A PROCESS FOR COTS-SELECTION AND MISMATCHES

HANDLING

A Goal-driven Approach

Sodany Kiv, Yves Wautelet and Manuel Kolp

Info. Syst. Research Unit (ISYS), University of Louvain, Belgium

Keywords:

Requirements engineering, COTS-based software development, i*, NFR, Multi-agent system.

Abstract:

Organizations facing the difﬁculties and costs associated with the development of their information systems

from scratch turn to use commercial off-the-shelf (COTS) products to build their systems. A crucial factor in

the success of such project is to perform a good COTS decision-making process, a process that aims at deﬁning

the organizations’ requirements, evaluating existing products and selecting the one that best ﬁts requirements.

However, even the best-ﬁtting product would not perfectly match requirements, this is referred to as COTS

mismatches. These mismatches occur as a result of an excess or shortage of COTS capabilities. Many of these

mismatches are resolved after the COTS selection. This paper presents a goal-driven agent-oriented approach

for proceeding the COTS decision-making and analysing mismatches during and after the COTS selection.

The methodology is overviewed and illustrated on a case study.

1 INTRODUCTION

Nowadays software developments become huger

while development budgets tend to be lower in cri-

sis times. To deal with such an environment, COTS-

based software development is an interesting area.

With such an approach, no need to develop the soft-

ware from scratch but rather to customize an exist-

ing solution. There are several deﬁnitions of COTS

(Ayala, 2008). In this paper, we refer to generic soft-

ware products that are developed by a third party for

clients. Due to the commercial potential of software

reuse, the known similarities between the businesses

and the open source movement; software packages at

disposal tend to be larger so that consumers can seek

products meeting their requirements in a broader area.

The development of COTS-based systems mainly

depends on performance of the COTS selection pro-

cess. This process consists of deﬁning the organi-

zations’ requirements, evaluating existing products

and selecting the one that best ﬁts the requirements.

Several approaches have been proposed to model

the COTS selection processes (see (Ayala, 2008)).

These approaches emphasize the importance of re-

quirements analysis in order to conduct a successful

selection. In this paper, we aim to take the beneﬁt

of goal-driven requirements engineering and agent-

orientation for modelling complex systems to im-

prove COTS-based software development. We pro-

pose a goal-driven agent-oriented methodology for

COTS selection as well as analysing mismatches be-

tween COTS components and stakeholders’ require-

ments during and after selection.

Section 2 overviews the problem and positions the

paper while Section 3 explains the methodology itself.

Section 4 illustrates the methodology application on a

case study and Section 5 ﬁnally concludes the paper.

2 PROBLEM STATEMENT

This section introduces COTS-based software devel-

opment and the advantage of adopting agent-oriented

modeling and design into COTS-based developments.

It positions the paper and brieﬂy overviews related

work.

2.1 COTS-based Software Development

COTS-based software development (CBSD) is based

on the idea of building new systems using COTS

products, rather than developing systems from

scratch. It has become a strategic ﬁeld for building

large-scale and complex systems due to its potential

beneﬁts that are mainly its reduced costs and shorter

Kiv S., Wautelet Y. and Kolp M. (2010).

A PROCESS FOR COTS-SELECTION AND MISMATCHES HANDLING - A Goal-driven Approach.

In Proceedings of the 2nd International Conference on Agents and Artiﬁcial Intelligence - Artiﬁcial Intelligence, pages 98-106

DOI: 10.5220/0002732700980106

 SciTePress

development time, while maintaining quality. Ac-

cording to (Vigder et al., 1996), there are different

ways of using off-the-shelf software. This paper deals

with the buy-and-adapt approach. It is characterized

by acquiring a single (or very few) complete working

system(s) that satisﬁes most of the stakeholders’ re-

quirements and adapting and extending it to support

organizations’ goals.

The CBSD approach has raised a tremendous

amount of interests both in the research community

and in the software industry. Following (Brown and

Wallnau, 1998; Pour, 1999), the main advantages of

the CBSD approach are:

• better management of the application complexity;

• decrease of the development cost and time;

• increased ﬂexibility;

• increased quality (mature solutions from which

correctness has been established in earlier

projects).

Although the CBSD promises signiﬁcant beneﬁts,

there are some technical problems that limit their use.

