MINING FOR RELEVANT TERMS FROM LOG FILES

Hassan Saneifar

1,2

, St´ephane Bonniol

, Anne Laurent

, Pascal Poncelet

and Mathieu Roche

Laboratoire d’Informatique, de Robotique et de Micro´electronique de Montpellier (LIRMM)

Univ. Montpellier 2 - CNRS

161 rue Ada, 34392 Montpellier Cedex 5, France

Satin IP Technologies

Cap Omega, RP Benjamin Franklin, 34960 Montpellier Cedex 2, France

Keywords:

Natural language processing, Information retrieval, Terminology extraction, Terminology ranking, Log ﬁles.

Abstract:

The Information extracted from log ﬁles of computing systems can be considered one of the important re-

sources of information systems. In the case of Integrated Circuit design, log ﬁles generated by design tools

are not exhaustively exploited. The logs of this domain are multi-source, multi-format, and have a heteroge-

neous and evolving structure. Moreover, they usually do not respect the grammar and the structures of natural

language though they are written in English. According to features of such textual data, applying the classical

methods of information extraction is not an easy task, more particularly for terminology extraction. We have

previously introduced EXTERLOG approach to extract the terminology from such log ﬁles. In this paper, we

introduce a new developed version of EXTERLOG guided by Web. We score the extracted terms by a Web and

context based measure. We favor the more relevant terms of domain and emphasize the precision by ﬁltering

terms based on their scores. The experiments show that EXTERLOG is well-adapted terminology extraction

approach from log ﬁles.

1 INTRODUCTION

In many applications, computing systems generate re-

ports automatically. These digital reports, also known

as system logs, represent the major source of infor-

mation on the status of systems, products, or even the

causes of problems that can occur. Although log ﬁles

are generated in every ﬁeld of computing, the charac-

teristics of these logs, particularly the language, struc-

ture and context, differ from system to system. In

some areas, such as IntegratedCircuit (IC) design sys-

tems, the log ﬁles are not systematically exploited in

an effective way whereas in this particular ﬁeld, the

log ﬁles generated by IC design tools, contain essen-

tial information on the condition of production and

the ﬁnal products. In this context, a key challenge

is to provide approaches which consider the multi-

source, heterogeneous and scalable structures of log

ﬁles as well as their special vocabulary. Further-

more, although the contents of these logs are similar

to texts written in Natural Language (NL), they com-

ply neither with the grammar nor with the NL struc-

ture. Therefore, In order to extract information from

the logs, we need to adapt Natural Language Process-

ing (NLP) and Information Extraction (IE) techniques

to the speciﬁc characteristics of such textual data. An-

other key challenge is evaluation of results. In fact,

according to the particularity of such data, and then

due to the high noise ratio in results, the classic eval-

uation methods are not necessarily relevant. To em-

phasize the precision of results as a must according to

the accuracy of context, we have to deﬁne the noise

ﬁltering method which comply with the particularity

of such data.

The creation of a domain ontology is a primor-

dial need for our future work on information extrac-

tion from log ﬁles. Deﬁning the vocabulary of do-

main is one of the ﬁrst steps of building an ontology.

To analyze vocabulary and lexical structure of a cor-

pus, extraction of domain terminology is one of the

most important phases. We thus aim at extracting the

terminology of log ﬁles. The extracted terms will be

used in the creation of domain ontology in our future

works. Also, we will use extracted terms to study the

Saneifar H., Bonniol S., Laurent A., Poncelet P. and Roche M. (2009).

MINING FOR RELEVANT TERMS FROM LOG FILES.

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval, pages 77-84

DOI: 10.5220/0002307200770084

 SciTePress

different lexical structures of different logs in order to

enrich our information extraction methods. In this pa-

per, we introduce a new version of our approach EX-

TERLOG (EXtraction of TERminology from LOGs),

previously presented in (Saneifar et al., 2009), that is

developed to extract the terminology from these log

ﬁles. In this approach, we study how to adapt the ex-

isting terminology extraction methods to the particu-

lar and heterogeneous features of log ﬁles. We also

present in this paper a ﬁltering method of extracted

terms based on a ranking score in order to emphasize

the precision of extracted relevant terms.

In Sect. 2, we detail the utility of building domain

ontology and thus the terminology extraction in our

context and the special features and difﬁculties of this

domain. Our approach EXTERLOG is developed in

Sect. 3. Section 4 describes and compares the vari-

ous experiments that we performed to extract terms

from the logs and specially to evaluate the precision

of EXTERLOG.

