SEMANTICS BASED RECONCILIATON

FOR COLLABORATIVE ONTOLOGY EVOLUTION

Georgios M. Santipantakis and George A. Vouros

Dept. of Information and Communication Systems Eng, University of the Aegean, Karlovassi, 83200, Samos, Greece

Keywords: Ontology evolution, Collaborative ontology engineering, Reconciliation, Validity rules.

Abstract: The objective of this paper is to present the SR-COE (“Semantics-based Reconciliation in Collaborative

Ontology Development and Evolution”) system for supporting knowledge workers/engineers to the

synchronous and asynchronous collaborative ontology development and evolution: This system provides the

necessary generic infrastructure for enhancing the deployment of any ontology development tool in

distributed settings with concurrent workers, and for applying any collaborative ontology engineering

method effectively. SR-COE exploits the semantics of the modification actions performed from the

different, concurrent contributing parties so as to actively support them to reach mutual agreed ontologies.

1 INTRODUCTION

Exploitation of knowledge represented by means of

ontologies aims to facilitate the knowledge

management processes within and across

organizations. To obtain a global view of a domain,

often people need to express their perspectives, in a

collaborative manner. However, it is likely to

happen that different persons provide conflicting

specifications for ontology elements. It is important

to locate the implied conflicts and provide support

for these persons to resolve them towards reaching

an agreement. Aiming to actively support knowledge

workers and engineers to shape a commonly

accepted conceptualization of a domain, this paper

presents the “Semantics-based Reconciliation for

Collaborative Ontology Development and

Evolution” (SR-COE) system: SR-COE exploits the

semantics of the modification actions performed by

knowledge engineers and workers, who act

concurrently on a single ontology. The system

detects actions with conflicting effects and

reconciles them, proposing alternative and conflicts-

free ontology versions. Semantics are being captured

by means of constraints/dependencies between the

effects of modification actions.

2 RELATED WORK

AND MOTIVATION

Methodologies towards the collaborative

development of ontologies propose concrete

methodological steps for facilitating collaboration

and reaching consensus. A wide range of approaches

is available, featuring techniques for locking

ontologies’ versions (Farquhar et al, 1996), centrally

accessible shared spaces (Kotis, Vouros, 2006),

and/or require collaborative parties to provide

arguments on the developed versions via

participating in argumentation dialogues (Tempich

et al 2005).

Several tools have been presented in the

collaborative ontology development domain (Sure et

al, 2002), (Arprez et al, 2001), (Bozsak et al, 2002),

(Domingue, 1998), (Ceusters et al, 2001), (Hotho et

al, 2006), (Tummarello et al 2006), (Sunagawa et al.

2003), (Auer et al, 2006) (Tudorache et al, 2008).

However, to the best of our knowledge, there is not

any tool that allows collaborative parties to

simultaneously and jointly modify the same

ontology version without any restriction (as far as

the creation and access to any version is concerned),

actively supporting people to locate and reconcile

conflicting specifications and views.

To facilitate collaborators’ awareness on the

status of the evolving ontology, some of the

methodologies/tools focus on providing a central

repository. Different versions of the same ontology

can be stored in this repository, possibly escorted

153

M. Santipantakis G. and A. Vouros G. (2009).

SEMANTICS BASED RECONCILIATON FOR COLLABORATIVE ONTOLOGY EVOLUTION .

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development, pages 153-158

DOI: 10.5220/0002290501530158

 SciTePress

with arguments concerning changes made. Locking

and shared-space methods have inherent limitations:

(a) They do not conserve against conflicts that may

appear between versions, (b) they confine real

collaboration, as each user modifying an ontology is

the only one connected to it, and (c) they do not

actively support collaborative parties to inspect all

possible conflicts and reconcile different

perspectives.

To a greater extent than current tools/environ-

ments for ontology development/evolution we

require a system that shall facilitate collaboration by:

 Imposing the minimum possible restrictions on

the collaboration and multi-party deve-

lopment/evolution process: The evolution,

creation and access to different versions of

ontologies needs to be made seamlessly, for all

participants, without directly affecting each

other.

