TARANTULA

A Scalable and Extensible Web Spider

Anshul Saxena

, Keshav Dubey

, Sanjay K. Dhurandher

and Issac Woungang

Division of Computer Engineering, Netaji Subhas Institute of Technology, University of Delhi, Delhi, India

CAITFS, Division of Information Technology, Netaji Subhas Institute of Technology, University of Delhi, Delhi, India

Department of Computer Science, Ryerson University, Toronto, Canada

Keywords: Crawler, Compressed Tries, Crawling Strategies, Distributed Processing.

Abstract: Web crawlers today suffer from poor navigation techniques which reduce their scalability while crawling

the World Wide Web (WWW). In this paper we present a web crawler named Tarantula that is scalable and

fully configurable. The work on Tarantula project was started with the aim of making a simple, elegant and

yet an efficient Web Crawler offering better crawling strategies while walking through the WWW. This

paper also presents a comparison with the Heritrix (Mohr et al.) crawler. The structure of the crawler

facilitates new navigation techniques which can be used with existing techniques to give improved crawl

results. Tarantula has a pluggable, extensible architecture that further facilitates customization by the user.

1 INTRODUCTION

The World Wide Web (WWW) or the web can be

viewed as a huge distributed database across several

million of hosts over the Internet where data entities

are stored as web pages on web servers. The data on

the Web is varied, mostly unstructured and not

catalogued and their logical relationships are

represented by hyperlinks. According to Netcraft

survey in April 2009, the number of hostnames has

increased by ten times to 232,000,000 than what it

was in 1995. On the first look, implementation of a

web crawling system appears to be trivial. However,

due to the enormous size of the web, its high rate of

expansion, its variedness and non uniformity,

making a web crawler capable of following links and

downloading web pages as it moves from one

website to another is a complex task.

A good crawler system can be judged on the

basis of two important parameters. The first

parameter is the crawling strategy used by the

crawler. While there are many existing crawling

strategies (Hafri and Djeraba, 2004) each one with

its merits and demerits, choice of crawling strategy

used is a key factor in deciding the scalability of the

web crawler. The other important parameter is the

performance of the crawler within the allotted

resources. Limitations of primary and secondary

memory and network bandwidth are the key

bottlenecks in the performance of a crawler. Also,

the size of the Internet is in hundreds of Terabytes.

Hence, it is imperative to have a design that extends

to handle these factors effectively. This paper

focuses on the design and architectural details of

Tarantula that incorporates all the above mentioned

features.

The remaining paper is organized as follows. In

section 2, we discuss about the previous work done

in this area. Our motivation for this project is

presented in section 3. Section 4 describes briefly

the architecture of Tarantula. Section 5 explains the

algorithms and the hashing techniques used in the

various modules. We present our results in section 6

and then finally conclude this work in section 7 and

give the future work that can be carried out in this

dimension in section 8.

2 RELATED WORK

When the Internet first came into existence, there

were very few web pages on the web hence a web

crawler was not necessary at that time. But with the

internet revolution in the last decade, the number of

167

Saxena A., Dubey K., Dhurandher S. and Woungang I. (2009).

TARANTULA - A Scalable and Extensible Web Spider.

In Proceedings of the International Conference on Knowledge Management and Information Sharing, pages 167-172

DOI: 10.5220/0002302001670172

 SciTePress

web pages online grew exponentially, and thus the

need for a search engine to index these pages

became indispensable. Web spiders were used by

these search engines to scale up the web and hence

they became popular. Since then, the web spiders

have been crawling the web on a regular basis.

A popular web crawler is the UbiCrawler (Boldi

et al., 2004). It is made up of several web agents that

scan their own share of the web by autonomously

coordinating their behaviour. Each agent performs

its task by running several threads, each dedicated to

scan a single host using a Breadth-First visit thus

ensuring that politeness is maintained as different

threads visit different hosts at the same time.

However, breadth-first navigation technique being a

top-down approach results in web crawler missing

out on possible detection of new URLs that can be

obtained from already discovered URLs. For

example, given a URL say

www.example.com/pics/page1.html, there might be

possible existence of URLs like

www.example.com/pics/ and www.example.com/

pics/page2.html, etc. Discovering such URLs from

the existing URLs increases the scalability of the

web crawler.

