MICRO-RESOURCE

A Microformat Framework for Dual Restful Web Services

Li Li and Wu Chou

Avaya Labs Research, 233 Mt. Airy Road, Basking Ridge, New Jersey, U.S.A.

Keywords: Microformat, REST, Web service.

Abstract: RESTful architecture style that underlies the Web has gained rapid adoption as a way to develop web

services for machines. But the full potential of REST is hindered by the fact that HTML pages designed for

human interactions are not suitable for machine processing. To address this problem, we developed a

microformat framework, called micro-resource, to extend web sites into dual RESTful web services for both

human and machines alike with minimum changes. This framework avoids the pitfalls of alternative

“parallel” web services by keeping the correspondence and duality between human and machine webs. This

framework is simple, extensible and also composable with other existing microformats. Initial application of

this framework on some RESTful service composition shows that the approach is efficient and feasible.

1 INTRODUCTION

REST stands for REpresentational State Transfer,

the architecture style underlying the World Wide

Web. The architecture style and design principles of

REST are discussed and analyzed extensively in

(Fielding 2000, AWWW 2004, Richardson 2007). A

key concept in REST is resource, which is

addressable by URI and has representations

corresponding to its state. Each resource supports a

subset of the uniform interface, such as HTTP, that

manipulates its state through representations. A

resource is typically connected with other resources

through URIs. A web service hosted on a web site

consists of a collection of resources. A client,

typically a browser, interacts with the service by

exchanging representations with those resources. In

these interactions, the service is stateless as the

client maintains the application states. In other

words, a representation obtained from a resource

contains complete information and instructions on

how to interact with the service at that point. This

self-describing ability is an important feature of

REST and is referred to as the “hypermedia as the

engine of application state” axiom of REST.

Due to its proved scalability and robustness over

the Web and inherent simplicity, REST has gained

rapid recognition as an alternative to the message-

oriented web service architecture based on SOAP

and WSDL.

In principle, REST can support both human-

machine and machine-machine interactions.

However, some technologies that implement REST,

namly HTML and XHTML, are designed for

humans, rather than for machines (For convenience,

this paper uses HTML to refer to both HTML and

XHTML henceforth). Therefore, it is difficult for a

program to extract meaningful data and instructions

from these HTML documents. This difficulty creates

a gap that prevents us from treating a human web

site as a programmable web service for machines,

even though such convergence is beneficial and

feasible.

To close this gap, we adopt the microformat

approach and propose a microformat framework,

called micro-resource, to annotate HTML

documents such that a HTML document becomes

suitable for both human and machine processing. A

microformat is a set of tags embeded in a HTML

document without affecting the visual display of the

page, while a program can extract semantic

information based on these tags and the predefined

rules. The major advantages of microformat are:

1. it normalizes semantic data represented in

different formats;

2. it minimizes changes to HTML pages by

reusing the information in them;

3. it creates a dual representation for both human

and machine;

Li L. and Chou W.

MICRO-RESOURCE - A Microformat Framework for Dual Restful Web Services.

DOI: 10.5220/0002805500560063

In Proceedings of the 6th International Conference on Web Information Systems and Technology (WEBIST 2010), page

ISBN: 978-989-674-025-2

However, most microformats are designed to

extract a specific type of semantic data, such as

business card. They are not sufficient as a

framework for RESTful services. Despite some

initiatives to develop microformats for RESTful

services, we have not seen a comprehensive

technical proposal so far. In current approaches,

each microformat requires a special parser that

understands the tags and rules of that microformat.

But a service framework needs to be extensible to

include any type of semantic data from different

domains. To address this issue, our framework

employes a two-level microformat such that a

general parser can extract and compose the semantic

information for different services.

Because microformat offers dual representation,

it can mitigate the cost of converting a human web

site into a machine web service. In this case, we just

add microformats to the HTML pages without

changing the rest of the service implementation. The

cost of maintaing a dual web service is also

relatively low especially when the HTML pages are

generated automatically at desgin time or runtime. It

seems that a dual web service creates overhead as

the service has to transmit extra data that are ignored

by the machine, but this overhead keeps the

correspondence between human and machine webs

and eliminates the need to create parallel web

services, in which resource representations and

service flows are duplicated. Because of the

correspondence, dual web services offer a much

more user friendly self-describing facility for

developers. When designed properly, a dual web

service can significantly increase its usability by

allowing a developer to interact with the service in

the same way a regular user interact with a web

application. From a developer’s point of view, a web

service effectively becomes “What You See Is What

You Get,” where “What You See” is the HTML

pages and “What You Get” is the services embeded

in the pages.

