ON A CONSTRUCTION OF STREAM-CIPHER-BASED HASH

FUNCTIONS

Yuto Nakano, Jun Kurihara, Shinsaku Kiyomoto and Toshiaki Tanaka

KDDI R&D Laboratories Inc., 2-1-15, Ohara, Fujimino, Saitama, Japan

Keywords:

Hash function, Stream cipher, Collision resistance, Second preimage resistance, Preimage resistance.

Abstract:

Hash functions using stream ciphers as components perform fast on a variety of platforms. However, the secu-

rity and the design policy of stream-cipher-based hash functions (SCHs) have not yet been studied sufﬁciently.

In this paper, we analyze its design criteria based on a ideal function of SCHs. First, we show that attacks

against a stream cipher can also be threats against SCHs. Then we discuss the security on each phase of SCH;

message injection, blank rounds, and hash generation with this function. Finally we derive the necessary

conditions on the stream cipher function for an SCH to be secure.

1 INTRODUCTION

Hash functions are used in many cryptographic ap-

plications, e.g., message authentication codes, dig-

ital signatures and authentication protocols. Stan-

dard hash functions MD5 (Rivest, 1992) and SHA-1

(NIST, 1995) have been demonstrated that these func-

tions are not collision resistant (Wang et al., 2005;

Wang and Yu, 2005). Many constructions for new

hash functions have been presented as alternatives to

these ordinary algorithms. Some hash functions such

as Abacus (Sholer, 2008) and Boole (Rose, 2008) are

based on stream ciphers, and shows that they have

good performance on a variety of platforms. A note-

worthy advantage of stream cipher-based hash func-

tions is that the algorithm is used not only for gener-

ating a hash value but also for encrypting/decrypting

data as a stream cipher. We can reduce total costs of

implementations for a hash function and a symmetric-

key encryption algorithm with a stream-cipher-based

hash function. Thus, it is a reasonable solution for

resource constraint devices.

The general construction of stream-cipher-based

hash functions (SCHs) was ﬁrst introduced by Goli´c

(Goli´c, 2001) as a mode of operation of stream ci-

phers. An SCH consists of a stream cipher function

and an additional function that inputs a message into

the internal state of the stream cipher function. There-

fore, a modelof an SCH consists of a pre-computation

function and a stream cipher function. The stream ci-

pher function is a core component of SCHs and an

appropriate algorithm is selected from among exist-

ing stream cipher algorithms. The pre-computation

function is used to absorb the message into the inter-

nal state of the stream cipher function. On the other

hand, a well developed evaluation design of the secu-

rity of SCHs is yet to be produced, and design princi-

ples of secure SCHs have not been established.

In this paper, we deﬁne a stream cipher function

that consists of three rounds; message injection, blank

rounds, and hash generation. With this function, we

show that an attack on the keystream feedback mode

and an attack against a self-synchronizing stream ci-

pher can also be employed as an attack against SCHs.

Furthermore, we analyze the security of each phase

from an attack perspective. As a result of our work,

following criteria can be formulated:

• The size of the internal state is larger than the size

the of hash value. |S| > |H| is required for col-

lision, second preimage, and preimage resistance,

where |S| is the size of the internal state and |H| is

the length of the hash value.

• The message injection has to be collision resis-

tant. The computational cost of the collision at-

tack against message injection has to be equal to

or more than 2

|H|/2

, and an adversary is not able

to control the internal state of the stream cipher

function.

• Blank rounds are preimage resistant. That is, de-

riving the internal state after message injection by

going blank rounds backwardly requires 2

|H|

com-

putational cost. Furthermore, the transition of the

internal state is cyclic and its period is more than

or equal to 2

|H|

334

Nakano Y., Kurihara J., Kiyomoto S. and Tanaka T. (2010).

ON A CONSTRUCTION OF STREAM-CIPHER-BASED HASH FUNCTIONS.

In Proceedings of the International Conference on Security and Cryptography, pages 334-343

DOI: 10.5220/0002939703340343

 SciTePress

• The hash value has to be affected by the whole

internal state. Suppose that the internal state size

is |S| and the hash size is |H|, the hash value bit

has to be decided by at least an |S|/|H|-bit internal

state.

• Suppose that an x-bit internal state can be con-

trolled by an x-bit message and this operation does

not affect other bits, then the whole internal state

can be controlled with an |S|/x-bit message. Here

we assume that one bit message is xored with n

bits of the internal state at equal intervals. Then

the adversary can control up to an |S|/n-bit in-

ternal state. Hence the condition s(n − 1) ≥ nh

is required for a message injection to be collision

resistant.

2 PRELIMINARIES

We provide deﬁnitions and summarizes related works

in this section.

2.1 Deﬁnitions

Throughout the paper, we use the following notations.

