SWARM INTELLIGENCE FOR RULE DISCOVERY IN DATA

MINING

Andre B. de Carvalho, Taylor Savegnago and Aurora Pozo

Federal University of Parana, Curitiba PR, Brazil

Keywords:

Particle swarm optimization, Rule induction, Multi-objective optimization.

Abstract:

This paper aims to discuss Swarm Intelligence approaches for Rule Discovery in Data Mining. The ﬁrst

approach is a new rule learning algorithm based on Particle Swarm Optimization (PSO) and that uses a Mul-

tiobjective technique to conceive a complete novel approach to induce classiﬁers, called MOPSO-N. In this

approach the properties of the rules can be expressed in different objectives and then the algorithm ﬁnds these

rules in an unique run by exploring Pareto dominance concepts. The second approach, called PSO/ACO2

algorithm, uses a hybrid technique combining Particle Swarm Optimization and Ant Colony Optimization.

Both approaches directly deal with continuous and nominal attribute values, a feature that current bioinspired

rule induction algorithms lack. In this work, an experiment is performed to evaluated both approaches by

comparing the performance of the induced classiﬁers.

1 INTRODUCTION

Data mining is the overall process of extracting

knowledge from data. In this area, rules are one of

the most used forms to represent the extracted knowl-

edge. This is because of their simplicity, intuitive as-

pect, modularity, and because they can be obtained

directly from a data set (Fawcett, 2001). Therefore,

rules induction has been established as a fundamental

component of many data mining systems.

This work deals with learning classiﬁcation rules,

or rule induction. In the rule induction process, the

algorithm receives a labeled data set as input. This

data set must contain examples with the descriptor

attributes and the class values. This attributes could

have nominal or discrete values. The algorithm looks

to the examples and identiﬁes patterns. These patterns

are going to be represented in rules. A rule is a pair

<antecedent, consequent> or if antecedent then con-

sequent. The antecedent represents the restrictions in

the values of the attributes and the consequent is the

class value. After the end of the learning process, new

examples that arrive can be classiﬁed by the learned

rules.

Although many techniques have been proposed

and successfully implemented, few works take into

account the importance of the comprehensibility as-

pect of the generated models and rules. Other impor-

tant challenge in this area is related to the kind of at-

tributes, previous works with Swarm Intelligence,

have never addressed the case where the data sets con-

tain both continuous and nominal attributes. Consid-

ering this fact, this work discuss two, recently pre-

sented, different algorithms based on Swarm Intel-

ligence for Discovering Rules in data mining con-

text, called MOPSO-N (Carvalho and Pozo, 2008)

and PSO/ACO2 (Holden and Freitas, 2008). Both ap-

proaches directly deal with both continuous and nom-

inal attribute values.

The MOPSO-N (Multi-Objective Particle Swarm

Optimization-N) algorithm is our proposed approach

and was ﬁrst presented in (Carvalho and Pozo, 2008).

It is based on Particle Swarm Optimization (Kennedy

and Eberhart, 1995) (PSO) and uses a multiobjec-

tive approach where the properties of the rules can

be expressed in different objectives and the algorithm

ﬁnds these rules in a unique run. These rules can

be used as an unordered classiﬁer. The proposed al-

gorithm has the goal to generate a good classiﬁer in

terms of the Area Under the ROC Curve, AUC. So,

two objectives were chosen, the sensitivity and speci-

ﬁcity criteria that are directly related with the ROC

curve (Fawcett, 2001). The hypothesis behind these

strategies is that classiﬁers composed by rules that

maximize these objectives present good performance

in terms of AUC. The MOPSO-N algorithm was val-

idated using the AUC and comparing its performance

to other well known traditional rule induction algori-

314

B. de Carvalho A., Savegnago T. and Pozo A. (2010).

SWARM INTELLIGENCE FOR RULE DISCOVERY IN DATA MINING.

In Proceedings of the 12th International Conference on Enterprise Information Systems - Artiﬁcial Intelligence and Decision Support Systems, pages

314-319

DOI: 10.5220/0002966303140319

 SciTePress

thms like C4.5, NNge and RIPPER. In this experiment

the algorithm obtained good results, very competitive

with the other algorithms.

