PREREQUISITES FOR AFFECTIVE

IGNAL PROCESSING (ASP) – PART II

Egon L. van den Broek

The Netherlands

Joris H. Janssen

User Experience Group, Philips Research Europe, High Tech Campus 34, 5656 AE Eindhoven, The Netherlands

Jennifer A. Healey

Future Technology Research, Intel Labs Santa Clara, Juliette Lane SC12-319 Santa Clara CA 95054, U.S.A.

Marjolein D. van der Zwaag

User Experience Group, Philips Research Europe, High Tech Campus 34, 5656 AE Eindhoven, The Netherlands

Keywords:

Affective signal processing, Emotion, User identiﬁcation, Theoretical speciﬁcation.

Abstract:

Last year, in van den Broek et al. (2009a), a start was made with deﬁning prerequisites for affective signal

processing (ASP). Four prerequisites were identiﬁed: validation (e.g., mapping of constructs on signals),

triangulation, a physiology-driven approach, and contributions of the signal processing community. In parallel

with this paper, in van den Broek et al. (2010) another set of two prerequisites is presented: integration of

biosignals and physical characteristic. This paper continues this quest and deﬁnes two additional prerequisites:

identiﬁcation of users and theoretical speciﬁcation. In addition, the second part of a review on the classiﬁcation

of emotions through ASP is presented; the ﬁrst part can be found in van den Broek et al. (2009a).

1 INTRODUCTION

Almost half a century ago, Ulric Neisser (1963, p.

194) described three fundamental and interrelated

characteristics of human thought that are conspicu-

ously absent from existing or contemplated computer

programs.

1. Human thinking always takes place in, and con-

tributes to, a cumulative process of growth and

development.

2. Human thinking begins in an intimate association

with emotions and feelings which is never entirely

lost.

3. Almost all human activity, including thinking,

serves not one but a multiplicity of motives at the

same time.

Nonetheless, artiﬁcial intelligence (AI) aimed at un-

derstanding human thought and developing computa-

tional and executable models of human thought with-

out considering these three notions. Although, nowa-

days, a computer can beat the world’s best chess play-

ers, the general opinion is that AI has failed. We, and

others, think that Ulric Neisser’s words are of vital

importance and should be brought into AI practice.

In this paper, we will treat the second issue

Neisser raised, that of emotions and feelings or, in

other words, affect. Eversince Picard’s book Affective

Computing (AC) 1997, this direction of research has

received growing interest. However, as with AI, the

results with AC are disappointing. This is explained

by the fact that research relevant for AC is scattered

over a broad range of sciences and lacks generaliza-

tion and robustness.

To force a breakthrough in results on AC we pro-

188

L. van den Broek E., H. Janssen J., A. Healey J. and D. van der Zwaag M. (2010).

PREREQUISITES FOR AFFECTIVE SIGNAL PROCESSING (ASP) – PART II.

In Proceedings of the Third International Conference on Bio-inspired Systems and Signal Processing, pages 188-193

DOI: 10.5220/0002696601880193

 SciTePress

pose to consider a set of prerequisites for affective

signal processing (ASP), before starting with AC in

practice. The ﬁrst part of these prerequisites was in-

troduced last year in van den Broek et al. (2009a).

This set of prerequisites was, however, not complete.

This paper introduces the second part of the prerequi-

sites on ASP. In parallel, the third part of the prereq-

uisites on ASP is introduced in van den Broek et al.

(2010). Together, these three papers should form the

foundation for more successful ASP and AC.

In the next section, we will brieﬂy denote ASP and

AC, including a review presented in Table 1. This ta-

ble contains the second part of our survey on ASP and

AC, complementary to the part presented in van den

Broek et al. (2009a). Section 3 introduces two new

prerequisites for successful ASP, complementary to

both those introduced in van den Broek et al. (2009a)

and in van den Broek et al. (2010). Finally, we

draw conclusions and denote the prerequisites’ impli-

cations for applications on ASP.