2 CONTEXT

Today, digital systems generate many types of log

ﬁles, which give essential information on the sys-

tems. Some types of log ﬁles, like network moni-

toring logs, web services interactions or web usage

logs are widely exploited (Yamanishi and Maruyama,

2005)(Facca and Lanzi, 2005). These kinds of log

ﬁles are based on the management of events. That is,

the computing system, which generates the log ﬁles,

records the system events based on their occurring

times. The contents of these logs comply with norms

according to the nature of events and their global us-

age (e.g. web usage area).

However, in some areas such as integrated cir-

cuit design systems, rather than being some recorded

events, the generated log ﬁles are digital reports on

conﬁguration, condition and states of systems. The

aim of the exploitation of these log ﬁles is not to an-

alyze the events but to extract information about sys-

tem conﬁguration and especially about the ﬁnal prod-

uct’s condition. Hence, log ﬁles are considered an

important source of information for systems designed

to query and manage the production. Information ex-

traction in log ﬁles generated by IC design tools has

an attractive interest for automatic management and

monitoring of IC production. However, several as-

pects of these log ﬁles have been less emphasized in

existing methods of text mining and NLP. These spe-

ciﬁc characteristics raise several challenges that re-

quire more research.

2.1 IE & Log Files

To use these logs in an information system, we must

implement information extraction methods which are

adapted to the characteristics of these logs. Moreover,

these features explain why we need a domain ontol-

ogy to extract information from the log ﬁles.

In the ﬁeld of integrated circuits design, several

levels need to be considered. At every level, different

design tools can be used which make the generated

log ﬁles the multi-source data. Despite the fact that

the logs of the same design level report the same

information, their structures can differ signiﬁcantly

depending on the design tool used. Speciﬁcally, each

design tool often uses its own vocabulary to report

the same information. In the veriﬁcation level, for

example, we produce two log ﬁles (e.g. log “A” and

log “B”) by two different tools. The information

about, for example, the “

Statement coverage

” will

be expressed as follows in the log “A”:

TOTAL COVERED PERCENT

Lines 10 11 12

statements 20 21 22

But the same information in the log “B”, will be dis-

closed from this single line:

EC: 2.1%

As shown above, the same information in two log

ﬁles produced by two different tools is represented by

different structures and vocabulary. Moreover, design

tools evolve over time and this evolution often occurs

unexpectedly. Therefore, the format of the data in the

log ﬁles changes, which make the automatic manage-

ment of data difﬁcult. The heterogeneity of data exists

not only between the log ﬁles produced by different

tools, but also within a given log ﬁle. For example,

the symbols used to present an object, such as the

header for tables, change in a given log. Similarly,

there are several formats for punctuation, the separa-

tion lines, and representation of missing data. There-

fore, we need intelligent and generalized methods,

which can be applied at the same time on different

logs (multi-source textual data) which have the multi-

format and heterogeneous data. These methods must

also take into account the variable vocabulary of these

logs. To generalize the extraction methods, we thus

need to identify the terms used by each tool in order

to create the domain ontology. This ontology allows

us to better identify equivalent terms in the logs gen-

erated by different tools and so to reduce the hetero-

geneity of data. For instance, to check “

Absence of

Attributes

” as a query on the logs, one must search

for the following different sentences in the logs, de-

pending on the version and type of design tool used:

KDIR 2009 - International Conference on Knowledge Discovery and Information Retrieval

•

"Do not use

map to module

attribute

•

"Do not use

one cold

one hot

attributes

•

"Do not use

enum encoding

attribute

Instead of using several patterns, each one

adapted for a speciﬁc sentence, by associating

the words “

map to module attribute

”, “

one hot

attributes

” and “

enum encoding attribute

” to

the concept “

Absence of Attributes

”, we use a

general pattern that expands automatically according

to different logs using the domain ontology. The

ontology-driven expansion of query is studied in

many works, see (Voorhees, 1994)(Dey et al., 2005).