The PSO/ACO2, was proposed by Holden and

Freitas in (Holden and Freitas, 2008), uses a hybrid

technique combining Particle Swarm Optimization

and Ant Colony Optimization (Dorigo and St

utzle,

2004). The algorithm uses a traditional sequential

covering approach to discover one rule at a time. This

rule is found by a two steps one run of the Ant Colony

algorithm searches a rule based on nominal attributes

and after then a conventional PSO algorithm with

constriction use this rule as a base for the discovery

of a rule with continuous values. The algorithm was

evaluated on 27 public domain benchmark data sets

used in the classiﬁcation literature, and the authors

showed that PSO/ACO2 is at least competitive with

PART in terms of accuracy and that PSO/ACO2 often

generates a simpler rule sets.

After, the study of these systems, some impor-

tant differences between both systems can be noticed:

the multiobjective versus the sequential covering ap-

proaches, and the hybrid PSO/ACO versus the pure

PSO to deal with nominal and continuous attributes.

In this work, the main aspects of both algorithms

are presented and them an empirical set of experi-

ments is made. This experiments has the goal to com-

pare both Swarm Intelligence algorithms, MOPSO-N

and PSO/ACO2. The algorithms are evaluated com-

paring the performance of the induced classiﬁers in

respect to the accuracy and ROC graph analysis.

The rest of this paper is organized as follows.

Section 2 reviews mains concepts of Multiple Ob-

jective Particle Swarm and describes the MOPSO-

N algorithm. Section 3 gives a brief review of the

PSO/ACO2 algorithm. In Section 4 the experiments

are discussed. Finally, Section 5 concludes the paper

and discusses future works.

2 RULE LEARNING WITH

MULTIOBJECTIVE PARTICLE

SWARM OPTIMIZATION

This section presents the main aspects of Multiobjec-

tive Particle Swarm Optimization and the proposed al-

gorithm, MOPSO-N. First, Section 2.1 discuss some

interest topics of the MOPSO metaheuristic. In Sec-

tion 2.2, the MOPSO-N algorithm is presented.

2.1 Multiobjective Particle Swarm

Optimization

Particle Swarm Optimization (Kennedy and Eberhart,

1995) (PSO) works with a population-based heuristic

inspired by the social behavior of bird ﬂocking aim-

ing to ﬁnd food. . In Particle Swarm Optimization the

system initializes with a set of solutions and searches

for optima by updating generations. The set of possi-

ble solutions is a set of particles, called swarm, which

moves in the search space, in a cooperative search

procedure. These moves are performed by an oper-

ator called velocity of a particle and moves it through

an n-dimensional space based on the best positions of

their leader (social component) and on their own best

position (local component).

Optimization problems with two or more objec-

tive functions are called Multiobjective. In such prob-

lems, the objectives to be optimized are usually in

conﬂict, which means that there is not a single solu-

tion for these problems and the goal is to ﬁnd a good

trade-off of solutions that represent the better possible

compromise among the objectives. The general multi-

objective maximization problem (with no restrictions)

can be stated as to maximize (1).

−→

f (

−→

x ) = ( f

(

−→

x ), ..., f

(

−→

x )) (1)

subjected to

−→

x ∈ Π, where:

−→

x is a vector of decision

variables and Π is a ﬁnite set of feasible solutions. Let

−→

x ∈ Π and

−→

y ∈ Π be two solutions. For a maximiza-

tion problem, the solution

−→

x dominates

−→

y if:

∀ f

∈

−→

f , i = 1...Q, f

(

−→

x ) ≥ f

(

−→

y ), and

∃ f

∈

−→

f , f

(

−→

x ) > f

(

−→

y )

−→

x is a non-dominated solution if there is no solution

−→

y that dominates

−→

x .

The goal is to discover solutions that are not dom-

inated by any other in the objective space. A set of

non-dominated solutions is called Pareto optimal and

the set of all non-dominated objective vectors is called

Pareto Front.

