LANGUAGE-ORIENTED PROGRAMMING

VIA DSL STACKING

Bernhard G. Humm

Darmstadt University of Applied Sciences, Department of Computer Science, Darmstadt, Germany

Ralf S. Engelschall

Capgemini sd&m Research, Munich, Germany

Keywords:

Language-oriented programming, Extensible programming languages, Domain-speciﬁc languages, Meta pro-

gramming, Semantic web, Business information systems, Lisp.

Abstract:

According to the paradigm of Language-Oriented Programming, an application for a problem should be im-

plemented in the most appropriate domain-speciﬁc language (DSL). This paper introduces DSL stacking, an

efﬁcient method for implementing Language-Oriented Programming where DSLs and general-purpose lan-

guages are incrementally developed on top of a base language. This is demonstrated with components of a

business information system that are implemented in different DSLs for Semantic Web technology in Lisp.

1 INTRODUCTION

When analyzing large-scale commercial IT projects

today, you usually ﬁnd that ﬁve or even more lan-

guages are being used – even in a “pure Java project”

if you take a closer look. HTML and JavaScript may

be used for GUI programing, SQL or EJBQL for

database accesses, UML for data modeling, Perl for

the UML to Java generator, BPEL for process logic

and several XML dialects for conﬁguration. Why

would projects put up with the high costs of hetero-

geneity? This is because different problem domains

require different language constructs.

This is the main idea of a paradigm called

Language-Oriented Programming (Ward, 1994;

Fowler, 2005; Dmitriev, 2005; Brauer et al., 2008).

It can be brieﬂy summarized as follows. When you

have to solve a complex problem, ﬁrst choose –

or, if necessary, develop – a language that is most

appropriate for the problem. Then, implement the

solution in this language.

In most publications today, such a language

is called a Domain-Speciﬁc Language (DSL) (van

Deursen et al., 2000) – see Sect. 5.2. Earlier pub-

lications use the term Problem-Oriented Language

(Goldﬁnger, 1961). In this paper we stick to the term

DSL although it shall be noted that the problem area

does not have to be a business domain and the lan-

guage may be more or less speciﬁc, depending on its

purpose.

Like all software engineering paradigms,

Language-Oriented Programming ultimately serves

one goal: to allow for developing applications of

high-quality at reasonable cost. To this end, which

criteria do we expect from a DSL most appropriate

for a particular domain and why?

Sufﬁcient Semantic Expressiveness. The DSL

must allow to express logic necessary for the

respective application domain directly in the

language, e.g., rules in a knowledge-based

system. This is necessary for implementing the

application at all.

Conciseness and Comprehensibility. Statements

should be expressed adequately, i.e., as concisely

and comprehensibly as possible. Boilerplate code

should be avoided. Inadequate representation has

several drawbacks. Firstly, developing unneces-

sarily voluminous code increases the costs for de-

veloping the application. Even higher are the

follow-up costs for maintenance. Secondly, the

quality of the solution decreases since errors can-

not be detected as easily. The more adequate the

representation – i.e., the closer to the problem do-

main – the more problem domain experts can be

involved in the development.

Integration. It must be possible to integrate the DSL

application with other applications, possibly im-

279

G. Humm B. and S. Engelschall R. (2010).

LANGUAGE-ORIENTED PROGRAMMING VIA DSL STACKING.

In Proceedings of the 5th International Conference on Software and Data Technologies, pages 279-287

DOI: 10.5220/0002925402790287

 SciTePress

plemented in other DSLs. This includes invoca-

tion at run-time and, ideally, integrated develop-

ment including integrated debugging. Integration

is mandatory if the DSL application is a compo-

nent of a larger application, e.g., a business infor-

mation system. Integrated development decreases

development costs, particularly for testing and de-

bugging.

Performance. Applications implemented in the DSL

must meet the respective performance require-

ments.

Those aspects help the application developer (de-

signer and implementer). Language-Oriented Pro-

graming adds another role: the language developer

(designer and implementer). The following aspect

helps the language developer.

Efﬁcient DSL Development. The design, imple-

mentation including validation logic, testing, and

maintenance of DSLs should be as efﬁcient as

possible. Efﬁcient DSL development directly af-

fects the total development cost.

In this paper, we present a method for Language-

Oriented Programming called DSL Stacking. DSL

stacking may meet all the criteria described above.

We demonstrate this with a sample Lisp application

using Semantic Web technology in the insurance busi-

ness.

