A Language Model for Human-Machine Dialog: The

Reversible Semantic Grammar

ome Lehuen and Thierry Lemeunier

LIUM, Universit

e du Maine, Avenue Olivier Messiaen, 72085 Le Mans, France

Abstract. In this paper we present algorithms for analysis and generation in a

human-machine dialog context. The originality of our approach is to base these

two algorithms on the same knowledge. The latter combines both semantic and

syntactic aspects. The algorithms are based on a double principle: the correspon-

dence between offers and expectations, and the calculation of a heuristic score.

We present also some results obtained by performing an evaluation based on the

MEDIA French corpus.

1 Introduction

The human-machine spoken dialog systems generally dissociate analysis processes

from generation processes. Yet, it is useful to pool the knowledge of the analysis and of

the generation processes so that the system can say what it understands and can under-

stand what it says. There are at least three consequences. Firstly, the user’s utterances

can be quoted or reformulated. Secondly, the machine can control itself during the gen-

eration processes. Thirdly, a joint improvement of these two skills is possible as soon

as the knowledge increases.

We propose a speciﬁc model of language called the Reversible Semantic Grammar

(RSG) which combines both semantic and syntactic aspects. The originality of our ap-

proach consists in the reversibility: this language model is used at the same time to

analyze and to generate utterances. Another important point of this dual representation

is that it allows a robust analysis of the spoken utterances and a rather subtle generation.

The RSG takes place in an existing dialog engine which is structured into four levels

(see Fig. 1). The three upper ones (language, dialog and interactive task) communicate

through a shared working memory, in the same way as the ”blackboard” architectures.

This article focuses on the language level. The RSG is presented in section 2. The

analysis and the generation algorithms are detailed and exempliﬁed in section 3. Some

results and a comparison with other systems are given in section 4.

2 The RSG Model of Language

The knowledge model is based on the notions of concept and of relations between

concepts. This last aspect is inspired by the model of dependency structures proposed

by the French linguist Lucien Tesni

ere [1]. A concept represents an object, an action, an

Lehuen J. and Lemeunier T.

A Language Model for Human-Machine Dialog: The Reversible Semantic Grammar.

DOI: 10.5220/0003017200170026

In Proceedings of the 7th International Workshop on Natural Language Processing and Cognitive Science (ICEIS 2010), page

ISBN: 978-989-8425-13-3

Application Level

Interactive Task Level

Dialog Level

Underlying application

(dialog-independent)

Speciﬁc dialog rules

(task-dependent)

Generic dialog rules

(task-independent)

Shared

Memory

Language Level (RSG)

Knowledge and algorithms

for analysis and generation

Fig. 1. RSG in the dialog engine.

syntactic

patterns

concept "blah blah blah"

generation

analysis

{ x, y, z }

{ e1, e2 } { e3, e4 }

offers

expectations

Fig. 2. Model of a concept of valence 2.

attribute, etc. The features of a concept are its offers, its expectations, and its syntactic

patterns (see Fig. 2).

The offers are semantic categories and deﬁne the concept [2]. The expectations are

also semantic categories but describe the potential links with other concepts. An expec-

tation is not necessarily required. Each concept has a library of syntactic patterns. The

latter contains words and references to the expectations of the concept. Each pattern can

be characterized by distinctive features (pragmatic and/or morphological ones) which

allow a precise description of the pattern’s use (level of language, politeness, illocutory

force, gender, number, etc.). This full-form encoding simpliﬁes the generation process.

The representation of an utterance consists in an oriented graph. The nodes in

the graph, called ”comprehension granules”, are concepts instanciated in the context

of utterance. For example the following French utterance: ”bonjour, je voudrais une

baguette bien cuite s’il vous plat” (hello, I’d like a nice crisp baguette please) is repre-

sented in Fig. 3.

3 The Analysis and the Generation of Utterances

3.1 The Analysis Algorithm

According to the knowledge model, the analysis consists in building a structure of gran-

ules from a string of characters. The process composed of ﬁve stages creates and links

granules according to syntactic criteria (the pattern matching) and/or semantic criteria

(the correspondence between offers and expectations). These two kinds of criterion are

either combined, or used independently from one another in order to generate hypothe-

ses. The ﬁve stages of the analysis are:

1. Nucleus Identiﬁcation: the instantiation of certain types of ”leaf granules” (such

as dates) using regular expressions or local grammars;

Bonjour, je voudrais une baguette bien cuite s'il vous plaît.

(quantity)

(object)

(quality)

(opening) (politeness)(speech-act)

(speech-act)

REQUEST#6

(quantity)

ONE#2

(object)

BAGUETTE#5

(quality)

NICECRISP#3

(opening)

GREETING#1

(politeness)

PLEASE#4

Root granules

Fig. 3. Dependency structure produced by the RSG.

