EFFECTIVENESS AND PREFERENCES

OF ANTHROPOMORPHIC FEEDBACK

IN A STATISTICS CONTEXT

Pietro Murano and Nooralisa Mohd Tuah

School of Computing, Science and Engineering, University of Salford, Gt. Manchester, M5 4WT, U.K.

Keywords: Usability, Evaluation, Anthropomorphism, Interface Feedback.

Abstract: This paper describes an experiment and its results concerning research that has been going on for a number

of years in the area of anthropomorphic user interface feedback. The main aims of the research have been to

examine the effectiveness and user satisfaction of anthropomorphic feedback. The results are useful to all

user interface designers wishing to improve the usability of their products. There is still disagreement in the

research community concerning the usefulness of anthropomorphism at the user interface. This research is

contributing knowledge to the aim of discovering whether such approaches are effective and liked by users.

The experiment described in this paper, concerns the context of statistics tutoring/revision, which is part of

the domain of software for in-depth learning. Anthropomorphic feedback was compared against an

equivalent non-anthropomorphic feedback. The results indicated the anthropomorphic feedback to be

preferred by users for some factors. However the evidence for effectiveness was inconclusive.

1 INTRODUCTION

The usability of a system is sometimes neglected by

software developers. However the usability of a

software system and particularly the user interface is

paramount to a system being successful in terms of

user satisfaction, efficiency and success as a

commercial product.

The aim of this research is to further knowledge

concerning which types of feedback are effective

and liked by users, particularly the authors are

investigating the appropriateness of

anthropomorphism at the user interface.

Anthropomorphism at the user interface usually

involves some part of the user interface, taking on

some human quality (De Angeli, Johnson, and

Coventry, 2001), e.g. a synthetic character acting as

an assistant to users. Video of a human may also be

viewed as being anthropomorphic (Bengtsson,

Burgoon, Cederberg, Bonito and Lundeberg, 1999).

Lastly various commercial objects have also been

anthropomorphised (DiSalvo and Gemperle, 2003).

Anthropomorphic feedback has been researched

for several years by various researchers around the

world. Despite a reasonable amount of research

being conducted in this area, there is still

disagreement amongst researchers regarding the

usefulness of anthropomorphism at the user

interface. Some studies have shown

anthropomorphic feedback to be more effective and

preferred by users and in some other studies the

converse has been shown. This kind of disparity can

also be seen in the work of Murano and his

collaborators (see Murano, 2002a, 2002b, 2003,

2005, Murano, Gee and Holt, 2007 and Murano, Ede

and Holt, 2008).

An early study conducted by one of the authors

(Murano, 2002b, 2005), concerned the context of

English as a foreign language pronunciation. This

was in the domain of software for in-depth learning.

In this study, anthropomorphic and non-

anthropomorphic feedback types were compared.

Participants were given a series of pronunciation

tasks and they were scored according to their self-

correction success, based on automated feedback

given to them during the experimental sessions. The

feedback was varied as being either

anthropomorphic or non-anthropomorphic. The data

collected for this experiment showed with

significant results that the anthropomorphic

feedback was more effective and preferred by users.

However in another study by Hongpaisanwiwat

and Lewis (2003) in the tutoring type context, the

authors investigated animated characters and voices

in the context of graphics tutoring. They specifically

143

Murano P. and Mohd Tuah N. (2010).

EFFECTIVENESS AND PREFERENCES OF ANTHROPOMORPHIC FEEDBACK IN A STATISTICS CONTEXT.

In Proceedings of the 12th International Conference on Enterprise Information Systems - Human-Computer Interaction, pages 143-148

 SciTePress

dealt with participants’ understanding and

concentration in learning in relation to a set of

learning materials. Their experiment had three

conditions. These were an animated character, a

‘pointing finger’ and no character. Further, within

these conditions they used synthetic or human

voices. The authors also factored into the

investigation some human personality types.

The general results of the experiment were that

there was no significant difference in understanding

for participants using the animated character. No

significance was found with the synthetic character

condition or the type of voices used in relation to

what the participants remembered. An interaction

effect was observed showing the animated character

with synthetic voice condition to be better at helping

participants remember relevant aspects of the

learning materials, compared with the animated

character with human voice. No significance or

interaction effects were observed for the personality

type groups, type of voice used and the animated

character condition. Furthermore, the personality

type, type of voice and animated character did not

have any main effect on the participants

remembering items which had been specifically

emphasised. Further interaction effects were

observed showing that the amount of emphasised

items remembered by participants using the

‘pointing finger’ and no character conditions with a

human voice was greater than participants using the

synthetic voice. Also, participants remembered more

in the animated character with synthetic voice

condition compared with the animated character

with human voice condition. There were no

significant differences concerning participants’

subjective opinions of the learning materials.

