C-FUZZY DECISION TREES IN DEFAULT PREDICTION OF

SMALL ENTERPRISES

Maria Luiza F. Velloso, Thales Ávila Carneiro

Department of Eletronics, Rio de Janeiro State University, São Francisco Xavier 524, Rio de Janeiro, Brazil

José Augusto Gonçalves do Canto

Institute of Political Science and Economics, Candido MendesUniversity, Rio de Janeiro, Brazil

Keywords: Decision trees, Fuzzy clustering, Default prediction.

Abstract: This work uses fuzzy c-tree in order to predict default in small and medium enterprises in Brazil, using

indexes that reflect the financial situation of enterprise, such as profitable capability, operating efficiency,

repayment capability and situation of enterprise’s cash flow, etc. Fuzzy c-trees are based on information

granules—multivariable entities characterized by high homogeneity (low variability). The results are

compared with those produced by the “standard” version of the decision tree, the C4.5 tree. The

experimental study illustrates a better performance of the C-tree.

1 INTRODUCTION

The issue of credit availability to small firms has

garnered world-wide concern recently. Small and

Medium Enterprises (SMEs) are almost 99% of the

total number of firms in Brazil, and they offer 78%

of the jobs in the country. But, around 80% of SMEs

is shut down before one year of activity. Many

public and financial institutions launch each year

plans in order to sustain this essential player of

nation economies (Altman, Sabato, 2006).

Borrowing remains undoubtedly the most important

source of external SME financing.

SMEs in Brazil share some characteristics with

the private individuals:

− Large number of applications

− Small profit margins

− Irregular available information (especially

for the micro companies).

Small firms may be particularly vulnerable

because they are often so informationally opaque,

and the informational wedge between insiders and

outsiders tends to be more acute for small

companies, which makes the provision of external

finance particularly challenging (Berger, Udell,

2002). Some financial ratios are used in the context

of default prediction in small and micro firms

operating in a state of Brazil and we choose some of

them, as described in Section 3.

Although the enterprise’s wish of returning loan,

which is represented by the rate of returning

interests, we often don’t have any information about

the amount of interests that has been repaid by

enterprises that are requiring a loan for the first time.

In this case, the prediction of default relies on

information in the balance sheet of these enterprises.

Decision trees (Quinlan, 1986) are the

commonly used architectures of machine learning

and classification systems, particularly in default

prediction or scoring. They come with a

comprehensive list of various training and pruning

schemes, a diversity of discretization (quantization)

algorithms, and a series of detailed learning

refinements. In spite of such variety of the

underlying development activities, one can easily

find several fundamental properties that are common

in the entire spectrum of the decision trees. First, the

trees operate on discrete attributes that assume a

finite (usually quite small) number of values.

Second, in the design procedure, one attribute is

chosen at a time. More specifically, one selects the

most “discriminative” attribute and expands (grows)

the tree by adding the node whose attribute’s values

are located at the branches originating from this

node. The discriminatory power of the attribute

Velloso M., Carneiro T. and Canto J. (2009).

C-FUZZY DECISION TREES IN DEFAULT PREDICTION OF SMALL ENTERPRISES.

In Proceedings of the International Joint Conference on Computational Intelligence, pages 94-98

DOI: 10.5220/0002324500940098

 SciTePress

(which stands behind its selection out of the

collectionof the attributes existing in the problem at

hand) is quantified by means of some criterion such

as entropy, Gini index, etc. (Weber, 1992).

Fuzzy clustered-oriented decision trees have an

structure where data can be perceived as a collection

of information granules (Pedrycz, Sosnowski, 2004).

Information granules are represented by clusters.

The continuous nature of the classes is captured by

fuzzy clusters. Fuzzy granulation deals with the

discretization problem in the formation of the tree in

a direct and intimate manner.

This work uses fuzzy c-tree in order to predict

default in small and medium enterprises in Brazil,

using indexes that reflect the financial situation of

enterprise, such as profitable capability, operating

efficiency, repayment capability and situation of

enterprise’s cash flow, etc.

Section 2 reviews some concepts of Fuzzy

Decision C- Trees and Section 3 describes the

experiment.

2 CLUSTER DECISION TREE

The architecture of the cluster–based decision tree

develops around fuzzy clusters that are treated as

generic building blocks of the tree. The training data

set X={x(k),y(k)}, k=1,2, …, N, where x(k) ∈ R

is clustered into clusters so that the similar data

points are put together.

These clusters are completely characterized by

their prototypes (centroids). They are positioned at

top nodes of the tree structure. The way of building

the clusters implies a specific way in which we

allocate elements of X to each of them. Each cluster

comes with a subset of X, namely X

, X

, … , X

The process of growing the tree is guided by a

certain heterogeneity criterion that quantifies a

diversity of the data (with respect to the output

variable y) falling under the given cluster (node).

