MIXTURES OF GAUSSIAN DISTRIBUTIONS UNDER LINEAR

DIMENSIONALITY REDUCTION

Ahmed Fawzi Otoom, Oscar Perez Concha and Massimo Piccardi

Faculty of Engineering and IT, University of Technology, Sydney (UTS), Sydney, Australia

Keywords:

Dimensionality reduction, Linear transformation, Random projections, Mixture models, Object classiﬁcation.

Abstract:

High dimensional spaces pose a serious challenge to the learning process. It is a combination of limited

number of samples and high dimensions that positions many problems under the “curse of dimensionality”,

which restricts severely the practical application of density estimation. Many techniques have been proposed

in the past to discover embedded, locally-linear manifolds of lower dimensionality, including the mixture of

Principal Component Analyzers, the mixture of Probabilistic Principal Component Analyzers and the mixture

of Factor Analyzers. In this paper, we present a mixture model for reducing dimensionality based on a linear

transformation which is not restricted to be orthogonal. Two methods are proposed for the learning of all

the transformations and mixture parameters: the ﬁrst method is based on an iterative maximum-likelihood

approach and the second is based on random transformations and ﬁxed (non iterative) probability functions.

For experimental validation, we have used the proposed model for maximum-likelihood classiﬁcation of ﬁve

“hard” data sets including data sets from the UCI repository and the authors’ own. Moreover, we compared the

classiﬁcation performance of the proposed method with that of other popular classiﬁers including the mixture

of Probabilistic Principal Component Analyzers and the Gaussian mixture model. In all cases but one, the

accuracy achieved by the proposed method proved the highest, with increases with respect to the runner-up

ranging from 0.2% to 5.2%.

1 INTRODUCTION

In the pattern recognition literature, it is widely rec-

ognized that high dimensional spaces cause particular

difﬁculties in designing a classiﬁer. One of the rea-

sons is that, in many applications, data points are rep-

resented in a high dimensional space when intrinsi-

cally they lie in a manifold of much lower dimension-

ality. Secondly, high dimensions imply high number

of parameters which makes the computational task of

manipulating and inverting large matrices too expen-

sive. Thirdly, the behaviour and interpretability of

concepts acquired for low dimensionality spaces are

not always generalized to spaces of many dimensions.

Finally, the exponential growth for the need of train-

ing samples with the increasing number of dimen-

sions. The combination of all these severe difﬁcul-

ties that can be present in high dimensional spaces is

called the “curse of dimensionality” (Bellman, 1961).

In order to mollify the curse, classiﬁcation is often

preceded by a dimensionality reduction step where

the original features are combined into a signiﬁcantly

smaller set.

One of the simplest and widely applied techniques

for this purpose is Principle Component Analysis

(PCA). In PCA, the data in the high dimensional

space (P − dimensional) are transformed by an

orthogonal projection into a lower dimensional

space (D − dimensional). This transformation is

performed in a way that maximizes the variance

of the projected data by computing the eigenvalue

decomposition of the data covariance matrix. In

the reduced space, clustering analysis, density mod-

eling and classiﬁcation are carried out often with

higher classiﬁcation accuracy than in the original

space. PCA has proved to be successful in many

applications; however, if the dimensionality of the

feature space is very high, the calculation of the

eigenvectors becomes computationally hard with

a complexity of O(nP

) + O(P

), where n is the

number of data vectors (often, the O(nP

) is the

dominant term). Moreover, variance maximization

may not necessarily lead to high class discrimination.

A simple yet interesting alternative approach is to use

random transformations (Kaski, 1998), (Fodor, 2002).

511

Otoom A., Perez Concha O. and Piccardi M. (2010).

MIXTURES OF GAUSSIAN DISTRIBUTIONS UNDER LINEAR DIMENSIONALITY REDUCTION.

In Proceedings of the International Conference on Computer Vision Theory and Applications, pages 511-518

DOI: 10.5220/0002844005110518

 SciTePress

In this approach, the original data Y is transformed

into the lower dimensional X via: X = WY , where W

is a D x P matrix (D << P) and its columns are re-

alizations of independent and identically distributed

(i.i.d) zero-mean normal variables, scaled to have unit

length (Fodor, 2002). Therefore, the complexity of

computing the random matrix is O(PD). It has been

shown that projecting the data to a random lower-

dimensional subspace yields results comparable to

conventional methods such as PCA, as long as the re-

duced dimension is sufﬁciently large (Kaski, 1998),

(Bingham and Mannila, 2001).