 Actively supporting the detection of conflicts for

each ontology version, and facilitating the

reconciliation of conflicts by exploiting the

semantics of the actions performed.

 Being methodology-independent, therefore

generically applicable.

 Facilitating the deployment of ontology

engineering tools in distributed settings, so as to

support collaboration.

 Being seamlessly combined with any

argumentation framework.

We need to emphasize that the implementation of

such a generic system, acting as an infrastructure for

collaborative ontology development and evolution,

will allow the transfer of ontology engineering tools

from their “classic” standalone mode, to their

deployment in distributed settings.

To address these issues we have implemented

SR-COE. It actively supports people to collaborate

while being either connected or disconnected: Each

user holds a replica of an ontology, which is being

developed/evolved by using any preferred tool.

Modifications performed by remote and concurrent

collaborators on their local replicas need to be

merged: As local replicas may diverge, possible

conflicts between them must be detected and

reconciled. As a result of this reconciliation, all

users are aware of (a) the modifications made by

others, (b) of the possible conflicts that arise, and (c)

of the possible, alternative conflicts-free versions of

the ontology. We have to point out that the system

has to be able to support any state of the art

methodology that accentuate the active participation

of knowledge workers in the ontology engineering

lifecycle, (e.g. HCOME and DILIGENT).

3 BACKGROUND KNOWLEDGE

3.1 Semantics based Reconciliation via

Telex

The work presented in (Shapiro et al, 2004)

introduced a formalism for maintaining consistency

in distributed systems for data sharing. Based on this

formalism, work done in Telex (Benmouffok et al.,

2009) enables collaborative and distributed

development and evolution of “documents”. A

document may be of any form and format,

containing formal or informal specifications. In the

context of our work, a document is an evolving

ontology.

An application is a “middleware” between the

user and Telex (Shapiro et al, 2004). Telex is

instantiated in each collaborating site. Users by

means of their applications can modify their local

replicas of documents, either being online or offline,

while Telex takes the hard responsibility to merge

replicas. To do this, applications need to update

Telex with fragments of actions and constraints.

Then, Telex exploits the semantics of modification

actions which are being captured by constraints.

Constraints are application-specific invariants that

parameterize Telex. The types of constraints are

presented in the paragraphs that follow.

Telex takes care of replication, consistency,

storage and access control; collecting, transmitting

and persisting actions; detecting conflicts and

computing high-quality schedules.

Telex in each site maintains an Action-Constraint

Graph (ACG), where nodes are actions, and arcs

constraints between them. The actions represent

operations that users apply to replicas of a document

via their applications, and arcs represent constraints

between these operations. Constraints enable the

computation of possible, alternative schedules. The

ACG is formed by the union of all operations

performed in all sites: When a local update occurs,

the system replicates every action to the other

collaborating sites.

Table 1 shows the set of available types of

constraints (Benmouffok et al., 2009). The constraint

NotAfter indicates that an ordering between the

actions A and B must be maintained, such that no

schedule that commits to the execution of both

actions executes B before A. The constraint

Enables is an implication between the

corresponding actions. If a schedule commits to

execute B, then it must also commit to execute A

without considering any ordering between the

actions.

KEOD 2009 - International Conference on Knowledge Engineering and Ontology Development

154

Table 1: Constraint types.

In case that A is aborted in a schedule this constraint

forces B to be aborted as well. Combining these

primitive constraints, the

Atomic, Casual

Dependence and Antagonism constraints are

generated. The

Casual Dependence constraint

defines that action B depends on A, and a schedule

commits to it iff it commits to A. The

Antagonism

constraint identifies a conflict between actions A and

B. This constraint defines that when a schedule

commits to execute action A, it aborts B and vice-

versa.

A set of actions is said to be in conflict, if they

form a “→” (

NotAfter) cycle. This means that no

sound schedule can commit to the execution of all

these actions. The

Antagonism constraint is a

special case of such as cycle between the actions A

and B.

