MODEL-FREE LEARNING FROM DEMONSTRATION

Erik A. Billing, Thomas Hellstr¨om and Lars-Erik Janlert

Department of Computing Science, Ume˚a University, Ume˚a, Sweden

Keywords:

Learning from demonstration, Prediction, Robot imitation, Motor control, Model-free learning.

Abstract:

A novel robot learning algorithm called Predictive Sequence Learning (PSL) is presented and evaluated. PSL

is a model-free prediction algorithm inspired by the dynamic temporal difference algorithm S-Learning. While

S-Learning has previously been applied as a reinforcement learning algorithm for robots, PSL is here applied

to a Learning from Demonstration problem. The proposed algorithm is evaluated on four tasks using a Khepera

II robot. PSL builds a model from demonstrated data which is used to repeat the demonstrated behavior. After

training, PSL can control the robot by continually predicting the next action, based on the sequence of passed

sensor and motor events. PSL was able to successfully learn and repeat the ﬁrst three (elementary) tasks, but

it was unable to successfully repeat the fourth (composed) behavior. The results indicate that PSL is suitable

for learning problems up to a certain complexity, while higher level coordination is required for learning more

complex behaviors.

1 INTRODUCTION

Recent years have witnessed an increased interest

in computational mechanisms that will allow robots

to Learn from Demonstrations (LFD). With this ap-

proach, also referred to as Imitation Learning, the

robot learns a behavior from a set of good examples,

demonstrations. The ﬁeld has identiﬁed a number of

key problems, commonly formulated as what to imi-

tate, how to imitate, when to imitate and who to im-

itate (Billard et al., 2008). In the present work, we

focus on the ﬁrst question, referring to which aspects

of the demonstration should be learned and repeated.

Inspiration is taken from several functional mod-

els of the brain and prediction is exploited as a way

to learn state deﬁnitions. A novel learning algo-

rithm, called Predictive Sequence Learning (PSL), is

here presented and evaluated. PSL is inspired by

S-Learning (Rohrer and Hulet, 2006a; Rohrer and

Hulet, 2006b), which has previously been applied to

robot learning problems as a model-free reinforce-

ment learning algorithm (Rohrer, 2009; Rohrer et al.,

2009).

The paper is organized as follows. In Section 2

a theoretical background and biological motivation is

given. Section 3 gives a detailed description of the

proposed algorithm. Section 4 describes the exper-

imental setup and results for evaluation of the algo-

rithm. In Section 5, conclusions, limitations and fu-

ture work are discussed.

2 MOTIVATION

One common approach to identify what in a demon-

stration that is to be imitated is to exploit the variabil-

ity in several demonstrations of the same behavior.

Invariants among the demonstrations are seen as the

most relevant and selected as essential components of

the task (Billard et al., 2008; Delson and West, 1994).

Several methods for discovering invariants in demon-

strations can be found in the LFD literature. One

method presented by Billard and co-workers applies

a time-delayed neural network for extraction of rele-

vant features from a manipulation task (Billard et al.,

2003; Billard and Mataric, 2001). A more recent ap-

proach uses demonstrations to impose constraints in a

dynamical system, e.g. (Calinon et al., 2007; Guenter

et al., 2007).

While this is a suitable method for many types

of tasks, there are also applications where it is less

obvious which aspects of a behavior should be in-

variant, or if the relevant aspects of that behavior is

captured by the invariants. Since there is no uni-

versal method to determine whether two demonstra-

tions should be seen as manifestations of the same

behavior or two different behaviors (Billing and Hell-

strm, 2008b), it is in most LFD applications up to

A. Billing E., Hellström T. and Janlert L. (2010).

MODEL-FREE LEARNING FROM DEMONSTRATION.

In Proceedings of the 2nd International Conference on Agents and Artiﬁcial Intelligence - Agents, pages 62-71

DOI: 10.5220/0002729500620071

 SciTePress

the teacher to decide. However, the teacher’s group-

ing of actions into behaviors may not be useful for

the robot. In the well known imitation framework

by Nehaniv and Dautenhahn (Nehaniv and Dauten-

hahn, 2000), it is emphasized that the success of an

imitation is observer dependent. The consequence

of observer dependence when it comes to interpret-

ing sequences of actions has been further illustrated

with Pfeifer and Scheier’s argument about the frame

of reference (Pfeifer and Scheier, 1997; Pfeifer and

Scheier, 2001), and is also reﬂected in Simon’s para-

ble with the ant (Simon, 1969). A longer discussion

related to these issues can be found in (Billing, 2007).

Pfeifer and Scheier promotes the use of a low

level speciﬁcation (Pfeifer and Scheier, 2001), and

speciﬁcally the sensory-motor space I =U ×Y, where

U and Y denotes the action space and observation

space, respectively. Representations created directly

in I prevents the robot from having memory, which

has obvious limitations. However, systems with no

or very limited memory capabilities has still reached

great success within the robotics community through

the works by Rodney Brooks, e.g., (Brooks, 1990;

Brooks, 1991a; Brooks, 1991b; Brooks, 1986), and

the development of the reactive and behavior based

control paradigms, e.g., (Arkin, 1998). By extend-

ing the deﬁnition of I such that it captures a cer-

tain amount of temporal structure, the memory limi-

tation can be removed. Such a temporally extended

sensory-motor space is denoted history information

space I

= I

× I

× ... × I

, where τ denotes the

temporal extension of I (Billing and Hellstrm, 2008b).