This article is structured as follows. Sect. 2 and

3 give an overview of Language-Oriented Program-

ming, Semantic Web technology, the insurance sam-

ple and Lisp. In Sect. 4 we present a family of DSLs

for applying Semantic Web technology in the insur-

ance business. Sect. 5 explains the concept of DSL

stacking. In Sect. 6, we discuss the results. Sect. 7

concludes this article.

2 LANGUAGE-ORIENTED

PROGRAMMING

The term Language-Oriented Programming (Ward,

1994; Fowler, 2005; Dmitriev, 2005; Brauer et al.,

2008) has already been used for a number of years.

The idea, however, is even much older and has been

around since the invention of the ﬁrst high-level pro-

gramming languages. There have been a number

of extensible language initiatives in the 1960 and

1970s, e.g, translator writing systems like “The Syn-

tax Directed Compiler” (Irons, 1961) or extensible

programming languages like Lisp (McCarthy, 1960),

IMP (Irons, 1970), and Smalltalk-72 (Kay, 1993).

Extensible languages facilitate the development of

DSLs. The Unix little languages like AWK (Aho

et al., 1988) or make (Feldman, 1979) are examples

of DSLs.

Recently, there have evolved a number of

Language-Oriented Programming initiatives. Apart

from OMG’s MDA initiative these are the STEPS

project (Kay et al., 2008), Microsoft’s “Software

Factories” (Greenﬁeld, 2004), “Intentional Program-

ming” (Simonyi et al., 2006) and the “Meta-

Programming System” (Dmitriev, 2005). In those

publications, the term “language workbench” is used

as an integrated environment to design and implement

DSLs and to program applications in those DSLs.

Additionally, a number of new extensible pro-

gramming languages like F#, Ruby, Groovy, and

Scala have evolved in the last decade. They explicitly

provide features for language-oriented programming

like Groovy’s Meta-Object Protocol (MOP).

Two approaches to Language-Oriented Program-

ming can be distinguished: external DSLs and inter-

nal DSLs (Fowler, 2005).

Internal DSLs are idiomatic ways of writing higher-

level language code in the host language of the

application (“base language” – see Sect. 5.2)

directly. Example: AllegroProlog, a Prolog

(Clocksin and Mellish, 1987) implementation by

Franz Inc. fully integrated in Lisp that allows Pro-

log programming in Lisp notation. The extensible

programming language initiatives all fall into this

category.

External DSLs are different from the base language.

DSL programs are scanned, parsed and trans-

formed into the base language using some form of

compiler or interpreter. Example: a BPEL (OA-

SIS, 2007) engine parses XML code and trans-

forms it into data structures of a programming lan-

guage like Java. The Unix little languages and

MDA fall into this category. External DSLs may

be embedded in a host language, e.g., as strings,

or may be programmed in separate ﬁles.

In this paper, we focus on internal DSLs.

3 SAMPLE DOMAIN: SEMANTIC

WEB TECHNOLOGY IN THE

INSURANCE BUSINESS

3.1 Semantic Web Standards

The World Wide Web Consortium (W3C) has stan-

dardized a number of languages under the term “Se-

mantic Web” (Berners-Lee et al., 2001). The lan-

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

280

guages are based on the technologies XML and URI.

The main Semantic Web standards are as follows

(World Wide Web Consortium (W3C), 2010).

RDF (Resource Description Framework) is the ba-

sic Semantic Web modeling language. The funda-

mental data structure is a triple consisting of sub-

ject, predicate, and object.

RDF-S (RDF Schema) builds on top of RDF adding

the concepts of classes and properties.

OWL (Web Ontology Language) builds on top of

RDF-S and adds expressive set-based logic.

SPARQL (SPARQL Protocol and RDF Query Lan-

guage) allows for querying RDF-S and OWL

statements.

3.2 RDF Triples

The triple is the basic yet powerful data structure of

RDF. Every triple consists of subject, predicate, and

object. See Figure 1. It allows for basic statements

like “Peter has an income of $ 65,000”. It further-

more allows statements about class / instance rela-

tionships as in “Peter is a Person” and “Person is a

Class”. It also allows statements about properties like

“has-income is a Property”.

65,000Peter has-income

PersonPeter rdf:type

rdfs:classPerson rdf:type

rdf:Propertyhas-income

rdf:type

Figure 1: RDF triples.

3.3 Serialization Syntaxes for RDF

Different serialization syntaxes for RDF have been

standardized: RDF/XML, N3, Turtle, and N-Triples.

The W3C recommends RDF/XML for exchanging

RDF triples.

The following code example implements an RDF

triple stating that “Peter has the disease heart-stroke”.

