COMPUTATION OF THE SEMANTIC RELATEDNESS BETWEEN

WORDS USING CONCEPT CLOUDS

Swarnim Kulkarni and Doina Caragea

Department of Computing and Information Sciences, Kansas State University, Manhattan, Kansas, U.S.A.

Keywords:

Semantic relatedness, Automatic concept extraction, Concept cloud, PageRank, Information retrieval.

Abstract:

Determining the semantic relatedness between two words refers to computing a statistical measure of similarity

between those words. Word similarity measures are useful in a wide range of applications such as natural

language processing, query recommendation, relation extraction, spelling correction, document comparison

and other information retrieval tasks. Although several methods that address this problem have been proposed

in the past, effective computation of semantic relatedness still remains a challenging task. In this paper,

we propose a new technique for computing the relatedness between two words. In our approach, instead of

computing the relatedness between the two words directly, we propose to ﬁrst compute the relatedness between

their generated concept clouds using web-based coefﬁcients. Next, we use the obtained measure to determine

the relatedness between the original words. Our approach heavily relies on a concept extraction algorithm that

extracts concepts related to a given query and generates a concept cloud for the query concept. We perform

an evaluation on the Miller-Charles benchmark dataset and obtain a correlation coefﬁcient of 0.882, which is

better than the correlation coefﬁcients of all other existing state of art methods, hence providing evidence for

the effectiveness of our method.

1 INTRODUCTION

Building a system that can effectively determine the

similarity between two words has been a problem of

interest to many researchers in artiﬁcial intelligence

and information retrieval areas. A robust solution to

this problem would not only help in a wide range

of applications such as document comparison, spell

checking, community mining, but more importantly

such semantic metrics would help the computers to

gain a “common sense” of the information on the web.

Semantic metrics between words have been used

by researchers to deﬁne semantic relatedness, seman-

tic similarity and semantic distance, as described in

(Gracia and Mena, 2008). For completeness, we pro-

vide brief deﬁnitions of these concepts here. Seman-

tic relatedness considers any type of relationship be-

tween two words (including hypernymy, hyponymy,

synonymy and meronymy relationships, among oth-

ers) and is usually a statistical similarity measure be-

tween the two words. Semantic similarity is a more

specialized version of semantic relatedness that con-

siders only synonymy and hypernymy relationships

between words. Semantic distance is a distance-based

measure of semantic relatedness. That is, the more

related two words are, the smaller is the semantic dis-

tance between them.

Compared to machines, humans are able to ac-

curately determine the similarity between two words

based on their common sense knowledge. For ex-

ample, in order to determine that the words <apple,

computer> are more closely related than the words

<apple, car>, humans would use their knowledge

that apple is the name of a company that manufac-

tures computer hardware and software, to determine

that apple is semantically more related to computer

than to car. Our goal is to provide machines with such

power by using an automated concept cloud based ap-

proach to determine semantic relatedness.

More precisely, our approach computes the se-

mantic relatedness between two words by computing

the similarity between their concept clouds. To auto-

matically generate concept clouds, we use a Concept

Extractor (CE) tool that we recently proposed in

(Kulkarni and Caragea, 2009). The Concept Extrac-

tor takes as input a word query and generates a con-

cept cloud for the query, by extracting its associated

concepts from the web. Thus, for a given pair of

words, we ﬁrst extract the concepts associated with

each word in the pair and generate their concepts

183

Kulkarni S. and Caragea D. (2009).

COMPUTATION OF THE SEMANTIC RELATEDNESS BETWEEN WORDS USING CONCEPT CLOUDS.

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval, pages 183-188

DOI: 10.5220/0002303701830188

 SciTePress

clouds. We then compute the semantic relatedness be-

tween the two concept clouds and use it to determine

the relatedness between the initial word pair.

The rest of the paper is organized as follows: Sec-

tion 2 discusses related work. Section 3 gives a de-

tailed description of the our approach for calculating

semantic relatedness and its underlying algorithms.

Section 4 contains the experimental results and an

evaluation of our method by comparison with other

similar methods. We conclude the paper in Section 5.