On the other hand, PCA has also been reﬁned as

a maximum likelihood solution for a probabilistic la-

tent variable model, commonly known as Probabilis-

tic PCA (PPCA) (Tipping and Bishop, 1999b). In

PPCA, a P-dimensional observed data vector y can be

described in terms of a D-dimensional latent vector x

as:

y = W x + µ + ε (1)

where W is a P x D matrix describing a linear transfor-

mation and ε is an independent Gaussian noise with

a spherical covariance matrix σ

I. In this direction,

Factor analysis (FA) (Bartholomew, 1987) is closely

related to PPCA, except that the noise is assumed to

have a diagonal covariance matrix.

In recent years, there have been growing inter-

est in developing different techniques for discovering

embedded, locally-linear manifolds of lower dimen-

sionality that extend the above methods including:

mixture of PCA (Hinton et al., 1997), MPPCA (Tip-

ping and Bishop, 1999a), and mixture of FA (Ghahra-

mani and Hinton, 1997), amongst others.

In this paper, we present a novel probabilistic mix-

ture model for dimensionality reduction. Each com-

ponent of the mixture consists of a linear transforma-

tion projecting the original data onto a subspace and

a Gaussian distribution is ﬁtted on the projected data.

This approach is inspired by a sensor fusion analogy,

where each component of the mixture is seen as a

sensor that can capture a good representation of the

original data by ﬁnding the best transformation ma-

trix to represent the data into a new reduced space,

and then, ﬁtting a Gaussian distribution over the trans-

formed data. For this reason and for immediacy, we

have named the proposed method MLiT - mixture of

Gaussians under Linear Transformations.

One of the main novelties of our technique is that

the transformation matrices are not restricted to be or-

thogonal, and this paper explores how this will have

an effect on the ﬁnal classiﬁcation performance. Two

different ways are proposed to learn the model’s pa-

rameters:

i. The ﬁrst approach initializes the transformation

matrices to orthogonal base vectors, and then

learns the parameters of all the transformation ma-

trices and Gaussian distributions in a maximum-

likelihood framework (which might cause the vec-

tors to adopt a non orthogonal arrangement) by

using an Expectation-Maximization (EM) algo-

rithm.

ii. The second approach, faster and less computa-

tionally expensive than the ﬁrst one, assigns the

transformation matrices to random matrices and

ﬁxes the Gaussians based on the sample mean and

covariance. According to (Kaski, 1998), in a high

dimensional space, there are a much larger num-

ber of sufﬁciently close to orthogonal than orthog-

onal vectors that might likely be found by carrying

out a random mapping.

The proposed technique, MLiT, is used to

learn class-conditional likelihoods for maximum-

likelihood classiﬁcation of ﬁve “hard” data sets from

the UCI repository and the authors’ own. Moreover,

our model is compared against the well known MP-

PCA and the conventional Gaussian Mixture Model

(GMM).

This paper is organized as follows: Section 2

presents the proposed method (MLiT), the maximum

likelihood solution, the initialization procedure for

this solution, and the learning of the transformation’s

parameters using random matrices. Section 3 de-

scribes the experiments conducted to evaluate MLiT

over multiple data sets, comparing the results with

state-of-the-art classiﬁers. Finally, in section 4, we

draw our conclusions and discuss future work.

2 APPROACH AND

METHODOLOGY

In this section, we describe MLiT, a method for gen-

erating a mixture distribution in a dimensionally re-

duced space that can be useful for density modelling

and classiﬁcation. We ﬁrst describe the model in the

next subsection. We then present in Subsection 2.2

the maximum-likelihood solution devised to learn the

model from a set of samples. We also discuss the

initialization procedure for this solution. Finally, in

Subsection 2.3, we present another way for learning

the model’s parameters based on random matrices.

