Service Orchestration for Linking Open

Data: Applying a SOA Principle to the Web of Data

Christian Sadilek

, Rainer Simon

and Bernhard Haslhofer

Austrian Institute of Technology, Digital Memory Engineering Group

Donau-City-Str. 1, 1220 Vienna, Austria

University of Vienna, Department of Distributed and Multimedia Systems

Liebiggasse 4/3-4, 1010 Vienna, Austria

Abstract. The rising popularity of RESTful Web services has recently motivated

the extension of existing service orchestration engines to support the composition

of services that do not rely on machine-readable descriptions. At the same time,

within the Linking Open Data initiative, data sets are published conforming to

the Linked Data principles, which can be naturally achieved by exposing RDF

data through RESTful interfaces. In this position paper, we motivate the use of

service orchestration to deﬁne workﬂows for interlinking open data. We introduce

the design of an abstract workﬂow for the semantic enrichment of such data with

the purpose of providing an integrated view on otherwise isolated data sources.

Finally, based on this abstract workﬂow we present early work on a concrete

implementation and report on our experiences.

1 Introduction

The W3C Linking Open Data (LOD) community project

aims to create a Web of in-

terlinked datasets based on the Resource Description Framework (RDF) and following

the Linked Data principles

. These principles demand that exposed data objects on the

Web are identiﬁed with dereferenceable HTTP URIs, providing both human and ma-

chine readable representations and include links to other resources. These demands are

inherently supported for data objects exposed through services that follow the REST ar-

chitectural style [1], also referred to as RESTful Web services [2]. Likewise, Battle and

Benson point out that RDF is capable of semantically describing and aligning data from

disparate sources, but the lack of standard or agreed-upon access methods prevents the

widespread use of such data, and consequently argue that the REST methodology is a

natural ﬁt for Semantic Web operations as it integrates well with its resource paradigm

[3]. The emerging number of frameworks (e.g. RESTEasy

, Restlet

), APIs (e.g. Ama-

zon

, Yahoo

) and programming standards [4] indicate the recently growing popularity

http://esw.w3.org/topic/SweoIG/TaskForces/CommunityProjects/LinkingOpenData/

http://www.w3.org/DesignIssues/LinkedData.html

http://jboss.org/resteasy

http://www.restlet.org/

http://aws.amazon.com

http://developer.yahoo.com

Sadilek C., Simon R. and Haslhofer B.

Service Orchestration for Linking Open Data: Applying a SOA Principle to the Web of Data.

DOI: 10.5220/0002971100670072

In Proceedings of the International Joint Workshop on Technologies for Context-Aware Business Process Management, Advanced Enterprise Architecture and Repositories and Recent

Trends in SOA Based Information Systems (ICEIS 2010), page

ISBN: 978-989-8425-09-6

of RESTful Web services. This popularity has led to extensions of existing service or-

chestration engines like Apache ODE

to incorporate this type of services, which are not

built upon machine-readable descriptions. As a fundamental building block of service

oriented architectures, service orchestration is an approach to service composition that

describes how Web services interact [5]. It enables the deﬁnition of executable work-

ﬂows as combination of Web services to support compositionality and reuse without

demanding locally deployed services [6]. In this paper, we argue that due to these ben-

eﬁts, executable workﬂows can simplify and further facilitate the interlinking of open

data. We present the design and implementation of a workﬂow for semantic enrichment

of unstructured content from existing applications to integrate it in the Web of Data.

2 Background and Related Work

Service orchestration for Semantic Web services is also addressed by Nitzsche et al.

presenting an extension to BPEL

using a WSDL-less interaction model [7]. The ex-

tension, called BPEL4SWS, motivated the implementation of an execution engine for

semantic business processes [8]. Other approaches are based on templates [9] or a novel

programming language [10]. For our work, we are aiming to use standard-conforming

BPEL instances without process description extensions to facilitate the support for dif-

ferent service orchestration engines which we argue is crucial to maintain reusability.

A system that employs Named Entity Recognition (NER) and human feedback to

link news content to DBpedia

is shown by Kobilarovet al. in [11]. A frameworknamed

Silk that enables discovering RDF links using a declarative language for specifying

link conditions is presented by Bizer et al. in [12], and Raimond et al. introduce an

algorithm for automatic interlinking of music datasets in [13]. Further, a solution for

ﬁnding equivalent geospatial entities in the Web of Data for creating links between

them is given by Auer et al. in [14].

We present a semi-automatic approach which incorporates workﬂows and human

feedback. Our work is complementaryto the aforementioned approaches as it also oper-

ates on extracted entities within different data sources in order to discover relationships

between them. In fact, if Web service interfaces were implemented on top of these exist-

ing components they could be employed as services within workﬂows for interlinking

open data. Within our workﬂows an optional step is carried out prior to link discovery

to identify named entities of different types in unstructured content using existing entity

recognition services.

