NEURONS OR SYMBOLS

Why does OR Remain Exclusive?

Ekaterina Komendantskaya

School of Computer Science, University of St Andrews, U.K.

Keywords:

Computational logic in neural networks, Neuro-symbolic networks, Connectionism, Hybrid networks.

Abstract:

Neuro-Symbolic Integration is an interdisciplinary area that endeavours to unify neural networks and symbolic

logic. The goal is to create a system that combines the advantages of neural networks (adaptive behaviour,

robustness, tolerance of noise and probability) and symbolic logic (validity of computations, generality, higher-

order reasoning). Several different approaches have been proposed in the past. However, the existing neuro-

symbolic networks provide only a limited coverage of the techniques used in computational logic. In this

paper, we outline the areas of neuro-symbolism where computational logic has been implemented so far, and

analyse the problematic areas. We show why certain concepts cannot be implemented using the existing

neuro-symbolic networks, and propose four main improvements needed to build neuro-symbolic networks of

the future.

1 INTRODUCTION

The joint efforts of researchers in many areas have

given many insights on how logic and neuroscience

can relate

: Boolean (binary) networks can com-

pute logical connectives (McCulloch and Pitts, 1943;

Aleksander and Morton, 1993); binary threshold net-

works can simulate Finite Automata, (Universal) Tur-

ing machines can be simulated by neural networks

with rational weights (Siegelmann, 1999).

The natural question that arises is how neural net-

works can cope with logical theories and calculi. The

traditional approach developed by neuro-symbolic

community is based upon McCulloch and Pitts binary

neural networks and encodes the semantics of ﬁrst-

order logic theories in neural networks. The books

(d’Avila Garcez et al., 2002; d’Avila Garcez et al.,

2008) and papers (Bader et al., 2008; Domingos,

2008; H¨olldobler et al., 1999; Lange and Dyer, 1989;

Hitzler et al., 2004; Wang and Domingos, 2008) are

good examples of this approach. We discuss here

why this kind of view has not yet resulted in a neuro-

symbolic system that successfully implements algo-

rithms of computational logic.

The title of this position paper is inspired by the book

”Neurons and Symbols”, (Aleksander and Morton, 1993),

that claimed, rather convincingly, that neural and symbolic

approaches to computation and information processing can

be considered as two complementary sides of one machine.

Throughout this paper, we make one subtle dis-

tinction between the levels of abstraction one uses

when speaking about relations between logic and neu-

ral networks. The most fundamental results relating

logic and neural networks, such as papers by McCul-

loch and Pitts (McCulloch and Pitts, 1943), Kleene

(Kleene, 1956), books by von Neumann (Neumann,

1958) and Minsky (Minsky, 1954; Minsky, 1969),

considered neural networks at the level of automata

and computing machines, showing that the neural net-

works, taken as a hardware, can simulate computa-

tions performed by digital computers.

This line of research has been successfully devel-

oped. There has been series of publications concern-

ing computational complexity of neural networks and

their relation to Turing computability. Pollack (Pol-

lack, 1987) showed that a particular type of heteroge-

neous processor network is Turing universal. Siegel-

mann and Sontag (Siegelmann and Sontag, 1991)

showed the universality of homogeneous networks of

ﬁrst-order neurons having piecewise-linear activation

functions. Their results were generalised by Kilian

and Siegelmann (Kilian and Siegelmann, 1996) to

include various sigmoidal activation functions. The

number of neurons required for universality with ﬁrst-

order neurons was estimated at 886 (Siegelmann and

Sontag, 1995), and in the later papers was reduced

to 96 (Koiran et al., 1994) and down to 25 (Indyk,

1995). In (Siegelmannand Margenstern, 1999), it was

502

Komendantskaya E. (2009).

NEURONS OR SYMBOLS - Why Does OR Remain Exclusive?.

In Proceedings of the International Joint Conference on Computational Intelligence, pages 502-507

DOI: 10.5220/0002334805020507

 SciTePress

shown that there is a universal neural network with

nine switch-afﬁne neurons which is Turing universal.