VISAPP 2010 - International Conference on Computer Vision Theory and Applications

512

2.1 Mixture of Gaussians under Linear

Transformations (MLiT)

Let us consider a multivariate random variable, y, in

a high, P-dimensional space. We deﬁne the lower,

D-dimensional space through a compressive linear

model

x = Ωy (2)

where Ω is a D ×P real matrix, with D <= P and

typically D << P. We also posit a density function,

p(x), in x-space and consider

f (y) = p(Ωy) = p(x); (3)

f (y) is not a proper density in y-space: rather, a

probability function that repeats the probability den-

sity p(x) for all y points satisfying x = Ωy. As such,

f (y) expresses the probability of the combination of

two distributions: a distribution modelled by p(x) in

the D-dimensional subspace spanned by the rows of

Ω (the retained dimensions); and a uniform distribu-

tion along the (P −D)-dimensional subspace satisfy-

ing equation x = Ωy for any given x (the discarded di-

mensions). For instance, if p(x) is Gaussian, f (y) has

the shape of a Gaussian “ridge” i.e. a D-dimensional

Gaussian function which repeats itself along the di-

rection of x = Ωy in y-space. When referring to its

distributional properties hereafter, we will refer to this

distribution as Gaussian-uniform. Following the sen-

sor analogy, x can be seen as a view of y made avail-

able by a sensor. If the representation power of x is

adequate, it will permit to successfully study prop-

erties of y e.g. classify measurements in classes of

interest.

In general, exploiting an array of M sensors can

offer a richer representation of y than a single sensor.

By calling f (y|l) the probability function for the l-th

sensor in the array, l = 1..M, it holds that:

f (y|l) = p(Ω

y|l) (4)

where we have assumed that each sensor has its

own independent view of y, expressed by Ω

(Kittler,

1998).

Let us now assume that we have a way to estimate

a discrete distribution, p(l), stating the quality of the

l-th sensor at explaining the y sample. From Bayes

theorem, we obtain:

f (y,l) = f (y|l)p(l) = p(Ω

y|l)p(l) (5)

By marginalizing over l, we obtain the probability

function f (y) for the sensor array case:

f (y) =

∑

l=1

f (y,l) =

∑

l=1

f (y|l)p(l) =

∑

l=1

p(Ω

y|l)p(l)

(6)

which closely recalls the general density of a mix-

ture distribution. However, probabilities are com-

puted in subspaces spanned by linear transformations

and such transformations differ for each component.

For simplicity of treatment, we further assume that

the individual sensor densities are Gaussian, and note

= p(l), obtaining:

f (y) =

∑

l=1

N (Ω

y|µ

,Σ

) (7)

where the N (Ω

y|µ

,Σ

) terms are the densities in

the subspaces; means µ

, and covariance matrices Σ

are the parameters of each Gaussian component in the

l-th subspace for l = 1..M; weights α

are the mixing

coefﬁcients.

Once an f (y) density is learnt for each c class,

c = 1..C, maximum likelihood classiﬁcation can be

simply attained as:

∗

= argmax

( f (y|c)) (8)

We note that this model makes no attempt at posi-

tioning the subspaces over clusters of data in y-space

or minimizing reconstruction errors. As such, the

number of views is not in correspondence with the

number of clusters in the sample set. Rather, each

view is justiﬁed by a good likelihood ﬁt i.e. providing

high within-class invariance.

2.2 Maximum Likelihood (ML)

Solution

We propose maximum likelihood as one way for

jointly ﬁnding the parameters θ

= {α

,µ

,Σ

,Ω

}

l=1

To this aim, we consider a set of i.i.d. observations,

Y =

{

}

i=1..N

, in the high dimensional space. Our

goal is then that of ﬁnding values for parameters of

(7) maximizing likelihood

L(θ) = p(Y |θ) =

∏

i=1

f (y

) =

∏

i=1

(

∑

l=1

N (Ω

|µ

,Σ

))

(9)

where θ = {Ω

,α

,µ

,Σ

} and l = 1..M. As usual

in similar cases, rather than attempting maximization

of (9) directly, we adopt an EM approach. This re-

quires positing the existence of a set of discrete, M-

valued latent variables, Z =

{

}

i=1..N

, whose mini-

mum requirement is that the expression of joint prob-

ability function f (y

,Z) be simpler than f (y

) itself.

MIXTURES OF GAUSSIAN DISTRIBUTIONS UNDER LINEAR DIMENSIONALITY REDUCTION

513

The target for maximization is the expected value of

the complete-data log-likelihood,

Q(θ,θ

) =

∑

[ln(p(Y,Z|θ)p(Z|Y,θ

)] (10)

where θ and θ

represent the new and old parame-

ters in the EM iterations, respectively. In (10), Z rep-

resents a single realization of the entire set of the la-

tent variables and the summation extends over all its

possible M

values. The whole derivation has been

presented by the authors in a previous work.

