EXPLORING EMPIRICALLY THE RELATIONSHIP BETWEEN

LACK OF COHESION IN OBJECT-ORIENTED SYSTEMS AND

COUPLING AND SIZE

Linda Badri, Mourad Badri and Fadel Toure

Software Engineering Research Laboratory, Department of Mathematics and Computer Science

University of Quebec at Trois-Rivières, Trois-Rivières, Quebec, Canada

Keywords: Software Quality, Quality Attributes, Software Attributes, Metrics, Lack of Cohesion, Coupling, Size.

Abstract: The study presented in this paper aims at exploring empirically the relationship between lack of cohesion of

classes in object-oriented systems and their coupling and size. We designed and conducted an empirical

study on various open source Java software systems. The experiment has been conducted using several well

known code-based metrics related to cohesion, coupling and size. The results of this study provide evidence

that a lack of cohesion may actually be associated with (high) coupling and (large) size.

1 INTRODUCTION

A large number of object-oriented (OO) metrics

have been proposed in the literature. They are used

to assess different software attributes. Software

metrics can be calculated automatically from source

code. The assessment of even large software systems

can then be performed quickly at a low cost.

Software metrics can be useful in predicting

software quality and supporting various software

engineering activities (Basili, 1996; Bansiya, 2002;

Briand, 2000; Chidamber, 1998; Darcy, 2005; El

Emam, 1999; Fenton, 1996).

Cohesion is considered as one of most important

OO software attributes. Many metrics have been

proposed in the last several years to measure class

cohesion in OO systems. Class cohesion (more

specifically, functional cohesion) is defined as the

degree of relatedness between members of a class. In

OO systems, a class should represent a single logical

concept, and not to be a collection of miscellaneous

features. OO analysis and design methods promote a

modular design by creating classes with high

cohesion and low coupling (Larman, 2003;

Pressman, 2005; Sommerville, 2004). Improper

assignment of responsibilities in the design phase

can produce low cohesive classes with unrelated

members. The reasoning is that classes that lack

cohesion are poorly designed and will be difficult,

among others, to understand, to test and to maintain.

However, there is no empirical evidence on these

claims. In fact, studies have failed to show a

significant relationship between cohesion metrics

and software quality attributes such as fault-

proneness or changeability (Briand, 1998; Briand,

2000; Kabaili, 2001). Moreover, studies have noted

that cohesion metrics fail to properly reflect

cohesion of classes (Aman, 2002; Chae, 2000; Chae,

2004; Kabaili, 2000; Kabaili, 2001). As against,

several studies have showed that there exist a

significant relationship between software attributes

such as complexity, coupling and size and software

quality attributes such as fault-proneness, testability

and maintainability.

One possible explanation of the lack of

relationship between cohesion (according to

experimented cohesion metrics) and some software

quality attributes is due to the difficulty of

measuring cohesion from syntactic elements of code

(Briand, 1998; Briand, 2000; Henderson-sellers,

1996; Stein, 2005). Moreover, cohesion metrics are

in our opinion based on restrictive criteria, in the

sense that they do not consider some characteristics

of classes, which lead in many situations to some

inconsistency between the computed cohesion

values and the intuitively expected ones (Badri,

2004; Chae, 2000; Chae, 2004; Kabaili, 2001).

However, an empirical study performed by Stein et

al. (Stein, 2005) pointed to a more basic relationship

between cohesion and complexity: that a lack of

317

Badri L., Badri M. and Toure F. (2010).

EXPLORING EMPIRICALLY THE RELATIONSHIP BETWEEN LACK OF COHESION IN OBJECT-ORIENTED SYSTEMS AND COUPLING AND SIZE.

In Proceedings of the 5th International Conference on Software and Data Technologies, pages 317-324

DOI: 10.5220/0003012203170324

 SciTePress

cohesion may be associated with high complexity.

In this paper, we decided to explore empirically

the relationship between lack of cohesion (disparity

of the code) of classes in OO systems and their

coupling and size. Our hypothesis is that classes

with high (strong) coupling and/or large size will

lack cohesion. To test our hypothesis, we chose in

our experiment two well-known lack of cohesion

metrics: LCOM (Lack of COhesion in Methods)

(Chidamber, 1994) and LCOM* (Henderson-sellers,

1996). In order to facilitate comparison with our

class cohesion measurement approach (Badri, 2004;

Badri, 2008), and knowing that the selected cohesion

metrics are basically lack of cohesion metrics

(inverse cohesion measures), we derive a lack of

cohesion measure from the cohesion metric we

proposed.

