A FRAMEWORK FOR MANAGING COMPONENTS USING

NON-FUNCTIONAL PROPERTIES

∗

Jean-Michel Hufﬂen

LIFC (EA CNRS 4269), University of Franche-Comt´e, 16, route de Gray, 25030 Besanc¸on Cedex, France

Keywords:

Non-functional properties, Component-based approach, Component conﬁguration, TACOS project, XML.

Abstract:

As part of a component-based approach, we propose a framework to group speciﬁcations of component hi-

erarchies, possibly including the speciﬁcation of non-functional properties. We show how we are able to

choose a particular implementation of a component—or change an implementation to another—regarding

non-functional properties, and how we are able to express conﬁgurations of component-based architectures.

Our approach uses programs related to XML, and non-functional properties are managed by means of a termi-

nology originating from the metadata used by the Dublin Core.

1 INTRODUCTION

It is known that functional requirements specify what

a system is supposed to do whereas non-functional

requirements express what a system is supposed to

be. Non-functional requirements include constraints

and quality factors (Sommerville, 2006, Ch. 2). Ex-

amples are time-constrained response or requested

services’ availability. Presently, there is no consen-

sus about classifying these properties, as reported in

(Glinz, 2007). In this article, we propose a framework

to handle some hierarchies of components, within a

component-based approach, suitable for systems with

high-safety requirements. By ‘some hierarchies’, we

mean that several implementations may be associated

with a component’s speciﬁcation. The choice among

such implementations of a same speciﬁcation can be

guided by considering non-functional properties. We

assume that preliminary steps of designing some ver-

sions about components and interactions among them

have already been done. We aim to assist designers

when they wish to compare differentconﬁgurations of

the same service. For example, they can study what

is induced by the replacement of a component by an-

other one.

At ﬁrst glance, our approach may be compared

with using Makeﬁles, in order to build executable ﬁles

from source ones by means of the

make

command

∗

This work is supported by the French agency for re-

search (TACOS ANR-06-SETI-017-03).

See (Oram and Talbott, 1991) for more details.

But it is well-known that such ﬁles contain informa-

tion redundancy since dependences have to be put ex-

plicitly. As an example, such a speciﬁcation is related

to ﬁles written using the C programming language:

f.o

f.c dep

.h ... dep

expresses that the f.o object ﬁle has to be rebuild

if a ﬁle belonging to f.c, dep

.h, ..., dep

.h is

newer than the present f.o ﬁle, or if this last ﬁle does

not exist. But this information must be put even if it

is already expressed within ﬁles. Since we consider

source ﬁles written in C, the dependence of the f.o

ﬁle on the dep

.h ﬁle has probably been expressed

within the f.c source ﬁle by the macro-instruction:

#include "

dep

In particular, that is why some additional programs—

e.g.,

automake

(Vaughn et al., 2000) or (cmake,

2009)—have been developed to supply this informa-

tion from source ﬁles. The same drawback related to

information redundancy exists with the conﬁguration

ﬁles used by the Ant program

: a

target

element in-

cludes a

depends

attribute, even if this information

can be deduced from source ﬁles.

Our conﬁguration ﬁles use XML

-like syntax. We

also use the terminology originating from (Dublin

Core Metadata Initiative, 2008) for metadata related

to non-functional properties. In addition, types qual-

ifying the possible values for non-functional proper-

ties can be speciﬁed by the rigorous approach of XML

See (Tilly and Burke, 2002) for more details.

eXtensible Markup Language.

460

Hufﬂen J. (2009).

A FRAMEWORK FOR MANAGING COMPONENTS USING NON-FUNCTIONAL PROPERTIES.

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development, pages 460-463

DOI: 10.5220/0002309104600463

 SciTePress

Schema (W3C, 2008). We explain all these points in

§ 2. Then § 3 gives the different steps of the use of

our framework. § 4 discusses our modus operandi,

and § 5 sketches which ways are open. Reading this

article only requires basic knowledge of XML.