We can choose the nodes with the highest

heterogeneities values and treat them as candidates

for further refinement.

The process is repeated by selecting the most

heterogeneous node out of all final nodes. The

growth of the tree is carried out by expanding the

nodes and building their consecutive levels that

capture more details of the structure. It is noticeable

that the node expansion leads to the increase in

either the depth or width (breadth) of the tree. The

pattern of the growth is very much implied by the

characteristics of the data as well as influenced by

the number of the clusters.

2.1 Tree Development

Fuzzy clustering is a core functional part of the

overall tree. It builds the clusters and the standard

fuzzy C-means (FCM) (Bezdek, 1981) is used.

For the purpose of clustering the ordered pairs

{x(k),y(k)} are concatenated. This implies that the

clustering takes place in the (d+1) dimensional

space and involves the data distributed in the input

and output space. Likewise, the resulting prototype

) is positioned in R

d+1

.The coordinates of the

prototype are split into two parts as follows:

= {v

, v

, …, v

} = {f

, f

, …, f

}

and

= f

n+1

The first part, v

, describes a prototype located in the

input space and it is used in the classification

(prediction) mode.

The growth process of the tree is pursued by

quantifying the diversity of data located at the

individual nodes of the tree and splitting the nodes

that exhibit the highest diversity. This criterion takes

into account the variability of the data, finds the

node with the highest value of the criterion, and

splits it into c nodes that occur at the consecutive

lower level of the tree.

The ith node N

can be represented as an ordered

triple

= < X

, Y

, U

> (1)

denotes all elements of the data set that

belong to this node in virtue of the highest

membership grade

{

(k)∣u

(k) > u

(k) for all

≠i

}

(2)

The index j pertains to the nodes originating

from the same parent.

The second set collects the output coordinates of

the elements that have already been assigned to X

Likewise, U

= [u

(x(1)), u

(x(2)), …., u

((x(N))] is a

vector of the grades of membership of the elements

in X

We define the representative of this node

positioned in the output space as the weighted sum

(note that in the construct hereafter we include only

those elements that contribute to the cluster so the

summation is taken over X

and Y

), as follows:

(

)

(

)

(

)

()()

∑

kxu

kykxu

(3)

C-FUZZY DECISION TREES IN DEFAULT PREDICTION OF SMALL ENTERPRISES

The variability of the data in the output space

existing at this node V

is taken as a spread around

the representative ( m

) where again we consider a

partial involvement of the elements in X

weighting the distance by the associated

membership grade,

()()

(

)()

() ()()

∑

−

×∈

YXkykx

mky

kxuV

(4)

In the next step, we select the node of the tree

(leaf) that has the highest value of V

, and expand

the node by forming its children by applying the

clustering of the associated data set into c clusters.

The process is then repeated: we examine the leaves

of the tree and expand the one with the highest value

of the diversity criterion.

The growth of the tree is controlled by conditions

under which the clusters can be further expanded

(split).We envision two intuitively conditions that

tackle the nature of the data behind each node.

The first one is self-evident: a given node can be

expanded if it contains enough data points. With

clusters, we require this number to be greater than

the number of the clusters; otherwise, the clusters

cannot be formed.

The second stopping condition pertains to the

structure of data that we attempt to discover through

clustering. It becomes obvious that once we

approach smaller subsets of data, the dominant

structure (which is strongly visible at the level of the

entire and far more numerous data set) may not

manifest that profoundly in the subset. It is likely

that the smaller the data, the less pronounced its

structure. This becomes reflected in the entries of the

partition matrix that tend to be equal to each other

and equal to 1/c.

If no structure becomes present, this equal

distribution of membership grades occurs across

each column of the partition matrix.

The diversity criterion (sum of variabilities at

the leaves) can be also viewed as another

termination criterion.

2.2 Classification (Prediction) Mode

Once the C-tree has been constructed, it can be used

to classify a new input ( x) or predict a value of the

associated output variable (denoted here by ).

In the calculations, we rely on the membership

grades computed for each cluster as the standard

fuzzy C-means (FCM). The calculations pertain to

the leaves of the C-tree, so for several levels of

depth we have to traverse the tree first to reach the

specific leaves. This is done by computing u

(x) and

moving down. At some level, we determine the path

that maximizes u

(x). The process repeats for each

level of the tree. The predicted value occurring at the

final leaf node is equal to m

defined in Equation (3).

3 DEFAULT PREDICTION

The sample data set comes from a state-owned

commercial bank. The dataset of 243 samples

represent SMEs. Among these enterprises, the

number of the enterprises which can repay the loan

is 123, the rest 120 are those which can not repay the

loan.

In order to evaluate the performance of the tree a

fivefold cross-validation was used. More

specifically, in each pass, an 80–20 split of data is

generated into the training and testing set,

respectively, and the experiments are repeated for

five different splits for training and testing data.