Heritrix is the web crawler developed by Internet

Archive's, an open-source corporation. Heritrix

provides a number of storing and scheduling

strategies to crawl the seed list. Each of its crawler

process can be assigned up to 64 sites to crawl, and

it is ensured that no site is assigned to more than one

crawler. The crawler process reads a list of seed

URLs for its assigned sites from disk into the

queues, and then uses asynchronous I/O to fetch

pages from these queues in parallel. After the page is

downloaded, the crawler performs link extraction on

it and if a link refers to the site of the page it was

contained in, it is added to the appropriate site

queue; otherwise it is logged to disk. Periodically, a

batch process performs merging of these logged

“cross-site” URLs into the site-speciﬁc seed sets and

thus ﬁltering out duplicates in the process and the

process is repeated till exhaustion of URL in the list.

KSpider (Koht-arsa and Sanguanpong, 2002), is

a scalable, cluster based web spider. It uses a URL

compression scheme that stores the URLs in a

balanced AVL tree. The compressed URLs are

stored in memory rather than on hard disk because

storing the URLs in memory improves the

performance of the crawler. Common prefix among

URLs is used to reduce the size of the URLs by

storing the common prefixes once and reusing them

for many URLs. However, the structure of AVL

restricts the number of children to two and increases

the height of the tree even though it is balanced.

Tarantula capitalizes over KSpider by making

optimal use of the common prefixes among URLs

by using a slight modified version of compressed

tries. These data structure are broad and therefore

can have more than two children thereby decreasing

the height of the tree. Also, unlike KSpider,

Tarantula stores all the URLs belonging to the same

host in the same compressed trie. This is useful in

restricting the depth of crawling a hostname and also

provides easy mechanism for ensuring politeness of

the crawler system. Applying compression

algorithms to URLs and then expanding them again

leads to a lot of CPU usage and time expenditure. It

is therefore advantageous to compress the URLs

based on common prefixes. Though the compression

is not as high, the speed of the crawler is greatly

enhanced.

3 MOTIVATION

One of the initial motivations for this work was to

develop a crawling system which is able to scale a

greater degree of the web. The crawling system

should be able to process a large number of URLs

from far and wide thus trying to cover the entire

breadth of the Internet. This prompted us to come up

with unique crawling strategies, which when

combined with the page ranking and refreshing

crawling schemes, gives excellent results.

We also wanted that the design used data

structures that reduce the amount of I/O needed and

CPU processing performed to pursue the newly

extracted URLs for downloading the web pages.

By looking at some URLs, it is possible to

detect the existence of newer URLs that might be

valid but have not yet been discovered by the

crawler possibly because of broken web links.

Therefore, mining on the URLs discovered was yet

another motivation behind development of Tarantula

web crawler.

KMIS 2009 - International Conference on Knowledge Management and Information Sharing

168

Figure 1: Tarantula Architecture.

4 ARCHITECTURE

The Figure 1 depicts the architecture of the proposed

Tarantula web crawler. The URL Storage and

scheduler module sends a list of URLs to the Data

Collector module for downloading the

corresponding web pages. It consists of URL Buffer

Queue which stores a queue of URLs that are to be

fetched by the crawler. One by one the Data

Downloader sub module fetches the web pages from

the Internet and sends the downloaded data to the

Data Processing module. During the process of

downloading the web page, the crawler system

maintains a DNS repository as well as a DNS cache

to speed up the download rate of the crawler by

avoiding latency caused by redundant DNS

resolving queries.

The web page downloaded by the Data Collector

module is sent to the Data Processing module. Here,

the web page is stored as a data stream variable and

is processed by the URL Extractor to retrieve fresh

web links from the web page and the Stats Collector

sub module processes it to collect statistical data

about the web page. Tarantula can be configured to

collect different types of statistical data from the

web pages. Once processed, the web page is handed

over to a free “save thread” from the thread pool that

store the web page at an appropriate location on the

hard disk. The list of freshly extracted URLs is then

sent to the URL Processing module.

The URL Processing module firstly consists of a

URL Normalizer sub module which converts the

URL into their canonical form. This is necessary to

avoid different URLs pointing to the same web page

from being scheduled for downloading. While there

is no universally accepted canonical form,

depending upon the focus of the crawler system,

appropriate normalization techniques can be applied.

The URL Filter reads the output from the URL

Normalizer and filters out unwanted or already

downloaded URLs. Here again different filters based

on keywords, file type, etc. can be used depending

upon the requirement. The filtered and normalized

URLs are now ready to be scheduled for

downloading. The URLs to be downloaded by

another crawler thread or by a crawler thread on

another terminal is decided by the Communicator

module. This module is responsible for unbiased

distribution of URLs to every crawler thread on

every terminal. Using a hash technique, the URL list

is distributed amongst crawler threads running on

different terminals on a high speed crawler LAN.