As shown in Figure 1, Telex comprises the

Scheduler, the Agreement module, the Logger and

the Transmitter. Each detected conflict triggers the

generation of schedules from Scheduler, which

“marks” each action to be either “aborted” or

“committed” in each schedule. For instance, the

detection of a pair of antagonistic actions drives

Telex to construct two alternative schedules, where

each of the antagonistic actions is either aborted or

committed.

A schedule may be selected by the local

application and be provided to the agreement

module as a proposal. Because of the asynchronous

communication, proposals may be different. The

agreement module is responsible though to help sites

reach an agreement. It is possible that some

applications require the selection of proposals based

on application specific criteria and/or policies. Telex

provides the freedom to developers to implement the

algorithm they need. The basic algorithm relies on

voting, so that user preferences are to be taken into

account. It is important to be mentioned that each

Telex module is instantiated per each locally “open”

document. We refer the interested reader to (Shapiro

et al, 2004) for further details.

3.2 Ontology Evolution via Validity

Rules

Considering the problem of ontology evolution in

the face of modification actions, authors in

(Konstandinidis et al., 2008) devise a framework and

algorithm for determining the effects and side-

effects of any such action. Although the framework

proposed is general, authors focus in a fragment of

RDF/S. To abstract from the underlying language

and develop a uniform framework, RDF is mapped

to First-Order Logic (FOL) expressions. The

representation of ontological facts by means of First

Order Logic predicates is shown in table 2

(Konstandinidis et al., 2008).

Table 2: Ontological facts as First Order Logic predicates.

The semantics of specifications are captured via

validity rules, which introduce a validity model.

Validity rules are encoded in the form:

),()(

,...,1 iiini

vuQvuPu

∃

∨→

∀

where

v,u

are tuples of variables, P and Q

are

conjunctions of relational atoms of the form

R(w

,...,w

), and equality atoms of the form (w

where w

,...,w

, w

, are variables or constants.

An example of a validity rule is the following:

(

)

(

)()

wx,InstCwz,Domainzy,x,PI _→∧

This rule states that given an instance (x z y) of a

property z whose domain is w, then x must be an

instance of w. All validity rules are specified in

(Konstandinidis et al., 2008).

The FOL specifications are equipped with closed

semantics, i.e., CWA (closed world assumption).

This means that, for two formulas p, q, if p⊬q, then

p⊢¬q. Abusing notation, for two sets of ground facts

U, V, we will say that U implies V (U⊢V ) to denote

that U⊢ p for all p in V. Any expression of the form

P(x

,…,x

) is called a positive ground fact where P is

a predicate of arity k and x

,…,x

are constant

symbols. Any expression of the form ¬P(x

,…,x

) is

called a negative ground fact iff P(x

,…,x

) is a

positive ground fact. L denotes the set of all well-

formed formulae that can be formed in this FOL. We

denote by L+ the set of positive ground facts, and L-

SEMANTICS BASED RECONCILIATON FOR COLLABORATIVE ONTOLOGY EVOLUTION

155

the set of negative ground facts. An evolving

ontology is a set K

⊆

L+. In simple words, an

ontology is any set of positive ground facts. An

update is any set of positive or negative ground

facts. The application of any modification action to

an evolving ontology should result in a set of effects.

Each effect is a ground fact.

By definition, ontologies have two properties: (a)

they are always consistent (in the purely logical

sense) and (b) they imply only the positive ground

facts that are already in the ontology. The above two

properties together with the CWA semantics, imply

that (a)

P(x)

∈

⇔

K ⊢ P(x)

⇔

K ⊬¬P(x) and

(b) P(x)

∉

⇔

K ⊢¬P(x)

⇔

K ⊬P(x)

An application of these properties is that, applying a

modification action with effect ¬P(x) to the ontology

K corresponds to removing P(x) from K. On the

other hand, updating an ontology with positive

ground facts corresponds to adding facts in K.