In Multiobjective Particle Swarm Optimization

there are many ﬁtness functions. By exploring Pareto

dominance concepts, it is possible to obtain results

with speciﬁc properties. Based on this concept each

particle of the swarm could have different leaders, but

only one may be selected to update the velocity. This

set of leaders is stored in a repository, which contains

the best non-dominated solutions found. The MOPSO

components are deﬁned as follows.

Each particle p

, at a time step t, has a position

x(t) ∈ R

, that represents a possible solution. The

position of the particle, at time t + 1, is obtained by

adding its velocity, v(t) ∈ R

, to x(t):

−→

x (t + 1) =

−→

x (t) +

−→

v (t +1) (2)

SWARM INTELLIGENCE FOR RULE DISCOVERY IN DATA MINING

315

The velocity of a particle p

is based on the best posi-

tion already fetched by the particle,

−→

best

(t), and the

best position already fetched by the set of neighbors

of p

−→

(t), that is a leader from the repository. The

velocity update function, in time step t + 1 is deﬁned

as follows:

−→

v (t +1) = ϖ ∗

−→

v (t)+

+ (c

∗ φ

) ∗ (

−→

best

(t) −

−→

x (t)) +

+ (c

∗ φ

) ∗ (

−→

(t) −

−→

x (t)) (3)

The variables φ

and φ

, in Equation 3, are coefﬁ-

cients that determine the inﬂuence of the particle’s po-

sitions. The constants c

and c

indicates how much

each component inﬂuences on the velocity. The coef-

ﬁcient ϖ is the particle inertia and controls how much

the previous velocity affects the current one.

−→

is a

particle from the repository, chosen as a guide of p

There are many ways to make this choice. At the end

of the algorithm, the solutions in the repository are

the ﬁnal output. One possible way to make the leader

choice is called the sigma distance (Mostaghim and

Teich, 2003).

2.2 MOPSO-N Algorithm

MOPSO-N was proposed to handle with both numer-

ical and discrete attributes. In this way, it can be used

in different domains, mainly those ones with contin-

uous attributes. It was ﬁrst introduced in (Carvalho

and Pozo, 2008). In this section, MOPSO-N aspects,

such as representation and generation of the particles

are described.

The algorithm uses the Michigan approach where

each particle represents a single solution or a rule.

In this context, a particle is an n-dimensional vector

of real numbers. One integer number represents the

value for each discrete attribute and two real numbers

represent an interval for numerical attributes. The in-

terval is deﬁned by its lower and upper values. Each

attribute can accept the value ’?’, which means that,

for that rule, the attribute does not matter for the clas-

siﬁcation. In the proposed approach the class value

is set in the beginning of the execution. To represent

the particle as a possible solution, the attributes values

must be codiﬁed into real numbers. The codiﬁcation

of the discrete attributes is conceived by real numbers

related to each attribute value of the database. When a

numerical attribute has a void value, their cells in the

particle representation receive the lower bound value

available on the database.

The rule learning algorithm using MOPSO-N

works as follows. The initialization procedure ran-

domly spreads all particles in the search space and

initializes the components of the particle. In this

process, the discrete attributes are deﬁned by using

a roulette procedure, where the most frequent val-

ues have higher probabilities. The probability of the

generic value of each attribute, ’?’, is a function of the

number of possible values for the attribute. For the

numerical attributes, ﬁrst, all attributes have the prob-

ability to be empty, prob empty. If an attribute is set

as non-empty, the lower and upper limits are spread

randomly in the interval deﬁned by the minimum and

maximum values for the attribute (obtained from the

data set). After then, the particle’s components, like

velocity and local leader are initialized.

Once the initial conﬁguration is performed, the

evolutionary loop is executed performing the moves

of all particles in the search space. In this work the

stop criterion is the maximum number of generations.

In each iteration, initially, the operations discussed in

the previous section are implemented.

In the position update, a mod operator is applied.