<rdf:RDF

xmlns:rdf="http://-

www.w3.org/1999/02/22-rdf-syntax-ns#"

xmlns:ins="http://

www.fbi.h-da.de/insurance-example#">

<rdf:Description rdf:about="http://

www.fbi.h-da.de/insurance-example#Peter">

<ins:has-disease>

<rdf:Description

rdf:about="http://www.fbi.h-da.de/

insurance-example#Heart-Stroke">

</rdf:Description>

</ins:has-disease>

</rdf:Description>

</rdf:RDF>

Ten lines of XML code are necessary for expressing

a simple triple. With this verbose code, RDF/XML

is certainly no adequate representation for Semantic

Web programming. Other representations more or

less alleviate shortcomings of RDF/XML to provide a

more concise and human-comprehensible form – one

of the main concerns of Language-Oriented Program-

ming.

3.4 Business Domain: Insurance

We have developed a family of DSLs and have imple-

mented an insurance example application using those

DSLs. The example is about issuing disability insur-

ance. The customer interested in a disability insur-

ance must provide, apart from personal data, infor-

mation about employment, ﬁnancial situation, health,

and lifestyle. Based on this situation, the applica-

tion will perform a customer rating. For example, se-

vere diseases present in the family history may lead to

the decision of not offering a policy to the applicant.

Based on the rating, the application automatically ac-

cepts or declines the application or involves human

intervention.

3.5 Lisp as Base Language

Lisp (McCarthy, 1960) is one of the earliest high-level

programming languages. To date, numerous dialects

and versions have been speciﬁed and implemented.

Two aspects of Lisp make it ideal for developing in-

ternal DSLs:

Code is Data. Lisp data are represented by sym-

bolic expressions, so-called S-expressions (Mc-

Carthy, 1960). S-expressions are atoms like

numbers or characters and arbitrary lists of S-

expressions. Lisp programs are also expressed as

S-expressions: function deﬁnitions, control struc-

tures, class declarations etc. So, the syntax tree

of Lisp code is directly expressed as Lisp data

and, hence, can itself be transformed by Lisp pro-

grams.

Macro Processor. With the built-in macro processor,

language extensions to Lisp can be implemented

efﬁciently and with limited effort.

For those reasons, we have chosen Lisp for the im-

plementation of the sample application. However, it

shall be noted that Language-Oriented Programming

is not at all restricted to Lisp.

LANGUAGE-ORIENTED PROGRAMMING VIA DSL STACKING

281

ins:Peter

ins:Profession

“Natural Person“

rdfs:class

ins:Person

rdf:type

rdfs:comment

rdf:type

rdfs:seeAlso

Figure 2: Deﬁnition of a class and an instance.

We used the Allegro CL Express Edition by Franz

Inc. as integrated development environment for pro-

gramming Allegro Common Lisp, a professional im-

plementation of the ANSI Common Lisp standard

(Steele, 1984). Allegro CL was chosen due to its

extensive libraries, particularly AllegroGraph for Se-

mantic Web programming.

4 DSLS FOR THE SAMPLE

DOMAIN

4.1 Parts

The code example in Sect. 3.3 has shown that

RDF/XML does not fulﬁll the requirement of being

concise and comprehensive: ten lines of code for ex-

pressing one triple. We, therefore, introduce more ad-

equate language constructs. In the ﬁrst step, we ab-

breviate URI namespaces as in XML qualiﬁed names.

As a language extension, we use the ! macro of Alle-

groGraph.

Instead of writing

http://www.fbi.h-da.de/insurance-example#

Heart-Stroke

we can simply write

!ins:Heart-Stroke

– assuming that we have registered the name space:

(register-namespace "ins"

"http://www.fbi.h-da.de/insurance-example#")

4.2 Triples

Next, we use the add-triple macro of AllegroGraph

as a concise syntax for specifying triples. The fol-

lowing code example is equivalent to the verbose

RDF/XML triple deﬁnition from Sect. 3.3.

(add-triple !ins:Peter !ins:has-disease

!ins:Heart-Stroke)

ins:has-disease

ins:Heart-Strokeins:Peter

ins:Disease

ins:Person

rdf:Propertyrdf:type

rdfs:domain

rdfs:range

ins:has-disease

Figure 3: Deﬁnition of a property.

4.3 Classes, Subclasses and Instances

So far, we have used concise Lisp-based notations for

expressing parts and triples, the basic RDF data struc-

tures. Now, we extend the language by higher-order

constructs for classes, subclasses, and instances. We

deﬁne the macros add-class, add-subclass, and

add-instance. Figure 2 shows an example in RDF-

S. The equivalent statements are expressed in two

lines of DSL code as follows.