A good summary can be found in (Siegelmann, 1999).

The paper by McCulloch and Pitts (McCulloch

and Pitts, 1943) started another line of research

into the relation between logic and neural networks.

Namely, Connectionism, and one of its branches -

Neuro-Symbolic Integration (G¨usgen and H¨olldobler,

1992; Bader and Hitzler, 2005; Hammer and Hitzler,

2007) took up this problem at another level of ab-

straction. Neural networks were taken as a ready-to-

use tool in which one could implement some aspects

of logical deduction. Unlike the theoretical line of

research we described above, this approach did not

necessarily involve general translation of automata or

Turing machines into Neural networks. On the con-

trary, it often explored the ways of developing neural

networks architectures that could be suitable for a par-

ticular task in computational logic. The generality of

the theoretical level was sacriﬁced for convenient and

efﬁcient implementations. We give a survey of this

approach in Section 2.

We also note here, that this second approach to

developing neuro-symbolic networks has been inﬂu-

enced by the fact that the hardware development of

digital computers took over from neuro computers;

and the development of neural networks became more

a question of software than of a hardware. And this

justiﬁes the changes in the style of neuro-symbolism.

However, neuro-symbolic networks have not yet

become a useful tool in computational logic. Instead,

neuro-symbolism has found its place somewhere on

the intersection of artiﬁcial intelligence, cognitivesci-

ence, and linguistics. See (Markus, 2001; Smolensky

and Legendre, 2006) for very successful examples. In

Section 3, we formulate four principles that are es-

sential for implementing algorithms of computational

logic. We conclude in Section 4.

2 PROPERTIES OF EXISTING

NEURO-SYMBOLIC NETS

Many of the neuro-symbolic networks rely on the rep-

resentation of logical connectives by McCulloch and

Pitts (McCulloch and Pitts, 1943). We start with a

simple example concerning a very popular approach

to implementing semantic operators for logic pro-

grams in neural networks.

Logic programs consist of clauses of the form

A ← B

, . . . , B

, where A, B

, . . . , B

are atomic (ﬁrst-

order) formulae. For a given program P, the Herbrand

Base B

is a set that contains all possible ground in-

stances of atomic formulae appearing in P. Given a

logic program P, one can deﬁne a semantic opera-

tor T

that computes the least Herbrand model of P:

(I) = {A ∈ B

: A ← B

, . . . , B

is a ground instance

of a clause in P and {B

, . . . , B

} ⊆ I}, where I is an

interpretation of a program given by a set of proposi-

tions that are true. See (Lloyd, 1987) for formal de-

scription.

Theorem 1. (H

olldobler and Kalinke, 1994;

olldobler et al., 1999) For each propositional logic

program P, there exists a 3-layer recurrent neural

network built of binary threshold units that computes

We will call these networks T

-neural networks

and illustrate them below. The theorem extends to

function-free ﬁrst-order logic programs, and other

subclasses of ﬁrst-order logic programs that have ﬁ-

nite models. First-order logic programs in their full-

generality may have inﬁnite models, and these cases

would require inﬁnite neural networks, see (Hitzler

et al., 2004; Bader et al., 2008) for discussions and

solutions.

Example 1. Consider the ground logic program:

B ←

A ←

C ← A, B.

The neural network below computes T

↑ 2 =

{A, B, C}, that is, the least model of P, in two itera-

tions. Each of the atoms A, B, C is represented by a

neuron in the output and input layers. Connections

between the hidden layer and both outer layers are

set in a particular way that reﬂects the structure of

clauses. The weights of the recurrent connections be-

tween the output and the input layer are set to 1. That

is, all the connections

on the following dia-

gram have weights set to 1. Numbers 0.5, −0.5, etc.

show the thresholds (biases) of the neurons. The ac-

tivation functions are binary, that is, if the neuron re-

ceives a signal greater than its threshold, it outputs 1;

and it outputs 0 otherwise.

