TOWARDS THE AUTOMATIC IDENTIFICATION OF VIOLATIONS

TO THE NORMALIZED SYSTEMS DESIGN THEOREMS

Kris Ven, David Bellens, Philip Huysmans and Dieter Van Nuffel

University of Antwerp, Prinsstraat 13, 2000 Antwerp, Belgium

Keywords:

Normalized systems, Software architecture, Modularity, Quality.

Abstract:

Contemporary organizations are operating in increasingly volatile environments and must be able to respond

quickly to their environment. Given the importance of information technology within organizations, the evolv-

ability of information systems will to a large degree determine how quickly organizations are able to react to

changes in their environment. Unfortunately, current information systems struggle to provide the required

levels of evolvability. Recently, the Normalized Systems approach has been proposed which aims to address

this issue. The Normalized Systems approach is based on the systems theoretic concept of stability to ensure

the evolvability of information systems. To this end, the Normalized Systems approach proposes four design

theorems that act as constraints on the modular structure of software. In this paper, we explore the feasibility

of building a tool that is able to automatically identify manifestations of violations to these Normalized Sys-

tems design theorems in the source code of information systems. This would help organizations in identifying

limitations to the evolvability of their information systems. We describe how a prototype of such tool was

developed, and illustrate how it can help to analyze the source code of an existing application.

1 INTRODUCTION

Contemporary organizations are operating in increas-

ingly volatile environments. Hence, organizations

must be able to respond quickly to their environment

in order to gain a competitive advantage. Since or-

ganizations are becoming increasingly dependent on

information technology (IT) to support their opera-

tions, the evolvability of the IT infrastructure will de-

termine to a large degree how quickly organizations

are able to react to changes in their environment. Un-

fortunately, current information systems struggle to

provide the requested levels of evolvability. One of

the challenges that contributes to this issue is the ex-

istence of Lehman’s Law of Increasing Complexity

which states: “As an evolving program is continu-

ally changed, its complexity, reﬂecting deteriorating

structure, increases unless work is done to maintain

or reduce it.” (Lehman, 1980, p. 1068). This law

implies that over time, the structure of software will

become more complex, thereby requiring increasing

effort to add new functionality to an existing system.

To address this issue, the Normalized Systems ap-

proach starts from the systems theoretic concept of

stability to ensure the evolvability of information sys-

tems (Mannaert and Verelst, 2009). It argues that the

main obstacle to evolvability is the existence of so-

called combinatorial effects. The Normalized Sys-

tems approach deﬁnes clear design theorems that im-

pose constraints on the modular structure of software

and that eliminate combinatorial effects. Adhering to

these theorems therefore results in information sys-

tems that exhibit stability and that defy Lehman’s law

(Mannaert and Verelst, 2009).

Organizations currently have a large number of in-

house developed information systems in use. These

information systems are likely to contain combina-

torial effects that limit their evolvability. Organiza-

tions will therefore be looking towards ways to iden-

tify these combinatorial effects in their code base, and

to devise solutions to improve the evolvability of their

information systems. Manually inspecting the source

code may be a possibility, but is likely to be a very

time-consuming task. Automatic identiﬁcation there-

fore seems to be a very interesting alternative. In this

paper, we explore the feasibility of building a tool

to automatically identify manifestations of violations

to the Normalized Systems design theorems. We de-

scribe how a prototype of such a tool was developed,

and illustrate how it can help to analyze the source

code of an existing application.

Ven K., Bellens D., Huysmans P. and Van Nuffel D. (2010).

TOWARDS THE AUTOMATIC IDENTIFICATION OF VIOLATIONS TO THE NORMALIZED SYSTEMS DESIGN THEOREMS.

