A RELIABLE HYBRID TECHNIQUE FOR

HUMAN FACE DETECTION

Ayesha Hakim, Stephen Marsland and Hans W. Guesgen

School of Engineering and Advanced Technology, Massey University, Palmerston North, New Zealand

Keywords: Face Detection, Haar-classifier, Skin-colour, Occlusion.

Abstract: The progress of computer vision technology has opened new doors for interactive and friendly computer

interfaces. Human face detection is an essential step of various human-related computer applications,

including face recognition, emotion recognition, lip reading, and several intelligent human computer

interfaces. Since it is the basic step in such applications, it must be reliable enough to support further steps.

Several approaches to detecting human faces have been proposed so far, but none of them can detect faces

in all different conditions such as varying lighting conditions; frontal, profile, tilted and rotated faces;

occlusions by glasses, hijab, facial hair; and noise. We propose a more reliable hybrid approach that is able

to detect human faces in multiple circumstances. Moreover, a brief, but comprehensive, review of the

literature is presented that may be useful to evaluate any face detection system. Our proposed approach

gives up to 97% accuracy on 600 images (both simple and complicated), which is the highest accuracy rate

reported to date to our knowledge.

1 INTRODUCTION

The current growth of computer technologies has

paved the way to a new machinery world where

human life is improved by artificial intelligence.

Research efforts in human-computer interaction aim

to find ways to enable computers to interact with

humans in more natural ways, e.g. by recognizing

their gestures, speech, hand writing, and even

emotions.

Human face detection is an essential first step in

almost all face-related problems. It involves

localizing and extracting the face region from the

rest of the image (Hjelmas and Low, 2001). The

objective of face detection is to find out whether or

not there are any faces present in the image and, if

so, to return the location and size of each (Yang,

Kreigman and Ahuja, 2002). It helps to limit the

search space for facial features since the system does

not have to search for features in the whole image

(McDermott, 2006). It also has numerous other

applications in areas such as human face

recognition, emotions recognition, sign language

recognition, lip reading, face focusing in cameras,

and other intelligent human-computer interfaces.

Unfortunately, human face detection is not an

easy task. Depending on the camera-face pose, some

facial features might be partially or totally occluded,

which might make it difficult to detect the face.

Varying lighting conditions might result in some

parts of the faces being only partially lit, which

might mean that not all features are clearly visible.

Also, there is a wide variety in the appearance of

faces, both because of natural variation and because

of additions such as facial hair and glasses. Various

facial expressions and physiognomies of faces also

cause problems, since they change the normal

appearance of the face. Some images have a single

face, others have multiple or no face at all, some

may have complex backgrounds and some may be

noisy due to poor quality images. All such problems

are big hindrances in detecting faces from images.

We concentrate on the problem of human face

detection in static images having complex

background; varying lighting conditions; glasses;

facial hair; various facial expressions (spontaneous

and posed); considerable variations in head poses;

occlusions; noise; profile, tilted, and rotated faces.

In this paper we propose a hybrid method that

uses two of the most successful (and

complementary) algorithms and uses them each

appropriately. This provides a method that is

significantly more accurate than either alone and

also significantly faster, on average, than one of

241

Hakim A., Marsland S. and W. Guesgen H. (2010).

A RELIABLE HYBRID TECHNIQUE FOR HUMAN FACE DETECTION.

In Proceedings of the International Conference on Computer Vision Theory and Applications, pages 241-244

 SciTePress

them.

See full version of paper, table comparing

various published results and our experimental

results on website (http://muse.massey.ac.nz).

2 RELATED WORK

Early efforts to develop automatic systems for

human face detection began at the start of 1970s, but

progress remained slow until the 1990s. The

literature reveals a remarkable rise in interest in this

research topic over the past decade (Hjelmas and

Low, 2001). The first problem in the area of human

face detection is the search for some ‘standard

dataset’ that can be treated as a target to compare

detection rates between algorithms. Unfortunately,

there is no such standard comprehensive database

available and the databases that most of the research

groups used for evaluation consist of gray scale

images. So the first step was to collect an RGB

image dataset that can be used to test all of the above

mentioned conditions.

