Biometrics for Emotion Detection (BED

Exploring the combination of Speech and ECG

Marleen H. Schut

, Kees Tuinenbreijer

, Egon L. van den Broek

and Joyce H. D. M. Westerink

Philips Consumer Lifestyle Advanced Technology

High Tech Campus 37, 5656 AE Eindhoven, The Netherlands

Human-Centered Computing Consultancy, Austria

User Experience Group, Philips Research Europe

High Tech Campus 34, 5656 AE Eindhoven, The Netherlands

Abstract. The paradigm Biometrics for Emotion Detection (BED) is introduced,

which enables unobtrusive emotion recognition, taking into account varying en-

vironments. It uses the electrocardiogram (ECG) and speech, as a powerful but

rarely used combination to unravel people’s emotions. BED was applied in two

environments (i.e., ofﬁce and home-like) in which 40 people watched 6 ﬁlm

scenes. It is shown that both heart rate variability (derived from the ECG) and,

when people’s gender is taken into account, the standard deviation of the fun-

damental frequency of speech indicate people’s experienced emotions. As such,

these measures validate each other. Moreover, it is found that people’s environ-

ment can indeed of inﬂuence experienced emotions. These results indicate that

BED might become an important paradigm for unobtrusive emotion detection.

1 Introduction

A goal of human-centered computing is computer systems that can unobtrusively per-

ceive and understand human behavior in unstructured environments and respond ap-

propriately. [1]

Three of the issues raised in this quote formed the starting point of the research de-

scribed in this paper: 1) unobtrusively perceive, 2) understand, and 3) unstructured en-

vironments. Regrettably, in practice, the combination of these issues is rarely taken into

account in research towards human-centered computing. This paper describes research

that took into account all three aspects that were just denoted. To enable unobtrusive

recordings of humans, we exploit the combination of the electrocardiogram (ECG) and

In parallel with the abbreviation for Biometrics for Emotion Detection, BED denotes a sec-

ond aspect of the paradigm: a supporting surface or structure or a foundation (source:

http://www.merriam-webster.com) for unobtrusive emotion detection.

H. Schut M., Tuinenbreijer K., L. van den Broek E. and H. D. M. Westerink J. (2010).

Biometrics for Emotion Detection (BED): Exploring the combination of Speech and ECG.

In Proceedings of the 1st International Workshop on Bio-inspired Human-Machine Interfaces and Healthcare Applications, pages 59-66

DOI: 10.5220/0002813400590066

 SciTePress

speech. The combination of speech and biosignals (in general) to determine emotions is

rare. However, some research has been conducted; e.g., [2, 3]. This research concluded

that they . . . did not achieve the same high gains that were achieved for audio-visual

data which seems to indicate that speech and physiological data contain less comple-

mentary information. [2] (p. 63). This paper present a study that challenges this conclu-

sion. In combination with people’s subjective experiences, these two signals should be

able to unravel generic principles underlying humans’ emotions, at least partly.

It has been widely acknowledged that emotion elicitation is as crucial as is it com-

plex for affective computing purposes. Moreover, context has been frequently men-

tioned as a factor of inﬂuence. This study explores whether or not context has an inﬂu-

ence on emotion elicitation, as it comprises two identical studies in different settings.

This is expected to provide a little grip on the inﬂuence of environmental factors / con-

text. Since we want to explore generic principles behind human emotions, we ignore

inter-personal differences. Please note that with this position, we do not challenge the

notion that signiﬁcant differences among humans exist; cf. [4]. Ultimately, a personal-

ized approach will need to be adopted; however, before that, generic principles have to

identiﬁed to enable more efﬁcient processing of cues.

First, we will brieﬂy introduce the construct emotion (Section 2) and the model of

emotion used. Section 4 describes the two studies conducted, with which we explore the

use of the paradigm BED. This includes a description of the speech and ECG signals. In

Section 5, the analysis of the two studies is presented. These comprise only a limited set

of features, as an exhaustive search in feature space was not the aim of this study. Last,

in Section 6, the implications of this research will be discussed and future directives

will be provided.