The E-step computes p(z

= l|y

,θ

), or p(l|y

,θ

)

for brevity, which is the responsibility of the l-th com-

ponent for the y

sample (Bishop, 2006).

p(l|y

,θ

) =

N (Ω

|µ

,Σ

)

∑

k=1

N (Ω

|µ

,Σ

)

(11)

Maximizing (10) leads to the following M-step for

the parameters:

∑

i=1

p(l|y

,θ

) (12)

∑

i=1

Ω

p(l|y

,θ

)

∑

i=1

p(l|y

,θ

)

(13)

i=1

(Ω

−µ

)(Ω

−µ

)

p(l|y

,θ

)

∑

i=1

p(l|y

,θ

)

(14)

For the maximization of Ω

, we considered this

matrix as P,D ×1 column vectors, Ω

= (w

)

, j =

1..P, and we update it column by column, rather than

the whole matrix at once. Therefore, the re-estimation

formula for (w

)

is the following:

)

∑

i=1

(−(w

)

−... −(w

)

+ µ

p(l|y

,θ

)

∑

i=1

p(l|y

,θ

)

(15)

where N is the number of samples, (w

)

, j = 2..P

are the other columns’ “old” values, θ

represent the

model’s old parameters.

Two important issues may occur as a result of the

projection step:

i. the component densities across the mixture model

and across different classes, can be different in

scale. By this, we mean that the linearly trans-

formed space (the x-space) does not have a de-

ﬁned scale; therefore, likelihood p(x) can be made

arbitrarily larger or smaller by changes to the scale

of x.

ii. as a consequence of this and the maximum-

likelihood target, the scale of x may tend to 0

along iterations to endorse high values of p(x). In

turn, this implies that the projection matrix may

also tend to zero (an undesirable solution that we

call degenerate or singular hereafter).

In order to avoid these problems, we propose the

normalization of the projection matrix at each step of

the EM algorithm; henceforth, we refer to this method

as MLiT (Normalized) or MLiT (N). By equating the

concept of norm to that of scale, this will make the

densities of equal scale across the different compo-

nents, and also across different classes. Further, this

will avoid Ω

reaching the degenerate solution and act

as a likelihood regularization. Therefore, after each

EM step, we normalize Ω

as follows:

Ω

Norm(Ω

)

(16)

We have tried several norms (L1, L2, Inﬁnity and

Frobenius), with the Frobenius norm providing the

highest and most stable results. Therefore, in the fol-

lowing, we report results based on this norm:

Frobenius norm(Ω

) =

∑

diag(Ω

Ω

) (17)

Thus, MLiT (N) searches for possible solutions

over the likelihood space. Every time a solution is

provided by the maximization step of EM, we nor-

malize the projection matrix Ω

in order to keep it

on an equal scale. The expectation-maximization

steps become therefore expectation-maximization-

normalization steps. An obvious disadvantage of this

approach is that the new normalized solution might

or might not have higher likelihood than the previ-

ous normalized solution. For this reason, we monitor

the evolution of the likelihood along the iterations and

elicit ad-hoc convergence criteria.

2.2.1 Initialization Phase

In EM, the parameter values traversed along the it-

erations and the likelihood value achieved at conver-

gence may strongly depend on the parameters’ initial

values. For our approach, we choose to apply a deter-

ministic initialization to ensure repeatable results at

each run. Namely, we decided to initialize the pro-

jection matrix, Ω, by the orthonormal transformation

provided by PCA, selecting either the largest or the

smallest eigenvectors (i.e. the eigenvectors associ-

ated with the largest and smallest eigenvalues, respec-

tively).

Projecting the data by the largest eigenvectors

transforms them into a space where their variance

VISAPP 2010 - International Conference on Computer Vision Theory and Applications

514

is maximized and, under the hypothesis that their

distribution be Gaussian, the likelihood is minimum

amongst all orthonormal projections (Bolton and

Krzanowski, 1999), and therefore forcing the EM to

explore a large region of the parameter space before

convergence. Conversely, projecting them with the

smallest eigenvectors transforms them into a space

where their variance is minimized and likelihood is

maximum.