Among those problems, we ﬁnd:

• how the business requirements must be captured

and reﬁned, based on a process that leads to the

development of a COTS-based system;

• how the different COTS products must be put to-

gether and deployed using the latest technologies;

• how to select the COTS products that are the clos-

est to the developers’ needs;

• how to handle the mismatches between the COTS

capabilities and the system requirements.

The methodology proposed in this paper partially

addresses these issues.

2.2 An Agent Approach for CBSD

The paper introduces a requirements-driven method-

ology for COTS-based software development using

the agent paradigm at analysis and design stages.

The factor that really makes agent-oriented soft-

ware engineering distinct from any other software

engineering paradigm is the higher level of abstrac-

tion employed in the development of software sys-

tems. The idea of modelling a system in terms of

autonomous entities with characteristics similar to hu-

mans introduces a close-to-real-life modelling of the

system, and therefore makes the development of the

software system natural. Moreover, an agent is a goal-

driven entity with autonomy and self-control of capa-

bilities (Jennings and Wooldridge, 1999). Thus, goal-

oriented analysis has been used in agent-oriented re-

quirements engineering.

In what sense can our approach be considered as

agent-oriented?

• At analysis stage. The i* (i-star) framework (Yu,

1995), which directly introduces organizational

and social concepts - proper to an agent ontology

- into software modelling is used. This choice has

been made to better match the representation of

the organization the software system has to be de-

veloped in.

• At design stage. On the basis of the analysis dia-

grams, a MAS is designed. This is architecturally

made of a set of agents owning a series of capabil-

ities that the COTS components have to execute

for goal realization. This architecture furnishes

designers and developers scenarios that should be

included into the software application using dele-

gation to software components. The whole system

is adaptive and follows a non-monotonic logic;

the component selected by an agent to perform a

given capability at one time will evolve with con-

textual changes within the software system. This

ensures independence between requirements and

available COTS source code.

2.3 Paper Position

(Alves and Finkelstein, 2003) distinguishes, when

studying a COTS component functional aspects, two

main levels of agregation: goal and subgoal on the

one side and feature on the other. Goals are, in that

paper, based on the deﬁnition found in KAOS (Lam-

sweerde, 2001) and features are deﬁned in the paper

as a set of features implemented by the COTS product.

Our approach is to deﬁne two processes in paral-

lel. On the one side we proceed with a classical RE

approach using i* (i-star) models with the i* goals re-

ﬁned in a set of agent capabilities (see 3.2.1). On the

other side COTS components are analyzed in a set of

goals, subgoals and features as deﬁned in (Alves and

Finkelstein, 2003). i* goals can then be directly com-

pared to COTS goals and subgoals and agent capabil-

ities can be compared to agent capabilities for han-

dling the differencies between the expected and the

furnished (called mismatches) on a two level basis.

Elements of the different diagrams however need

further deﬁnition to be compared. Indeed, the weak-

nesses of the elements deﬁned in i* models are iden-

tiﬁed in (Estrada et al., 2006) and particularily con-

cerns the goal deﬁnition. In the models developed

here we rely on the deﬁnition of (Wautelet, 2008) for

modeling goals. This deﬁnition is in accordance with

the one of (Lamsweerde, 2001) used in (Alves and

Finkelstein, 2003). In the same way the conceptual

A PROCESS FOR COTS-SELECTION AND MISMATCHES HANDLING - A Goal-driven Approach

model of agent capabilities in 3.2.1 has been deﬁned

for being in accordance with the (Alves and Finkel-

stein, 2003) feature deﬁnition.

Following (C. Abts and Clark, 2000; Boehm et al.,

2003), CBSD includes ﬁve phases:

• requirement engineering (RE);

• COTS evaluation and selection;

• COTS mismatches handling;

• COTS integration and system evolution.

This paper proposes a framework that covers the

four ﬁrst steps depicted above. Indeed, it uses the

i* (i-star) (Yu, 1995; Yu, 1997) framework for RE.

i* goals are then further studied using an NFR goal

graph (Chung et al., 2000) for being compared to the

COTS goals in order to evaluate and select COTS

components (macro-level for COTS study). Then an

agent design model allows to distinguish the lower

level functionalities (called capabilities) that should

be fulﬁlled by the component’s features. This part

concerns handling mismatches after a component

has been selected (micro-level study). The integration

of methods for COTS integration and system evolu-

tion is left for future work. This process is depicted

in detail in the rest of this paper.

