AN ONTOLOGY DRIVEN APPROACH TO SOFTWARE SYSTEMS

COMPOSITION

Hlomani Hlomani and Deborah Stacey

Computing and Information Science, University of Guelph, Guelph, Ontario, Canada

Keywords:

Ontologies, Software systems composition, Semantic web.

Abstract:

This paper discusses a proof of concept prototype system driven by knowledge embodied in a set of Ontolo-

gies; an algorithm Ontology and an execution timeline Ontology. The main idea behind Ontology Driven

Compositional System (ODCS) is allowing domain experts to compose a system by choosing the system com-

ponents and the desired interactions between these components in a way suitable to their problem. This differs

from systems that ship with predeﬁned data sets and algorithms that are preset for a speciﬁc purpose which

may not be suitable for certain dynamic domains that require highly adaptive, and easily modiﬁable systems.

1 INTRODUCTION

Ontologies, have been gaining interest and accep-

tance in computational audiences: formal Ontologies

are a form of software, thus software development

methodologies can be adapted to serve Ontology de-

velopment.

As well, Ontology development can be

adapted to serve software development methodolo-

gies.

The premise of this paper is that no single solution

exists for all problems at hand as some domains are

faced with very dynamic problems dictated by many

parameters and environmental settings. This implies

the need for systems that can be rapidly developed and

changed to ﬁt a given task. The changes may be in al-

tering the constituent components (e.g. algorithms) or

in altering the performance and functionality of these

algorithms. The problem though is that with cur-

rent system development approaches, modifying the

system would require a substantial amount of tech-

nical proﬁciency and time while in most disciplines

(e.g. syndromic surveillance, also know as disease de-

tection, monitoring, and real-time situational aware-

ness) it may be desirable to have the very users of

the system (e.g. epidemiologists) dictate, among other

things, the algorithms suitable for a problem, the ap-

propriate data sources, and the arrangement and ﬂow

of data between the constituent algorithms. These

users may be technically na

ıve and, therefore, it may

International Conference on Knowledge En-

gineering and Ontology Development website:

http://www.keod.ic3k.org/.

be desirable for these users (domain experts) to not

concern themselves with the programming aspect of

composing the system. We therefore propose a proto-

type system that has at its core several Ontologies that

provide rich descriptions of the components of a sys-

tem thereby allowing for the autonomous creation and

modiﬁcation of systems which are problem or mission

oriented by the very domain experts who need to use

them.

2 BACKGROUND

2.1 The Semantic Web and Ontologies

The semantic web is deﬁned by Shadbolt, Hall and

Berners-Lee as a web of data as opposed to the cur-

rent web which is a web of documents (Shadbolt et al.,

2006). It is envisioned to extend the current web by

giving web content semantic meaning for the better-

ment of cooperation between computers and humans

(Dong, 2004). Central to the semantic web approach

is the use of Ontologies which play a pivotal role not

only in the advancement of the semantic web but in

knowledge sharing and management at large. These

are formal computer stored speciﬁcations of concepts

in a domain and the relationships that holds between

those concepts to provide for a common platform for

information exchange (Tjoa et al., 2005; Horridge

et al., 2007). Zhang (Zhang, 2007) asserts that an On-

tology is a rich expression of semantic relations.

254

Hlomani H. and Stacey D. (2009).

AN ONTOLOGY DRIVEN APPROACH TO SOFTWARE SYSTEMS COMPOSITION.

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development, pages 254-260

DOI: 10.5220/0002304502540260

 SciTePress

2.1.1 General Software Development

Architecture

An Ontology driven approach to software systems de-

velopment is similar to other software development

paradigms in that there has to be a guiding archi-

tecture that speciﬁes the components within the in-

tended systems and how these components relate to

each other. For the semantic web a ﬁtting architec-

ture was presented by Knublauch (Knublauch, 2004).