2. Utterance Segmentation: the identiﬁcation of parts of the utterance likely to con-

tain a granule using the concepts’ expectations and the syntactic patterns. The aim

is to generate some lexical hypotheses (word or expressions) as hypothetical gran-

ules;

3. Structure Construction: the instantiation of granules as well as the connections

between them using the concepts’ expectations and the syntactic patterns. The al-

gorithm is based on the opportunistic ﬁlling of a chart and on a heuristic function;

4. Conﬂict Resolution: the removal of the remaining conﬂicts of position between

granules. The ”weak granules” are suppressed for the beneﬁt of the ”strong gran-

ules” using an evaluation function;

5. Granule Rescuing: the linking of ”orphan granules” to others thanks to hypothet-

ical links using the correspondence between offers and expectations, as well as a

proximity criteria.

The method we use to analyze without backtracking is ”chart parsing” [3] [4]. Basi-

cally, a chart parser emulates parallel processing by concurrently pursuing all alternative

analyses at each step. The chart parser can identify the multiple understandings. It is up

to the dialog level to select one through interaction. At the end, there only remain the

”strong granules” or conﬂictual granules of the same score (Fig. 4 presents an analysis

result).

A score of a granule G is computed by taking into account its coverage (number

of words), its dispersion (number of words that are not taken into account), the scores

of its links Ai and the scores of its children Gi. The score of a link is equal to the

number of common features between the offers and the expectations. An example of

score computing is given in Fig. 4.

score(G) = coverage(G) − dispersion(G) +

v al

i=1

(10×score(A

)×score(G

))

3.2 Some Particular Cases of Analysis

This section presents examples illustrating particular performances, such as the identi-

ﬁcation of tonic or periphrastic questions and as the resolution of certain ambiguities

and as the generation of hypotheses.

quantity:ONE

score = 1

object:BAGUETTE

score = 34

quality:NICECRISP

score = 2

offers = { object, eatable }

text = "une baguette très bien cuite"

position = 4

coverage = 5

dispersion = 1

offers = { quality }

text = "bien cuite"

position = 7

coverage = 2

dispersion = 0

expectations = { quantity }

scoreA1 = 1

expectations = { quality }

scoreA2 = 1

offers = { quantity }

text = "une"

position = 4

coverage = 1

dispersion = 0

Fig. 4. Calculation of the score of the granule BAGUETTE.

– The ﬁrst example illustrates the difference between the analysis of a tonic ques-

tion and the analysis of a periphrastic one. In the representations below, the tonic

character is indicated by the underlined categories and the periphrastic character is

indicated by the speech-act granule:

a) Le second semestre commence quand ? (When does the 2nd semester start?)

⇒ (information:DATE question tonic

A1:(event:S2))

b) Je voudrais savoir

a quelle date commence le second semestre (I’d like to know

when the 2nd semester starts)

⇒ (speech-act:REQUEST

A1:(information:DATE

A1:(event:S2)))

– The second example shows how the analyzer naturally solves the rare (and artiﬁ-

cial) cases of homonymous ambiguity, if the context so permits. Here, the problem

with the French word ”avocat” (which can be both a lawyer or an avocado) is solved

thanks to its adjective:

c) Je voudrais un avocat bien m

ur (I’d like a well ripe avocado)

⇒ (speech-act:REQUEST

A1:(object:AVOCADO

A1:(quantity:ONE)

A2:(aspect:RIPE)))

d) Je voudrais un avocat comp

etent (I’d like a competent lawyer)

⇒ (speech-act:REQUEST

A1:(person:LAWYER

A1:(quantity:ONE)

A2:(skill:COMPETENT)))

– The coordinating-conjunction ”et” (and) is built according to the categories or the

features of the granules situated on the left and on the right of the conjunction. The

category of the concept AND is given by its two child-granules:

e) Puis-je avoir une baguette et avez-vous deux croissants ? (Can I have one baguette

and have you got two croissants?)

⇒ (speech-act:AND

A1:(speech-act:REQUEST

A1:(object:BAGUETTE

A1:(quantity:ONE)))

A2:(speech-act:REQUEST

A1:(object:CROISSANT

A1:(quantity:TWO))))

f) Je voudrais une baguette et deux croissants (I’d like one baguette and two crois-

sants?)