In our experiments, we noticed that there is no cer-

tain initialization method that always provide the best

classiﬁcation accuracy. Thus, we experiment with

both methods and choose the one providing better ac-

curacy results.

As the data per class are projected to each of the

components, the remaining initial parameters of the

EM algorithm are chosen as follows:

• The initial mean µ

and covariance matrix Σ

each component will be the sample mean and

covariance computed directly from the projected

data of each component, x

– µ

∑

n=1

– Σ

N−1

∑

n=1

−µ

)(x

−µ

)

• The initial priors α

for l = 1..M, are chosen to be

equal across all the components:

– α

2.3 Random Transformations Solution

In this subsection, we present another method for

learning the transformation matrix, Ω

, based on us-

ing random matrices (MLiT (R)). The main idea is to

use random matrices of Gaussian distributed elements

and with unit length columns. This idea is moti-

vated by the Johnson-Lindenstrauss lemma (Johnson

and Lindenstrauss, 1984): if points in a feature space

Y (P-dimensional) are projected onto a randomly se-

lected subspace of suitable high dimension D, then the

distances between the points are approximately pre-

served if D is large enough.

<(||φ(y

) −φ(y

)||

−||y

−y

)

≤

||(y

) −(y

)||

(18)

where || ||

and || ||

denote the Euclidean dis-

tance norms in V

and V

, respectively, and <>

the average over all possible isotropic random choices

for the unit vectors deﬁning the random mapping φ.

In our case, we chose the elements of the Ω

be drawn from a zero-mean normal distribution with

a variance of 1/

√

P, where P is the original space

dimension. The columns of Ω

are then normalized

to be unitary vectors. Moreover, we decided to have

the same transformation matrices across all classes.

Thus, with the above settings, the scale of the trans-

formation matrices is comparable.

After transforming the data of each class as: X

Ω

Y , we ﬁx a Gaussian distribution over the trans-

formed data and the mixture parameters are as fol-

lows:

• The priors α

for l = 1..M, are chosen to be equal

across all the components.

• The ﬁnal mean µ

and covariance matrix Σ

each component are the sample mean and covari-

ance, computed directly from the projected data

of each component, x

3 EXPERIMENTS AND ANALYSIS

The empirical evaluation of a classiﬁer’s accuracy re-

quires extensive testing over multiple data sets and

a comparative analysis with existing, state-of-the-art

classiﬁers. To this aim, in this section we present de-

tails on the data sets used and experiments conducted.

3.1 Data Sets

We evaluate the proposed method on ﬁve data sets,

four of which are selected from the UCI Machine

Learning Repository (Asuncion and Newman, 2007),

and are widely used by the pattern recognition com-

munity for evaluating learning algorithms. These four

data sets are the Vehicle data set, Wisconsin Diagnos-

tic Breast Cancer data set (WDBC), Wisconsin Prog-

nostic Breast Cancer (WPBC) data set, and Optical

Handwritten Digits data set (OpticDigit). The last

data set, named Public Premises Video Surveillance

data set (PPVS), was collected by the authors them-

selves.

The Vehicle data set involves classiﬁcation of a

given silhouette as one of four types of vehicles,

namely, “bus”, “Opel”, “Saab” and “van”. The ve-

hicle silhouettes are described by various shape mea-

surements. The rationale for choosing this data set is

that it is the most similar in the UCI repository to our

own data set and can offer a comparative insight into

the method’s performance. The WDBC and WPBC

data sets contain various shape features from images

of ﬁne needle aspirates (FNA) of breast mass for diag-

nosis and prognosis of breast cancer. The OpticDigit

data set is based on rescaled bitmaps of handwritten

digits: the original 32x32 black and white bitmaps

are divided into non-overlapping blocks of 4x4 pixels

and the number of ‘on’ pixels counted in each block,

MIXTURES OF GAUSSIAN DISTRIBUTIONS UNDER LINEAR DIMENSIONALITY REDUCTION

515

Table 1: Comparative summary of the data sets used.