2 BASIS

We consider a basic notion of component: a unit of

construction implementing some services via inter-

faces. If a component is built from other subcom-

ponents, it is said to be composite. Otherwise, it is

simple. Such a simple component can be speciﬁed by

the

tacos:component

element

(several successive

tacos:implements

elements are allowed):

<tacos:component id="id-0" path="path-to-id-0">

<tacos:implements ref="interface-0"

role="server" name="..."/>

<tacos:nonfunctional-properties>

<tacos:nf-property name="nfp:complexity"

as="nfp:performance"

value="linear"/>

<tacos:nf-property

name="nfp:reliability" as="nfp:specific"

check-up="http://tacos.loria.fr/..."/>

...

</tacos:nonfunctional-properties>

</tacos:component>

The

attribute is unique—of type

xsd:ID

—

whereas

path

is used to localise the component. Then

non-functional properties are grouped. For each of

them, if the

check-up

attribute is present, its value

is a

URI

denoting a program that applies to what is

located at

path

’s value and reports about this prop-

erty. For example, if the reliability is expressed as the

mean time between failures, it can be computed by a

tool and the result—the

value

attribute—is the type

xsd:decimal

. Likewise, a non-functional property

related to efﬁciency can be reported by a tool running

the component with benchmarks. If a non-functional

property is supposed to be not checkable by means of

a program, the

value

attribute is to be supplied by

designers. Most non-functional properties are prede-

ﬁned, they belong to the namespace identiﬁed by the

nfp

preﬁx. A designer can add new properties by re-

ﬁning our XML schema. The

attribute is used to

group non-functional properties into several families:

it allows us to retrieve information concerning non-

functional properties belonging to a same class. A

composite component can be speciﬁed as follows:

The preﬁx originates from the TACOS project, cf. § 4.

Uniform Resource Identiﬁer (Network Working

Group, 2002).

<tacos:composite-component id="id-2"

path="...">

<tacos:implements .../>

<tacos:refers-to ref="id-0" nb="2"/>

<tacos:refers-to ref="id-1"/>

<tacos:nonfunctional-properties>...</...>

</tacos:composite-component>

There are three subcomponents of this last com-

ponent: two instances of the

id-0

component (the

attribute gives the number of replications), and one

instance of

id-1

(

defaults to

). Non-functional

properties speciﬁed for this composite component

hold for the whole of it, without reference to its sub-

components’ properties. The general layout is:

<tacos:components ...

(Namespace deﬁnitions.)

<tacos:general-metadata>

<dc:title>Example</dc:title>

<dc:creator>H., J.-M. (...)</dc:creator>

...

</tacos:general-metadata>

<tacos:component-specifications>

<tacos:component id="id-0">...</...>

<tacos:composite-component id="id-2">

...

</...>

</tacos:component-specifications>

</tacos:components>

The elements introducing metadata use the ba-

sic elements of the Dublin Core, preﬁxed by

The speciﬁcation of all the components is ﬂatten,

in the sense that no component is deﬁned inside

the speciﬁcation of a composite component. A ref-

erence to another component is expressed by an

tacos:refers-to

element, as shown above.

3 STEPS

Here are the ﬁve successive steps of our method.

1. This step is sketched at § 2, it just states the result

of the conception of a hierarchy of components.

This result is close has been shown, but without

the speciﬁcation of non-functional properties.

2. Elements of non-functional properties are added

by designers, with accurate values associated with

the

check-up

value

attributes.

3. We consider all the

tacos:nf-property

ele-

ments of our conﬁguration ﬁle. If the

check-up

attribute is used, the corresponding program is

called, and the result is given as a new or updated

value

attribute. So each

tacos:nf-property

element is given a

value

attribute. In addition,

some metadata elements are computed, e.g., the

following element is put at the speciﬁcation’s end

of the

id-0

component:

A FRAMEWORK FOR MANAGING COMPONENTS USING NON-FUNCTIONAL PROPERTIES

461

<tacos:technical-metadata>

<dcterms:isReferencedBy>id-1</...>

</tacos:technical-metadata>

The

dcterms

preﬁx is used for the elements be-

longing to the Qualiﬁed Dublin Core: such ele-

ments reﬁne the semantics of Dublin Core’s basic

elements. This step is performed by applying an

XSLT

program (W3C, 2007c). The result is given

in a new conﬁguration ﬁle, extending the original

one, and so-called complete.