With the aim to specify and compute conflicts

using validity rules, following (Konstandinidis et al.,

2008), we use component sets. The component set

that corresponds to a validity rule c with respect to

some tuple of constants

is defined as

}}:,1|),(

...),(),({}0|)({{),(

constantznizxQ

zxQzxQkjxPxcComp

iij

≤≤∧

∧

∧∪

≤

<¬=

GGG

For example, for the rule

()

(

)()

wx,InstCwz,Domainzy,x,PI _→∧

the derived component set would be

{{¬PI(x,y,z)}, {¬Domain(z,w)},{C_Inst(x,w)}}

As proposed in (Konstandinidis G. et al., 2008), a

ground fact

P(x) which is added in an ontology K,

would violate a rule c, iff there is some set V and

tuple of constants

for which ¬P(x)∈V and

V∈

()

uc,Comp

and for all V'∈

()

uc,Comp

, V≠V', it

holds that

K ⊬V'.

Let us for instance consider the following

scenario that exemplifies the above and reveals our

considerations for collaborative ontology evolution:

Let us consider George who performs an action that

adds the fact

PI(x,y,z) in his ontology replica, and

Peggy who performs an action with effect

Domain(z,w), in her own replica. Then, none of

these replicas violate the validity rule

() ()

(

)

wx,InstCwz,Domainzy,x,PI _→∧

according to the above mentioned definition (given

that

C_Inst(x,w) does not hold in any of the

replicas). This is indeed so, since, given the

component set of this rule, the fact ¬

Domain(z,w)

(respectively, ¬PI(x,y,z)) validates the rule for

George (respectively Peggy). However, when the

two replicas are combined, the rule is violated, given

that in the merged version

PI(x,y,z) and Domain(z,w)

hold but

C_Inst(x,w) does not hold. Notice that if

C_Inst(x,w) holds, then both local views are

consistent, as well as the global view. However, it is

obvious that users cannot be “forced” to insert the

fact

C_Inst(x,w) in their replicas to assure the

validity of the merged version. In the merged

version this must be done to maintain consistency, or

else, alternative schedules must be constructed

where either

PI(x,y,z) or Domain(z,w) is aborted.

4 COLLABORATIVE

ONTOLOGY EVOLUTION

In order to apply the semantic-based reconciliation

method to the domain of ontology evolution,

possible modification actions and their constraints

must be defined.

Table 3 shows the constraints that derive from

the validity rules. The first column provides a

reference name, the second one contains the

component sets derived from the validity rules, and

the third one provides the corresponding constraints.

At this point it is important to notice two things:

(a) Constraints concern the effects of

modification actions, rather than the actions

themselves: Therefore, for SR-COE, nodes in ACG

are labelled with predicates from Table 2 and

conjunctions of them.

Subsequently, when we refer

to actions we actually refer to their effects

. Given a

schedule as described above, provided by Telex, we

can create a new ontology version from the schedule

itself. The generated version incorporates the effects

of actions performed by the different collaborating

parties and it provides a “landmark” for ontology

developers to proceed towards an agreed

conceptualization. This landmark is called a

“

checkpoint”. Checkpoints give the ability to the

users to “roll back”, i.e. to undo modifications.

(b) Some of the constraints in Table 3 have a

compound side, something which is not inherently

supported by Telex. For this purpose we introduce

the notion of the

compound (complex) action. A

compound action is formed by a conjunction of

actions. Its status, as it is determined by the Telex

scheduler, depends on the status of the actions it

consists of: If any atomic action contained in some

compound action is aborted, the compound is

aborted as well. A compound action is also

represented as an action in the ACG, along with the

constraints that bound it to the atomic actions it

consists of. For instance, given a compound action

“

x_and_y”, the constraints

x_and_y""x""

◁

→

and

KEOD 2009 - International Conference on Knowledge Engineering and Ontology Development

156

x_and_y""y""

◁

→

are added to ACG.

Table 3: Derived constraints from component sets.