2 Emotions

As John F. Cohn states [1]: Efforts at emotion recognition [. . . ] are inherently ﬂawed

unless one recognizes that emotion - intentions, action tendencies, appraisals and other

cognitions, physiological and neuromuscular changes, and feelings is not readily ob-

servable. In other words, emotions are a complex set of interactions among subjective

and objective factors, mediated by neural/hormonal systems. Consequently, emotions

can [5]:

1. cause affective experiences such as feelings of arousal and (dis)pleasure;

2. generate cognitive processes; e.g., emotionally relevant perceptual effects, appraisals,

labeling processes;

3. activate widespread physiological adjustments to arousing conditions; and

4. lead to behavior that is often expressive, goal directed, and adaptive.

Much can be said both in favor and against this deﬁnition. However, with this work we

do not aim to provide an exhaustive elaboration on the deﬁnition of emotions. There-

fore, we adopt the previous deﬁnition of emotions as working deﬁnition.

In his seminal study, Russell (1980) introduced the circumplex model of emotion,

which claims that all emotions can be characterized by two independent bipolar dimen-

sions: judged valence (i.e., pleasure/positive or displeasure/negative) and arousal [6].

The circumplex model allows a representation of emotions in a 2D space, which pro-

vides a visualization of emotions and their relation in a comprehensible way. Parallel

to Russell’s model various other models of emotion have been introduced, using 1)

categories, 2) unipolar or bipolar dimensions, 3) some other simple structure, and 4) a

hierarchy. For an overview on models of emotion, we refer to [6].

For the current research, we adapted Russell’s circumplex model [6]. The bipolar

valence dimension was replaced by two unipolar valence dimensions, untying positive

and negative valence. The arousal dimension was not altered. A similar approach have

been used earlier; e.g., see [7, 8]. The 3D model we propose tackles a major disadvan-

tage of the circumplex model: the disability to handle mixed emotions; i.e., parallel

experience of positive and negative valence.

3 Signals of Emotion

People’s emotional state can be accessed through processing various of their signals.

When reviewing literature, it becomes apparent that these signals can be assigned to

two groups: 1) A broad range of physiological measures signals [9] and 2) Specialized

areas of signal processing: speech processing, movement analysis, and computer vision

techniques [10–12]. These distinct measurement methods are seldom combined; where,

on the one hand, several physiological measures are frequently combined (e.g., [4, 8])

and, on the other hand, speech processing, movement analysis, and computer vision are

frequently combined (e.g., [11]).

Physiological measures are often obtrusive and, hence, disregarded for user-centered

applications, as AmI is. However, wearable computing and wireless sensing technolo-

gies relief this problem [13]. In contrast, speech and computer vision are unobtrusive

but very noise sensitive. The audio recordings used for speech processing suffer various

types of noise. However, with no need for speech recognition, the remaining problem is

binary: a speech signal or no speech signal, which makes it feasible. Computer vision

techniques, although appealing, are only usable for emotion recognition in very stable

environments; e.g., without occlusion and with ﬁxed light sources.

Speech and physiological measures, in particular the ECG, are rarely combined to

access the emotional state of users, although especially their combination is promising.

A possible explanation is the lack of knowledge that exists on the application of this

combination of measures for emotion measurement; cf. [10, 11] and [8, 9].

From features of both the speech and the ECG signal, we expect to extract cues

on people’s experienced valence and arousal. Since this study is (one of) the ﬁrst to

employ the combination of speech and ECG, we chose for a controlled study to assess

their feasibility for human-centered computing purposes. However, before the study is

described, each of the signals used are introduced.

4 Principles and Implementation

Let us quote John F. Cohn [1], once more: Emotion can only be inferred from con-

text, self-report, physiological indicators, and expressive behavior. The four factors ad-

dressed in this quote are incorporated in this research on BED. For each of them will be

explained how they are embedded in BED and are implemented in the research.

4.1 Context

As was stated in the introduction, context is of the utmost importance. However, ﬁeld

research introduces a broad range of factors that cannot be controlled. These factors can

be considered as severe forms of noise, when analyzing the data obtained. Most often,

this results in qualitative data gathering and its analysis. In contrast, with the signals

ECG and speech, we aim to gather quantitative data. Therefore, we chose to conduct a

semi-controlled study.

40 people (average age: 27) voluntarily participated in this research. Half of them

was assigned to a living room environment and half of them was assigned to an ofﬁce

environment. Except for this difference, both groups participated in the same study,

under the same conditions. All participants had (corrected to) normal vision and hearing

and none of them had cardiovascular problems.

To trigger emotions, the participants watched six scenes (length: 3.18 min), adopted

from [7, 8]. For a more exhaustive description of the ﬁlm scenes, we refer to [7].