With a large enough τ, I

can model any behavior.

However, a large τ leads to an explosion of the num-

ber of possible states, and the robot has to generalize

such that it can act even though the present state has

not appeared during training.

In the present work, we present a learning method

that is not based on ﬁnding invariants among several

demonstrations of, what the teacher understands to

be “the same behavior”. Taking inspiration from re-

cent models of the brain where prediction plays a cen-

tral role, e.g. (Friston, 2003; George, 2008; Haruno

et al., 2001; Lee and Mumford, 2003), we approach

the question of what to imitate by the use of predic-

tion.

2.1 Functional Models of Cortex

During the last two decades a growing body of re-

search has proposed computational models that aim

to capture different aspects of human brain function,

speciﬁcally the cortex. This research includes models

of perception, e.g., Riesenhuber and Poggio’s hierar-

chical model (Riesenhuber and Poggio, 1999) which

has inspired several more recent perceptual models

(George, 2008; Lee and Mumford, 2003; Poggio and

Bizzi, 2004), models of motor control (Haruno et al.,

2003; Rohrer and Hulet, 2006a; Wolpert and Ghahra-

mani, 2000; Wolpert and Flanagan, 2001; Wolpert,

2003) and learning (Friston, 2003). In 2004, this

ﬁeld reached a larger audience with the release of

Jeff Hawkins’s book On Intelligence (Hawkins and

Blakeslee, 2002). With the ambition to present a uni-

ﬁed theory of the brain, the book describes cortex

as a hierarchical memory system and promotes the

idea of a common cortical algorithm. Hawkins’s the-

ory of cortical function, referred to as the Memory-

Prediction framework, describes the brain as a predic-

tion system. Intelligence is, in this view, more about

applying memories in order to predict the future, than

it is about computing a response to a stimulus.

A core issue related to the idea of a common cor-

tical algorithm is what sort of bias the brain uses. One

answer is that the body has a large number of reward

systems. These systems are activated when we eat,

laugh or make love, activities that through evolution

have proved to be important for survival. However,

these reward systems are not enough. The brain also

needs to store the knowledge of how to activate these

reward systems.

In this context, prediction appears to be critical for

learning. The ability to predict the future allows the

agent to foresee the consequences of its actions and

in the long term how to reach a certain goal. How-

ever, prediction also plays an even more fundamental

role by providing information about how well a cer-

tain model of the world correlates with reality.

This argument is supported not only by Hawkins’s

work, but by a large body of research investigating

the computational aspects of the brain. It has been

proposed that the central nervous system (CNS) sim-

ulates aspects of the sensorimotor loop (Jordan and

Rumelhart, 1992; Kawato et al., 1987; Miall and

Wolpert, 1996; Wolpert and Flanagan, 2001). This in-

volves a modular view of the CNS, where each mod-

ule implements one forward model and one inverse

model. The forward model predicts the sensory con-

sequences of a motor command, while the inverse

model calculates the motor command that, in the cur-

rent state, leads to the goal (Wolpert, 2003). Each

module works under a certain context or bias, i.e., as-

sumptions about the world which are necessary for the

module’s actions to be successful. One purpose of the

forward model is to create an estimate of how well the

present situation corresponds to these assumptions. If

the prediction error is low the situation is familiar.

However, if the prediction error is high, the situation

MODEL-FREE LEARNING FROM DEMONSTRATION

does not correspond to the module’s context and ac-

tions produced by the inverse model may be inappro-

priate.

These ﬁndings have inspired recent research on

robot perception and control. One example is the

rehearse, predict, observe, reinforce decomposition

proposed by Demiris and others (Demiris and Hayes,

2002; Demiris and Simmons, 2006; Schaal et al.,

2003) which adapts the view of perception and action

as two aspects of a single process. Hierarchical rep-

resentations following this decomposition have also

been tested in an LFD setting (Demiris and Johnson,

2003) where the robot successfully learns sequences

of actions from observation. The present work should

be seen as a further investigation of these theories ap-

plied to robots, with focus to learning with minimal

bias.

2.2 Sequence Learning

The learning algorithm presented in this paper, re-

ferred to as Predictive Sequence Learning (PSL), is

inspired by S-Learning, a dynamic temporal differ-

ence (TD) algorithm presented by Rohrer and Hulet,

(Rohrer and Hulet, 2006a; Rohrer and Hulet, 2006b).

S-Learning builds sequences of passed events which

may be used to predict future events, and in contrast

to most other TD algorithms it can base its predictions

on many previous states.

S-Learning can be seen as a variable order Markov

model (VMM) and we have observed that it is very

similar to the well known compression algorithm

LZ78 (Ziv and Lempel, 1978). This coincidence is

not that surprising considering the close relationship

between loss-less compression and prediction (Be-

gleiter and Yona, 2004). In principle, any lossless

compression algorithm could be used for prediction,

and vice versa (Feder and Merhav, 1994).

