EVALUATING THE QUALITY OF FREE/OPEN SOURCE

PROJECTS

Lerina Aversano, Igino Pennino and Maria Tortorella

Department of Engineering, University of Sannio, via Traiano 82100, Benevento, Italy

Keywords: Measurement, Documentation, Economics, Reliability, Experimentation, Standardization, Legal Aspects,

Free/Open Source Projects, Quality Model, ISO/IEC 9126, ERP.

Abstract: Characterization and evaluation of software quality is one of the main challenge of software engineering.

One of currently used standards is ISO/IEC 9126, which defines a quality model for software products.

However, in the context of Free/Open Source software, differences in production, distribution and support

modality, have to be considered as additional quality characteristics apart from ISO standard ones. This

paper defines a quality model for Free/Open Source Software projects, equipped with an evaluation

framework, realized by applying the Goal Question Metric paradigm. The evaluation of an open source

system has been carried out as case study.

1 INTRODUCTION

Since many years, software engineering is facing

software quality related problems. Lots of energy

were spent for defining methodological and

technological tools for managing such issues. The

main requirement is the characterization of software

quality and, consequentially, evaluation of the

quality of a software system.

The International Organization for

Standardization (ISO), faced the question by

defining the ISO/IEC 9126 standard (ISO, 2004),

published for the first time in 1991. It is a quality

model for software products, to be considered as

reference for evaluating them. Unfortunately, the

ISO/IEC 9126 standard is not enough for

characterizing the quality of an Free/Open Source

software (FlOSS)

project. Actually, additional

characteristics are required with reference to the

global quality of the project, as a FlOSS project is

different from a closed source one in terms of

production, distribution and support modalities,

more than product related characteristics.

Many organizations and researchers consider the

evaluation of these aspects as necessary to assess the

quality of an open source project.

FlOSS stands for Free libre Open Source Software.

In particular, Kamseu and Habra analyzed the

different factors that potentially influence the

adoption of an open source software (Kamseu,

2009). They identified a three dimensional model

and stated that for having a good global project

quality, it has to be considered the quality of: the

development process; the community which made

and maintain the product; and the product. Sung,

Kim and Rhew focused on the quality of the product

and identified some problems in evaluating an OSS

product, such as the difficulty of using description

and/or specification and collecting information if the

developers do not make it public (Sung, 2007).

IRCA (Wheeler, 2009) is an OSS selection process,

based on side-by-side comparison of different

software, defined by David Wheeler. The process

consists of four steps: Identify candidates, Read

existing reviews, Compare the leading programs'

basic attributes to your needs, and Analyze the top

candidates in more depth. The QSOS – Qualification

and Selection of Open Source software –

methodology consists of a set of steps regarding the

start, evaluation, adjustment and selection OSS

projects whose products seems to fit with the overall

requirements (QSOS, 2006). The OpenBRR project

– Business Readiness Rating for Open Source – born

with the same purpose of QSOS’s one (OpenBRR,

2005). QualiPSo – Quality Platform for Open

Source Software – is one of the biggest initiatives

related to open source software realized by the

186

Aversano L., Pennino I. and Tortorella M. (2010).

EVALUATING THE QUALITY OF FREE/OPEN SOURCE PROJECTS.

In Proceedings of the Fifth International Conference on Evaluation of Novel Approaches to Software Engineer ing, pages 186-191

DOI: 10.5220/0003000701860191

 SciTePress

European Union, and its products include an

evaluation framework for the trustworthiness of

Open Source projects (Del Bianco, 2008).

This research presented in this paper starts form

the evaluation of the listed approach and proposes

the EFFORT evaluation framework, aiming at

overcoming their limitations. Then, the aim of the

paper is:

• Definition of a quality model for FlOSS projects,

extending the ISO/IEC 9126 standard and

considering characteristics peculiar to that kind

of projects.

• Definition of a framework for evaluating FlOSS

projects, which gives guide lines, procedures and

metrics to actually perform the measurement.

The paper is structured as follows: section 2

describes the proposed measurement framework;

section 4 reports a case study, consisting of the

evaluation of a FlOSS project; conclusions and

future works are discussed section 5.

2 THE PROPOSED

FRAMEWORK

This section presents the proposed evaluation

framework, called EFFORT – Evaluation

Framework for Free/Open souRce projects. Its main

purpose is defining a quality model and

measurement tool for supporting the evaluation of

FlOSS projects, avoiding the limitation of the

approaches analyzed in the previous section.

The quality model is synthesized in Figure 1. It

defines the quality of a FlOSS project as the synergy

of three major components: quality of the product

developed within the project, trustworthiness of the

community of developers and contributors, product

attractiveness to its specified catchment area. Figure

1 shows the hierarchy of considered attributes.