To date, various methods have been proposed for

human face detection from images. Each method has

its own benefits and limitations, but there has not

been a consistent review and comparison of face

detection methodologies. Since face detection is the

basic step, it must be very efficient and reliable. The

literature reveals that the systems that are reliable

are not generally efficient, and vice versa. Moreover,

a lot of costly training is usually required as a pre-

processing step.

Some of the most widely used methods of human

face detection are based on Haar classifiers (Viola

and Jones, 2004; Lienhart and Maydt, 2002), human

skin colour (Hsu, Abdel-Mottaleb and Jain, 2002;

Wang and Yuan, 2001; Singh et al., 2003; Lin et al.,

2008), and facial feature detection (Lee, S. Park and

M. Park, 2005). These methods, although capable

(to some extent) of detecting human faces alone, do

not cover the wide spectrum of different conditions

due to some limitations.

Viola and Jones (Viola and Jones, 2004)

proposed using boosting of Haar-like features to

detect the face region. Using this method, real-time

detection can be achieved with the help of very

simple and easily computable Haar-like features, and

a cascade of boosted classifiers. AdaBoost was used

to select the most representative features in a large

set. On the other hand, Haar classifier detection

results are highly dependent on image quality,

contrast and brightness and it gives false positives or

false negatives if the image is blurred or face in the

image is occluded.

Most researchers report only false negatives, i.e.

faces that are not detected. However, the problem of

false positives (identifying a region as a face when it

is not) is also a potential problem with face detection

algorithms. There is also a significant difference

between what is considered a correct result. Some

papers report any result that includes a part of the

face as correct. For frontal, non-occluded images we

require that all of the eyes, nose, and lips (primary

features) are included in the face ‘box’.

Skin colour-based detection methods perceive

skin regions over the whole image and create face

candidates on the basis of several image processing

techniques. These methods help to detect faces

under varying poses (partially occluded or rotated),

but are highly dependent on lighting conditions and

are not reliable alone. Although image processing

and morphological operations improve the false

positives, the method still fails to differentiate

between face and anything having similar colours to

skin.

Feature-based detection algorithms aim to locate

faces on the basis of facial features (such as eyes,

eyebrows, nose, mouth, and hair-line). The problem

with this method is that the image features can be

highly variable due to noise, illumination, and

occlusion. So this method may be used to verify the

detected face, but cannot detect the face reliably.

Due to each method’s limitations, they all suffer

from varying conditions (mentioned in Section 1)

and are not able to detect faces reliably.

3 PROPOSED APPROACH

We propose a hybrid approach for human face

detection in static images based on two of the most

widely used algorithms boosted Haar classifiers and

skin colour, both of which are described in Section

2. First of all, the image is processed by a Haar

classifier, because this method is very efficient and

reliable for frontal faces. If this method fails to

detect any face present in image (usually, because of

its limitations as discussed in Section 2), the image

is handed over to a skin colour tester. The skin

colour tester consists of multiple steps including

skin likelihood detection and segmentation of skin

region. The resulting image passes through some

morphological operations, aspect ratio test, and

finally goes through a template matching test. Due to

various operations and tests, skin colour-based

detection is time consuming. If this method fails, the

system automatically adjusts the image brightness

VISAPP 2010 - International Conference on Computer Vision Theory and Applications

242

and lighting conditions. After adjustment, the

possibility of face detection by Haar classifier

increases, so it is again tested by Haar.

We also experimented with an eye-detection test

following face detection to avoid false positives.

While it was effective for some images, the time it

took and the low rate of false positives meant that

we do not need to use it in the final system. Not

using it also makes the system better able to deal

with occlusion and camera pose.

4 EXPERIMENTAL RESULTS

Due to the unavailability of a standard accessible

dataset of RGB images, there is a strong need to

collect a set of images that can evaluate face

detection systems under a wide range of different

conditions (as mentioned in Section 1). By

collecting the images from various ‘accessible’

sources, along with our personal and web images,

we obtained a set of images that seems to fulfil all

possible conditions.

