PER-REQUEST CONTRACTS FOR WEB SERVICES

TRANSACTIONS

David Paul, Frans Henskens and Michael Hannaford

Distributed Computing Research Group, School of Electrical Engineering and Computer Science

University of Newcastle, Callaghan NSW, Australia

Keywords:

ACID reduction, Semantic atomicity, Tentative hold.

Abstract:

To allow providers to keep their autonomy and ensure the overall system can run satisfactorily, it is common

practice in the Web Services environment for providers to reduce the strength of some of the traditionally-

required ACID properties when offering transactional support. However, current standards require providers

to offer a constant level of transactional support for each operation they provide. We describe a method that

allows service providers to dynamically decide on the level of transactional support to offer for each client

request. This allows the provider to base the level of transactional support offered on the current state of the

system and internal logic, resulting in potential beneﬁts for both service providers and consumers.

1 INTRODUCTION

Web Services transactions combine services provided

by multiple, possibly completely unrelated parties

into a single action. While these transactions are

loosely based on the techniques used in conventional

databases, strictly enforcing ACID properties in the

Web Services environment is often impractical. Thus,

it is typical to reduce the strength of some of the tra-

ditional transaction properties when combining multi-

ple service calls into a transaction-like workﬂow. The

currently supported reductions are static; they must be

decided before the transaction begins, and all parties

must provide the same level of support, even if some

would be willing to support stronger versions of the

properties. This paper presents some concepts and

evaluation leading to the development of a protocol

that allows the dynamic speciﬁcation of the strength

of various ACID properties for Web Services transac-

tions.

The ACID properties of Atomicity, Consistency,

Isolation, and Durability are well understood in tra-

ditional databases (Gray and Reuter, 1993). How-

ever, these are typically single systems, where a trans-

action coordinator has complete control over every

aspect of the system. In the Web Services environ-

ment, transactions involve multiple autonomous enti-

ties working together, and very few are willing to give

up the autonomy that ensuring the full ACID proper-

ties would require. Further, as Web Services transac-

tions can run for long periods of time (perhaps days

or weeks), complete support for the ACID properties

can severely negatively affect the performance of both

individual systems and the system as a whole.

Current techniques (e.g. (Ceponkus et al., 2002;

Cox et al., 2004; Bunting et al., 2003)) reduce these

problems by relaxing some of the ACID properties.

However each entity in the transaction must provide

the same level of transactional support. We believe

that allowing different entities to dynamically provide

different reductions to the ACID properties will im-

prove support for transaction-like workﬂows in the

Web Services environment. In our model, different

providers in a transaction can choose the level of

support for transactions that they desire. The client

can then combine actions with different transactional

guarantees into a cohesive whole that takes full ad-

vantage of the transactional support offered by each

service. A simulator has been created to evaluate such

a system.

Using this simulator it is possible to test how

different reductions to the ACID properties work in

different situations. The model can also facilitate

changes to parameters such as the network topology,

failure rates of particular services, or the number and

length of transactions being run in such a way that al-

lows repeatable testing with changes only to the trans-

actional properties being used. The simulator will

Paul D., Henskens F. and Hannaford M.

PER-REQUEST CONTRACTS FOR WEB SERVICES TRANSACTIONS.

DOI: 10.5220/0002801800810088

In Proceedings of the 6th International Conference on Web Information Systems and Technology (WEBIST 2010), page

ISBN: 978-989-674-025-2

also be used to develop and test a dynamic protocol

that allows the strength of the various ACID proper-

ties supported to be negotiated during run-time.

This paper is organised as follows: Section 2

gives background information about transactions in

the Web Services environment, and points out useful

research for the study discussed in this paper. Sec-

tion 3 then describes a motivating scenario to demon-

strate the usefulness of per-request contracts between

clients and service providers. This scenario is exam-

ined in Section 4, and the results discussed in Section

5. Finally Section 6 concludes the paper and indicates

future directions.