S-Learning was originally developed to capture

the discrete episodic properties observed in many

types of human motor behavior (Rohrer, 2007). It

takes inspiration from the Hierarchical Temporal

Memory algorithm (George and Hawkins, 2005), with

focus on introducing as few assumptions into learning

as possible. More recently, it has been applied as a

model-free reinforcement learning algorithm for both

simulated and physical robots (Rohrer, 2009; Rohrer

et al., 2009). We have also evaluated S-Learning as an

algorithm for behavior recognition (Billing and Hell-

strm, 2008a). However, to our knowledge it has never

been used as a control algorithm for LFD.

The model-free design of S-Learning, together

with its focus on sequential data and its connections

to human motor control makes S-Learning very inter-

esting for further investigation as a method for robot

learning. With the ambition to increase the focus on

prediction, and propose a model that automatically

can detect when it is consistent with the world, PSL

was designed.

3 PREDICTIVE SEQUENCE

LEARNING

PSL is trained on an event sequence η =

,. .. ,e

), where each event e is a member

of an alphabet

∑

. η is deﬁned up to the current time t

from where the next event e

t+1

is to be predicted.

PSL stores its knowledge as a set of hypotheses,

known as a hypothesis library H. A hypothesis h ∈ H

expresses a dependence between an event sequence

X = (e

t− n

t− n+1

,. .. ,e

) and a target event I = e

t+1

h : X ⇒ I (1)

is referred to as the body of h and I

denotes the

head. Each h is associated with a conﬁdence c reﬂect-

ing the conditional probability P(I|X). For a given

η, c is deﬁned as c(X ⇒ I) = s(X,I) /s(X), where

the support s(X) describes the proportion of transac-

tions in η that contains X and (X, I) denotes the con-

catenation of X, and I. A transaction is deﬁned as a

sub-sequence of the same size as X. The length of h,

denoted |h|, is deﬁned as the number of elements in

. Hypotheses are also referred to as states, since a

hypothesis of length |h| corresponds to VMM state of

order |h|.

3.1 Detailed Description of PSL

Let the library H be an empty set of hypotheses. Dur-

ing learning, described in Algorithm 1, PSL tries to

predict the future event e

t+1

, based on the observed

event sequence η. If it fails to predict the future state,

a new hypothesis h

new

is created and added to H. h

new

is one element longer than the longest matching hy-

pothesis previously existing in H. In this way, PSL

learns only when it fails to predict.

For example, consider the event sequence η =

ABCCABCCA. Let t = 1. PSL will search for a

hypothesis with a body matching A. Initially H is

empty and consequently PSL will create a new hy-

pothesis (A) ⇒ B which is added to H. The same

procedure will be executed at t = 2 and t = 3 so that

H = {(A) ⇒ B;(B) ⇒ C;(C) ⇒ C}. At t = 4, PSL

will ﬁnd a matching hypothesis h

max

: (C) ⇒ C pro-

ducing the wrong prediction C. Consequently, a new

hypothesis (C) ⇒ A is added to H. The predictions at

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

t = 5 and t = 6 will be successful while h : (C) ⇒ A

will be selected at t = 7 and produce the wrong pre-

diction. As a consequence, PSL will create a new

hypothesis h

new

: (B,C) ⇒ C. Source code from the

implementation used in the present work is available

online (Billing, 2009).

Algorithm 1. Predictive Sequence Learning (PSL).

Given an event sequence η = (e

,. .. ,e

)

1. Let the current time t = 1 and the library H =

2. Let M ⊆ H be all hypotheses h with X



t− |h|+1

t− |h|+2

,. .. ,e



3. If M =

(a) Create a new hypothesis h

new

: (e

) ⇒ e

t+1

(b) Add h

new

to H

4. Let h

max

be the longest hypothesis h ∈ M. If sev-

eral hypotheses with the same length exist, select

the one with highest conﬁdence c.

5. If e

t+1

6= I

max

(a) Let h

correct

∈ H be the longest hypothesis h ∈ M

with I

= e

t+1

(b) If no such hypothesis exists in H, create a new

hypothesis h

new

: (e

) ⇒ e

t+1

new



t− |h

correct

t− |h

correct

|+1

t− |h

correct

|+2

,. .. ,e



⇒

t+1

(d) Add h

new

to H

6. Update the conﬁdence for h

max

and h

correct

as de-

scribed in Section 3

7. Set t = t + 1

8. If t < n, then continue from 2.

Algorithm 2. Making predictions using PSL.

Given an event sequence η = (e

,. .. ,e

)

1. Let M ⊆ H be all hypotheses h with X



t− |h|+1

t− |h|+2

,. .. ,e



2. Let h

max

be the longest hypothesis h ∈ M. If sev-

eral hypothesis with the same length exists, select

the one with highest conﬁdence c.

3. Return the prediction e

′

t+1

= I(h

max

)

3.2 Making Predictions

After, or during, learning, PSL can be used to make

predictions based on the sequence of passed events

η = (e

,. .. ,e

). Since PSL continuously makes

predictions during learning, this procedure is very

similar to the learning algorithm (Algorithm 1). The

prediction procedure is described in Algorithm 2.

