PROGRAMMING REACTIVE AGENT-BASED MOBILE

ROBOTS USING ICARO-T FRAMEWORK

José M. Gascueña, Antonio Fernández-Caballero

Universidad de Castilla-La Mancha, Escuela de Ingenieros Industriales de Albacete

Instituto de Investigación en Informática de Albacete, 02071-Albacete, Spain

Francisco J. Garijo

Institut de Recherche en Informatique de Toulouse, Equipe SMAC

Université Paul Sabatier, 118 route de Narbone, 31062 Toulouse Cedex 9 – France

Keywords: Agents, Multi-Agent Systems, Agent-Oriented programming languages, Agent framework.

Abstract: This paper describes the experience and the results of using agent-based component patterns for developing

mobile robots. The work is based on the open source ICARO-T framework, which provides four categories

of component patterns: agent organization pattern to describe the overall architecture of the system,

cognitive and reactive agent patterns to model agent behaviour, and resource patterns to encapsulate

computing entities providing services to agents. The experimental setting is based on the development of a

team of cooperating robots for achieving surveillance tasks.

1 INTRODUCTION

There is a huge amount of work and valuable

proposals about agent oriented programming

frameworks and languages (Bordini et al. (2005),

Braubach & Pokahr (2009). This paper analyses the

MAS development process using the ICARO-T

framework (Garijo et al., 2008). The differentiating

factor from ICARO-T is the use of component

patterns for modelling MAS. Development

guidelines for creating application components using

agent patterns are also provided. The main

advantage of ICARO-T framework is that it provides

to engineers not only concepts and models, but also

customizable MAS design and Java code fully

compatible with software engineering standards.

While other agent based platforms, such as FIPA,

focus on communication standards, ICARO focuses

on providing high level software components for

easy development of complex agent behaviour,

agent coordination, and MAS organization. An

additional reason for choosing ICARO-T is cost-

effectiveness of agent patterns in application

development (Garijo et al., 2004).

The ICARO-T framework is the result from the

cumulative experience in the development of agent-

based applications in the last ten years. Therefore,

the framework architecture and the underlying

patterns have been elaborated, refined and validated

through the realization of several agent-based

applications. The first such system discovered

patterns for building reactive and cognitive agents. It

was a cooperative working system (Garijo et. al,

1998), which was refined with the development of a

project management system for the creation of

intelligent network services (Gómez- Sanz, Pavón &

Garijo, 2000). Scalability of the cognitive agent

model was considered in a context with thousands of

users, in a MAS that supported the personalization

of web sites (Gómez-Sanz, Pavón & Díaz-Carrasco,

2003), and the reuse of this solution in an online

discussion and decision making system (Luehrs,

Pavón & Schneider, 2003), as well as a prototype to

validate the MESSAGE methodology (Caire et. al,

2002).

In 2008 a new version of the framework was

delivered as open source (http://icaro.morfeo-

project.org/); then new teams started using ICARO

as support for academic courses and for research

projects (e.g. the e-learning project ENLACE

(Celorrio & Verdejo, 2007)). Utilization as

implementation support for a new integrative MAS

287

Gascueña J., Fernández-caballero A. and Garijo F. (2010).

PROGRAMMING REACTIVE AGENT-BASED MOBILE ROBOTS USING ICARO-T FRAMEWORK.

In Proceedings of the 2nd International Conference on Agents and Artiﬁcial Intelligence - Agents, pages 287-291

DOI: 10.5220/0002715602870291

 SciTePress

methodology is also considered (Gascueña &

Fernández-Caballero, 2009a) in the domain of

multisensory surveillance (Pavón et al., 2007;

Gascueña & Fernández-Caballero, 2009b).

ICARO-T offers three categories of reusable

component models: agent organization models to

describe the overall structure of the system, agent

models, based on reactive and cognitive agent

behaviour, and resource models to encapsulate

computing entities providing services to agents. The

reactive agent architecture is made up of three

components: perception, control and actuation. The

perception works as an event handling mechanism.

It stores incoming events, delivering them to the

control on demand. The control is modelled as an

extended finite state machine which consumes

events stored in the perception, and performs

transitions by changing its internal state and

invoking actions in the actuation model. Reactive

agents behave like event-consuming processes

which change their internal state and execute

operations according to their state transition table.