3 THE METHODOLOGY

The methodology for COTS-based software develop-

ment presented in this paper proposes a two level (mi-

cro and macro) analysis and design framework. First

of all, a classical RE using i* diagrams and the NFR

goal graph is performed for COTS selection (macro-

level approach). Then a MAS design allows to de-

termine at lowest level (in the form of agent capabil-

ities) the functions that must be fulﬁlled by the com-

ponent to handle mismatches (micro-level). Those are

overviewed in this section.

3.1 Macro-level Approach: COTS

Selection

Our framework is proposed to facilitate a systematic,

repeatable and requirements-driven COTS selection

process. Figure 1 represents the different steps re-

quired to fulfull the analysis. Those steps are in accor-

dance with the deﬁnition of a SPEM WorkDeﬁnition

(see (OMG, 2005)).

• Analysing organizational environment. This in-

volves analysing the organization where the sys-

tem will operate. The output of this activity is an

Figure 1: Overview of our COTS selection process.

organisational model, which includes relevant ac-

tors who can be human or software, their goals

to pursue, and their respective dependencies. We

propose to use the i* organizational modelling

framework (Yu, 1995).

• Searching for COTS products. This involves

searching for required software in the market-

place. The output of this work is the information

about the available COTS products in accordance

with requirements.

• Formalizing goals. This consists of making

a goal graph with the help of the i* model

where tasks are depicted as operational goals and

non-functional requirements are analysed using

the NFR framework proposed in (Chung et al.,

2000).For prioritizing goal, we associate each

goal with a degree of desirability:

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

100

– Very high: Very critical goal that must be ful-

ﬁlled otherwise the success of the project will

be strongly compromised.

– High: Critical goal that must be fulﬁlled other-

wise the success of the project will be compro-

mised.

– Medium: Important goal that should be fulﬁlled

in order to ensure that signiﬁcant goals will be

satisﬁed.

– Low: Desirable goal that could be interesting to

have but that does not affect the success of the

system.

– Very low: Slightly desirable goal that does not

affect the success of the system.

This allows to distinguish the key features that

should be taken into account when proceeding

COTS evaluation and selection. This work should

be done in parallel with the searching for COTS

products in the marketplace.

• Filtering search results. This involves eliminat-

ing the COTS products according to a short-list

criteria and those that do not provide any possibil-

ities to fulﬁl the must-have goals, and acquiring

more information on the short-listed candidates.

The following is an example of short-listing crite-

ria:

– Vendor size. Is the vendor too big to pay atten-

tion to us? Or is the vendor too small to survive

and provide consistent service?

– Domain knowledge. What are the target domain

and market of the vendor? Do they correspond

with the company’s needs?

– Consultant service. Does the vendor pro-

vide consulting services? Does the vendor co-

operate with the consultant companies?

– Vendor’s reputation and ﬁnancial position.

Does the vendor have a good or bad reputation?

Does the vendor have a good ﬁnancial situation

or show any sign of potential ﬁnancial crisis?

– Technology. Is the technology used ﬂexible and

long lasting?

– Price of software. Is the price of the software

acceptable?

• Evaluating the pre-selected COTS products. In-

stead of evaluating products based on detailed

and ﬁxed selection criteria like those proposed

by other selection methods (Ncube and Maiden,

1999; Kontio, 1995).It consists of matching the

pre-selected COTS products’ features with the

goals modelled in the goal graph. When a COTS

product does not perfectly meet a speciﬁc goal as

a result of an excess or shortage of COTS capabil-

ities, the decision makers need to decide how to

handle it. The decision is made according to the

type of mismatch. Based on the literature review,

we deﬁne several types of mismatches as well as

the recommended resolutions which can be used

to support the decision-making depicted in Figure

2.If the resolution involves adjusting the require-

ments, the goal graph will be modiﬁed.The mis-

match is handled during the COTS selection pro-

cess. Otherwise, if it involves tailoring the prod-

uct, the mismatch will be analysed in order to de-

ﬁne its possible actions and make an approximate

estimation of its complexity and risk. The mis-

match will be further analysed and resolved after

the COTS selection. In this way features might

inﬂuence the reﬁnement of goals which leads to a

very interactive and collaborative process. More-

over, the complexity of mismatches handling after

the COTS selection will also be taken into consid-

eration for the COTS decision-making.