B C

GFED@ABC

0.5



GFED@ABC

0.5



GFED@ABC

0.5



ONMLHIJK

−0.5

ONMLHIJK

−0.5

GFED@ABC

1.5

GFED@ABC

0.5

GFED@ABC

0.5

GFED@ABC

0.5

B C

NEURONS OR SYMBOLS - Why Does OR Remain Exclusive?

503

There are three characteristic properties that

distinguish T

-neural networks. We summarise them

as follows.

1. For a given program P, the number of neurons in

the input and output layers is the number of atoms

in the Herbrand base B

2. Signals of T

-neural networks are binary, and this

provides the computations of truth value functions

∧ and ← that are used in program clauses.

3. As a consequence of the property (3), ﬁrst-order

atoms are not represented in the neural network

directly, and only truth values 1 and 0, that are the

same for all the atoms, are propagated.

These three properties arise from a more general

Principle universally applicable to neuro-symbolic

networks of other kinds: When processing a logic

theory, the neural networks process truth values of

the ground instances of formulae, and compute the

models of the theory as a result. Moreover, each

ground instance of an atom from the given theory

should be represented by at least one neuron.

The main Principle has three main conse-

quences. The resulting network cannot:

• directly deal with recursive programs, that is, pro-

grams that can have inﬁnitely many ground in-

stances;

• deal with non-ground reasoning that is common

in computational logic;

• cover proof-theoretic aspect of logic theories;

One would be surprised to ﬁnd how often neuro-

symbolic systems of different architectures obey the

main Principle and its three consequences. We will

consider some examples.

There were attempts to develop an original Learn-

ing Theory within Neuro-Symbolic integration. In

(d’Avila Garcez et al., 2002; d’Avila Garcez et al.,

2008), binary threshold units in the hidden layer of

networks were replaced by sigmoidal units. Such

networks allow back-propagation which can be used

to train neural networks. These neural networks obey

the general Principle, albeit they process signals from

the interval [−1, 1]. They were applied to inductive

logic programming, where facts in a database can be

assigned some measures of probabilities. The values

from the interval [−1, 0] were recognised by the out-

put unit as “false”, and the values from the interval

[0, 1] as “true”.

The Markov Logic Networks (Wang and Domin-

gos, 2008; Domingos, 2008) are another possible

modiﬁcation of T

-neural networks. Here, the compu-

tational power of Markov chains and stochastic (prob-

abilistic) methods was used to give an account of

Logics of Probabilities. These networks do not use

a semantic operator directly, but the methodology is

very close to T

-networks, in that the networks rely

on ground instances of atoms appearing in logic pro-

grams, and propagate their truth values. This model

has been successfully applied to many practical prob-

lems, but it still obeys the main Principle.

Propositional Modal Logic Programs (d’Avila

Garcez et al., 2007; d’Avila Garcez et al., 2008).

Construction of T

-neural networks was exactly re-

produced in this approach, the only difference being

that it was adapted to Kripke semantics. That is, in

each possible world (by Kripke) one could have a sep-

arate T

-neural network computing classical values.

Fibrational Neural Networks. Some research was

done on creating networks of T

-neural networks,

they were called Fibring Neural Networks in (d’Avila

Garcez and Gabbay, 2004).

Many-Valued Logic Programs. This approach was

developed in (Komendantskaya et al., 2007; Komen-

dantskaya, 2007). Here, binary neurons represented

some atom together with its value, and several ad-

ditional layers were needed in order to reﬂect some

additional properties of many-valued semantic oper-

ators. These networks have the same properties as

-networks.

There have been several papers relating Fuzzy

Prolog and Fuzzy Neural Networks, (Ding, 1995;

Nauck et al., 1997; Zadeh, 1992). The resulting neu-

ral networks are called Fuzzy-Logical Neural Net-

works. The authors of (Nauck et al., 1997) show

that Fuzzy Logic Programs can be simulated by feed-

forward neural networks; moreover, they use learning

algorithms when working with fuzzy numbers. The

Fuzzy-Logical Neural Nets are capable of propagating

fuzzy signals, and not just 0, 1. If we examine Fuzzy-

Logical Neural Networks relative to the T

-neural net-

works, we will notice that they are not correlated with

semantic operators any more, however, they still obey

the main Principle, in that they work with truth val-

ues and functions over truth values, and do not encode

ﬁrst-order atoms directly.