An extensive description of the cognitive agent is

available in (Pavón, Garijo & Gómez-Sanz, 2008).

The reactive agent is able to receive events from

different components (agents and resources) through

their use interface. The perception (1) provides

interfaces to store events in a queue and to consume

them, and (2) provides events to the control when

requested via the perception consumption interface.

To achieve their goals, the agents need to interact

with the computing entities in their environment.

Agents view these entities as “resources”. More

formally, in agent-based applications developed

using ICARO-T resources are those computing

entities that are not agents, and are used by the

agents to obtain information for achieving their

objectives. Basic computing entities including

components for building new agents and resource

models are also available in the framework.

An application in the ICARO-T framework is

modelled as an organization made up of controller

components, which are agents, and resources.

Therefore, there are three layers in the organization:

the control layer (CL), which is made up of

controller components; the resource layer (RL),

made up of the components that supply information

or provide some support functionality to the agents

to achieve their goals; finally the information layer

(IL) contains ontology and/or information entities

needed for modelling both the framework itself and

applications.

2 REACTIVE COLLABORATING

MOBILE ROBOTS

The selected case study, for illustrating the

development process using ICARO-T, implements

the collaboration among several mobile robots (a

minimum of five) to carry out a common

surveillance task in an industrial estate. The robots

navigate randomly through pre-defined surveillance

paths in a simulated environment. When there is an

alarm in a building, a robot is assigned the role of

the chief, three robots will be subordinated, and the

other ones will be expecting in rearguard to receive

orders from the chief (e.g. to replace a damaged

robot). Failures are discovered by the robot itself

when any of its mounted devices (e.g., sonar, laser,

camera, etc) does not work in a right way.

The robots perceive that an alarm has occurred

through two mechanisms: (1) the security guard

notifies robots that an alarm has occurred and where

it has taken place, (2) the robot is equipped to

perceive an alarm itself when it is close enough to

the corner of a building; therefore it does not have to

wait for the security guard announcement. The alarm

is covered when a robot coalition (one chief and

three subordinates) surrounds the building, that is,

the robots that form a coalition are located at the

four building corners where the alarm has occurred.

2.1 Application Resource and Agent

Identification

The first step undertaken by the developer, in order

to implement a multi-agent system with ICARO-T,

is to identify the application agents and resources

from the established requirements. For the proposed

application an agent and three resources were

identified. RobotApplicationAgent is a reactive agent

that supports the robot functionalities. InterfaceRes

is a visualization resource that allows the user to

interact with the application (simulating an alarm

rising in a given building, notifying that an alarm

has occurred, simulating that a robot has detected a

failure, and restarting the application), and to

visualize what is happening in the simulated

environment. EnvironmentRes is a resource that

provides information about the simulated

environment (industrial estate dimensions, building

where the alarm has taken place, robots that do not

work well, and robots initial locations).

RobotLocationRes is a resource that stores the robots

location and the moment in which they were

updated.

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

288

2.2 The Application Agent Description

The reactive agent behaviour is modelled with a

finite state automaton, where the states represent

concrete situations of the agent life cycle. The state

diagram interpretation corresponding with the

reactive agent that controls a robot is as commented

next. There are three kinds of states: initial

(InitialState), final (FinalState) and intermediate

ones (e.g., AlarmDetection, Rearguard, and so on).

When an agent is in a given state and its event queue

has an event, which belongs to the valid inputs

(events) for transition, then the agent transits from

the current state to the transition target state and

executes the action associated with that transition.

This mechanism is not repeated again in the new

state until the execution of such an action has been

completed. There is a kind of particular transition,

the universal transition, which is valid for any

automaton state. This transition takes place for a

given input. Then, the action is executed and the

automaton transits to the next state, regardless of the

automaton’s state. For the reactive agent to be

capable of interpreting the graphically represented

automaton it is necessary to express it in a textual

way through an XML file. Actions are part of the

reactive agent automaton and are defined as methods

of semantic actions. Table 1 has been introduced to

better understand how the modelled automaton

works.