The ontology will allow us to better identify

equivalent terms in the logs generated by differ-

ent tools. Several approaches are based on the do-

main ontology to better guide the information extrac-

tion (Even and Enguehard, 2002). An ontology also

deﬁnes the common vocabulary of a domain (Moll´a

and Vicedo, 2007). In our context, the domain ontol-

ogy allows us to categorize the terms associated with

a concept sought on the logs. The creation of ontol-

ogy requires a lexical analysis of a corpus to identify

the terms of the domain. We hence seek to identify

the terms of the logs of every design tool. We will

then look at these terms in order to make the cor-

respondence between them and to create the domain

ontology. Thus, we aim at studying the extraction of

terminology from log ﬁles.

Also, the language used in these logs is a difﬁ-

culty that affects the methods of information extrac-

tion. Although the language used in these logs is En-

glish, the contents of these logs do not usually comply

with “classic” grammar. Moreover, there are words

that are often constituted from alphanumeric and spe-

cial characters.

Due to these speciﬁc characteristics of log ﬁles,

the methods of NLP, including the terminology ex-

traction, developed for texts written in natural lan-

guage, are not necessarily well suited to the log ﬁles.

2.2 Terminology Extraction

Background

The extraction of domain terminology from the tex-

tual data is an essential task to establish specialized

dictionary of a domain (Roche et al., 2004). The ex-

traction of co-occurring words is an important step in

identifying the terms. To identify the co-occurrences,

some approaches are based on syntactic techniques

which rely initially on the grammatical tagging of

words. The terminological candidates are then ex-

tracted using syntactic patterns (e.g. adjective-noun,

noun-noun). We develop the grammatical tagging of

log ﬁles using our approach EXTERLOG in Sect. 3.2.

Bigrams

are used in (meng Tan et al., 2002) as

features to improve the performance of the text clas-

siﬁcation. The series of three words (i.e. trigrams) or

more is not always essential (Grobelnik, 1998). The

deﬁned rules and grammar are used in (David and

Plante, 1990) in order to extract the nominal terms

as well as to evaluate them. The machine learning

methods based on Hidden Markov Models (HMMs)

are used in (Collier et al., 2002) to extract termi-

nology in the ﬁeld of molecular biology. EXIT, in-

troduced by (Roche et al., 2004) is an iterative ap-

proach that ﬁnds the terms in an incremental way. A

term found in an iteration is used in the next one to

ﬁnd more complex terms. Some works try to extract

the co-occurrences in a ﬁxed size window (normally

ﬁve words). In this case, the extracted words may

not be directly related (Lin, 1998). XTRACT avoids

this problem by considering the relative positions of

co-occurrences. XTRACT is a terminology extrac-

tion system, which identiﬁes lexical relations in the

large corpus of English texts (Smadja, 1993). SYN-

TEX, proposed by (Bourigault and Fabre, 2000), per-

forms syntactic analysis of texts to identify the names,

verbs, adjectives, adverbs, the noun phrases and ver-

bal phrases. It analyses the text by applying syntactic

rules to extract terms.

As described above, we have previously studied

the extraction of terminology based on identifying the

co-occurring words without using the syntactic pat-

terns from log ﬁles (see (Saneifar et al., 2009)). As

explained in (Saneifar et al., 2009), the terminology

extraction based on syntactic patterns is quite relevant

to the context of log ﬁles. We shown that the accu-

racy of terms extracted based on syntactic patterns is

indeed higher than the precision of bigrams extracted

without such patterns. Despite the fact that normaliza-

tion and tagging the texts of logs is not an easy task,

our previous experiments show that an effort in this

direction is useful in order to extract quality terms.

But according to the need of high accuracy in this do-

main and the fact that manual validation of terms by

an expert is expensive, we develop here the automatic

evaluation phase of EXTERLOG. This evaluation of

terms is detailed in Section 3.4.

The statistical methods used are generally asso-

ciated with syntactic methods for evaluating the ad-

equacy of terminological candidates (Daille, 2003).

These methods are based on statistical measures such

as information gain to validate an extracted candidate

N-grams are deﬁned as the series of any “n” words.

MINING FOR RELEVANT TERMS FROM LOG FILES

as a term. Among these measures, the occurrence

frequency of candidates is a basic notion. However,

these statistical methods are not relevant to be applied

on the log ﬁles. Indeed, statistical approaches can

cope with high frequency terms but tend to miss low

frequency ones (Evans and Zhai, 1996). According to

the log ﬁles described above, the repetition of words

is rare. Each part of a log ﬁle contains some informa-

tion independent from other parts. In addition, it is

not reasonable to establish a large corpus of logs by

gathering log ﬁles generated by the same tool at the

same level of design. Since, it just results the redun-

dancy of words. Evaluation of terms based on some

other resources like as web is studied by many works.