In Proceedings of the 5th International Conference on Software and Data Technologies, pages 23-28

DOI: 10.5220/0003005000230028

 SciTePress

2 NORMALIZED SYSTEMS

The basic assumption of the Normalized Systems ap-

proach is that information systems should be able to

evolve over time, and should therefore be designed

to accommodate change. This implies that the soft-

ware architecture should not only satisfy the cur-

rent requirements, but should also support future re-

quirements. It is a well-known problem in software

engineering that the structure of software degrades

and becomes more complex over time as changes

are applied to it. This problem has been deﬁned by

Manny Lehman as the Law of Increasing Complexity

(Lehman and Ramil, 2001; Lehman, 1980). The prac-

tical manifestation of this law is that the impact of any

given change to an information system will increase

over time (Belady and Lehman, 1976; Lehman, 1980;

Lehman and Ramil, 2001). This is clearly an impor-

tant concern for information systems development.

Recently, the Normalized Systems approach has

been proposed which aims to address this issue. The

Normalized Systems approach uses the systems the-

oretic concept of stability as the basis for develop-

ing information systems (Mannaert and Verelst, 2009;

Mannaert et al., 2008). In systems theory, stability

refers to a system in which a bounded input func-

tion results in bounded output values, even as t → ∞.

When applied to information systems, this means that

applying a speciﬁc change to the information system

should always require the same effort, irrespective

of the size of the information system or the point in

time at which the change is applied. The Normalized

Systems approach further relies on the assumption of

unlimited systems evolution (Mannaert and Verelst,

2009). This means that the system becomes ever

larger in the sense that the number of modules—and

the number of dependencies between them—become

inﬁnite or unbounded as t → ∞. This may seem an

overstated assumption, but actually, it is quite logical

as even the introduction of a single module or depen-

dency every twenty years corresponds to an inﬁnite

amount for an inﬁnite time period.

Information systems exhibiting stability with re-

spect to a deﬁned set of changes are called Normal-

ized Systems (Mannaert and Verelst, 2009). In con-

trast, when changes do require increasing effort as the

system grows, combinatorial effects are said to occur

(Mannaert and Verelst, 2009). In order to obtain sta-

ble information systems, these combinatorial effects

should be eliminated. In order to identify and avoid

most of these combinatorial effects, a set of four de-

sign theorems was developed (Mannaert et al., 2008;

Mannaert and Verelst, 2009). We will now brieﬂy

describe each of these theorems. More details are

beyond the scope of this paper and can be found in

the literature (Mannaert et al., 2008; Mannaert and

Verelst, 2009).

The ﬁrst theorem, separation of concerns, re-

quires that every change driver or concern is sepa-

rated from other concerns. This theorem allows for

the isolation of the impact of each change driver. This

principle was informally described by Parnas already

in 1972 as what was later called design for change

(Parnas, 1972). This theorem implies that each mod-

ule can contain only one submodular task (which

is deﬁned as a change driver), but also that work-

ﬂows should be separated from functional submod-

ular tasks.

The second theorem, data version transparency,

requires that data is communicated in version trans-

parent ways between components. This requires that

this data can be changed (e.g., additional data can be

sent between components), without having an impact

on the components and their interfaces. This can, for

example, be accomplished by appropriate and system-

atic use of web services instead of using binary trans-

fer of parameters. This also implies that most external

APIs cannot be used directly, since they use an enu-

meration of primitive data types in their interface.

The third theorem, action version transparency,

requires that a component can be upgraded without

impacting the calling components. This can be ac-

complished by appropriate and systematic use of, for

example, polymorphism or a facade pattern.

The fourth theorem, separation of states, requires

that actions or steps in a workﬂow are separated

from each other in time by keeping state after ev-

ery action or step. This suggests an asynchronous

and stateful way of calling other components. Syn-

chronous calls—resulting in pipelines of objects call-

ing other objects which are typical for object-oriented

development—result in combinatorial effects.

3 TOOL DEVELOPMENT

In order to automatically identify manifestations of

violations to the Normalized Systems design theo-

rems, a tool prototype was developed. This tool iden-

tiﬁes manifestations of violations to the Normalized

Systems design theorems at the API level. The tool

was developed in an iterative way using the design

science methodology (Peffers et al., 2007). In this

paper, we are primarily concerned with building and

evaluating an instantiation artifact (March and Smith,

1995).