2 BACKGROUND AND RELATED

WORK

There are two approaches to the speciﬁcation of Web

Services transactions. The ﬁrst, used in protocols

such as the Transaction Internet Protocol (Lyon et al.,

1998), is to attempt to move traditional transactions

to the Web Services environment. The second is to

redeﬁne the concept of a transaction. Rather than

specifying that the ACID properties must all be met,

protocols such as BTP (Ceponkus et al., 2002), WS-

Transaction (Cabrera et al., 2005; Cox et al., 2004)

and WS-CAF (Bunting et al., 2003) reduce some of

the ACID properties to allow transaction-like work-

ﬂows that are better suited to the Web Services envi-

ronment.

The Transaction Internet Protocol (Lyon et al.,

1998) is based on the concept of two-phase-commit,

which has a transaction coordinator that ﬁrst asks

each participant in the transaction to guarantee that

it can perform the requested action. Each participant

then sends a response to the coordinator specifying

whether or not they will give that guarantee. If each

participant does agree, then the coordinator sends a

conﬁrmation message to each of them; the partici-

pants have all guaranteed that the actions will com-

plete successfully, so the transaction will also be suc-

cessful. If one or more participants cannot give the

requested guarantee, then the coordinator must let all

participants know that the transaction has failed.

Once a participant has guaranteed that resources

are available, it must ensure that these resources are

reserved until the coordinator sends its second mes-

sage. This can take an indeterminate amount of time,

and possibly even forever if there is a break in a com-

munication link. During this time, the participant

must keep the requested resources available for the

client, which can negatively affect other client inter-

actions with that system.

Each service provider in the Web Services envi-

ronment is autonomous, so they are typically not will-

ing to give up the control necessary to support full

ACID transactions through a two-phase commit pro-

tocol. Instead they typically offer a reduced level

of transaction support. The most common reduc-

tion for Web Services transactions is to replace the

ACID property of atomicity with semantic atomic-

ity (Garcia-Molina, 1983). Semantic atomicity allows

any requested action to be completed immediately (if

possible), and, if the transaction has to roll back, a

compensating action is performed to undo the already

completed action.

Semantic atomicity typically removes the property

of isolation from Web Services transactions, which

can result in the overall system behaving in an unde-

sirable manner. For example, a request may be denied

because a currently running transaction has already

been allocated the requested resource. If that trans-

action later fails and the compensating action returns

the resource, then, in retrospect, the denied request

could have been approved. While there are techniques

that allow full support of isolation (Alrifai et al., 2006;

Choi et al., 2005), this support necessarily affects how

well services can perform.

There are different techniques that attempt to re-

duce the problems involved with ignoring global iso-

lation while still providing an acceptable level of ser-

vice. One such method is the Tentative Hold Proto-

col (Roberts and Srinivasan, 2001), which replaces

the exclusive locks required by other techniques with

non-exclusive ones. In this protocol, a client requests

some resources from a provider, and the provider

sends a reply that informs the client whether the re-

quested resources are currently available. If the re-

sources are available then the client can continue, as-

suming that the resources will be available when they

are ready to commit. If ever the situation changes, and

the requested resources become unavailable, then the

service provider can notify the client and the transac-

tion can be cancelled.

It is also possible to combine multiple reductions

of transactional properties to allow the beneﬁts of

each technique to be used. For example, (Limthan-

maphon and Zhang, 2004) allows support of both ten-

tative holds and, through the use of compensating ac-

tions, semantic atomicity. (Fauvet et al., 2005) also

includes two-phase commit. These combinations are

useful, but the proposals only allow the use of the re-

ductions explicitly built into them; service providers

are forced into supporting a subset of the allowed re-

ductions, which may not include the level of support

they wish to provide.