Data set # Features # Instances # Classes

Vehicle 18 846 4

OpticDigit 64 5620 10

WDBC 30 569 2

WPBC 33 198 2

PPVS 44 600 4

resulting in a 64-dimensional feature vector of homo-

geneous features. The Public Premises Video Surveil-

lance data set (PPVS) is based on video footage pro-

vided by an industrial partner. It involves classiﬁca-

tion of an object in a video surveillance environment

into one of four classes: “trolleys”, “bags”, “single

persons”, and “groups of people”. The images of

these objects have been clipped from video footage

acquired at a number of airports and train stations

world-wide. The feature set consists of statistics of

various local features such as line segments, circles,

corners, and global shape descriptors such as ﬁtted

ellipses and bounding boxes. This feature set is de-

scribed in detail in (Otoom, 2007).

As we can conclude from the previous paragraphs

and the data displayed in Table 1, there are major

differences between these ﬁve data sets in terms of

the nature of data and application context, number

of instances available, number of features extracted,

types of features used for representation and number

of classes. Therefore, the chosen data sets offer a suit-

able basis for comparative analysis.

3.2 Experiments

In this subsection, we present classiﬁcation results for

the proposed method on the ﬁve aforedescribed data

sets. We compare the performance of our approach

with that of mixture of PPCA (MPPCA) and Gaussian

mixture model (GMM). Experiments with these clas-

siﬁers were carried out in MATLAB by setting all tun-

able parameters in the most genuine way to achieve

the highest performance. We summarize below the

main parameters, and in Table 2, we report the values

that achieved the best accuracy results. The parame-

ters are as follows:

• GMM: There is one main parameter, the number

of the GMM components (M).

• MPPCA: There are two main parameters, the

number of reduced dimensions (D), and the num-

ber of mixture components (M).

For MLiT, the parameters to adjust are selected as

follows:

• The number of the mixture components (M) and

reduced dimensions (D) were manually selected

as reported in Table 2.

• For MLiT (N):

– The initial transformation matrices for each

class, Ω

[0]

, were computed by using either the

smallest or the largest consecutive eigenvectors

of the covariance matrix of the original data.

For example, in the case of largest eigenvec-

tors, two components per class (M = 2), and a

reduced space of three dimensions (D = 3), we

select the three ﬁrst eigenvectors for Ω

[0]

and

the eigenvectors between the third and the ﬁfth

for Ω

[0]

– Initial transformed data: X

[0]

= Ω

[0]

Y , l = 1..M.

– Initial means, µ

[0]

, and variances, Σ

[0]

, l = 1..M:

from the initial transformed data.

– Equal initial priors for all components, α

[0]

, l = 1..M.

• For MLiT (R):

– Ω

is chosen randomly from a 1-D zero-mean

Gaussian distribution with a variance of 1/

√

– The priors α

for l = 1..M, are chosen to be

equal across all the components: α

– The mean µ

and covariance matrix Σ

of each

component are the sample mean and covari-

ance, computed directly from the projected data

of that component, x

As stopping criteria, for MLiT (N) the normal-

ization step does not guarantee a monotonic increase

in the likelihood; hence, we elicit an ad-hoc criteria

for stopping by running the EM algorithm for 50 it-

erations and choosing that delivering the maximum

accuracy by cross-validation. For MPPCA, we ob-

served that the accuracy stabilized after 200 iterations.

For GMM, instead, accuracy stabilization was empir-

ically achieved after 50 iterations. For validation, we

have chosen 5-fold cross-validation since it offers a

good trade off between the large bias of the hold-out

method and the large variance of the leave-one-out

method (Breiman and Spector, 1992). This implies

randomly partitioning the data set into ﬁve disjoint

subsets, training the classiﬁer with four and using the

last for testing. Classiﬁcation accuracy is averaged

over ﬁve runs by using, in turn, each fold for testing.

We express classiﬁcation accuracy simply as the per-

centage of correctly classiﬁed instances with respect

to their total number:

accuracy =

number of correctly classiﬁed samples

total number of samples

(19)

VISAPP 2010 - International Conference on Computer Vision Theory and Applications

516

Table 2: Results for 5-fold CV in terms of accuracy (%) and standard deviation, on ﬁve data sets and across different classiﬁers,

with the highest indicated in boldface font. For each dataset, the ﬁrst row presents the main parameters’ values for different

classiﬁers, and the second row shows the achieved accuracy (%).