In order to explore the relationship between lack

of cohesion and coupling and size, we investigate in

this study a small selection of coupling and size

metrics. We focus on measures defined at the class

level. We chose the well-known coupling metrics:

CBO (Coupling Between Objects) (Chidamber,

1994) and FO (Fan-Out) (Kitchenham, 1990), and

size measures: LOC (Lines Of Code), NOA

(Number of Attributes) and NOO (Number of

Operations) (Henderson-sellers, 1996). Our aim in

this project, as a next step, is to investigate lack of

cohesion as a predictor of some relevant external

software quality attributes such as testability and

maintainability. These issues will be addressed in a

future work. We designed and conducted an

empirical study on several open source Java

software systems. The achieved results provide

evidence that a lack of cohesion may actually be

associated with high coupling and large size,

validating some fundamental design principles of

software engineering.

The rest of the paper is organized as follows:

We give in Section 2 an overview of major class

cohesion metrics. Section 3 presents some related

work. Section 4 presents briefly our approach for

class cohesion measurement. Section 5 gives some

characteristics of the systems we used in our

experiment. We present and discuss in Section 6 and

Section 7 the empirical investigation that we

conducted to explore respectively the relationship

between lack of cohesion and coupling and the

relationship between lack of cohesion and size.

Finally, Section 8 summarizes the contributions of

this work, discusses some of its limitations and

outlines directions for further research.

2 COHESION METRICS

Yourdon et al. (Yourdon, 1979) defined cohesion, in

the procedural paradigm, as a measure of the extent

of the functional relationships of the elements in a

module. In the OO paradigm, Booch (Booch, 1994)

described high functional cohesion as existing when

the elements of a class all work together to provide

some well-bounded behavior. There are several

types of cohesion: functional cohesion, sequential

cohesion, coincidental cohesion, etc. (Henderson-

sellers, 1996; Yourdon, 1979). In this work, we

focus on functional cohesion.

Many metrics have been proposed in the last

several years in order to measure class cohesion in

OO systems. The argument over the most

meaningful of those metrics continues to be debated

(Counsell, 2006). Major of proposed cohesion

metrics are based on the notion of degree of

similarity of methods, and usually capture cohesion

in terms of connections between members of a class.

They present, however, some differences in the

definition of the relationships between members in a

class (mechanism that defines cohesion and its

measure). A class is more cohesive, as stated in

(Chae, 2000), when a larger number of its instance

variables are referenced by a method (LCOM

(Henderson-sellers, 1996), Coh (Briand, 1998)), or a

larger number of methods pairs share instance

variables (LCOM1 (Chidamber, 1991), LCOM2

(Chidamber, 1994), LCOM3 (Li, 1993), LCOM4

(Hitz, 1995), Co (Hitz, 1995), TCC and LCC

(Bieman, 1995), DC

and DC

(Badri, 2004; Badri,

2008)). We chose in our study the cohesion metrics:

LCOM (Chidamber, 1994) and LCOM

(Henderson-sellers, 1996). LCOM (referenced in the

literature as LCOM2, as a refinement of LCOM1) is

defined as the number of pairs of methods in a class

having no common attributes minus the number of

pairs of methods having at least one common

attribute. LCOM is set to zero when the value is

negative. LCOM

is somewhat different from the

LCOM metric. LCOM

is different also from the

other versions of the LCOM metric proposed by Li

et al. (Li, 1993) and Hitz et al. (Hitz, 1995). It

considers that cohesion is directly proportional to the

number of instance variables that are referenced by

the methods of a class.

These metrics are known as structural metrics,

which is the most investigated category of cohesion

metrics. They measure cohesion on structural

information extracted from the source code. Several

studies, using the Principal Component Analysis

technique, have been conducted in order to

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

318

understand the underlying orthogonal dimensions

captured by some of these metrics (Aggarwal, 2006;

Briand, 1998; Chae, 2000; Etzkorn, 2004; Marcus,

2005). Briand et al. (Briand, 1998) developed a

unified framework for cohesion measurement in OO

systems that classifies and discusses several

cohesion metrics. Development of metrics for class

cohesion assessment still continues (Badri, 2008;

Chae, 2004; Chen, 2002; Counsell, 2006; Marcus,

2005; Marcus, 2008; Meyers, 2004; Woo, 2009;

Zhou, 2002; Zhou, 2003). Recent approaches for

assessing class cohesion focus on semantic cohesion

(De Lucia, 2008; Marcus, 2008). We focus in this

work on structural cohesion metrics.

3 COUPLING AND SIZE

METRICS

Coupling between two classes exists if one class

access or uses some elements of the other class.

Chidamber et al. (Chidamber, 1994) proposed the

CBO (Coupling Between Objects) metric that counts

for a class the number of other classes to which it is

coupled. This metric has been validated by Basili et

al. (Basili, 1996) as a fault prone indicator.