While most standards specify support for only

WEBIST 2010 - 6th International Conference on Web Information Systems and Technologies

certain transaction-like behaviours and reductions,

there has been some work into offering more gen-

eral support. For example, transactional attitudes

(Mikalsen et al., 2002) allow providers to specify their

transaction-like behaviour using an extension to their

WSDL service descriptions. This allows the provider

to explicitly describe how its actions can be used in a

transaction, and allows for the combination of multi-

ple different levels of transaction support, using mid-

dleware to hide the transactional complexities this re-

quires from the client. However, providers are re-

stricted to offering only one level of transaction sup-

port for each published service; it is impossible for

the provider to change the level of support from one

request to another.

This project believes that there is a number of pos-

sible reductions to the ACID properties that result in

a useful transaction-like workﬂow. In particular, we

believe that allowing different reductions to be used

by different providers in a single transaction can im-

prove performance of both transactions and individual

providers. Further, we believe that a provider should

be able to dynamically decide the level of transac-

tional support to provide for a particular request based

on internal logic, its current state, and the incoming

request. For the purpose of this paper, we look at ser-

vices that can be provided with either semantic atom-

icity or tentative holds, as speciﬁed in the next section.

3 EXAMPLE SCENARIO

Consider three providers offering a competing service

that clients wish to use in a transaction. This service

allows a client to order a certain number of ﬁnite re-

sources (for example, this could be a booking of a

number of hotel rooms, or an order for a number of

books). Each provider is free to choose the level of

transaction support that it wishes to make available,

and each service is identical except for the level of

transaction support being offered.

The providers choose between the following three

levels of transaction support: (It is assumed that

clients can query the level of transactional support of-

fered by a service provider at any time.)

• Support for Semantic Atomicity. A client sends a

request asking the provider for a certain number

of resources. If the provider offers these to the

client, then those resources cannot be offered to

any other client. The client can, however, later

cancel the order without penalty, in which case the

resources again become available for later clients.

• Support for Tentative Holds. A client can send a

request asking if the provider could fulﬁl a partic-

ular order. The provider sends back a message

indicating whether the requested number of re-

sources are currently available. Whilst the client

has not ﬁnalised the booking, the provider is able

to use the requested resources for other clients. If

the resources become unavailable before the client

ﬁnalises its booking, the provider lets the client

know that the hold is no longer valid. Once a

client has ﬁnalised an order, it cannot be cancelled

without penalty.

• Variable Support. The provider offers seman-

tic atomicity while resources are plentiful, but

switches to only supporting tentative holds when

the number of resources it can provide reach a cer-

tain level.

The behaviour of clients depends on the level of

transactional support offered by the providers. Some

clients will refuse to use any provider that does not

support semantic atomicity. As the service offered by

these providers is only one part of the client’s trans-

action, using a service that only offers a tentative hold

may lead to some actions in a transaction complet-

ing successfully before another action fails. To en-

sure that the client has no risk of penalty for a failed

transaction, it may be necessary for the client to undo

a booking without penalty, which is only possible if

semantic atomicity is offered.

Other clients will not care about the level of trans-

action support offered for this service. These clients

are either using the order for this service as a pivot ac-

tion (Zhang et al., 1994) (a single action in a transac-

tion such that its success or failure determines the suc-

cess or failure of the entire transaction), or are willing

to accept the risk that either this order succeeds while

their other actions fail, or that this order fails while

their other actions succeed.

Finally, some clients will prefer to use a provider

that offers semantic atomicity, but, if necessary, will

be willing to use one that only provides tentative

holds. These clients are similar to those that do not

care about the level of transaction support being of-

fered, but are only willing to risk having this booking

complete and the other actions fail if no better alter-

native exists.

In any case, each client ﬁnds a provider that of-

fers a level of transaction support that they are happy

with. If no such provider is found then the trans-

action fails with no action being taken. Otherwise,

if this provider offers semantic atomicity, the client

books the resources and then attempts the other ac-

tions in their transaction. If the other actions fail then

the client cancels the order and the transaction fails

without penalty. If the other actions succeed, then the

transaction has completed successfully.