He differentiates between two layers of a semantic

web application. First, there is a semantic web layer

that hard-codes knowledge about a particular domain

which is then used to model the behavior of the ap-

plication. Secondly there is an internal layer which

is composed of the reasoning mechanisms and the ap-

plication’s control logic that controls the application’s

functionality and interacts with the user via an inter-

face. The prototype system discussed in this paper

takes advantage of this general architecture but how-

ever provides extended deﬁnitions of certain concepts

particularly in the application logic. This approach

will be discussed in Section 3.

2.2 Other Approaches to Systems

Composition

2.2.1 Web Services

Web services are Service Oriented Computing (SOC)

implementations that provide a standardized way of

presenting some functionality in the form of inte-

grated web-based applications using XML, SOAP,

WSDL, UDDI and other internet protocols. They

are distributed applications which can be discovered,

bound to and interactively accessed in an autonomous

manner (Charﬁ and Mezini, 2007). They have also

been deﬁned in the literature as networked capabil-

ities with openly accessible interfaces for other ma-

chines to discover and invoke in real time (Blake and

Nowlan, 2008; Milanovic and Malek, 2004). Web

Services are network, technology and platform inde-

pendent (Papazoglou, 2003) making them highly in-

teroperable. They are also loosely coupled making

the idea of reusability very attainable.

Web Services ﬁt into this discussion of system

composition in that a functional system can be devel-

oped from putting together already existing web ser-

vices in what is termed as service composition. Ser-

vice composition is a cost effective approach which

allows a developer to build a fully ﬂedged application

by using already existing components in the form of

web services. Although there may be some beneﬁt

in invoking a single web service, combining several

already existing services and ordering them to best

suit your requirements may bring added value (Charﬁ

and Mezini, 2007; Milanovic and Malek, 2004). De-

velopers therefore use service composition to rapidly

develop applications that meet users needs, meet an

organization’s goal, or provide a new service function

(Milanovic and Malek, 2004; Feenstra et al., 2007).

While service composition has advantages in the-

ory, the adoption and use of discovery protocols and

the lack of development of libraries of freely avail-

able and discoverable services has left this approach

mostly unrealized. Since web services are by def-

inition distributed and thus require distributed re-

sources, this restricts their applicability in some do-

mains where privacy and security are critical. It also

necessitates that the user be constantly connected to

the Internet. While the compositional system being

proposed in this paper does not necessarily use web

services, the utilization of distributed programs and

resources is a logical extension of our system deﬁni-

tions and thus our system is a superset of the domain

of all services/programs including web services.

3 ONTOLOGY DRIVEN

COMPOSITIONAL SYSTEM

(ODCS)

A prototype system called ODCS has been developed

that demonstrates the power and suitability of using

Ontologies as the main driver for a compositional sys-

tem both for its development and post development

functionality. By compositional system we mean a

system that allows its components to be put together

in a systematic manner to achieve a common goal or

to derive yet another functional application. This was

done by building on current research in the use of

semantic webs for application development. These

include design patterns/architectures, tools and tech-

nologies. As mentioned earlier the architecture dis-

cussed in (Knublauch, 2004) was adopted for the de-

velopment of this system (Figure 1).

Figure 1: ODCS Architecture.

AN ONTOLOGY DRIVEN APPROACH TO SOFTWARE SYSTEMS COMPOSITION

255

3.1 Ontologies

The use of Ontologies to provide domain speciﬁc

knowledge base in order to facilitate for communica-

tion and knowledge sharing between people and vari-

ous computer agents is arguably the pillar on which

the semantic web hinges. We however take it be-

yond just the facilitation of knowledge sharing. We

use this common knowledge to drive the development

of a compositional system by using the Ontologies to

provide an extensible description of the components

of a system and how they can be put together. To

achieve this we have created Ontologies to describe

algorithms that provide the needed functionality in-

cluding architectural elements and the order of exe-

cution to describe the order in which the composed

algorithms are going to be run. This section discusses

these Ontologies.