The binary default variable Yi = 1 if firm i

defaults, and Y

= 0 otherwise.

Our model is an accounting based model. In this

kind of model, accounting balance sheets are used

and the input indexes include the enterprise’s

capability of returning loan and wish of returning

loan. The wish of returning loan is measured by the

rate of returning interests, namely

= Amount of interests that has been repaid /

Amount of interests that should be repaid.

The capability of returning loan is measured by

several indexes that reflect the financial situation of

enterprise, such as profitable capability, operating

efficiency, repayment capability and situation of

enterprise’s cash flow, etc. The several rates are as

follows:

= Earnings before taxes / Average total assets

= Total liabilities / Ownership interest

= Operational cash flow / Total liabilities

= Working capital / Total assets.

Each index represented the average of three

periods before the prediction period.

In order to evaluate the performance of the tree a

fivefold cross-validation was used. More

specifically, in each pass, an 80–20 split of data is

generated into the training and testing set,

respectively, and the experiments are repeated for

five different splits for training and testing data.

The chosen number of clusters was c=2, since

we were dealing with a binary classification. We

selected the first node of the tree, which is

IJCCI 2009 - International Joint Conference on Computational Intelligence

characterized by the highest value of the variability

index, and expand it by forming two children nodes

by applying the FCM algorithm to data associated

with this original node. The decision tree grown in

this manner is visualized in Fig. 1. Nodes in gray

represent zero variability. All leaves of the tree have

zero variability. Therefore, the error in training

dataset was zero.

Figure 1: Fuzzy c-tree structure. Gray circles have zero

variability.

It is of interest to compare the results produced

by the C-decision tree with those obtained when

applying “standard” decision trees, namely C4.5.

The results are summarized in Table 1. We

report the mean values of the error. For the C-

decision trees, the number of nodes is equal to the

number of clusters multiplied by the number of

iterations. The C-tree is more compact (in terms of

the number of nodes). This is not surprising as its

nodes are more complex than those in the C4.5

decision tree. The results on the training and test sets

are better for the C-trees.

Table 1: C-decisions tree and C4.5 results.

Decision

Tree

Error

Training

Error Test Nodes

C-tree 0% 20% 10

C4.5 10% 35% 14

4 CONCLUSIONS

The C-decision trees are classification constructs

that are built on a basis of information granules—

fuzzy clusters. In contrast to C4.5-like trees, all

features are used once at a time, and such a

development approach promotes more compact trees

and a versatile geometry of the partition of the

feature space. The experimental study illustrates a

better performance of the C-tree. Further research

should be conducted to test the potential

improvements associated with such approach. New

strategies for splitting nodes can be developed as

well as for stopping criterions. We intend conduct

research in order to extract rules with improved

interpretability. Others comparisons could be

experimented. In spite of the simplicity adopted, the

experimental results confirm the effectiveness of c-

trees in default prediction of SMEs .

REFERENCES

Altman, Edward I., Sabato, Gabriele. 2006. The Impact of

Basel II on SME Risk Management, 7° Forum

Internacional de Credito SERASA, Sao Paulo - Brazil

Berger, Allen N. Moore, Udell, Gregory F. ,2002. Small

Business Credit Availability and Relationship

Lending: The Importance of Bank Organisational

Structure. The Economic Journal, Vol. 112, 2002.

J. R. Quinlann, “Induction of decision trees,” Machine

Learning. 1, pp. 81–106, 1986.

W. P. Alexander and S. Grimshaw, “Treed regression,” J.

Computational Graphical Statistics, vol. 5, pp. 156–

175, 1996.

L. Breiman, J. H. Friedman, R. A. Olshen, and C. J.

Stone, Classification and Regression Trees. Belmont,

CA: Wadsworth, 1984.

A. K. Jain et al., “Data clustering: A review,” ACM

Comput. Surv., vol. 31, no. 3, pp. 264–323, Sep. 1999.

C4.5: Programs for Machine Learning. San Francisco,

CA:Morgan Kaufmann, 1993.

R.Weber, “Fuzzy ID3: A class of methods for automatic

knowledge acquisition,” in Proc. 2nd Int. Conf Fuzzy

Logic Neural Networks, Iizuka, Japan, Jul. 17–22,

1992, pp. 265–268.

W. Pedrycz, Z. A. Sosnowski, “C–Fuzzy Decision Trees”,

IEEE Transactions on Systems, Man, and Cybernetics,

Part C: Applications and Reviews, Vol. 35, No. 4,

2005.

J. C. Bezdek, Pattern Recognition with Fuzzy Objective

Functions, New York: Plenum, 1981.

W. Hardle. Applied nonparametric regression, Institut fur

Statistik und Okonometrie Spandauer Str.1,D-10178

Berlin, 1994.R., Lopes, J., 1999.

C-FUZZY DECISION TREES IN DEFAULT PREDICTION OF SMALL ENTERPRISES