2.3 Application Resources Description

Application resources inherit the management

interface from the resource pattern. The developer

should define the use interface and the class that

implements the interface for each resource. In

general, an interface NAMEUseItf is created in a

package called icaro.applications.resources.NAME

for a NAME resource. This interface defines

methods callable from other components.

2.4 How to Access a Resource and Send

Events

Firstly a variable, whose type is resource use

interface, is defined. After that, the resource use

interface is retrieved from interface repository.

Then, all is ready to access the methods offered by

the interface. A resource accesses another resource

by following a mechanism similar to the previously

described one. Next, we illustrate how an event

containing information is sent by an agent. First, an

array of objects is created with a size equal to the

objects to be sent, and then it is initialized. Let us

highlight that the order of assignment should be the

same that appears in the parameters definition of the

semantic action that will be executed upon receiving

the event. After that the interface repository use

interface is retrieved and it is used to get the use

interface associated with the agent instance to which

the event will be sent. Then, the event is created.

Finally, the event is sent using the use interface.

Notice that sending an event to an agent from a

resource follows this same idea.

2.5 Organization File Description

The application organization is described through an

XML file (in our case it is “RobotSimulation.xml”)

that conforms to “OrganizationDescription-

Schema.xsd” file. Firstly, the XML file describes the

organization components features: managers’

behaviour, application agents’ behaviour, and

application resources description. Secondly, the

application instances are defined. Moreover, the

instances managed for each manager are also

specified. Finally, a script file in bin folder should be

created to launch the developed application. This file

will contain the following command: ‘ant -

buildfile=../build.xml run –DdescriptionPath=

DESC’ (in our case DESC is RobotSimulation).

3 CONCLUSIONS

In order to cope with application development

complexity, the availability of architectural

framework ICARO-T facilitates the development of

MAS in several ways. (1) The categorization of

entities either as agents or resources implies a clear

design choice for the developer. (2) Environment

can be modelled as a set of resources, with clear

usage and management interfaces. There are

standard patterns and mechanisms in the framework

to facilitate their access. (3) Management of agents

and resources follows certain patterns and most

management functionality is already implemented.

This relieves the developer of a considerable amount

of work, and guarantees that the component will be

under control. (4) The framework enforces a pattern

for system initialization, which is particularly

important in MAS where multiple distributed

entities have to be initialized consistently, and this

turns out to be a complex issue in many systems. (5)

Agents work as autonomous entities and encapsulate

their behaviour (reactive, cognitive) behind their

interfaces.

PROGRAMMING REACTIVE AGENT-BASED MOBILE ROBOTS USING ICARO-T FRAMEWORK

289

Table 1: Description of the automaton’s actions.

Action Description

move The agent sends itself a newStep event if there is no alarm.

notifyPosition

Determines if the agent becomes the chief. The chief is the agent closer to the alarm and the ties

are solved in favour of the agent that has a lower index. The agent sends itself a ChiefDesignation

event if it becomes the chief.

stayInRearguard

The agent updates its role as rearguard and learns who the chief is. The robot does not move while

it has this role.

subordinate

The agent (1) updates its role as subordinate and learns who is the chief, and (2) sends itself a

newStep event.

assignRoles

The agent (1) updates its role as chief, (2) assigns to what corner the chief should go, (3) assigns

to what corners the three next closets agents to the alarm should go to, and sends them a

subordinateDesignation event that contains the following information: the target corner that it

should occupy and who is the chief robot, (4) send to the other agents a rearguardDesignation

event, and finally, (5) sends itself a newStep event. The notifyPosition action may be consulted to

know how the ties are solved.

goToFreeCorner

If the chief/subordinate agent is on the assigned target corner, then it sends itself an

alarmTargetCorner event; otherwise it determines to what corner it will move next, and it sends

itself a newStep event.

notifyChiefOfTheError

If the agent is a rearguard, then it sends an errorRearguard event to the chief; whereas if it is a

subordinate agent, then it sends an errorSubordinate event, which contains its identification

number to the chief. In both cases the agent marks the controlled robot as damaged.

informChief

The subordinate agent sends to the chief agent an alarmTargetCornerSub event, which contains

the subordinate agent identification number.