This operation is used to limit the particle into the

search space and to to promote equal probability of

selection to each attribute values. For discrete at-

tributes, the values are bounded to the number of val-

ues for each attribute. For the numerical ones, a mod

operator is proposed. It is executed using the maxi-

mum and minimum values of the attribute. If the new

upper limit overﬂows the maximum value, the excess

is added to the minimum value, and that is the new

limit. After this process, the smaller value is the new

lower limit, and the larger is the upper. If both val-

ues overﬂow the limits, the attributes are set to empty

(’?’).

After all particles have been moved through the

search space, they are evaluated using the objectives

and once again the best particles are loaded in the

repository and the global leaders are redeﬁned. A

procedure checks for more general or speciﬁc rules

in the repository before a rule is added to it. A rule

is more speciﬁc than other rule if it has less attribute

constraints and the same contingency table. Only the

more general rules are kept in the archive.

At the end of the execution, the rules are usually

aggregated into a rule set to build a classiﬁer. After,

the classiﬁer can be used to classify unseen instances.

The classiﬁcation of a new instance is performed by

a voting process. In the voting process, all rules vote

the class of the instances. The process contains the

following steps: for each class, all rules that cover

the input instance are identiﬁed. The identiﬁed rules

are sorted according to some ordering criteria. This

work uses the Laplace Accuracy, discussed in (Yanbo

J. Wang and Coenen, 2006). The ordering process is

applied to allow the selection of only the best k rules,

according to the ordering criteria, to vote the class of

ICEIS 2010 - 12th International Conference on Enterprise Information Systems

316

the instance. This number can vary from one rule to

all rules. The next step counts the votes of each class.

Finally, the class that scores higher is declared as the

class of the example.

3 THE PSO/ACO2 ALGORITHM

The PSO/ACO2 (Holden and Freitas, 2008) algorithm

achieves a native support of nominal data by com-

bining ideas from ant colony optimization (Dorigo

and St

utzle, 2004) and particle swarm optimiza-

tion (Kennedy and Eberhart, 1995) to create a classiﬁ-

cation metaheuristic that supports innately both nom-

inal and continuous attributes.

The algorithm uses a traditional sequential cover-

ing approach to discover one classiﬁcation rule at a

time. The sequential covering approach starts with an

empty set of rules. Then, for each class the algorithm

performs a WHILE loop, where TS is used to store

the set of training examples the rules will be created

from. On each iteration of this loop, one run of the

ant colony algorithm ﬁnds a rule based on nominal

attributes. This rule is used as a base for the discov-

ery of a rule with continuous values. For the contin-

uous part of the rule, a conventional PSO algorithm

with constriction is used. The PSO algorithm returns

the best discovered rule (BestRule). After the Be-

stRule has been generated it is then added to the rule

set, but, after a pruning procedure inspired by Ant-

Miner’s pruning procedure (Parpinelli et al., 2002).

Finally, the algorithm removes all the examples cov-

ered by the rule from TS and the process is repeated

with the remaining examples, and continues until the

maximum number of uncovered examples per class

(MaxUncovExampPerClass) is reached. When this

threshold has been reached TS is reset by adding all

the previously covered examples. This process means

that the rule set generated is unordered and is submit-

ted to an ordered process, considering a quality mea-

sure. The measure used to estimate the quality of a

rule is the Laplace-corrected Precision. Also, after the

rule set has been ordered it is pruned as a whole. The

pruned process involves tentatively to remove terms

from each rule and seeing if each term’s removal af-

fects the accuracy of the entire rule set. After this pro-

cess is complete, the algorithm also removes whole

rules that do not contribute to the classiﬁcation accu-

racy.

The algorithm was evaluated on 27 public do-

main benchmark data sets used in the classiﬁcation

literature, and the authors shown that PSO/ACO2 is

at least competitive with PART, an industry standard

classiﬁcation algorithm, in terms of accuracy, and that

Table 1: Description of data sets used in the experiments.

# Data set Attributes Examples % of Majority Class

1 breast 10 683 65.00

2 bupa 7 345 57.97

3 ecoli 8 336 89.58

4 ﬂag 29 174 91.23

5 glass 10 214 92.05

6 haberman 4 306 73.52

7 heart 14 270 55.00

8 ionosphere 34 351 64.10

9 new-thyroid 6 215 83.72

10 pima 9 768 65.51

11 vehicle 19 846 76.47

PSO/ACO2 often generates much simpler rule sets.