Figure 2: Mismatch resolution.

– Fulﬁl conditional mismatch. When there is a

constraint that has to be accomplished in order

to fully fulﬁl the initial goal.

– Fail mismatch. When a goal cannot be satisﬁed

by the evaluated COTS.

– Extend mismatch. When the evaluated COTS

has features that are not requested by the stake-

holders. The Extend mismatch can be:

∗ Hurtful - when an extra feature has a negative

impact over a particular goal.

∗ Neutral - when an extra feature does not inter-

fere with the achievement of any goal nor the

stakeholder want it.

∗ Helpful - when an extra feature is useful and

can be included in the system requirements.

– Differ mismatch. When the evaluated COTS

partially satisﬁes all the constraints imposed by

the goal. There are three different levels of Dif-

A PROCESS FOR COTS-SELECTION AND MISMATCHES HANDLING - A Goal-driven Approach

101

fer mismatch: GUI, parameter, and process lev-

els.

We also propose a template illustrating in Figure

3 for documenting the mismatches of each COTS

product that will use as a part of the decision-

making support.

Figure 3: Mismatch documentation template.

• Making decision. It involves making the decision

on the COTS selection as well as the action plan to

handle the mismatches based on the COTS evalu-

ation result. The result of the evaluation is a tech-

nical factor for making the decision. However,

this decision is also based on the economic aspect.

3.2 Micro-Level Approach: Mismatches

Handling

In this section we depict the micro-level. At this

level we design an agent model as a set of capabili-

ties which can be directly compared to COTS features

as deﬁned in (Alves and Finkelstein, 2003).

Goals identiﬁed at previous stage are mapped into

a series Agent Capabilities which are a set of atomic

functions that must be fulﬁlled by the COTS com-

ponent. The sequence of agent capabilties resolves

a speciﬁc goal.

3.2.1 Agent Capabilites: A Conceptual Model

In this section, we will bring the agent capabilites

model to further formalization. Figure 4 depicts

the relevant concepts and their dependencies using a

UML class diagram notation. The model is structured

as follows: the agent pursues a series of intentions

modeled as goals and are then resolved through a se-

ries of capabilities in the form of a realization path.

When developing the agent concepts into a UML se-

quence diagram, capabilities are mapped in the form

of messages, agents are represented through classes

and realization paths implemented by the sequence

diagram success scenarios.

Deﬁnition 1. A tuple h{(cp

, q

), . . . ,

(cp

i+m

, q

i+m

)}, Ag

i is called an agent a, where cp

is a capability. The agent advertises its capability

to participate to a goal realization with deﬁned

QoS level and cost q

. The advertised level is a

vector of QoS- and cost-property and value pairs

Figure 4: A capabilities meta-model.

following a QoS ontology. Ag

is assumed to contain

all additional properties of the agent irrelevant for

the present discussion, yet necessary when building a

MAS.

Format and content of Ag

will depend on the pro-

gramming language being used. A Capability is part

of a Goal realization.

Deﬁnition 2. A capability cp

is hcp

pre

, τ

, cp

post

where cp

pre

describes the capability precondition, τ

is a speciﬁcation (in some language) of how the agent

is to execute the capability, and cp

post

describes the

conditions true after the capability is executed. Ca-

pabilities belong to the set CP.

Deﬁnition 3. hr p

, rp

, rpTransit

, rpState

is a realization path rp

, where rp

provides the de-

tails of the functional speciﬁcation of the realized

goal, (r p

, rp

) deﬁnes a sequence diagram where

represents the series of capabilites required to

realize a goal and r p

the agents performing them.

The two functions label swimlanes and messages with

capability information: rpTransit

: r p

7−→ CP is

a partial function returning the capability for a given

message in the sequence diagram, while rpState

7−→ {cp

pre

}

∈CP

∪ {cp

post

}

∈CP

maps each

message to a condition from the set of all capability

preconditions (i.e., {cp

pre

}

∈CP

) and postconditions

(i.e., {cp

post

}

∈CP

). The capability speciﬁed on a

message must have the precondition and postcondi-

tion corresponding to conditions given, respectively,

on its origin and its destination swimlane.

