IMPROVED DISEASE OUTCOME PREDICTION BASED ON

MICROARRAY AND CLINICAL DATA COMBINATION AND

PRE-VALIDATION

Jana

Silhav´a and Pavel Smrˇz

Faculty of Information Technology, Brno University of Technology, Boˇzetˇechova 2, 61266 Brno, Czech Republic

Keywords:

Boosting, Clinical data, Combined models, Generalized linear models, Logistic regression, Microarray data,

Model evaluation.

Abstract:

Combining relevant information from high-dimensional microarray data and low-dimensional clinical vari-

ables to predict disease outcome is important to improve treatment decisions. Such a combination may yield

more accurate predictions than those obtained based on the use of microarray or clinical data alone. We pro-

pose a combination of logistic regression for clinical data and BinomialBoosting for microarray data. Then

we propose its extension designed for redundant sets of data. Our approach combines microarray and clinical

data at the level of decision integration. The extension includes pre-validation of models built with microarray

and clinical data followed by weights calculation. Weights determine relevance of microarray and clinical

models for data combination. Evaluations are performed with several redundant and non-redundant simu-

lated datasets. Then some tests are applied to two real benchmark datasets. Our approach increases outcome

prediction on non-redundant simulated datasets and does not decrease outcome prediction on redundant sim-

ulated datasets. Pre-validation of built models improves outcome of the prediction up to 4% in the case of real

redundant dataset.

1 INTRODUCTION

Clinical variables such as tumor grade, tumor size,

age, gender, family history and others depending on

the type of cancer have been used in prediction of

disease status and progression (Gajdos et al., 1999).

On the other hand, microarray data is an alternative

way of disease prediction (Michiels et al., 2005; Klijn

et al., 2005). Combining relevant information from

high-dimensional genomic data and low-dimensional

clinical variables to predict disease outcome is im-

portant to improve treatment decisions. Data combi-

nation increases prediction accuracy and may derive

a hybrid prognostic signature from combined data.

Attractiveness of prediction problems that can in-

clude disease outcome prediction or survival analysis,

comes from their ability to identify a group of patients

that can avoid aggressive chemotherapy (Fernandez-

Teijeiro et al., 2004).

Here, disease outcome is deﬁned as a variable that

can have two values: poor prognosis or good progno-

sis, so we focus on a binary class prediction. The class

prediction is classiﬁcation where the algorithm learns

from samples with known class membership (training

set) and establishes a prediction rule to classify new

samples (test set).

The quality of prediction of both microarray and

clinical data can depend on many factors, e.g. quality

of collected datasets, quantity of samples in datasets,

balance, relevance of used variables, etc. Ideally, vari-

ables should represent the changes caused by a dis-

ease. The quality of disease outcome predictor is de-

pendent on a machine learning method, on the pro-

cess of training and other eﬀects. In literature, there

are many examples that do not evaluate microarray

experiments correctly (Dupuy and Simon, 2007).

Prediction accuracy of combination of microar-

ray and clinical data depends on complementarity of

these two data sources. If data sources or data mod-

els are complementary, i.e. they contain some non-

redundant information, combination of models leads

to increased prediction accuracy. Prediction accuracy

also depends on quality of models. In case the data

sources are redundant, pre-validation of microarray

and clinical data can assess quality of this data or the

models. The concept of pre-validation for microarray

108

Šilhavá J. and Smrž P. (2010).

IMPROVED DISEASE OUTCOME PREDICTION BASED ON MICROARRAY AND CLINICAL DATA COMBINATION AND PRE-VALIDATION.

In Proceedings of the First International Conference on Bioinformatics, pages 108-113

DOI: 10.5220/0002697601080113

 SciTePress

and clinical data is presented in (Tibshirani and Efron,

2002).

This paper describes a combination of logistic re-

gression for clinical data and BinomialBoosting for

microarray data. Then it describes its extension de-

signed for redundant sets of data. Microarray and

clinical data are combined at the levelof decision inte-

gration. The characters of logistic regression and Bi-

nomialBoosting models allow for their combination,

see Section 2. BinomialBoosting (Buhlmann and

Hothorn, 2007) enables use of logistic regresion with

high-dimensional data, which is impossible without

dimension reduction step and with high-dimensional

data. Logistic regression with high-dimensional data

can produce numerically unstable estimates and the

predicting model does not generalize well (Hosmer

and Lemeshow, 2000). In contrast to combined logis-

tic regression and BinomialBoosting models, the sec-

ond approach includes pre-validation of models built

with microarray and clinical data followed by weights

calculation. Weights set relevance of microarray and

clinical models for data combination.