The Web, as a huge corpus, is more and more used in

NLP methods specially in validation of results. How-

ever, in our context, we study the corpus of a very

specialized domain. The terms used in this domain

are the specialized terms and not frequently seen on

the Web. Then, we could not use the classic statis-

tical measures based on simple frequencies of terms

in corpus in order to give a score to every extracted

term. Furthermore, our approach aims at reducing the

noise ratio in results, thus emphasizing the precision,

by ﬁltering the extracted terms using a web based sta-

tistical measures which considers in the same time the

context of log ﬁles. We detail this aspect in Sect. 3.4.

A lot of works compare the different techniques

of terminology extraction and their performance. But

most of these studies are experimented on textual

data, which are classical texts written in natural lan-

guage. Most of the corpus that are used are struc-

tured in a consistent way. In particular, this textual

data complies with the grammar of NL. However, in

our context, the characteristics of logs (such as not to

comply with natural language grammar, their hetero-

geneous and evolving structures (cf. Sect. 2)) impose

an adaptation of these methods to ensure that they are

relevant for the case of log ﬁles.

3 EXTERLOG: EXTRACTION OF

TERMINOLOGY FROM LOGS

Our approach, EXTERLOG, is developed to extract the

terminology in the log ﬁles. The extraction process

involves normalization, preprocessing of log ﬁles and

grammatical tagging of word in order to extract the

terms. EXTERLOG contains also a ﬁltering phase of

extracted terms based on a scoring measure.

3.1 Preprocessing & Normalization

The heterogeneity of the log ﬁles is a problem, which

can affect the performance of information extraction

methods. In order to reduce the heterogeneity of data

and prepare them to extract terminology, we apply

a series of preprocessing and normalization on the

logs. Given the speciﬁcity of our data, the normal-

ization method, adapted to the logs, makes the format

and structure of logs more consistent. We replace the

punctuations, separation lines and the headers of the

tables by special characters to limit ambiguity. Then,

we tokenize the texts of logs, considering that certain

words or structures do not have to be tokenized. For

example, the technical word “

Circuit4-LED3

” is a

single word which should not be tokenized into two

words “Circuit4” and “LED3”. Besides, we distin-

guish automatically the lines representing the header

of tables from the lines which separate the parts. Af-

ter the normalization of logs, we have less ambiguity

and less common symbols for differentconcepts. This

normalization makes the structure of logs produced

by different tools more homogeneous.

3.2 Grammatical Tagging

Grammatical tagging (also called part-of-speech tag-

ging) is a method of NLP used to analyse the text ﬁles

which aims to annotate words based on their gram-

matical roles. In the context of log ﬁles, there are

some difﬁculties and limitations for applying a gram-

matical tagging on such textual data.

Indeed, the classic techniques of POS tagging are de-

veloped using the standard grammar of natural lan-

guage. In addition, they are normally trained on texts

written in a standard natural language, such as jour-

nals. Therefore, they consider that a sentence ends

with a fullstop, for example, which is not the case

in the log ﬁles that we handle. More speciﬁcally, in

these log ﬁles, sentences and paragraphs are not al-

ways well structured. Besides, there are several con-

structions that do not comply with the structure of

sentences in natural language. To identify the role

of words in the log ﬁles, we use BRILL rule-based

part-of-speech tagging method (Brill, 1992). Since

existing taggers like BRILL are trained on general

language corpora, they give inconsistent results on

the specialized texts. (Amrani et al., 2004) propose a

semi-automatic approach for tagging corpora of spe-

ciality. They build a new tagger which corrects the

base of rules obtained by BRILL tagger and adapt it

to a corpus of speciality. In the context of log ﬁles, we

need also to adapt BRILL tagger just as in (Amrani

et al., 2004). We thus adapted BRILL to the context

KDIR 2009 - International Conference on Knowledge Discovery and Information Retrieval

of log ﬁles by introducing the new contextual and lex-

ical rules. Since, the classic rules of BRILL, which

are deﬁned according to the NL grammar, are not rel-

evant to log ﬁles. For example, a word beginning

with a number is considered a “cardinal” by BRILL.

However, in the log ﬁles, there are many words like

12.1vSo10

that must not be labelled as “cardinal”.