(add-class !ins:Person :comment "Natural Person"

:see-also !ins:Profession)

(add-instance !ins:Peter !ins:Person)

:comment, :see-also, and :label are optional key-

word parameters to provide further information about

the class. We have provided them for all higher-order

triple-generating macros. They can all be omitted as,

in this example, :label.

The macro deﬁnition of add-class is straight for-

ward.

(defmacro add-class

(class &key comment label see-also)

‘(progn

(add-triple ,class !rdf:type !rdfs:class)

,(if comment ‘(add-triple ,class

!rdfs:comment (literal ,comment)))

,(if label ‘(add-triple ,class

!rdfs:label (literal ,label)))

,(if see-also ‘(add-triple ,class

!rdfs:seeAlso ,see-also))))

The macro always generates an

rdf:type rdfs:class triple and, optionally,

up to three triples for comment, label, and see-also.

It allows specifying several statements in one ex-

pression. Additionally, it frees the modeler from

unnecessary and possibly confusing details, e.g.,

that the predicate type is deﬁned in namespace RDF

whereas the class class is speciﬁed in namespace

RDFS.

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

282

4.4 Properties

Properties in RDF-S are deﬁned via three triples,

specifying the property itself, its domain and range.

Figure 3 shows an example. We have deﬁned the

macro add-property that allows programmers to ex-

press those three triples in a single, concise expres-

sion:

(add-property !ins:Person

!ins:has-disease !ins:Disease)

(add-triple !ins:Peter

!ins:has-disease !ins:Heart-Stroke)

The RDF triple as a binary predicate is a simple yet

powerful building block. However, in semantic mod-

eling often n-ary predicates are needed, with n ≥ 1.

For this reason, we have extended the add-property

macro to cope with different arities. See the follow-

ing examples.

(add-property !ins:Disease !ins:is-inheritable)

(add-statement !ins:Heart-Stroke

!ins:is-inheritable)

(add-property !ins:Person !ins:takes-drug

!ins:Drug !ins:Frequency)

(add-statement !ins:Peter !ins:takes-drug

!ins:Alcohol !ins:rarely)

The ﬁrst example shows a unary predicate expressing

whether a disease is inheritable – here: heart stroke.

The likelihood of suffering from a heart stroke is in-

creased for people whose direct relatives have had

a stroke. The predicate is implemented with range

xs:Boolean.

The second example shows a tertiary predicate ex-

pressing the drug consumption behavior of a person –

here that Peter drinks alcohol rarely. The predicate is

implemented using RDF blank nodes.

So far, our DSLs contain general-purpose Seman-

tic Web extensions: parts, triples, classes, and pred-

icates. In the following section, we add business-

domain speciﬁc extensions.

4.5 Business Domain Speciﬁc

Extensions

The following example

(add-insurance-statements !ins:Peter

:daily-duty :sales

:income 80000

:height 175

:weight 98

:drugs ’(:Tobacco :regularly)

:disease-of-relative :Heart-Stroke)

is expanded to:

(add-instance !ins:Peter !ins:Person)

(add-triple !ins:Peter

!ins:has-daily-duty !ins:Sales)

(add-triple !ins:Peter !ins:has-income

(value->upi 80000 :int))

(add-triple !ins:Peter !ins:has-height

(value->upi 175 :int))

(add-triple !ins:Peter !ins:has-weight

(value->upi 98 :int))

(add-statement !ins:Peter !ins:takes-drug

!ins:Tobacco !ins:regularly)

(add-triple !ins:Peter

!ins:relative-has-disease !ins:Heart-Stroke)

Again, the notation has become more concise and

more comprehensible.

5 DSL STACKING

5.1 Bootstrapping

The German author R. E. Raspe (1736-1794) has

written the wonderful tale of the impostor Baron

unchhausen. M

unchhausen told his credulous au-

dience that he once got into a swamp and he started to

sink in. Quick-wittedly, he pulled himself out of the

swamp by his hair or – in the less painful variation of

the story – on his bootstraps.