Considering again our example, the constraint

corresponding to the “Property instance and

Domain” rule will not be violated in any of the

replicas where

PI(x,y,z) or Domain(z,w) hold, but a

conflict will be detected in the merged version,

where both

PI(x,y,z) and Domain(z,w) hold and

C_Inst(x,w) does not hold.

Each of the collaborators modifies a local replica

of an ontology: The effects of modifications label

the nodes in ACG. Telex replicates and schedules

these effects to all sites. Any user may create a

checkpoint from a generated schedule and continue

evolving it. A checkpoint is published to remote

users as a new ontology version, by the time the user

who created it, starts modifying it. The set of shared

checkpoints defines the

versioning tree: Users may

select to evolve any checkpoint created by any of the

collaborating parties, creating a new set of

checkpoints, and so on. The depth and breadth of

this tree is subject to the rules and policies that the

collaborating community sets.

5 SR-COE ARCHITECTURE

An overview of the SR-COE architecture is

presented in figure 1.

Assuming that the user modifies a locally stored

ontology version, then, the following events occur:

 The ontology parser detects new modifications

(the

diff) and calls the validity checker. These

effects will not directly affect other replicas.

Doing so, it allows users to modify the same

ontology with no restriction, concurrently.

 The validity checker generates a new fragment

that is sent to Telex.

Figure 1: The overall architecture of SR-COE.

 Telex takes control, to handle new fragments

appropriately. Modifications that do not raise

conflicts in schedules are appended to these.

Otherwise, alternative schedules are provided, if

possible.

 The ontology updater module informs the user

for any new schedule and updates the locally

stored ontology model, on user’s request.

The paragraphs that follow present each SR-COE

module in detail.

The Ontology Parser module is responsible to

monitor the selected ontology version and retrieve

the effects of modification actions performed. When

a change occurs, the module identifies the elements

added or removed and provides them to the validity

checker module. This module is also responsible to

creating a checkpoint upon user’s request.

Given the new facts retrieved by the ontology parser,

the validity checker module is triggered to infer new

facts (i.e. inherited properties and transitivity of

subsumption relations), to produce constraints and to

validate the changes in the local replica.

In case that removed elements are detected, the

validity checker constructs antagonism constraints

between these facts and their negations. Constraints

generated by the validity rules are initially exploited

locally, to check for local conflicts. If no conflicts

are found, the validity checker proceeds to the

generation of a fragment containing new facts and

corresponding constraints to be sent to Telex.

Otherwise, the validity checker generates

antagonism constraints between the conflicting facts,

driving the computation of alternative schedules.

Doing so, users can continue modifying the locally

stored file, even if a conflict has occurred.

The Scheduler and Agreement modules of Telex

provide global consistency (given sound

constraints), and provide assistance towards

reaching an agreed conceptualization (Benmouffok

SEMANTICS BASED RECONCILIATON FOR COLLABORATIVE ONTOLOGY EVOLUTION

157

et al., 2009). Each user “runs” an instance of SR-

COE, and thus of Telex, that operates locally. Telex

is responsible to maintain the ACG, given the

fragments generated from validity checker module.

When the graph is updated by new nodes and the

corresponding constraints, the scheduler computes

new schedules, which are provided to the ontology

updater module.

The ontology updater connects the GUI of the

corresponding ontology engineering tool and SR-

COE. In our prototype implementation, it provides

information on the available schedules, as well as

information about modification actions (issuer,

action, effects) performed in the concurrent

collaborating sites. It notifies users about conflicts

detected and schedules built, without requiring users

to take any particular immediate action. However,

users may request to view a schedule and create a

new checkpoint which is added to the versioning

tree. Subsequently, the user can access this new file

via SR-COE, making this version available to the

rest of the community. Users proceed by choosing

the version to modify, creating new checkpoints, and

so on, until they reach an agreed conceptualization.

It is important to be mentioned that ontologies

comprise only positive facts that correspond to

committed actions in a schedule. Negative facts are

incorporated as nodes in ACG so as conflicts

between replicas to be detected.

