages suitable for this task:

– Hardware Deﬁnition Languages (HDL, [10]) used for detailed deﬁnition of the

hardware;

– Architecture Description Languages (ADL, [9] and [13]) used for high-level de-

scription of the hardware;

– and general purpose programming languages (such as C/C++).

HDL speciﬁcations deﬁne CPU operations with very high level of detail. All three

major modern HDL – VHDL [5], Verilog [6], and SystemC [7] – have execution en-

vironments that can serve as a simulator to run any assembly language programs for

the target CPU: Synopsys VCS, Mentor Graphics ModelSim, Cadence NC-Sim and

other. Still, low performance of HDL-based simulators is one of the major obstacles

for HDL application in cross toolkit development. Another issue is the late moment of

HDL description availability: it appears after completing the instruction set design and

functional decomposition. Furthermore, HDL does not contain an explicit instruction

set deﬁnition that makes automated assembler/disassembler development impossible.

These issues prevent from using HDL to automate cross toolkit development.

Architecture Description Languages (such as nML[1], ISDL[2], EXPRESSION[3])

are under active development during the recent decade. There are tools created for rapid

hardware prototyping at the high level including cross toolkit generation. Correspond-

ing approaches are really good for early design phase since they help to explore key

design decisions. Unfortunately, at the later design stages details in an ADL description

become smaller, the size of the description grows and sooner or later it comes across the

limitations of the language. As a result, is breaks the efﬁciency of the simulator gener-

ated from the ADL description and makes the proﬁler to give only rough performance

estimates without clear picture of bottlenecks. Cross toolkits completely generated from

an ADL description are not applicable for industrial-grade software development yet.

Manual coding with C or C++ language gives full control over all possible details

and allows creation of cross toolkits of industrial quality and efﬁciency. Many compa-

nies offer services on cross toolkit development in C/C++ (e.g. TASKING, Raisonance,

Signum Systems, ICE Technology, etc.). Still it requires signiﬁcant efforts and (what

is more important) time to develop the toolkit from scratch and maintain it aligned

with the requirements. Long development cycle makes it almost impossible to use cross

toolkits developed in C/C++ for hardware prototyping and design space exploration.

3 ISE Language

We developed ISE (Instruction Set Extension) language to specify hardware design ele-

ments that are subject to most frequent changes: memory architecture and CPI instruc-

tion set. ISE description is used to generate assembler and disassembler tools com-

pletely and to generate components of the linker, debugger and simulator tool.

111

The following considerations guided the language design:

– the structure of an ISE description should follow the typical structure of an instruc-

tion set reference manual (like [14] or [12]) that usually serve as the input for the

ISE description development;

– support for irregular encoding of instructions typical for embedded DSP applica-

tions including support for large number of various formats, distributed encoding

of operands in the word, etc.;

– operational deﬁnition of data types, logic and arithmetic instructions, other exe-

cutable entities should be speciﬁed in a C-like programming language.

ISE module consists of 7 sections:

1. .architecture deﬁnes global CPU architecture properties such as pipeline stages,

CPU resources (buses, ALUs, etc.), initial CPU state;

2. .storage deﬁnes memory structure including memory ranges, I/O ports, access

time;

3. .ttypes and .otypes deﬁne data type to represent registers and instruction operands;

4. .instructions deﬁnes CPU instruction set (see 3.1);

5. .aspects deﬁnes various aspects of binary encoding of CPU instructions or speciﬁes

additional resources or operational semantics of instructions;

6. .conﬂicts speciﬁes constraints on sequential execution of instructions such as po-

tential write after read register or bus conﬂict; assembler uses conﬂict constraints

to automatically insert NOP instructions to prevent conﬂicts during software exe-

cution.

3.1 Instruction Deﬁnition

.instruction section is the primary section an ISE module. It deﬁnes the instruction set

of the target CPU. For each instruction cross toolkit developers can specify:

– mnemonics and binary encoding;

– reference manual entry;

– instruction properties and resources used;

– instruction constraints and inter-instruction dependencies;

– deﬁnition of execution pipeline stage.