2 RELATED WORK

The problem of determining the semantic relatedness

between two words has been an area of interest to

researchers from several areas for long time. Some

very preliminary approaches (Rada et al., 1989) cal-

culated the similarity between two words on the ba-

sis of the number of edges in the term hierarchy cre-

ated by indexing of articles. Similar edge-counting

based methods were also applied on existing knowl-

edge repositories such as Roget’s Thesaurus (Jarmasz

and Szpakowicz, 2003) or WordNet (Hirst and St-

Onge, 1998) to compute the semantic relatedness.

To improve the preliminary approaches to calcu-

lating the semantic relatedness between words, more

sophisticated methods have been proposed. Instead

on simply relying on the number of connecting edges,

Leacock and Chodorow (1998) have proposed to take

the depth of the term hierarchy into consideration.

Others groups have proposed to use the description of

words present in dictionaries (Lesk, 1986) and tech-

niques such as LSA (Deerwester et al., 1990) to com-

pute semantic relatedness. However, due to the very

limited size of WordNet as a knowledge base and the

absence of well known named entities (e.g., Harry

Potter) in WordNet, researchers have started to look

for more comprehensive knowledge bases.

The advent of Wikipedia in 2001 has fulﬁlled

the need for a more comprehensive knowledge base.

Many techniques that use Wikipedia to compute se-

mantic relatedness have been developed in the recent

years. Among others, Strube and Ponzetto (2005)

have used Wikipedia to determine semantic related-

ness. Their results outperform those obtained us-

ing WordNet, hence showing the effectiveness of

Wikipedia in determining the similarity between two

words. Gabrilovich and Markovitch (2007) have de-

veloped a technique, called Explicit Semantic Anal-

ysis (ESA), to represent the meaning of words in

a high dimensional space of concepts derived from

Wikipedia. Experimental results show that ESA out-

performs the method given by (Strube and Ponzetto,

2005). Chernov et al. (2006) have suggested to

make use of the links between categories present on

Wikipedia to extract semantic information. Milne and

Witten (2008) have proposed the use of links between

articles of Wikipedia rather than its categories to de-

termine semantic relatedness between words. Zesch

et al. (2008) have proposed to use Wiktionary, a

comprehensive wiki-based dictionary and thesaurus

for computation of semantic relatedness. Although

Wikipedia has proven to be a better knowledge base

than WordNet, many terms (e.g., 1980 movies) are

still unavailable on Wikipedia. This has motivated

the use of the whole web as the knowledge base for

calculating semantic relatedness.

Bollegala et al. (2007) have proposed to use page

counts and text snippets extracted from result pages

of web searches to measure semantic relatedness be-

tween words. They achieve a high correlation mea-

sure of 0.83 on the Charles-Miller benchmark dataset.

Sahami and Heilman (2006) have used a similar mea-

sure. Cilibrasi et al. (2007) have proposed to compute

the semantic relatedness using the normalized google

distance (NGD), in which they used Google

T M

to de-

termine how closely related two words are on the ba-

sis of their frequency of occurring together in web

documents. Chen et al. (2006) have proposed to ex-

ploit the text snippets returned by a Web search engine

as an important measure in computing the semantic

similarity between two words.

The approach in (Salahli, 2009) is the closest to

our approach, as it uses the related terms of two words

to determine the semantic relatedness between the

words. However, the major drawback of the approach

proposed in (Salahli, 2009) is that the related terms

are manually selected. As opposed to that, our ap-

proach automatically retrieves the most relevant terms

to a given word query. Furthermore, Salahli compares

the related terms to the original query. In our ap-

proach, we compute the semantic relatedness between

two words using the semantic similarity between their

generated concept clouds. To the best of our knowl-

edge, such an approach has not been proposed yet.

3 PROPOSED APPROACH

The steps of out proposed approach are shown in Fig-

ure 1. We use a two-phase procedure to compute the

semantic relatedness between two words. The ﬁrst

phase involves the use of a Concept Extractor (Kulka-

rni and Caragea, 2009) to identify concepts related to

the given pair of words and to generate their concept

clouds. In the second phase, we use web-based coef-

ﬁcients (Cosine, Jaccard, Dice, Overlap) to compute

KDIR 2009 - International Conference on Knowledge Discovery and Information Retrieval

184

Figure 1: Steps of our proposed approach.

the semantic relatedness between the generated con-

cept clouds, and use the resulting score to determine

the relatedness between the original words. We will

next describe the precise steps in our approach, and in

particular, the algorithm that determines the semantic

relatedness between two concept clouds.