The rest of this paper is organized as follows.

Section 2 surveys related work to our approach.

Section 3 describes the general micro-resource

framework. Section 4 introduces the rules of micro-

resource. Section 5 is dedicated to the aggregation

and composition of micro-resource with other

microformats. Section 6 presents our experimental

study and results. We conclude this paper in Section

2 RELATED WORK

Microformat is an on-line community effort

(microformat.org) to develop microformats for

different applications. As of today, there are 9

specifications and 15 drafts. Each microformat

specifies a set of tags (properties) and rules on how

to annotate semantic data with those tags. These tags

can be embedded into a HTML document, using

HTML attributes class and rel, to assign

semantic meanings to the document without

affecting its rendering. For example, the hCard

(microformat.org) microformat has 2 required

properties and 24 optional ones, collectively

describing a business card. Since all HTML

elements have these two attributes, we can tag any

element in a HTML document,that has semantic

data. If necessary, the HTML grouping elements

<div> and <span> can be used to create additional

tagging points.

To illustrate the power of microformat, a

telephone number 5555 that occurs in three

different places: plain text, a table cell and an anchor

text of a hyperlink, can be normalized with one tag

of the hCard microformats:

Such microformats in HTML pages can be

transformed into semantic representations, such as

JSON or RDF, by special parsers or using W3C

GRDDL (GRDDL 2007) framework. In this sense,

microformat can be regarded as a binding

mechanism of abstract Infoset (Li 2009).

There are some initiatives to develop

microformats for describing RESTful web services

(REST microformat) as well.

REX (REST-Enabled XHTML) (REX) is an

effort to develop a dual-use XHTML profile using

microformats. Its goal is to cover a subset of REST

services that can be represented by XHTML with

microformats. The REX project page outlines some

interesting questions, challenges and general

directions, but we did not find a proposed

specification or draft in the official microformat site.

For this reason, it is difficult to compare our

approach with REX, but REX encourages our

pursuit of microformat based approach.

Peter Williams proposes (Williams 2008) a

JSON based framework to describe REST services

in terms of concepts such as service, resource,

service provider and container. In this framework,

there is a top-level capability resource from which

services can be discovered through HTTP GET. On

MICRO-RESOURCE - A Microformat Framework for Dual Restful Web Services

the other hand, services can also register with the

capability resource. In some sense, the capability

resource is a directory service, like a Sitemap

(Sitemap). But its service description does not

contain any information about how to interact with

the services, which is the focus of our approach.

WADL (Web Application Description

Language) (Hadley 2006) is a XML dialect that

describes REST services, as an equivalent of WSDL

for SOAP based web services. The key elements of

WADL include <resources>, which is a collection of

<resource> elements that describe resources of the

web application. Each <resource> element has a

URI path attribute, a list of <params> elements and

may contain other resources. A <resource> is also

associated with a set of <method> elements, each

having a HTTP verb, <request> and <response>

elements. The <request> and <response> elements

are associated with <representation> elements which

define the media type and root XML element of the

representation. In addition, a <response> element

also contains <fault> element that lists the HTTP

status codes. While WADL codifies the basic

concepts of REST services, it only describes the

static aspects of resources within a web service. If a

web service creates new types of resources, as it

often happens when a web site upgrades, the

corresponding WADL has to be updated

accordingly. This paradigm therefore misses the

dynamic and self-describing facility of REST

services.

hRESTS (Kopecky 2008) is an effort to use

microformat to describe REST services in HTML.

The proposed microformat is based on a functional

service model similar to WSDL. The model is

defined as RDF classes such as service, address,

operation, method, input and output. These class

labels are then used to annotate HTML pages,

including links and forms, in the microformat

fashion. Using the GRDDL framework (GRDDL

2007), XSLT transformations are applied to the

HTML with microformat to extract RDF graph

about the services, to be consumed by the clients.

Although the goal of this approach is very similar to

ours, its service model does not have the notion of

resource. Without modelling resource explicitly, it is

difficult to model the representation of resources and

relations between resources, which in our opinion

are the corner stones of REST.

RDFa (RDFa 2008) and eRDF (eRDF 2006),

both derived from RDF, are more powerful

mechanisms to insert semantic information into

HTML pages, in a fashion similar to microformats.