Kitchenham et al. (Kitchenham, 1990) defined FO

(Fan-Out) as a count of the number of classes that

are called by a given class. Various other coupling

metrics have been proposed in the literature (Briand,

1997; Hitz, 1995; Li, 1993; Li, 1995). Studies

showed, in fact, that coupling metrics are good

predictive indicators of software quality (Aggarwal,

2006; Briand, 2000; Bruntink, 2006; Chaumum,

2000; Harrison, 1998; Xu, 2008; Zhou, 2006). Well

known practices of software engineering promote

modular design with low coupling between classes

in order to facilitate, among others, comprehension,

testing, maintenance and evolution (Larman, 2003;

Pressman, 2005; Sommerville, 2004). Furthermore,

size is also a good indicator of various attributes of

software quality. The metric LOC (Lines Of Code),

widely accepted in the software engineering

community as a size/complexity metric (Dunsmore,

1984; Henderson-sellers, 1996; Levitin, 1986; Pant,

1995; Weyuker, 1988), has been used for a number

of different software development activities. Many

empirical results showed its usefulness (Basili, 1996;

Bruntink, 2006; Henderson-sellers, 1996; Dagpinar,

2003; El Emam, 1999; Xu, 2008). NOA (Number of

Attributes) and NOO (Number of Operations) are

alternative size metrics more appropriate to an OO

context.

4 CLASS COHESION

MEASUREMENT

We give, in this section, a brief overview of our

approach for class cohesion measurement. For more

details see (Badri, 2004; Badri, 2008). The approach

is based on different cohesion criteria. It takes into

account different ways of capturing functional

cohesion in a class.

Used Attributes: Two methods M

and M

are

directly related if there is at least one attribute shared

by the two methods.

Invoked Methods: Two methods M

and M

are

directly related if there is at least one method

invoked by the two methods. We also consider that

and M

are directly related if M

invokes M

, or

vice-versa.

Common Objects Parameters: Two methods M

and

are directly related if there is at least one

parameter of object type used by the two methods.

Two methods M

and M

may be directly connected

in many ways: they share at least one instance

variable in common, or interact at least with another

method of the same class, or share at least one object

passed as parameter. Let us consider a class C with n

methods. The maximum number of methods pairs is

[n * (n – 1) / 2]. Consider an undirected graph G

where the vertices are the methods of the class C,

and there is an edge between two vertices if the

corresponding methods are directly related. Let E

be the number of edges in the graph G

. The

cohesion of the class C, based on the direct relation

between its methods, is defined as: DC

= |E

| / [n *

(n – 1) / 2] Є [0,1]. DC

gives the percentage of

methods pairs, which are directly related.

In order to facilitate comparison with the metrics

LCOM and LCOM

, we derive a lack of cohesion

measure (following the same approach of LCOM)

from our approach. We associate to a class C (with n

methods) a lack of cohesion measure (not

normalized) based on the direct relation given by:

= [n * (n – 1) / 2] – 2 * |E

|. When the

difference is negative, LC

is set to zero.

5 SELECTED SYSTEMS

In order to achieve significant results, the data used

in our empirical study were collected from several

open source Java software systems. We used in our

experiment eight systems from different domains

and of varying sizes. The analyzed systems consist

of a total of more than 2 000 classes (more than

EXPLORING EMPIRICALLY THE RELATIONSHIP BETWEEN LACK OF COHESION IN OBJECT-ORIENTED

SYSTEMS AND COUPLING AND SIZE

319

Table 1: Some characteristics of the used systems and mean values of the selected metrics.

#Classes #Attributes #Methods #LOC CBO FO LOC NOA NOO LCOM LCOM* LC

GNUJSP 79 207 373 5225 5.28 4 66.14 2.62 9.47 94.85 60.57 52.67

JFLEX 47 403 401 9086 6.66 3.87 193.32 8.57 8.53 38.2 55.17 59.6

DBUNIT 213 464 874 11562 6.03 4.12 54.28 2.18 3.82 12.97 44.42 8.58

FREECS 115 712 822 15244 9.43 4.74 132.56 6.19 7.15 71.60 72.89 74.30

JHOTDRAW 301 688 3109 20767 8.26 5.34 68.99 2.29 8.51 125.82 46.16 80.46

JMOL 294 1942 1972 28967 7.88 4.76 98.53 6.61 6.14 249.92 68.68 161.78

ANT 657 3244 5822 63518 6.81 4.87 96.68 4.94 7.87 76.74 61.76 61.80

JFREECHART 411 2344 5589 67481 9.72 6.92 164.19 5.70 12.78 198.32 54.08 236.04

200 000 lines of code). We provide in what follows

some background on the systems that are used in this

study.

- GNUJSP (http://www.klomp.org/gnujsp/). A free

implementation of JSP (Java Server Pages). The

analyzed version (1.0.1) contains 79 classes.

- JMOL (http://www.openscience.org). A software

for visualizing molecules for students, educators and

researchers. The analyzed version (7) contains 294

classes.

- FREECS (http://freecs.sourceforge.net/). An

online chat server. The analyzed version (1.2.2)

contains 115 classes.

- JFLEX (http://jflex.de/). A lexical analyzer

generator. The analyzed version (1.4) contains 47

classes.