3.1 Input Pre-Processor

The Input Pre-Processor module takes the given

word-pair as input and divides it into two separate

words. Each word is then pre-processed by convert-

ing it to lower case letters. Furthermore, any special

characters such as “@”, if present, are removed from

the words. Finally, the two words are provided as in-

put to the concept extractor (one at a time).

3.2 Concept Extractor

The Concept Extractor module takes as input words

from the Input Pre-Processor module and, for each

word, it extracts its related concepts and forms the

concept cloud by including the top k related concepts.

More details about the Concept Extractor module can

be found in (Kulkarni and Caragea, 2009).

In this paper, we use the top ﬁve related concepts

to generate the concept cloud of a term. Please note

that before generating the concept cloud, we perform

a ﬁltering of the related concepts. Filtering involves

removal of long concepts (more than 3 words), con-

cepts containing special characters such as “@”, and

general concepts such as dictionary, web, etc.

3.3 Cloud Comparator

The function of the Cloud Comparator module is to

perform a statistical comparison of the concept clouds

corresponding to two words, using web based coef-

ﬁcients such as Dice and Jaccard coefﬁcients. To

Figure 2: An example illustrating the functionality of the

Cloud Comparator module.

achieve that, the Cloud Comparator computes a sta-

tistical similarity measure between all pairs of con-

cepts < A, B >, where A belongs to the cloud of one

term and B belongs to the cloud of the second term,

and calculates the average of all similarity scores to

determine the relatedness between the original words.

We will use the example in Figure 2 to illustrate

the functionality of the Cloud Comparator module.

We assume that we want to ﬁnd the semantic relat-

edness between the words automobile and car. After

executing the ﬁrst two modules in our procedure, the

concept cloud for automobile is {Car, Auto, Subaru,

Technology, Vehicles}, while the concept cloud for

car is {Used Cars, New Cars, Auto, Buy a Car, Au-

tomobile}. The comparator takes each concept from

the ﬁrst cloud, e.g., Car and ﬁnds its relatedness to

concepts in the second cloud using web-based coefﬁ-

cients. Preliminary experiments have shown that the

Jaccard’s coefﬁcient produces the best results. Hence,

we have used the Jaccard’s coefﬁcient to compute se-

mantic relatedness between two concept clouds.

Traditionally, the Jaccard’s coefﬁcient is used to

determine the similarity between two given sets, A

and B, by taking the ratio between the size of the in-

tersection of the two sets and the size of the union of

the two sets. That is: Jaccard(A, B) =

|P ∩ Q|

|P ∪ Q|

However, Bollegala et al. (2007) have modiﬁed

the Jaccard’s coefﬁcient deﬁnition to make it possible

to compute the relatedness between two words, P and

Q, using web search results. Thus:

Jaccard(P, Q) =

H(P ∩ Q)

H(P)+ H(Q)−H(P ∩ Q)

where H(P) and H(Q) refer the number of pages re-

trieved when the query “P” and the query “Q” are

posted to a search engine, respectively; and H(P ∩ Q)

is the number of pages retrieved when the query

“P”“Q” is posted to a search engine.

To compute the relatedness between a term i from

the ﬁrst concept cloud A, denoted con

(i), and the

second concept cloud B, we compute the Jaccard’s co-

efﬁcient between con

(i) and all concepts con

( j) in

COMPUTATION OF THE SEMANTIC RELATEDNESS BETWEEN WORDS USING CONCEPT CLOUDS

185

the concept cloud B and then take the average of all

scores obtained. That is:

rel(con

(i), cloud(B)) =

∑

j=1

Jaccard(con

(i), con

( j))

where n is the total number of concepts in cloud(B).

Consider the example in Figure 2. The similarity

between the concept car and the cloud car is com-

puted as:

rel(car, cloud(car)) =

∑

j=1

Jaccard(car, con

car

( j))

We calculate this score for each concept in ﬁrst

cloud A and then pass on the array of scores to the

Score Generator module.