• M: input message

• m

: input message to the stream cipher function at

time t

• S

: internal state of the stream cipher function at

time t

• o

: output of the stream cipher function at time t

• |x|: bit length of x (x can be M, S,H)

• ⊕: bitwise exclusive-or

• S

msg

, S

′

msg

: internal state of stream cipher function

after message M or M

′

are injected, respectively

• S

blk

, S

′

blk

: internal state of stream cipher function

after blank rounds derived from S

msg

or S

′

msg

, re-

spectively

• ∆

msg

: internal state difference after message injec-

tion ∆

msg

= S

′

msg

− S

msg

• ∆

blk

: internal state difference after blank rounds

∆

blk

= S

′

blk

− S

blk

2.2 Security Deﬁnitions for Hash

Functions

Security requirements for hash functions are colli-

sion resistance, second pre-image resistance, and pre-

image resistance (Menezes et al., 1996). Let M and

′

be messages, |H| be hash length, h be a hash func-

tion, and the symbol || be concatenation of data.

Collision Resistance. Finding M and M

′

such that

h(M) = h(M

′

) and M 6= M

′

requires 2

|H|/2

hash oper-

ations.

Second Pre-image Resistance. Finding M for

given M

′

such that h(M) = h(M

′

) and M 6= M

′

re-

quires 2

|H|

hash operations.

Pre-image Resistance. Finding M from h(M) re-

quires 2

|H|

hash operations.

Length-extension Security. This requirement has

been proposed in NIST SHA-3 competition. Given

h(M), the complexity of ﬁnding (z, x) such that x =

h(M||z) should be greater than or equal to either the

complexity of guessing M itself or 2

|H|

2.3 Related Work

Here we introduce important research related to the

construction of SCHs.

2.3.1 Self-synchronizing Stream Cipher

A self-synchronizing stream cipher (SSSC) is one

in which the keystream is generated from the secret

key and a ﬁxed number of previous ciphertext bits

(Menezes et al., 1996).

Let p

, c

, and z

be a plaintext bit, a ciphertext

bit, and a keystream bit at time t, respectively. The

keystream at time t depends on the secret key K and

previous n

ciphertext bits c

t−n

,...,c

t−1

, where

is called input memory. The keystream bit is de-

scribed by

= f

t−n

t−(n

−1)

,..., c

t−1

,K), (1)

where f

is the function deﬁned by the stream cipher.

When the ciphertext is decrypted, the keystream is

generated in the same manner as encryption. For the

ﬁrst keystream bit, the previous n

ciphertext bits do

not exist. Therefore, n

-bit Initial Vector(IV) has to

be deﬁned as IV = c

−1)

,...,c

2.3.2 Keystream Feedback Mode

Keystream feedback mode is employed in the initial-

ization of many stream ciphers such as SNOW (Ek-

dahl and Johansson, 2002). In the initialization of

stream ciphers, an initial key and an IV are loaded

into the internal state of the stream cipher. After load-

ing the key and the IV, the stream cipher is clocked

a speciﬁed number of times. In the initialization pro-

cess, keystream bits are fed back to the internal state

to enable the further diffusion of the key and the IV.

ON A CONSTRUCTION OF STREAM-CIPHER-BASED HASH FUNCTIONS

335

Figure 1: Schematic of Abacus.

2.3.3 Goli

c’s Construction

Goli´c (Goli´c, 2001) showed how to convert a

keystream generator into a stream cipher with mem-

ory (SCM) mode and how to built hash functions with

SCM mode. When a feedback shift register (FSR)

based keystream generator is used, SCM mode is eas-

ily converted by adding the plaintext bit to the feed-

back bit of the FSR. The following is the scheme of

Goli´c’s construction.

1. Generate a keystream by feeding back a message

into the keystream generator and encrypting the

message.

2. Another encryption is applied; this time the ci-

phertext obtained in step 1. is used in reverse or-

der.

3. Generate a keystream by feeding back a constant

value (if possible, set all constants to zero) for αm

times, where α is not a large integer.

4. Output the last h successive bits of the keystream

obtained in step 3. as the hash value.

In step 1, using a ﬁxed and known key, SCM mode is

clocked m times with an m-bit message and the corre-

sponding m-bit ciphertext is memorized. SCM mode

is clocked another m times with the m-bit ciphertext

in the reverse order in step 2. SCM mode is clocked

αm times where α is not a large integer (e.g., three),

and the last h successive ciphertext bits (or keystream

bits) are output as the hash value.

As the ciphertext in reverse order is used in step 2,

this scheme requires an amount of memory that is the

same as the message size.

2.3.4 Abacus

Abacus is a family of hash functions submitted to

NIST for consideration as SHA-3. Abacus has four

registers (

ra, rb, rc, rd

) as shown in Fig 1. We

only show the absorb phase. Refer to (Sholer, 2008)

for detailed information.

The absorb phase processes one byte of a mes-

sage in a round. First, the values of four registers

Figure 2: Schematic of Boole.

and a byte message are Exclusive-ORed(XORed) and

the results go through S-Boxes. In the next step, four

counters are combined with registers. Then, the maxi-

mum distance separable (MDS) matrix function is ap-

plied and four bytes are output. Four bytes of registers

go through the S-Boxes again.

ATTACKS ON ABACUS. Two second pre-image at-

tacks against Abacus were proposed by Nikoli´c et

al. (Nikoli´c and Khovratovich, 2008) and Wilson

(Wilson, 2008) independently. In the paper (Wilson,

2008), Wilson also showed a collision attack.