PER-REQUEST CONTRACTS FOR WEB SERVICES TRANSACTIONS

If, on the other hand, the found provider only of-

fers a tentative hold to the client, then the client’s ac-

tion depends on the risk they are willing to take. If

the client is willing to have this service succeed with

a possibility that the other actions in the transaction

fail, then they complete this order immediately, and

then attempt the other actions. Successful comple-

tion of the other actions means a successful comple-

tion of the entire transaction. Failure of the other ac-

tions, however, means that the transaction fails and

the client cannot cancel its completed order with the

provider without a penalty.

The ﬁnal case is where the found provider offers

a tentative hold, and the client is willing to have the

other actions complete successfully while the order

for this service fails. Once the client has the ten-

tative hold on the resources, it attempts to complete

the other actions. If these fail then the client re-

leases its tentative hold and the transaction fails with-

out penalty. However, if the other actions complete

successfully then the client attempts to ﬁnalise the or-

der. As long as the tentative hold is still valid then

this will be successful, resulting in a successful trans-

action. However, it is possible for the tentative hold

to become invalid while waiting for the other actions

to complete. If this occurs, the client can attempt to

ﬁnd the resources from another provider, but if this is

impossible the transaction will fail with the other ac-

tions having been completed successfully. If the other

actions are not undoable, this will result in a partially

completed transaction, which may mean a penalty for

the client.

To ease the burden on the client, the above logic

can be moved into an abstract service (Sch

afer et al.,

2007). Each of the three competing providers is reg-

istered with the abstract service, and clients then send

their requests to this service rather than to any of the

providers individually. The abstract service then takes

the responsibility for ﬁnding an appropriate provider

for any booking or tentative hold request. In particu-

lar, in the event that the abstract service has a tentative

hold that is later cancelled, the abstract service can

attempt to ﬁnd the resources from another provider,

only informing the client of any problem if no other

provider can satisfy the request.

4 EXAMINING THE SCENARIO

In order to determine whether having providers that

dynamically change their transactional support for a

service is beneﬁcial, a software model of the situa-

tion in Section 3 has been created. This model simu-

lates the sending of messages between clients and ser-

vice providers, monitoring each message that is sent.

The clients directly interact with the three service

providers, though the logic would be similar if each

client instead utilised an abstract service for commu-

nicating with the different providers.

In the model, the transactions of 1000 clients are

generated to be started between times 1 and 100, with

the start time of each transaction chosen randomly. It

is assumed that the majority of these clients (80%)

would prefer providers that offer semantic atomic-

ity over those only offering tentative holds, with the

other 20% being equally split between those unwill-

ing to use any provider that does not offer semantic

atomicity and those who do not care about the trans-

action support offered by the providers. Given that

each provider offers an otherwise identical service, it

is fair to assume that the majority would prefer the

provider that offers a better transactional guarantee.

For the ﬁrst test, as well as their other activities,

each client wishes to order (randomly) between 1 and

10 resources from one of the three providers. The

second test is identical except half of the clients wish

to order a large number of resources (50). When a

client needs to choose which provider to use, it ran-

domly chooses between any of the providers that of-

fer the required resources with the requested transac-

tional guarantee.

Of the clients willing to risk having a partially

completed transaction (that is, all except those who

insist on semantic atomicity), half are assumed to risk

having this service complete and the other actions in

their transaction fail, and the other half to risk having

this service fail while the other actions in their trans-

action complete. The results of failures with penal-

ties would be skewed differently if these rates were

changed, but, for this study, all that is important is the

fact that a failure with penalty occurred, not whether

that penalty was on this service or the other actions in

the transaction.

Each client also wishes to perform some other ac-

tions as a part of their transaction. These other actions

are modelled as an activity that takes between 1 and

10 time units, and fails 20% of the time. In reality,

the other actions could consist of multiple activities,

but, for this study, it is sufﬁcient to model them as a

single activity, since all that is important is whether

they succeed or fail.

