PROBLEM AND ALGORITHM FINE-TUNING

A Case of Study using Bridge Club and Simulated Annealing

Nelson Rangel-Valdez, Jos´e Torres-Jim´enez, Josue Bracho-R´ıos and Pedro Quiz-Ramos

Laboratory of Information Technologies, CINVESTAV, Cd. Victoria, Tamaulipas, Mexico

Keywords:

Parameter tuning, Covering arrays, Bridge club, Simulated annealing.

Abstract:

Sometimes, it is difﬁcult to cope with a good set of values for the parameters of an algorithm that solves an spe-

ciﬁc optimization problem. This work presents a methodology for ﬁne-tuning the parameters of a Simulated

Annealing (SA) algorithm solving the Bridge Club (BC) problem. The methodology uses Covering Arrays as

a tool that evaluates a set of values for the parameters of the SA so that it achieves its best performance when

solving BC. The results in the experiments performed show that, using this methodology, the SA reached the

optimal solution of the BC problem with a relatively small number of evaluations, in comparison with other

strategies that solves BC.

1 INTRODUCTION

The Bridge Club (BC) problem has been considered

as a case of study in discrete optimization. This prob-

lem, in appearance simple, arises as a complex prob-

lem when solved by an exact approach. The Bridge

Club problem and its optimal solution are deﬁned in

(Elenbogen and Maxim, 1992).

BC has been solved using several approxi-

mated approaches: greedy algorithm (Elenbogen and

Maxim, 1992), partial branch & bound (Elenbo-

gen and Maxim, 1992), steepest descent (Elenbo-

gen and Maxim, 1992), annealed search (Elenbo-

gen and Maxim, 1992), Kreher, et. al. (Kreher

et al., 1996), Genetic Algorithm (Simpson, 1997),

tabu search (Morales, 1997). Even though some of

these techniques are sensitive to the values of its pa-

rameters, few is known about how good such values

are (Simpson, 1997).

Table 1 compares the reported algorithms that

solve the BC problem. First column shows the name

of the methods. The second and third columns show

the best solution and time spent by each algorithm,

respectively. The last column shows the number of

evaluations of the cost function used by each algo-

rithm to reach their best reported value.

The best values for the parameters of an algo-

rithm are estimated according with the problem that

is solved. Several strategies to choose these values

can be found in the literature. Generally, the best

Table 1: Comparison between the different algorithms that

solve BC.

Method Cost Time Evaluations

Greedy Algorithm 22 3 hrs. 40,397

Partial Branch & Bound 20 8 hrs. 100,000

Steepest Descent 14 2 hrs. 75,000

Annealed Search 14 1 hr. 50,000

Kreher, et. al. 12 - 1,000,000

Genetic Algorithm 12 - 375,000

Tabu Search 12 - 3,456 - 153,600

values for an algorithm are determined through an

experimental design. Sometimes, these values are

taken from the literature (Laarhovenand Aarts, 1987).

Some other are just chosen without validating its ef-

fectiveness. More recent approaches try new tech-

niques based on factorial designs (D´ıaz and Laguna,

2006).

In the search for the best solution of a problem

we try to ﬁnd the best values for its parameters and

the parameters of the algorithm that solves it. The pa-

rameters of a problem are the ones that are deﬁned ac-

cording with its deﬁnition. Among these parameters

are the neighborhood function, the evaluation func-

tion, initial solution and internal representation. The

parameters of an algorithm are those that do not need

the deﬁnition of the problem to be speciﬁed. Some ex-

amples of algorithm parameters are temperature and

population. Most of the time, the selection of the val-

ues for the parameters of the problem is independent

from the parameters of the algorithm. This way of

302

Rangel-Valdez N., Torres-Jimenez J., Bracho-Rios J. and Quiz-Ramos P. (2009).

PROBLEM AND ALGORITHM FINE-TUNING - A Case of Study using Bridge Club and Simulated Annealing.

In Proceedings of the International Joint Conference on Computational Intelligence, pages 302-305

DOI: 10.5220/0002321303020305

 SciTePress

choosing values represents an area of opportunity in

the sense that, combining both kind of parameters we

can choose their values in one experimental design

and we can exploit the relationship that can exist be-

tween the parameters of the algorithm and the param-

eters of the problem.

In order to show the effectiveness of a methodol-

ogy for ﬁne-tuning parameters of both the algorithm

and the problem, this paper proposes a methodology

based on Covering Arrays (Lopez-Escogido et al.,

2008). The proposed methodology ﬁne-tunes the pa-

rameters of a solution for the Bridge Club problem

via Simulated Annealing.