In the absorb phase of Abacus, message bytes are

XORed with the register

rd[0]

. At this point, the

adversary can set the value of

rd[0]

to zero. Once

the value of

rd[0]

is determined, it remains the same

in the following 88 rounds. Thus, with an 89-byte

message, the adversary can ﬁx the whole register

Then the attack uses a meet-in-the-middle

(MITM) approach (Menezes et al., 1996). Since

whole values of the register

are set to zeros the in-

ternal state of the Abacus is reducedto 1+5+37= 43

bytes. Therefore the MITM approach only requires

8×43/2

= 2

172

computation.

Vulnerabilities of Abacus are that the register

value can be determined from the input message and

that the hash output function is not a one-way func-

tion.

2.3.5 Boole

Boole (Rose, 2008) is a family of hash functions

submitted to NIST for SHA-3 competition. The

schematic of Boole is shown in Figure 2. Boole is

constructed from a non-linear feedback shift regis-

ter, input accumulators, and an output ﬁlter function.

Boole consists of three phases, i.e., an input phase, a

mixing phase, and an output phase. The state tran-

sition function of the register, referred to as a cycle,

transforms state S

into S

t+1

A message word is input to three word accumu-

lators, and the accumulators are updated in the input

phase. Then the register is cycled once. After the in-

SECRYPT 2010 - International Conference on Security and Cryptography

336

Figure 3: Model of SCH

put phase, the register is mixed with three accumula-

tors, then the register is cycled 16 times, and the hash

value is generated.

ATTACK ON BOOLE. A pre-image attack against

Boole is presented by Nikoli´c (Mendel et al., 2009).

This attack uses the MITM method. The value of ten

registers can be determined from the message and the

target hash. Therefore the search space is reduced to

nine registers. Each register is one byte, hence the

complexity of the attack is 2

Boole is vulnerable in two ways: the register value

can be determined from the input message and the

hash output function is not a one-way function.

A collision attack on Boole is also proposed

(Mendel et al., 2009). Since two boolean functions

used in Boole are not invertible, the collision can be

constructed in these functions.

3 CONSTRUCTION OF SCHS

In this section we present a general model of SCH,

which is shown as Figure3. An SCH is modeled with

two components: a pre-computation function and a

stream cipher function. This is the generalized model

of the construction of the hash functions based on

stream ciphers.

3.1 Pre-computation Function

A pre-computation function is appended to a stream

cipher for constructing an SCH. The pre-computation

function is the part which takes an input message and

an intermediate hash value as an input and determines

the internal state of the stream cipher function. The

stream cipher function plays the role of diffusing the

message into the internal state. The hash value is a

certain length of keystream which is produced by the

stream cipher function. Generally, keys and IVs are

set to a constant value, usually to zero, and the mes-

sage is loaded to the internal state of the stream cipher

function. Goli´c’s construction consists of a ﬁrst-in-

last-out (FILO) buffer and a stream cipher. Therefore

it is obvious that the FILO buffer should be treated as

pre-computation function and the stream cipher is the

stream cipher function.

Generally, the pre-computation function requires

very few computations; for example, the pre-

computation function in Abacus is deﬁned as the reg-

isters where the message is XORed. Namely the op-

eration rd[0] ⊕ msg[i] is the pre-computation function

in Abacus. In the case of Boole, three accumulators;

lsum, xsum, and rsum, are used to input a message

into the non-linear feedback shift register. Hence op-

erations which use these accumulators are deﬁned as

the pre-computation function.

3.2 Hash Value Generation

SCHs execute three phases: message injection, blank

rounds, and hash generation. Here, the message is

loaded into the internal state of the stream cipher in

the message injection. The blank round is an oper-

ation in which the stream cipher function is clocked

by feeding back the output without outputting the

keystream. This phase is a similar operation to the

initialization of the stream cipher. The stream cipher

outputs a keystream as a hash value in the hash gen-

eration.

We deﬁne a stream cipher with a pre-computation

function at time t as f(m

). In the stream ci-

pher function, the internal state is updated and the

keystream (hash value) is generated from the mes-

sage, internal state, and feedback of output. The op-

eration can be denoted as:

f(m

) → S

t+1

. (2)

We denote message injection, blank rounds, and hash

generation by Eq. (2) as follows:

f(m

) → S

t+1

, (3)

f(0,S

) → S

t+1

, (4)

f(0,S

,0) → S

t+1

. (5)

The internal state is updated from message, previous

state, and feedback of output in the message injection.

In blank rounds, the internal state is updated from the

previous state, and output. During hash generation,

only the previous state is used to update the state and

output the hash value.

4 ATTACKS AGAINST SCH

In this section, we considere the relation between

attacks against stream ciphers and attacks against

SCHs. We also consider general attacks against hash

functions to derive secure construction of SCHs.