Therefore, we deﬁned the special lexical and con-

textual rules in BRILL. The structures of log ﬁles

can contribute important information for extracting

the relevant patterns in future works. Therefore, we

preserve the structure of ﬁles during grammatical tag-

ging. We introduce the new tags, called “Document

Structure Tags”, which present the different structures

in log ﬁles. For example, the tag “\TH” represents the

header of tables or “\SPL” represents the lines sepa-

rating the log parts. The special structures in log ﬁles

are identiﬁed during normalization by deﬁned rules.

Then, they are identiﬁed during tagging by the new

speciﬁc contextual rules deﬁned in BRILL. We ﬁnally

get the logs tagged by the grammatical roles of words

and also by the labels that determine the structure of

logs.

3.3 Extraction of Co-occurrences

We extract the co-occurrences in the log ﬁles respect-

ing a deﬁned part-of-speech syntactic pattern. We

call the co-occurrences extracted using syntactic pat-

tern “POS-candidates”

. The syntactic patterns deter-

mine the adjacent words with the deﬁned grammatical

roles. The syntactic patterns are used in (Daille, 2003)

and (Bourigault and Fabre, 2000) to extract terminol-

ogy. As argued in (Daille, 2003), the base structures

of syntactic patterns are not frozen structures and ac-

cept variations. According to the terms found in our

context, the syntactic patterns that we use to extract

the “POS-candidates” from log ﬁles are:

“\JJ - \NN” (Adjective-Noun),

“\NN - \NN” (Noun-Noun).

These extracted terms at this phase must be scored to

favor the most relevant terms of the domain.

3.4 Filtering of Candidates

All the extracted terms are not necessarily the rel-

evant terms of the domain. Because of some huge

log ﬁles and the large vocabulary of the logs, there

exists so many extracted terms. Also, according

to the particular features of such data, in spite of

adapted normalization and tagging methods that we

used, there exists some noise (no relevant terms) in

POS: Part-Of-Speech

the extracted terms. Moreover, we are focused on a

specialized domain where just some terms are really

bidden to the domain’s context. Thus, we score, rank

and then ﬁlter the extracted terms in order to favor

the most relevant terms according to the context. The

statistical measures are often used in terminology

extraction ﬁeld to evaluate the terms (see (Daille,

1996)). The following ones are the most widely used.

Mutual Information. One of the most commonly

used measures to compute a sort of relationship be-

tween the words composing what is called a co-

occurrence is Church’s Mutual Information (MI)

(Church and Hanks, 1990). The simpliﬁed formula

is the following where nb designates the number of

occurrences of words and couples of words:

MI(x, y) = log

nb(x, y)

nb(x)nb(y)

Cubic Mutual Information. The Cubic Mutual

Information is an empirical measure based on MI,

that enhances the impact of frequent co-occurrences,

something which is absent in the original MI (Daille,

1994).

MI3(x, y) = log

nb(x, y)

nb(x)nb(y)

This measure is used in several works related to noun

or verb terms extraction in texts (Roche and Prince,

2007).

Dice’s Coefﬁcient. An interesting quality measure is

Dice’s coefﬁcient (Smadja et al., 1996). It is deﬁned

by the following formula based on the frequency of

occurrence.

Dice(x, y) =

2× nb(x, y)

nb(x) + nb(y)

These measures are based on the occurrence frequen-

cies of terms in corpus. Scoring the terms based on

frequencies of terms in corpus of logs is not a rele-

vant approach in our context. As we have already ex-

plained, the techniques based on frequency of terms

in a corpus (e.g. pruning terms having low frequency)

are not relevantto this context as a representative term

does not necessarily havea high frequency in log ﬁles.

That is why we score the terms according to their

frequencies on the Web as a large corpus where fre-

quency of a term can be representative. Working on

a specialized domain, we have bias scores based on

the simple count of occurrences of a term on Web.

Indeed, on Web, we capture occurrences of terms re-

gardless of the context in which they are seen. Thus,

we should consider only the occurrences of terms

MINING FOR RELEVANT TERMS FROM LOG FILES

on web which are situated in the IC design context.

We use therefore an extension of described measures

called AcroDef. AcroDef is a quality measure where

context and Web resources are essential characteris-

tics to be taken into account (see (Roche and Prince,

2007)). The below formulas deﬁne the AcroDe f mea-

sures, respectively based on MI and Cubic MI.