However, since our primary purpose is to interact

with a web service, instead of inferring properties

about the service, we choose microformat over RDF

for this project. But our approach can use semantic

web if necessary, as a microformat can always be

converted to RDF triples.

Realizing that HTML is not suitable to encode

machine-readable data, many web sites create

“parallel” web services where two types of services,

HTML for human users and XML for machine APIs

are developed. While this approach satisfies both

human and machine, as dual web services intend to

do, it has some drawbacks. First, it increases

development and maintenance cost because the two

web services offer different URIs, representation

formats, functionalities and access methods

(Richardson 2007, page 27). Second, parallel web

services tend to drift apart. As pointed out by

(Richardson 2007, page 96), most web service APIs

are not connected through links and forms, as human

web sites do. The loss of connectedness decreases

the self-describing facility and usability of the

service. Third, the machine APIs cannot be learned

and tested in a web browser as easily as surfing a

web site. Developers have to read manuals and write

code to understand the services. Even though we can

create XSLTs to transform XML documents for

machines into HTML pages for humans, writing

XSLT rules is not a trivial amount of work and it

does not put the human needs first. The dual web

service that we promote is centred on human users

and developers. This is one of the principles of

microformat: “human first and machine second.”

(microformat.org wiki)

3 MICRO-RESOURCE

FRAMEWORK

Our goal is to develop a microformat framework to

enable dual web services, such that one service

implementation is used for both human and machine

consumption. The high-level interactions of duality

of a web service are illustrated in Figure 1, where

the arrows indicate the flow of data between

components.

A micro browser is part of an automaton that

interacts with web services through microformats

and forms. The automaton can be a stand-alone

client application or a component within web

services. But in the dual web service, these use cases

are treated the same.

A human user can interact with a well-designed

web application he never visited before without any

problem. This is because 1) the web pages clearly

describes the interactions using a natural language,

WEBIST 2010 - 6th International Conference on Web Information Systems and Technologies

such as English, that is understood by the user; and

2) the user already has some background knowledge

about the basic mechanics of web browsers, for

example, what happens if a link is clicked, or a

submit button is pushed.

Figure 1: Dual web service architecture.

For the dual web service to work, a micro

browser has to “mimic” the human-machine

interactions with the same services. For this “mimic”

to be feasible, we have to make more stringent

assumptions because machines can only understand

precise and well-defined data and protocols.

Without losing generality, we can assume an

automaton is implemented as a finite-state machine

(FSM) that controls the micro browser. Because

each web service is different, we assume the finite-

state machine is service specific. However, the

micro browser is independent of specific services,

just as a web browser is independent of web sites.

Figure 2: Components of micro browser.

The architecture of automata based on this idea

is depicted in Figure 2, where a micro parser parses

the microformats into the micro-resource data model

proposed in this paper. The JSON (http://json.org/)

is used as the intermediate language between the two

layers. The reason we choose JSON is that it is a

standard, simple and yet powerful data structure that

can be serialized, transmitted and manipulated by a

variety of programming languages, including Java,

C++, C#, Perl and JavaScript. For this reason, a

micro browser can be implemented in those

languages and executed in various environments,

including inside a web browser.

To support this architecture, the microformat has

to be service independent yet powerful enough to

convey the useful semantic information about the

service. Otherwise, the micro browser cannot be

service independent and the FSM layer does not

have sufficient information to act on.

Based on our analysis using REST principles,

HTML documents contain the following three types

of information that are useful to interact with the

resources in a service:

1. properties: the state and schema of a resource;

2. composition: the subordinate resources of a

resource;

3. interface: the methods supported by a

resource;

To capture this information, we propose a

resource-oriented microformat, called micro-

resource. A micro-resource is a microformat

representation of a resource. The data model of

micro-resource can be defined by the following

UML class diagram (Figure 3).

Figure 3: Data model of micro-resource microformat.

This data model specifies that each micro-

resource has a type, a collection of properties and

some methods. Each property has a set of attributes,

modelled after HTML field elements (input, textarea

and select). Each method is associated with a URI

and is a subset of the uniform interface (GET,

POST, PUT, DELETE, etc.). Each micro-resource

can recursively contain other subordinate micro-

resources. Each property can have recursive child

properties as well.

Unlike most current microformats that has a

closed set of tags, micro-resource is a generic

microformat with open ended tags. This is necessary

because we want to use micro-resource to different

web services, each with its own set of resources.