- ANT (www.apache.org). A Java-based build tool,

with functionalities similar to the Unix "make"

utility. The analyzed version (1.5.3) contains 657

classes.

- JHOTDRAW (http://www.jhotdraw.org). A Java

GUI framework for technical and structured

graphics. The analyzed version (5.4) contains 301

classes.

- JFREECHART (http://www.jfree.org/jfreechart).

A chart library for the Java (tm) platform. The

analyzed version (1.1.0) contains 411 classes.

- DBUNIT (http://www.dbunit.org). A Database

Testing Framework. The analyzed version (2.1)

contains 213 classes.

Table 1 summarizes some characteristics of the used

systems and gives the mean values of the selected

metrics.

6 RELATIONSHIP BETWEEN

LACK OF COHESION AND

COUPLING

We present, in this section, the empirical study we

conducted in order to assess the relationship between

lack of cohesion and coupling. We performed

statistical tests using correlation. The null and

alternative hypotheses were:

 H0: There is no significant correlation between

lack of cohesion and coupling.

 H1: There is a significant correlation between

lack of cohesion and coupling.

In this experiment, rejecting the null hypothesis

indicates that there is a statistically significant

relationship between lack of cohesion and coupling

(chosen significance level α=0.05). We used the

coupling metrics CBO and FO, and the lack of

cohesion metrics LCOM, LCOM* and LC

. The

metrics LCOM, LCOM

CBO and FO have been

computed using the Borland Together tool. The LC

metric has been computed using the tool we

developed. Several classes in the selected systems

have, in fact, only one method. These classes were

considered as special classes and have been

excluded from our measurements. We also excluded

all abstract classes. Special methods like

constructors were also removed. These methods may

artificially increase or decrease the cohesion of a

class.

We collected the metrics data from the eight

selected systems. Given the distribution of the

measures we observed, we preferred a non-

parametric measure of correlation in order to test the

correlation between lack of cohesion and coupling.

We used the Spearman’s correlation coefficient.

This technique, based on ranks of the observations,

is widely used for measuring the degree of linear

relationship between the ranks of two variables (two

sets of ranked data). It measures how tightly the

ranked data clusters around a straight line.

Spearman's correlation coefficient will take a value

between -1 and +1. A positive correlation is one in

which the ranks of both variables increase together.

A negative correlation is one in which the ranks of

one variable increase as the ranks of the other

variable decrease. A correlation close to zero means

that there is no linear relationship between the ranks.

We also used the Kendall method to investigate

if the two rankings (lack of cohesion and coupling)

are consistent. Kendall's rank correlation reflects the

strength of the dependence between the variables

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

320

Table 2: Correlations between Lack of cohesion and Coupling metrics.

earman Kendall

earman Kendall S

earman Kendall

CBO FO CBO FO CBO FO CBO FO CBO FO CBO FO CBO FO CBO FO

JHOTDRAW

LCOM 0.568 0.608 0.431 0.474

GNUJSP

LCOM 0.517 0.467 0.373 0.353

ANT

LCOM 0.508 0.519 0.373 0.388

JMOL

LCOM 0.338 0.393 0.242 0.292

210 0 0 0 0 26 0.007 0.016 0.011 0.017 498 0 0 0 0 161 0 0 0 0

LCOM* 0.368 0.366 0.275 0.28 LCOM* 0.58 0.569 0.468 0.459 LCOM* 0.466 0.45 0.346 0.333 LCOM* 0.167 0.154 0.128 0.117

176 0 0 0 0 21 0.006 0.007 0.005 0.006 456 0 0 0 0 123 0.064 0.089 0.044 0.068

0.598 0.61 0.459 0.477 LC

0.497 0.478 0.366 0.348 LC

0.598 0.622 0.46 0.486 LC

0.33 0.438 0.258 0.357

301 0 0 0 0 36 0.002 0.003 0.004 0.006 657 0 0 0 0 294 0 0 0 0

CBO FO CBO FO CBO FO CBO FO CBO FO CBO FO CBO FO CBO FO

FREECS

LCOM 0.545 0.553 0.414 0.432

JFLEX

LCOM 0.508 0.478 0.382 0.359

JFREECHART

LCOM 0.568 0.562 0.42 0.419

DBUNIT

LCOM 0.368 0.294 0.267 0.214

105 0 0 0 0 41 0.001 0.002 0.001 0.003 362 0 0 0 0 130 0 0.001 0 0.001

LCOM* 0.457 0.445 0.32 0.314 LCOM* 0.563 0.499 0.437 0.408 LCOM* 0.276 0.304 0.202 0.223 LCOM* 0.246 0.294 0.19 0.23

111 0.001 0.002 0.002 0.003 35 0 0.002 0 0.001 392 0 0 0 0 99 0.014 0.003 0.01 0.002

0.509 0.542 0.386 0.44 LC

0.606 0.588 0.456 0.445 LC

0.566 0.566 0.421 0.423 LC

0.424 0.46 0.323 0.353

115 0 0 0 0 47 0 0 0 0 411 0 0 0 0 213 0 0 0 0

being compared. High values of the Kendall’s

correlation coefficient means that the most pairs of

values are concordant, indicating that the two

rankings (lack of cohesion and coupling) are

consistent. Analysis of the data sets is done by

calculating the Spearman’s and Kendall’s correlation

coefficients for each pair of metrics (lack of

cohesion metric, coupling metric). We have a total

of six pairs of metrics.