The length of the ﬁlm scenes enables a reliable extraction of HR variability from the

ECG [14]. The ﬁlm scenes were presented in a random order. While watching the ﬁlm

scenes, their ECG signal was recorded using a modiﬁed Polar ECG measurement belt

that was connected to a NI USB-6008 data acquisition device. Its output was recorded

in a LabVIEW program (sample rate: 200 Hz). After the ﬁlm scene was watched, the

people were asked to talk about it. For this a standard microphone was used (sample

rate: 44.100 Hz; sample size: 16 bit).

After instructions and a control of the equipment, the people read aloud a non

emotional story. In this way it was checked if the people had understood the instruc-

tions, whether or not the equipment worked, and people’s personal baseline for both the

speech and the ECG signal was determined.

4.2 Self-report

After all ﬁlm scenes were shown, the people rated the ﬁlms, using 11 point Likert

scales. Hence, their subjective attitudes were determined. Separate Likert scales were

presented for positive and negative affect and for arousal; see also Section 2.

4.3 Physiological Indicator: Electrocardiogram (ECG)

The electrocardiogram (ECG) is an autonomic signal that cannot be controlled easily,

just like the electrodermal activity. ECG can be measured directly from the chest. Alter-

natively, the periodic component of the blood ﬂow in the ﬁnger or in an ear which can

be translated into the ECG. From the ECG, the heart rate (HR) can be easily obtained;

e.g., [9, 13]. Research identiﬁed features of HR as indicators for both experienced va-

lence and arousal [15].

In addition to the HR, a range of other features can be derived from the ECG. The

most frequently used one is HR variability (HRV). HRV decreases with an increase in

mental effort, stress, and frustration [9]. Moreover, some indications have been found

that HRV is also inﬂuenced by the valence of an event, object, or action [15]. Taken

together, HRV is one of the most powerful features to discriminate among emotions.

4.4 Expressive Behavior: The Speech Signal

Speech processing, speech dialog, and speech synthesis can exhibit some form of in-

telligent, user-perceived behavior and, hence, are useful in designing human-centered

computing environments [1]. However, speech comprises another feature: emotion elic-

itation [10, 11].

The human speech signal can be characterized through various features and their

accompanying parameters. However, no consensus exists on the features and parameters

of speech that reﬂect the emotional state of the speaker. Most evidence is present for

the variability (e.g., standard deviation; SD) of the fundamental frequency (F0), energy

of speech, and intensity of air pressure [10, 11]. Therefore, this feature is derived from

speech as its emotion indicator.

5 Analysis

5.1 Data Reduction

Before the actual data reduction could take place, noise reduction was applied for both

the ECG and the speech signal. First, recording errors were removed. Of 11 participants

either the ECG signal, the speech signal, or both was distorted (e.g., the microphone was

positioned to close to the mouth, coughing, yawning) or not recorded at all. The data of

these participants was omitted from further analyses.

The measurement belt for the ECG signal appeared to be sensitive to movements

of the participant. For this type of noise was controlled and, if present, the ECG signal

was corrected for it. Using the corrected ECG signal, people’s HR was determined.

Subsequently, HRV (i.e., SD of HR) was calculated.

The speech signal was segmented in such a way that for each ﬁlm scene a separate

speech signal was determined. Moreover, silences and utterances such as ‘euh’ were

removed. This resulted noise-free speech signals. In order to cope with interpersonal

differences in speech, the signals were normalized by subtracting a baseline from the

original signal. Subsequently, the speech processing environment Praat [16] was used

to extract the SD F0 and the intensity of air pressure.

5.2 Subjective Measurements

The people rated the ﬁlm scenes on their experienced positive and negative valence and

on arousal. For each ﬁlm scene, peoples’ average ratings on each of these scales were

calculated. Together, these two categorized dimensions of the valence–arousal model

depict six emotion classes.

Each of the six emotion classes is represented in this research through one ﬁlm frag-

ment. The emotion classes with the values on the three dimensions, their categorization

in valence and arousal, and the accompanying ﬁlm fragment can be found in [7].

5.3 Feature Extraction

From both the speech signal and the ECG signal a large number of features can be

derived [14, 15]. This research did, however, not aim to provide an extensive compar-

ison of speech and ECG features. Instead, the combination of these two signals was

explored. From the ECG signal, the intervals between the R-waves (R-R intervals) as

well as their mean were determined. Subsequently, the HRV was deﬁned as the SD of

the R-R intervals.