The three providers are tested using each of the

three possible transactional guarantees. When using

the variable scheme that changes from semantic atom-

icity to tentative holds, the provider changes to use

tentative hold if the request would bring the number

of available resources to under 50% of the initial re-

sources offered by the provider. This is sufﬁcient for

WEBIST 2010 - 6th International Conference on Web Information Systems and Technologies

Table 1: Results when providers have limited resources.

Provider 1 Provider 2 Provider 3 Clients (%)

Failure with

Protocol Protocol Protocol Success No

penalty

Penalty

on other

activity

Penalty

on this

service

Any

penalty

Tentative Tentative Tentative 61.2 28.7 7.6 2.5 10.1

Variable Tentative Tentative 61.3 29.9 6.3 2.5 8.8

Variable Variable Tentative 62.2 29.5 5.7 2.6 8.3

Variable Variable Variable 61.6 31.7 3.6 3.1 6.7

Semantic Tentative Tentative 61.9 31.6 4.6 1.9 6.5

Semantic Variable Tentative 62.0 32.5 3.0 2.5 5.5

Semantic Variable Variable 62.0 31.7 3.1 3.2 6.3

Semantic Semantic Tentative 60.3 32.6 3.7 3.4 7.1

Semantic Semantic Variable 60.8 32.8 2.1 4.3 6.4

Semantic Semantic Semantic 61.0 39.0 0.0 0.0 0.0

the purposes of this investigation, but the logic could

be much more complicated in a real world system

(for example, a provider could always offer semantic

atomicity to regular clients, or only ever offer tenta-

tive holds to unfamiliar clients with large orders).

It is assumed that each provider offers the same

number of resources. This is tested ﬁrstly with each

provider offering 1000 resources, and then with each

offering 3500. Thus, in the ﬁrst test, there are far

fewer resources than are required by the set of clients,

meaning that the reservations for these providers are

most likely to fail. When each provider has 3500 re-

sources, there are sufﬁcient resources for each client

and transactions only fail if the other actions fail, or

semantic atomicity is required but not offered.

5 RESULTS

The results for the test where providers only have

1000 resources are shown in Table 1. In each case, at

least 99.9% of the resources offered by each provider

were used, so the only important difference between

tests are the protocols used by the providers and

the number of clients that succeeded, failed without

penalty, and failed with penalty.

The protocol offered by each provider is speci-

ﬁed in its “Protocol” column of the table. “Tentative”

means that the provider offered the tentative scheme,

which only ever gives out tentative holds. “Semantic”

means that the provider offered the semantic scheme,

always offering semantic atomicity if the requested

resources are available. Finally, “Variable” means

that the provider offered the variable scheme, where

it switches from offering semantic atomicity to offer-

ing tentative holds once its change-over threshold has

been reached.

The other columns in the table show the success or

failure rate of the clients. The “Success” column gives

the percentage of clients that successfully booked the

required resources from one of the three providers

and also had their other activities succeed. The “No

penalty” column speciﬁes how many clients had both

actions fail without penalty. “Penalty on other activ-

ity” gives the number of clients that had their other ac-

tivities succeed but were unable to book the resources

required from any of the three providers. “Penalty on

this service” gives the number of clients that success-

fully booked the resources from one of the providers,

but then had their other activities fail. “Any penalty”

is the sum of “Penalty on other activity” and “Penalty

on this service”, and indicates how many clients had a

failure resulting in a partially completed transaction.

When all providers offered the tentative scheme,

61.2% of transactions completed successfully, and

10.1% failed with penalty. When a single provider

instead offered the variable scheme, the number of

failures with penalty was slightly lower (8.8%). Com-

pare this to the case where a single provider offered

the semantic scheme while the others offered the ten-

tative scheme. In this case, only 6.5% of transac-

tions failed with penalty. This shows that the variable

scheme provides better service for clients than exclu-

sive use of the tentative scheme, as the rate of client

failures with penalty is much lower (though not as low

as when the provider offers the semantic scheme).