The paper is organized as follows: Section 2 de-

scribes the combination of logistic regression and Bi-

nomialBoosting, then it describes its extension in-

cluding pre-validation. Simulations are performed

with several generated datasets in redundant and non-

redundant setting together with some tests applied to

two real benchmark datasets in Section 3. Some re-

lated work is shortly discussed in Section 4. Section 5

concludes this paper.

2 METHODS

2.1 Microarray and Clinical Data

Combination

Notation: Let Z be the n×q matrix with n samples and

q-dimensional clinical data. The response variable is

a n-dimensional vector Y. Then let X be other matrix

with microarray data. X is the n× p matrix containing

n samples and the expression values of p genes.

This approach consists of the two models: logis-

tic regression (LOG) and BinomialBoosting (BB), see

Figure 1. In a very brief description, BinomialBoost-

ing consists of the estimate initialization and then for

1 to M boosting iterations: (1) the negative gradient

vector is computed, (2) the negative gradient vector is

ﬁtted by the componentwise linear least squares as the

base procedure and ﬁnally (3) the estimate and the co-

eﬃcients are updated. The optimal number of boost-

ing iteration is the main tuning parameter which is

LOG

η

inverse

logit



η

Figure 1: The schematic drawing of microarray and clinical

data combination. Logistic regression and BinomialBoost-

ing models are trained just with training part of clinical and

microarray dataset.

determined with Akaike information criterion (AIC)

(Hothorn and Buhlmann, 2007).

Our approach combines microarray and clinical

data at the level of decision integration. This means

that separate models for microarray and clinical data

are trained and then the predictions of these models

(η

and η

) are combined. The combination of the

outputs of these models is possible because the out-

puts of these models are linear and there are some

similar properties of logistic regression (Hosmer and

Lemeshow, 2000) and BinomialBoosting (Buhlmann

and Hothorn, 2007).

Similar properties of logistic regression and Binomi-

alBoosting:

• generalized linear models:

= g(η

) , (1)

where g is a link function. η

is a linear model:

= β

j=1

i, j

for i = 1, . . . , n , (2)

where β denotes coeﬃcients, k and Q can be spec-

iﬁed as: p and X for microarray data; q and Z for

clinical data.

• response variable Y

is considered binomial

(Bernoulli) random variable p

: Y

∼ binomial(p

, n).

Binomial response variables relate to logit function:

logit(p) = log



1−p



. Inverse logit is the link func-

tion g in logistic regression (1). In BinomialBoosting,

logit function is included in binomial loss function as

a population minimizer. BinomialBoosting with the

componentwise linear least squares as a base proce-

dure yields a ﬁt of a linear logistic regression model

(Buhlmann and Hothorn, 2007).

This approach of combination of microarray and clin-

ical data can be described as follows, see Figure 1.

Microarray and clinical data are repeatedly split into

training and test sets via Monte Carlo cross-validation

(MCCV) procedure, see (Molinaro et al., 2005). Each

clinical training set is ﬁtted to logistic regression

IMPROVED DISEASE OUTCOME PREDICTION BASED ON MICROARRAY AND CLINICAL DATA

COMBINATION AND PRE-VALIDATION

109

model. Then the linear prediction of each clinical test

set gives predictions η

of the linear model (2) de-

noted for clinical data with the upper index Z. Each

microarray training set is ﬁtted to the model using Bi-

nomialBoosting. Then the linear prediction of each

microarray test set gives predictions η

of the linear

model (2) denoted for microarray data with the upper

index X. According to the additivity rule that is valid

for linear models, we can sum the linear predictions:

= η

+ η

. (3)

Then the logit inversion of η

gives a response:

1+ e

. (4)

In the rest of this paper, this approach is denoted

as LOG/Z+BB/X

2.2 Microarray and Clinical Data

Pre-validation and Combination

This approach, in contrast to microarray and clini-

cal data combination, sets weights that determine rel-

evance of linear predictions for combination of mi-

croarray and clinical models, as shown in Figure 2.

This approach was designed for redundant datasets.

Weights are set based on pre-validation. The con-

cept of pre-validation for microarray data and clinical

variables is described in (Tibshirani and Efron, 2002).