ON A CONSTRUCTION OF STREAM-CIPHER-BASED HASH FUNCTIONS

337

4.1 Relation to the Attack against a

Stream Cipher

Since blank rounds of an SCH and the initialization of

stream ciphers have the same structure, chosen IV/key

attack against stream ciphers can be applied to the at-

tack against SCH. Wu et al. (Wu and Preneel, 2007)

presented the chosen IV attack against Py (Biham and

Seberry, 2005) and Pypy (Biham and Seberry, 2006)

in which an adversary can ﬁnd an identical keystream

using IVs which have special differences. In the ini-

tialization of keystream feedback mode, the internal

state is updated after the key and IV setup as follows:

f(S

) → S

t+1

, (6)

where S

and z

are the internal state and keystream

at time t. Blank rounds in an SCH can be denoted

as Eq. (4). There is no message to be injected into

the internal state during blank rounds, Eq. (4) can be

modiﬁed as:

f(S

) → S

t+1

. (7)

From the Eq. (6) and (7), an attack against keystream

feedback mode can be used against blank rounds of

an SCH. In the case where the attack proposed by Wu

et al. is applied to the SCH, an adversary can ﬁnd

two identical hash values from different messages;

this leads to a collision and second preimage attack

against SCHs. If there is an attack that reveals the se-

cret key from the keystream, such attack leads to the

preimage attack against SCHs.

Blank rounds also have a relation to SSSC. In

Eq. (1) c

t−1

can be considered as an output feedback

at time t and (c

t−n

, c

t−(n

−1)

, ..., c

t−2

) as an in-

ternal state. At time t + 1, c

will be fed back and

t−(n

−1)

, ..., c

t−1

) will be the internal state. Let S

be S

= (c

t−n

, c

t−(n

−1)

, ..., c

t−2

), then the gener-

ation of the keystream can be denoted as:

t+1

= f(S

, p

⊕ z

and the internal state is updated at the same time:

f(S

, p

⊕ z

) → S

t+1

, p

t+1

⊕ z

t+1

. (8)

Hence an attack against SSSCs can be regarded as an

attack against SCHs from Eq. (7) and (8).

An attack aganist an SSSC which controls the

keystream or ciphertext with the fed-back ciphertext

should be considered. If there is an attack such that

identical ciphertexts can be obtained from different

plaintexts, this attack can be converted to the colli-

sion attack against SCH. Moreover, if the adversary

can set the ciphertext arbitrarily, it is considered to be

a second preimage attack.

4.2 Collision Attacks

We consider collision attacks against each phase; the

message injection, blank rounds, and the hash gener-

ation in an SCH.

4.2.1 Message Injection

We set the message difference which is canceled after

all message bits are input to the internal state in the

attack against message injection. Let M and M

′

be a

pair of collision messages. Then for the two internal

states S

msg

and S

′

msg

, S

msg

= S

′

msg

holds and no input

exists except the output feedback after the message

injection. Hence S

blk

= S

′

blk

and H = H

′

are obtained.

4.2.2 Blank Rounds

In the collision attack against blank rounds, the differ-

ence canceled during the blank roundsis set to the pair

of messages. Suppose two internal states S

blk

′

blk

are obtained after applying blank rounds to S

msg

′

msg

The collision attack against blank rounds is successful

if S

blk

= S

′

blk

First, an adversary searches for a point at which

two internal states collide; we call this point c. Once

internal states pass point c during j times blank

rounds, then the internal states remain the same for

the rest of the blank rounds, and this leads to a colli-

sion. Set two internal states S

msg

′

msg

which pass the

point c at i-th clock of blank rounds, and derive two

messages M, M

′

from S

msg

′

msg

. Since the adversary

has j choices for i, one point c means j collision pairs.

4.2.3 Hash Generation

First, an adversary has to ﬁnd the difference ∆

blk

which is canceled during f (0, S

,0) → S

t+1

Second, he has to ﬁnd the difference ∆

msg

which leads

to ∆

blk

. Then he derives collision messages M,M

′

from S

msg

′

msg

4.2.4 Multi-collision Attack

A. Joux (Joux, 2004) presented a multi-collision at-

tack on iterated hash functions. Constructiong 2

col-

lisions only costs t times as much as an ordinary col-

lision.

4.3 Second Preimage Attacks

As second preimage attacks, attacks on message in-

jection, blank rounds, and hash generation have to be

considered.

SECRYPT 2010 - International Conference on Security and Cryptography

338

4.3.1 Message Injection

In the second preimage attack against message injec-

tion, an adversary tries to ﬁnd another message M

′

which satisﬁes S

msg

= S

′

msg

for the given message M.

Two internal states derived from two messages are

identical and so are the hash values.

4.3.2 Blank Rounds

By applying j clock of blank rounds internal states

blk

′

blk

are obtained from S

msg

′

msg

. If blank rounds

have collision in them, a second preimage attack be-

comes possible. Similar to the collision attack, an ad-

versary searches for the point c. Given the internal

state S

msg

, and it passes the point c during j clocks of

blank rounds, then another internal state S

′

msg

can be

found. Thus a second preimage attack against blank

rounds can be performed.

4.3.3 Hash Generation

Suppose that h-bit hash is generated and the internal

state is updated every one clock of the hash genera-

tion. If |S| > |H|, then collision occurs by compress-

ing the |S|-bit internal state to the |H|-bit hash. By us-

ing this property, a second preimage attack becomes

possible. Speciﬁcally, derive internal states S

blk

and

′

blk

for given H then a second preimage of M can be

found by inverting blank rounds and the message in-

jection.