Bootstrapping has since then become a metaphor

for self-sustaining processes of that kind. With our

Semantic Web DSL, we have done one kind of boot-

strapping. As the example in Sect 3.3 (ten lines of

code for a simple triple) shows, RDF/XML is like a

swamp for application developers. Instead of express-

ing complex matters in the language of their business

domain, they sink into a mass of unnecessary, confus-

ing boilerplate code. By deﬁning the DSLs in Sect. 4,

we have – step by step – pulled ourselves out of this

swamp:

1. Name spaces instead of full URIs

2. Concise triple notation

3. Classes, subclasses and instances

4. Predicates of different arities

5. Business-domain speciﬁc extensions

At the end of the bootstrapping process, the appli-

cation developer is able to express business logic in a

concise, comprehensible form.

Analyzing the bootstrapping process shows that

we have applied the principle of stacking to our DSLs.

We call this method DSL Stacking.

Before specifying the method, we need to deﬁne a

few concepts.

LANGUAGE-ORIENTED PROGRAMMING VIA DSL STACKING

283

Base Language

Intermediate DSLs

Insurance Predicates

Semantic Web DSL:

Predicates

Classes

Triples

Parts

RDFS

RDF

XMLLisp S-expressions

Top DSL

Language Concept

W3C Technology Stack

(Subset)

Insurance DSL Stack with

Semantic Web technology

general

specific

Common LispGPLs

Figure 4: DSL stacks.

5.2 Concepts

In DSL stacking, we distinguish different kinds of

languages, all of which are speciﬁed by syntax and

semantics.

• A base language is a language that allows the

speciﬁcation and / or implementation of other lan-

guages. Minimally, it must contain primitives like

numbers and characters and composition features

like nested lists. Additional features include, e.g.,

name spaces. Base languages are usually self-

describing, i.e., they can be speciﬁed in them-

selves. Examples are: XML as the base lan-

guage for all XML dialects like BPEL; MOF as

the base language for UML, CORBA IDL etc.;

Lisp S-expressions as the base language for Com-

mon Lisp as well as the Semantic Web DSL from

Sect.4.

• A general purpose language (GPL) is program-

ming or speciﬁcation language for a wide vari-

ety of problems. Examples are C (Kernighan and

Ritchie, 2008), Java (Gosling et al., 2005), or

OMG’s UML.

• A domain-speciﬁc language (DSL) is a program-

ming or speciﬁcation language dedicated to a par-

ticular problem domain. Examples are WS-BPEL

(OASIS, 2007) or the DSLs from Sect.4.

• A DSL stack is a set of languages with based-on

dependencies. A language L1 is based on another

language L2 if L1 is speciﬁed or implemented in

L2. DSLs may be based on other DSLs, GPLs, or

on the base language.

Figure 4 shows the DSL stack for the Semantic Web

DSL from Sect. 4. Languages further up in the stack

are based on the lower ones. As the base language we

use Lisp S-expressions. This is analogous to XML

as base language of the W3C Semantic Web Stack.

On top of the base language, we use Common Lisp

as a GPL to implement DSLs for parts and for triples.

They implement the semantics of RDF. On top of the

base technologies, we have implemented general pur-

pose Semantic Web extensions for classes and predi-

cates. They provide semantics equivalent to RDF-S.

In fact, they extend RDF-S insofar as they provide

classes, subclasses, instances, and predicates as lan-

guage constructs whereas in RDFS one is constrained

to the lower-level triple notation. Again on top we

have implemented predicates that are speciﬁc to the

insurance business domain.

5.3 The Language Stacking Method

We postulate the following requirements for the dif-

ferent languages on the DSL stack before we deﬁne

the language stacking method.

Base Language. A base language should have a min-

imalistic intrusive syntax and built-in bootstrap-

ping features.

In Lisp, the S-expression syntax is minimalistic,

allowing for deﬁning arbitrary concepts like data

structures, control structures, and aspects of all

kinds.

Bootstrapping features allow the implementation

of new language constructs. In Lisp, these are the

macro processor in combination with the fact that

code is represented as data. Other examples of

bootstrapping features are the Meta-Object Proto-

col (MOP) in Groovy, or implicit conversions in

Scala.

Intermediate DSLs are those DSLs, in which the

application developer does not program directly,

i.e., which are not on top of the DSL stack. They

should focus on a particular problem domain and

be simple yet expressive (Felleisen, 1990). The

triple notation is an excellent example being ex-

tremely simple yet allowing for implementing all

higher-level constructs like classes, subclasses,

instances, and predicates.

Top DSL. The top DSL is the one in which the ap-

plication developer programs directly, i.e. the one

on top of the DSL stack. It should be most ad-

equate for the application being developed: suf-

ﬁciently expressive, concise and comprehensible

for the domain expert.

DSL stacking is a method for language developers to

provide DSLs for application developers. It consists

of the following steps.