An interesting study was also conducted by

Moundridou and Virvou (2002) in a software

algebra tutor context. They examined the effects of

using an anthropomorphic ‘conversational’ agent.

Two conditions were tested in an experiment. The

first condition had a synthetic face and

accompanying voice. The second condition was the

same as the first condition, but had the agent

removed and was replaced by textual messages. The

information presented was equal under both

conditions.

The main findings of the experiment were that

the time taken for the algebra tasks was not

significantly different for the two groups.

Questionnaire responses to do with participant

attitudes towards the experienced user interface,

showed significant results in favour of the

anthropomorphic agent. Participants tended to enjoy

the system more, finding it more useful and less

difficult to use. Furthermore in relation to a post-test

administered to the participants, there were no

statistically significant results to suggest that the

anthropomorphic agent helped participants to

complete the test in a faster time with better overall

results.

The remainder of this paper has two further main

sections. Section 2 describes the conducted

experiment, along with the main results and

experimental conclusions. Section 3 discusses

overall conclusions along with some proposals for

further work.

2 STATISTICS EXPERIMENT

2.1 Aims

The aim of this experiment was to gather data

concerning the effectiveness (i.e. errors and task

time) and user satisfaction of different feedback

types in the context of software aiding users to

revise or remind themselves of how to carry out

statistical procedures without the use of a statistical

application. This could potentially help students

either coming back to use statistics after some time

and therefore requiring some reminders, or it could

help students studying a basic course in statistics.

Two feedback types were tested –

anthropomorphic and non-anthropomorphic. The

anthropomorphic feedback was in the form of an

animated character (Media Semantics, 2009)

uttering the required instructional content feedback,

while the non-anthropomorphic feedback consisted

of textual content.

2.2 Users

 24 participants, with a university education,

took part in the experiment.

 All the participants in the study were in the

21-35 age range.

 A combination of male and female

participants were used.

 All the participants had some knowledge of

basic statistics. However all participants

had not used statistics for some time and

had been taught the subject some time in

the past.

 All participants had a basic knowledge of

using a computer for general tasks.

2.3 Design

A between users design was used, where all 24

participants were randomly assigned to one of the

ICEIS 2010 - 12th International Conference on Enterprise Information Systems

144

two conditions being tested. A between users design

was chosen because this would avoid learning

effects in the carrying out of the tasks.

2.4 Variables

The independent variable was the type of feedback

(instructions uttered by the animated character and

textual instructions) and the type of tasks, consisting

of viewing some instructional material and then

taking part in a quiz.

The dependent variables were the participants'

performance in carrying out the tasks and their

subjective opinions.

The dependent measures were that the

performance was measured by task completion

success, i.e. whether a participant completed quiz

questions correctly and the time taken to complete a

quiz question. The subjective opinions were

measured using a post-experiment questionnaire

questionnaire had various questions relating to the

general user interface and the participants'

experience of using the prototype system.

2.5 Apparatus and Materials

The experiment was conducted using two rooms.

The first room was used as a waiting room, while the

second room housed the computers with the installed

prototype system.

The second room contained four high end

laptops with similar specifications. Each had the

prototype system installed.

Headphones were used for the anthropomorphic

condition, so that the same venue could be used for

up to four participants at a time. The headphones

allowed each participant in the anthropomorphic

condition to listen to the verbal utterances without

disturbing other participants.

Each participant was given a sheet of paper and a

pen for note taking and calculation purposes.

Two questionnaires were designed and used in

this experiment. A pre-experiment questionnaire was

used for recruitment purposes and a post-experiment

questionnaire was used for eliciting subjective

opinions. The pre-experiment questionnaire

contained some basic personal questions, e.g. age

group etc. There were also questions about computer

experience and statistics experience. The post-

experiment questionnaire contained questions, using

Likert type scales, eliciting opinions on the user

interface and its components, the instructional

material, the quiz and the participants’ feelings

during the interaction.

2.6 Procedure and Tasks

The first step was to recruit suitable participants who

had some basic computer usage experience and

some knowledge of basic statistics. However it was

a requirement that the sample used should not have

been using statistics recently and had not been

learning about statistics recently. This was because

the prototype developed was specifically dealing

with the context of giving a user a reminder of how

to calculate certain statistical tests and/or help

someone learning some basic statistics. The

recruitment was achieved by using an appropriate

pre-experiment questionnaire.