3.1.1 Algorithm Ontology

This Ontology was designed to provide an extensi-

ble standard description of algorithms in the context

of the elements or aspects of the algorithm that one

would need to know about the algorithm in order to

use the algorithm. The use of a common descrip-

tion of algorithms would allow for easier addition

and removal of algorithms from a system or applica-

tion as this will be done at the semantic level rather

than at the programming level therefore reducing de-

pendence on skilled personnel. The development of

an Ontology for algorithms, however, proved to be

more complex than initially perceived. This can be at-

tributed to the existence of diverse views and percep-

tions on classiﬁcation of algorithms. Unlike in other

domains where agreed upon taxonomies and classiﬁ-

cations already exist, the same cannot be said about

algorithms. Algorithms vary in terms of their pur-

pose, input and output requirements, and the param-

eters needed to modify their behavior. Algorithms

that use a similar problem solving approach can also

be group together to form a hierarchy. We cannot,

therefore claim absolute correctness as different lev-

els of abstractions and perceptions exists. However,

it seems more reasonable to classify algorithms ac-

cording to the reason they were designed (purpose).

The focus of this Ontology however is not to provide

a classiﬁcation of algorithms but rather we focus on

providing a generic description of the algorithms in

order to facilitate automation of the algorithms’ us-

age and provide a plug and play kind of functionality.

Such elements as the algorithm’s operating environ-

ment, algorithm type, input, output, and how it is used

are described in the Ontology.

The classes in the Ontology describe what is

needed to run an instance of an algorithm deﬁned by

the subclasses of the Algorithm class. In this On-

tology everything is a subclass of Thing including

Algorithm which can be seen as the overarching con-

cept. The algorithm concept is the very thing that all

the other classes in the Ontology describe and relate

to. We differentiate between two main classes of algo-

rithms: Computational Algorithms and Architectural

Elements. We perceive computational algorithms to

be the very algorithms that provide domain speciﬁc or

general purpose functionality. Architectural elements

are those pieces of code whose operation provide sup-

port to the computational elements and help in creat-

ing and maintaining the structure of the system.

An algorithm exists in some sort of ﬁle be it in

its source code form or as a ready to run executable

ﬁle. For this purpose we created a AlgorithmFile

class which aims at describing aspects relating to the

actual algorithm ﬁle. It deﬁnes such properties as the

ﬁle name, creation date, last updated date etc. It also

deﬁnes object properties that provide linkage to lo-

cation and operating environment classes. Each al-

gorithm executable or source code ﬁle has a speciﬁc

environment in which it can operate on. For this pur-

pose we have an OperationEnvironment class that

describes this environment. This include subclasses

to describe the operating system, drivers, and other

software needed to run the algorithm.

Subclasses specify speciﬁc types of algorithms

and deﬁne other properties that are relevant to that

speciﬁc type. Figure 2 depicts this kind of hi-

erarchical structure of the class. If the system

has to search for a statistical algorithm the re-

sults could be an instance of any of the subclasses

of the statistical algorithms e.g. an instance of an

EMAAlgorithm class since its instance is an instance

of StatisticalAlgorithm due to inheritance. This

inheritance structure allows the class to be extended

when a new algorithm type deﬁnition is needed.

Figure 2: Overview of the Algorithm class hierarchy.

Most algorithms take in some sort of input, there-

fore for every instance of an algorithm there must be

KEOD 2009 - International Conference on Knowledge Engineering and Ontology Development

256

an indication of whether it receives any input and a

precise deﬁnition of how the input is received. The

Input class provides these descriptions. Input to an

algorithm may be in the form of data ﬁles read by the

algorithm, command line parameters passed through

the input stream to the algorithm or read from conﬁg-

uration ﬁles. These are described by further deﬁn-

ing subclasses of the Input class. For example, a

Parameters class is deﬁned and its subclasses are

then deﬁned to include the CommandLine class that

describes the parameters passed through the input

stream to the algorithm and ConfigurationFiles

class that describes parameters read from conﬁgura-

tion ﬁles. These subclasses can also be further sub-

classed to provide needed details. This is depicted by

Figure 3.