1. Select a base language that meets the require-

ments speciﬁed above.

2. If necessary, select a GPL implemented on top of

the base language.

3. While the requirements for a top DSL are not yet

met: select or develop DSLs on top of the stacked

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

284

Integration, project-specific extensions (e.g., Insurance Predicates)

Configuration

DSL

Test DSLWorkflow DSL

Semantic Web

DSL

GUI DSL

Entity, queries,

application data

type DSLs

Base Language

(Lisp S-Expressions)

GPL

(Common Lisp)

Figure 5: Language hierarchy.

languages. Those languages must meet the re-

quirements for intermediate DSLs.

Language stacking as a method is to be used by the

language developer. The application developer does

not have to be aware of the DSL stack since he is

programming in the top DSL only. Whether or not

the top DSL includes language features of lower-level

languages is a matter of visibility. In internal DSLs,

all lower-level language features are visible by de-

fault. However, sometimes it is desirable to restrict

language features by hiding lower-level DSLs, e.g.,

for security reasons or in order to reduce the com-

plexity for the application developer.

5.4 Integrating Multiple Languages

So far, we have considered a single stack of DSLs

only. When building large applications like business

information systems, different tasks require different

kinds of DSLs. Stacking all languages on the same

base language allows to seamlessly integrate compo-

nents implemented in different DSLs. This not only

allows for invoking functions from any language to

any other language at runtime. It also means inte-

grated development: using the same editor, compiler,

and test tools for different languages. Also – most

importantly – integrated debugging of applications in

different languages is possible.

To demonstrate this, we have implemented or used

a number of Lisp-based DSLs for business informa-

tion systems and have integrated them with the Se-

mantic Web DSL from Sect. 4 (see Figure 5).

• Application data types DSL, based on the Com-

mon Lisp type system

• Persistent entity DSL based on AllegroCache

• Entity query DSL based on AllegroCache

• Workﬂow DSL based on Allegro Common Lisp

Multiprocessing

• GUI DSL: Allegro Common Graphics

• Test DSL: LispUnit

• Conﬁguration DSL: ASDF

We have, then, implemented a prototypical in-

surance application based on those languages. Fig-

ure 6 shows an UML component diagram of the ap-

plication. It is structured as a three-layer architecture

Presentation

Insurance

Back-Office

Dialogs

Insurance

Customer

Dialogs

Application

Logic

Policy

Issuing

Rating

Product

Management

Customer

Management

Insurance Issuing Workflow

Data Access

Static Data

Transaction

Data

Rules Data

Workflow DSL

Semantic Web

DSLs

Entity, Query,

Appl. Data Type,

DSLs

Entity, Query,

Appl. Data Type,

DSLs

GUI DSL

Figure 6: Insurance example component architecture.

in which each component is implemented in one or

more DSLs. Insurance Back-Ofﬁce and Customer Di-

alogs are implemented with the GUI DSL. The insur-

ance issuing workﬂow is implemented in the work-

ﬂow DSL. Product Management, Customer Manage-

ment and Policy Issueing are implemented in DSLs

for Business Information Systems including applica-

tion data types, persistent entities and entity queries.

The rating component is implemented in the Seman-

tic Web DSL described in Sect. 4. Finally, static data,

transactional data and rules data are stored and re-

trieved via the persistent entity DSL.

6 DISCUSSION

6.1 Evaluation of Goals

We now evaluate the approach presented against the

criteria for developing high-quality solutions at rea-

sonable cost set out in Sect. 1.

Sufﬁcient Expressiveness. The Semantic Web DSL

presented is based on the RDF/RDF-S technol-

ogy and, hence, expose at least their expressive-

ness. Together with a Prolog-based rules and

query DSL, the insurance rating logic could be ex-

pressed directly.

Conciseness and Comprehensibility. Statements

should be expressed adequately, i.e., as concisely

and comprehensibly as possible. Unnecessary

boilerplate code was avoided. We have compared

the code size of the insurance application im-

plemented in the Semantic Web DSL to the size

of the resulting N-triples code. We measured a

saving of 74% in lines of code (one N-Triple part

LANGUAGE-ORIENTED PROGRAMMING VIA DSL STACKING

285

per line) respectively 77% in code size (number

of characters including white space). This will

result in considerable less implementation and

maintenance cost.

Not numerically measurable but obvious is the in-

creased comprehensibility of the code – under-

standable and maybe even editable by business

domain experts. This will result in higher qual-

ity of the solution.

Integration. We have integrated the insurance com-

ponents, all implemented in different DSLs, with

each other to form a business information system.