Mnemonics part of an instruction deﬁnition is a template string that speciﬁes ﬁxed

part of mnemonics (e.g. ADD, MOV), optional sufﬁxes (e.g. ADDC or ADDS) and operands.

A singe instruction might have several deﬁnitions depending on the operand types. For

example, MOV instruction could have different deﬁnitions for register-register operation,

Binary encoding is a template that speciﬁes how to encode/decode instructions de-

pending on the instruction name, sufﬁxes and operands.

Reference manual entry is a human-readable speciﬁcation of the instruction.

Properties and resources specify external aspects of the instruction execution such

as registers that it reads and writes, buses that the instruction accesses, ﬂags set etc. This

information is used to detect and resolve conﬂicts by the assembler tool. Besides this the

112

instruction deﬁnition might specify explicit dependencies on preceding or succeeding

instructions in the constraints and dependencies section.

ISE language contains an extension of C programming language called ISE-C. This

extension is used to specify execution of the operation on each pipeline stage. ISE-C

has extra types for integer and ﬁxed point arithmetic of various bit length, new built-in

bit operators (e.g. shift with rotation), built-in primitives for bit handling. ISE-C has

some grammar extension for handling operands and optional sufﬁxes in mnemonics.

Furthermore ISE-C expression can use a large number of functions implemented in ISE

core library.

An example of instruction speciﬁcation is presented at ﬁgure 2.

Please note that unlike classic ADL languages ISE speciﬁcation does not provide

the complete CPU model. The purpose of ISE is to simplify deﬁnition of the elements

that are subject to the most frequent changes. All the rest of the model is speciﬁed using

C/C++ code. This separation allows for ﬂexible and maintainable hardware deﬁnition

along with high performance and cycle-precise simulation.

4 Application to the Codevelopment Process

The proposed hybrid ADL/C++ hardware deﬁnition is supported by the MetaDSP frame-

work for cross-toolkit development. The framework is intended for use by software

developers. Typical use case is as following:

1. hardware developers provide the software team with hardware deﬁnition in the form

of ISE speciﬁcation;

2. software developers generate cross tools from the speciﬁcation;

3. software team develops the software in Embedded-C[8] and build using the gener-

ated cross-assembler and cross-compiler;

4. the machine code is executed and proﬁled in simulator.

To support this use case the framework includes:

– ISE translator that generates components of cross tools from the ISE speciﬁcation;

– pre-deﬁned components for ISE development (e.g. ISE-C core functions library);

– an IDE for hardware deﬁnition development (in ISE and C++), target software de-

velopment (in Embedded C and assembly languages), controlled execution within

simulator; the Embedded C compiler supports a number of optimizations speciﬁc

for DSP applications[11].

The ﬁgure 3 presents the structure of the MetaDSP framework.

MetaDSP toolkit uses ISE speciﬁcation to generate cross tools and components.

For example, the MetaDSP tools generate assembler and disassembler tools completely

from the ISE speciﬁcation. For linker MetaDSP generates information about instruc-

tion binary encodings, instruction operands and relocatable instructions. Debugger and

proﬁler use memory structures and operand types from the ISE speciﬁcation.

The cycle-precise simulator is an important part of the toolkit. Figure 4 presents its

architecture. MetaDSP tools generate several components from the ISE speciﬁcation:

memory implementation (from .storage section), resources (from .architectu-

113

This is a C-style block comment.

// This is a C++-style one-line comment.

// <ALU001> - the identifier of the definition.

// ADD[S:A][C:B] - instruction mnemonics with

// optional parts. Actually defines 4 instruc-

// tions: ADD, ADDS, ADDC, ADDSC.

// GRs, GRt - identifiers of a general-purpose

// register. Rules for binary encoding of GRs

// and GRt are defined in .otypes section.