Table 2 summarises the results of the correlation

analysis. It shows, for each used system and between

each distinct pair of metrics, the obtained values for

the Spearman’s and Kendall’s correlation

coefficients with their corresponding p-values.

Moreover, under each metric name in Table 2, we

mention the number of classes that were actually

used in the analysis. The cohesion values of several

classes (like classes having no attributes) are not, in

fact, computed by the Together tool for the metrics

LCOM and LCOM

. This is due to the definition of

measures themselves. The cohesion values of such

classes are, however, computed (using our tool) for

the metric LC

. These classes have, in fact, several

methods which are connected according to the

cohesion criteria defined in section 4.

The obtained Spearman’s correlation coefficients

are significant (at α=0.05). Moreover, the measures

have positive correlation. Since the used cohesion

metrics are, in fact, lack of cohesion measures

(inverse cohesion measures), the positive

coefficients indicate that the ranks of both lack of

cohesion and coupling increase together, which is

consistent with the idea on cohesion and coupling in

the software engineering community. Moreover, the

obtained values of the Kendall’s correlation

coefficient are also significant (at α=0.05). They

confirm that there is more concordance than

discordance in the pairs of metrics, confirming that

the two rankings are consistent. Overall, the results

of the correlation analysis support the idea that the

more strongly a class is coupled to other classes, the

less cohesive the class is likely to be.

We can also see from Table 2 that the metric

is more strongly correlated with the coupling

measures than the metrics LCOM and LCOM*. The

higher correlation values are observed for systems

JHOTDRAW, ANT and JFLEX (metric LC

). The

fact that the metrics LCOM and LCOM* are based

on the concept of sharing instance variables only,

which is a restrictive way of capturing cohesion in

our opinion, leads to lack of cohesion values that do

not, in fact, reflect properly the cohesion of classes.

The metric LC

, compared to the metrics LCOM

and LCOM

, is based on various and complementary

cohesion criteria. It captures more pairs of connected

methods than LCOM and LCOM* metrics. It

captures additional dimensions of cohesion

measurement. This explains, in our opinion, why

obtains higher correlation values with coupling

measures than the metrics LCOM and LCOM

7 RELATIONSHIP BETWEEN

LACK OF COHESION AND

SIZE

We present, in this section, the empirical study we

conducted in order to assess the relationship between

lack of cohesion and size. We performed statistical

tests using correlation. The null and alternative

hypotheses were:

 H0: There is no significant correlation between

lack of cohesion and size.

 H1: There is a significant correlation between

lack of cohesion and size.

Rejecting the null hypothesis, in this experiment

also, indicates that there is a statistically significant

relationship between lack of cohesion and size

EXPLORING EMPIRICALLY THE RELATIONSHIP BETWEEN LACK OF COHESION IN OBJECT-ORIENTED

SYSTEMS AND COUPLING AND SIZE

321

Table 3: Correlations between Lack of cohesion and Size metrics.