Invocations Dialog → Work f low → Rating →

Database did not require an additional middle-

ware. Editing, compiling, and testing was all per-

formed in one development environment (Alle-

gro CL Express Edition). Particularly, integrated

debugging of code implemented in different lan-

guages was possible and most helpful.

Performance. The Semantic Web DSL has been im-

plemented as Lisp macros which are expanded at

compile time and, therefore, cause no runtime per-

formance penalty whatsoever.

Efﬁcient DSL Development. The code for imple-

menting the Semantic Web DSL on top of Al-

legroGraph described in Sect. 4 is less than 100

lines of Lisp code (loc) including comments. The

total amount of code for all DSLs used in the in-

surance application as described in Sect. 5.4 is

less than 1,000 loc. Development and testing of

all DSLs was an effort of less than a person month.

This can be regarded as an efﬁcient means of im-

plementing such a comprehensive set of DSLs.

However, it shall be noted that the implementa-

tion is experimental and not production-ready. A

major effort in production-ready DSL implemen-

tations lies in the meaningful handling of compiler

errors, particularly if the DSL is to be used by

non-programmers.

This demonstrates the validity of the approach in gen-

eral and the Semantic Web DSL in particular.

6.2 DSL Stacking

Language stacking is an application of the principle of

separation of concerns – like component-orientation

and layered architectures. Different aspects are sep-

arated into several languages, like components in a

system. Different languages are built on top of each

other with strict dependencies, like in a layered archi-

tecture.

DSL stacking is a form of language stacking.

However, there is an important difference to the Se-

mantic Web language stacking. The designers of

the Semantic Web standards have, as a standardiza-

tion body, to stop bootstrapping at a reasonable level

of generality. DSL stacking continues bootstrapping

from there until the requirements for the top DSL are

met, i.e., a most adequate language for the respective

problem domain is found. This allows to gain the full

beneﬁt of Language-Oriented Programming.

7 CONCLUSIONS

To conclude, we summarize the key statements of this

article. When you have a complex problem to solve

you should proceed as follows.

1. Use a development environment that allows the

design and implementation of DSLs.

2. For each subproblem, choose a DSL which is

most appropriate: concise and comprehensible.

3. If such a DSL does not exist, develop one.

4. Stack the DSL on top of a lower-level language.

The base language is the bottom of the stack.

Language-Oriented Programming is neither new nor

a silver bullet but it helps in the development of appli-

cations with high quality at reasonable cost. For ap-

plications using XML-based Internet technology like

Semantic Web standards, Language-Oriented pro-

gramming is particularly useful – see also (Graunke

et al., 2001). We have demonstrated the effectiveness

by measurements of code savings of about three quar-

ters in an experimental implementation of an insur-

ance business information system.

DSL stacking allows for cost-efﬁcient realiza-

tion of Language-Oriented Programming. We have

demonstrated this by implementing a complete Se-

mantic Web DSL in less than 100 loc and by imple-

menting DLSs for application data types, persistent

entities, entity queries, workﬂow, GUI, test, and con-

ﬁguration in less than 1000 loc.

Those convincing numbers are partially due to the

prototypical character of the implementation and ex-

isting powerful lower-level DSLs like Allegro Graph

on which the new DSLs could be stacked. They are

also partially due to the fact that Lisp as an extensi-

ble language is particularly suitable for implementing

internal DSLs.

A downside for applying Language-Oriented Pro-

gramming and DSL stacking in large-scale industrial

projects is that extensible programming languages are

currently not in mainstream use. This has a number of

consequences: the stock of programmers is limited,

development and production tools are less perfected.

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

286

However, we notice a revival of extensible pro-

gramming languages. Within the last decade, quite

a number of such languages have been implemented

on top of mainstream platforms and their number is

increasing rapidly. Examples are implementations of

Python, Ruby, Groovy, and Scala on the Java Platform

or F# on the .NET platform. Furthermore, there are a

number of Lisp implementations on the Java platform,

e.g., ABCL, Clojure, Jatha, and CLForJava.

What needs to be done? Professional tool support

for Language-Oriented Programming and DSL stack-

ing, integration with mainstream platforms like Java

and the development of useful DSLs to be taken off

the shelf.

REFERENCES

Aho, A. V., Kernighan, B. W., and Weinberger, P. J. (1988).

The AWK Programming Language. Addison-Wesley.

Berners-Lee, T., Hendler, J., and Lassila, O. (2001).