Figure 3: Overview of the Input class hierarchy.

When composing a system by combining algorithms

together through their input streams and output stream

several incompatibilities may exist some of these in-

clude data type mismatches and data stream mis-

matches. The architectural elements class within the

algorithms Ontology therefore serves to provide a

generic description of these internal glue elements of

the system. Data type converters are components of

a compositional system that offers data conversion to

facilitate compatibility between algorithms. Convert-

ers are algorithms in that they are standalone pieces

of code that can be fed input and run to produce some

output. An example mismatch is that of different data

stream types feeding into and out of a pipe. One al-

gorithm may be printing output to the standard stream

while the algorithm it connects to expects input from

a ﬁle. Therefore rather than just declaring the connec-

tion to be impossible an architectural element would

be placed between these two algorithms to satisfy

both algorithms’ requirements. In this case the ele-

ment would be reading data from the standard stream

and writing it to a ﬁle so that the next algorithm can

read the ﬁle.

3.1.2 Execution Timeline Ontology

Ultimately the composed system will be run. To fa-

cilitate ﬂexibility and extensibility we have developed

an Ontology that describes how the events within the

composed system will be run. Please refer to section

3.4 for a detailed discussion on the individual ele-

ments of a timeline. The basic functionality of this

Ontology is to describe the order in which the con-

nected algorithms will be executed. The Ontology de-

ﬁnes this order in the form of a Timeline class that

has a number of intervals. The Interval class has

a collection of start and end triggers and a number

of events. The Event class also has begin and end

triggers. Speciﬁc triggers are deﬁned as subclasses

of the Trigger class. Triggers could for example be

performing the function of checking for preconditions

and postcondition of an event or an interval or speci-

fying what the next process (event or interval) to run

is. The Ontology also deﬁnes exit points within each

event, interval and timeline in the form of errors han-

dlers.

3.2 Class Libraries

The system discussed in this paper along with many

other semantic web enabled applications is driven by

a number of core Ontologies. Their functionality re-

lies on the querying of ontological instances and their

property values. This include the use of reasoning en-

gines (in this case FaCt++) to infer some knowledge

which was perhaps never explicitly asserted. Two al-

ternative approaches to achieving this knowledge ac-

quisition from Ontologies exists. Generic OWL pars-

ing APIs such as Jena and Prot

e-OWL can be used

to directly interact with the Ontology. These provide

a model in which OWL instances and their proper-

ties are saved using generic Java classes (Knublauch,

2004). As the application grows these may be ren-

dered inconvenient since access to OWL objects is

done through specifying the objects’ names often as

strings. This is rather hard to maintain. Another ap-

proach which is deemed to be the better of the two

and adopted in this work is one in which in addi-

tion to using generic APIs, access to the ontological

facets is done through custom made Java classes that

resemble the structure of the Ontology. This does not

only allow seamless access to the Ontology but also

provide cleaner object oriented design patterns. This

class library consists of deﬁnitions of interfaces and

classes that implements these interfaces. The inter-

face is a normal Java interface that deﬁnes mandatory

properties and methods that should be implemented

by classes that commits to using this interface. The

power of interfaces will be discussed in Section 3.2.2

where such issues as multiple inheritance will be ex-

amined.

AN ONTOLOGY DRIVEN APPROACH TO SOFTWARE SYSTEMS COMPOSITION

257

3.2.1 Generation of Class Libraries

The creation of custom Java classes that map to the

Ontology classes is not a trivial process but one can

manually create them. However, there exists code

generators that can be used to ease this rather intri-

cate process. This Java code generation capability

does exist within the Prot

e-OWL editor and it was

used for the generation of the Access Class Libraries

used for the development of this system. Several other

code generators exist; examples include OWL2Java

and Jastor (Zimmermann, 2009; Szekely, 2009). The

primary reason for the use of a Java class code genera-

tor was to delegate this task to mechanisms that would

do it instantly and hence save considerable amounts

of time. However, the code was then manual ex-

amined to identify omissions and physically amend

faults. These code generators are designed to create

a set of Java interfaces and implementation classes

from OWL Ontologies such that an instance of a Java

class represents an instance of an OWL class within

the Ontology. As will be discussed in the section that

follows the code generators may not represent all the

classes and constraints within the Ontology solely be-

cause of the difference between Java and OWL. Man-

ual inspection of the generated code and writing of

the omitted concept may still have to be performed.