AcroDef

) =

nb(

i=1

+C)

∏

i=1

nb(a

+C|a

6∈ M

stop−words

)

where n ≥ 2

AcroDef

MI3

) =

nb(

i=1

+C)

∏

i=1

nb(a

+C|a

6∈ M

stop−words

)

where n ≥ 2

In AcroDef, the context “C” is represented as

a set of signiﬁcant words. The nb function used

in the preceding measures represents the number of

pages provided by the search engine to given query.

Then nb(a

+C) returns the number of pages apply-

ing query a

+ C which means all words of the term

in addition to those of context C. In our case, for

example, for a term x

like “atpg patterns” consist-

ing of two words (so i = 2), nb(atpg

patterns+C)

is the number page returned by applying query “atpg

pattern” AND C on a search engine, where C is a set

of words representing the context. The AcroDef

Dice

formula based Dice’s formula is written as follows:



+C|a

6∈ M

stop−words

}

i∈[1,n]



× nb(

i=1

+C)

∑

i=1

nb(a

+C|a

6∈ M

stop−words

)

where n ≥ 2

In (Roche and Prince, 2007), “C” is represented

as a set of signiﬁcant words (e.g. encryption, infor-

mation and code to represent the Cryptography con-

text). The authors made some experiments with dif-

ferent number of words represented as context. In all

cases, authors use “AND” search engine operator be-

tween the words of context. That is, they request the

pages containing all words in “C”. However, work-

ing on a very specialized domainwhich contains some

more speciﬁc sub domains, we do not get the best re-

sults by using just an “AND” operator for the words

of context.

To specify the words which represent the context

of log ﬁles, we build a corpus of documents including

the reference documents of Integrated Circuit design

tools and tree other domains documents. We rank the

words of corpus by using tf-idf measure (see (Salton

and Buckley, 1987)). Tf-idf gives higher score to the

frequent words of a domain which are not frequent

in other ones. Then, we choose the ﬁrst ﬁve words

(ranked in tf-idf order) of IC design documents as

representing word of the context. As argued above,

we look for web pages containing a given term and

two or more words of context (using the operators

OR and AND). Finally, the extracted terms are ranked

by means of their AcroDef scores. We favor the

most ranked terms by ﬁltering those having most low

AcroDef scores.

4 EXPERIMENTS

In all experiments the log corpus is composed of logs

of ﬁve levels of IC design. For each level, we consid-

ered two logs generated in different conditions of de-

sign systems. The size of the log corpus is about 950

KB. All the experiments are done using the Google

search engine.

4.1 Evaluation of Terms by AcroDef

The extracted terms by EXTERLOG from the log ﬁles

are so numerous which make difﬁcult the ﬁnal vali-

dation by experts of domain. Thus, we experiment

by taking a sample of extracted terms. We select the

200 more frequent terms extracted from logs of every

IC design level. Note that in few levels, there exists

less than 200 terms. The taken sample consists of 700

terms at all.

To ﬁlter the extracted terms from log ﬁles, we

rank them by AcroDef (cf. 3.4). To apply AcroDef,

we determine the context words as described in Sect.

3.4. Then, we use the Google search engine to cap-

ture the number of pages containing a given term and

two or more words of context. Suppose a given term

like ”CPU time” where C

i ∈ {1 − 5} are the con-

text words, the query used in Google search engine is

“CPU time” AND C

AND C

OR C

Once AcroDef scores are calculated, we rank the

terms based on their AcroDef. The more AcroDef

has a higher value, the more the term is representa-

tive (seen) in our context. Then, we select the most

rated terms in the goal of emphasizing the precision

by reducing the noise ratio (no relevant terms) in re-

sults. Once the terms ﬁltered, we asked two domain

experts to evaluate remain terms in order to determine

the precision of our terminology extraction approach

from log ﬁles. First extracted terms are tagged by a

domain expert as relevant or not relevant according

to the context and their usefulness in the logs. Then,

another expert reviewed the tagged terms by the ﬁrst

KDIR 2009 - International Conference on Knowledge Discovery and Information Retrieval

expert. Then, the precision is calculated as percentage

of remain terms (after ﬁltering by AcroDef scores)

which are tagged as “relevant” by experts.

Precision =

|Terms

relevant

∩ Terms

remained

|Terms

remained

Terms

relevant

= terms validated by expert in sample scale

Terms

remained

= terms remained after ﬁltering

We calculate the recall as the percentage of all rel-

evant terms (tagged by experts in sample scale) which

remain after ﬁltering.