The pre-experiment questionnaires were

completed in room 1 and assuming the volunteers

had the required profile, they were then asked to

move to room 2 containing the laptops. This was

done in clusters of four, since there were four

laptops. Then the participants were given a brief

verbal overview of the experiment and some basic

instructions regarding how the experiment would be

done. At this point each participant was given a

sheet of paper with some details of the system and

the details of the tasks they would do.

At all times during the experiment, three

experiment assistants were present to observe users

and provide help as required (although no help that

would aid in completing the tasks was given). Prior

to the experiments taking place, a meeting was held

with all experiment assistants so that during the

experiment sessions, consistency could be

maintained between the assistants. The main

consistency issue involved treating participants in

the same manner regardless of experimental

assistant.

The next step involved showing and explaining

to participants how the system worked. Following

this, the experiment began by participants listening

to or reading (depending on experimental condition)

an introductory part of the prototype. This then led

to the actual tutorial section, which gave some

instruction on some basic statistical 'tests'. When this

was completed participants would go to the quiz

section, where they would attempt some similar

statistical problems to those discussed in the tutorial.

The system recorded the time to complete each

quiz question and if the solution provided was

correct. Participants were also observed and any

issues were recorded on an observation protocol.

At the end of the tasks, participants completed a

post-experiment questionnaire which dealt with

subjective opinions. When this was completed,

EFFECTIVENESS AND PREFERENCES OF ANTHROPOMORPHIC FEEDBACK IN A STATISTICS CONTEXT

145

participants were debriefed and then lunch was

provided for them as a reward for their participation.

Overall each participant spent approximately 30-

40 minutes on the tasks. The actual tasks in the

experiment involved listening to instructional

material about calculating the mean, median, mode,

range, standard deviation and variance. Then quiz

questions had to be answered for each of these areas

of concern. Only one attempt per question was

allowed for all quiz questions.

2.7 Results

The data were analysed in terms of their

distributions, particularly the means and standard

deviations. Significance testing was carried out by

means of t-tests for between users designs. Where a

significant result was observed, relevant tables are

shown below. However for brevity, no tables are

provided in instances of insignificant results.

Firstly the distribution tables are provided below

(tables 1 -5) for the statistically significant data.

Overall these show low standard deviations,

indicating consistency in the participants’ scoring.

Table 1: Helpfulness of Screen Appearance.

Mean

4.58

Std Dev

0.50

Std Err Mean

0.10

upper 95% Mean

4.80

lower 95% Mean

4.37

Table 2: Precise Instructions.

Mean

4.5

Std Dev

0.51

Std Err Mean

0.10

upper 95% Mean

4.72

lower 95% Mean

4.28

Table 3: Helpful Text Formatting.

Mean

4.71

Std Dev

0.46

Std Err Mean

0.09

upper 95% Mean

4.90

lower 95% Mean

4.51

Table 4: Specific Quiz Questions.

Mean

4.46

Std Dev

0.51

Std Err Mean

0.10

upper 95% Mean

4.67

lower 95% Mean

4.24

Table 5: Will Use Info Elsewhere Agree/Disagree.

Mean

4.83

Std Dev

0.38

Std Err Mean

0.08

upper 95% Mean

4.99

lower 95% Mean

4.67

For effectiveness issues, the times taken for quiz

questions and the rate of correct solutions provided

for the quiz questions were each analysed by means

of a t-test. These did not reveal any significance.

All of the responses provided by the participants

through the post-experiment questionnaire were also

analysed by means of t-tests. The post-experiment

questionnaire contained questions, using Likert type

scales, eliciting opinions on the user interface and its

components, the instructional material, the quiz and

the participants’ feelings during the interaction. The

scales used, ranged from one to five. In most cases

(and in all cases for the tables below) one reflected

the most negative opinion and five reflected the

most positive opinion. Four questions concerning the

participants’ feelings during the interaction used the

one score to reflect a positive response (not shown

below due to insignificant results).

For the variables ‘helpfulness of screen

appearance’ and ‘group’, the anthropomorphic

feedback is significantly (p<0.01) rated as being

more helpful than the non-anthropomorphic

feedback. The t-observed is 2.76**. This can be seen

in Table 6 below:

Table 6: Helpfulness of Screen appearance, Anth

(Anthropomorphic) vs Non-Anth (Non-Anthropomorphic).