2 AFFECTIVE SIGNAL

PROCESSING (ASP)

ASP is often employed from three specialized areas

of signal processing:

• movement analysis (Gunes and Piccardi, 2009),

• computer vision techniques (Gunes and Piccardi,

2009), and

• speech processing (Ververidis and Kotropoulos,

2006).

However, these signals still have their major disad-

vantages. In contrast, such issues have been resolved

for biosignals in recent years: currently, high ﬁdelity,

cheap, and unobtrusive biosignal recordings are easy

to obtain. Moreover,the recording devices can be eas-

ily integrated in various products (van den Broek and

Westerink, 2009; Gamboa et al., 2009). Therefore,

this paper focusses on biosignals. For an overview

of the most commonly used biosignals and their fea-

tures, we refer to van den Broek et al. (2009a).

The review in Table 1 illustrates both differences

and similarities among research on AC, conducted

over the last decade. As this table shows, most stud-

ies recorded people’s cardiovascular and electroder-

mal activity. However, differences between the stud-

ies prevail over the similarities. The number of par-

ticipants ranges from 1 to 50, although studies includ-

ing > 20 participants are relatively rare; cf. Table 1.

The number of features determined through ASP also

ranges considerably; i.e., from 3 to 193. Only half of

the studies applied feature selection/reduction, where

this would be advisable in general.

For AC, a broad plethora of classiﬁers are used.

The characteristics of the categories among which has

to be discriminated is different from most other clas-

siﬁcation problems. The emotion classes used are

typically ill deﬁned, which makes it hard to compare

studies. Moreover, the number of emotion categories

(i.e., the classes) to be discriminated ranges consider-

ably: from 2 to 8. Although these are small numbers

in terms of pattern recognition and machine learn-

ing, the results are behind that of other classiﬁcation

problems. With AC recognition rates of 60%–80%

are common, where in most other pattern recogni-

tion problems, recognition rates of > 90% and often

> 95% are often reported. This illustrates the com-

plex nature of AC and the need to consider prerequi-

sites for ASP.

3 PREREQUISITES – PART II

In van den Broek et al. (2009a), the ﬁrst set of prereq-

uisites for ASP was introduced: validity, triangula-

tion, a physiology-driven approach, and contributions

from signal processing. One additional set of prereq-

uisites is presented in van den Broek et al. (2010) and

comprises: physical characteristics and integration of

biosignals. Here we present a third set, which com-

plements the two other, by discussing user identiﬁca-

tion and theoretical speciﬁcation.

3.1 Tailored ASP – User Identiﬁcation

Throughout the ﬁeld of AC, an ongoing debate is

present on generic versus personal approaches to

emotion recognition. Some research groups special-

ized in AC have moved from general AC to AC for

specialized groups or individuals. For example, the

group of Picard currently focusses on autism (Picard

and Goodwin, 2008). In general, the identiﬁcation

of users has major implications for ASP. We propose

three distinct categories, among which research in af-

fective science could choose:

1. all: generic ASP; see also Table 1 and van den

Broek et al. (2009c);vanden Broek and Westerink

(2009)

2. group: tailored ASP; e.g., Choi and Woo (2005);

Sternbach and Tursky (1965)

3. individual: personalized ASP; e.g., Picard et al.

(2001); Healey and Picard (2005)

Although attractive from a practical point of view, the

category all will probably not solve the mysteries con-

PREREQUISITES FOR AFFECTIVE SIGNAL PROCESSING (ASP) - PART II

189

Table 1: An overview of 18 studies on automatic biosignal-driven classiﬁcation of emotions of the last decade.