4.4 Preimage Attacks

Preimage attacks consist of three phases: against the

hash generation, blank rounds, and message injection.

In hash generation, since the |S|-bit internal state

is compressed into the |H|-bit hash, it is impossible to

derive all bits on S

blk

only from H.

An adversary tries to invert blank rounds to derive

msg

from S

blk

. Let p be the probability at which all

|S| bits of the internal state can be correctly guessed

by going through one clock of blank rounds in reverse

order. Then the probability to derive S

msg

from S

blk

given as p

The adversary derives the initial state S

from the

internal state after the message injection S

msg

in the

preimage attack against message injection. Since all

bits of S

msg

are known at this point, it would be pos-

sible to guess a message M from S

msg

4.5 Length-extension Attacks

The adversary has to compute the hash value x =

H(M||y) without M. Thus, the adversary tries to ob-

tain S

msg

or S

blk

for the message M||y using the hash

value H(M).

5 CONSTRUCTING A SECURE

SCH

In this section, we propose a construction of an SCH

which has collision, second preimage, and preimage

resistance.

5.1 Collision Resistance

We discuss collision resistance and collision resistant

SCHs.

5.1.1 Collision Resistant SCH

We consider the following three cases as collision at-

tacks against SCHs:

1. Against message injection

Decide message difference which leads to an

identical internal state after all message bits are

injected.

2. Against blank rounds

The internal state difference caused by messages

is canceled during blank rounds.

3. Against hash generation

The difference given by messages goes through

blank rounds and is canceled during hash genera-

tion.

Theorem 1. Suppose |S| > |H|. Given the collision-

resistant message injection, SCHs constructed with

blank rounds whose period of the transition of the in-

ternal state is longer than 2

|H|

and hash generation

which uses the whole internal state to derive the hash

value. Then such SCHs are collision resistant.

Proof. It is obvious that the condition |S| > |H| is re-

quired. SCHs which satisfy lemmas 1, 2, and 3 are se-

cure against case 1, 2, and 3 attacks. Therefore these

SCHs are collision resistant.

Lemma 1. If a message injection has collision resis-

tance, then SCHs can withstant a case 1 attack.

Proof. If there is a collision attack, which is more

efﬁcient than a birthday attack, targeting the inter-

nal state after message injection, then an adversary

can ﬁnd two different messages M, M

′

which have the

same internal states S

msg

= S

′

msg

. With two identi-

cal internal states after the message injection, internal

states during blank rounds and hash generation must

ON A CONSTRUCTION OF STREAM-CIPHER-BASED HASH FUNCTIONS

339

be also identical and two hash values collide. Hence

message injection has to be collision resistant.

Lemma 2. If the assumption in Lemma 1 holds and

the internal state transition during blank rounds is up-

dated cyclically and has a period of 2

|H|

or longer,

SCHs are secure against case 1 and 2 attacks.

Proof. If the internal state transition during blank

rounds is cyclic and its period is 2

|H|

or longer, there

are at least 2

|H|

candidates for the value of the inter-

nal state. Therefore the computational cost required

for the collision attack must exceed 2

|H|/2

. Further-

more, as the internal state is not compressed in blank

rounds, collision resistance of blank rounds is guar-

anteed.

Hence the assumption of Lemma 1 holds and tran-

sition of the internal state in blank rounds has longer

period than 2

|H|

, SCHs are secure against case 1 and

2 attacks.

Lemma 3. If assumptions in Lemma 2 hold and the

hash value is affected by the whole internal state,

SCHs are secure against case 1, 2, and 3 attacks.

Proof. In the hash generation, if all bits of the inter-

nal state affect the hash value, any difference of the

internal state is not canceled, and the slight difference

of the internal state invokes signiﬁcant changes in the

hash value. This ensures that the hash generation is

collision resistant.

Hence if assumptions of Lemma 1 and 2 hold and

the hash value is affected by the whole internal state,

SCHs are secure against case 1, 2, and 3 attacks.

5.1.2 Condition for Collision Resistant SCH

Here we discuss how to build a collision resistant

stream cipher function which satisﬁes the condition

we presume to prove Theorem 1.

• Collision Resistant Message Injection. Suppose

that an x-bit internal state can be controlled by

an x-bit message and this operation does not af-

fect other bits, then the whole internal state can

be controlled with |S|/x-bit message. Hence mul-

tiple bits of the internal state have to be inﬂuenced

by one bit message. In addition to this, the mes-

sage needs to be used more than once to avoid the

internal state being controlled.

By ﬁxing the internal state of the stream cipher

function, the computational cost of attacks can be

reduced. This method is applied by attacks against

Abacus and Boole (Nikoli´c and Khovratovich,

2008; Wilson, 2008; Nikoli´c, 2008). Hence

the security of an SCH is greatly dependent on

whether the adversary can control the internal

state or not. We suppose that the message is in-

put into the internal state by xoring with the value

in the internal state. Here one bit message is xored

with n bits of the internal state at equal intervals.