Consequently, you can treat a hCard and a

hCalendar both as micro-resource. We need to tell

which tags are for micro-resources, since micro-

resource allows open ended tags, and tags from

HTML

(microformat)

Dual

Web

Service

web

browser

micro

browser

HTML

(Form)

auto

aton

HTML

(microformat)

HTML

(Form)

FSM

micro browser

micro parser

HTTP client

micro-resource (JSON)

MICRO-RESOURCE - A Microformat Framework for Dual Restful Web Services

different microformats can be mixed in one HTML

page. With this piece of information, a generic micro

parser can be used to instantiate the data model in

Figure 3. Otherwise, we have to 1) know all the

resource types of all services; 2) build a special

micro parser for each service; or 3) disallow mixture

of microformats. But none of these choices is

practical or necessary.

The micro-resource therefore has a two-level

structure: the first level uses the HTML <meta>

element to list the micro-resources present in the

document and the second level are actual micro-

resources tagged by using the HTML class and

rel attributes. Figure 4 is an example HTML file

with embedded micro-resources.

<head>

charset=UTF-8"/>

subscription"></meta>

<title>Subscriptions</title>

</head>

<body>

The subscriptions:

<thead>

<tr>

<th>Title</th>

<th>Direction</th><th>Author</th><th>Updated</th>

</tr>

</thead>

<tbody>

<td class="title"><a href="…"

rel="GET">title</a></td>

<td class="direction">1</td><td

class="author">author</td><td class="updated">2009-09-

22T17:05:35.979-0400</td>

</tr>

</tbody>

</table>

<a href="…" rel="POST">Post New Subscription</a>

</p>

</body>

</html>

Figure 4: A HTML page with micro-resource

microformat.

In this HTML document, the micro-resource tag

resource in the second <meta> element (in bold

font) declares there are two micro-resources in this

document: subscriptions and

subscription. The subscriptions micro-

resource has a subordinate micro-resource

subscription, and supports POST method to a

URI. The subscription micro-resource has

properties title, direction, author and

updated, and accepts GET method to a URI.

The above semantic information about resources

is extracted by the micro parser into a JSON

representation (Figure 5):

{

"POST": {"_uri": "…"},

"_children": [

{

"GET": {"_uri": "…"},

"_type": "subscription",

"author": {"_value": "author"},

"direction": {"_value": "1"},

"title": {"_value": "title"},

"updated": {"_value": "2009-09-22T17:05:35.979-0400"}

"_type": "subscriptions"

}

Figure 5: JSON representation of a micro-resource data

model.

In the JSON representation, micro-resource built-

in attributes have an underscore prefix (_type,

_children, for example) whereas others are service

specific tags outside the micro-resource

microformat.

The micro-resource microformat normalizes the

resource representations embedded in the HTML

documents, making these representations accessible

to the micro browser while keeping the

correspondence between HTML and micro-resource

data model.

4 MICRO-RESOURCE RULES

The micro-resource microformat does not specify

what tags can be used for a micro-resource, but only

constrain the relations between the tags in a HTML

document according to the data model depicted in

Figure 3. By default, it assumes all resource and

property tags in the class attribute and all method

tags in the rel attribute, because almost all

microformats use these two tags exclusively. Due to

space limit, we only list the main rules of micro-

resource tagging below:

Definition 1: Main Rules of micro-resource.

declaration: the micro-resources to occur in

the document are declared in a HTML <meta>

header element:

content=”list of tags” />

resource: a tag R in a class attribute of

element P is treated as a micro-resource if R is

declared so.

children: any child element of P tagged as a

WEBIST 2010 - 6th International Conference on Web Information Systems and Technologies

micro-resource is treated as a child resource of

properties: any child element of P has a class

tag but is not a declared micro-resource is treated

as a property of R or a child property. The value

of a property can be 1) href attribute of <a>

element; 2) value attribute of an <input>

element; or 3) content of an element.

method: an element, P or its child, with rel

attribute is treated as the methods of micro-

resource R. The URI of the element, including the

elements, becomes the URI of the methods.

form: a form can be tagged as a micro-

resource and its fields as the properties of the

micro-resource. Only information useful for

filling the fields and submitting the form is

collected based on the following template:

<form class={resource}

method={method} action={uri} >

<input|textarea|select

name={input} type={type}

value={value} class=”{property}

required?” lang={lang}

maxlength={maxlength} />+

</form>

These rules essentially map a HTML page with

micro-resource tags into a tree, where each node is a

micro-resource decorated with properties and

methods. We believe majority of HTML pages can

be mapped to such micro-resource trees. For

example, a Google search result page, if tagged with

micro-resource, can be rendered into a micro-

resource tree like the following, where each

directory /R represents a micro-resource R whose

properties and methods are highlighted inside the

square brackets:

/result

/search [input: q, POST: uri]

/matches

/match [preview: text, GET: uri]

/cached [GET: uri]

/similar [GET: uri]

…

/more

/page [index: 1, GET: uri]

…

/next [GET: uri]

/related

/term [term: text, GET: uri]

…

Figure 6: Micro-resource tree for Google search results.