For prediction of a suite of future events, e

′

t+1

can

be added to η to create η

′

. Then repeat the procedure

described in Algorithm 2 using η

′

as event history.

3.3 Differences and Similarities between

PSL and S-Learning

Like PSL, S-Learning is trained on an event sequence

η. However, S-Learning does not produce hypothe-

ses. Instead, knowledge is represented as Sequences

φ, stored in a sequence library κ (Rohrer and Hulet,

2006b). φ does not describe a relation between a body

and a head, like hypotheses do. Instead, φ describes

a plain sequence of elements e ∈ η. During learning,

sequences are “grown” each time a matching pattern

for that sequence appears in the training data. Com-

mon patterns in η produce long sequences in κ. When

S-Learning is used to predict the next event, the be-

ginning of each φ ∈ κ is matched to the end of η. The

sequence producing the longest match is selected as a

winner, and the end of the winning sequence is used

to predict future events.

One problem with this approach, observed during

our previous work with S-Learning (Billing and Hell-

strm, 2008a), is that new, longer sequences, are cre-

ated even though the existing sequence already has

Markov property, meaning that it can predict the next

element optimally. To prevent the model from getting

unreasonably large, S-Learning implements a max-

imum sequence length m. As a result, κ becomes

unnecessarily large, even when m is relatively low.

More importantly, by setting the maximum sequence

length m, a task-dependent modeling parameter is

introduced, which may limit S-Learning’s ability to

model η.

PSL was designed to alleviate the problems with

S-Learning. Since PSL learns only when it fails to

predict, it is less prune to be overtrained and can em-

ploy an unlimited maximum sequence length without

exploding the library size.

4 EVALUATION

The PSL algorithm was tested on a Khepera II minia-

ture robot (K-Team, 2007). In the ﬁrst evaluation

(Section 4.1), the performance of PSL on a play-

ful LFD task is demonstrated. During both experi-

ments, the robot is given limited sensing abilities us-

ing only its eight infrared proximity sensors mounted

around its sides. In a second experiment (Section 4.2),

MODEL-FREE LEARNING FROM DEMONSTRATION

the prediction performance during training of PSL is

compared to the performance of S-Learning, using

recorded sensor and motor data from the robot.

One important issue, promoted both by Rohrer

with colleagues (Rohrer et al., 2009; Rohrer, 2009)

and ourselves (Billing and Hellstrm, 2008b), is the

ability to learn even with limited prior knowledge of

what is to be learned. Prior knowledge is informa-

tion intentionally introduced into the system to sup-

port learning, often referred to as ontological bias or

design bias (Billing and Hellstrm, 2008b). Examples

of common design biases are pre-deﬁned state spec-

iﬁcations, pre-processing of sensor data, the size of

a neural network, the length of a temporal window

or other “tweaking” parameters. While design biases

help in learning, they also limit the range of behaviors

a robot can learn. Furthermore, a system implement-

ing large amounts of design bias will to a larger extent

base its decisions not on its own experience, but on

knowledge of the programmer designing the learning

algorithm, making it hard to determine what the sys-

tem has actually learned.

In addition to design bias, there are many limita-

tions and constraints introduced by other means, e.g.,

by the size and shape of the robot including its sensing

and action capabilities, structure of the environment

and performance limitations of the computer used.

These kinds of limitations are referred to as prag-

matical bias. We generally try to limit the amount

of ontological bias, while pragmatical bias should be

exploited by the learning algorithm to ﬁnd valuable

patterns.

In the present experiments, the robot has no pre-

vious knowledge about its surroundings or itself. The

only obvious design bias is the thresholding of prox-

imity sensors into three levels, far, medium and close,

corresponding to distances of a few centimeters. This

thresholding was introduced to decrease the size of

the observation space Y, limiting the amount of train-

ing required. An observation y ∈ Y is deﬁned as the

combination of the eight proximity sensors, produc-

ing a total of 3

possible observations.

An action u ∈ U is deﬁned as the combination of

the speed commands sent to the two motors. The

Khepera II robot has 256 possible speeds for each

wheel, producing an action space U of 256

possible

actions. However, only a small fraction of these were

used during demonstration.

The event sequence is built up by alternating sen-

sor and action events, η = (u

.. ., u

). k

is here used to denote the current stage, rather than

the current position in η denoted by t. Even though

events is categorized into observations and actions,

PSL makes no distinction between these two types

of events. From the perspective of the algorithm, all

events e

∈

∑

are discrete entities with no predeﬁned

relations, where

∑

= Y ∪U.

In each stage k, PSL is used to predict the next

event, given η. Since the last element of η is an ob-

servation, PSL will predict an action u

∈ U, leading

to the observation y

∈ Y. u

and y

are appended

to η, transforming stage k to k + 1. This alternat-

ing use of observations and actions was adopted from

S-Learning (Rohrer and Hulet, 2006a). A stage fre-

quency of 10 Hz was used, producing one observation

and one action every 0.1 seconds.