3.4 Score Generator

The Score Generator is the simplest module in our

framework. It takes as input the array of scores re-

ceived from the Cloud Comparator and computes the

average of the scores to obtain a ﬁnal score for the two

initial words. That is,

score(A, B) =

∑

i=1

rel(con

(i), cloud(B))

where m refers to the total number of concepts in

cloud(A). It can be seen that:

score(A, B) =

∑

i=1

∑

j=1

Jaccard(con

(i), con

( j))

m ∗ n

The calculated score is reported to the user as the se-

mantic relatedness score between the given words.

4 EXPERIMENTAL RESULTS

AND EVALUATION

As the effectiveness of our method is highly depen-

dent on the results of the Concept Extractor module,

we start by brieﬂy presenting the results of the Con-

cept Extractor module on several types of queries.

Then, we evaluate the procedure for calculating the

semantic relatedness on the Miller-Charles bench-

mark dataset. Similar to previous work (Bollegala

et al., 2007), we compute the correlation coefﬁcient

between our relatedness scores and benchmark scores

and we compare the resulting correlation coefﬁcient

with the correlation coefﬁcients reported for other

similar methods. The comparison shows that our ap-

proach outperforms previous approaches reported in

the literature.

4.1 Evaluation of Concept Extractor

We conducted ﬁve experiments on the Concept Ex-

tractor module. In the ﬁrst experiment, we used a

single well-deﬁned concept as the query. In the sec-

ond experiment, we provided the system with similar

keywords from a speciﬁc domain. In the third experi-

ment, we tested the system by providing the name of

a person as the query. In the fourth experiment, we

provided a misspelled query as input. The goal of the

ﬁfth experiment was to test the ability of the system to

perform word sense disambiguation. The results for

the experiments are summarized in Table 1.

4.2 Evaluation on Miller-Charles Data

We evaluated the Cloud Comparator module on

the Miller-Charles benchmark dataset. The Miller-

Charles dataset is a data set of 30 word pairs, which

have been evaluated for semantic relatedness, on a

scale of 0-4, by a group of 38 human subjects. Ta-

ble 2 summarizes our results as well as results of

previous approaches obtained from (Bollegala et al.,

2007). Please note that all scores, except for the

Miller-Charles scores, have been scaled to [0,1] by

dividing them by the maximum score (such that the

best score becomes 1). The page count and the con-

cept data collected is as of May 4th, 2009.

The correlations between the scores obtained with

each method and the benchmark scores are also re-

ported in Table 2. As can be seen, our approach

outperforms similar existing methods by achieving a

high Pearson correlation coefﬁcient of 0.882. The

highest scoring pair is midday-noon while the lowest

scoring pair is bird-crane. In addition to being more

accurate, another advantage of our approach is that it

is not dependent on a single knowledge source such

as WordNet or Wikipedia and hence, has the capabil-

ity to determine semantic relatedness between almost

any word-pair.

5 SUMMARY AND DISCUSSION

In this paper, we have proposed a method for com-

puting the semantic relatedness between two given

words. Our approach relies on a Concept Extractor

procedure (Kulkarni and Caragea, 2009) for ﬁnding

related concepts based on web searches (i.e., con-

cept clouds for the two words). We compute the se-

mantic relatedness between the clouds using the web-

based Jaccard coefﬁcient. Experimental results on

the Miller-Charles benchmark dataset show that our

approach outperforms similar existing approaches in

KDIR 2009 - International Conference on Knowledge Discovery and Information Retrieval

186

Table 1: Concept Extractor results: related concepts extracted for a given query.

Query Type Query Extracted Concepts

Flu Inﬂuenza, Flu, Flu Shot, Flu vaccine, Avian ﬂu, Cold, Acetaminophen

General Kansas State University K-State, Kansas State, CIS, Ahearn ﬁeld house , Kansas, Powercat, Courses

Set-based Mars Venus Earth Mars, Earth, Moon, Sun, Jupiter, Mercury, Neptune

Christopher Manning

Chris Manning, Christopher d. Manning, Computer Science, Data mining,

Ergativity: argument structure and grammatical relations, Foundations of sta-

tistical natural language processing, Introduction to information retrieval

Name-based Dan Brown Author, Da vinci code, Angels and Demons, Biography, Deception point

Spelling-error Contectiivtis Conjunctivitis, Pinkeye, Allergic conjunctivitis, Chlamydia, Eye infection, In-

fectious, Bacterial conjunctivitis

Leopard OS Apple, Mac OS X, Mac OS History, Operating System, 32-bit, 64-bit, Software