5 AGGREGATION AND

COMPOSITION

Microformats can be aggregated and composed.

Aggregation is the process that merges the semantic

data from the same or different HTML documents.

For example, we can aggregate XFN microformats

(microformat.org) in a person’s home page and work

page to infer his social relationships. Composition is

the process that builds a microformat from other

ones. For example, hReview microformat is built

upon three microformats: 1) hCard that designates

the person who reviews an item, 2) rel-tag that

assigns a tag to the item being reviewed; and 3) rel-

license the associates a license with the review.

Figure 7: Part of the aggregated micro-resource map for a

dual web service.

Micro-resource can be aggregated and composed

in the same way. The micro-resource trees obtained

from the HTML pages of a web site can be

aggregated into a micro-resource map, where the

nodes in individual micro-resource trees are linked

based on methods of the micro-resources. For

example, Figure 7 shows a portion of the cross-

linked micro-resource map for a web service we

developed. For clarity, only the GET links are

displayed for each micro-resource. This micro-

resource map provides a snapshot of the web

services that can help developers to find entry points

to the services and how to consume them

accordingly.

Aggregation can be achieved in several ways.

For example, a web crawler that recognizes the

micro-resource and other microformats can search

the HTML documents and parses the microformats

in them. A plug-in to the browser can also be used to

parse the retrieved microformats while a developer

interacts with the service.

Micro-resource can also be composed with other

existing microformats. We can declare that hCard,

GET

Tree 1

/topics

/topic

/subscriptions

/notifications

/topics

Tree 2

/subscriptions

/subscription

Tree 3

/notifications

/notification

GET

MICRO-RESOURCE - A Microformat Framework for Dual Restful Web Services

hCalendar, hAtom, hReview, or any proper

microformat as micro-resource, using the declaration

rule in Definition 1. In such composition, each

composed microformat data model is treated as a

“super class” of the micro-resource data model in

Figure 3. In other words, the micro-resource data

model extends the composed microformat (hCard

for instance) with additional data, including property

attributes and methods. This inheritance relation is

illustrated in Figure 8.

Figure 8: Composition of micro-resource as inheritance.

Such composed data model can be built by

coordinating multiple microformat parsers. Given a

HTML document, we can activate the parsers for

declared micro-resources. Once the root class of a

microformat is detected (vcard for hCard, for

example), the parser for that microformat is used to

process the corresponding HTML section to build

one data model. The micro-resource parser is also

used to process the same section to build another

data model. The two models are then merged into

one.

<html>

<head>

</head>

<body>

<ol>

Your <span class="type">work</span> email: <input

type="text" name="work-email" class="value"

value="lli5@avaya.com" />

</li>

Your <span class="type">home</span> phone number:

<input type="text" name="home-phone" value="5555"

class="value required"/>

</li> </ol></form></body></html>

Figure 9: A form tagged as vCard micro-resource.

To illustrate this process, Figure 9 is a small

HTML document in which a form used to update a

person’s contact is tagged as a hCard which is also

declared as a micro-resource. For clarity, micro-

resource tags are in bold font and vCard tags are in

italics. Notice that the <input> element is tagged

by both hCard property tel and micro-resource

property required. The merged micro-resource

JSON representation is shown in Figure 10.

{

"PUT": {"_uri": "..."},

"_type": "vcard",

"email": {

"type": {"_value": "work"},

"value": {

"_input": "work-email",

"_type": "text",

"_value": "lli5@avaya.com"

}

"fn": {"_value": "Li Li"},

"tel": {

"type": {"_value": "home"},

"value": {

"_input": "home-phone",

"_required": true,

"_type": "text",

"_value": "5555"

}

Figure 10: The micro-resource composed with vCard.