Spearman

LOC NOO NOA LOC NOO NOA LOC NOO NOA LOC NOO NOA

JHOTDRAW

LCOM 0.688 0.81 0.441

GNUJSP

LCOM 0.749 0.873 0.269

JMOL

LCOM 0.698 0.805 457

ANT

LCOM 0.752 0.852 0.692

210 0 0 0 26 0.007 0 0.183 161 0 0 0 498 0 0 0

LCOM* 0.384 0.81 0.731 LCOM* 0.68 0.253 0.719 LCOM* 0.425 0.34 0.467 LCOM* 0.652 0.688 0.761

176 0 0 0 21 0.001 0.267 0 123 0 0 0 456 0 0 0

LCD 0.744 0.853 0.578 LC

0.67 0.67 0.419 LC

0.705 0.845 0.634 LC

0.797 0.886 0.793

301 0 0 0 36 0.002 0 0.011 294 0 0 0 657 0 0 0

LOC NOO NOA LOC NOO NOA

FREECS

LCOM 0,590 0.749 0.463

JFLEX

LCOM 0.512 0.483 0.419

DBUNIT

LCOM 0.529 0.574 0.146

JFREECHART

LCOM 0.689 0.721 0.561

105 0 0 0 41 0.001 0.002 0.007 130 0 0 0.099 362 0 0 0

LCOM* 0.753 0.601 0.575 LCOM* 0.545 0.674 0.561 LCOM* 0.478 0.384 0.649 LCOM* 0.359 0.446 0.672

111 0 0 0 35 0.001 0 0.001 99 0 0 0 392 0 0 0

0.678 0.897 0.631 LC

0.802 0.933 0.469 LC

0.719 0.847 0.432 LC

0.826 0.992 0.736

115 0 0 0 47 0 0 0.001 213 0 0 0 411 0 0 0

(chosen significance level α=0.05). We used the

well-known size metrics LOC (Lines Of Code),

NOA (Number of Attributes) and NOO (Number of

Operations). We used also, as for the previous

empirical study, the lack of cohesion metrics

LCOM, LCOM* and LC

. In this experiment also,

special classes and methods have been excluded

from our measurements. We collected the metrics

data from the eight selected systems. We used the

Spearman technique to assess the correlation. Table

3 summarises the results of the correlation analysis.

It shows, for each used system and between each

distinct pair of metrics (lack of cohesion metric, size

metric), the obtained values for the Spearman’s

correlation coefficient (with their corresponding p-

values). We have a total of nine pairs of metrics. The

obtained correlations in this experiment also are

significant (at α=0.05). Furthermore, the correlation

values are positive. This indicates that the ranks of

both lack of cohesion and size increase together,

which is consistent with the idea on cohesion and

size in the software engineering community.

These findings indicate that there is a relative

strong correlation between lack of cohesion and the

quantities measured by size (particularly the number

of methods). The obtained results support the idea

that the larger the class is, the less cohesive the class

is likely to be. It is, in fact, plausible that the larger a

class is, particularly in terms of number of attributes

and methods, the more tasks it includes, so there is

an increased likelihood that some of those tasks are

unrelated which reduces the cohesion of the class.

Overall, we can observe from Table 3 that the

obtained correlation values are higher than those

obtained with coupling (Table 2). Moreover, the

metric LC

is more strongly correlated, in this

experiment also, with the size measures than the

metrics LCOM and LCOM

. The higher correlation

values between LC

and LOC are observed for

systems JFREECHART, JFLEX, ANT,

JHOTDRAW and DBUNIT. The same trend is also

observed with the metric NOO. The correlation

between LC

and particularly the metric NOO is

very strong. As it was the case in the previous

empirical investigation, this confirms that LC

captures additional dimensions of cohesion

measurement compared to the metrics LCOM and

LCOM

. Moreover, the number of classes in a

system seems not influencing the correlation values.

In fact, the higher values of correlations are

observed in relative small systems (such as JFLEX

with 47 classes) as well as in relatively large systems

(such as ANT with 657 classes).

8 CONCLUSIONS AND FUTURE

WORK

The paper investigates the relationship between lack

of cohesion in OO systems and coupling and size.

We performed an empirical study on various open

source Java software systems. We used several well-

known code-based metrics related to cohesion,

coupling and size. The achieved results support the

idea that a lack of cohesion may actually be

associated with (high) coupling and (large) size,

validating some fundamental design principles of

software engineering. The correlation analysis

showed also that, essentially, the metric LC

has

higher correlation values with coupling and size

measures than the metrics LCOM and LCOM

which confirms that it captures additional

dimensions in class cohesion measurement. We hope

this study will contribute to a better understanding of

the relationship between cohesion (lack of cohesion)

and other OO software attributes.

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

322

The analysis performed here is correlational in

nature. We have demonstrated that there is a

statistically and practically significant relationship

between lack of cohesion of classes in OO systems

and coupling and size. Such statistical relationships

do not imply causality. They only provide empirical

evidence of it. Only controlled experiments, where

the measures would be varied in a controlled

manner, could really demonstrate causality.

However, such experiments would be difficult to

perform in practice as stated by Briand et al. in

(Briand, 2000).

The study performed in this paper should be

replicated across many environments and systems,

particularly large-scale systems, in order to draw

more general conclusions about the relationship

between lack of cohesion and coupling and size. In

fact, there are a number of limitations that may

affect the results of the study or limit their

interpretation and generalization.

Firstly, the obtained results are based on the data

set we collected from the analyzed systems. Our

study involved a relatively small number of systems

considering the fact that there are plenty of OO

systems available. This may pose a threat to the

scalability of the results. Even if we believe that the

total number of analyzed classes is enough large to

allow obtaining significant results, the study should

be, however, replicated on a large number of OO

systems to increase the generality of the results.

Secondly, the systems used in the experiment are

rather small or medium. Our study should be

replicated on large systems. Thirdly, it is also

possible that facts such as the development process

used to develop the analyzed systems (for example,

using design heuristics to guide the design process)

and the development style of a given development

team might affect the results or produce different

results for specific applications. Moreover, our study

involved only software systems written in Java.

While there is no reason to suspect that the results

would be different with systems written in other OO

languages (such as C++), it would be interesting to

study systems written in other languages.