Those URLs that are to be scheduled for

downloading by the current crawler thread is then

sent to the URL Storage and Scheduling module.

The URL Storing and Scheduling module

consists of a URL Seen Test sub module which

checks if the URL has been fetched by the crawler

system or not. Those URLs that have been fetched in

the past and need no refreshment are removed while

TARANTULA - A Scalable and Extensible Web Spider

169

the rest are forwarded to the URL Packing module

where the URLs are stored in memory as

compressed tries (Maly, 1976). Compressed tries

apart from reducing the size of the URL offer other

advantages as discussed later. From the compressed

tries, the Scheduler sub module picks out the URLs

in the order in which they are to be downloaded by

the Data collector module.

This entire cycle is repeated by every crawler

thread on every terminal on the high speed LAN.

5 ALGORITHM

The algorithm conceived for the Tarantula makes it

the most unique feature of the entire

implementation. This spans over the new scheduling

methodologies and provides an innovative URL

compression technique.

5.1 Data Structure

The URLs filtered out from the URL Seen Test are

packed into a data structure of the type compressed

tries. The URLs are hashed on their host name as per

two equations: equation 1 and equation 2 as shown

below that distribute the URLs between different

crawler terminals, and between the different threads

of a terminal into corresponding compressed trie in

which the URL is to be packed in.

hash(URL) = (Σ Sum of ASCII values of even

characters of hostname) % Total number of Threads

per Crawler System

(1)

hash(URL) = (Σ Sum of ASCII values of od

characters of hostname) % Total number of Threads

per Crawler System

(2)

Figure 2: Compressed Trie structure.

The compressed trie node as shown in Figure 2

consists of a variable storing a portion of the URL

and a list of characters storing the first character of

the portion of the URL represented by every child

node. The order of the characters in the list decides

the order of find of the URLs by the crawler thread.

Since the trie stores the URLs based on their

common parts, it offers high compressions for big

websites having long URLs with large common

parts. This data structure has the advantage that

URLs of the same host names are stored in the same

sub trie. Hence only one node ( may be more) stores

the host name while all the URLs with the same host

name share the sub trie and as we go down the sub

trie, the URL represented by the current node is used

as prefix by the child node to represent a new URL.

The crawler follows a bottom up approach by

starting with the URL represented by the leaf node

and moves upwards to retrieve new URLs. It is also

possible for the crawler to retrieve URLs that have

not yet been seen by the crawler but are implicitly

understood. To see how, consider a sample trie as

shown in Figure 3.

Figure 3: Retrieval of new URLs.

If the crawler got a URL

www.example.com/video/clips/, it is stored in the

compressed tries as shown in Figure 3. The crawler

follows a bottom-up approach to retrieve the URLs

from the compressed tries. In this case, it starts with

the leaf node “clips/” and identifies the URL

www.example/com/video/clips/. After scheduling

this URL, it moves on to a node at a higher level

“video/” representing the URL

www.example.com/video/. Finally, we get

www.example.com/ as the last URL. Hence from

one URL, the crawler is implicitly able to find out

two new URLs which it has not seen before. Also, if

the crawler had discovered a new URL

www.example.com/pics1/Page1.html, then there

might be a possibility of existence of other URLs

such as www.example.com/pics1/Page2.html or

www.exampe.com/pics2/Page1.html. The bottom-up

approach imposed by the above data structure makes

it possible to mine the discovered URLs and help

discovering possible new URLs.

5.2 Scheduling Techniques

Two custom scheduling techniques have been

devised which are used in conjuncture with the URL

KMIS 2009 - International Conference on Knowledge Management and Information Sharing

170

prioritization and ranking schemes for better crawl

results. These have been discussed below.

5.2.1 Top Sliding Window Technique

Consider a compress trie consisting of URLs of n

different websites. The scheduler will maintain a

sliding window of size less than or equal to n. By

top sliding window we mean that the sliding window

will contain elements pointing to the left most leaf

node of all the child nodes of the compressed trie

which have node values as the hostnames of

different websites as shown in Figure 4.This will

guarantee that the URLs pointed to by elements in

the sliding window belong to different web servers.

Each compressed trie will have a different sized

sliding window and a URL in any sliding window

will have different host name from any other URL in

any sliding window. Thus the politeness of the

crawler is maintained.

Figure 4: Top Sliding Window Scheduling.