We tested our system on 186 images from the

Psychological Image Collection at Stirling (PICS)

(http://pics.psych.stir.ac.uk, n.d.) and got a detection

rate of 98% with 1 false positive. Peer and Solina

(1999) reported 97.7% average detection rate on 44

images, while Wang and Sung (1999) showed

almost 90% detection rate on 50 randomly selected

images from PICS dataset.

Using 60 images from the MMI facial expression

dataset (Pantic et al., 2005), 35 images from the

Indian face dataset (Jain and Mukherjee, 2002), 100

images from Libor Spacek’s facial image dataset

(Spacek, n.d.), and 13 images from the AR face

dataset (Martinez and Benavente, 1998) we got

100% detection rate with 9, 0, 9 and 1 false positive

respectively. Anisetti et al. (2006) used AR face

dataset testing, which gives 72.9% average detection

rate on images without black sun glasses and yellow

light.

On the XM2VTS (Messer et al., 1999) sample

set (54 frontal, 32 side profile and 2 dark frontal

view images), we got 94% detection rate with 10

false positives. However, it gives 100% detection

rate with 0 false positives on frontal faces only.

Asteriadis, Nikolaidis and Pitas (2009) used only the

frontal faces of XM2VTS dataset and got 99.74%

average detection rate.

On 81 personal photo collections, some other test

sets and the web images we got 97% detection rate

with 12 false positives. Wang and Yuan (2001)

gives 91.1% detection rate on web images, Hsu,

Abdel-Mottaleb and Jain (2002) gives 80.35%

detection rate on personal and news images, and

Garcia (2004) gives 90.5% detection rate on web test

set. On 75 very complicated images from yahoo

news we got 86% detection rate with 12 false

positives.

These images were not rescaled before testing,

have different lighting conditions, multiple facial

expressions, facial hair, glasses, mufflers, hijab,

multiple variations of head poses and camera angle.

As compared to previous researches results, on such

a diverse collection of images, the average result of

97% detection rate on almost 600 images is quite

satisfactory.

Performance Comparison Graph

(using mixed testset of 100 images)

100

Haar Classifiers Skin Colour Detection Proposed Approach

Detection Rate (%)

Time (sec)

Detection Rate (%)

Time (sec)

Figure 1: Performance comparison graph.

We compared the accuracy and efficiency of the

proposed system with the most commonly used face

detection techniques such as the Haar classifier and

skin colour based detection. The methods were

tested against 100 mixed images of varying

conditions. The graph in Figure 1 shows that Haar

classifiers gives 50.25% accuracy in 0.677 seconds

per image, while the skin colour method gives

34.46% accuracy in 12.63 seconds per image, while

our proposed method gives the highest accuracy of

88.50% in 2.54 seconds per image. These results are

obtained by using MATLAB on a Pentium 4 CPU

3.40 GHz with 1.00 GB RAM. The high deviation of

time in the proposed system is caused by the skin

colour detection method being used.

Noise is the most common problem in images,

caused by low quality cameras, foggy environments,

dust, smoke, or motion. We tested our system

against different kind of noises (Salt & pepper noise,

Gaussian noise, and Speckle noise), and got

satisfactory results. Two different datasets, each

having 20 images, were used for testing the noise

resistance. Dataset A contains all frontal face images

and dataset B contains mixed complicated images.

In the case of salt & pepper noise, for dataset A

the system shows 100% accuracy with 70% noise

intensity, while for dataset B it shows up to 80%

A RELIABLE HYBRID TECHNIQUE FOR HUMAN FACE DETECTION

243

accuracy with 60% noise intensity. In the case of

Gaussian noise, the results fluctuate with noise

variance. For dataset A, the system gives 100%

accuracy up to 2% noise variance, while it fluctuates

between 0 and 100 up to 6% variance, while for

dataset B the accuracy fluctuates between 0 and 100

up to 4% noise variance and between 0 to 30 up to

6% variance. Similarly, in the case of Speckle noise,

the results fluctuate with noise variance. For dataset

A, the system gives 100% accuracy up to 2% noise

variance, while it fluctuates between 90-95% up to

10% variance, while for dataset B the accuracy

fluctuates between 85 and 100 up to 5% noise

variance and between 75 to 100 up to 9% variance.