Difference

0.50

t Ratio

2.76

Std Err Dif

0.18

20.89

Upper CL Dif

0.88

Prob > |t|

0.01

Lower CL Dif

0.12

Prob > t

0.01

Confidence

0.95

Prob < t

0.99

For the variables ‘precise instructions’ and

‘group’, the anthropomorphic condition is

significantly (p<0.01) rated as being more precise

than the non-anthropomorphic condition. The t-

observed is 2.71**. This can be seen in Table 7

below:

ICEIS 2010 - 12th International Conference on Enterprise Information Systems

146

Table 7: Precise Instructions, Anth vs Non-Anth.

Difference

0.50

t Ratio

2.71

Std Err Dif

0.18

Upper CL Dif

0.88

Prob > |t|

0.01

Lower CL Dif

0.12

Prob > t

0.01

Confidence

0.95

Prob < t

0.99

For the variables ‘text formatting’ and ‘group’,

the text formatting in the non-anthropomorphic

condition is significantly (p<0.05) rated as being

better than the text formatting in the

anthropomorphic condition. The t-observed is 2.42*.

This can be seen in Table 8 below:

Table 8: Helpful Text Formatting, Anth vs Non-Anth.

Difference

-0.42

t Ratio

-2.42

Std Err Dif

0.17

17.15

Upper CL Dif

-0.05

Prob > |t|

0.03

Lower CL Dif

-0.78

Prob > t

0.99

Confidence

0.95

Prob < t

0.01

For the variables ‘specific quiz questions’ and

‘group’, the quiz questions in the anthropomorphic

condition are significantly (p<0.05) rated as being

more specific in nature than the same quiz questions

in the non-anthropomorphic condition. The t-

observed is 2.16*. This can be seen in Table 9

below:

Table 9: Specific Quiz Questions, Anth vs Non-Anth.

Difference

0.42

t Ratio

2.16

Std Err Dif

0.19

21.84

Upper CL Dif

0.82

Prob > |t|

0.04

Lower CL Dif

0.01

Prob > t

0.02

Confidence

0.95

Prob < t

0.98

For the variables ‘will use info elsewhere’ and

‘group’, the participants in the anthropomorphic

condition stated they would more likely use the

information they had viewed somewhere else (i.e. on

some other occasion and/or setting) compared with

the participants in the non-anthropomorphic

condition. The differences are significant (p<0.05),

the t-observed is 2.35*. This can be seen in Table 10

below:

Table 10: Will Use Info Elsewhere - Agree/Disagree, Anth

vs Non-Anth.

Difference

0.33

t Ratio

2.35

Std Err Dif

0.14

Upper CL Dif

0.65

Prob > |t|

0.04

Lower CL Dif

0.02

Prob > t

0.02

Confidence

0.95

Prob < t

0.98

2.8 Discussion of Results

Overall there were no significant results for

performance, where performance was measured by

examining the correctness of quiz questions and the

time taken. The reason for this outcome could be

that the tutorial material was not advanced enough to

allow differences to emerge with respect to the

different feedback types. However, one potentially

positive aspect of this result is that it gives some

confidence that the sample chosen which was

randomly assigned to the two different groups was

approximately equivalent in nature. This had been

one of the aims in the recruitment procedure. A

further aspect that could have affected the lack of

differences emerging in performance was that the

sample size should have ideally been larger.

For the subjective questions answered by

participants, where there was significance observed

in the results, the significance indicated the

anthropomorphic feedback to be mainly preferred

over the non-anthropomorphic feedback. This was

the case for helpful screen appearance, precise

screen instructions, specific quiz questions and the

likelihood of using the viewed information on some

other occasion. One exception was for the text

formatting, where the non-anthropomorphic

feedback was significantly rated to be better. The

reason for this single significant result for the non-

anthropomorphic feedback is unclear. However one

aspect that could explain the result, concerns the fact

that the non-anthropomorphic condition used text to

explain the concepts of the statistical material. The

anthropomorphic condition used a character to utter

or speak the same material resulting in much less

text appearing on the screen. The anthropomorphic

condition only had text on the screen to show the

formulae used and to label some interface elements.

3 CONCLUSIONS AND FUTURE

RECOMMENDATIONS

Although the outcomes of this experiment had few

significant results for subjective preferences and no

significant results for performance, the preferences

do appear to lie in the anthropomorphic region.

However, the authors of this paper conclude that

there is still further work to do before one can make

more concrete conclusions on whether

anthropomorphism at the user interface is useful in

terms of improving performance and subjective

satisfaction in a statistical tutorial context.