This document is organized as follows. Sec-

tion 2 shows the details about the implementation of

the Simulated Annealing that solves the Bridge Club

problem. Section 3 describes the methodology used

to tune the parameters of the Simulated Annealing

as well as the parameters of the problem. Section

4 shows the results of applying the tuning process

in the solution of the Bridge Club problem through

the Simulated Annealing algorithm. Finally, section

5 presents the conclusions derived from this research

work.

2 SIMULATED ANNEALING

The Simulated Annealing Algorithm(SA) ﬁrst intro-

duced by S.Kirkpatrick (Kirkpatrick, 1983) is in-

spired in statistical mechanics. The parameters of the

SA are the cooling schedule and the stop criterion.

The parameters of the BC problem are the internal

representation of the solution, the initial solution, the

neighborhood function and the evaluation function.

The cooling schedule refers to an initial temper-

ature T

, a ﬁnal temperature T

, a cooling factor

α, the frozen parameter Γ (number of consecutive

Markov chains without improvement) and the length

of a Markov chain L. In addition, in order to deter-

mine the moment in which the SA ends, a number of

evaluations I is used. Once that the evaluation func-

tion is performed I times, the SA exits and reports the

best solution achieved.

The solution representations for the BC problem

are based in the matrix representations proposed in

(Simpson, 1997) (representation R

), in (Elenbogen

and Maxim, 1992) (representation R

) and a new rep-

resentation (representation R

that ﬁxes the group A

in the initial solution in the ﬁrst column of the repre-

sentation proposed by (Elenbogen and Maxim, 1992).

The initial solution for all the representations is

randomly generated. The values of the matrix M with

representation R

will be randomly chosen between

{1, 2,..., 12} or between {A, B,C} otherwise.

In this approach we tested three evaluation func-

tions. The ﬁrst one Π

(M ) shown in Equation 1 and

deﬁned in Elenbogen, et al. (Elenbogen and Maxim,

1992).

(M ) =

∑

i=1

∑

j=i+1

− 2)

(1)

Two other evaluation functions are analyzed in the

solution of the BC problem. The evaluation function

(M ) rises to 4 instead of 2 the difference (m

−2).

The evaluation function Π

(M ) obtains the absolute

difference instead of a power. Any evaluation func-

tion Π must be minimized by the SA algorithm to

achieve the optimal solution.

This research work proposes three methods to

build new solutions M

′

during the SA. The neighbor-

hood function N

creates M

′

by exchanging values

between two elements m

i, j

, m

i,k

of a given a solution

matrix M . The inversion strategy N

can be deﬁned

as a set of exchanges; given two elements m

i, j

, m

i,k

∈

M , j < k, a new solution M

′

is constructed by apply-

ing N

to m

i,ι

, m

i,κ

, for all j ≤ ι, κ ≤ k.

The neighborhood function based in rotations N

creates M

′

using a solution M and two elements

i, j

, m

i,k

∈ M , j < k. This function assigns the value

of each element m

i,ι

, for every j ≤ ι < k, to the el-

ement m

i,ι+1

. The element m

i,k

assigns its value to

i, j

Every neighborhood function N requires two el-

ements m

i, j

, m

i,k

∈ M . The elements can be deﬁned

by choosing the values for i, j, k . The value i repre-

sents a row in M while the values j, k represent two

different columns. This research work proposes three

methods χ

, χ

to choose the values of i, j, k to test

the performance of the SA algorithm.

The method χ

randomly chooses the values i, j, k

every time that a neighborhood function N build a

new solution M

′

. The method χ

is just like χ

but

it randomly selects the value of j once. After that, its

value is increased by one at every call of a neighbor-

hood function N . The method χ

, differs in which

values i, j are randomly chosen once and after that

their values are increased by one each time a neigh-

borhood function N constructs a new solution M

′

The SA stops the search for a solution for the BC

problem when one of the following criteria are met:

the system get frozen, the ﬁnal temperature T

has

been reached, the maximum number of evaluations

I has been exceeded or the optimal solution has been

found, i.e., Π(M ) = 12, for a particular value of M .

The next section describes the tuning process fol-

lowed to ﬁnd the best values for the parameters of the

SA to solve the BC problem.

PROBLEM AND ALGORITHM FINE-TUNING - A Case of Study using Bridge Club and Simulated Annealing

303

3 FINE-TUNING OF THE SA

Fine-tuning of parameters is the process of adjusting

the parameters of an algorithm to solve a problem.

Several works like (Barr et al., 1995), (Fink and S.,

2002) have addressed the importance of performing

a calibration of the parameters in heuristic and meta-

heuristic approaches. Related works about method-

ologies that can be followed to perform a ﬁne-tuning

are shown in (D´ıaz and Laguna, 2006), (Fidanova

et al., 2009), (Taguchi, 1994).