information source year signals parti- number of selection / classiﬁers target classiﬁcation

cipants features reduction result

Picard et al. 2001 C ,E ,R ,M 1 40 SFS, Fisher LDA 8 emotions 81%

Lisetti & Nasoz 2002 C ,E ,S 10 3 - kNN, LDA 5 emotions 85%*

Kim et al. 2002 C ,E ,S 50 10 - SVM 4 emotions 61%

50/125 10 - SVM 3 emotions 55% / 78%

Kim et al. 2004 C ,E ,S 50 10 Fisher SVM 4 emotions 62%

3 emotions 78%

Rani et al. 2004 C ,E ,M 1 6 - FLS 2 anxiety levels ??%

Healey & Picard 2005 C ,E ,R ,M 9 22 Fisher LDA 3 stress levels 97%

Kim et al. 2005 C ,E ,R ,M 3 26 SFS LDF 4 emotions 53% / 74%

Lisetti & Nasoz 2005 C ,E ,S 41 86 - kNN, ANN (2x) 2 emotions (3 sets of) 92%

Liu et al. 2005 C ,E ,M 15 13(?) - kNN, RT, BN, SVM 5 emotions 86%

Liu et al. 2006 C ,E ,M ,S 14 35 - RT 3 anxiety levels 70%

Rainville et al. 2006 C ,G ,S ,M ,P 43 18 PCA LDA 4 emotions 49%

Jones & Troen 2007 C ,E ,R 13 11 - ANN 5 arousal levels 31% / 62%

5 valence levels 26% / 57%

Yang & Liu 2007 C ,E ,R ,M 1 193 BPSO kNN 4 emotions 86%

Kim 2007 C ,E ,R ,M ,S 3 77 SBS kNN, ANN, LDA 4 emotions 51%–71%

Cheng & Liu 2008 M 1 14 DWT ANN 4 emotions 75%

Lichtenstein et al. 2008 C ,E ,R ,M ,S 40 5 - SVM 5 emotions 47%

2 levels of arousal 82%

2 levels of valence 72%

Chanel et al. 2009 C ,E ,R 10 18 - LDA, SVM, RVM 3 emotions 51%

2 emotions 66%

Van den Broek et al. in press E ,M 21 10 ANOVA, PCA kNN, SVM, ANN 4 emotions 61%

Signals: C : cardiovascular activity; E : electrodermal activity; R : respiration; M : electromyogram; S : skin temperature; and P : pupil diameter. Selection:

PCA: Principal Component Analysis; SFS: Sequential Forward Selection; SBS: Sequential Backward Selection; BPSO: Binary Particle Swarm Optimization;

DWT: Discrete Wavelet Transform; Fisher: Fisher projection; and ANOVA: ANalysis Of VAriance. Classiﬁers: RT: Regression Tree; BN: Bayesian Network;

ANN: Artiﬁcial Neural Network; SVM: Support Vector Machine; RVM: Relevance Vector Machines; LDA: Linear Discriminant Analysis; kNN: k-Nearest

Neighbors; and FLS: Fuzzy Logic System. Note. * The authors present 100% successful classiﬁcation for two emotion categories. However, this might

indicate a questionable training and testing setup.

cerning affect. As is long known in neurology and

psychology, special cases can help in improving ASP.

For the categories group and individual, the fol-

lowing subdivision can be made:

1. Speciﬁc characteristics; e.g., autism (Picard and

Goodwin, 2008)

2. Psychological traits; e.g., Personality (Krohne

et al., 2002; van den Broek et al., 2009c) or em-

pathic intelligence (H˚akansson and Montgomery,

2003).

3. Demographics; e.g., age, sex, race (Sternbach and

Tursky, 1965), or level of education (van den

Broek et al., 2009c).

4. Activities; e.g., ofﬁce work (Janssen et al., 2009),

driving a car (Healey and Picard, 2005) or ﬂying

a plane, and running (Healey, 2009).

This subdivision is based current practice with ASP;

however, possibly it should be altered.

So far, comparisons between research results on

ASP are mostly made between results of either in-

dividuals or groups selected to resemble the general

population; cf. Table 1. However, user-tailored ap-

proaches should be explored as well. In particular, ex-

periences with speciﬁc groups can substantially con-

tribute to the further development of ASP, as has been

seen in other sciences; e.g., biology, psychology, and

medicine. But also, individual biosignal response pat-

terns should be taken into consideration, since peo-

ple’s affective signals differ widely.