3.2.2 OWL to Java Mismatches and their Fixes

It would have been ideal to have a one-to-one map-

ping of the Java classes to the OWL Ontology

classes including their properties and asserted restric-

tions. However due to signiﬁcant differences inherent

within these languages this may not be attainable and

therefore alternative ways need to be devised to min-

imize the impact of these differences. One of the ma-

jor omissions by the code generator in our case was

a someValuesFrom restriction placed on several data

and object properties. The purpose of this restriction

was to constraint the creation of property values to

certain pre-listed classes and class instances. This im-

plies enumerated classes. Enumerated classes are ig-

nored by code generators since they are anonymous

classes. This has little impact on our system since our

primary focus is not on the creation of Ontology in-

stances but rather their use to drive the development

of a compositional system and in the cases where the

population of the Ontology is done through an On-

tology editor like Prot

e this limitation would not

be applicable. It would however be quite important

for an application that alters the Ontology instances

to handle this variation.

We do however recognize solutions and mappings

provided in (Kalyanpur et al., 2004). The paper sug-

gests two rather simple solutions. The ﬁrst solution

involves the deﬁnition of an enum, struct or a list ob-

ject that contains possible values for the property. The

method that creates the property value will then loop

through the enum checking to see if the new value is

one of the possible values contained in the enum. The

second solution is somewhat similar to the ﬁrst one

but it instead makes use of listeners registered on the

restricted property which are invoked every time the

property is changed.

Java is a single inheritance object oriented lan-

guage while OWL is a very rich and highly expressive

description logic based language that supports multi-

ple inheritance. Java does not support what may be

referred to as multiple implementation inheritance. It

however allows a class to implement multiple inter-

faces. This is a feature that can be exploited to model

classes that have two or more super-classes. We have

however, managed to get away with not using multi-

ple inheritance in the implementation of our Ontolo-

gies so this remains a feature that can be explored

should the Ontology evolve and have classes that in-

herit from several other classes.

3.3 Data Flow

Our idea revolves around pulling already existing al-

gorithms and connecting them into a functional sys-

tem. We therefore developed a framework to facil-

itate this connectivity and the ﬂow of data between

algorithms. This was achieved by developing a col-

lection of classes that deﬁnes a TaskGraph, Task,

Nodes and Connectors. A Task is a representation

of a unit that performs some function. For the pur-

pose of this prototype system this can be in the form

of an algorithm, a converter or any of the architectural

elements. A Task is created when the user chooses

an algorithm or when an architectural element is in-

voked to provide for compatibility of the algorithms.

A TaskGraph on the other hand is a collection of con-

nected tasks. Nodes represent the inputs and outputs

to an algorithm, converter or an element. They can

take the form of ﬁle input and output nodes, standard

input or output stream nodes, socket nodes and pa-

rameter nodes. We also deﬁne a Connector class that

describes methods needed to establish a connection

between algorithms. The possibility or absence of a

connection being established between selected algo-

rithms depends upon the compatibility of these out-

put and input nodes. The connectivity also depends

upon the availability of a glue component (either a

converter or element) that will be placed in between

the algorithms in case the algorithms nodes are in-

compatible.

KEOD 2009 - International Conference on Knowledge Engineering and Ontology Development

258

3.4 Execution Timeline

Once a TaskGraph has been established a walk

through the TaskGraph will be done to extract

and create events thereby creating an execution

Timeline. This creation and ordering of events is de-

pendent on the type of output and input of the send-

ing and receiving algorithms. To illustrate this con-

sider Figure 4. The ﬁgure depicts a TaskGraph that

Figure 4: An example TaskGraph and the extraction of

Events.

has three connected Tasks. Task A pipes its input

into Task B (this is possible since A prints to the

output stream and B reads from the input stream).