Although no general consensus exists concerning the parameters of speech to be

used for emotion detection, much evidence is present for the SD F0 and the Intensity of

air pressure. They are useful for measuring experienced emotions. For a domain [0, T ],

the intensity of air pressure in the speech signal is deﬁned as:

10 log

T P

(t) dt, (1)

where x(t) is the amplitude or sound pressure of the signal in Pa (Pascal) and P

2 · 10

−5

Pa is the auditory threshold [16]. It is expressed in dB (decibels) relative to P

The F0 of pitch was extracted from the corrected speech signal through a fast

Fourier transform over the signal. Subsequently, its SD is calculated. We refer to the

documentation that accompanies [16], for a more detailed description of the extraction

of F0 of pitch from the speech signal.

5.4 Results

All data was analyzed through a RM ANOVA, with three measures: HRV determined

from the ECG signal and the SD F0 and intensity of the speech signal. Two between

subject factors were included in the analyses: the environment (ofﬁce/living room) and

gender (male/female). Age was omitted from the analysis since a preliminary analysis

revealed that age was of no inﬂuence on any of the measures. First, the multivariate test

will be reported, including all four measures. Next, for each measure the univariate tests

will be reported. With all analyses, the interaction effects will be reported.

The multivariate analyses showed a strong effect for the emotion classes on the

set of physiological parameters/measures, F(15,11) = 29.688, p < .001. In addition, in

interaction with both gender (F(15,11) = 7.266, p = .001) and environment (F(15,11)

= 17.235, p = .000), an effect of the emotion classes on the measures was found. In

line with these interaction effects, a three-way interaction effect between the emotion

classes, gender, and the environment was found on the measures, F(15,11) = 8.737, p <

.001.

A strong main effect was found for the emotion classes on HRV, F(5,125) = 38.677,

p < .001. An interaction effect of the emotion classes and both gender (F(5,125) =

7.678, p < .001) and environment (F(5,125) = 18.856, p < .001) on HRV was found. In

line with the two-way interaction effects on HRV, a three-way interaction effect on HRV

between the emotion classes, gender, and environment was found, F(5,125) = 10.967, p

< .001.

An interaction effect between the emotion classes and gender on SD F0 was found,

F(5,125) = 2.553, p = .031. In addition, a three-way interaction effect on the intensity

of speech between the emotion classes, gender, and environment was found, F(5,125) =

3.052, p = .013.

6 Discussion

The emotions elicited by the ﬁlm fragments are clearly discriminated by HRV. In inter-

action with gender, both HRV and SD F0 show to be a good discriminator among the

six emotion classes. When both gender and environment are taken into account, both

HRV and the intensity of speech reﬂect the emotions experienced.

Of the F0 of speech, it is known that male and females have different characteris-

tics. Hence, the inﬂuence of gender was expected and will always have be taken into

account. Moreover, environmental factors have to be incorporated in the processing

scheme. Note that the difference between the environments assessed in this research

was limited; hence, in practice this effect can be far more substantial. Further, research

on the intensity of speech should reveal how robust the current ﬁndings for this param-

eter are.

Both HRV and SD F0 of speech showed to be good generic unobtrusive discrim-

inators between emotions. This makes them par excellence suitable as biometrics for

unobtrusive emotion discrimination. This study is rare in that it reports the use of biosig-

nals in combination with speech to unravel user’s emotional state. However, it should

be noted that the variety among emotions is rich and only six are assessed in the cur-

rent research. Moreover, it is unknown how sensitive both measures are for emotion

discrimination. Hence, further research is needed on this.

The results of this research should be seen in the perspective of the vast amount of

research already done on emotions. This research has revealed a range of issues that

can, and probably should, also be taken into account. First, the notion of time should

be taken into consideration that helps to distinguish between emotions, moods, and

personality [6, 17]. Second, BED distinguishes four factors: context, self-report, phys-

iological indicators, and expressive behavior. The last three of them can be inﬂuenced

by personality characteristics. For example, an introvert person will express his emo-

tions in another way than an extrovert person. Moreover, probably also the self-reports

and physiological indicators or biosignals will be inﬂuenced by this personality trait.

Moreover, whether or not a person is neurotic will inﬂuence his behavior, in particular

in relation to his environment (or context); e.g., see also [17].