Further, replacing more providers offering the

tentative scheme with providers that offer the vari-

able scheme results in even lower rates of failure

with penalty. When all providers offered the vari-

PER-REQUEST CONTRACTS FOR WEB SERVICES TRANSACTIONS

Table 2: Results when providers have sufﬁcient resources.

Provider 1 Provider 2 Provider 3 Clients

Protocol Utility (%) Protocol Utility (%) Protocol Utility (%)

Success

(%)

Failure

with no

penalty

(%)

Failure

with

penalty

(%)

Tentative 37.37 Tentative 34.49 Tentative 32.17 72.6 18.8 8.6

Variable 68.89 Tentative 19.71 Tentative 20.06 76.6 18.0 5.4

Variable 53.57 Variable 54.46 Tentative 7.51 80.0 18.8 1.2

Variable 43.31 Variable 37.60 Variable 35.40 80.7 19.3 0.0

Semantic 99.40 Tentative 06.91 Tentative 8.11 80.0 19.2 0.8

Semantic 63.66 Variable 49.51 Tentative 4.11 80.7 18.8 0.5

Semantic 43.31 Variable 37.60 Variable 35.40 80.7 19.3 0.0

Semantic 59.09 Semantic 54.09 Tentative 4.11 80.7 18.8 0.5

Semantic 43.31 Semantic 37.60 Variable 35.40 80.7 19.3 0.0

Semantic 43.31 Semantic 37.60 Semantic 35.40 80.7 19.3 0.0

able scheme, only 6.7% of transactions failed with a

penalty for the client. While this is not as good as the

0% rate when only the semantic scheme was offered,

it is signiﬁcantly better than the original 10.1%.

The success rate of transactions using techniques

other than the tentative scheme are also fairly high.

The decreased risk obviously means that fewer trans-

actions can succeed, but this is almost completely

compensated for by the clients that refuse to use any

transactional guarantee other than semantic atomicity;

when only the tentative scheme is offered, they are

guaranteed to fail (without penalty), but when even

just one provider offers the semantic scheme or the

variable scheme then these transactions have a chance

to succeed.

Table 2 shows the results of starting each provider

with 3500 available resources. Again, clients can be

seen to have a lower chance of failure with penalty

when transactional guarantees stronger than tentative

holds are provided. In fact, as there are sufﬁcient re-

sources, the only failures with penalty that occur are

when the client risks making a booking on a provider

that only offers a tentative hold, and then the other

actions in the client’s transaction fail.

More interesting are the results for provider util-

ity, namely the percentage of original resources that

the clients have used once all transactions have com-

pleted. Since it is assumed that most clients prefer

using a provider who offers semantic atomicity, when

each provider has enough resources, those using the

variable scheme or the semantic scheme have a higher

utility. In fact, in many cases, the provider offering

the variable scheme behaves exactly like the provider

offering the semantic scheme, as the number of re-

sources it has remaining never gets below the amount

where the switch to tentative hold occurs.

The most obvious exception to this is where two

of the providers offer the tentative scheme, and the

other offers either the variable scheme or the seman-

tic scheme. When the provider offers the variable

scheme, it has a utility of 68.89%. When the semantic

scheme is used instead, however, the provider has a

utility of 99.40%. This is because the provider offer-

ing the variable scheme offers semantic atomicity un-

til its utility would be over 50%, and then only offers

tentative holds. Thus, once the provider changes to

tentative holds, clients no longer prefer that provider

over any of the others. When the semantic scheme

is offered, however, more clients prefer using that

provider as long as it has resources available.