3 Workﬂow Design

The abstract workﬂow depicted in Fig. 1 is suitable for interlinking open data. The

workﬂow exposes a service that takes a query string as parameter and initiates the

workﬂow’s execution. This query string is used to formulate a search request for a LOD

http://ode.apache.org

www.oasis-open.org/committees/wsbpel

http://dbpedia.org

Fig.1. Abstract workﬂow for interlinking open data. Assign activities and result polling have

been omitted for brevity.

source to retrieve the source data set. The ﬁrst activity of the Link Resources scope in-

vokes an Entity Recognition Service in order to analyze textual ﬁelds and return named

entities found in the text. This activity can be skipped if link discovery can be carried

out based on existing entities in the source data. The subsequent invocation of the Link

Discovery Service aims to retrieve dereferenceable URIs for the identiﬁed entities. As

RDF/XML is assumed to be the representation format, it is possible to execute XPath

expressions against the source data and to formulate a loop for iterating through all

resources in the source data set. The loop iterations can safely be executed in parallel

because iterations operate on distinct resources without any shared mutable state. How-

ever, avoiding the overutilization of external services is an argument for sequential loop

iteration. The described two-step approach to linking resources offers a certain ﬂexibil-

ity. For example: A Geoparser

could be employed as an Entity Recognition Service

to parse unstructured content for location names and return the discovered entities em-

bedded in XML. Then a service like GeoNames

could be used as a Link Discovery

Service to return dereferenceable URIs for the corresponding locations. We will de-

scribe an additional application of this approach in greater detail in the next section.

If the returned URIs are complemented by values that express the certainty of the

matching concept, or in the case that multiple URIs are returned for ambiguous entities,

http://www.w3.org/TR/xpath

http://geoparser.digmap.eu/

http://www.geonames.org

a decision will have to be made before assigning the link and updating the resource

to ensure the semantic validity. This decision is based on the condition of the activity

isLinkCertaintyAcceptable. It could for example be based on a threshold for the deter-

mined certainty or on an XPath count operation for the number of links in the provided

service output. If the condition evaluates to true the link to the URI will be created and

assigned to the resource. Finally, the resource is modiﬁed by sending an update request

to the LOD source. This is done by either sending an SPARQL/Update

statement,

if provided by the Link Discovery Service, or using a HTTP PUT request to send the

updated triples as RDF/XML representation. In case the condition evaluates to false, a

separate service will be invoked that collects decisions to be made collaboratively by

users. In this case the resource will be updated as soon as the positive decision has been

made.

For the invocation of asynchronous operations on RESTful Web services we have

decided to use a result polling mechanism as an alternative to callbacks based on mes-

sage correlation. The latter requires the introduction of state to any implementation

case which violates the key REST principle of stateless communication. It is therefore

assumed that for such invocations on RESTful Web services a task or job identiﬁer is

synchronously returned which in turn can be used to frequently poll for the result within

a loop activity as shown in Fig. 2. This activity is terminated as the result becomes avail-

able.

Fig.2. Invocation of a RESTful Web service with result polling as an alternative to callbacks

based on message correlation.

4 Workﬂow Implementation

The prototypical implementation of the abstract workﬂow presented in the previous

chapter makes use of a LOD source for multimedia annotations. This data source is

utilized by a set of Web applications that enable users to collaboratively associate their

knowledge with multimedia objects and fragments in the form of unstructured text. The

use case we implement is to semantically enrich these user-contributed annotations by

linking them to matching geographic resources using the rdfs:seeAlso predicate with

the purpose of being able to provide an integrated view on these resources. Although

the workﬂow is currently executed on a batch job basis, the annotation application’s

http://www.w3.org/Submission/SPARQL-Update/

architecture would allow to conﬁgure workﬂow invocations on certain pre-deﬁned ap-

plication events (e.g. when an annotation is created, referred to or updated).

The workﬂow is implemented in BPEL 2.0 using Apache ODE 1.3.3 as a service or-

chestration engine. ODE includes a set of WSDL 1.1 extensions to describe invocations

of RESTful Web service operations. The workﬂow is querying the recently added anno-

tations at the RESTful annotation backend. The user contributed content is then sent to

OpenCalais

, a service that creates semantic metadata based on unstructured text. The

OpenCalais Web service returns the metadata as resources represented in RDF/XML.

Therefore, the relevant links can be extracted and added to the annotation model. Open-

Calais serves as both an Entity Recognition Service and a Link Discovery Service here.

The provided resource type and relevance ﬁelds can be used to decide which links

should be stored directly and which should be accepted by users ﬁrst and therefore

need to be sent to the decision system. In this example, we have decided to accept all

links to cities and countries (of types http://s.opencalais.com/1/type/er/Geo/City and

http://s.opencalais.com/1/type/er/Geo/Country) with a relevance score above 0.7. It is

only a matter of adapting the selection criteria to change the workﬂow to identify and

link to entities of a different domain or category like person for instance.