A Covering Array(CA) (Lopez-Escogido et al.,

2008) is an array M of size N× k consisting of N vec-

tors of length k with entries from 0, 1, . .., v− 1 (v is

the size of the alphabet) such that every one of the v

possible vectors of size t occurs at least once in every

possible selection of t elements from the vectors. The

parameter t is referred to as the covering strength.

This process is based in a set of instances β of a

problem P and in a Covering Array CA(N;t, k, v) to

study the effect of the interaction between parameters

in the solution of P using an algorithm A .

In the CA, the value k is the number of param-

eters of the algorithm A and the problem P object

of the ﬁne-tuning. The value of the alphabet v will

correspond to the cardinality of the set of values for

the parameters considered in the tuning process. The

level of interaction between parameters is initialized

to t = 2. During the process, the performance ϕ

the algorithm solving the problem P with a level of

interaction t is measured. If the performance is im-

proved, the values of the parameters of P and A are

adjusted in order to ﬁnd better solutions. If the perfor-

mance ϕ

is no longer improved, the interaction level

t is increased by one only if ϕ

− ϕ

t−1

> ε. ε is a

threshold selected so that the ﬁne-tuning process halts

in a suitable amount of time. Every time that the level

of interaction t is increased then a new CA(N;t, k, v)

must be constructed.

The next section presents the experiments done to

tune the values of the parameters of the Simulated An-

nealing to solve the BC problem using the methodol-

ogy described in this section.

4 EXPERIMENTAL RESULTS

The methodology described in Section 3 was used to

ﬁne-tune the parameters of the Simulated Annealing

in order to solve the BC problem.

The initial values selected for the parameters dur-

ing the tuning process are shown in Table 2. The ﬁrst

column shows the parameter, the last 3 columns are

the values selected for that parameter.

Table 2: Values for the parameters of the Simulated Anneal-

ing.

Type of Parameter Parameter 1

value (0) 2

value (1) 3

value (2)

Problem R R

Problem χ χ

Problem Π Π

Algorithm T

1.0 0.5 0.25

Algorithm α 0.99 0.90 0.85

Algorithm T

0.001 0.000001 0.000000001

Algorithm I 10000 100000 1000000

Algorithm L 500 800 1000

Algorithm Γ 5 10 15

Problem N N

Table 3: Summary of the results obtained during the ﬁne-

tuning process using a CA(14;2, 10, 3).

Num. Avg. Avg. Avg. Avg.

Conf. Sol. Opt. Sol. Time Eval. Opt. Eval.

0002010112 14.00 0.00 37.29 0.00 20129.03 0.00

0101221200 12.00 6.00 32.26 0.90 97483.81 4666.67

0120112011 22.00 0.00 49.03 0.00 127741.88 0.00

0210002222 18.00 0.00 53.68 21.94 1331612.75 0.00

1001101122 14.00 0.00 38.84 0.00 91354.82 0.00

1011212100 12.00 2.00 32.77 0.58 47380.64 4800.00

1021020221 18.00 0.00 46.45 0.00 19354.84 0.00

1112000020 12.00 4.00 32.90 0.00 18322.58 4250.00

1210120210 12.00 2.00 37.16 0.00 18903.23 3000.00

2000021002 14.00 0.00 33.29 1.94 193548.45 0.00

2120200102 14.00 0.00 38.45 0.00 20129.03 0.00

2202122101 28.00 0.00 72.00 3.87 284903.31 0.00

2211201011 30.00 0.00 112.52 0.00 37741.95 0.00

2222211220 12.00 2.00 37.03 0.00 80903.23 45000.00

Table 3, in the ﬁrst column, shows the ﬁrst

CA(14;2, 10, 3) used for the tuning process. The al-

phabet for this CA is shown in the Table 2. Each digit

from left to right correspond to a parameter shown in

Table 2. The values 0, 1 and 2 correspond to values in

the columns 2, 3 and 4, in Table 2, respectively.

The BC problem was solved using the SA and the

CA shown in the ﬁrst column of Table 3. The BC

problem was solved 31 times by each conﬁguration.

Table 3 summarizes the results obtained during the

ﬁne-tuning process using a level of interaction of two

t = 2. Column 2 shows the best solution achieved

by each conﬁguration. Column 3 shows the number

of times that the optimal solution was reached. Col-

umn 4 presents the average cost of a solution using a

speciﬁc conﬁguration. Column 5 presents the average

time measured in seconds that the SA spent in ﬁnding

the optimal solution. Column 6 is the average number

of times that the evaluation function was computed

during the SA. Column 7 shows the average number

of times that the SA needs to compute the evaluation

function in order to ﬁnd the optimal solution.

The results presented in Table 3 show a low qual-

ity in the solution achieved by the SA using the com-

bination of the values described by CA(14;2, 10, 3).