However, the authors also comment that PSO/ACO2

is partly greedy in the sense that it builds each rule

with the aim of optimizing that rule’s quality individ-

ually, without directly taking into account the interac-

tion with other rules.

4 EXPERIMENTS

This Section describes an experiment to compare the

two Swarm Intelligence algorithms, MOPSO-N and

PSO/ACO2. The classiﬁcation results of MOPSO-

N, PSO/ACO2 are evaluated using the accuracy mea-

sure and through ROC Graph analysis. Section 4.1

presents the methodology used in the experiment and

Section 4.2 presents the results.

4.1 Methodology

For the experiments, both algorithms were evaluated

through 11 databases from the UCI machine learn-

ing repository (Asuncion and Newman, 2007)(Ta-

ble 1). The experiments were executed using 10-fold-

stratiﬁed cross validation and for all algorithms were

given the same training and test ﬁles.

In the experiments two comparison were made:

comparison of the accuracy and a ROC Graph anal-

ysis. The accuracy (4) relates the total number

of instances correctly classiﬁed, True Positive (T P)

and True Negative (T N), to the total number of

instances(N

inst

Accuracy =

T P + T N

inst

(4)

The non-parametric Wilcoxon test, with 5% con-

ﬁdence level, was executed to deﬁne which algorithm

is better. It was adopted the methodology presented

in (Dem

sar, 2006). Here, the Wilcoxon test was ap-

plied with all accuracy values for all data sets.

SWARM INTELLIGENCE FOR RULE DISCOVERY IN DATA MINING

317

Table 2: Average values of accuracy and number of rules

for each algorithm.

Data set

MOPSO-N PSO/ACO2

Accuracy # Rules Accuracy # Rules

1 95.18 (1.38) 80.51 96.62 (1.95) 7.4

2 65.78 (5.63) 164.97 69.29 (6.30) 22.3

3 90.60 (32.09) 60.63 89.26 (5.91) 5.6

4 90.76 (3.38) 53.59 89.21 (4.45) 5.4

5 91.61 (16.22) 57.73 90.23 (5.50) 5.4

6 75.30 (10.50) 185.97 73.19 (9.03) 13.2

7 80.00 (8.93) 162.06 80.00 (10.50) 11.4

8 85.14 (6.55) 66.6 83.75 (7.01) 3.9

9 93.52 (9.89) 36.8 94.93 (3.97) 2

10 74.18 (4.59) 243.46 73.95 (6.21) 32.4

11 85.58 (3.2) 142.02 95.02 (2.43) 14.4

The second comparison has the goal to compare

the classiﬁcation of the Swarm Intelligence algo-

rithms in terms of a ROC Graph analysis. This anal-

ysis is considered a relevant criterion to deal with im-

balanced data, misclassiﬁcation costs and noisy data.

The ROC Graph relates the false positive rate, f pr,

(axis-x) and the true positives rate, t pr, (axis-y) of a

classiﬁer (Fawcett, 2001).

To compare the classiﬁcation results of classiﬁers,

often it is used the Area Under the ROC Curve (AUC).

However the PSO/ACO2 implementation used do not

return this measure. To overcome this limitation, in

this experiment was performed a multiobjective anal-

ysis based on the ROC Graph. To determine which

algorithm has better performance it was applied the

dominance ranking (Zitzler and Thiele, 1999). Dom-

inance ranking stands for a general, preference inde-

pendent assessment method that is based on pairwise

comparisons. Here, each execution of both algorithm

was compared. In this analysis, for each fold of data

set, the execution of both algorithms is compared,

and the test indicates which algorithm dominates the

other, i.e., has greater values of t pr and lower values

of f pr. After the execution of the dominance ranking

between MOPSO-N and PSO/ACO2, the Wilcoxon

test was performed to deﬁne which algorithm has the

best ranking.