Then the adversary can control up to an |S|/n-bit

internal state.

|S|−|S|/n

= 2

|S|(n−1)

≥ 2

|H|/2

. (9)

It can be shown that the fewer points that are used

in the message injection, the less computational

cost is required from Eq. (9). When n = 2, the

computational cost of ﬁnding a collision is 2

|S|/4

and when n = |S|, the cost is 2

|S|−1

The following condition is derived for a message

injection to be collision resistant;

|S|(n− 1) ≥ n|H|. (10)

When n = 1, the Eq. (10) does not hold. Therefore

n has to be equal to or greater than 2, n ≥ 2.

• Collision Resistant Blank Rounds. Suppose that

the transition of the internal state in blank rounds

has the period which is longer than 2

|H|

. If the

internal state after the message injection S

msg

different, then the internal state after blank rounds

blk

is also different, since the number of blank

rounds j (j < 2

|H|

) is independent of the message

length. Hence the difference in the internal state

is not canceled during blank rounds. The transi-

tion of the internal state in blank rounds does not

always have the period longer than 2

|H|

in order

to satisfy the collision resistance. If the period

i of the operations performed in blank rounds is

larger than the number of blank rounds j and the

transition does not have the collision point of the

internal state, then such blank rounds imply colli-

sion resistance. In order for blank rounds to have

the period longer than 2

|H|

, a linear feedback shift

be used as one of option. However LFSRs are

vulnerable to correlation attacks, hence other ap-

proaches should be considered.

Blank rounds with i > j ensure the collision re-

sistance and second preimage resistance of blank

rounds.

• Collision Resistant Hash Generation. The inter-

nal state is compressed to derive the hash value in

the hash generation. In this process, all bits of the

internal state have to affect the hash value, oth-

erwise collisions can occur by putting differences

on bits which do not affect the hash value. In or-

der for the hash value to be affected by the whole

internal state, more than one bit of the state has to

SECRYPT 2010 - International Conference on Security and Cryptography

340

be used to generate a bit of hash value. This can

be easily achieved with an n-to-1 ﬁlter function.

As an example, suppose the internal state size is

double the hash size. Then two internal state bits

have to be used to generate a 1-bit hash.

5.1.3 Multi-collision Resistance

Here we give a theorem and proof that collision resis-

tant SCHs are secure against multi-collision attacks.

Theorem 2. Collision resistant SCHs are also multi-

collision resistant.

Proof. Since the internal state size is larger than the

hash size. If the internal state of the stream cipher w

is large enough, there is no efﬁcient way to ﬁnd the

internal state collision, hence a multi-collision attack

does not affect the security of SCHs.

5.2 Second Preimage Resistance

In this section, we consider constructions of second

preimage resistant SCHs.

Theorem 3. Collision resistant hash functions are

also second preimage resistant.

Proof. Generally a collision resistant hash function is

also second preimage resistant (Menezes et al., 1996).

A SCH, which satisﬁes Theorem 1, woudl be second

preimage resistant. Hence collision resistant SCHs

imply second preimage resistant SCHs.

5.3 Preimage Resistance

In this section, a preimage attack and preimage resis-

tance will be explained.

5.3.1 Preimage Resistant SCH

Preimage attack against SCH consists of following

three steps:

1. Against hash generation

Find the internal state S

blk

from the hash value H.

2. Against blank rounds

Find the internal state S

msg

from S

blk

3. Against message injection

Derivethe message M from the internal state S

msg

Theorem 4. If the computational cost of deriving the

internal state S

msg

from S

blk

is more than 2

|H|

, or |S| >

|H|, then SCHs have preimage resistance.

Proof. SCHs which satisfy lemmas 4 or 5 are secure

against attacks in steps 1 or 2, respectively. When an

adversary tries to ﬁnd a preimage of the message, the

adversary has to compute steps 1 to 3, which are de-

scribed at the beginning of this section. We assumed

that |S| > |H| in Theorem 1, therefore step 1 of the

attack is infeasible. Hence, collision resistant SCHs

imply preimage resistant SCHs.

Lemma 4. If the internal state size |S| is larger

than the hash size, |S| > |H|, then the SCH is secure

against the step 1 of the attack.

Proof. The information of |S| − |H| bits of the inter-

nal state will be perished by compressing the |S|-bit

internal state to the |H|-bit hash value. Preimage re-

sistance holds because of this property.

Lemma 5. If blank rounds have preimage resistance,

then the SCH is secure against step 2 of the attack.

Proof. Let the probability of recovering the internal

state by inverting one clock of blank rounds be p, then

inverting j-clock of blank rounds and recovering S

msg

from S

blk

can be denoted as p

. If p

< 2

−|H|

holds,

then blank rounds are preimage resistant.

Since S

msg

is known, it is possible to invert mes-

sage injection to gain the input message, because we

have to assume the case where |M| > |S| as well as the

case where |M| ≤ |S|. Hence, message injection with

preimage resistance hardly exists.

5.3.2 Condition for Preimage Resistant SCH

Here we discuss how to build a preimage resistant

stream cipher function which satisﬁes the condition

we presume to prove Theorem 4.

There are two ways for blank rounds to be preim-

age resistant.

1. Collision occurs during blank rounds.

2. For j-clock blank rounds, p

< 2

−|H|

holds, where

p is the probability of reverting one-clock of blank

rounds and guessing the internal state correctly.