4.1 Demonstration and Repetition of

Temporally Structured Behavior

To evaluate the performance of PSL on an LFD prob-

lem, four tasks are deﬁned and demonstrated using the

Khepera II robot. Task 1 involves the robot moving

forward in a corridor approaching an object (cylindri-

cal wood block). When the robot gets close to the

object, it should stop and wait for the human teacher

to “load” the object, i.e., place it upon the robot. After

loading, the robot turns around and goes back along

the corridor. Task 2 involves general corridor driving,

taking turns in the right way without hitting the walls

and so on. Task 3 constitutes the “unloading” proce-

dure, where the robot stops in a corner and waits for

the teacher to remove the object and place it to the

right of the robot. Then the robot turns and pushes

the cylinder straight forward for about 10 centime-

ters, backs away and turns to go for another object.

Task 4 is the combination of the three previous tasks.

The sequence of actions expected by the robot is illus-

trated in Figure 1 and the experimental setup can be

seen in Figure 2. Even though the setup was roughly

the same in all experiments, the starting positions and

exact placement of the walls varied between demon-

stration and repetition.

All tasks capture a certain amount of temporal

structure. One example is the turning after loading

the object in Task 1. Exactly the same pattern of sen-

sor and motor data will appear before, as well as after,

turning. However, two different sequences of actions

is expected. Speciﬁcally, after the teacher has taken

the cylinder to place it on the robot, only the sensors

on the robot’s sides are activated. The same sensor

pattern appears directly after the robot has completed

the 180 degree turn, before it starts to move back

along the corridor. Furthermore, the teacher does not

act instantly. After placing the object on the robot,

one or two seconds passed before the teacher issued

a turning command, making it more difﬁcult for the

learning algorithm to ﬁnd the connection between the

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

wait for loading,

then turn and go back

turn

start

unload

push object

Figure 1: Schematic overview of the composed behavior

(Task 4). Light gray rectangles mark walls, dark gray cir-

cles mark the objects and dashed circles mark a number

of key positions for the robot. The robot starts by driving

upwards in the ﬁgure, following the dashed line. until it

reaches the object at the loading position. After loading,

the robot turns around and follows the dashed line back un-

til it reaches the unload position. When the cylinder has

been unloaded (placed to the left of the robot), the robot

turns and pushes the object. Finally, it backs away from the

pile and awaits further instructions.

Figure 2: Experimental setup.

events. Even Task 2 which is often seen as a typi-

cal reactive behavior is, due to the heavy thresholding

of sensor data, temporally demanding. Even longer

temporal structures can be found in Task 3, where

the robot must push the object and remember for how

long the object is to be pushed. This distance was not

controlled in any way, making different demonstra-

tions of the same task containing slightly conﬂicting

data.

Results. After training, the robot was able to re-

peat Task 1, 2 and 3 successfully. For Task 1, seven

demonstrations was used for a total of about 2.6 min.

Task 2 was demonstrated for about 8.7 min and Task

3 was demonstrated nine times, in total 4.6 min. The

robot did occasional mistakes in all three tasks, reach-

Table 1: Detailed statistics on the four evaluation tasks.

Training events is the number of sensor and motor events

in demonstrated data. Lib. size is the number of hypotheses

in library after training. Avg. |h| is the average hypothesis

length after training.

Task Training

events

Lib. size Avg. |h|

Task 1 3102 4049 9.81

Task 2 10419 30517 16

Task 3 5518 8797 11

Task 4 26476 38029 15

ing situations where it had no training data. In these

situations it sometimes needed help to be able to com-

plete the task. However, the number of mistakes

clearly decreased with increased training, and mis-

takes made by the teacher during training often helped

the robot to recover from mistakes during repetition.

For Task 4, the demonstrations from all three par-

tial tasks were used, plus a single 2 min demonstra-

tion of the entire Task 4. Even after extensive train-

ing, resulting in almost 40 000 hypotheses in library,

the robot was unable to repeat the complete behavior

without frequent mistakes. Knowledge from the dif-

ferent sub-tasks was clearly interfering, causing the

robot to stop and wait for unloading when it was sup-

posed to turn, turning when it was supposed to follow

the wall and so on. Detailed results for all four tasks

can be found in Table 1.

PSL was trained until it could predict about 98%

of the demonstrated data correctly. It would be pos-

sible to train it until it reproduces all events correctly,

but this takes time and initial experiments showed

that it did not affect the imitation performance sig-

niﬁcantly.

4.2 Comparison between S-Learning

and PSL

In Section 3.3, a number of motivations for the de-

sign of PSL were given, in relation to S-Learning.

One such motivation was the ability to learn and

increase the model size only when necessary. S-

Learning always learns and creates new sequences

for all common events, while PSL only learns when

prediction fails. However, it should be pointed out

that even though S-Learning never stops to learn un-

less an explicit limit on sequence length is introduced,

it quickly reduces the rate at which new sequences

are created in domains where it already has extensive

knowledge.