Since each programming language has its own

constructs and syntax, different violations are possi-

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

ble in different programming languages. We decided

to focus on the Java programming language since it is

a very relevant language within an enterprise context

(cf., Java EE). The tool consists of two main compo-

nents,

NSTVdoclet

and

NSTVdetect

, that have to be

run in succession.

The

NSTVdoclet

component is written as a cus-

tom doclet to

javadoc

. The

javadoc

tool is part of

the Java 2 SDK. By default, it generates documenta-

tion in HTML format of the API of a Java applica-

tion. The

javadoc

tool is, however, easy to extend

by creating custom doclets that provide output in an

alternate format. It was decided to develop a custom

doclet for

javadoc

that would write selected informa-

tion obtained by

javadoc

to a temporary database.

This method has three main advantages. First, it al-

lows us to reuse the source code parsing algorithm of

javadoc

. Second, most Java applications ship with

ant

build ﬁle that allows to automatically gener-

ate the API documentation for the application using

javadoc

. In that case, it is quite easy to specify in

the build ﬁle that our custom

javadoc

doclet must be

used. Third, it is more efﬁcient to parse the source

code only once, and have the

NSTVdetect

tool make

use of the already parsed information that is available

in the temporary database. Since we do not require

all the information that is obtained by

javadoc

, this

information is ﬁltered and only the information re-

quired by

NSTVdetect

is written away in a temporary

database.

The

NSTVdetect

component processes the infor-

mation in this database and analyzes it to identify

manifestations of violations to the Normalized Sys-

tems design theorems. Hence, we needed to deﬁne

which violations will be detected by this tool. To this

end, we determined how Java applications could vio-

late the Normalized Systems design theorems. In this

ﬁrst iteration, we distinguish between three violations

that may occur in Java applications. Each of these vi-

olations are related to one or more of the Normalized

Systems design theorems. In fact, an N − N relation-

ship exists between the violations and the Normalized

Systems design theorems: a single design theorem

can be violated in several ways, while a single viola-

tion can refer to more than one theorem. Although the

current list of violations is not exhaustive, it includes

common violations against the Normalized Systems

design theorems and covers all four design theorems.

This list can be further expanded in the future. As

such, the current list represents a lower bound of the

violations to the Normalized Systems design theo-

rems that exist in Java applications. For each of these

violations, a separate

NSTVdetect

module was devel-

oped. Each module analyzes the internal representa-

tion of the source code for manifestations of a speciﬁc

violation in Java applications. We will now discuss

these violations and how they are detected by each

module in more detail.

3.1 Import Multiple Concerns Violation

A class is a basic module in the Java programming

language. Java classes can import and use functional-

ity from external technology environments and pack-

ages by using the

import

instruction. This may intro-

duce dependencies on these external technologies in

an implicit way. The Normalized Systems approach

considers the use of an external technology in a class

to be a separate concern, since the external technology

can evolve differently from the background technol-

ogy environment of the class (Mannaert and Verelst,

2009). The separation of concerns design theorem re-

quires that each change driver or concern is isolated

from other concerns, so that each concern can evolve

independently. This means that each module should

contain only one change driver. The separation of

concerns theorem therefore implies that a class should

refer to at most one external technology. Otherwise,

combinatorial effects are introduced in the design.

The Import Multiple Concerns Violation module

determines which concerns are used by each class

based on the imported libraries (using the

import

statements in Java). Before running the analysis, the

researcher must deﬁne which concerns are present in

the application, as well as which libraries fall under

each concern. Based on this deﬁnition, it is deter-

mined how many different concerns are combined in

each class. As stated before, a class should not ad-

dress more than one concern. Depending on the ap-

plication, one concern could, for example, be the use

of the Java Swing packages for the graphical user in-

terface, while a second concern could be the use of the

Java JDBC packages to support database access. Ac-

cording to the separation of concerns theorem, both

concerns should not be combined in a single class.

This is consistent with the concept of multi-tier archi-

tectures. Another concern could be the use of another

application, such as Cocoon to provide a web-based

user interface.