This paper incorporates only points 1 through 5 com-

pared to our approach described in Section 2.3. Also,

we use diﬀerent classiﬁers and leave-one-out cross-

validation (LOOCV), while (Tibshirani and Efron,

2002) uses k-fold CV.

2.3 Determination of Weights for

Models

We have K training samples in t-iteration of MCCV.

We use LOOCV for pre-validation and consequently

we determine weights. The weights are determined as

follows:

1. Set aside one sample of K training samples.

2. Build model with logistic regression (Binomial-

Boosting) for Z (X)

using only data from the

other K − 1 samples.

3. Predict linear response with built modelon left out

case.

In the rest of this paper, a slash in a title separates a

model and type of data.

Z denotes clinical data and X denotes microarray data.

4. Repeat steps 1–3 for each of the samples K to get

pre-validated predictors from Z and X.

5. Fit logistic regression model to pre-validated pre-

dictors from Z and X.

6. Compute weights w

(6), where i denotes Z or X.

7. Repeate steps 1-6 for randomized training data

obtained from MCCV.

8. Compute modus of weights ˆw

from w

for X and

In this approach, logistic regression is used

twice—in building model of Z and in building model

of pre-validated predictors from Z and X. Logistic

regression describes the relationship between one or

more variables and an outcome. Each of coeﬃcients

describes the size of the contribution of each variable.

Large regression coeﬃcient means that the variable

strongly inﬂuences the probability of that outcome.

The folowing equation for Z and X variable is derived

from (2):

η = β

+ β

. (5)

Then the weights are determined as follows:

= abs





, w

= abs





. (6)

In this approach, randomized training data ob-

tained from MCCV is used twice—in weights esti-

mation as described in Section 2.2 and in building

model of Z and X as described in Section 2.1. His-

togram of weights obtained from t-iteration of MCCV

is close to exponential distributions of probability

density function. In the case of exponential distribu-

tion, the modus is the value with the highest density.

In the rest of this paper, this approach is denoted

as pre-LOG/ Z+BB/X.

inverse

logit

LOG



η

Figure 2: The schematic drawing of microarray and clinical

data pre-validation and combination. Logistic regression

and BinomialBoosting models are trained just with training

part of clinical and microarray dataset.

BIOINFORMATICS 2010 - International Conference on Bioinformatics

110

Table 1: Non-redundant datasets. AUCs from test datasets (including mean AUCs and standard deviations) evaluated over

100 MCCV iterations.

1. 2. 3. 4.

, µ

0, 0 1, 0.25 0.5, 0.5 1, 0.5

Method (no power) µ

> µ

< µ

(strong p.)

LOG/Z+BB/X 0.53 ± 0.05 0.69 ± 0.04 0.73 ± 0.04 0.79 ± 0.04

LOG/Z 0.55 ± 0.05 0.65 ± 0.06 0.56 ± 0.05 0.65 ± 0.06

BB/X 0.51 ± 0.05 0.60 ± 0.05 0.72 ± 0.05 0.72 ± 0.05

Table 2: Redundant datasets. AUCs from test datasets (including mean AUCs and standard deviations) evaluated over 100

MCCV iterations.

1. 2. 3. 4.

, µ

0, 0 1, 0.25 0.5, 0.5 1, 0.5

Method (no power) µ

> µ

< µ

(strong p.)

LOG/Z+BB/X 0.51 ± 0.05 0.94 ± 0.02 0.96 ± 0.02 0.98 ± 0.01

LOG/Z 0.49 ± 0.05 0.94 ± 0.02 0.78 ± 0.04 0.94 ± 0.02

BB/X 0.51 ± 0.05 0.71 ± 0.04 0.98 ± 0.01 0.98 ± 0.01

3 RESULTS

The focus of evaluation was to test LOG/Z+BB/X ap-

proach with non-redundant and redundant datasets.

Simulated data was used for this purpose. Then

we tested LOG/Z+BB/X and pre-LOG/Z+BB/X with

two real benchmark datasets. We performed experi-

ments in R environment

using packages ‘stats’ and

‘mboost’.

MCCV without replacement split the samples ran-

domly into a learning and test sets numerous times.

Large number of iterations lead to more stable results.

In our case, the whole procedure was repeated 100

times with learning set and test set ratio 4 : 1. We es-

timated the Area Under the ROC Curve (AUC) and

AUCs were averaged over 100 MCCV iterations.