The existence of collision in blank rounds means they

are vulnerable to collision and second preimage at-

tacks. Hence, method 2 is appropriate and the stream

cipher function has to satisfy p

< 2

−|H|

with the

probability p and the number of blank rounds j.

The existence of collision is inevitable if the size

of the internal state is larger than that of the hash

value. However, the collision ensures preimage re-

sistance in the hash generation.

ON A CONSTRUCTION OF STREAM-CIPHER-BASED HASH FUNCTIONS

341

5.4 Length-extension Security

We give the theorem and proof that a preimage resis-

tant SCH is secure against the length-extensionattack.

Theorem 5. Preimage resistant SCHs are secure

against a length-extension attack.

Proof. In SCHs, the hash value H(M||z) is com-

puted independently of the hash value H(M), because

of blank rounds. If an adversary cannot obtain M

from H(M) efﬁciently, the adversary cannot compute

H(M||z). Thus, an SCH is secure against a length-

extension attack, where the SCH has preimage resis-

tance.

6 DISCUSSION

Both attacks against Abacus and Boole exploit the

fact that an adversary can easily cause collisions of

the internal state by tweaking messages. Moreover,

they also exploit the fact that the internal state S

blk

which produces the desired hash value can be derived.

In fact, these ciphers do not satisfy our criterion, i.e.,

“the message injection has to be collision resistant”.

Thus, this evidence supports the feasibility of our cri-

terion.

Relations to the attacks against stream ciphers also

have to be considered. Internal state recovery attacks

such as guess-and-determine attacks (Bleichenbacher

and Patel, 1999) and correlation attacks (Hawkes and

Rose, 2002; Meier and Staffelbach, 1988) obtain in-

ternal state bits from keystream bits. These attacks

can be used for preimage attacks on SCHs. That is,

an attacker can obtain internal state bits from the hash

value if the stream cipher used for the SCH is vulner-

able against an internal state recovery attack. Where

we select a stream cipher algorithm for constructing

an SCH, it is a mandatory condition that the stream

cipher is secure against existing attacks. Recovering

the internal state of the stream cipher function from h-

bit keystream incurs a computational cost of at least

|H|

. If there is an attack which recovers the internal

state of the stream cipher function with a computation

cost of less than 2

|H|

computational cost, this attack

can lead to a pre-image attack against the SCH.

Distinguishing attacks (Coppersmith et al., 2002)

are another possible approach for recovering internal

state bits. A linear approximation of the nonlinear

process is obtained by a distinguishing attack and it is

applicable to recovering internal state bits. The inter-

nal state bits can be determined to solve a system of

linear equations. The attacks require a much longer

keystream than the h-bit hash value, hence, it is rarely

applied to a pre-image attack on the SCH.

Next, we discuss relationships between two spe-

ciﬁc attacks on stream ciphers and our criteria for

constructing SCHs. Two types of attack as shown in

Sect. 4 are relevant to collisions in the blank round.

For example, the chosen IV attack against Py and

Pypy corresponds to the collision attack against blank

rounds in an SCH. In the chosen IV attack against Py

and Pypy, identical keystreams can be generated from

different IVs. Keystreams correspond to hash val-

ues and IVs correspond to internal states. Initializa-

tion of Py and Pypy and blank rounds in an SCH are

basically the same operations, hence this attack can

be applied to collision and second preimage attack

against an SCH. From this view-point, we should use

a stream cipher that is secure against the attacks when

constructing an SCH. Furthermore, security against

these attacks is strongly related to our criterion; blank

rounds have to be executed as the transition of the in-

ternal state has the longer period than 2

|H|

An attack in which the adversary tries to control

the output keystream by inputting a certain ciphertext

can be considered to be an attack against an SSSC

(Joux and Muller, 2003; Joux and Muller, 2006). This

type of attacks can be applied to attacks against blank

rounds of SCHs as discussed in Sect. 4.1. Hence,

the stream cipher functions have to resist this type of

attacks in order to be collision and second preimage

resistant.

7 CONCLUSIONS

In this paper, we introduced a model of SCH, consist-

ing of a pre-computation function and a stream cipher

function. Then we deﬁned the stream cipher func-

tion with pre-computation as the one which updates

an internal state and outputs a hash value from three

inputs: a message, an internal state, and feedback.

Then we showed that the keystream feedback mode

and the self-synchronizing stream cipher are equiva-

lent to SCHs. Therefore, attacks against these stream

ciphers can be various attacks against SCHs. Further-

more we described each phase of SCH with the func-

tion we deﬁned, and considered attacks against each

phase. As a result of our work, the following neces-

sary conditions can be obtained:

• |S| > |H| is required for collision, second preim-

age, and preimage resistance.

• The computational cost of the collision attack on

message injection has to be equal or more than

|H|/2

, and an adversary is not able to control the

internal state of the stream cipher function.

SECRYPT 2010 - International Conference on Security and Cryptography

342

• The internal state transition during blank rounds

has a period of at least 2

|H|

• Deriving the internal state after the message injec-

tion by going through one clock of blank rounds in

reverse order incurs a computational cost of 2

|H|

• When one bit message is xored with n bits of the

internal state at equal intervals, then the condition

|S|(n−1) ≥ n|H| is required for message injection

to be collision resistant, where n is the number of

bits of the internal state which are xored with one

bit message.