6 APPLICATION AND

EXPERIMENTAL RESULTS

We have tagged a web service we developed for

event notifications with the micro-resource

framework. The tagging was made easy because it is

done on the HTML templates that generate all the

HTML pages. We also developed a prototype

general-purpose micro-resource parser based on

JAVA SAX parser. The micro-resource framework

was used to implement more complex web services

based on the primitive ones.

One such service is to move the subscriptions of

one topic to another topic such that the notifications

can be redirected to the new topic. This composed

service is hosted on a redirect resource that mediates

interactions between three types of resources

distributed across different web sites. A highlight

view of these interactions is illustrated in Figure 11,

where micro-resource is used to retrieve data from

HTML pages to update the involved resources.

We tested the performance of the micro-resource

parser on several sample HTML files, and the

experimental results, on a Windows 2003 Server

with dual 3 Ghz CPU and 2 GB RAM, are

summarized in Table 1. The results show that the

performance is acceptable and that parsing time

increases slowly compared to the file size and tag

number increases.

micro-resource data model

erties

(

attributes

)

methods

microformat data model

erties

(

sub

erties

)

WEBIST 2010 - 6th International Conference on Web Information Systems and Technologies

Figure 11: Service composition with micro-resources.

Table 1: Performance of micro-resource parser.

File size (B) No. of tags Avg. Time (ms)

349 6 7

1943 15 10

2041 11 14

3662 19 14

7 CONCLUSIONS

This paper presented a microformat framework,

micro-resource, based on the fundamental principles

of REST, to support the development of dual web

services. For this purpose, we compared this

approach against others, including alternative

parallel web services, and described the framework,

rules, aggregation and composition of micro-

resources with illustrative examples. We

implemented a prototype parser and demonstrated its

performance for service composition. Our study

showed that micro-resource framework has the

potential to narrow or even close the gap between

human and machine web services such that the full

power of RESTful web services can be reached out

to applications in both environments with minimum

investment from service consumers and providers.

REFERENCES

AWWW 2004: Architecture of the World Wide Web,

Volume One, W3C Recommendation 15 December

2004, http://www.w3.org/TR/webarch/

eRDF 2006: Embeddable RDF, http://

research.talis.com/2005/erdf/wiki/Main/RdfInHtml

Fielding, Roy, Architectural Styles and the Design of

Network-based Software Architectures, Ph.D.

Dissertation, 2000, http://www.ics.uci.edu/~fielding/

pubs/dissertation/top.htm

GRDDL 2007: Gleaning Resource Descriptions from

Dialects of Languages (GRDDL), W3C

Recommendation 11 September 2007,

http://www.w3.org/TR/grddl/

Hadley, Marc, Web Application Description Language

(WADL), http://research.sun.com/techrep/2006/

abstract-153.html

Khare, Rohit, Microformats, the Next (Small) Thing on

the Semantic Web? IEEE Internet Computing, vol. 10,

no. 1, pp. 68-75, Jan./Feb. 2006.

Kopecky, J., Gomadam, K., Vitvar, T., hRESTS: an

HTML Microformat for Describing RESTful Web

Services, 2008 IEEE/WIC/ACM International

Conference on Web Intelligence and Intelligent Agent

Technology, pp. 619-625, 2008.

Khare, R., Celik, T., Microformats: a Pragmatic Path to

the Semantic Web, WWW 2006, pp. 865-866, 2006.

Li, L., Chou, W., Infoset for Service Abstraction and

Lightweight Message Processing, ICWS 2009, pages

703-710, Los Angeles, July 2009.

microformat.org: http://www.microformats.org

RDFa 2008: RDFa in XHTML: Syntax and Processing, A

collection of attributes and processing rules for

extending XHTML to support RDF, W3C

Recommendation 14 October 2008,

http://www.w3.org/TR/rdfa-syntax/.

REST microformat: http:/www.micrformats.org/wiki/rest

REX: http://microformats.org/wiki/rex-proposal-preso

Richardson, L. Ruby, S., RESTful Web Services, O’Reilly

Media, Inc. 2007.

Sitemap 0.90, http://www.sitemaps.org/.

Stolley, Karl, Using Microformats: Gateway to the

Semantic Web Tutorial, IEEE Transactions on

Professional Communications, Vol 52, No. 3, pp. 291-

302, 2009.

Williams, Peter: RESTful Service Discovery and

Description, http://barelyenough.org/blog/2008/01/

restful-service-discovery-and-description/, 2008.

MICRO-RESOURCE - A Microformat Framework for Dual Restful Web Services