3.1 Simulated Datasets

We tested LOG/Z+BB/X with non-redundant and re-

dundant datasets. We generated simulated datasets

through the use of R script available in (Boulesteix

et al., 2008). In case of redundant sets, microar-

ray and clinical variables are generated using exactly

the same model. Such variables discriminate classes

in the same way and giving redundant information.

In case of non-redundant sets, the observations are

assumed to form two distinct subgroups (Boulesteix

et al., 2008). Then we considered diﬀerent predic-

tive powers for the clinical variables µ

and diﬀer-

ent predictive powers for the microarray variables

. In present simulations, µ

= 0 denotes no power,

= 0.5 moderate power and µ

= 1 strong power for

www.r-project.org

Z. Similarly µ

= 0, 0.25, 0.5 for X. Diﬀerence in

and µ

ranges compensates for ranges of predictor

values for microarray and clinical variables.

The following Tables 1 and 2 display selected re-

sults of LOG/Z+BB/X for diﬀerent predictive pow-

ers of Z and X. In case of non-redundant datasets,

LOG/Z+BB/X increases AUCs. LOG/Z+BB/X has a

good performance on redundant datasets as well.

3.2 Real Datasets

For evaluation, we used two benchmark breast can-

cer datasets (van’t Veer et al., 2002) and (Pittman

et al., 2004). The ﬁrst one gives the expression levels

of 22483 genes for 78 breast cancer patients. Based

on existence of distant metastases, 34 of these sam-

ples are classiﬁed into the poor prognosis group, the

rest 44 samples belong to the the good prognosis

group. The used dataset is prepared as described in

(van’t Veer et al., 2002) and is included in R package

‘DENMARKLAB’ (Fridlyand and Yang, 2004). This

dataset includes 4348 resulting genes. Clinical vari-

ables are age, tumor grade, estrogen receptor status,

progesterone receptor status, tumor size and angioin-

vasion. The second one gives the expression levels

of 12625 genes for 158 breast cancer patients. Ac-

cording to recurrence of disease, 63 of these sam-

ples are classifed into the poor prognosis group, the

rest 95 samples belong to the good prognosis group.

The data was pre-processed using packages ‘gcrma’

and ‘geneﬁlter’ to normalize and ﬁlter the data. The

genes that showed a low variability across all samples

were cleared out. The resulting dataset includes 8961

genes. Clinical variables are age, lymph node status,

IMPROVED DISEASE OUTCOME PREDICTION BASED ON MICROARRAY AND CLINICAL DATA

COMBINATION AND PRE-VALIDATION

111

Table 3: van’t Veer dataset. AUCs from test datasets (including mean AUCs and standard deviations) evaluated over 100

MCCV iterations. p denostes a number of microarray variables.

Method p = 50 p = 200 p = 500

LOG/Z+BB/X 0.79 ± 0.11 0.78 ± 0.11 0.79 ± 0.11

LOG/Z 0.82 ± 0.10 − −

BB/X 0.67 ± 0.13 0.65 ± 0.12 0.65 ± 0.11

pre-LOG/Z+BB/X 0.81 ± 0.10 0.82 ± 0.11 0.82 ± 0.10

Table 4: Pittman dataset. AUCs from test datasets (including mean AUCs and standard deviations) evaluated over 100

MCCV iterations. p denostes a number of microarray variables.

Method p = 50 p = 200 p = 500

LOG/Z+BB/X 0.79 ± 0.07 0.81 ± 0.08 0.82 ± 0.08

LOG/Z 0.67 ± 0.09 − −

BB/X 0.75 ± 0.08 0.77 ± 0.08 0.78 ± 0.08

pre-LOG/Z+BB/X 0.74 ± 0.08 0.76 ± 0.08 0.78 ± 0.08

estrogen receptor status, family history, tumor grade

and tumor size.

We perform tests for diﬀerent numbers of vari-

ables (p = 50, 200, 500) in order to inspect eﬃciency

of both approaches. Variables are selected on the ba-

sis of the absolute value of the t-statistic using R pack-

age ‘st’.

Average AUCs and standard deviations over

100 MCCV iterations include Tables 3 and 4.

LOG/Z+BB/X perform with Pittman dataset well, see

Table 4. Pittman dataset approaches non-redundant

datasets and combination of microarray and clini-

cal data implicates outcome prediction improvement.