Having said that, the question remains, how to

handle this striking variety between people. We

present three approaches, which are on another level

than usually adopted, but can tackle these problems:

Hybrid classiﬁcation systems (Berzal et al., 2004).

Most often, such architectures incorporate both a

(logic-based) reasoning system and a machine learn-

ing component. To the authors knowledge, so far, this

approach has not been applied for ASP. It has, how-

ever, been applied successfully for speech-based emo-

tion recognition (Schuller et al., 2004).

Multi-agent systems and multi-classiﬁer systems.

Two approaches within this ﬁeld could be of interest:

1) Multi-layered architectures, where each layer de-

BIOSIGNALS 2010 - International Conference on Bio-inspired Systems and Signal Processing

190

termines the possible classes to be processed or the

classiﬁers to be chosen for the next layer and 2) An

ensemble of classiﬁers, trained on the same or dis-

tinct biosignals and their features. Their outputs are

collected into one compound classiﬁcation, often de-

termined through a voting scheme. For more informa-

tion on this topic, we refer to Lam and Suen (1995)

and Kuncheva (2002).

Biosignal signatures. Related to schemes that are

used in forensics (Rogers, 2003), ASP could bene-

ﬁt from personalized proﬁles or schemes that tailor

to a generic proﬁle to people’s unique biosignal sig-

natures. Moreover, this approach could be extended

to incorporate context information, as is already done

in forensics (Rogers, 2003). Biosignal signatures re-

quire advanced multi-modal data mining and knowl-

edge discovery strategies, and is related to the base-

line matrix as proposed by Picard et al. (2001).

Each of these approaches enable processing of

multi-modal data, which allows to incorporate a range

of characteristics. This makes them promising for

ASP applications, also outside the scope of user iden-

tiﬁcation.

3.2 Theoretical Speciﬁcation

Changes in biosignals relate to changes in many psy-

chological constructs Cacioppo and Tassinary (1990).

For ASP, it is important to distinguish between these

different psychological constructs. This involves two

different situations: Firstly, biosignals can have more

or less equal response patterns but in different time

frames; e.g., short time frames for emotions and

longer time frames for moods. Second, biosignals

can have the same response patterns in the same time

frames but still relate to different psychological con-

structs; an increase in inspiration rate can imply in-

creased positive moods but also increased task de-

mands or mental effort. We propose three ways of

dealing with this complexity: (1) speciﬁcation of the

relation between construct of interest and biosignal,

(2) involving context information, and (3) using mul-

tiple classiﬁer systems.

In the ﬁrst place, a thorough description of the

relation between the construct of interest and the

biosignals is necessary. By doing this, distinguishing

biosignal properties for the construct of interest can

be found. For instance, when classifying emotions

short-term changes are of interest, whereas when clas-

sifying moods only long-term changes are relevant.

In addition, when trying to distinguish workload from

mood, one should not be interested in skin conduc-

tance changes. Instead, one could look at heart rate

variability as this typically reacts stronger to work-

load than mood.

Second, context provides a lot of information on

the psychological constructs which might have been

changed. For example, while driving a car work-

load is changing quickly depending on the road sit-

uation while your mood is likely to remain equal.

On the other hand, during watching a television show

changes in biosignals are more likely to come from

affect induction than from changes in cognitive load,

motivation, or memory. By inserting context infor-

mation, e.g. captured by a camera, the probability

that changes will occur in speciﬁc psychological con-

structs can be modeled into the system. Thereby, in-

creasing the change of allocating changes in biosig-

nals to changes in the correct psychological construct.

Finally, one can use multiple classiﬁers to make a

classiﬁcation of all separate psychological constructs.

In turn, the construct that with the most certain clas-

siﬁcation can be selected as the inﬂuenced construct.

Moreover, an extra classiﬁer can be trained that re-

ceives it’s input from the separate classiﬁers and

makes a selection based on this information.