Recall =

|Terms

relevant

∩ Terms

remained

|Terms

relevant

Terms

validated

= terms validated by expert in sample scale

Terms

remained

= terms remained after ﬁltering

We also calculate F-score as the harmonic mean

of precision and recall to measure our approach accu-

racy.

F − score =

2∗ (Precision∗Recall)

Precision+Recall

We experiment with different numbers of the most

ranked terms as the ones which remain after ﬁlter-

ing. That is, suppose n terms in sample, we ﬁlter

the terms by selecting the m most ranked terms by

AcroDef score. Table 1 shows the results of ﬁltering

with different m as threshold of ﬁltering. In m = 500,

for example, we take the 500 most ranked terms. In

m = 700, we do not actually ﬁlter any terms. Thus,

the recall is equal to 100%. The results show that by

means of our ﬁltering approach, we favor more rele-

vant terms and emphasize the precision.

Table 1: Precision, Recall, and F-score of terms in each

level of ﬁltering based on AcroDef

score.

m Precision Recall F-score

200 80 % 38 % 52 %

300 78 % 56 % 65 %

400 74 % 71 % 72 %

500 72 % 87 % 79 %

600 66 % 95 % 78 %

700 59 % 100 % 74 %

Table 2 demonstrates the same ﬁltering results but

based on AcroDe f

MI3

scores. Table 3 shows the same

experiments using AcroDef

Dice

as scoring measure.

According to results, AcroDef

MI3

is more relevant

to score the extracted terms in our context. By us-

ing AcroDef

MI3

we reach better precision. That is,

AcroDef

MI3

score better the relevant terms of domain.

Table 2: Precision, Recall, and F-score of terms in each

level of ﬁltering m based on AcroDef

MI3

score

m Precision Recall F-score

200 86 % 41 % 56 %

300 79 % 57 % 67 %

400 76 % 74 % 75 %

500 72 % 87 % 79 %

600 66 % 95 % 78 %

700 59 % 100 % 74 %

Table 3: Precision, Recall, and F-score of terms in each

level of ﬁltering m based on AcroDef

Dice

score

m Precision Recall F-score

200 85 % 41 % 55 %

300 79 % 57 % 67 %

400 74 % 72 % 73 %

500 72 % 87 % 79 %

600 66 % 95 % 78 %

700 59 % 100 % 74 %

5 CONCLUSIONS & FUTURE

WORK

In this paper, we describe a particular type of textual

data: log ﬁles generated by tools for integrated circuit

design. Since these log ﬁles are multi-source, multi-

format, heterogeneous, and evolving textual data, the

NLP and IE methods are not necessarily well suited

to extract information.

To extract domain terminology, we extracted the

co-occurrences. For that, we apply the speciﬁc pre-

processing, normalization and tagging methods. To

reduce the noise ratio in extracted terms and favor

more relevant terms of this domain, we score terms

using a Web and context based measure. Then, we se-

lect the most ranked terms by ﬁltering based on score

of terms. The experiments show that our approach

of terminology extraction from log ﬁles, EXTERLOG,

can achieve an F-score equal to 0.79 after ﬁltering of

terms.

To improve the performance of terminology ex-

traction, we will develop our normalization method.

Given the importance of accurate grammatical tag-

ging, we will improve the grammatical tagger. Fi-

nally, we plan to take into account the terminology

extracted using our system to enrich the patterns of

information extraction from log ﬁles.

MINING FOR RELEVANT TERMS FROM LOG FILES

REFERENCES

Amrani, A., Kodratoff, Y., and Matte-Tailliez, O. (2004).

A semi-automatic system for tagging specialized cor-

pora. In PAKDD, pages 670–681.

Bourigault, D. and Fabre, C. (2000). Approche linguis-

tique pour l’analyse syntaxique de corpus. Cahiers de

Grammaire - Universit´e Toulouse le Mirail, (25):131–

151.

Brill, E. (1992). A simple rule-based part of speech tagger.

In In Proceedings of the Third Conference on Applied

Natural Language Processing, pages 152–155.

Church, K. W. and Hanks, P. (1990). Word association

norms, mutual information, and lexicography. In

Computational Linguistics, volume 16, pages 22–29.

Collier, N., Nobata, C., and Tsujii, J. (2002). Automatic

acquisition and classiﬁcation of terminology using a

tagged corpus in the molecular biology domain. Jour-

nal of Terminology, John Benjamins, 7(2):239–257.