Other more practical considerations should also be noted. For example, the advances

made in wearable computing and sensors facilitates the communication between hu-

mans and systems; cf. [13]. This enables the use of more recordings of biosignals in

parallel to speech recordings and ECG. In this way, an even higher probability of cor-

rect interpretation can be achieved [8, 9].

It is surprising that the combination of speech and biosignals has not been used

more often to unravel user’s emotions; cf [2, 3]. Par excellence, these signals could be

exploited in parallel for generic human-centered computing purposes, as is illustrated

through BED. Both speech and ECG parameters can unravel users’ emotion space.

Moreover, various manners of implementation of the required sensors secure an unob-

trusive recording of both signals. This having said, with this article we hope to motivate

a further exploration of the combination of speech and biosignals. Possibly, they enable

the signiﬁcant step forward in making reliable unobtrusive emotion detection a success.

References

1. Cohn, J.F.: Foundations of human computing: Facial expression and emotion. Lecture notes

in Artiﬁcial Intelligence (Artiﬁcal Intelligence for Human Computing) 4451 (2007) 1–16

2. Kim, J., Andr

e, E.: Emotion recognition using physiological and speech signal in short-term

observation. Lecture Notes in Computer Science (Perception and Interactive Technologies)

4021 (2006) 53–64

3. Kim, J.: 15. In: Bimodal emotion recognition using speech and physiological changes.

Vienna, Austria: I-Tech Education and Publishing (2007) 265–280

4. Kim, J., Andr

e, E.: Emotion recognition based on physiological changes in music listening.

IEEE Transactions on Pattern Analysis and Machine Intelligence 30 (2008) 2067–2083

5. Kleinginna, P.R., Kleinginna, A.M.: A categorized list of emotion deﬁnitions, with a sug-

gestion for a consensual deﬁnition. Motivation and Emotion 5 (1981) 345–379

6. Russel, J.A., Barrett, L.F.: Core affect, prototypical emotional episodes, and other things

called emotion: Dissecting the elephant. Journal of Personality and Social Psychology 26

(1999) 805–819

7. van den Broek, E.L., Westerink, J.H.D.M.: Considerations for emotion-aware consumer

products. Applied Ergonomics 40 (2009) 1055–1064

8. van den Broek, E.L., Lis

y, V., Janssen, J.H., Westerink, J.H.D.M., Schut, M.H., Tuinenbrei-

jer, K. In: Affective Man-Machine Interface: Unveiling human emotions through biosignals.

Volume 52 of Communications in Computer and Information Science. Berlin/Heidelberg,

Germany: Springer-Verlag (2010) 21–47

9. Fairclough, S.H.: Fundamentals of physiological computing. Interacting with Computers 21

(2009) 133–145

10. Ververidis, D., Kotropoulos, C.: Emotional speech recognition: Resources, features, and

methods. Speech Communication 48 (2006) 1162–1181

11. Zeng, Z., Pantic, M., Roisman, G.I., Huang, T.S.: A survey of affect recognition methods:

Audio, visual, and spontaneous expressions. IEEE Transactions on Pattern Analysis and

Machine Intelligence 31 (2009) 39–58

12. Gunes, H., Piccardi, M.: Automatic temporal segment detection and affect recognition from

face and body display. IEEE Transactions on Systems, Man, and Cybernetics – Part B:

Cybernetics 39 (2009) 64–84

13. Pantelopoulos, A., Bourbakis, N.G.: A survey on wearable sensor-based systems for health

monitoring and prognosis. IEEE Transactions on Systems, Man, and Cybernetics, Part C:

Applications and Reviews 40 (2010) 1–12

14. Berntson, G.G., Bigger, J.T., Eckberg, D.L., Grossman, P., Kaufmann, P.G., Malik, M., Na-

garaja, H.N., Porges, S.W., Saul, J.P., Stone, P.H., van der Molen, M.W.: Heart rate variabil-

ity: Origins, methods, and interpretive caveats. Psychophysiology 34 (1997) 623–648

15. Appelhans, B.M., Luecken, L.J.: Heart rate variability as an index of regulated emotional

responding. Review of General Psychology 10 (2006) 229–240

16. Boersma, P.P.G., Weenink, D.J.M.: Praat 4.0.4 (2006) URL: http://www.praat.org [Last ac-

cessed on January 13, 2010].

17. Barrett, L.F.: Valence as a basic building block of emotional life. Journal of Research in

Personality 40 (2006) 35–55