To conclude, these three ways can help to deal

with the problem of the many-to-many relationship

between psychology and physiology. Note that we

have assumed that the psychological constructs are

independent of each other, which is actually not the

case. Nonetheless, treating them as if being indepen-

dent of each other is necessary for practical purposes.

4 CONCLUSIONS

This paper provided the second part of prerequisites

for ASP. For the ﬁrst and third part, we refer to re-

spectively van den Broek et al. (2009a) and van den

Broek et al. (2010). Here, the prerequisites identi-

ﬁcation of users and theoretical speciﬁcation are in-

troduced. These prerequisites are complementary to

those presented in the other two papers: validity, tri-

angulation, the physiology-driven approach, and con-

tributions of signal processing (van den Broek et al.,

2009a) and physical characteristics and integration of

biosignals (van den Broek et al., 2010). Moreover,the

second part of a review on ASP has been presented;

see Table 1, complementary to the review table pre-

sented in van den Broek et al. (2009a).

The review (see Table 1) and the prerequisites, il-

lustrate the complexity and lack of success of AC.

This urges us to emphasize that a step back should be

made by looking at prerequisites for successful ASP

to achieve true progress on a later stage, instead of

running forward and ignoring the problems encoun-

tered in previous studies. We sincerely hope that

PREREQUISITES FOR AFFECTIVE SIGNAL PROCESSING (ASP) - PART II

191

the prerequisites can contribute to or even guide the

promising future ASP provides us with.

ACKNOWLEDGEMENTS

The authors would like to thank Joyce H.D.M. West-

erink (Philips Research, Eindhoven, The Netherlands)

for her comments on an earlier versions of this pa-

per. Furthermore, we would like to thank the anony-

mous reviewers, who provided us the opportunity to

improve this paper.

REFERENCES

Berzal, F., Cubero, J.-C., S´anchez, D., and Serrano, J. M.

(2004). ART: A hybrid classiﬁcation model. Machine

Learning, 54(1):67–.

Cacioppo, J. and Tassinary, L. (1990). Inferring psycholog-

ical signiﬁcance from physiological signals. American

Psychologist, 45(1):16–28.

Chanel, G., Kierkels, J. J. M., Soleymani, M., and Pun,

T. (2009). Short-term emotion assessment in a recall

paradigm. International Journal of Human-Computer

Studies, 67(8):607–627.

Cheng, B. and Liu, G. (2008). Emotion recognition from

surface EMG signal using wavelet transform and neu-

ral network. In Proceedings of The 2nd International

Conference on Bioinformatics and Biomedical Engineer-

ing (ICBBE), pages 1363–1366, Shanghai, China. Piscat-

away, NJ, USA: IEEE Press.

Choi, A. and Woo, W. (2005). Physiological sensing and

feature extraction for emotion recognition by exploit-

ing acupuncture spots. Lecture Notes in Computer Sci-

ence (Affective Computing and Intelligent Interaction),

3784:590–597.

Gamboa, H., Silva, F., Silva, H., and Falc˜ao, R. (2009).

PLUX – Biosignals Acquisition and Processing. URL:

http://www.plux.info

[Last accessed on November

02, 2009].

Gunes, H. and Piccardi, M. (2009). Automatic temporal

segment detection and affect recognition from face and

body display. IEEE Transactions on Systems, Man, and

Cybernetics – Part B: Cybernetics, 39(1):64–84.

H˚akansson, J. and Montgomery, H. (2003). Empathy as an

interpersonal phenomenon. Journal of Social and Per-

sonal Relationships, 20(3):267–284.

Healey, J. A. (2009). Affect detection in the real world:

Recording and processing physiological signals. In Pro-

ceedings of the IEEE 3rd International Conference on

Affective Computing and Intelligent Interaction, ACII,

volume 1, pages 729–734, Amsterdam, The Netherlands.

IEEE Press.

Healey, J. A. and Picard, R. W. (2005). Detecting stress

during real-world driving tasks using physiological sen-

sors. IEEE Transactions on Intelligent Transportation

Systems, 6(2):156–166.