As future work, we plan to investigate the

relationship between lack of cohesion and some

relevant external software quality attributes such as

testability. In addition, we will extend this study by

integrating other class cohesion metrics, particularly

semantic cohesion metrics.

ACKNOWLEDGEMENTS

This project was financially supported by NSERC

(National Sciences and Engineering Research

Council of Canada).

REFERENCES

Aggarwal, K. K., Yogesh, S., Arvinder K., Ruchika, M.,

2006. Empirical study of object-oriented metrics.

Journal of Object Technology. vol. 5. no. 8.

Aggarwal, K. K., Yogesh, S., Arvinder, K., Ruchika, M.,

2006. Investigating the effect of coupling metrics on

fault proneness in object-oriented systems. SQP, vol. 8

no. 4.

Aman, H., Yamasaki, K., Yamada, H., Noda, M.T., 2002.

A proposal of class cohesion metrics using sizes of

cohesive parts. Knowledge-Based Sof. Engineering. T.

Welzer et al. (Eds) IOS Press.

Badri, L., Badri, M., 2004. A proposal of a new class

cohesion criterion: An empirical Study. Journal of

Object Technology. vol. 3, no. 4, Special issue:

TOOLS USA.

Badri, L., Badri, M., Gueye, A., 2008. Revisiting class

cohesion, An empirical investigation on several

systems. Journal of Object Technology. vol. 7, no. 6.

Basili, V. R., Briand, L.C., Melo, W., 1996. A validation

of object-oriented design metrics as quality indicators.

IEEE TSE, 22 (10).

Bansiya, J., Davis, C.G., 2002. A hierarchical model for

object-oriented design quality assessment. IEEE TSE,

vol. 28, no. 1.

Bieman, J. M., Kang, B. K., 1995. Cohesion and reuse in

an object-oriented system. Proc. of the Symposium on

Software Reusability.

Booch, G., 1994. Object-Oriented Analysis and Design

With Applications, Benjamin/Cummings. 2

edition.

Briand, L. C., Daly, J., Porter, V., Wuest, J., 1997. The

dimensions of coupling in object-oriented design.

Proceedings of OOPSLA’97.

Briand, L.C., Daly, J., Porter, V., Wuest, J., 1998. A

unified framework for cohesion measurement in

object-oriented systems. Empirical Software

Engineering, 3 (1).

Briand, L. C., Daly, J., Porter, V., Wuest, J., 2000.

Exploring the relationships between design measures

and software quality in object-oriented systems.

Journal of Systems and Software, No. 51.

Bruntink, M., Van Deursen, A., 2006. An empirical study

into class testability. Journal of Sysems and Software,

79, 9.

Chae, H. S., Kwon, Y. R., Bae, D. H., 2000. A cohesion

measure for object-oriented classes. Software Practice

and Experience, No. 30.

Chae, H. S., Kwon, Y. R., Bae, D. H., 2004 Improving

cohesion metrics for classes by considering dependent

instance variables. IEEE TSE. vol. 30, no. 11.

EXPLORING EMPIRICALLY THE RELATIONSHIP BETWEEN LACK OF COHESION IN OBJECT-ORIENTED

SYSTEMS AND COUPLING AND SIZE

323

Chaumun, M. A., Kabaili, H., Keller, R. K., Lustman, F.,

St-Denis, G., 2000. Design properties and object-

oriented sotware changeability. Proc. of the 4

Euromicro Working Conference on Software

Maintenance and Reengineering.

Chen, Z., Zhou, Y., Xu, B., Zhao, J., Yang, H., 2002. A

novel approach to measuring class cohesion based on

dependence analysis. Proc. 18

International

Conferrence on Software Maintenance.

Chidamber, S. R., Kemerer, C.F., 1991. Towards a

Metrics Suite for Object-Oriented Design. OOPSLA.

Special Issue of SIGPLAN Notices, Vol. 26, No. 10.

Chidamber, S. R., Kemerer, C. F., 1994. A Metrics suite

for object Oriented Design. IEEE TSE. Vol. 20, No. 6.

Chidamber, S. R., Darcy, D. P., Kemerer, C. F., 1998.

Managerial use of metrics for object-oriented

software : An exploratory analysis. IEEE TSE, Vol.

24, No. 8.

Counsell, S., Swift, S., 2006. The interpretation and utility

of three cohesion metrics for object-oriented design.

ACM TSEM. vol. 15, no. 2.

Dagpinar, M., Jahnke, J. H., 2003. Predicting

maintenability with object-oriented metrics – An

empirical comparaison. Proc. of the 10

working

conference on reverse engineering (WCRE’03). IEEE

computer society.

Darcy, D., Kemerer, K., 2005. OO metrics in practice,

IEEE Software. vol. 22, no. 6.