Finally, table 3 shows the results when each

provider offers 3500 resources, and half the clients

attempt to order 50 of them. Once again, the num-

ber of transactions that fail with penalty decreases

as more providers offer stronger transactional guar-

antees. However, since many clients attempt to book

large numbers of resources, when only the semantic

scheme is offered the utility of each provider is sig-

niﬁcantly reduced. This is because clients lock the re-

sources, making them unavailable for others, so more

transactions fail immediately. Interestingly, when just

one provider offers the variable scheme or the ten-

tative scheme rather than the semantic scheme, the

utility of all providers is increased. Since clients get

the tentative holds rather than immediately failing, the

transaction stays active for longer, giving it a greater

chance to succeed. If ever the tentative hold is can-

celled, the client, rather than simply failing, searches

for another provider to offer the required resources.

If this occurs after a transaction that had an exclu-

WEBIST 2010 - 6th International Conference on Web Information Systems and Technologies

Table 3: Results when half of the clients request large amounts of resources.

Provider 1 Provider 2 Provider 3 Clients

Protocol Utility (%) Protocol Utility (%) Protocol Utility (%)

Success

(%)

Failure

with no

penalty

(%)

Failure

with

penalty

(%)

Tentative 98.51 Tentative 99.91 Tentative 100.00 46.5 32.6 20.9

Variable 99.94 Tentative 99.54 Tentative 98.74 45.0 36.3 18.7

Variable 99.11 Variable 99.89 Tentative 99.74 43.4 43.0 13.6

Variable 98.06 Variable 99.49 Variable 99.57 43.0 48.0 9.0

Semantic 99.94 Tentative 98.89 Tentative 99.54 44.9 41.6 13.5

Semantic 99.94 Variable 100.00 Tentative 97.00 44.8 45.9 9.3

Semantic 99.94 Variable 99.71 Variable 99.34 42.2 53.4 4.4

Semantic 99.69 Semantic 99.97 Tentative 99.80 41.3 51.5 7.2

Semantic 97.60 Semantic 96.31 Variable 96.14 39.7 57.6 2.7

Semantic 83.06 Semantic 81.34 Semantic 83.51 34.8 65.2 0.0

sive hold on items from a different provider has failed,

those resources are then available to the client that lost

the hold.

6 CONCLUSIONS AND FUTURE

WORK

Transactions in the Web Services environment are

necessarily quite different to traditional ACID trans-

actions. However, the support provided by current

standards is not always sufﬁcient. While existing

standards do allow some reduction to the ACID prop-

erties, these reductions are static, and each provider

in the transaction must necessarily support the same

reductions.

We have demonstrated that allowing service

providers to dynamically decide on the level of trans-

action support to offer for a particular request can be

beneﬁcial to both service providers and clients. Us-

ing a simple example where a provider changes from

offering semantic atomicity to tentative holds based

purely on the number of resources it has available, it

has been seen that fewer client transactions fail with a

penalty. Further, assuming that most users would pre-

fer services with better transactional guarantees, the

utility of the provider increases.

It has also been shown that, in certain circum-

stances, using the variable scheme can increase the

utility of providers over that supplied by using only

semantic atomicity. Thus, the alternate scheme has

beneﬁts over both offering just semantic atomicity

and just tentative holds.

While the example in this paper only consid-

ers two different transactional approaches (semantic

atomicity and tentative hold), many others are avail-

able. Thus, future work will look at combining dif-

ferent transactional guarantees into a single system

in which providers can dynamically decide on the

level of transaction support they wish to provide.

This study will also investigate different logic to help

providers make that decision.

The authors have not discussed the actual protocol

to allow clients and providers to negotiate on the level

of transaction support to be provided for a particular

service request. When performing a transaction com-

prised of actions from multiple providers, the level of

risk a client is willing to accept on one service call

may depend on the guarantees given by the providers

of the other actions in the transaction. Thus, not only

will the level of support a provider is willing to guar-

antee change dynamically, but so too will the level

that a client is willing to accept. As service providers

typically want their services to be used to give the

highest proﬁt possible, and offering certain transac-

tional guarantees can be expensive, research into de-

termining how a provider can discover the level of

support required to attract a particular client will be

as important as having the client determine what level

is being offered.