Classiﬁer MLiT (N) MLiT (R) MPPCA GMM

Parameters D M D M D M M

Dataset

PPVS 33 1 30 2 25 2 2

(%) 76.7 ±2.4 78.5 ±2.0 73.5 ±4.0 73.3 ±2.1

Vehicle 14 2 18 2 10 2 2

(%) 85.6 ±1.9 84.3 ±2.1 83.6 ±1.3 82.8 ±1.9

OpticDigit 29 2 35 5 16 1 2

(%) 98.4 ±0.3 98.3 ±0.3 98.6 ±0.4 96.9 ±0.3

WDBC 18 1 20 4 20 2 2

(%) 96.1 ±1.7 95.9 ±1.9 94.7 ±1.7 95.9 ±1.8

WPBC 4 4 25 2 15 4 4

(%) 77.4 ±1.1 76.9 ±1.8 76.9 ±0.0 75.9 ±1.4

It is important to note that, in the following, we

report the classiﬁcation results in terms of two sta-

tistical measures: average accuracy over the various

runs, and standard deviation. However, we chose the

average accuracy as the main measure for comparing

the different classiﬁers; nevertheless, the standard de-

viation is an important measure for the precision of

the classiﬁcation accuracy, and it can be considered

together with the accuracy for a better estimate of the

classiﬁcation performance.

Table 2 reports the best results of 5-fold cross-

validation on the various data sets and across the com-

pared classiﬁers. We note that in this table, for MLiT

(N), all results are obtained with largest eigenvectors

initialization except the cases of Vehicle and WPBC

data sets. It is clear from this table that, in all cases

(except the PPVS data set), MLiT (N) has slightly

outperformed the performance of MLiT (R), proving

that the maximum likelihood solution can be a bet-

ter learning method in comparison to that of learn-

ing based on random matrices. However, the mar-

gin of improvements is not very high, which indi-

cates that the random transformations solution can de-

liver promising results with less computation. We can

also note from Table 2 that the performance of MLiT

outperformed that of MPPCA on four out of the ﬁve

compared data sets with improvements ranging from

0.5% to 5.0%, proving the strength of MLiT against

a state-of-the-art classiﬁer (MPPCA has slightly out-

performed MLiT by 0.2% only on the OpticDigit data

set). Moreover, we can note that, in all cases, the per-

formance of MLiT outperformed that of GMM with

improvements ranging from 0.2% to 5.2%. This il-

lustrates the ability of MLiT in overcoming the curse

of dimensionality and providing better performance

in the reduced space. MPPCA has also provided bet-

ter classiﬁcation results than GMM on majority of the

data sets.

Overall, the experiments on the ﬁve data sets pre-

sented in this section showed that MLiT reported

higher experimental accuracy over both compared

classiﬁers (except the case of OpticDigit where MP-

PCA slightly outperformed MLiT). Interpretation of

accuracy results in high dimensional spaces is not im-

mediate. In the case of the ML solution, we lean

to attribute these improvements in accuracy to the

Gaussian-uniform distribution property of focussing

on invariant features. This permits the building

of compact models that have proved discriminative

when used with the Bayes inversion rule, while it

introduces elements of robustness since outliers are

ousted to the discarded dimensions during training

as much as possible. The non-orthogonality of the

transformation adds further degrees of freedom to the

model. However, this feature seems to be used only to

a limited extent since the maximum accuracy is often

achieved during the very ﬁrst iterations of EM, when

the transformation only mildly deviates from orthog-

onality. In these terms, both the maximum likelihood

and random solutions are often close to orthogonal

transformations.

4 CONCLUSIONS

In this paper, we have presented a method for lin-

ear dimensionality reduction within mixture distribu-

tions. The model that we have proposed for the class-

conditional likelihood is a mixture of Gaussian distri-

butions under linear transformations (7). This model

MIXTURES OF GAUSSIAN DISTRIBUTIONS UNDER LINEAR DIMENSIONALITY REDUCTION

517

equates to a uniform distribution along the discarded

dimensions and a full Gaussian model along the re-

tained dimensions.

It is important to contrast this model properly to

the several existing methods for linear dimensionality

reduction in mixture models such as mixtures of PCA,

PPCA, and FA. One of the main points of difference is

that the linear transformation is not restricted to be or-

thogonal. Further, the linear model adopted, x = Ωy,

does not assume additive noise models and makes x

observable. On the ground of that, we can evaluate

density N (Ωy|µ,Σ) = N (x|µ,Σ) directly in x-space.