The measurement framework was defined on the

basis of the Goal Question Metrics paradigm. In

correspondence of each first-level characteristics of

Figure 1, one Goal is defined. Then, the EFFORT

measurement framework includes three goals.

Questions, consequentially, map the second-level

characteristics, even if, Goal 1 has been broken up

into sub-goals, because of its high complexity. For

question of space, the metric level is not presented.

The following subsections summarily describe each

goal, providing a formalization of the goal itself,

incidental definitions of specific terms and list of

questions. A complete portion of the framework,

with the questions, will be just shown for Goal 2.

2.1 Product Quality

One of the main aspects that denotes the quality of a

project is product quality. So, it was necessary to

consider all the aspects of software product quality,

as defined by ISO/IEC 9126 standard (ISO, 2004).

Goal 1 is defined as follows:

Analyze the software product with the aim of

evaluating its quality, from a software

engineering’s point of view.

Given the vastness of the aspects considered by

the ISO standard, Goal 1 is decomposed in sub-

goals, each of which is focused on a single issue

corresponding to one of the six main characteristics

of the reference model: portability, maintainability,

reliability, functionality, usability, and efficiency.

The in-use quality characteristic is not considered in

this context.

Table 1 shows the sub-goals and questions

related to portability, maintainability.

For a precise definition of each characteristic, the

ISO/IEC 9126 standard can be referred (ISO, 2004).

Table 1: Some sub-goals of the Product Quality.

Sub-goal 1a:

nalyze the software product with the aim o

evaluating it as regards the portability, from a software

engineering’s point of view

1a.1

What degree of adaptability does the product offer?

1a.2

What degree of installability does the product offer?

1a.3

What degree of replaceability does the product offer?

1a.4

What degree of coesistence does the product offer?

Sub-goal 1b: Analyze the software product with the aim o

evaluating it as regards the maintainability, from a software

engineering’s point of view

1b.1

What degree of analyzability does the product offer?

1b.2

What degree of changeability does the product offer?

1b.3

What degree of testability does the product offer?

1b.4

What degree of technology concentration does the

product offer?

1b.5

What degree of stability does the product offer?

2.2 Community Trustworthiness

When adopting a FlOSS product, users are generally

worried about offered support in case of troubles.

The community, in fact, is not in duty-bound of

supporting a user that adopts its software product.

Anyway, a certain degree of support is generally

given in quantity and modality that differ from a

community to another one. We have considered

EVALUATING THE QUALITY OF FREE/OPEN SOURCE PROJECTS

187

Figure 1: Quality model for FlOSS Projects.

valuable to include community trustworthiness in the

definition of the global quality of a FlOSS project.

With community trustworthiness, the degree of trust

that a user can give to a community regarding the

support. Goal 2 is defined as follows:

Analyze the offered support with the aim of

evaluating the community with reference to

the trustworthiness, from a

(user/organization) adopter’s point of view.

A community Generally provides a set of tools that

support users in using its products such as forums,

mailing lists, bug trackers, documentation, wiki and

frequently asking questions. It is also possible to

acquire a commercial edition of the software

product, that usually differs from free edition in

terms of support and warranties provided. Another

important factor that influences trust in a project is

the availability of documentation for installing,

using and modifying the software product. All these

aspects together with the activeness of the

community are considered in the community

trustworthiness concept. Table 2 shows the set of

questions related to Goal 2. While Table 4 lists the

metrics related to question 2.3.

Table 2: Questions about Community Trustworthiness.

Q 2.1

How many developers does the community

involve?

Q 2.2 What degree of activity has the community?

Q 2.3 Support tools are available and effective?

Q 2.4 Are support services provided?

Q 2.5

Is the documentation exhaustive and easily

consultable?

Table 3: Metrics related to question Q 2.3.

M 2.3.1

umber of thread per yea

M 2.3.2 Index of unreplied threads

M 2.3.3

umber of forums

M 2.3.4 Average of threads per forum

M 2.3.5 Average of posts per year

M 2.3.6 Degree of internationalization of the forum

M 2.3.7

umber of trackers

M 2.3.8 Wiki volume

M 2.3.9

umber of frequently asked questions

2.3 Product Attractiveness

This goal has the purpose of evaluating the

attractiveness of the product toward its catchment

area. The term attractiveness indicates all the factors

that influence the adoption of a product by a

potential user, who perceive convenience and

usefulness for achieving his scopes.

Goal 3, related to product attractiveness, is

formalized as follows:

Analyze software product with the aim of

evaluating it as regards attractiveness from a

(user/organization) adopter’s point of view.

This goal is more dependent from the application

context than the other ones. The application context

helps to explain why different kind of software

products are developed. Two elements that have to

be considered, during the selection of a FlOSS

product, are functional adequacy and diffusion. The

latter, in fact, could be considered as a marker of

how the product is appreciated and recognized as

useful and effective. This aspects are considered for

formulating the questions of Goal 3 listed in Table 4.