To evaluate the effect of these differences between

PSL and S-Learning, prediction performance and li-

brary size was measured during training in three test

MODEL-FREE LEARNING FROM DEMONSTRATION

cases. Case 1 contained a demonstration of the load-

ing procedure (Task 1) used in the LFD evaluation,

Section 4.1. During the demonstration, the procedure

was repeated seven times for a total of about 150 sec-

onds (3000 sensor and motor events). Case 2 encap-

sulated the whole composed behavior (Task 4) used

in LFD evaluation. The behavior was demonstrated

once for 120 seconds (2400 events). Case 3 consti-

tuted 200 seconds of synthetic data, describing a 0.1

Hz sinus wave discretized with a temporal resolution

of 20 Hz and an amplitude resolution of 0.1 (resulting

in 20 discrete levels). The 4000 elements long data

sequence created a clean repetitive pattern with minor

ﬂuctuations due to sampling variations.

In addition to PSL and S-Learning, a ﬁrst order

Markov model (1MM) was included in the tests. The

Markov model can obviously not learn the pattern in

any of the three test cases perfectly, since there is no

direct mapping e

⇒ e

t+1

for most events. Hence, The

1MM should be seen only as a base reference.

Results. Figures 3, 4 and 5 displays results from the

three test cases. The upper plot of each ﬁgure repre-

sents the accumulated error count for each of the three

learning algorithms. The lower plot shows the model

size (number of sequences in library) for PSL and S-

Learning. Since the Markov model does not have a

library, the number of edges in the Markov graph is

shown, which best corresponds to sequences or hy-

potheses in S-Learning and PSL, respectively.

5 DISCUSSION

In the present work, a novel robot learning algorithm

called Predictive Sequence Learning (PSL) is pre-

sented and evaluated in an LFD setting. PSL is both

parameter-free and model-free in the sense that no on-

tological information about the robot or conditions in

the world is pre-deﬁned in the system. Instead, PSL

creates a state space (hypothesis library) in order to

predict the demonstrated data optimally. This state

space can thereafter be used to control the robot such

that it repeats the demonstrated behavior.

In contrast to many other LFD algorithms, PSL

does not build representations from invariants among

several demonstrations that a human teacher consid-

ers to be “the same behavior”. All knowledge, from

one or several demonstrations, is stored as hypothe-

ses in the library. PSL treats inconsistencies in these

demonstrations by generating longer hypotheses that

will allow it to make the correct predictions. In this

way, the ambiguous deﬁnition of behavior is avoided.

In the prediction performance comparison, PSL

0 50 100 150

500

1000

time (s)

error count

Accumulated training error

PSL

S-Learning

1MM

0 50 100 150

200

400

600

800

time (s)

library size

Model growth

PSL

S-Learning

1MM

Figure 3: Case 1 - Loading behavior. See text for details.

0 20 40 60 80 100 120

500

1000

time (s)

error count

Accumulated training error

PSL

S-Learning

1MM

0 20 40 60 80 100 120

200

400

600

time (s)

library size

Model growth

PSL

S-Learning

1MM

Figure 4: Case 2 - Composed behavior. See text for details.

0 20 40 60 80 100 120 140 160 180 200

500

1000

time (s)

error count

Accumulated training error

PSL

S-Learning

1MM

0 20 40 60 80 100 120 140 160 180 200

200

400

600

800

time (s)

library size

Model growth

PSL

S-Learning

1MM

Figure 5: Case 3 - Sinus wave. See text for details.

produces signiﬁcantly smaller libraries than S-

Learning on all three data sets. The difference is par-

ticularly large in Case 3 (Figure 5), where the algo-

rithms learn to predict the data almost perfectly. In

this situation, S-Learning continues to create new se-

quences, while PSL does not.

In Case 3, PSL also shows the clearly fastest learn-

ing rates (least accumulated errors). The reason can

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

be found in that PSL learns on each event where it

fails to predict, while S-Learning learns based on se-

quence length. When the model grows, S-Learning

decreases its learning rate even though the perfor-

mance is still low. In contrast, the learning rate of PSL

is always proportional to performance, which can also

be seen in the plots for all three test cases (Figures 3,

4 and 5). However, even though PSL commits less ac-

cumulated errors than S-Learning in all three tests, the

performance difference in Case 1 and 2 is small and

how these results generalize to other kinds of data is

still an open question.

In the demonstration-repetition evaluation, tasks

1, 2 and 3 were repeated correctly. Even though the

robot made occasional mistakes, the imitation perfor-

mance clearly increased with more demonstrations.

However, in Task 4, which was a combination of

the three ﬁrst tasks, an opposite pattern could be ob-

served. Despite the fact that PSL was still able to

predict demonstrated data almost perfectly, knowl-

edge from the three elementary tasks clearly inter-

fered. The reason for this interference is that Task

4 requires much longer temporal dynamics than any

of the elementary tasks did when learned separately.

One example of how this knowledge interference

is manifested is the turning versus unloading. When

the robot approaches the position marked as turn in

Figure 1, coming from the left and is supposed to take

a right turn, it no longer sees the right wall behind

it. Consequently, the situation looks identical to that

of unloading. When the robot is to unload, it goes

downward in Figure 1 (position unload) but instead

of turning it must wait for the cylinder to be placed to

its right side. To make the right prediction, PSL has

to base its decision on information relatively far back

in the event history. Even though PSL has no problem

to build a sufﬁciently large model from training data,

the large temporal window produces a combinatorial

explosion and the chance of the right patterns reap-

pearing during repetition is small. As a result, PSL

decreases the temporal window (i.e., uses shorter hy-

potheses), and the two situations become inseparable.