4. Several complete conﬁguration ﬁles modelling hi-

erarchies can be merged into one, in order to share

the common parts—interfaces or components. In

addition, metadata about alternatives and reﬁne-

ments are added, e.g., if another conﬁguration ﬁle

contains another component

id-3

, implementing

the same interface than

id-0

, the technical meta-

data of the speciﬁcation of

id-0

will include:

<dcterms:alternative>id-3</...>

an analogous information being added to the spec-

iﬁcation of

id-3

. This step is also performed by

applying an XSLT program.

5. Using a conﬁguration ﬁle as a data base, we can

ask for information about components, including

non-functional properties. As a simple example,

the following fragment, written in the XQuery lan-

guage (W3C, 2007b), yields all the paths of the

components such that the non-functional proper-

ties classiﬁed as

nfp:performance

are ‘good’,

the result being an XML text.

{

for $component in

(doc("...")/tacos:components/

tacos:component-specifications/*)

return

if (some $nf-property in

$component/

tacos:nonfunctional-properties/

tacos:nf-property satisfies

$nf-property/@as eq

"nfp:performance" and

check-good($nf-property/@value))

then <a>

{

$component/@path

}

</a>

else ()

}

</answers>

We can also assembly components in order to

build complete software, using selection criteria

based on non-functional properties. If this opera-

tion succeeds, a version name is chosen and con-

cerned components’ metadata are updated:

<dcterms:isVersionOf>version-0</...>

eXtensible Stylesheet Language Transformations.

this step being performed by an XSLT program.

6. We should be able to deriveﬁles usable by

make

—

Makefile.in

ﬁles, used by the

configure

program (Vaughn et al., 2000)—or Ant.

4 CRITICISM

This approach has been put into action as part of the

TACOS

project, proposing a component-based ap-

proach suitable for land transportation systems. These

systems, which are both distributed and embedded,

require to express functional properties, as well as

non-functional ones. As a good example of our

method, there are several versions and variants of

the localisation component of a vehicle. These ver-

sions use the same basic components but the com-

posite components grouping them are organised dif-

ferently. There are much debate within the working

group about these versions. Our approach allows us to

make easier these comparisons, in particular regard-

ing non-functionalproperties. More precisely, Steps 1

to 5 have been implemented using the Saxon program

(Kay, 2008), providing an XQuery and XSLT proces-

sor; Step 6 is almost ﬁnished.

A close approach exists within the SCA framework

(Service Component Architecture, 2007), that pro-

vides a programming model for building applications

based on a service-oriented architecture. SCA also

uses ﬁles written using XML-like syntax, and similar

notions exist: interfaces, simple and composite com-

ponents. But this approach is more restrictive: inter-

faces can be Java or WSDL

interfaces. Likewise, SCA

allows a limited choice among several implementa-

tion types for a component’s implementation. The

most used is Java, but other languages, such as C++ or

C, are also allowed. That is, we are not wholly inde-

pendent of the language chosen, even if a wide variety

is available. Properties can be speciﬁed, and may be

deduced from programs’ texts, e.g., implementations

written in Java can use annotations. The main differ-

ence with our approach is that an SCA text describes

only one assembly; there is no way to specify alterna-

tives in SCA, no possible replacement of a component

by another. Some elements used within SCA can be

viewed as metadata, but they are deﬁned in an ad hoc

way. Likewise, UniFrame (Raje et al., 2001) creates a

comprehensive framework that enables the discovery,

interoperability and collaboration of components via

Trustworthy Assembling of Components: frOm re-

quirements to Speciﬁcation. See this project home page

http://tacos.loria.fr for more details.

Web Services Deﬁnition Language (W3C, 2007a).

KEOD 2009 - International Conference on Knowledge Engineering and Ontology Development

462

software generative techniques. Non-functional prop-

erties are handled as quality-of-service parameters,

SQL requests are used to query such a frame about

QoS parameters. The selection of alternative com-

ponenents is possible, too. Nevertheless, our notion

of composite component is more powerful, and the re-

lationships among components we model by means of

Dublin Core elements are more reﬁned. In addition,

as far as we know, UniFrame does not provide tools to

perform the merge of several hierarchies sharing com-

mon components. On the contrary, we do not provide

the automatic generation of glues and wrappers, as

UniFrame does, but as part of the TACOS project, that

can be done by means of Fractal, a modular and ex-

tensible component model that can be used with var-

ious programming languages to design, implement,

deploy and reconﬁgure various systems and applica-

tions (Bruneton et al., 2004).