Capabilities can thus be understood as a functional

decomposition of a goal with the realization path as a

success scenario. The functional speciﬁcation of the

capability, rp

, is not of interest here but depends of

the programming language and other implementation

considerations.

By conceptualizing the realization path as sug-

gested in Def.3, the service is thus mapped onto a se-

quence diagram SeQ where each swimlane is a step

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

102

in goal realization and a message in SeQ corresponds

to the execution of a capability cp

by an agent a

k,u

where u ranges over agents that can execute cp

ac-

cording to the criteria set in the goal. Each path from

the starting agent (e.g., agent Agent

in Figure 3) to

the ending agent (also agent Agent

in Figure 3) thus

corresponds to a sequence of capabilities ensuring the

completion of the goal within the prescribed QoS. A

realization path could be hcp

, cp

k+1

, ..., cp

k+n

i. The

model thus assumes that there are alternative ways for

completing the goal. The topology of the sequence

diagram—i.e., the agent structure and the capabili-

ties associated to messages between the agents—is

provided by the designer through the goal deﬁnition,

so that the sequence diagram is a graphical model of

the different ways the goal can be performed as a se-

quence of capabilities.

3.2.2 The Process

An overview of the process for analysing the mis-

matches that require the COTS customization to be

resolved is depicted in Figure 5. It consists of the fol-

lowing activities:

• Deﬁning realization path. For each mismatch that

will be handled by COTS customization, we de-

ﬁne the realization path of the unsatisﬁed goal. A

realization path is a set of functions (called capa-

bilities) the agent should answer to for realizing a

goal. We use the UML sequence diagram to repre-

sent the realization path. The agents’ capabilities

are then listed in a table with a name, informal

deﬁnition and the name of the agent the capability

belongs to. The set of capabilities constitutes an

abstraction level between the organizational anal-

ysis and the technology in which the COTS is im-

plemented.

• Deﬁning resolution. Based on the realization path

and the documentation of the selected COTS fea-

tures, we deﬁne the causes of mismatches and res-

olutions to handle them. Resolution are envisaged

on a case by case basis.

4 CASE STUDY

This section overviews the application of the pro-

posed methodology onto a case study issued of supply

chain management and more particularly outbound

logistics. In this case study, we consider COTS as a

third party component used to build the global system.

We overview the different third party components that

have to be introduced into the global system, brieﬂy

Figure 5: Overview of our mismatches analysis process.

describe the SRD and ﬁnally focus on the adoption of

a COTS for the Transportation Management System

(TMS).

4.1 Outbound Logistics

Outbound logistics is the process related to the move-

ment and storage of products from the end of the pro-

duction line to the end user. In the context of this pa-

per we mostly focus on transportation. The actors of

the supply chain play different roles in the outbound

logistic ﬂow. The producer will be a logistic client in

its relationship with the raw material supplier, which

will be considered as the shipper. The carrier will re-

ceive transportation orders from the shipper and will

deliver goods to the client, while relying on the infras-

tructure holder and manager. In its relation with the

intermediary wholesaler, the producer will then play

the role of the shipper and the wholesaler will be the

client.

Supplier

Shipper

Producer

Client

Shipper

Wholesaler

Client

Shipper

Final client

Client

Carrier

Scheduler

Strategic planner

Infrastructure manager

Operational planner

Strategic planner

Logistic

request

Transport

Coordination

Order

Figure 6: Material ﬂows in the outbound logistics chain.

Figure 6 summarizes the material ﬂows between

the actors of the outbound logistics chain. The idea

underlying the software development is to favour

these actors’ collaboration. Indeed, collaborative de-

cision will tend to avoid local equilibriums (at ac-

tor level) and wastes in the global supply chain op-

A PROCESS FOR COTS-SELECTION AND MISMATCHES HANDLING - A Goal-driven Approach

103

timisation, giving opportunities to achieve the great-

est value that the chain can deliver at lowest cost (see

(Pache and Spalanzani, 2007)). More information on

the applicative package development can be found in

(Wautelet et al., 2009).

4.2 Third Party Components

Third party components that can fulﬁl an amount of

the identiﬁed requirements in the context of the de-

velopment of the collaborative system e are the fol-

lowing:

• The Fleet Management System (FMS);

• The Warehouse Management System (WMS);

• The Enterprise Resource Planning (ERP);

• The Transportation Management Systems

(TMS) is computer software designed to manage

transportation operations. It aids in determining

the most efﬁcient and most cost-effective way to

execute the movement of product(s).