5.1 Conclusions and Future Work

The results shows that the proposed algorithm is fea-

sible for LFD problems up to a certain complexity.

PSL implements very few assumptions of what to be

learned and is therefore likely to be applicable to a

wide range of problems.

However, PSL also shows clear limitations when

the learning problem increases and longer temporal

dynamics is required. PSL is subject to combina-

torial explosion and the amount of required training

data increases exponentially with problem complex-

ity. In these situations, some higher-level coordina-

tion is clearly necessary. One possible solution is

to place PSL as a module in a hierarchical system.

PSL learns both to predict sensor data as a response

of action (forward model) and select actions based

on the current state (inverse model). In the present

work, PSL is viewed purely as a controller and the

forward model is consequently not considered. How-

ever, as discussed in Section 2.1, forward models can

play an important role in coordinating action. One ar-

chitecture exploring this direction is the hierarchical

model of human motor control known as HMOSAIC

(Haruno et al., 2003). It would be possible to consider

PSL as one part in a similar architecture. Exploiting

these possibilities will be part of our future work.

ACKNOWLEDGEMENTS

We would like to thank Brandon Rohrer at Sandia Na-

tional Laboratories and Christian Balkenius at Lund

University for valuable input to this work.

REFERENCES

Arkin, R. C. (1998). Behaviour-Based Robotics. MIT Press.

Begleiter, R. and Yona, G. (2004). On prediction using vari-

able order markov models. Journal of Artiﬁcial Intel-

ligence Research, 22:385–421.

Billard, A., Calinon, S., Dillmann, R., and Schaal, S.

(2008). Robot programming by demonstration. In

Siciliano, B. and Khatib, O., editors, Handbook of

Robotics. Springer.

Billard, A., Epars, Y., Cheng, G., and Schaal, S. (2003).

Discovering imitation strategies through categoriza-

tion of multi-dimensional data. In Proceedings

of IEEE/RSJ International Conference on Intelligent

Robots and Systems, volume 3, pages 2398–2403

vol.3.

Billard, A. and Mataric, M. J. (2001). Learning human arm

movements by imitation:: Evaluation of a biologically

inspired connectionist architecture. Robotics and Au-

tonomous Systems, 37(2-3):145–160.

Billing, E. A. (2007). Representing behavior - distributed

theories in a context of robotics. Technical report,

UMINF 0725, Department of Computing Science,

Ume University.

Billing, E. A. (2009). Cognition reversed.

http://www.cognitionreversed.com.

Billing, E. A. and Hellstrm, T. (2008a). Behavior recog-

nition for segmentation of demonstrated tasks. In

IEEE SMC International Conference on Distributed

Human-Machine Systems, pages 228 – 234, Athens,

Greece.

MODEL-FREE LEARNING FROM DEMONSTRATION

Billing, E. A. and Hellstrm, T. (2008b). Formalising learn-

ing from demonstration. Technical report, UMINF

0810, Department of Computing Science, Ume Uni-

versity.

Brooks, R. A. (1986). A robust layered control system for

a mobile robot. In IEEE Journal of Robotics and Au-

tomation RA-2, volume 1, pages 14–23.

Brooks, R. A. (1990). Elephants don’t play chess. Robotics

and Autonomous Systems, 6:3–15.

Brooks, R. A. (1991a). Intelligence without reason. Pro-

ceedings, 1991 Int. Joint Conf. on Artiﬁcial Intelli-

gence, pages 569–595.

Brooks, R. A. (1991b). New approaches to robotics. Sci-

ence, 253(13):1227–1232.

Calinon, S., Guenter, F., and Billard, A. (2007). On

learning, representing and generalizing a task in a

humanoid robot. IEEE Transactions on Systems,

Man and Cybernetics, Part B. Special issue on robot

learning by observation, demonstration and imitation,

37(2):286–298.

Delson, N. and West, H. (1994). Robot programming by hu-

man demonstration: The use of human inconsistency

in improving 3D robot trajectories. In Proceedings of

the IEEE/RSJ/GI International Conference on Intelli-

gent Robots and Systems ’94. Advanced Robotic Sys-

tems and the Real World, IROS ’94., volume 2, pages

1248–1255, Munich, Germany.

Demiris, J. and Hayes, G. R. (2002). Imitation as a

dual-route process featuring predictive and learning

components: a biologically plausible computational

model. In Imitation in animals and artifacts, pages

327–361. MIT Press.

Demiris, Y. and Johnson, M. (2003). Distributed, predictive

perception of actions: a biologically inspired robotics

architecture for imitation and learning. Connection

Science, 15(4):231–243.

Demiris, Y. and Simmons, G. (2006). Perceiving the un-

usual: Temporal properties of hierarchical motor rep-

resentations for action perception. Neural Networks,

19(3):272–284.

Feder, M. and Merhav, N. (1994). Relations between en-

tropy and error probability. IEEE Transactions on In-

formation Theory, 40(1):259–266.

Friston, K. J. (2003). Learning and inference in the brain.

Neural Networks: The Ofﬁcial Journal of the In-

ternational Neural Network Society, 16(9):1325–52.

PMID: 14622888.