REFERENCES

Alrifai, M., Dolog, P., and Nejdl, W. (2006). Transactions

concurrency control in Web Service environment. In

The Fourth IEEE European Conference on Web Ser-

vices (ECOWS’06), pages 109–118.

Bunting, D., Chapman, M., Hurley, O., Little, M., Mis-

chkinsky, J., Newcomer, E., Webber, J., and Swen-

son, K. (2003). Web Services Composite Application

PER-REQUEST CONTRACTS FOR WEB SERVICES TRANSACTIONS

Framework (WS-CAF) ver1.0. Technical report, Ar-

juna Technologies Ltd.

Cabrera, L. F., Copeland, G., Feingold, M., Freund, R. W.,

Freund, T., Johnson, J., Joyce, S., Kaler, C., Klein,

J., Langworthy, D., Little, M., Nadalin, A., New-

comer, E., Orchard, D., Robinson, I., Shewchuk, J.,

and Storey, T. (2005). Web Services Coordination

(WS-Coordination). Technical report, Arjuna Tech-

nologies Ltd., BEA Systems Inc, Hitachi Ltd., IBM

Corporation, IONA Technologies, Microsoft Corpo-

ration.

Ceponkus, A., Dalal, S., Fletcher, T., Furniss, P., Green, A.,

and Pope, B. (2002). Business Transaction Protocol

1.0. Technical report, OASIS.

Choi, S., Jang, H., Kim, J., Kim, S. M., Song, J., and Lee,

Y. (2005). Maintaining consistency under isolation re-

laxation of Web Services transactions. In The Sixth In-

ternational Conference on Web Information Systems

Engineering (WISE’05), pages 245–257, New York,

NY, USA.

Cox, W., Cabrera, L. F., Copeland, G., Freund, T., Klein,

J., Storey, T., and Thatte, S. (2004). Web Services

Transaction (WS-Transaction). Technical report, BEA

Systems Inc, International Business Machines Corpo-

ration, Microsoft Corporation.

Fauvet, M.-C., Duarte, H., Duman, M., and Benatal-

lah, B. (2005). Handling transactional properties in

web service composition. In The Sixth International

Conference on Web Information Systems Engineering

(WISE’05), pages 273–289.

Garcia-Molina, H. (1983). Using semantic knowledge for

transaction processing in a distributed database. ACM

Trans. Database Syst., 8(2):186–213.

Gray, J. and Reuter, A. (1993). Transaction processing :

concepts and techniques. Morgan Kaufmann Publish-

ers, San Mateo, Calif.

Limthanmaphon, B. and Zhang, Y. (2004). Web Service

composition transaction management. In The Fif-

teenth Australasian database conference (ADC ’04),

pages 171–179. Australian Computer Society, Inc.

Lyon, J., Evans, K., and Klein, J. (1998). Transaction Inter-

net Protocol version 3.0. Technical report, Microsoft

Corporation and Tandem Computers.

Mikalsen, T., Tai, S., and Rouvellou, I. (2002). Trans-

actional attitudes: Reliable composition of au-

tonomous web services. In Workshop on Dependable

Middleware-based Systems (WDMS’02) at the De-

pendable Systems and Network Conference (DSN’02).

Roberts, J. and Srinivasan, K. (2001). Tentative Hold Pro-

tocol part 1: White paper. Note, World Wide Web

Consortium.

Sch

afer, M., Dolog, P., and Nejdl, W. (2007). Engineer-

ing compensations in web service environment. In In-

ternational Conference on Web Engineering, Como,

Italy. Springer Berlin/Heidelberg.

Zhang, A., Nodine, M., Bhargava, B., and Bukhres, O.

(1994). Ensuring relaxed atomicity for ﬂexible trans-

actions in multidatabase systems. In The ACM SIG-

MOD International Conference on Management of

Data (SIGMOD’94), pages 67–78. ACM Press.

WEBIST 2010 - 6th International Conference on Web Information Systems and Technologies