The MOPSO-N parameter are: 100 generations,

500 particles, for each fold, one run was performed,

ω, φ

and φ

, randomly vary [0, 0.8], [0,1]and[0, 1],

respectively, c

and c

were deﬁned as 2.05 and

textttprob empty was empirically set to 0.1.

The PSO/ACO2 classiﬁcation algorithm is freely

available

and was executed with the default parame-

ters presented in (Holden and Freitas, 2008). There,

the authors used 100 iterations and 100 particles, for

each call to the PSO algorithm, and the ﬁtness func-

tion adopted was the precision of the rule.

Available at http://sourceforge.net/projects/psoaco2.

Table 3: Average values of tpr and fpr for each algorithm.

Data set

MOPSO-N PSO/ACO2

t pr f pr t pr f pr

1 87.90 (9.89) 2.46 (2.66) 97.53 (2.66) 5.00 (4.73)

2 32.28 (11.47) 10.00 (8.81) 61.95 (16.21) 25.50 (9.55)

3 14.16 (19.26) 0.00 (0.00) 95.84 (3.76) 57.50 (23.38)

4 5.00 (15.81) 0.58 (1.86) 97.71 (2.95) 100.00 (0.00)

5 5.00 (15.81) 1.55 (3.52) 97.71 (2.95) 100.00 (0.00)

6 24.72 (13.20) 4.92 (5.37) 86.71 (7.52) 64.86 (23.76)

7 75.83 (15.44) 17.33 (10.97) 72.50 (11.81) 13.33 (13.69)

8 67.37 (15.06) 2.64 (4.26) 92.43 (6.61) 31.79 (19.30)

9 64.16 (30.18) 0.00 (0.00) 98.88 (3.51) 8.33 (18.00)

10 93.20 (3.55) 60.11 (12.10) 61.86 (11.20) 19.60 (5.94)

11 40.81 (13.14) 0.62 (0.80) 87.97 (6.71) 2.79 (2.05)

Figure 1: Box plot of the accuracy values for MOPSO-N

and PSO/ACO2 for all data sets.

4.2 Swarm Intelligence Algorithms

Comparison

The average values of accuracy and number of rules

(average of 10 folds values) for each data set are pre-

sented in Table 2. The number between brackets indi-

cates the standard deviation.

For the Wilcoxon test, the p-value obtained was

0.3938, so both algorithms have equivalent results.

Figure 1 shows the box plot of the accuracy values

used in the test. This result shows that the MOPSO-

N algorithm has good classiﬁcation results in terms

of accuracy, although it has the main concern to gen-

erate good values of AUC. However the PSO/ACO2

generates a smaller number of rules than MOPSO-N.

This characteristic is attractive, since a simple classi-

ﬁer can be more understandable.

For the second comparison the values for t pr and

f pr for all data sets were evaluated through the domi-

nance rank test. Table 3 presents the average value of

t pr and f pr (average of 10 folds values) for all data

sets obtained for each algorithm.

In this experiment the MOPSO-N algorithm ob-

tained better results than PSO/ACO2, according to

Wilcoxon test, with p-value = 0.0013. It can be ob-

served that MOPSO obtained very good values of

ICEIS 2010 - 12th International Conference on Enterprise Information Systems

318

f pr, even when dealing with unbalanced data. As

example, for data set 4, MOPSO obtained f pr =

0.58, while PSO/ACO2 obtained f pr = 100, i.e.,

while MOPSO makes few mistakes, the PSO/ACO2

classiﬁes almost every instance as the positive class.

The PSO/ACO2 algorithm obtained better values of

t pr than MOPSO-N, i.e., PSO/ACO2 makes more

hits then MOPSO-N, however these hits are obtained

through a classiﬁcation that produces a high number

of errors. These very good values of f pr made the

MOPSO algorithm had good results in the dominance

ranking test, since their results are rarely dominated

by the PSO/ACO2 results.

These results stress that our approach has good

classiﬁcation results when analyzing the results

through the ROC Graph. This conﬁrms the hypothe-

sis that maximizing the Sensitivity and the Speciﬁcity

of rules will generate a good classiﬁer.