markReachedTarget

CornerSub

The chief agent (1) marks the target corner that the subordinate agent has occupied, (2) increases

the number of occupied corners, and, (3) notifies the user when four target corners have been

occupied.

markReachedTarget

CornerChief

The chief agent (1) marks the target corner that it has occupied, (2) increases the number of

occupied corners, and, (3) notifies the user when four target corners have been occupied.

selectSubordinate

InRearguard

The chief agent (1) increases the number of damaged robots, (2) identifies the closest rearguard

agent to the target corner to be occupied by the damaged subordinate agent, and, (3) sends a

subordinateDesignation event that contains the target corner and the chief identification number.

markFailureyRearguard

The chief agent (1) marks the rearguard agent that sent an errorRearguard event as damaged, and,

(2) increases the number of damaged robots.

generateRoles

Reasignation

The chief agent (1) marks itself as damaged, (2) increases number of damaged robots, and, (3)

sends to the rest of agents a rolesReassignation event that contains the location of the building

where the alarm occurred.

ACKNOWLEDGEMENTS

This work was partially supported by Spanish

Ministerio de Ciencia e Innovación TIN2007-67586-

C02-02, and Junta de Comunidades de Castilla-La

Mancha PII2I09-0069-0994 and PEII09-0054-9581

grants.

REFERENCES

Bordini, R.H., Dastani, M., Dix, J., El Fallah Seghrouchni,

A. (Editors.). (2005). Multi-Agent Programming:

Languages, Platforms and Applications. Springer.

Braubach, L., Pokahr, A. (2009).

http://jadex.informatik.uni-

hamburg.de/bin/view/Links/Agent+Platforms.

Caire, G., Coulier, W., Garijo, F., Gómez, J., Pavón, J.,

Leal, F., Chainho, P., Kearney, P., Stark, J., Evans, R.,

Massonet, P. (2002). Agent-oriented analysis using

MESSAGE/UML. LNCS 2222, pp. 119-135.

Celorrio, C., Verdejo, M.F. (2007). Adapted activity

deployment and configuration in a pervasive learning

framework. Pervasive Learning, PL2007, pp. 51-58.

Garijo, F., Polo, F., Spina, D., Rodríguez, C. (2008).

ICARO-T User Manual. Technical Report, Telefonica

I+D.

Garijo, F., Bravo, S., Gonzalez, J., Bobadilla, E. (2004)

BOGAR_LN: An agent based component framework

for developing multi-modal services using natural

language. LNAI 3040, pp. 207-220.

Garijo, F., Tous, J., Matias, J.M., Corley, S., Tesselaar, M.

(1998). Development of a multi-agent system for

cooperative work with network negotiation

Capabilities. LNCS 1437, pp. 204–219.

Gascueña, J.M., Fernández-Caballero, A. (2009). Towards

an integrative methodology to develop multi-agent

systems. First International Conference on Agents and

Artificial Intelligence, ICAART'09, pp. 392-399.

Gascueña, J.M., Fernández-Caballero, A. (2009). On the

use of agent technology in intelligent, multi-sensory

and distributed surveillance. The Knowledge

Engineering Review, to appear.

Gómez-Sanz, J., Pavón, J., Díaz-Carrasco, A. (2003). The

PSI3 agent recommender system. LNCS 2722, pp. 30-39.

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

290

Gómez-Sanz, J., Pavón, J., Garijo, F. (2000). Intelligent

interface agents behavior modeling. LNAI 1793, pp.

598-609.

Luehrs, R., Pavón, J., Schneider, M. (2003). DEMOS tools

for online discussion and decision making. LNCS

2722, pp. 525-528.

Pavón, J., Garijo, F., Gómez-Sanz, J. (2008). Complex

systems and agent-oriented software engineering.

LNAI 5049, pp. 3-16.

Pavón, J. Gómez-Sanz, J., Fernández-Caballero, A.,

Valencia-Jiménez, J.J. (2007). Development of

intelligent multisensor surveillance systems with

agents. Robotics and Autonomous Systems 55(12), pp.

892-903.

PROGRAMMING REACTIVE AGENT-BASED MOBILE ROBOTS USING ICARO-T FRAMEWORK

291