Even with approaches that are not directly tied to

logic programs, such as (Pollack, 1990; Shastri and

Ajjanagadde, 1993), one can notice that the networks

essentially rely upon ground reasoningand binary sig-

nal processing.

3 OBSTACLES AND SOLUTIONS

Networks considered in the previous section have

been successfully implemented for certain practical

IJCCI 2009 - International Joint Conference on Computational Intelligence

504

or industrial problems. But they did not advance our

understanding of how inference algorithms used in

computational logic and proof theory could be imple-

mented in neural networks.

In this section, we offer four principles for devel-

oping neuro-symbolic networks suitable for simulat-

ing the algorithms of computational logic.

1. Implementation of Techniques from Proof The-

ory should not be Replaced by the Model Theory.

There are two reasons why such a replacement cannot

lead to successful implementations of computational

logic.

In the case of ﬁrst-order theories, the semantics is

often developed on the meta-level, not using the syn-

tax of the theory. For example, ﬁrst-order logic pro-

grams are executed by the algorithms of uniﬁcation

and SLD-resolution, whereas their semantics is given

by semantic (ﬁxed point) operators. Neural-symbolic

networks we have surveyed can do the semantics of (a

restricted class of) ﬁrst-order logic programs, but not

the syntactic inference. And implementations of the

former did not lead to the implementation of the lat-

ter. Using logic programming terminology, the neuro-

symbolic networks could do declarative semantics,

but not the operational one.

Another obstacle is that the traditional Neuro-

Symbolic Networks, owing to their dependence on

truth value assignments and ﬁrst-order semantics, do

not adapt well to higher-order logics and type theory.

Moreover, in typed theories, such as typed lambda

calculus or the calculus of constructions, the very

distinction between syntax and semantics is erased,

and manipulations with types of expressions are per-

formed using the syntax of the theory, and this, in its

turn, justiﬁes correctness of computations.

Because the existing neuro-symbolic networks do

not adapt well to the two major trends in compu-

tational logic – automated proving (given by oper-

ational semantics of ﬁrst-order logic programs) and

Type theory, – they have not yet found their proper

niche in the area, and are normally conceived as a

branch of AI rather than of computational logic.

2. Direct Processing of Logic Terms should be Pre-

ferred to Processing of their Truth Values. This

can be achieved by using a one-to-one numerical en-

coding of the symbols of the formal alphabet, such

as G¨odel numbering. The main difﬁculty here is to

represent strings of such numbers.

Logic formulae are effectively strings of symbols

of a given alphabet. However, according to a general

convention, neurons do not process strings, or ordered

sequences, or any other structured data. Every neu-

ron can accept only a scalar as a signal, and output a

scalar in its turn. This general convention has been

developed through decades of discussion, and differ-

ent views on it are best summarised in (Aleksander

and Morton, 1993; Smolensky and Legendre, 2006).

However, some order is innate to neural networks:

and this order is imposed by position of neurons in a

given layer, and by positions of layers in a network.

So, although each neuron accepts only a scalar num-

ber as an input, a layer of neurons accepts a vector

of such numbers, and the whole network can accept a

matrix of numbers.

Therefore, a vector of neurons in a layer mirrors

the structure of a string, and the matrix that describes

a many-layered neural network mirrors the structure

of a tree. This is all we need to encode logical terms

(strings of symbols of an alphabet), and term trees -

in case we use a tree-like representation of terms in

parallel algorithms. See (Pollack, 1990; Smolensky

and Legendre, 2006) for related discussion.