Janssen, J. H., van den Broek, E. L., and Westerink, J. H.

D. M. (2009). Personalized affective music player. In

Proceedings of the IEEE 3rd International Conference

on Affective Computing and Intelligent Interaction, ACII,

volume 1, pages 472–477, Amsterdam, The Netherlands.

IEEE Press.

Jones, C. M. and Troen, T. (2007). Biometric valence and

arousal recognition. In Thomas, B. H., editor, Proceed-

ings of the Australasian Computer-Human Interaction

Conference (OzCHI), pages 191–194, Adelaide, Aus-

tralia.

Kim, J. (2007). Bimodal emotion recognition using speech

and physiological changes, chapter 15, pages 265–280.

Vienna, Austria: I-Tech Education and Publishing.

Kim, J., Andr´e, E., Rehm, M., Vogt, T., and Wagner, J.

(2005). Integrating information from speech and phys-

iological signals to achieve emotional sensitivity. In

Proceedings of the 9th European Conference on Speech

Communication and Technology, pages 809–812, Lis-

boa, Portugal. Lisboa, Portugal: L2F – Spoken Language

Systems Laboratory.

Kim, K. H., Bang, S. W., and Kim, S. R. (2002). Develop-

ment of person-independent emotion recognition system

based on multiple physiological signals. In Proceedings

of the Second Joint EMBS–BMES Conference, volume 1:

Bioengineering – Integrative Methodologies, New Tech-

nologies, pages 50–51, Houston, Texas, USA.

Kim, K. H., Bang, S. W., and Kim, S. R. (2004). Emotion

recognition system using short-term monitoring of phys-

iological signals. Medical & Biological Engineering &

Computing, 42(3):419–427.

Krohne, H. W., Pieper, M., Knoll, N., and Breimer, N.

(2002). The cognitive regulation of emotions: The role

of success versus failure experience and coping disposi-

tions. Cognition & Emotion, 16(2):217–243.

Kuncheva, L. I. (2002). A theoretical study on six classiﬁer

fusion techniques. IEEE Transactions on Pattern Analy-

sis and Machine Intelligence, 24(2):281–286.

Lam, L. and Suen, C. Y. (1995). Optimal combina-

tions of pattern classiﬁers. Pattern Recognition Letters,

16(9):945–954.

Lichtenstein, A., Oehme, A., Kupschick, S., and

J¨urgensohn, T. (2008). Comparing two emotion mod-

els for deriving affective states from physiological data.

Lecture Notes in Computer Science (Affect and Emotion

in Human-Computer Interaction), 4868:35–50.

Lisetti, C. L. and Nasoz, F. (2002). MAUI: a multimodal

affective user interface. In Proceedings of the tenth ACM

international conference on Multimedia, pages 161–170,

Juan les Pins, France. New York, NY, USA: ACM Press.

Lisetti, C. L. and Nasoz, F. (2005). Affective intelligent car

interfaces with emotion recognition. In Proceedings of

11th International Conference on Human-Computer In-

teraction, pages [on cd–rom], Las Vegas, Nevada, USA.

Mahwah, NJ, USA: Lawrence Erlbaum Associates, Inc.

Liu, C., Rani, P., and Sarkar, N. (2005). An empirical

study of machine learning techniques for affect recog-

nition in human-robot interaction. In Proceedings of

the IEEE/RSJ International Conference on Intelligent

BIOSIGNALS 2010 - International Conference on Bio-inspired Systems and Signal Processing

192

Robots and Systems (IROS), pages 2662–2667, Edmon-

ton, Alberta, Canada. Piscataway, NJ, USA: IEEE Press.

Liu, C., Rani, P., and Sarkar, N. (2006). Human-robot in-

teraction using affective cues. In Proceedings of the 15th

IEEE International Symposium on Robot and Human In-

teractive Communication (RO-MAN06), pages 285–290,

Hatﬁeld, UK. IEEE Computer Society.