For learning the model, we have presented two differ-

ent methods; the ﬁrst method learns the model’s pa-

rameters in a maximum likelihood framework (MLiT

(N)). Normalization is proposed as a way to regular-

ize this solution. Thus, a common scale is imposed

to all the transformations and a singularity problem

is avoided. Another simple yet powerful method for

learning the model’s parameters can be based on ran-

dom matrices (MLiT (R)). This method has offered

promising and computationally feasible results. How-

ever, the maximum likelihood solution delivered bet-

ter accuracy results in majority of the data sets sug-

gesting that it can be a better way for learning the

model’s parameters.

The experimental performance of MLiT has

proved to outperform that of MPPCA and GMM in al-

most all cases with improvements ranging from 0.2%

to 5.2% compared to the runner-up. The only case

where MLiT did not deliver the best accuracy is on

the OpticDigit data set where it was slightly outper-

formed by MPPCA by 0.2%. In addition to visual ob-

ject classiﬁcation, the proposed method permits gen-

eral application for density modeling and classiﬁca-

tion of other continuous numerical data requiring di-

mensionality reduction. Moreover, its re-estimation

formulas can be easily extended to suit boosting and

other weighted maximum likelihood targets and adapt

to a variety of pattern recognition frameworks.

ACKNOWLEDGEMENTS

The authors wish to thank the Australian Research

Council and iOmniscient Pty Ltd that have partially

supported this work under the Linkage Project fund-

ing scheme - grant LP0668325.

REFERENCES

Asuncion, A. and Newman, D. (2007). UCI machine learn-

ing repository.

Bartholomew, D. J. (1987). Latent Variable Models and

Factor Analysis. Charles Grifﬁn & Co. Ltd., London.

Bellman, R. (1961). Adaptive control processes - A guided

tour. Princeton University Press, Princeton, New Jer-

sey.

Bingham, E. and Mannila, H. (2001). Random projection in

dimensionality reduction: applications to image and

text data. In Proceedings of the 7th ACM SIGKDD In-

ternational Conference on Knowledge Discovery and

Data Mining (KDD-2001), pages 245–250.

Bishop, C. M. (2006). Pattern Recognition and Machine

Learning. Springer.

Bolton, R. J. and Krzanowski, W. J. (1999). A characteri-

zation of principal components for projection pursuit.

The American Statistician, 53(2):108–109.

Breiman, L. and Spector, P. (1992). Submodel selection and

evaluation in regression: The x-random case. Interna-

tional Statistical Review, 60(3):291–319.

Fodor, I. (2002). A survey of dimension reduction

techniques. Technical Report UCRL-ID-148494,

Lawrence Livermore National Laboratory.

Ghahramani, Z. and Hinton, G. (1997). The EM algorithm

for mixtures of factor analyzers. Technical Report

CRG-TR-96-1, University of Toronto.

Hinton, G. E., Dayan, P., and Revow, M. (1997). Modeling

the manifolds of images of handwritten digits. IEEE

Transactions on Neural Networks, 8(1):65–74.

Johnson, W. B. and Lindenstrauss, J. (1984). Extensions

of lipschitz mappings into a hilbert space. In Confer-

ence in modern analysis and probability, Contempo-

rary Math, volume 26, pages 189–206.

Kaski, S. (1998). Dimensionality reduction by random

mapping: Fast similarity computation for clustering.

In Proceedings of IJCNN’98, International Joint Con-

ference on Neural Networks, volume 1, pages 413–

418. IEEE Service Center.

Kittler, J. (1998). Combining classiﬁers: A theoreti-

cal framework. Pattern Analysis and Applications,

1(1):18–27.

Otoom, A. e. a. (2007). Towards automatic abandoned ob-

ject classiﬁcation in visual surveillance systems. In

Asia-Paciﬁc Workshop on Visual Information Process-

ing, pages 143–149, Tanian, Taiwan.

Tipping, M. E. and Bishop, C. M. (1999a). Mixtures of

probabilistic principal component analyzers. Neural

Computation, 11(2):443–482.

Tipping, M. E. and Bishop, C. M. (1999b). Probabilistic

principal component analysis. Journal of the Royal

Statistical Society: Series B (Statistical Methodol-

ogy),, 61(3):611–622.

VISAPP 2010 - International Conference on Computer Vision Theory and Applications

518