Daille, B. (1994). Approche mixte pour l’extraction au-

tomatique de terminologie : statistiques lexicales et

ﬁltres linguistiques. PhD thesis, Universit Paris 7.

Daille, B. (1996). Study and Implementation of Combined

Techniques for Automatic Extraction of Terminology.

In The Balancing Act: Combining Symbolic and Sta-

tistical Approaches to Language, MIT Press, pages

49–66.

Daille, B. (2003). Conceptual structuring through term vari-

ations. In Proceedings of the ACL 2003 workshop on

Multiword expressions, pages 9–16, Morristown, NJ,

USA. Association for Computational Linguistics.

David, S. and Plante, P. (1990). De la n´ecessit´e d’une ap-

proche morpho-syntaxique en analyse de textes. Intel-

ligence Artiﬁcielle et Sciences Cognitives au Qu´ebec,

2(3):140–155.

Dey, L., Singh, S., Rai, R., and Gupta, S. (2005). Ontology

aided query expansion for retrieving relevant texts. In

AWIC, pages 126–132.

Evans, D. A. and Zhai, C. (1996). Noun-phrase analysis

in unrestricted text for information retrieval. In Pro-

ceedings of the 34th annual meeting on Association

for Computational Linguistics, pages 17–24, Morris-

town, NJ, USA. Association for Computational Lin-

guistics.

Even, F. and Enguehard, C. (2002). Extraction

d’informations `a partir de corpus d´egrad´es. In Pro-

ceedings of 9`eme conference sur le Traitement Au-

tomatique des Langues Naturelles (TALN’02), pages

105–115.

Facca, F. M. and Lanzi, P. L. (2005). Mining interesting

knowledge from weblogs: a survey. Data Knowl.

Eng., 53(3):225–241.

Grobelnik, M. (1998). Word sequences as features in text-

learning. In In Proceedings of the 17th Electrotechni-

cal and Computer Science Conference (ERK98, pages

145–148.

Lin, D. (1998). Extracting collocations from text corpora.

In In First Workshop on Computational Terminology,

pages 57–63.

meng Tan, C., fang Wang, Y., and do Lee, C. (2002). The

use of bigrams to enhance text categorization. In Inf.

Process. Manage, pages 529–546.

Moll´a, D. and Vicedo, J. L. (2007). Question answering

in restricted domains: An overview. Computational

Linguistics, 33(1):41–61.

Roche, M., Heitz, T., Matte-Tailliez, O., and Kodratoff, Y.

(2004). EXIT: Un syst`eme it´eratif pour l’extraction

de la terminologie du domaine `a partir de corpus

sp´ecialis´es. In Proceedings of JADT’04 (International

Conference on Statistical Analysis of Textual Data),

volume 2, pages 946–956.

Roche, M. and Prince, V. (2007). AcroDef : A quality

measure for discriminating expansions of ambiguous

acronyms. In CONTEXT, pages 411–424.

Salton, G. and Buckley, C. (1987). Term weighting ap-

proaches in automatic text retrieval. Technical report,

Ithaca, NY, USA.

Saneifar, H., Bonniol, S., Laurent, A., Poncelet, P., and

Roche, M. (2009). Terminology extraction from log

ﬁles. In DEXA ’09: Proceedings of the 20th inter-

national conference on Database and Expert Systems

Applications. Springer-Verlag.

Smadja, F. (1993). Retrieving collocations from text:

Xtract. Comput. Linguist., 19(1):143–177.

Smadja, F., McKeown, K. R., and Hatzivassiloglou, V.

(1996). Translating collocations for bilingual lexi-

cons: A statistical approach. Computational Linguis-

tics, 22(1):1–38.

Voorhees, E. M. (1994). Query expansion using lexical-

semantic relations. In SIGIR ’94: Proceedings of the

17th annual international ACM SIGIR conference on

Research and development in information retrieval,

pages 61–69, New York, NY, USA. Springer-Verlag

New York, Inc.

Yamanishi, K. and Maruyama, Y. (2005). Dynamic sys-

log mining for network failure monitoring. In KDD

’05: Proceedings of the eleventh ACM SIGKDD inter-

national conference on Knowledge discovery in data

mining, pages 499–508, New York, NY, USA. ACM.

KDIR 2009 - International Conference on Knowledge Discovery and Information Retrieval