<ALU001> ADD[S:A][C:B] {GRs}, {GRt}

// Binary encoding rule.

// For example, "ADDC R0, R1" is encoded as

// 0111-0001-1000-1001

0111-0A0B-1SSS-1TTT

// The reference manual string.

"ADD[S][C] GRs, GRt"

// instruction properties:

// reads the registers GRs and GRt,

// writes the register GRs.

properties [ wgrn:GRs, rgrn:GRs, rgrn:GRt ]

// Operation of the EXE pipeline stage

// specifies using ISE-C language.

action {

alu_temp = GRs + GRt;

// If the suffix ‘C’ is set in mnemonics

// use ‘getFlag’ function from the core

// library.

if (#B) alu_temp += getFlag(ACO);

// If the suffix ‘S’ is set in mnemonics

// use ‘SAT16’ function from the core

// library.

if (#A) alu_temp = SAT16(alu_temp);

GRs = alu_temp;

}

Fig. 2. An example of instruction speciﬁcation.

re section), instruction implementations and decoding tables (from .instruction

section), as well as conﬂicts detector and instruction metadata.

Within the presented approach certain components are speciﬁed in C++:

– control logic, including pipeline control (if any), address generation, instruction

decoder;

– memory control;

– model of the peripheral devices including I/O ports.

114

– 16-bit RISC DSP CPU with support for Adaptive Multi-Rate (AMR) sound com-

pression algorithm. Produced 25 major releases of the cross-toolkit.

– 32-bit RISC DSP CPU with support for Fourier transform and other DSP exten-

sions. Produced 39 major releases of the cross-toolkit.

– 16/32-bit RISC CPU clone of ARM9 architecture.

– 16/32-bit VLIW DSP CPU with support for Fourier transform, DMA, etc. Produced

33 major releases of the cross-toolkit.

The following list summarizes lessons learned from the practical applications of the

approach. We compared time and effort needed in a pure C++ development cycle of

cross toolkits with the ISE-enabled process:

– size of assembler, disassembler and simulator sources (excluding generated code),

in lines of code: reduced by 12 times;

– cross-toolkit development team (excluding C compiler development): reducing from

10 to 3 engineers;

– number of errors detected in the presentation of hardware speciﬁcations in cross

tools: reduction by the factor of more than 10;

– average duration of the toolkit update: reduced from several days to hours (even

minutes in many cases).

5.1 Performance Study

This section presents a performance study of a production implementation of the AMR

sound compression algorithm. The study was performed on Intel Core 2 Duo 2.4 GHz.

The size of the implementation was 119 C source ﬁles and 142 C header ﬁles, and

25 ﬁles in the assembly language; total size of sources was 20.2 thousand LOC without

comments and empty lines. The duration of the audio sample (10 seconds voice speech)

lasted 670 million of cycles on the target hardware.

Table 1 presents elapsed time measurements of the generated cross tools for the

AMR case study. Table 2 presents measurements of the generated simulator in MCPS

(millions of cycles per second).

Table 1. AMR sample – cross toolkit performance.

Operation Duration, sec.

Translation (.c → .asm) 22

Assembly (.asm → .obj) 14

Link (.obj → .exe) 1

Build, total 37

Execution on the audio sample

(fast mode)

Execution on the audio sample

(debug mode with proﬁling)

117

Table 2. AMR sample – simulator performance.

Execution mode MCPS

Fast mode 12.6

Debug mode with proﬁling 7.2

Peak performance on a synthetic sam-

ple

25.0

6 Conclusions

The paper presents an approach to automation of cross toolkit development for special-

purpose embedded systems such as DSP and microcontrollers. The approach aims at

creation the cross tools, namely assembler/disassembler, linker, simulator, debugger,

and proﬁler, at early stages of system design. Early creation of the cross tools gives

opportunity to prototype and estimate efﬁciency of design variations, co-development of

the hardware and software components of the target embedded system, and veriﬁcation

and QA of the hardware speciﬁcations before silicon production.