The Semantic Web: A new form of Web

content that is meaningful to computers will

unleash a revolution of new possibilities:

www.scientiﬁcamerican.com/article.cfm?id=the-

semantic-web. Scientiﬁc American.

Brauer, J., Crasemann, C., and Krasemann, H. (2008). Auf

dem Weg zu idealen Programmierwerkzeugen - Be-

standsaufnahme und Ausblick. Informatik Spektrum,

31(6):580–590.

Clocksin, W. F. and Mellish, C. (1987). Programming in

Prolog, 3rd Edition. Springer.

Dmitriev, S. (2005). Language Oriented Program-

ming: The Next Programming Paradigm.

http://www.onboard.jetbrains.com/is1/articles/04/10/

lop/.

Feldman, S. I. (1979). Make — A Program for Maintaining

Computer Programs. Software: Practice & Experi-

ence, 9:255–265.

Felleisen, M. (1990). On the Expressive Power of Program-

ming Languages. In Jones, N., editor, Proceedings 3rd

European Symposium on Programming (ESOP’90)

Copenhagen, Denmark, May , 1990, volume 432 of

Lecture Notes in Computer Science, pages 134–151,

Berlin, Heidelberg, Springer,.

Fowler, M. (2005). Language Workbenches: The

Killer-App for Domain Speciﬁc Languages?

http://martinfowler.com/articles/languageWorkbench.

html.

Goldﬁnger, R. (1961). Problem-oriented programming

language structure. Communications of the ACM,

4(3):138.

Gosling, J., Joy, B., Steele, G., and Bracha, G. (2005). The

Java language speciﬁcation. Addison-Wesley, Upper

Saddle River, NJ, 3. ed., 1. print. edition.

Graunke, P. T., Krishnamurthi, S., Van Der Hoeven, S.,

and Felleisen, M. (2001). Programming the Web

with High-Level Programming Languages. In David

Sands, editor, Proceedings 10th European Symposium

on Programming (ESOP 2001), Genova, Italy, April

2001, volume 2028 of Lecture Notes in Computer Sci-

ence. Springer.

Greenﬁeld, J. (2004). Software Factories: Assem-

bling Applications with Patterns, Models, Frame-

works, and Tools. http://msdn.microsoft.com/en-

us/library/ms954811.aspx.

Irons, E. T. (1961). A Syntax Directed Compiler for AL-

GOL 60. Communications of the ACM, 4(1):51–55.

Irons, E. T. (1970). Experience with an Extensible Lan-

guage. Communications of the ACM, 13(1):31–40.

Kay, A., Piumarta, I., Rose, K., Ingalls, D., and Amelang,

D. (2008). STEPS Toward The Reinvention of Pro-

gramming: 2008 Progress Report Submitted to the

National Science Foundation (NSF): VPRI Technical

Report TR-2008-004. Technical report, Viewpoints

Research Institute.

Kay, A. C. (1993). The Early History of Smalltalk. In

HOPL Preprints, pages 69–95.

Kernighan, B. W. and Ritchie, D. M. (2008). The C pro-

gramming language. Prentice Hall PTR, Upper Sad-

dle River, NJ, 2nd ed., 43. print. edition.

McCarthy, J. (1960). Recursive Functions of Symbolic Ex-

pressions and Their Computation by Machine, Part I.

Communications of the ACM, 3(4):184–195.

OASIS (2007). Web Services Business Process Ex-

ecution Language Version 2.0: OASIS Stan-

dard. http://docs.oasis-open.org/wsbpel/2.0/wsbpel-

v2.0.pdf.

Simonyi, C., Christerson, M., and Clifford, S. (2006). Inten-

tional software. In Tarr, P. L. and Cook, W. R., editors,

Proceedings of the 21th Annual ACM SIGPLAN Con-

ference on Object-Oriented Programming, Systems,

Languages, and Applications (OOPSLA 2006), pages

451–464.

Steele, G. L. (1984). COMMON LISP: The Language. Digi-

tal Press, 12 Crosby Drive, Bedford, MA 01730, USA.

van Deursen, A., Klint, P., and Visser, J. (2000). Domain-

Speciﬁc Languages: An Annotated Bibliography.

ACM SIGPLAN Notices, 35:26–36.

Ward, M. P. (1994). Language-Oriented Programming.

Software - Concepts and Tools, 15(4):147–161.

World Wide Web Consortium (W3C) (2010). Seman-

tic Web: http://www.w3.org/standards/semanticweb/,

last visited 30/4/2010.

LANGUAGE-ORIENTED PROGRAMMING VIA DSL STACKING

287