3.2 Primitive in Interface Violation

This violation is related to two Normalized Systems

design theorems, namely data version transparency

and action version transparency. The use of primi-

tive data types or the

java.lang.String

class in the

interface of a method constitutes a violation to both

design theorems. We illustrate this with an exam-

TOWARDS THE AUTOMATIC IDENTIFICATION OF VIOLATIONS TO THE NORMALIZED SYSTEMS DESIGN

THEOREMS

ple. Consider a method that allows the user to search

for a speciﬁc string in a set of ﬁles and that takes

a single parameter of the type

java.lang.String

that speciﬁes the text to search for. Next, assume

that the developers want to extend the search func-

tionality in the future by allowing users to make use

of regular expressions. In other words, the method

should support searching for regular texts as well as

regular expressions. In that case, the interface of

the method should be extended with a

boolean

vari-

able to indicate whether the string is a regular ex-

pression. This will, however, affect all other meth-

ods calling the search method. The method is not

action version transparent since the interface of the

method will change, and it is not possible to upgrade

to a new version of the method without having an im-

pact on the rest of the system. The data is not data

version transparent either, since its structure does not

allow to send additional data without any additional

changes to the system. To resolve this issue, it is

better to encapsulate the search parameters in a new

class

SearchConfiguration

that can be extended

with additional ﬁelds as new functionality is added

to the search method. The default constructor of the

SearchConfiguration

object should assign a neu-

tral value to newly added parameters (e.g., to indicate

that a search string is not a regular expression). By

calling the appropriate

set

method, the default set-

tings can be overwritten. Future changes would then

have no effect on methods calling the search method.

This solution would be compliant with the data and

action version transparency theorems.

The implication of both theorems is that the in-

terface of methods should not contain any primitive

data types (or objects from the

java.lang.String

class). The Primitive in Interface Violation module

inspects the interface of each non-private method and

determines whether the interfaceincludes one or more

primitive data types or the

java.lang.String

class.

3.3 Custom Exception Violation

The Java programming language provides the excep-

tion mechanism to handle errors that occur during the

execution of a method. If an exception is thrown by

a method, the calling method must process this error,

either by catching and handling the error internally, or

by throwing the exception further upward the stack.

Unfortunately, this is a violation of the separation of

states theorem which requires that state must be kept

upon return of a method call. This prohibits that a

calling method must be able to react to all possible

error states of a method. Instead, this should be han-

dled by a separate and dedicated module (Mannaert

and Verelst, 2009). Otherwise, combinatorial effects

occur in the design. Consider, for example, a method

that is called by N different methods in the applica-

tion. If the developer working on this method decides

to introduce a new error state by having the method

to throw a new exception, this has an impact on the N

methods that call this method, since they are forced by

the Java environment to catch or throw this exception.

Hence, the error handling takes place in N different

places. Since N becomes unbounded over time, the

impact of this change will increase over time, thereby

resulting in a combinatorial effect.

The Custom Exception Violation module

therefore determines which and how many

custom exceptions are thrown by all meth-

ods. We consider the use of standard Java

exceptions (e.g.,

java.lang.Exception

and

java.io.IOException

) to be acceptable, since they

are related to the background technology being used.

Even in this case, the use of these exceptions should

be kept to a minimum. The use of custom exceptions

should be avoided, since such errors should be

handled in a stateful way.

4 CASE STUDY

In order to test this tool, we performed an investiga-

tion of JabRef.

JabRef is a bibliography reference

manager that can be used to edit BibTeX ﬁles and is

written in Java. We focused on this application for

a number of reasons. First, it is distributed under an

open source license, thereby providing us with access

to the source code of the application. Second, the ap-

plication represents a moderate development effort. It

is not too small to be disregarded as a toy example,

and is not too large and complex to complicate the

evaluation of our tool. Third, the application is quite

popular and widely adopted. The ﬁrst stable version

was released in November 2003. The latest stable ver-

sion of JabRef that was available to us was version

2.5 and consists of 487 classes, 5,988 methods, and

98,982 LOC.

4.1 Import Multiple Concerns Violation

As mentioned in Section 3.1, we must ﬁrst specify

which concerns are present in a given application. For

JabRef, we identiﬁed 13 different concerns. A list of

these concerns and the packages that fall under each

concern are displayed in Table 1. All classes and

packages belonging to the

net.sf.jabref.*

pack-

age were considered part of the application itself and

http://jabref.sourceforge.net/

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

Table 1: List of concerns identiﬁed in JabRef.