In this paper we proposed the conditions for se-

cure SCHs. We showed that conditions for second

preimage and preimage resistant SCH are included in

the conditions for a collision resistant SCH. Further-

more, the condition for length-extension security is

included in the condition for the preimage resistant

SCH. Thus, we can focus on the conditions for the

collision resistant SCH, when we design the SCH.

Consideration of a concrete algorithm for a col-

lision resistant SCH should be the subject of future

work. Especially, we will consider a secure design

of pre-computationand message injection mechanism

for a SCH in the next stage.

REFERENCES

Biham, E. and Seberry, J. (2005). Py : A Fast and Se-

cure Stream Cipher using Rolling Arrays. eSTREAM,

ECRYPT Stream Cipher Project.

Biham, E. and Seberry, J. (2006). Pypy: Another Version

of Py. eSTREAM, ECRYPT Stream Cipher Project.

Bleichenbacher, D. and Patel, S. (1999). Sober crytanalysis.

In Knudsen, L. R., editor, FSE, volume 1636 of LNCS,

pages 305–316. Springer.

Coppersmith, D., Halevi, S., and Jutla, C. S. (2002). Crypt-

analysis of stream ciphers with linear masking. In

Yung, M., editor, CRYPTO, volume 2442 of LNCS,

pages 515–532. Springer.

Ekdahl, P. and Johansson, T. (2002). A New Version of

the Stream Cipher SNOW. In Nyberg, K. and Heys,

H. M., editors, SAC, volume 2595 of LNCS, pages 47–

61. Springer.

Goli´c, J. D. (2001). Modes of Operation of Stream Ciphers.

In Stinson, D. R. and Tavares, S. E., editors, SAC, vol-

ume 2012 of LNCS, pages 233–247. Springer.

Hawkes, P. and Rose, G. G. (2002). Guess-and-Determine

Attacks on SNOW. In Nyberg, K. and Heys, H. M.,

editors, SAC, volume 2595 of LNCS, pages 37–46.

Springer.

Joux, A. (2004). Multicollisions in Iterated Hash Functions.

Application to Cascaded Constructions. In Franklin,

M. K., editor, CRYPTO, volume 3152 of LNCS, pages

306–316. Springer.

Joux, A. and Muller, F. (2003). Loosening the KNOT. In Jo-

hansson, T., editor, FSE, volume 2887 of LNCS, pages

87–99. Springer.

Joux, A. and Muller, F. (2006). Chosen-Ciphertext Attacks

Against MOSQUITO. In Robshaw, M. J. B., editor,

FSE, volume 4047 of LNCS, pages 390–404. Springer.

Meier, W. and Staffelbach, O. (1988). Fast Correlation At-

tacks on Stream Ciphers. In EUROCRYPT, volume

330 of LNCS, pages 301–314. Springer.

Mendel, F., Nad, T., and Schl¨affer, M. (2009). Collision

Attack on Boole. In Abdalla, M., Pointcheval, D.,

Fouque, P.-A., and Vergnaud, D., editors, ACNS, vol-

ume 5536 of LNCS, pages 369–381.

Menezes, A. J., van Oorschot, P. C., and Vanstone, S. A.

(1996). Handbook of Applied Cryptography. CRC

Press.

Nikoli´c, I. (2008). Preimage attack on Boole-

n. The ECRYPT Hash Function Website,

http://ehash.iaik.tugraz.at/uploads/2/2f/Boole.pdf

Nikoli´c, I. and Khovratovich, D. (2008). Second

preimage attack on Abacus. available online,

http://lj.streamclub.ru/papers/hash/abacus.pdf

NIST (1995). Secure hash standard. FIPS180-1.

Rivest, R. (1992). The MD5 message digest algorithm.

RFC1321.

Rose, G. G. (2008). Design and primitive speciﬁca-

tion for Boole. submission to NIST, http://seer-

grog.net/BoolePaper.pdf

Sholer, N. (2008). Abacus a candidate

for SHA-3. submission to NIST,

http://ehash.iaik.tugraz.at/uploads/b/be/Abacus.pdf

Wang, X., Yin, Y. L., and Yu, H. (2005). Finding collisions

in the full SHA-1. In Shoup, V., editor, CRYPTO, vol-

ume 3621 of LNCS, pages 17–36. Springer.

Wang, X. and Yu, H. (2005). How to break MD5 and Other

Hash Functions. In Cramer, R., editor, EUROCRYPT,

volume 3494 of LNCS, pages 19–35. Springer.

Wilson, D. (2008). A second-preimage and col-

lision attack on Abacus. available online,

http://web.mit.edu/dwilson/www/hash/abacus attack.

pdf

Wu, H. and Preneel, B. (2007). Differential Cryptanalysis

of the Stream Ciphers Py, Py6 and Pypy. In Naor, M.,

editor, EUROCRYPT, volume 4515 of LNCS, pages

276–290. Springer.

ON A CONSTRUCTION OF STREAM-CIPHER-BASED HASH FUNCTIONS

343