Ambiguous word Leopard Animal Animals, Leopard, Snow Leopard, Mammals. Wildlife, Aardwolf

Table 2: Semantic relatedness results obtained with our approach and several related methods, by comparison with the Miller-

Charles scores. The results of the methods called Web Dice and Web Overlap (Bollegala et al., 2007), Sahami (Sahami and

Heilman, 2006), CODC (Chen et al., 2006) and Bollegala (Bollegala et al., 2007) are obtained from (Bollegala et al., 2007).

Pearson correlation coefﬁcients between the scores obtained with each method and the Miller-Charles scores are also reported.

Word Pair Miller-

Charles

Web Dice Web

Overlap

Sahami CODC Bollegala Our

approach

cord-smile 0.13 0.108 0.036 0.090 0 0 0.023

rooster-voyage 0.08 0.012 0.021 0.197 0 0.017 0.027

noon-string 0.08 0.133 0.060 0.082 0 0.018 0.034

glass-magician 0.11 0.124 0.408 0.143 0 0.180 0.027

monk-slave 0.55 0.191 0.067 0.095 0 0.375 0.029

coast-forest 0.42 0.870 0.310 0.248 0 0.405 0.078

monk-oracle 1.1 0.017 0.023 0.045 0 0.328 0.052

lad-wizard 0.42 0.077 0.070 0.149 0 0.220 0.012

forest-graveyard 0.84 0.072 0.246 0 0 0.547 0.062

food-rooster 0.89 0.013 0.425 0.075 0 0.060 0.121

coast-hill 0.87 0.965 0.279 0.293 0 0.874 0.010

car-journey 1.16 0.460 0.378 0.189 0.290 0.286 0.186

crane-implement 1.68 0.076 0.119 0.152 0 0.133 0.035

brother-lad 1.66 0.199 0.369 0.236 0.379 0.344 0.307

bird-crane 2.97 0.247 0.226 0.223 0 0.879 0.009

bird-cock 3.05 0.162 0.162 0.058 0.502 0.593 0.518

food-fruit 3.08 0.765 1 0.181 0.338 0.998 0.566

brother-monk 2.82 0.274 0.340 0.267 0.547 0.377 0.460

asylum-madhouse 3.61 0.025 0.102 0.212 0 0.773 0.849

furnace-stove 3.11 0.417 0.118 0.310 0.928 0.889 0.502

magician-wizard 3.5 0.309 0.383 0.233 0.671 1 0.493

journey-voyage 3.84 0.431 0.182 0.524 0.417 0.996 0.596

coast-shore 3.7 0.796 0.521 0.381 0.518 0.945 0.649

implement-tool 2.95 1 0.517 0.419 0.419 0.684 0.524

boy-lad 3.76 0.196 0.601 0.471 0 0.974 0.911

automobile-car 3.92 0.668 0.834 1 0.686 0.980 0.898

midday-noon 3.42 0.112 0.135 0.289 0.856 0.819 1.000

gem-jewel 3.84 0.309 0.094 0.211 1 0.686 0.884

Correlation 1 0.267 0.382 0.579 0.693 0.834 0.882

terms of the correlation coefﬁcient computed with re-

spect to the Miller-Charles benchmark scores. More

precisely, we obtained a high correlation coefﬁcient

of 0.882.

The success of our approach can be explained as

follows: The Concept Extractor forms the basis for

the proposed method. The Concept Extractor works

by extracting concepts using the top links returned

by a search engine. Therefore, the extracted con-

cepts are related to the most popular meaning of the

term. If we analyze the Miller-Charles dataset, we

note that the word pairs that are related through the

most popular meaning of the words get a higher rat-

ing by the human subjects. For example, between

the word pairs magician-wizard and glass-magician,

magician-wizard gets a higher rating by the human

COMPUTATION OF THE SEMANTIC RELATEDNESS BETWEEN WORDS USING CONCEPT CLOUDS

187

subjects (3.5) as compared to glass-magician (0.11).

This is because wizard is a more popular meaning of

the term magician as compared to glass. Our sys-

tem also assigns a higher score to magician-wizard, as

the concepts extracted for magician are closer to con-

cepts extracted for wizard than to concepts extracted

for glass.