Task B then writes its output to a ﬁle. Algorithm

C then reads the ﬁle and produces output of its own.

This implies two Events: ﬁrst Task A and B are

run concurrently piping A’s output to B and the out-

put of B is written to a ﬁle; secondly Task C runs,

reads the ﬁle produced by B and produces output. In

this example scenario, the Timeline deﬁnition would

have one Interval. The Interval would have one

start Trigger that deﬁnes the next process to be run

(Event 1) and the two Events. Event 1 would have

an end Trigger that speciﬁes Event 2 as the next

process to run. Event 2 on the other hand would have

a start Trigger that checks for the existence of the in-

put ﬁle before it could start otherwise the Event will

terminate with an appropriate error and ultimately the

Timeline will terminate too. The Interval will also

have an end Trigger that signals that the Interval

is the last within the given Timeline and therefore

providing an end point for the Timeline.

Figure 4 is an example of a pipes and ﬁlters archi-

tecture. This architectural style is a data ﬂow archi-

tecture that concerns itself primarily with the move-

ment of data between data processing elements (Tay-

lor et al., 2008). To better deﬁne a pipes and ﬁlters ar-

chitecture we ﬁrst deﬁne the components. Filters are

deﬁned by (Taylor et al., 2008) as preexisting com-

ponents/programs that consume data from the input

stream and produce data through the output stream.

Their basic function is to perform arbitrary process-

ing of data that may include transformation of the data

and enrichment. Pipes are deﬁned as connectors that

interconnect two ﬁlters by offering buffering func-

tionality and routing of the ﬁrst ﬁlter’s output stream

to the input stream of the second ﬁlter. It goes without

saying then that a pipes and ﬁlters architecture is an

architectural style that deﬁnes several executable pro-

grams (ﬁlters) that are executed possibly concurrently

and employing pipes to route data streams between

the programs. This type of architecture allows for the

creation of applications even by people without prior

software development training. This architectural pat-

tern is trivial to construct from the ODSC Ontologies

and can itself be stored in an Ontology that describes

architectural design patterns.

4 DISCUSSION

An Ontology driven system offers several advantages.

The users of the system has overall control of the sys-

tem. They have control over what algorithms are in-

cluded and excluded from their system. They how-

ever need not have any technical/programming skills

to be able to add or remove an algorithm from their

system. They may however need to have an under-

standing of Ontologies since this will be where most

modiﬁcations will take place. The whole approach

itself allows for possibilities that may have other-

wise not been possible following other software de-

velopment methodologies. A fully functioning sys-

tem can be rapidly developed by a non-technical user

and changed on the ﬂy without the aid of a techni-

cal professional. Technical personnel can devote their

time on developing algorithms that users may require

since new and already existing algorithms can be pub-

lished onto the Ontology thereby allowing them to be

ported and used in the system. The complexity or sim-

plicity of the system is dictated by the user as he/she

designs the system by selecting and connecting algo-

rithms into complex or simple combinations that are

suited for their purpose. The timeline Ontology and

framework also allows for several architectures to be

achieved depending on the needs of the application.

Events can be run concurrently and branching from

one set of events to another can also be achieved al-

lowing for ﬂexibility in the functionality and structure

of the application.

The prototype ODCS described in this paper does

not yet include a user interface to allow for simple

manipulation of the Ontologies by a non-technical do-

main expert. The interface is by design left as a de-

tachable module since it should be custom designed

to ﬁt the abilities, expectations and conceptual frame-

AN ONTOLOGY DRIVEN APPROACH TO SOFTWARE SYSTEMS COMPOSITION

259

work of the user’s domain of expertise. While the

interface may change, the underlying algorithms and

architectures captured in the Ontologies are available

for use by multiple domains. This will allow many ap-

plication areas to share algorithms developed for dif-

ferent domains. For example, there are many pattern

recognition and datamining algorithms developed by

the machine intelligence community that are often

overlooked by users in domains such as epidemiol-

ogy, economics, etc. and thus their applications are

unnecessarily limited. A system such as ODCS could

make a world of specialist algorithms and techniques

available to a much wider range of domains and users

than is now possible.