Given a ﬁrst-order formula F = P(t) built from

the symbols of the alphabet A, and having a one-to-

one numerical encoding of A given by a function η,

the vector [P

; (

; t

; )

] can be directly used as an

input or weight vector in a neural network. Here, we

denote the result of applying η to a symbol x by x

3. Levels of Abstraction should not be Mixed. Two

levels of abstraction we mentioned in the introduction

can provide two different solutions to the problem of

simulating symbolic logic in neural networks. On the

low level, we can build a network that simulates Tur-

ing machines, and then use it for symbolic computa-

tions. This approach can be bulky, and for this reason

logic algorithms are commonly written on a higher

level of abstraction than Turing machines. We suggest

to look for direct representations of these high-level

algorithms in Neural networks, ignoring the low-level

theoretical correspondence between neural networks

and Turing machines.

This direct approach may seem to lack generality;

nevertheless, we claim that it can be very useful in

practice. Consider, for example, the algorithm of ﬁrst-

order uniﬁcation due to (Robinson, 1965), that is used

as one of the basic and essential algorithms in proof

theory and computational logic. It is P-complete and

can be performed by a Turing machine, however, its

deﬁnition in terms of Turing machines can be bulky.

Its traditional description is as follows.

Suppose we have two ﬁrst-order formulae P(a)

and P(x). The algorithm of uniﬁcation will inspect

each symbol in the formulae, and pick two symbols

that disagree - x and a. Then it will substitute a for x in

P(x), and thus, the two formulae will be uniﬁed. This

can be done using a conventional error-correction

learning in neural networks. We simply need to

NEURONS OR SYMBOLS - Why Does OR Remain Exclusive?

505

take numerical vector representation of the symbolic

terms; let [P

; (

; a

; )

] and [P

; (

; x

; )

] de-

note the numerical encodings. Take a layer of 4

neurons. Let the weight vector be [P

; (

; x

; )

]

and the bias vector be [P

; (

; a

; )

]. Set the ac-

tivation function to be linear, and the target to be

[0; 0; 0; 0]. Send the signal 1 to the network, it

will output [0; 0; (x

− a

); 0]. Thus, the error –

the difference between the desired response and the

output – will be [0; 0; −(x

− a

); 0]. The error-

correction algorithm will amend the weight vector,

and, on the next iteration, the weight vector will be

; (

; a

; )

], and the error will be zero. See

(Komendantskaya, 2009b).

This example illustrates that some algorithms of

computational logic have direct analogy with the

learning algorithms of neurocomputing. This direct

use of neural networks for implementations of com-

putational logic should be further exploited.

This discussion of the uniﬁcation by error-

correction learning leads us to the last thesis:

4. Attitude to Learning Functions should be More

Liberal, and Allow Symbolic Components. Com-

ing back to the previous example, it is impossible to

get a general-purpose network that performs uniﬁca-

tion algorithm without adding a certain symbolic de-

scription into the deﬁnition of the learning function.

For example, we need to make sure that only a can

be substituted for x, and not x for a. In case we deal

with function symbols in the language, we may need

to substitute f(y) for x, and then the network will need

to be enlarged. Also, the occur check should be per-

formed, e.g., we should make sure that f(x) is not

substituted for x.

Among the advantages of having such hybrid

networks would be that simply switching between

conventional and pseudo-symbolic learning functions

one can achieve multi-functionality of the resulting

neural network. Another advantage is parallelism.

The algorithm of uniﬁcation is not the only algo-

rithm of computational logic that yields a simple and

direct representation as a learning process. As an-

other example, parallel (term)-rewritingcan be shown

to correspond to a form of Hebbian learning. That

is, given a string [1 2 3 1 2 3], a 6-neuron layer can

perform a rewriting operation for the rewriting rule

x → 3x using a Hebbian learning rule. For this, we

simply need to set the weight vector to be [1 2 3 1 2 3],

set the rate of learning to be 2, and send the input sig-

nal 1. At the next iteration, the weight will be rewrit-

ten to [3 6 9 3 6 9]. This example, moreover, shows

that neural networks are capable of parallel rewriting,

which will bring a much desired speed up to the com-

putations; (Komendantskaya, 2009a).