According to the results in Table 3, van’t Veer dataset

approaches redundant datasets. This ﬁnding coin-

cides with conclusion of (Gruvberger et al., 2003),

which points out a correlation of ER-alfa status in the

dataset generated by van’t Veer. LOG/Z+BB/X av-

erages linear predictions from microarray and clin-

ical models on redundant datasets. Compared to

LOG/Z+BB/X, pre-LOG/Z+BB/X improves AUCs

up to 4% in the case of real redundant dataset. Av-

erage AUC for pre-LOG/Z+ BB/X is 0.82.

4 RELATED WORK

The topic of combination or integration of microar-

ray and clinical data is not new. In literature,

there are more papers where authors describe vari-

ous ways of microarray and clinical data combination.

In principle, the results of designed approaches are

hard to compare because new approaches are evalu-

ated with diﬀerent datasets and measures. (Gevaert

et al., 2006) evaluate with using AUC as our pa-

per. They integrate microarray data and clinical vari-

ables with Bayesian networks in three ways: full

integration, decision integration and partial integra-

tion. Their Bayesian decision integration approach

combines data at the same level as our method and

achieves average AUC 0.79 with van’t Veer dataset.

In order to compare pre-LOG/Z+BB/X with the ap-

proach proposed in (Boulesteix et al., 2008), we have

performed our simulations also in terms of mean er-

ror rates. Our approach provides results 2% better

on average on the van’t Veer dataset. In the case of

Pittman dataset, LOG/Z+BB/X has results 5% bet-

ter than the approach proposed in (Boulesteix et al.,

2008). The method described in this article employs

pre-validation principle with PLS dimension reduc-

tion. Random forests are then applied with new com-

ponents and the clinical variables as predictors. (Eden

et al., 2004) reproduce van’t Veer classiﬁer for mi-

croarray predictors and apply an artiﬁcial neural net-

work (ANN) algorithm to clinical predictors. Their

approach achievesAUC 0.79 with all samples of van’t

Veer dataset and with LOOCV. Then this approach

achieves AUC 0.85 with only ER positive samples

of van’t Veer dataset. (Ma and Huang, 2007) pro-

pose Cov-TGDR method for combining diﬀerent type

of covariates in disease prediction. They use van’t

Veer dataset and achieveprediction error 0.227. How-

ever, they perform feature selection based on the bi-

nary outcome with training and test data which is not

correct (pre-processing step 4 and 5 in this article).

Other examples of methods that combine microarray

and clinical data are (Fernandez-Teijeiro et al., 2004;

Pittman et al., 2004), but these authors evaluate sur-

vival times. (Fernandez-Teijeiro et al., 2004) build

predictive model with combination of clinical vari-

ables and a small number of selected genes. (Pittman

et al., 2004) combine metagenes with clinical risk fac-

tors to improve prediction.

BIOINFORMATICS 2010 - International Conference on Bioinformatics

112

5 CONCLUSIONS

This article deals with outcome prediction of com-

bined models. We combined microarray and clini-

cal data. We described LOG/Z+BB/X approach and

its extension pre-LOG/Z+BB/X designed for redun-

dant datasets. In contrast to LOG/Z+BB/X, pre-

LOG/Z+BB/X includes pre-validationof models built

with microarray and clinical data followed by weights

calculation. Weights set relevance of microarray and

clinical models for data combination. We evalu-

ated LOG/Z+BB/X with non-redundant and redun-

dant simulated datasets for diﬀerent predictive powers

of microarray and clinical variables. LOG/Z+BB/X

increases AUCs on non-redundant simulated datasets

and it does not decrease AUCs on redundant sim-

ulated datasets. Then we evaluated LOG/Z+BB/X

and pre-LOG/Z+BB/X on two benchmark breast can-

cer datasets. LOG/Z+BB/X increases AUCs on

Pittman dataset. Compared to LOG/Z+BB/X, pre-

LOG/Z+BB/X improves outcome of the prediction

up to 4% in the case of van’t Veer dataset. Aver-

age AUC for pre-LOG/Z+BB/X is 0.82. In conclu-

sion, LOG/Z+BB/X performs with combined mod-

els well—both with non-redundant data and redun-

dant data. When this approach does not perform well,

it is possible to apply pre-LOG/Z+BB/X approach

or evaluate the quality of data or models separately.