4.3 Methodology Application

This section presents the application of the proposed

methodology for the selection of the Transportation

Management System for the development of a (much

larger) collaborative software system. First of all,

the i* diagrams allow enlightening the organization’s

environment and the (functional) goals depending of

the third party software, and a goal graph is drawn

to analyse both functional and non-functional ex-

pected requirements. A capability table documents

the atomic functions that should be included into the

application.

4.3.1 Macro-Level: Analysis Mismatches

• Analysing organizational environment

Figure 7 documents the i* diagrams issued of the

organizational modelling and requirements engi-

neering of the case study. The strategic depen-

dency diagram depicts the relevant actors and

their respective dependencies. Those dependen-

cies are further analysed. The result of the anal-

ysis is depicted in the strategic rationale diagram.

It provides a more detailed level of modelling by

looking inside actors. Each outbound logistic ac-

tor depicted above (as well as the ﬁnal client) and

the third party component we want to integrate in

the global system are all represented as an actor.

• Formalizing goal graph

The goal graph of Figure 8 represents both

the functional and non-functional aspects that

Figure 7: The i* diagrams.

the TMS should fulﬁl. Non-functional require-

ments includes Global Optimization (of the sup-

ply chain), Collaboration, Flexibility and Secu-

rity. After posing these non-functional require-

ments as goals to satisfy, we tend to reﬁne them

into sub-goals through AND and OR decomposi-

tions and with the help of SRD. The goals that

the component should reply to are depicted in

the SRD are represented as operationalzing goals.

The interdependencies among the goals are also

studied as shown in Figure 8. The desirability of

different goals are illustrated in Figure 9.

• Selecting COTS product

Searching COTS products in the marketplace and

acquiring their documentations are not the focus of

this paper. For illustration in this case study, we

suppose that a COTS product is selected after short-

listing the available products and evaluating the pre-

selected products. Figure 10 depicted the mismatches

of the selected COTS and their resolutions. Mis-

matches that will be handled by tailoring the COTS

product will be further analysed in the next stage. Due

to the lack of space we will only focus on the one mis-

match case, Transport load and route optimization.

4.3.2 Micro-Level: Design Mismatches

• Deﬁning realization path

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

104

Figure 8: The goal graph.

Based on the SRD and goal graph, we now can de-

ﬁne the realization path for the Transport load and

route optimization goal. On the goal graph of Figure

8, we can notice Selecting most adequate transport

is the mean to realize the Transport load and route

optimization goal. Figure 11 presents the sequence

diagram documenting the evoked goal’s success sce-

nario. Figure 12 depicts the capabilities list required

to fulﬁl this goal as well as the involved agents.

• Deﬁning resolution

At the lecture of the table, the reader will notice

that the capabilities EvaluateLogisticRequest and Se-

lectAlternativeRoute are the only ones, involved in the

Select most adequate transport goal that are not ful-

ﬁlled through a message already implemented into the

component. For the other capabilities, existing meth-

Figure 9: The goal desirability.

Figure 10: Mismatches documentation of the selected

COTS.

: Shipper: Shipper

Logistic_request

: Carrier: Carrier

: Service: Service

: Shipment: Shipment

1: createLogisticRequest( )

2: evaluateLogisticRequest( )

3: selectAlternativeRoute( )

5: DefineShipmentDate( )

6: notifyChipmentDate( )

4: recordServicesRequired( )

Figure 11: The resolution path of Select Most Adequate

Transport goal.

ods do already provide the same functional behaviour

and can be used as such or - if required - overloaded.

Consequently, the two evoked capabilities have to be

developed for adequate inclusion into the software

component so that it can achieve the documented suc-

cess scenario. The implementation of this inclusion

is not in scope of this paper since it is envisaged on a

case by case basis.

5 CONCLUSIONS

COTS-based software development constitutes a

promising area particularly in today’s crisis times

A PROCESS FOR COTS-SELECTION AND MISMATCHES HANDLING - A Goal-driven Approach

105

Figure 12: Capabilities required to fulﬁl the Select Most

Adequate Transport goal.

where costs have to be reduced as much as possi-

ble. COTS can nevertheless seldom be used as such

into an organization or into a larger software project.