Neisser, U. (1963). The imitation of man by machine – the

view that machines will think as man does reveals mis-

understanding of the nature of human thought. Science,

139(3551):193–197.

Picard, R. W. (1997). Affective Computing. Boston, MA,

USA: MIT Press.

Picard, R. W. and Goodwin, M. (2008). Developing inno-

vative technology for future personalized autism research

and treatment. Autism Advocate, 50(1):32–39.

Picard, R. W., Vyzas, E., and Healey, J. (2001). Toward ma-

chine emotional intelligence: Analysis of affective phys-

iological state. IEEE Transactions on Pattern Analysis

and Machine Intelligence, 23(10):1175–1191.

Rainville, P., Bechara, A., Naqvi, N., and Damasio, A. R.

(2006). Basic emotions are associated with distinct pat-

terns of cardiorespiratory activity. International Journal

of Psychophysiology, 61(1):5–18.

Rani, P., Sarkar, N., Smith, C., and Kirby, L. (2004). Anx-

iety detecting robotic systems - towards implicit human-

robot collaboration. Robotica, 22(1):85–95.

Rogers, M. (2003). The role of criminal proﬁling in the

computer forensics process. Computers & Security,

22(4):292–298.

Schuller, B., Rigoll, G., and Lang, M. (2004). Speech emo-

tion recognition combining acoustic features and linguis-

tic information in a hybrid support vector machine – be-

lief network architecture. In Proceedings of the IEEE In-

ternational Conference on Acoustics, Speech, and Signal

Processing (ICASSP ’04), volume 1, pages I–577–580,

Montreal, QC, Canada.

Sternbach, R. A. and Tursky, B. (1965). Ethnic differences

among housewives in psychophysical and skin potential

responses to electric shock. Psychophysiology, 1(3):241–

246.

van den Broek, E. L., Janssen, J. H., van der Zwaag, M. D.,

and Healey, J. A. (2010). Prerequisits for Affective Sig-

nal Processing (ASP) – Part III. In Biosignals 2010: Pro-

ceedings of the International Conference on Bio-Inspired

Systems and Signal Processing, page [this volume], Va-

lencia – Spain.

van den Broek, E. L., Janssen, J. H., Westerink, J. H. D. M.,

and Healey, J. A. (2009a). Prerequisits for Affective Sig-

nal Processing (ASP). In Encarnac¸˜ao, P. and Veloso,

A., editors, Biosignals 2009: Proceedings of the Inter-

national Conference on Bio-Inspired Systems and Signal

Processing, pages 426–433, Porto – Portugal.

van den Broek, E. L., Lis´y, V., Janssen, J. H., Westerink, J.

H. D. M., Schut, M. H., and Tuinenbreijer, K. (2009b).

Affective Man-Machine Interface: Unveiling human

emotions through biosignals, page [in press]. Biomedical

Engineering Systems and Technologies: BIOSTEC2009

Selected Revised papers. Berlin/Heidelberg, Germany:

Springer.

van den Broek, E. L., Schut, M. H., Westerink, J. H. D. M.,

and Tuinenbreijer, K. (2009c). Unobtrusive Sensing of

Emotions (USE). Journal of Ambient Intelligence and

Smart Environments, 1(3):287–299.

van den Broek, E. L. and Westerink, J. H. D. M. (2009).

Considerations for emotion-aware consumer products.

Applied Ergonomics, 40(6):1055–1064.

Ververidis, D. and Kotropoulos, C. (2006). Emotional

speech recognition: Resources, features, and methods.

Speech Communication, 48(9):1162–1181.

Yang, Y.-H., Lin, Y.-C., Su, Y.-F., and Chen, H. H. (2007).

Music emotion classiﬁcation: A regression approach. In

Proceedings of the IEEE International Conference on

Multimedia and Expo, pages 208–211, Beijing, China.

Piscataway, NJ, USA: IEEE, Inc.

PREREQUISITES FOR AFFECTIVE SIGNAL PROCESSING (ASP) - PART II

193