5 Conclusions

In this paper, we have exempliﬁed how orchestration of RESTful Web services can fa-

cilitate the interlinking of open data. We have deﬁned a basic abstract workﬂow that

utilizes named entity recognition and link discovery services, and is augmented by a

decision stage in which ambiguous link occurrences can be resolved through human in-

tervention. Furthermore, we have motivated that LOD sources should support updates

of resources using either an RDF/XML representation or the SPARQL/Update language

to enable the collaborative interlinking of open datasets. We have not aimed to create

semantic bridges for existing services by either mapping ﬁelds and parameters to an

ontology or by wrapping or even recreating services to map REST operations to Se-

mantic Web operations. The only requirement for the services used was the existence

of an XML Schema

to deﬁne how to access input and output data.

The initial motivation for our work was that we currently see a gap between the vast

amount of content created on the Web in partly unstructured, distributed and collabora-

tive manner and the Web of Data which is built on the notion of publishing structured

data using machine readable languages. We have shown that this challenge can be ad-

dressed by employing established technologies for Enterprise Information Systems: By

offering an infrastructure that can access content from various sources and tie together

different named entity recognition and link discovery services quickly and effortlessly,

they can unlock content from existing applications for the domain of the Semantic Web.

For future work, we will focus on improving the decision system to better sup-

port the (collaborative) human interaction within the workﬂows. We plan to experiment

with a broad range of services using different service orchestration engines and work-

ﬂow languages to research how to efﬁciently modify records in the Web of Data using

http://www.opencalais.com

http://www.w3.org/XML/Schema

executable workﬂows and to ﬁnd ways to integrate these workﬂows into existing appli-

cations.

Acknowledgements

This work has been partially supported by the EuropeanaConnect Targeted Project for

digital libraries, as part of the eContentplus Program of the European Commission.

References

1. Fielding, R.T.: Architectural styles and the design of network-based software architectures.

PhD thesis, University of California, Irvine (2000)

2. Richardson, L., Ruby, S.: RESTful Web Services. O’Reilly (2007)

3. Battle, R., Benson, E.: Bridging the semantic Web and Web 2.0 with Representational State

Transfer (REST). J. Web Sem. 6 (2008) 61–69

4. Hadley, M., Sandoz, P.: JAX-RS: The Java API for RESTful Web Services. Java Speciﬁca-

tion Request (JSR) 311 (2007)

5. Peltz, C.: Web Services Orchestration and Choreography. Computer 36 (2003) 46–52

6. Chen, L., Wassermann, B., Emmerich, W., Foster, H.: Web service orchestration with BPEL.

In: ICSE ’06: Proceedings of the 28th international conference on Software engineering,

New York, NY, USA, ACM (2006) 1071–1072

7. Nitzsche, J., van Lessen, T., Karastoyanova, D., Leymann, F.: BPEL for Semantic Web

Services (BPEL4SWS). In: On the Move to Meaningful Internet Systems 2007: OTM 2007

Workshops, Springer (2007) 179–188

8. Lessen, T., Nitzsche, J., Dimitrov, M., Konstantinov, M., Karastoyanova, D., Cekov, L., Ley-

mann, F.: An Execution Engine for Semantic Business Processes. Service-Oriented Com-

puting - ICSOC 2007 Workshops: ICSOC 2007, International Workshops, Vienna, Austria,

September 17, 2007, Revised Selected Papers (2009) 200–211

9. Sirin, E., Parsia, B., Hendler, J.: Template-based Composition of Semantic Web Services.

In: AAAI Fall Symposium on Agents and the Semantic Web, Virginia, USA (2005)

10. Hong-Hua, C., Shi, Y., De-Hui, D., Yang, X.: Orchestrating Semantic Web Services with

Semantic Programming Language. Semantic Computing and Systems, IEEE International

Workshop on 0 (2008) 101–106

11. Kobilarov, G., Scott, T., Raimond, Y., Oliver, S., Sizemore, C., Smethurst, M., Bizer, C., Lee,

R.: Media Meets Semantic Web — How the BBC Uses DBpedia and Linked Data to Make

Connections. In: ESWC 2009 Heraklion: Proceedings of the 6th European Semantic Web

Conference on The Semantic Web, Berlin, Heidelberg, Springer-Verlag (2009) 723–737

12. Bizer, C., Volz, J., Kobilarov, G., Gaedke, M.: Silk - A Link Discovery Framework for the

Web of Data. In: 18th International World Wide Web Conference. (2009)

13. Raimond, Y., Sutton, C., Sandler, M.: Automatic Interlinking of Music Datasets on the

Semantic Web. In: WWW 2008 Workshop: Linked Data on the Web (LDOW2008), Beijing,

China (2008)

14. Auer, S., Lehmann, J., Hellmann, S.: LinkedGeoData - Adding a Spatial Dimension to the

Web of Data. In: Proc. of 7th International Semantic Web Conference (ISWC). (2009)