De Lucia, A., Oliveto, R., Vorraro, L., 2008. Using

structural and semantic metrics to improve class

cohesion. Proc. of the ICSM.

Dunsmore, H.E., 1984. Software metrics: An overview of

an evolving methodology. Information Processing and

Management, 20(1-2), 183-192.

El Emam, K., Melo, W., 1999. The prediction of faulty

class using object-oriented design metrics. National

Research Council of Canada NRC/ERB 1064.

Etzkorn, L. H., Gholston, S.E., Fortune, J. L., Stein, C. E.,

Utley, D., 2004. A comparison of cohesion metrics for

object-oriented systems. Information and Software

Technology, 46.

Fenton, N., Pfleeger, S. L., 1996. Software Metrics: A

Rigorous and Practical Approach. Int. Thomson

Computer Press. 2

edition.

Harrison, R., Counsell, S. J., Nithi, R., 1998. An

investigation into the applicability and validity of

object-oriented design metrics. Empirical Software

Engineering, vol. 3, no. 3.

Henderson-Sellers, B., 1996. Object-Oriented Metrics

Measures of Complexity, Prentice-Hall.

Hitz, M., Montazeri, B., 1995. Measuring coupling and

cohesion in object-oriented systems. Proc. of the Int.

Symp. on Applied Corporate Computing.

Kabaili, H., Keller, R. K., Lustman, F., Saint-Denis, G.,

2000. Class Cohesion Revisited: An Empirical Study

on Industrial Systems. Proc. of the Workshop on

Quantitative Approaches Object-Oriented Software

Engineering. France.

Kabaili, H., Keller, R.K., Lustman, F., 2001. Cohesion as

Changeability Indicator in Object-Oriented Systems.

Proceedings of the Fifth European Conference on

Software Maintenance and Reengineering (CSMR

2001). Estoril Coast (Lisbon), Portugal.

Kitchenham, B. A. Linkman, S.J., 1990. Design metrics in

practice. Information Software Technology.

Larman, G., 2003. Applying UML and Design Patterns,

An introduction to object-oriented analysis and design

and the unified process, Prentice Hall.

Levitin, A. V., 1986. How to measure size and how not to,

Proc. 10

COMPSAC. Chicago, oct 8-10, IEEE

Computer Society Press.

Li, W., Henry, S., 1993. Object-oriented metrics that

predict maintainability. Journal of Systems and

Software. Vol. 23.

Li, W., Henry, S., Kafura, D., Schulman, R., 1995.

Measuring Object-Oriented Design. Journal of Object-

Oriented Programming. Vol. 8, No. 4.

Marcus, A., Poshyvanyk, D., 2005. The conceptual

cohesion of classes. Proc. 21th IEEE Int. Conf. on

Software Maintenance.

Marcus, A., Poshyvanyk, D., Ferenc, R., 2008. Using the

Conceptual Cohesion of Classes for Fault Prediction in

Object-Oriented Systems. IEEE TSE. Vol. 34, NO. 2.

Meyers, T.M., Binkley, D., 2004. Slice-Based cohesion

metrics and software intervention. Proc. 11

IEEE

WCRE.

Pant, Y. R., Verner, J. M., Hendreson-Sellers, B., 1995.

S/C: a software size/complexity measure, chapter 50 in

Software Quality and Productivity: Theory, Practice,

Education and Training, eds. M. Lee, B.-Z. Barta, and

P. Juliff, Chapman & Hall, London.

Pressman, R.S., 2005. Software Engineering, A

practitioner's approach, Mc Graw Hill.

Sommervile, I., 2004. Software Engineering.

Stein, C., Cox, G., Etzkorn, L., 2005. Exploring the

relationship between cohesion and complexity.

Journal of Computer Science. 1 (2),

Weyuker, E. J., 1988. Evaluating software complexity

measures. IEEE TSE. 14(9), 1357-11365.

Woo, G., Chae, H. S., Cui, J. F., Ji, J.H., 2009. Revising

cohesion measures by considering the impact of write

interactions between class members. Information and

Software Technology, 51.

Xu, J., Ho, D., Capretz, L.F., 2008. An Empirical

Validation of Object-Oriented Design Metrics for

Fault Prediction. Journal of Computer Science, 4 (7),

571-577.

Yourdon, E., Constantine, L., 1979. Structured Design,

Prentice Hall, Englewood Cliffs. N.J.

Zhou, Y., Xu, B., Zhao, J., Yang, H., 2002. ICBMC: An

improved cohesion measure for classes. Proc. 18

ICSM.

Zhou, Y., Wen, L., Wang, J., Chen., Y., Lu, H., Xu, B.,

2003. DRC: dependence-relationships-based cohesion

measure for classes. Proc. 10

APSEC.

Zhou, Y., Leung, H., 2006. Empirical analysis of object-

oriented design metrics for predicting high and low

severity faults. IEEE TSE. vol. 32, no. 10.

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

324