EFFECTIVENESS AND PREFERENCES OF ANTHROPOMORPHIC FEEDBACK IN A STATISTICS CONTEXT

147

However this work has been useful in two main

ways. The first is that as far as we know no one has

conducted an experiment of this sort investigating

specifically the context of statistics tutoring and

anthropomorphism. The closest we have found was

by Moundridou and Virvou (2002), which was in an

algebra context (briefly reviewed in section 1). Their

anthropomorphic feedback was used for giving

instructions and feedback. However, in contrast, the

work conducted by the authors used the

anthropomorphic feedback (in one of the conditions)

to also convey the instructional material. The second

aspect of usefulness of this experiment has

potentially shown the way forward for improving on

this work. The work can be particularly improved by

obtaining more participants, altering the tutorial

material to be more advanced so that differences in

the modes of presentation may emerge and by

improving upon the procedure used during the

experiment. The approach of using four laptops and

only three experimental observers could have meant

some bias being present in terms of inconsistent

observation (despite efforts at controlling this) and

some relevant occurrence not being noticed, due to

the reality of at least one observer having to observe

two individuals at once. A further aspect that could

be improved is to link this work with perhaps some

learning theories or other suitable theory of

cognition/interaction.

ACKNOWLEDGEMENTS

Prof Sunil Vadera, Prof Tim Ritchings and the

Universiti of Malaysia Sabah are acknowledged for

their support of this research.

REFERENCES

Bengtsson, B, Burgoon, J. K, Cederberg, C, Bonito, J, and

Lundeberg, M. (1999) The Impact of

Anthropomorphic Interfaces on Influence,

Understanding and Credibility. Proceedings of the

32nd Hawaii International Conference on System

Sciences, IEEE.

De Angeli, A, Johnson, G. I. and Coventry, L. (2001) The

Unfriendly User: Exploring Social Reactions to

Chatterbots, Proceedings of the International

Conference on Affective Human Factors Design,

Asean Academic Press.

Di Salvo, C. and Gemperle, F. (2003) From Seduction to

Fulfillment: The Use of Anthropomorphic Form in

Design, Proceedings of the Designing Pleasurable

Products and Interfaces Conference, p. 67-72, c ACM.

Hongpaisanwiwat, C. and Lewis, M. (2003) The Effect of

Animated Character in Multimedia Presentation:

Attention and Comprehension, Proceedings of the

2003 IEEE International Conference on Systems, Man

and Cybernetics.

Media Semantics (2009) http://www.mediasemantics.com.

Moundridou, M. and Virvou, M. (2002) Evaluating the

Persona Effect of an Interface Agent in a Tutoring

System. Journal of Computer Assisted Learning, 18, p.

253-261. Blackwell Science.

Murano, P, Ede, C. and Holt, P. O. (2008) Effectiveness

and Preferences of Anthropomorphic User Interface

Feedback in a PC Building Context and Cognitive

Load. 10

International Conference on Enterprise

Information Systems, Barcelona, Spain, 12-16 June,

2000 - INSTICC.

Murano, P, Gee, A. and Holt, P. O. (2007)

Anthropomorphic Vs Non-Anthropomorphic User

Interface Feedback for Online Hotel Bookings, 9th

International Conference on Enterprise Information

Systems, Funchal, Madeira, Portugal, 12-16 June 2007

- INSTICC.

Murano, P. (2005) Why Anthropomorphic User Interface

Feedback Can be Effective and Preferred by Users, 7th

International Conference on Enterprise Information

Systems, Miami, USA, 25-28 May 2005. INSTICC.

Murano, P. (2003) Anthropomorphic Vs Non-

Anthropomorphic Software Interface Feedback for

Online Factual Delivery, 7th International Conference

on Information Visualisation, London, England, 16-18

July 2003, IEEE.

Murano, P. (2002a) Anthropomorphic Vs Non-

Anthropomorphic Software Interface Feedback for

Online Systems Usage, 7th European Research

Consortium for Informatics and Mathematics

(ERCIM) Workshop - 'User Interfaces for All' -

Special Theme: 'Universal Access'. Paris (Chantilly),

France 24,25 October 2002. Published in Lecture

Notes in Computer Science - Springer.

Murano, P. (2002b) Effectiveness of Mapping Human-

Oriented Information to Feedback From a Software

Interface, Proceedings of the 24th International

Conference on Information Technology Interfaces,

Cavtat, Croatia, 24-27 June 2002.

ICEIS 2010 - 12th International Conference on Enterprise Information Systems

148