5 CONCLUSIONS

In this paper we highlighted the problems of conven-

tionally developed systems with predeﬁned data sets

and algorithms that are preset for a particular purpose.

We highlighted that these systems may not be suitable

for dynamic domains whose environment, parame-

ters and needs change rapidly. We then explored how

an Ontology driven approach to software composition

can be used to drive the creation of adaptive systems.

We speciﬁcally discussed ODCS, a prototype system

that follows this approach. It is safe then to conclude

that an Ontology driven system offers many advan-

tages and is suited for dynamic domains that require

systems that can be changed with ease by their users.

REFERENCES

Blake, M. and Nowlan, M. (2008). Taming web services

from the wild. IEEE Internet Computing, 12(5):62–

69.

Charﬁ, A. and Mezini, M. (2007). Ao4bpel: An

aspect-oriented extension to bpel. World Wide Web,

10(3):309–344.

Dong, J. (2004). Software modeling techniques and the se-

mantic web. In Proceedings of the 26th International

Conference on Software Engineering, pages 1160–

1163.

Feenstra, R., Janssen, M., and Wagenaar, R. (2007). Evalu-

ating web composition methods: The need for includ-

ing multi-actor elements. The Electronic Journal of

E-Government, 15(2):153–164.

Horridge, M., Jupp, S., Moulton, G., Rector, A., Stevens,

R., and Wroe, C. (2007). A practical guide

to building owl ontologies using the Protege-

OWL Plugin and CO-ODE Tools, 1.1 edition.

Retrieved June 25, 2009, from http://www.co-

ode.org/resources/tutorials/ProtegeOWLTutorial-

p4.0.pdf.

Kalyanpur, A., Pastor, D. J., Battle, S., and Padget, J.

(2004). Automatic mapping of owl ontologies into

java. In 16th International Conference on Software

Engineering and Knowledge Engineering, pages 98–

103.

Knublauch, H. (2004). Ontology-driven software develop-

ment in the context of the semantic web: An example

scenario with protege-owl. In International Workshop

on the Model-Driven Semantic Web.

Milanovic, N. and Malek, M. (2004). Current solutions for

web service composition. IEEE Internet Computing,

8(6):51–59.

Papazoglou, M. (2003). Service oriented computing: Con-

cepts, charecteristics and directions. In Fourth Inter-

national Conference on Web Information Systems En-

gineering, pages 3–12.

Shadbolt, N., Hall, W., and Berners-Lee, T. (2006). The

semantic web revised. IEEE Intelligent Systems,

21(3):96–101.

Szekely, B. (2009). Jastor: Typesafe, Ontology Driven RDF

Access from Java. Retrieved June 25, 2009, from

http://jastor.sourceforge.net/.

Taylor, R., Medvidovic, N., and Dashofy, E. (2008). Soft-

ware Architecture Foundations, Theory, and Practice.

John Wiley and Sons Inc.

Tjoa, A., Andjomshoaa, A., Shayeganfar, F., and Wagner,

R. (2005). Semantic web challenges and new require-

ments. In Proceedings of the 16th International Work-

shop on Databases and Expert Systems Applications,

pages 1160–1163.

Zhang, J. (2007). Ontology and the semantic web. In

Proceedings of the North American Symposium on

Knowledge Organization, pages 9–20.

Zimmermann, M. (2009). Owl2Java - A Java Code

Generator for OWL. Retrieved June 25, 2009, from

http://www.incunabulum.de/projects/it/owl2java/

owl2java-a-owl2java-generator.

KEOD 2009 - International Conference on Knowledge Engineering and Ontology Development

260