Concern Description

Java Swing

java.awt.*

javax.swing.*

Java Beans

java.beans.*

Java IO

java.io.*

java.nio.*

Java Net

java.net.*

Java SQL

java.sql.*

Java XML

javax.xml.*

org.w3c.dom.*

org.xml.sax.*

Java Plugin

org.java.plugin.*

antlr

antlr.*

org.antlr.*

glazedlists

ca.odell.glazedlists.*

jgoodies

com.jgoodies.*

ritopt

gnu.dtools.ritopt.*

microba

com.michaelbaranov.microba.*

jempbox

org.jempbox.*

pdfbox

org.pdfbox.*

Table 2: Import Multiple Concerns Violations.

Number of

Concerns Classes Percentage

0 306 31.2%

1 320 32.7%

2 228 23.3%

3 86 8.8%

4 34 3.5%

5 6 0.6%

Total: 980 100.0%

were therefore not considered a separate concern. The

results of the analysis are shown in Table 2. It shows

that 626 out of 980 (63.9%) classes include at most

one concern. Consequently, 36.1% of the classes ad-

dress two or more concerns and therefore represent

a manifestation of the Import Multiple Concerns Vi-

olation. Six classes even combine ﬁve different con-

cerns. A more in-depth analysis showed that these

classes all combined the glazedlists, Java Swing, Java

IO, and Java Net concerns with either the jgoodies or

Java Plugin concerns. Although most of these con-

cerns are related to the default Java SDK API, it does

create dependencies on different packages within the

API. This data also suggests that ﬁle system functions

(Java IO and Java Net) are combined with user in-

terface functions (Java Swing). This may neglect the

concept of multi-tiers and would therefore require at-

tention in a further screening of the source code.

4.2 Primitive in Interface Violation

The results for the Primitive in Interface analysis are

shown in Table 3. It shows that 4170 out of 5988

(69.6%) methods do not contain any primitive data

Table 3: Primitive in Interface Violations.

Methods with

All methods parameters

Violations

n % n %

0 4170 69.6% 1592 46.7%

1 1334 22.3% 1334 39.1%

2 294 4.9% 294 8.6%

3 132 2.2% 132 3.9%

4 34 0.6% 34 1.0%

5 18 0.3% 18 0.5%

6 6 0.1% 6 0.2%

Total: 5988 100.0% 3410 100.0%

Number of primitive and

java.lang.String

data types used in interface of each method

types or the

java.lang.String

class in their inter-

face. Further analysis showed, however, that 2578

methods do not take any parameters and therefore

require no input. In the next step in our analysis,

we excluded those methods from the analysis and fo-

cused on those methods that do require input param-

eters. Results showed that 1592 out of 3410 (46.7%)

methods only accept objects in their interface. Conse-

quently, 1818 out of 3410 (53.3%) methods represent

manifestations of the Primitive in Interface Violation.

4.3 Custom Exception Violation

As mentioned in Section 3.3, we consider the use

of standard Java exceptions to be acceptable, since

they represent the background technology being used.

This means that all

java.*

and

javax.*

exceptions

were ignored in this analysis. The results for the

Custom Exception Violation module are shown in Ta-

ble 4. It showsthat 5828 out of 5988 (97.3%)methods

do not throw any custom exceptions. The other 160

methods throw at least one custom exception. Our

data further shows that 5464 methods do not throw

any exceptions. If we only consider those methods

that actually throw one or more exceptions, it can be

seen that only 364 out of 524 (69.5%) methods do

not use any custom exceptions, while the other 160

(30.5%) methods do. These 160 methods therefore

represent manifestations of the Custom Exception Vi-

olation.

5 DISCUSSION AND

CONCLUSIONS

In this paper, we have explored the feasibility to auto-

matically identify manifestations of violations to the

Normalized Systems design theorems. To this end,

TOWARDS THE AUTOMATIC IDENTIFICATION OF VIOLATIONS TO THE NORMALIZED SYSTEMS DESIGN

THEOREMS

Table 4: Custom Exception Violations.