Plans to the future include incorporation of other

data sources into combination and deriving biomark-

ers signiﬁcantly involved in outcome prediction.

ACKNOWLEDGEMENTS

This work was partly supported by the Czech Min-

istry of Education research grants 2B06052 and

MSM0021630528. We thank Petr Holub and the re-

viewers for their constructive comments.

REFERENCES

Boulesteix, A. L., Porzelius, C., and Daumer, M. (2008).

Microarray-based classiﬁcation and clinical predic-

tors: on combined classiﬁers and additional predic-

tive value. Bioinformatics 24, 1698-1706.

Buhlmann, P. and Hothorn, T. (2007). Boosting Algorithms:

Regularization, Prediction and Model Fitting. Statist.

Sci. 22, 477-505.

Dupuy, A. and Simon, R. M. (2007). Critical Review of

Published Microarray Studies for Cancer Outcome

and Guidelines on Statistical Analysis and Reporting.

Journal of the National Cancer Institute 99 (2), 147-

157.

Eden, P., Ritz, C., and Rose, C. (2004). Good Old clinical

markers have similar power in breast cancer progno-

sis as microarray gene expression proﬁlers. Eur. J.

Cancer 40 (12), 1803-1806.

Fernandez-Teijeiro, A., Betensky, R. A., Sturla, L. M., Kim,

J. Y., Tamayo, P., and Pomeroy, S. L. (2004). Combin-

ing gene expression proﬁles and clinical parameters

for risk stratiﬁcation in medulloblastomas. J Clin On-

col. 22 (6), 994-998.

Fridlyand, J. and Yang, J. Y. H. (2004). DENMARK-

LAB R package. Advanced microarray data analysis:

Class discovery and class prediction. Available at

http://genome.cbs.dtu.dk/courses/norfa2004/Extras/.

Gajdos, C., Tartter, P. I., and Bleiweiss, I. (1999). Lym-

phatic Invasion, Tumor Size, and Age Are Indepen-

dent Predictors of Axillary Lymph Node Metastases in

Women With T1 Breast Cancers. Ann Surg. 230 (5),

692-696.

Gevaert, O., Smet, F. D., and Timmerman, D. (2006). Pre-

dicting the prognosis of breast cancer by integrating

clinical and microarray data with Bayesian networks.

Bioinformatics 22 (14), 184-190.

Gruvberger, S. K., Ringner, M., and Eden, P. (2003). Ex-

pression proﬁling to predict outcome in breast cancer:

the inﬂuence of sample selection. Breast Cancer Res.

5(1), 23-26.

Hosmer, D. W. and Lemeshow, S. (2000). Applied Logistic

Regression. Wiley, New York, 2nd edition.

Hothorn, T. and Buhlmann, P. (2007). mboost: Model-

Based Boosting. R package version 0.5-8. Bioinfor-

matics, Available at http://CRAN.R-project.org/.

Klijn, J. G. M., Wang, Y., Atkins, D., and Foekens, J. A.

(2005). Prediction of cancer outcome with microar-

rays. Lancet. 365 (9472), 1685-1685.

Ma, S. and Huang, J. (2007). Combining Clinical and Ge-

nomic Covariates via Cov-TGDR. Cancer Inform. 3,

371-378.

Michiels, S., Koscielny, S., and Hill, C. (2005). Prediction

of cancer outcome with microarrays: a multiple ran-

dom validation strategy. Lancet. 365 (9458), 488-492.

Molinaro, A., Simon, R., and Pfeiﬀer, R. M. (2005). Pre-

diction error estimation: a comparison of resampling

methods. Bioinformatics 21(15), 3301-3307.

Pittman, J., Huang, E., and Dressman, H. (2004). Inte-

grated modeling of clinical and gene expression in-

formation for personalized prediction of disease out-

comes. Proc.Natl.Acad.Sci. 101(22), 8431-8436.

Tibshirani, R. and Efron, B. (2002). Pre-validation and in-

ference in microarrays. Statistical applications in ge-

netics and molecular biology 1, 1.

van’t Veer, L. J., Dai, H., and van de Vijver, M. J. (2002).

Gene expression proﬁling predicts clinical outcome of

breast cancer. Nature 415, 530-536.

IMPROVED DISEASE OUTCOME PREDICTION BASED ON MICROARRAY AND CLINICAL DATA

COMBINATION AND PRE-VALIDATION

113