5 CONCLUSIONS

This work explores the Swarm Intelligence in rule

learning context. Two different algorithms based

on these concepts are discussed: MOPSO-N and

PSO/ACO2. The MOPSO-N algorithm has the fol-

lowing properties: ﬁrst, MOPSO-N uses a Multiob-

jective approach that allows us to create classiﬁers in

only one execution. This method works ﬁnding the

best non-dominated rules of a problem, by selecting

them in the rules generation process. Second, the al-

gorithm deals with both numerical and discrete data.

The PSO/ACO2 explores a hybrid approach using a

sequential covering algorithm that combines the ant

colony optimization technique to learn the nominal

part of a rule, and the particle swarm optimization

technique to deal with the continuous part of a rule.

Then, an empirical study was made to compare

these two approaches. Both algorithms are equiva-

lent in terms of accuracy, but the MOPSO-N outper-

forms the PSO/ACO2 in ROC Graph Analysis. The

PSO/ACO2 algorithm has the advantage to generate a

smaller set of rules and them to generate a more com-

prehensive model. Also, this study complements the

results presented in (Carvalho and Pozo, 2008) and

showed that the MOPSO-N algorithm has also good

classiﬁcations results when compared to a bioinspired

algorithm.

Future works include: the execution of a greater

number of experiments to validate the initial results,

the comparison of our approach with other known al-

gorithms in the literature, and enhancements of the

algorithm to proﬁt a more diverse set of rules with-

out increasing the size of the rule set, for example,

the prune procedure implemented by the PSO/ACO2

algorithm must be investigated.

REFERENCES

Asuncion, A. and Newman, D. J. (2007).

UCI Machine Learning Repository,

[http://www.ics.uci.edu/∼mlearn/MLRepository.html].

Irvine, CA: University of California, School of Infor-

mation e Computer Science.

Carvalho, A. B. and Pozo, A. (2008). Non-ordered data

mining rules through multi-objective particle swarm

optimization: Dealing with numeric and discrete at-

tributes. In Poceedings of Hybrid Intelligent Sys-

tems, 2008. HIS ’08. Eighth International Conference,

pages 495–500.

Dem

sar, J. (2006). Statistical comparisons of classiﬁers

over multiple data sets. J. Mach. Learn. Res., 7:1–30.

Dorigo, M. and St

utzle, T. (2004). Ant Colony Optimiza-

tion. The MIT Press.

Fawcett, T. (2001). Using rule sets to maximize ROC per-

formance. In IEEE International Conference on Data

Mining, pages 131–138. IEEE Computer Society.

Holden, N. and Freitas, A. A. (2008). A hybrid pso/aco

algorithm for discovering classiﬁcation rules in data

mining. Journal of Artiﬁcial Evolution Applications,

2008(3):1–11.

Kennedy, J. and Eberhart, R. (1995). Particle swarm opti-

mization. In IEEE International Conference on Neu-

ral Networks, pages 1942–1948. IEEE Press.

Mostaghim, S. and Teich, J. (2003). Strategies for ﬁnding

good local guides in multi-objective particle swarm

optimization. In SIS ’03 Swarm Intelligence Sym-

posium, pages 26–33. Proceedings of the 2003 IEEE

Swarm Intelligence Symposium. IEEE Computer So-

ciety.

Parpinelli, R., Lopes, H., and Freitas, A. (2002). Data

Mining with an Ant Colony Optimization Algorithm.

IEEE Trans on Evolutionary Computation, special is-

sue on Ant Colony Algorithms, 6(4):321–332.

Yanbo J. Wang, Q. X. and Coenen, F. (2006). A novel rule

ordering approach in classiﬁcation association rule

mining. International Journal of Computational In-

telligence Research, 2(3):287–308.

Zitzler, E. and Thiele, L. (1999). Multiobjective Evolu-

tionary Algorithms: A Comparative Case Study and

the Strength Pareto Approach. IEEE Transactions on

Evolutionary Computation, 3(4):257–271.

SWARM INTELLIGENCE FOR RULE DISCOVERY IN DATA MINING

319