George, D. (2008). How the Brain might work: A Hierar-

chical and Temporal Model for Learning and Recog-

nition. PhD thesis, Stanford University, Department

of Electrical Engineering.

George, D. and Hawkins, J. (2005). A hierarchical bayesian

model of invariant pattern recognition in the visual

cortex. In Neural Networks, 2005. IJCNN ’05. Pro-

ceedings. 2005 IEEE International Joint Conference

on, volume 3, pages 1812–1817 vol. 3.

Guenter, F., Hersch, M., Calinon, S., and Billard, A. (2007).

Reinforcement learning for imitating constrained

reaching movements. RSJ Advanced Robotics, Spe-

cial Issue on Imitative Robots, 21(13):1521–1544.

Haruno, M., Wolpert, D. M., and Kawato, M. (2003). Hier-

archical MOSAIC for movement generation. In Inter-

national Congress Series 1250, pages 575– 590. Else-

vier Science B.V.

Haruno, M., Wolpert, D. M., and Kawato, M. M. (2001).

MOSAIC model for sensorimotor learning and con-

trol. Neural Comput., 13(10):2201–2220.

Hawkins, J. and Blakeslee, S. (2002). On Intelligence.

Times Books.

Jordan, M. and Rumelhart, D. (1992). Forward models: Su-

pervised learning with a distal teacher. Cognitive Sci-

ence: A Multidisciplinary Journal, 16(3):354, 307.

K-Team (2007). Khepera robot. http://www.k-team.com.

Kawato, M., Furukawa, K., and Suzuki, R. (1987). A hier-

archical neural-network model for control and learn-

ing of voluntary movement. Biological Cybernetics,

57(3):169–185. PMID: 3676355.

Lee, T. and Mumford, D. (2003). Hierarchical bayesian in-

ference in the visual cortex. J Opt Soc Am A Opt Im-

age Sci Vis, 20(7):1448, 1434.

Miall, R. C. and Wolpert, D. M. (1996). Forward mod-

els for physiological motor control. Neural Netw.,

9(8):1265–1279.

Nehaniv, C. L. and Dautenhahn, K. (2000). Of humming-

birds and helicopters: An algebraic framework for

interdisciplinary studies of imitation and its applica-

tions. In Demiris, J. and Birk, A., editors, Learning

Robots: An Interdisciplinary Approach, volume 24,

pages 136–161. World Scientiﬁc Press.

Pfeifer, R. and Scheier, C. (1997). Sensory-motor coordi-

nation: the metaphor and beyond. Robotics and Au-

tonomous Systems, 20(2):157–178.

Pfeifer, R. and Scheier, C. (2001). Understanding Intelli-

gence. MIT Press. Cambrage, Massachusetts.

Poggio, T. and Bizzi, E. (2004). Generalization in vision

and motor control. Nature, 431(7010):768–774.

Riesenhuber, M. and Poggio, T. (1999). Hierarchical mod-

els of object recognition in cortex. Nature Neuro-

science, 2(11):1019–25. PMID: 10526343.

Rohrer, B. (2007). S-Learning: a biomimetic algorithm

for learning, memory, and control in robots. In CNE

apos;07. 3rd International IEEE/EMBS Conference

on Natural Engineering, pages 148 – 151, Kohala

Coast, Hawaii.

Rohrer, B. (2009). S-learning: A model-free, case-based

algorithm for robot learning and control. In Eighth

International Conference on Case-Based Reasoning,

Seattle Washington.

Rohrer, B., Bernard, M., Morrow, J. D., Rothganger, F., and

Xavier, P. (2009). Model-free learning and control in

a mobile robot. In Fifth International Conference on

Natural Computation, Tianjin, China.

Rohrer, B. and Hulet, S. (2006a). BECCA - a brain emu-

lating cognition and control architecture. Technical

report, Cybernetic Systems Integration Department,

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

Univeristy of Sandria National Laboratories, Alber-

querque, NM, USA.

Rohrer, B. and Hulet, S. (2006b). A learning and control

approach based on the human neuromotor system. In

Proceedings of Biomedical Robotics and Biomecha-

tronics, BioRob.

Schaal, S., Ijspeert, A., and Billard, A. (2003). Com-

putational approaches to motor learning by imita-

tion. Philosophical Transactions of the Royal So-

ciety B: Biological Sciences, 358(1431):537–547.

PMC1693137.

Simon, H. A. (1969). The Sciences of the Artiﬁcial. MIT

Press, Cambridge, Massachusetts.

Wolpert, D. M. (2003). A unifying computational frame-

work for motor control and social interaction. Phil.

Trans. R. Soc. Lond., B(358):593–602.

Wolpert, D. M. and Flanagan, J. R. (2001). Motor predic-

tion. Current Biology: CB, 11(18):729–732.

Wolpert, D. M. and Ghahramani, Z. (2000). Computational

principles of movement neuroscience. Nature Neuro-

science, 3:1212–1217.

Ziv, J. and Lempel, A. (1978). Compression of individ-

ual sequences via variable-rate coding. IEEE Trans-

actions on Information Theory, 24(5):530–536.

MODEL-FREE LEARNING FROM DEMONSTRATION