In order for this scheme to cover a more symbolic

form of rewriting — a term-rewriting — one must

allow a symbolic component into the conventional

learning function to deal with the symbolic subtleties

that arise when we rewrite and substitute ﬁrst-order

terms.

4 CONCLUSIONS

We separated two levels of abstraction at which the

relations between “neurons” and “symbols” can be

considered. We restricted our attention to the im-

plementational level. We analysed common proper-

ties of existing neuro-symbolic networks, and showed

that they obey one general Principle. This Princi-

ple and its three main consequences cause the dis-

junction “Neurons OR Symbols” to remain exclusive

— that is, they prevent implementations of the sym-

bolic (proof-theoretic) aspects of computational logic

in neural networks. Finally, we proposed four princi-

ples for building neuro-symbolic nets of the future.

ACKNOWLEDGEMENTS

The work was sponsored by EPSRC PF research grant

EP/F044046/1.

REFERENCES

Aleksander, I. and Morton, H. (1993). Neurons and Sym-

bols. Chapman and Hall.

Bader, S. and Hitzler, P. (2005). Dimensions of neural sym-

bolic integration - a structural survey. In Artemov, S.,

editor, We will show them: Essays in honour of Dov

Gabbay, volume 1, pages 167–194. King’s College,

London.

Bader, S., Hitzler, P., and H¨olldobler, S. (2008). Connec-

tionist model generation: A ﬁrst-order approach. Neu-

rocomputing, 71:2420–2432.

d’Avila Garcez, A., Broda, K. B., and Gabbay, D. M.

(2002). Neural-Symbolic Learning Systems: Founda-

tions and Applications. Springer-Verlag.

d’Avila Garcez, A. and Gabbay, D. M. (2004). Fibring

neural networks. In Proceedings of the 19th National

Conference on Artiﬁcial Intelligence, pages 342–347.

AAAI Press/MIT Press, San Jose, California, USA.

d’Avila Garcez, A., Lamb, L., and Gabbay, D. (2007). Con-

nectionist modal logic: Representing modalities in

neural networks. Theoretical Computer Science, 1-

2(371):34–53.

IJCCI 2009 - International Joint Conference on Computational Intelligence

506

d’Avila Garcez, A., Lamb, L. C., and Gabbay, D. M.

(2008). Neural-Symbolic Cognitive Reasoning. Cog-

nitive Technologies. Springer-Verlag.

Ding, L. (1995). Neural prolog - the concepts, construction

and mechanism. In Proceedings of the 3rd Int. Confer-

ence Fuzzy Logic, Neural Nets, and Soft Computing,

pages 181–192.

Domingos, P. (2008). Markov logic: a unifying lan-

guage for knowledge and information management. In

CIKM, page 519.

G¨usgen, H. W. and H¨olldobler, S. (1992). Connectionist

inference systems. In Fronh¨ofer, B. and Wrightson,

G., editors, Parallelization in Inference Systems, pages

82–100. Springer, LNAI 590.

Hammer, B. and Hitzler, P. (2007). Perspectives of Neural-

Symbolic Integration. Studies in Computational Intel-

ligence. Springer Verlag.

Hitzler, P., H¨olldobler, S., and Seda, A. K. (2004). Logic

programs and connectionist networks. Journal of Ap-

plied Logic, 2(3):245–272.

H¨olldobler, S. and Kalinke, Y. (1994). Towards a massively

parallel computational model for logic programming.

In Proceedings of the ECAI94 Workshop on Com-

bining Symbolic and Connectionist Processing, pages

68–77. ECCAI.

H¨olldobler, S., Kalinke, Y., and Storr, H. P. (1999). Approx-

imating the semantics of logic programs by recurrent

neural networks. Applied Intelligence, 11:45–58.