5 CONCLUSIONS

This paper has presented a hybrid system for human

face detection from static images, by combining two

methods and some pre-processing steps that is more

efficient than either and not too much less

computationally efficient than the better of the two.

We have shown that it is fairly robust to common

image problems such as noise and occlusions.

A brief review of the literature is presented along

with the most comprehensive set of RGB images

which fulfils all possible conditions for evaluation of

any face related application. The proposed system is

not complex and covers a wide range of human skin

colours.

We intend to follow two fronts of research from

here. The first is to use these results and extend them

to video images, which will combine tracking with

face detection. We will investigate further

algorithmic speed-ups for this to work in real time.

The second is to use the segmented face for human

emotion recognition which is the main focus of our

research.

REFERENCES

Anisetti, M., Bellandi, V., Damiani, E., Beverina, F.,

Arnone, L. & Rat, B. 2006, ‘A3fd: Accurate 3d face

detection’, Proc. of IEEE Int'l. Conf. on Signal-Image

Technology and Internet Based Systems.

Asteriadis, S., Nikolaidis, N., Pitas, I. 2009, ‘Facial feature

detection using distance vector fields’, Pattern

Recognition,1388-1398.

Garcia, C., Delakis, M. 2004, ‘Convolutional face finder:

A neural architecture for fast and robust face

detection’, IEEE Trans on Pattern Analysis and

Machine Intelligence, 1408–1423.

Hjelmas, E., Low, B. K. 2001, ‘Face Detection: A

Survey’, Computer Vision and Image Understanding,

236-274.

Hsu, R., Abdel-Mottaleb, M., Jain, A. K. May 2002, ‘Face

Detection in Colour Images’, IEEE Trans. on Pattern

Analysis and Machine Intelligence.

Jain, V., Mukherjee, A. 2002, ‘The Indian Face Database’.

Lee, T., Park, S., Park, M. 2005, ‘A New Facial Features

and Face Detection Method for Human-Robot

Interaction’, Proc. of the 2005 IEEE Int'l. Conf. on

Robotics and Automation, 2063-2068.

Lienhart, R., Maydt, J. 2002, ‘An Extended Set of Haar-

like Features for Rapid Object Detection’, IEEE ICIP.

Lin, H., Yen, S., Yeh, J., Lin, M. 2008, ‘Face Detection

Based on Skin Colour Segmentation and SVM

Classification’, Second Int'l. Conf. on Secure System

Integration and Reliability Improvement, 230-231.

Martinez, A. M., Benavente, R. 1998, The AR Face

Database. CVC Technical Report #24.

McDermott, J. 2006, ‘Facial Feature Extraction for Face

Characterization’.

Messer, K., Matas, J., Kittler, J., Luettin, J., Maitre, G.

1999, ‘XM2VTSDB: the extended M2VTS database’.

Pantic, M., Valstar, M. F., Rademaker, R., Maat, L. 2005,

‘Web-based Database for Facial Expression Analysis’,

Proc. IEEE Int'l Conf. Multmedia and Expo.

Peer, P., Solina, F. 1999, ‘An Automatic Human Face

Detection Method’, Proc. of the 4th Computer Vision

Winter Workshop (CVWW’99), 122–130.

Singh, S. Kr., Chauhan, D. S., Vatsa, M., Singh, R. 2003,

‘A Robust Skin Colour Based Face Detection

Algorithm’, Tamkang Journal of Science and

Engineering, 227-234.

Spacek, L., Facial images dataset.

Viola, P., Jones, M. J. 2004, ‘Robust real-time object

detection’, Int'l Journal of Computer Vision, 137-154.

Wang, J. G., Sung, E. 1999, ‘Frontal view face detection

and facial feature extraction using color and

morphological operations’, Pattern Recognition, 1053-

1068.

Wang, Y. Yuan, B. 2001, ‘A novel approach for human

face detection from colour images under complex

background’, Pattern Recognition, 1983-1992.

Yang, M., Kreigman, J., Ahuja, N. 2002, ‘Detecting Faces

in Images: A Survey’, IEEE Trans. On Pattern

Analysis and Machine Intelligence.

VISAPP 2010 - International Conference on Computer Vision Theory and Applications

244