Other advantages of our approach include the fol-

lowing: it is not limited to a particular knowledge

base such as WordNet or Wikipedia and, as a conse-

quence, it is capable of handling a larger set of inputs;

it is robust to the errors made by the user in inputs (as

the search engine usually corrects misspellings); and

it is able to handle multi-word queries.

Future work includes further improvements of the

correlation coefﬁcient, by improving the concept ex-

traction process. We believe that more precise con-

cept clouds will results in more accurate estimates for

the semantic relatedness between words. Extensions

of the approach to natural language processing appli-

cations are also part of our planned future work.

ACKNOWLEDGEMENTS

This work was funded by National Science founda-

tion grant number NSF 0711396 to Doina Caragea.

REFERENCES

Bollegala, D., Matsuo, Y., and Ishizuka, M. (2007). Mea-

suring semantic similarity between words using web

search engines. In Proc. of WWW 2007.

Chen, H., Lin, M., and Wei, Y. (2006). Novel association

measures using web search with double checking. In

In Proc. of the COLING/ACL 2006, pages 1009–1016.

Chernov, S., Iofciu, T., Nejdl, W., and Zhou, X. (2006).

Extracting semantic relationships between wikipedia

categories. In Proc. of SemWiki2006 Workshop, co-

located with ESWC2006.

Cilibrasi, R. and Vitanyi, P. (2007). The google similarity

distance. In IEEE Transactions on Knowledge and

Data Engineering, pages 370–383.

Deerwester, S., Dumais, S., Furnas, G., Landauer, T., and

Hashman, R. (1990). Indexing by latent semantic in-

dexing. In Journal of the Amer. Soc. for Inf. Science.

Gabrilovich, E. and Markovitch, S. (2007). Computing se-

mantic relatedness using wikipedia-based explicit se-

mantic analysis. In Proc. of the Int. Joint Conf. on

Artiﬁcial Intelligence (IJCAI-07), pages 1606–1611.

Gracia and Mena (2008). Web-based measure of seman-

tic relatedness. In Proc. of the 9th Int. Conf. on Web

Information Systems Engineering, pages 136–150.

Hirst, G. and St-Onge, D. (1998). Lexical chains as repre-

sentations of context for the detection and correction

of malapropisms. In C. Fellbaum Ed., pages 305–332.

MIT Press.

Jarmasz, M. and Szpakowicz, S. (2003). Rogets thesaurus

and semantic similarity. In Proc. of RANLP-03, pages

212–219.

Kulkarni, S. and Caragea, D. (2009). Towards bridging the

web and the semantic web. In Proc. of WI/IAT 2009.

Leacock, C. and Chodorow, M. (1998). Combining local

context and wordnet similarity for word sense iden-

tiﬁcation. In C. Fellbaum Ed., pages 265–283. MIT

Press.

Lesk, M. (1986). Automatic sense disambiguation using

dictionaries. In Proc. of the 5th Int. Conf. on Systems

Documentation.

Milne, D. and Witten, I. (2008). An effective, low-cost mea-

sure of semantic relatedness obtained from wikipedia

links. In Proc. of AAAI08 Workshop on Wikipedia and

Artiﬁcial Intelligence, Chicago,IL.

Rada, R., Milli, H., Bicknell, E., and Blettner, M. (1989).

Development and application of a metric to semantic

nets. In IEEE Transactions on Systems, Man and Cy-

bernetics, pages 17–30.

Sahami, M. and Heilman, T. (2006). A web-based ker-

nel function for measuring the similarity of short text

snippets. In Proc. of 15th Int. WWW Conf.

Salahli, M. A. (2009). An approach for measuring semantic

relatedness via related terms. In Mathematical and

Comp. Applications, volume 14, pages 55–63.

Strube, M. and Ponzetto, S. (2005). Exploiting semantic

role labeling, wordnet and wikipedia for coreference

resolution. In Proc. of the ACL HLT Conf.

Zesch T., Mller Christof, G. I. (2008). Using wiktionary

for computing semantic relatedness. In Proceedings

of AAAI 2008, pages 861–868.

KDIR 2009 - International Conference on Knowledge Discovery and Information Retrieval

188