6 CONCLUSIONS

To a greater extent than current tools/environments

for ontology development we have built a system

that facilitates collaborative ontology development

and evolution by: (a) Imposing the minimum

possible restrictions on the collaboration and multi-

party development/evolution process, allowing the

creation of different versions of ontologies and the

seamless access to these versions. (b) Actively

supporting the detection and reconciliation of

conflicts, by exploiting the semantics of the actions

performed. (c) Being methodology-independent,

therefore generically applicable. (d) Facilitating the

deployment of current ontology engineering tools in

distributed settings, supporting collaboration.

As described above, the validity rules presented

support the development and evolution of

lightweight ontologies using a rather simple model.

However, SR-COE can be easily customised by

incorporating any set of validity rules, to deal with

more expressive ontology languages.

An important step to be made concerns the study

of using SR-COE in conjunction with different

ontology engineering tools, maybe in the context of

different methodologies.

REFERENCES

Farquhar, A. et al, 1997. The Ontolingua Server: A tool

for collaborative ontology construction. Intl. J.

Human-Computer Studies 46, pp. 707–728 .

Kotis, K., Vouros, G., 2006. Human-centered ontology

engineering: The HCOME methodology, In KAIS, 10,

pp. 109-131.

Tempich, C. et al, 2005. An Argumentation Ontology for

Distributed, Loosely-controlled and evolvInG

Engineering processes of oNTologies (DILIGENT).

ESWC 2005, LNCS 3532, pp. 241–256 .

Sure, Y., et al 2002. OntoEdit: Collaborative Ontology

Development for the Semantic Web. ISWC 2002,

LNCS 2342, pp. 221–235 .

Arprez, J.C., at al, 2001. WebODE: a scalable workbench

for ontological engineering. K-CAP’01 .

Bozsak, E., et al, 2002. KAON - Towards a Large Scale

Semantic Web. 3rd Intl. Conf. on e-Commerce and

Web Technologies, LNCS 2455, pp. 304–313.

Domingue, J., 1998. Tadzebao and WebOnto: Discussing,

Browsing, and Editing Ontologies on the Web.

KAW’98, Banff, Canada.

Ceusters, W., et al, 2001. LinkFactory: an Advanced

Formal Ontology Management System. KCAP-2001,

Victoria, Canada.

Tudorache, T., et al, 2008. Collaborative Protege:

Enabling Community-based Authoring of Ontologies,

In Proc. Of the Workshop on Social and Collaborative

Construction of Structured Knowledge, ISWC 2008,

Banff, Canada.

Seidenberg, J., Rector, A., 2007. A Methodology for

Asynchronous Multi-User Editing of Semantic Web

Ontologies. K-CAP'07, pp. 127–134.

Hotho, A., et al, G., 2006. BibSonomy: A social bookmark

and publication sharing system. Conceptual Structures

Tool Interoperability Workshop at the 14th Int. Conf.

on Conceptual Structures, pp. 87-102.

Tummarello, G., et al., 2006. Enabling semantic web

communities with DBin: an overview. ISWC 06,

LNCS 4273, pp. 943–950.

Sunagawa, E., et al, 2003. An environment for distributed

ontology development based on dependency

management. ISWC’03, LNCS 2870, pp. 453-468.

Auer, S., et al, 2006. OntoWiki a tool for social, semantic

collaboration. ISWC, LNCS 4273, pp. 736-749.

Shapiro, M., et al, 2004. A constraint-based formalism for

consistency in Replicated Systems. OPODIS 04,

LNCS 3544, pp. 331-345.

Benmouffok, L., et al, 2009. Telex: A Platform for

Decentralised Sharing. In EuroSys 2009.

Konstandinidis G., et al, 2008. A Formal Approach for

RDF/S Ontology Evolution. ECAI-08, pp. 70-74.

KEOD 2009 - International Conference on Knowledge Engineering and Ontology Development

158