For simplicity, let us assume that level 1 nodes of a

compressed trie consists of www.example1.com,

www.example2.com, www. example3.com, and

www.example4.com as shown in Figure 5. Let us

also assume that all these URLs point to different

web servers and the crawler maintains a sliding

window of size 2. The compiler picks up the left

most leaf of the www.example1.com sub trie and the

www.example2.com sub trie in the first crawl

(represented as dotted border rectangle). In the

second crawl, the sliding window moves to the right

and contain URLs represented by the left most leaf

of www.example3.com and www.example4.com

(represented as single border rectangle).

Figure 5: Top Sliding Window Scheduling Example.

5.2.2 Leaf Sliding Window Technique

In this technique, we maintain a sliding window

containing pointers to all the leaf nodes of a trie as

shown in Figure 6. The size of the window is fixed

for all the compressed tries and it moves to and fro

from the left most leaf node to the right most leaf

node of the trie. The sliding windows are then

arranged in a column fashion to form a table of

URLs. Row wise scheduling of the URLs in the

table so formed is done by the URL Scheduler.

Figure 6: Leaf Sliding Window Scheduling.

In both the above crawling strategies, the number of

elements must be large enough to have sufficient

interval between the URLs with the same hostname.

6 EXPERIMENTAL RESULTS

The proposed web spider Tarantula is written

entirely in C#.net. The operating system of the

crawler machine was Windows XP Service Pack 2

(SP2). Only one machine was used. Its processor

was the AMD Turion™ 64 X2 TL-60 2.00GHz and

had a RAM of 1GB with 320GB SATA hard disk.

The Tarantula was run for four hours on a shared

internet connection of 2Mbps. The Heritrix crawler

with which the comparison was performed is

Internet Archive’s open source web crawler project.

The number of threads used in Tarantula and

Heritrix were 10. Heritrix was run under similar test

condition and the results have been compiled as

TARANTULA - A Scalable and Extensible Web Spider

171

follows:

Figure 7: Average Download Rate vs. Time.

Tarantula initially started slowly but picked up and

maintained a speed of about 2 documents per second

(doc/sec), while the Heritrix had an initial spike of

2.1 doc/sec but slowed down to nearly 1.5 doc/sec.

The Figure 7 shows the plot of average download

rate versus the time for Tarantula as well as Heritrix.

Figure 8: URLs Discovered vs. Time.

Figure 9: Bandwidth Utilization vs. Time.

The Figure 8 shows the number of URLs discovered

with time. From the graph, it is clear that the mining

of the URLs and the fast crawling rate have resulted

in exceptionally good results for the proposed

Tarantula crawler than the Heritrix crawler.

The Figure 9 shows the percentage bandwidth

utilization of Tarantula and Heritrix with time. With

high and low curves, the utilization of the bandwidth

by both the crawlers is nearly same.

7 CONCLUSIONS

In this paper, we have described the architecture and

implementation details of Tarantula web crawler,

and have presented some preliminary experimental

results for the same. We have been successful in

building such a system using efficient data structures

and scheduling algorithms. We have also used a

unique and particularly useful crawling strategy that

helps our crawler to make its requests politely

without compromising on the speed at which the

web pages are downloaded. Based upon the crawling

results, our crawling system proved to be much more

scalable and faster than the Heritrix web crawler.

8 FUTURE WORKS

Most of the web is hidden behind forms. To retrieve

these pages, the web crawler should be equipped to

handle deep web. Another way to handle this

problem is to divide the web into different categories

and design focused crawlers for each of these

categories. Tarantula is still a broad crawler which

does not perform either deep web crawling or

focused crawling. This technique may be considered

as a future enhancement to this work.

REFERENCES

Djeraba, C., Hafri, Y., 2004. Dominos: a New Web

Crawler's Design. In ECDL’04, 8th European

Conference on Research and Advanced Technologies

for Digital Libraries. Springer Press.

Mohr, G., Stack, M., Ranitovic, I., Avery, D. and

Kimpton, M., 2004. An Introduction to Heritrix An

open source archival quality web crawler. In

IWAW’04, 4th International Web Archiving Workshop.

Springer Press.

Boldi, P., Codenotti, B., Santini, M., Vigna, S., 2004.

UbiCrawler: A Scalable Fully Distributed Web

Crawler. In 8th Australian World Wide Web

Conference. John Wiley & Sons Publications.

Koht-arsa, K., Sanguanpong, S., 2002. High Performance

Large Scale Web Spider Architecture. In

International Symposium on Communications and

Information Technology. ANREG Publication.

Maly, K., 1976. Compressed Trie. ACM Publications.

KMIS 2009 - International Conference on Knowledge Management and Information Sharing

172