The best conﬁguration just achieved the optimum

value 19% of the times. The solutions of the SA aver-

aged a distance of 168% over the optimal solution, in

the best case.

In order to improve the performance of the SA

when solving the BC, the level of interaction between

IJCCI 2009 - International Joint Conference on Computational Intelligence

304

parameters t was increased. A new Covering Ar-

ray CA(54;3, 10, 3) was used. The results obtained

were signiﬁcantly improved. The best conﬁguration

achieved the optimum value in 54% of the cases. The

solutions of the SA averaged a distance of 6% over

the optimal solution. And with respect to the number

of evaluations performed by the SA to ﬁnd the opti-

mal solution, it averages 25458 evaluations. In gen-

eral, the time spent by the SA in ﬁnding a solution

was around 0.81 seconds. The improvement achieved

in the next level of interaction t = 4 did not surpass

the threshold ε. The ﬁne-tuning process halted at this

point. The SA algorithm performed better with the

conﬁguration 2010002110 for the SA algorithm and

BC parameters.

5 CONCLUSIONS

This document presents a methodology for ﬁne-

tuning the parameters of the SA and the BC problem.

The methodology relies on the use of a CA to perform

the parameters tuning.

The ﬁne-tuning process adjusts the values of the

set of parameters formed by the parameters of the SA

and the parameters of the Bridge Club problem. An

initial interaction of level two (a CA of strength t = 2)

was initially proven, the best conﬁguration achieved

the optimal solution 19% of the times it was runned.

In general, it averaged a 168% above the optimal solu-

tion. When increasing the level of interaction to three

(a CA of strength t = 3), the best conﬁguration found

the optimal solution in 54% of the times and its aver-

age distance from the optimal was reduced to 6%, a

dramatical change with respect to the interaction of

level t = 2. No signiﬁcative change in the perfor-

mance of the SA were achieved with greater level of

interaction.

The SA algorithm improves the reported results

by other approaches. The methodology shows that

the performance of an algorithm can be dramatically

affected by the interaction level between the param-

eters involved. In our case of study, an interaction

level of value three t = 3 was sufﬁcient to ﬁnd satis-

factory values for the parameters of the SA in order

to get a good performance in solving the BC problem.

Finally, we can conclude that the Covering Arrays,

as part of experimental designs, are valuable tools for

ﬁne-tune parameters associated with an algorithm and

the problem being solved.

ACKNOWLEDGEMENTS

This research was partially funded by the following

projects: CONACyT 58554-C´alculo de Covering Ar-

rays, 51623-Fondo Mixto CONACyT y Gobierno del

Estado de Tamaulipas.

REFERENCES

Barr, R., Golden, B., Kelly, J., Resende, M., W.R., and Jr., S.

(1995). Designing and reporting on computational ex-

periments with heuristic methods. Journal of Heuris-

tics, 1(1):9–32.

D´ıaz, B. A. and Laguna, M. (2006). Fine-tuning of algo-

rithms using fractional experimental designs and local

search. Operations Research, 54(1):99–114.

Elenbogen, B. and Maxim, B. (1992). Scheduling a bridge

club (a case study in discrete optimization). Mathe-

matics Magazine, 65(1):18–26.

Fidanova, S., Alba, E., and Molina, G. (2009). Memetic

simulated annealing for the gps surveying problem.

pages 281–288.

Fink, A. and S., V. (2002). Optimization Software Class Li-

braries. Operations Research/Computer Science In-

terfaces Series. Boston, Massachusetts.

Kirkpatrick, S. (1983). Optimization by simulated anneal-

ing. Science, 220(4598):671–680.

Kreher, D., Royle, G., and Wallis, W. (1996). A family

of resolvable regular graph designs. Discrete Math.,

156(1-3):269–275.

Laarhoven, P. J. M. and Aarts, E. H. L., editors (1987). Sim-

ulated annealing: theory and applications. Kluwer

Academic Publishers, Norwell, MA, USA.

Lopez-Escogido, D., Torres-Jimenez, J., Rodriguez-Tello,

E., and Rangel-Valdez, N. (2008). Strength two cov-

ering arrays construction using a sat representation. In

LNCS 5317/2008, pages 44–53.

Morales, L. (1997). Scheduling a bridge club by tabu

search. Mathematics Magazine, 70(4):287–290.

Simpson, R. (1997). Scheduling a bridge club us-

ing a genethic algorithm. Mathematics Magazine,

70(4):281–286.

Taguchi, G. (1994). Taguchi Methods: Design of Experi-

ments. American Supplier Institute.

PROBLEM AND ALGORITHM FINE-TUNING - A Case of Study using Bridge Club and Simulated Annealing

305