ENASE 2010 - International Conference on Evaluation of Novel Approaches to Software Engineering

188

Table 4: Questions about Product Attractiveness.

Q 3.1

What degree of functional adequacy does the

product offer?

Q 3.2

What degree of diffusion does the product

achieved?

Q 3.3 What level of cost effectiveness is estimated?

Q 3.4

What degree of reusability and redistribution is

left by the license?

Concerning cost effectiveness, considered in

Question 3.3, it is opportune to collect all the

information regarding cost of services. The amount

of available information can vary a lot among

projects. For making the evaluation framework more

complete with reference to a specific project, it is

possible to add metrics whenever required. This can

be also done also with reference to the license,

referred in Questions 3.4. It can have a various

degree of relevance, according to the purpose and

needs of the users. In particular, the kind of license

influences reuse and imposes some restrictions more

or less severe regarding the possibility of including

the code in own projects.

2.4 Data Analysis

Once data have been collected by means of metrics,

it is necessary to aggregate them, according to the

interpretation of the metrics, so one can obtain

useful information for answering the questions.

Aggregation of answers gives an indication

regarding the achievement of the goals.

In doing aggregation, the following issues needs

to be considered:

• Metrics have different type of scale, depending

on their nature. Then, it is not possible to directly

aggregate measures. To overcome that, after the

measurement is done, each metric is mapped to a

discrete score in the [1-5] interval.

• An high value for a metric can be interpreted in a

positive or a negative way, according to the

context of the related question. So, the

appropriate interpretation is provided for each

metric.

• Questions do not have the same relevance in the

evaluation of a goal. A relevance marker is

associated to each metric in the form of a

numeric value in [1,5] interval. Value 1 is

associated to questions with minimum relevance,

while value 5 means maximum relevance.

A specific function that takes into account the

observations above is so defined for the aggregation.

Let us call with:

, relevance associated to question id (sub-

goal for goal 1);

, the set of questions (sub-goals for goal 1)

related to goal g.

The aggregation function for Goal g is defined as

follows:

























/







where m(q) is the aggregation function of the

metrics of question q:





























1





















6









/|



where: M

is the set of metrics related to question q;

v(id) is the score obtained for metric id and i(id) is

its interpretation. In particular:











0

1

3 CASE STUDY

For assessing the usefulness of the proposed method

and identifying future works, a significant FlOSS

project was evaluated by using EFFORT. The

chosen project is Compiere (

www.compiere.com),

one of the most diffused ERP systems. Data were

collected by analysing the documentation, trackers,

repositories and official web sites of the project. In

addition, the source code was analyses and the

product itself was used. Further data source

considered were sourceforge.net, freshmeat.net and

ohloh.net.

In the following, data are reported in table and

graphical format. The “in vitro” nature of the

experiment did not allow a realistic evaluation of the

efficiency, so it has been leaved out from the

discussions of the results. In Table 6, one can

observe that the Compiere product is characterized

by more than sufficient quality. By analysing the

sub-characteristics, one can notice that the product

offers a good degree of portability and functionality,

an excellent reliability and a sufficient usability.

Concerning product quality results, the main limit of

Compiere regards its maintainability.

Looking at reliability, the following

consideration are recorded: a very good robustness,

in terms of age, small amount of discovered post

release bugs, low defect density, defect per module

and index of unsolved bugs, and even higher

recoverability, measured in terms of availability of

backup and restore functions and services.

EVALUATING THE QUALITY OF FREE/OPEN SOURCE PROJECTS

189

Table 5: Results regarding Product Quality.

Quality Characteristic Relevance Score

Portability 3 4,1

Adaptability 5

Install ability 2,64

Changeability 4,67

Maintainability 3 2,83

Analyzability 3

Modifiability 2,8

Testability 2,5

Technological Dispersion 3

Reliability 3 4,42

Robustness 4,16

Recoverability 4,67

Functionality 5 4,13

Functional Adequacy 3,25

Interoperability 5

Usability 4 3,28

Attractive 2

Operability 4

Comprehension 3,89

Learning ability 3,25

Product Quality 3,77

Table 6: Results forCommunity Trustworthiness.

Quality Characteristic Relevance Score

. developers 2 2

Community Activity 4 2,60

Support tools 5 2,44

Support services 2 3,44

Documentation 4 1,67

Community Trustworthiness 2,36

Table 7: Results regarding Product Attractiveness.