5 FURTHER WORK

Many tools are used within TACOS project, e.g., Frac-

tal. It does not consider non-functional properties,

but handles XML conﬁguration ﬁles. We succeeded

in getting such XML ﬁles, transforming them, and

adding speciﬁcation of non-functional properties. So

we can reuse the conception done by a Fractal user.

An advantage of using elements originating from

Dublin Core: we plan to use some tools related to

the Semantic Web. This idea is promising: as part

of studying services, this connection with the Seman-

tic Web has already been proposed in (Gerede et al.,

2008). Such metadata are also used within the Web

Services Semantics (W3C, 2005; WSMO, 2006).

6 CONCLUSIONS

We have wanted to show that we follow a rigorous ap-

proach, with the advantages and drawbacks of a gen-

eral one, without any hypothesis about languages and

paradigms used. Such an approach requires the de-

velopment of many additional tools, in particular, to

deal with non-functional properties. But the applica-

tion ﬁelds of such a framework is potentially high. Of

course, we need more case studies to experiment our

approach, but we are optimist because of the ﬁrst re-

sults we got from Fractal conﬁguration ﬁles.

REFERENCES

Bruneton,

E., Coupaye, Th., and Stefani, J.-

B. (2004). The Fractal Component Model.

http://fractal.objectweb.org/speciﬁcation/index.html.

cmake (2009). CMake. http://www.cmake.org/.

Dublin Core Metadata Initiative (2008). Dublin Core Meta-

data Initiative. http://dublincore.org.

Gerede, C. E., Ibarra, O. H., Ravikumar, B., and Su, J.

(2008). Minimum-cost delegation in service composi-

tion. Theoretical Computer Science, 409(3):417–431.

Glinz, M. (2007). On non-functional requirements. In Proc.

RE 07, New-Delhi, India.

Kay, M. H. (2008). Saxon. The XSLT and XQuery Proces-

sor. http://saxon.sourceforge.net.

Network Working Group (2002). Uniform Resource

Identiﬁers (URIs), URNs, and Uniform Resource

Names (URNs): Clariﬁcations and Recommenda-

tions. http://www.ietf.org/rfc/rfc3305.txt. Edited by

M. Mealling and R. Denenberg.

Oram, A. and Talbott, S. (1991). Managing Projects with

make. O’Reilly & Associates, Inc., 2 edition.

Raje, R., Bryant, B., Auguston, M., Olson, A., and Burt,

C. (2001). A uniﬁed approach for integration of dis-

tributed heterogeneous software components. In Proc.

of the 2001 Monterey Workshop Engineering Automa-

tion for Software Intensive System Integration, pages

109–119.

Service Component Architecture (2007). Assembly

Model Speﬁciation. http://www.osoa.org/download/

attachments/35/SCA AssemblyModel V100.pdf?ver-

sion=1.

Sommerville, I. (2006). Software Engineering. Addison-

Wesley, 8 edition.

Tilly, J. and Burke, E. M. (2002). Ant: the Deﬁnitive

Guide. O’Reilly & Associates, Inc.

Vaughn, G. V., Ellison, B., Tromey, T., and Taylor, I. L.

(2000). GNU Autoconf, Automake, and Libtool. Sams.

W3C (2005). HyperText Markup Language Home Page.

http://www.w3.org/MarkUp/.

W3C (2007a). Web Services Description Working Group.

http://www.w3.org/2002/ws/desc/.

W3C (2007b). XQuery 1.0: an XML Query Language.

http://www.w3.org/TR/xquery. W3C Recommenda-

tion. Edited by Scott Boag, Don Chamberlin, Mary

F. Fern´andez, Daniela Florescu, Jonathan Robie and

J´erˆome Sim´eon.

W3C (2007c). XSL Transformations (XSLT). Ver-

sion 2.0. http://www.w3.org/TR/2007/WD-xslt20-

20070123. W3C Recommendation. Edited by

Michael H. Kay.

W3C (2008). XML Schema. http://www.w3.org/XML/

Schema.

WSMO (2006). Web Service Modelling Ontology.

http://www.wsmo.org/TR/d2/v1.3/. Edited by Du-

mitru Roman, Holger Lausen, and Uwe Keller.

A FRAMEWORK FOR MANAGING COMPONENTS USING NON-FUNCTIONAL PROPERTIES

463