Methods with

All methods parameters

Violations

n % n %

0 5828 97.3% 364 69.5%

1 124 2.1% 124 23.7%

2 16 0.3% 16 3.1%

3 20 0.3% 20 3.8%

Total: 5988 100.0% 524 100.0%

Number of custom exceptions thrown

we developed a prototype of a tool to analyze Java ap-

plications This tool focuses on violations to the Nor-

malized Systems design theorems at the API level. A

ﬁrst contribution of our paper is that we have shown

that it is indeed possible to detect manifestations of vi-

olations to the Normalized Systems design theorems

in an automated manner. A second contribution is that

we have identiﬁed three violations to the Normalized

Systems design theorems that may occur in Java ap-

plications.

Since this tool is still a prototype, we acknowledge

several limitations with respect to our ﬁndings. The

results provide a ﬁrst-cut and rough assessment of vi-

olations to the Normalized Systems design theorems.

This assessment can increase awareness about—and

give a ﬁrst impression of—the code quality of an ap-

plication with respect to evolvability. The violations

identiﬁed by the tool should at the moment be consid-

ered a lower bound for the existence of combinatorial

effects, since the tool does not analyze the source code

for all potential sources of combinatorial effects.

Given the currentlimitations of our tool, we do not

want to make any claims with respect to the quality of

JabRef. Instead, the results obtained in the case study

will be used to further reﬁne our tool.

In addition, our results suggest that although the

automatic identiﬁcation of manifestations of viola-

tions to the Normalized Systems design theorems

is feasible, an additional manual inspection of the

source code is required. This inspection provides

more insight into the seriousness of the issues iden-

tiﬁed in the analysis. In practice, some trade-off will

need to take place to judge whether the additional ef-

fort of containing combinatorial effects is warranted

by the likelihood that a future change would manifest

itself. However, such decisions should be carefully

considered and developers should be aware that not

adhering to the Normalized Systems design theorems

may have a negative impact on the evolvability of the

software.

In future research, we intend to further develop

this tool to increase its ability to automatically detect

manifestations of violations to the Normalized Sys-

tems design theorems. To this end, we will further ex-

tend our list of violations to identify a larger number

of violations to the Normalized Systems design the-

orems. Our tool will therefore be expanded with ad-

ditional modules to test for the manifestation of these

new violations.

REFERENCES

Belady, L. and Lehman, M. M. (1976). A model of

large program development. IBM Systems Journal,

15(3):225–252.

Lehman, M. (1980). Programs, life cycles, and laws of soft-

ware evolution. Proceedings of the IEEE, 68(9):1060–

1076.

Lehman, M. and Ramil, J. (2001). Rules and tools for soft-

ware evolution planning and management. Annals of

Software Engineering, 11:15–44.

Mannaert, H. and Verelst, J. (2009). Normalized Systems—

Re-creating Information Technology Based on Laws

for Software Evolvability. Koppa, Kermt, Belgium.

Mannaert, H., Verelst, J., and Ven, K. (2008). Exploring

the concept of systems theoretic stability as a start-

ing point for a uniﬁed theory on software engineer-

ing. In Mannaert, H., Ohta, T., Dini, C., and Pel-

lerin, R., editors, Proceedings of the Third Interna-

tional Conference on Software Engineering Advances

(ICSEA 2008), Sliema, Malta, October 26-31, 2008,

pages 360–366, Los Alamitos, CA. IEEE CS Press.

March, S. T. and Smith, G. F. (1995). Design and natural

science research on information technology. Decision

Support Systems, 15(4):251–266.

Parnas, D. L. (1972). On the criteria to be used in decom-

posing systems into modules. Communications of the

ACM, 15(12):1053–1058.

Peffers, K., Tuunanen, T., Rothenberger, M. A., and Chat-

terjee, S. (2007). A design science research method-

ology for information systems research. Journal of

Management Information Systems, 24(3):45–77.

ICSOFT 2010 - 5th International Conference on Software and Data Technologies