Quality Characteristic Relevance Score

Functional Adequacy 5 3,25

Diffusion 4 4

Cost Effectiveness 3 2,40

Legal Reusability 1 5

Product Attractiveness 3,63

As Compiere is an ERP software, the presence of a

transaction management systems could also be

considered. Concerning maintainability, the lower

score has been evaluated by mainly using CK

metrics (Chidamber,1991), associated to the related

sub-characteristics. For instance, the medium-low

value for testability of Compiere depends on the

high average number of children (NOC) of classes,

number of attributes (NOA) and overridden methods

(NOM), as well as little availability of built in test

functions. The values of cyclomatic complexity

(VG) and dept of inheritance tree (DIT) are on the

average.

Table 6 reports data regarding the community

trustworthiness. In this and the next cases, the

hierarchy of characteristics has one less level.

The score obtained by Compiere for community

trustworthiness is definitely lower than the product

quality. In particular, community behind Compiere

is not particularly active; in fact, average number of

major releases per year, average number of commits

per year and closed bugs percentage are low values.

Support tools are poorly used. In particular, a low

activity in official forums was registered.

Documentation available free of charge is small;

while support by services results to be more than

sufficient, even if it is available just for the

commercial editions of the product. This aspect

reflects the business model of Compiere Inc., that is

slightly distant from traditional open source model:

product for free, support with fee.

Figure 2 shows a graphical representation of the

results. Looking at Table 7 and Figure 3, one can

notice that Compiere offers a good global

attractiveness. In particular, a sufficient functional

adequacy and an excellent legal reusability is

exhibited, because of the possibility left to the users

of choosing the license, even a commercial one.

Compiere does not seem to be very affordable,

compared to other FlOSS solutions. Compiere’s

product results quite diffused. The last characteristic

was evaluated by measuring: number of downloads,

index of freshmeat popularity, rating number of

sourceforge users, rating index of positive

sourceforge, number of success stories, visibility on

google, number of official partners, as well as

number of published books, experts review and

academic papers.

Figure 2: Compiere Community Trustworthiness.

ENASE 2010 - International Conference on Evaluation of Novel Approaches to Software Engineering

190

4 CONCLUSIONS

The work presented in this paper was motivated by

the necessity of having tools and models for

characterizing and evaluating the quality of FlOSS

projects, comprehensive of quality characteristics of

the product and peculiar aspects of such a kind of

projects.

The proposed study started by analysing many

approaches already existing for evaluating FlOSS.

All the considered approaches presented limitations

for performing a complete evaluation. Among them,

IRCA seems to be the most complete (Wheeler,

2009), but it did not include an evaluation

framework to perform the measurements. EFFORT

overcomes this limitation by proposing a

measurement framework that is directly applicable.

EFFORT was designed for completely covering

the intersections among the other analyzed

approaches. It offers a good coverage of the

ISO/IEC 9126 standard, with the exception of in-use

quality. Other characteristics analyzed by the other

approaches and considered significant were also

considered, such as: QSOS’ maturity, pretty much

covered by EFFORT’s diffusion; cost effectiveness

and OpenBRR’s Architecture, of which EFFORT

considers just dependence of third parts components.

During the analysis of the case study regarding

the Compiere project, it was noticed that some

characteristics of the ERP systems were not

considered by EFFORT. In particular, the

configurability and customizability of such a kind of

systems. In particular, they could be considered in

the context of attractiveness. This aspect suggests an

evolution of the EFFORT approach that considers a

specialization of the measurement framework to the

specific peculiarities of a FlOSS projects before its

application. Therefore, future work will regard the

definition of mechanisms for extending and

customizing EFFORT, and offering the possibility of

a better characterization of all aspects dependent on

the application domain.

REFERENCES

ISO -International Organization for Standardization, 2001-

2004. ISO standard 9126: Software Engineering –

Product Quality, part 1-4. ISO/IEC.

Chidamber, S. R., Kemerer, C. F., 1991. Towards a

metrics suite for object-oriented design". In ACM

SIGPLAN Notices, 26(11), ACM press, pp. 197 -211.

Kamseu, F., Habra, N., 2009. Adoption of open source

software: Is it the matter of quality? PReCISE

Sung, W. J., Kim, J. H., Rhew, S. Y., 2007. A quality

model for open source selection. In ALPIT 2007, Sixth

International Conference on Advanced Language

Processing and Web Information Technology IEEE

Comp. Soc. Press.

Wheeler, D. A., 2009. How to evaluate open source

software/free software (OSS/FS) programs, DOI=

http://www.dwheeler.com/oss_fs_why.html

QSOS, 2006. Method for Qualification and Selection of

Open Source software. Atos Origin.

OpenBRR, 2005. Business Readiness for Open Source.

Intel.

Del Bianco, V., Lavazza, L., Morasca, S., Taibi, D., 2008.

The observed characteristics and relevant factors used

for assessing the trustworthiness of OSS products and

artefacts. QualiPSo.

EVALUATING THE QUALITY OF FREE/OPEN SOURCE PROJECTS

191