Indyk, P. (1995). Optimal simulation of automata by neu-

ral nets. In Mayr, E. and Puech, C., editors, Proc. of

the Twelfth Annual Symposium on theoretical aspect

of Computer Science, LNCS, page 337.

Kilian, J. and Siegelmann, H. (1996). The dynamic univer-

sality of sigmoidal neural networks. Information and

Computation, 128(1):48–56.

Kleene, S. (1956). Neural nets and automata. In Automata

Studies, pages 3 – 43. Princeton University Press.

Koiran, P., Cosnard, M., and M.Garzon (1994). Com-

putability with low-dimensional dynamic systems.

Theoretical Computer Science, 132:113–128.

Komendantskaya, E. (2007). Learning and Deduction in

Neural Networks and Logic. PhD thesis, Department

of Mathematics, University College Cork, Ireland.

Komendantskaya, E. (2009a). Parallel rewriting in neural

networks. In Proceedings of ICNC’09.

Komendantskaya, E. (2009b). Uniﬁcation neural networks:

Uniﬁcation by error-correction learning. Submitted.

Komendantskaya, E., Lane, M., and Seda, A. (2007). Con-

nectionist representation of multi-valued logic pro-

grams. In Hammer, B. and Hizler, P., editors, Perspec-

tives of Neural-Symbolic Integration, Computational

Intelligence, pages 259–289. Springer Verlag. To ap-

pear.

Lange, T. E. and Dyer, M. G. (1989). High-level inferencing

in a connectionist network. Connection Science, 1:181

– 217.

Lloyd, J. (1987). Foundations of Logic Programming.

Springer-Verlag, 2nd edition.

Markus, G. (2001). The Algebraic Mind: Integrating Con-

nectionism and Cognitive Science. Cambridge, MA:

MIT Press.

McCulloch, W. and Pitts, W. (1943). A logical calculus

of the ideas immanent in nervous activity. Bulletin of

Math. Bio., 5:115–133.

Minsky, M. (1954). Neural Nets and the Brain - Model

Problem. PhD thesis, Princeton University, Princeton

NJ.

Minsky, M. (1969). Finite and Inﬁnite Machines.

Nauck, D., Klawonn, F., Kruse, R., and F.Klawonn (1997).

Foundations of Neuro-Fuzzy Systems. John Wiley and

Sons Inc., NY.

Neumann, J. V. (1958). The Computer and The Brain. Yale

University Press.

Pollack, J. (1987). On Connectionist Models of Natural

Language Processing. PhD thesis, Computer science

Department, University of Illinois, Urbana.

Pollack, J. (1990). Recursive distributed representations.

AIJ, 46:77–105.

Robinson, J. (1965). A machine-oriented logic based on

resolution principle. Journal of ACM, 12(1):23–41.

Shastri, L. and Ajjanagadde, V. (1993). From associations

to systematic reasoning: A connectionist representa-

tion of rules, variables and dynamic bindings using

temporal synchrony. Behavioural and Brain Sciences,

16(3):417–494.

Siegelmann, H. (1999). Neural Networks and Analog Com-

putation. Beyond the Turing Limit. Birkhauser.

Siegelmann, H. and Margenstern, M. (1999). Nine switch-

afﬁne neurons sufﬁce for Turing universality. Neural

Networks, 12:593–600.

Siegelmann, H. and Sontag, E. (1991). Turing computabil-

ity with neural nets. Applied Mathematics Letters,

4(6):77–80.

Siegelmann, H. and Sontag, E. (1995). On the computa-

tional power of neural nets. J. of Computers and Sys-

tem Science, 50(1):132–150.

Smolensky, P. and Legendre, G. (2006). The Harmonic

Mind. MIT Press.

Wang, J. and Domingos, P. (2008). Hybrid markov logic

networks. In AAAI, pages 1106–1111.

Zadeh, L. (1992). Interpolative reasoning in fuzzy logic and

neural network theory. Fuzzy Systems, pages 1–20.

NEURONS OR SYMBOLS - Why Does OR Remain Exclusive?

507