Thus, those software are often conceived in a ﬂexible

way that they can be tailored to a speciﬁc project.

As a contribution to COTS-based software de-

velopment, this paper presents a goal-driven agent-

oriented methodology for proceeding COTS selection

process and mismatch analysis during and after COTS

selection. It is part of the effort for better integrating

requirements into COTS-based software development

and analysing mismatches.

Further work notably includes extendent the

framework for COTS physical integration into the or-

ganization (deployment phase) and system evolution.

REFERENCES

Alves, C. and Finkelstein, A. (2003). Investigating con-

ﬂicts in cots decision-making. International Journal

of Software Engineering and Knowledge Engineering,

13(5):473–493.

Ayala, C. (2008). Systematic construction of goal-oriented

cots taxonomies. PhD Thesis.

Boehm, B. W., Port, D., Yang, Y., and Bhuta, J. (2003).

Not all cbs are created equally: Cots-intensive project

types. H. Erdogmus and T. Weng (Eds.): ICCBSS

2003, LNCS 2580, pages 36–50.

Brown, A. W. and Wallnau, K. C. (1998). The current state

of component-based software engineering. IEEE soft-

ware, pages 37–46.

C. Abts, B. W. B. and Clark, E. B. (2000). Cocots: a cots

software integration cost model: model overview and

preliminary data ﬁndings. The 11th ESCOM Confer-

ence, Munich, Geremany, pages 325–333.

Chung, L., Nixon, B., Yu, E., and Mylopoulos, J. (2000).

Non-functional requirements in software engineering.

Kluwer Academic Publishers.

Estrada, H., Rebollar, A., Pastor, O., and Mylopoulos, J.

(2006). An empirical evaluation of the i* framework

in a model-based software generation environment.

Proceedings of CAiSE, pages 513–527.

Jennings, N. R. and Wooldridge, M. (1999). Agent-oriented

software engineering. In Proceedings of the 9th Euro-

pean Workshop on Modelling Autonomous Agents in a

Multi-Agent World : Multi Agent System Engineering

(MAAMAW-99).

Kontio, J. (1995). A cots selection method and experiences

of its use. Proceedings of the 2Oth annual software

engineering workshop, Maryland.

Lamsweerde, A. V. (2001). Goal-oriented requirements en-

gineering: A guided tour. International Symp. On

Requirements Engineering (RE01).Toronto, Canada.,

pages 249–263.

Ncube, C. and Maiden, N. (1999). Pore: Procurement-

oriented requirements engineering method for the

component-based system engineering development

paradigm. in International Workshop on Component-

Based Software Engineering, Los Angeles, USA.

OMG (2005). Extending i* and tropos to model security.

The Software Process Engineering Metamodel Speci-

ﬁcation. Version 1.1.

Pache, G. and Spalanzani, A. (2007). La gestion des chanes

logistiques multi-acteurs : perspectives stratgiques.

Presses Universitaires de Grenoble (PUG).

Pour, G. (1999). Enterprise javabeans, javabeans & xml ex-

panding the possibilities for web-based enterprise ap-

plication development. Proceedings of Technology of

Object-Oriented Languages and Systems,TOOLS 31,

pages 282–291.

Vigder, M. R., Gentleman, W. M., and Dean, J. (1996). Cots

software integration: State of the art. National Re-

search Council Canada (NRC), 39198.

Wautelet, Y. (2008). A goal-driven project manage-

ment framework for multi-agent software develop-

ment: The case of i-tropos. PhD thesis, Universit

catholique de Louvain, Louvain School of Manage-

ment (LSM), Louvain-La-Neuve, Belgium, August.

Wautelet, Y., Achbany, Y., Lange, J.-C., and Kolp, M.

(2009). A process for developing adaptable and open

service systems: Application in supply chain manage-

ment. In proceedings of the 11th International Con-

ference on Enterprise Information Systems (ICEIS09),

LNBIP, pages 564–576.

Yu, E. (1995). Modeling strategic relationships for process

reengineering. PhD thesis, University of Toronto, De-

partment of Computer Science, Canada.

Yu, E. (1997). Towards modeling and reasoning support for

early-phase requirements engineering. RE ’97: Pro-

ceedings of the 3rd IEEE International Symposium on

Requirements Engineering, page 226.

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

106