The presented approach relies on a two-level description of the target hardware:

description of the most ﬂexible part – the instruction set and memory model – using

the new ADL language called ISE and description of complex ﬁne grained functional

aspects of CPU operations using a general purpose programming language (C/C++).

Having ADL descriptions along with a framework to generate components of the target

cross toolkits and common libraries brings high level of responsiveness to frequent

changes in the initial design that are a common issue for modern industrial projects.

Using C/C++ gives cycle-accurate simulation and overall efﬁciency of the cross toolkits

that meets the needs of industrial developers. The approach is supported by a family of

tools comprising MetaDSP framework.

The approach is applicable to various embedded systems with RISC core architec-

tures. It supports simple pipelines with ﬁxed number of stages, multiple memory banks,

instructions with ﬁxed and variable cycle count. These facilities cover most of mod-

ern special purpose CPUs (esp. DSP) and embedded systems. Still some features of

modern general purpose high performance processors lay beyond the capabilities of the

presented approach: superscalar architectures, microcode, instruction multi-issue, out-

of-order execution. Besides this, the basic memory model implemented in MetaDSP

does not support caches, speculative access, etc.

Despite the limitations of the approach mentioned above it was successfully applied

in a number of industrial projects including 16 and 32-bit RISC DSPs and 16/32 ARM

CPUs. Number of major design changes (with corresponding releases of cross toolkits)

ranged in those projects from 25 to 40. The industrial applications of the presented

approach proved the concept of using the hybrid ADL/C++ description for automated

development of cross toolkits in a volatile design process.

118

References

1. Fauth, A., Praet, J. V., and Freericks, M. (1995). Describing instruction set processors using

nML. In Proc. of European Design and Test Conference.

2. Hadjiyannis, G., Hanono, S., and Devadas, S. (1997). ISDL: An instruction set description

language for retargetability. In Proc. of 34th Design Automation Conference.

3. Halambi, A., Grun, P., Ganesh, V., Khare, A., Dutt, N., and Nicolau, A. (1999). EXPRES-

SION: A language for architecture exploration through compiler/simulator retargetability. In

Proc. of European Conference on Design, Automation and Test.

4. Hartoog, M., Rowson, J., and Reddy, P. (1997). Generation of software tools from processor

descriptions for hardware/software codesign. In Proc. of Design Automation Conference

(DAC).

5. IEEE Std 1076-2000 (2000). VHDL language reference manual.

6. IEEE Std 1364-2005 (2005). Hardware description language based on the Verilog hardware

description language.

7. IEEE Std 1666-2005 (2005). System C language reference manual.

8. ISO/IEC TR 18037:2008 (2004). Programming languages – C – Extensions to support em-

bedded processors.

9. Mishra, P. and Dutt, N. (2005). Architecture description languages for programmable em-

bedded systems. In IEEE Proceedings Computers and Digital Techniques, volume 152-3.

10. Navabi, Z. (2007). Languages for Design and Implementation of Hardware. The VLSI

Handbooks. CRC Press, 2nd edition.

11. Rubanov, V., Grinevich, A., and Markovtsev, D. (2006). Speciﬁc optimization features in a

C compiler for DSPs. In Programming and Computing Software, volume 32-1, pages 19–30.

12. Texas Instruments (2006). TMS320C6000 CPU and instruction set reference guide.

13. Tomiyama, H., Halambi, A., Grun, P., Dutt, N., and Nicolau, A. (1999). Architecture descrip-

tion languages for systems-on-chip design. In Proc. of Asia Paciﬁc Conf. on Chip Design

Language, pages 109–116.

14. VIA Technologies (2005). MicroDSP 2 instruction set description.

15. Yung-Chia, L. (2003). Hardware/software co-design with architecture description language.

119