⇒ (speech-act:REQUEST

A1:(object:AND

A1:(object:BAGUETTE

A1:(quantity:ONE))

A2:(object:CROISSANT

A1:(quantity:TWO))))

– The rescuing stage enables the analyzer to deal with dislocated utterances which

produce ”orphan granules”. The analyzer will try to connect them to nearby gran-

ules if possible. The codes of the hypothetical connections are underlined in the

examples below:

g) Le second semestre je voudrais savoir la date (the 2nd semester I would like to

know the date)

⇒ (speech-act:REQUEST

A1:(information:DATE

?A1:(event:S2)))

h) Le second semestre la date je voudrais savoir (the 2nd semester the date I would

like to know)

⇒ (speech-act:REQUEST

?A1:(information:DATE

?A1:(event:S2)))

– Finally, thanks to the step of segmentation, the analyzer is able to make lexical

hypotheses concerning unknown words. The unknown segments ”le truc” and ”le

bidule” are identiﬁed with the syntactic pattern ”ranger [objet] dans [rangement]”

(to tidy [object] in [place]).

i) Ranger le truc dans le bidule

⇒ (action:TIDY

A1:(?object:[le truc])

A2:(?place:[le bidule]))

3.3 The Generation Algorithm

The objective is to build a sentence from a granule structure by using the most adequate

syntactic patterns. The principle is based on the propagation of a ”global generation

goal” Tg from the root to its leaves. A score is calculated for each node and for each

verbalization according to Tg and to a local criterion that takes into account its dis-

tinctive features, the scores of its children and links. The ﬁnal sentence is obtained by

combining the best verbalizations. Let V be a verbalization and Tp(V) its distinctive

features. Let Vi be a candidate verbalization for the i

child granule and Tp(Vi) its

distinctive features. The score of V is computed by the following formula:

score(V ) = card(T p(V ), T g) +

v al

i=1

(10×score(V i) + card(T p(V ), T p(V i)))

where card(s1, s2) = cardinality(s1 ∩ s2) for two sets s1 and s2. In Fig. 5, the score

of the verbalization ”une baguette bien cuite” is 25, whereas the score of the wrong

verbalization ”un baguette bien cuit” is 23 (there are two gender agreement errors:

”un” instead of ”une” and ”cuit” instead of ”cuite”). Let the generation goal be Tg =

{colloquial}, then the score of the verbalization ”je voudrais une baguette bien cuite”

will be 251 whereas the score of the best verbalization ”ﬁle-moi une baguette bien

cuite” will be 252.

granule BAGUETTE

Tg = { colloquial }

text = "ﬁle-moi une baguette bien cuite"

score = 1 + 1 + 250 = 252

pattern = "ﬁle-moi A1"

Tp = { colloquial }

Tg = { colloquial }

text A1 = "une baguette bien cuite"

score A1 = 1 + 12 + 12 = 25

granule ONE

text A2 = "bien cuite"

pattern = "A1 baguette A2"

Tp = { fem, sing }

pattern = "bien cuite"

Tp = { fem, sing }

pattern = "une"

Tp = { fem, sing }

Tg = { colloquial }

GOAL

score A2 = 1

granule NICECRISP

granule REQUEST

Fig. 5. Example of a generation process.

3.4 An Example of Use of the Generation Capabilities

The following example shows how RSG can be used in order to reformulate a dislocated

utterance like: ”Je voudrais baguette... une” (Can I have baguette... one). The result of

the analysis of this utterance is:

⇒ (speech-act:REQUEST

A1:(object:BAGUETTE

?A1:(quantity:ONE)))

There is an uncertain link between the two granules BAGUETTE and ONE (it’s the

result of the ”granule rescuing” stage (see 3.1)), so the dialog engine has to check it

by engaging a validation tactic. The generated response is: ”Pardon, j’ai un doute sur

la quantit

e exprim

ee, vous voulez bien une baguette ?” (Sorry, I have doubts about the

quantity you have expressed, do you want one baguette?). This response consists of two

parts. The ﬁrst one (Sorry [...] expressed) uses a description pattern of the expectation

A1 of the granule BAGUETTE. The second one (do you want one baguette) is based

on a veriﬁcation pattern of the granule REQUEST.

4 The Evaluation of the Analyzer

4.1 The MEDIA Corpus

At this time, we have evaluated only our analyzer using the French MEDIA dialog cor-

pus. This corpus has already been used in the MEDIA evaluation campaign [5] [6] that

aimed to deﬁne and test an evaluation methodology to compare and diagnose the un-

derstanding capability of spoken dialog systems. Both context-independent and context-

dependent understanding evaluations had been planned but only the ﬁrst possibility was

performed.

The MEDIA task is the reservation of hotel rooms with tourist information, using

information obtained from a web-based database. The dialog corpus was recorded using

a WOZ system simulating a vocal tourist information phone server. Each caller believed

he or she was talking to a machine whereas in fact he was talking to a human being (a

wizard) who simulated the behavior of a tourist information server. In this way, 1257

have been recorded from 250 different speakers where each caller carried out 5 different

hotel reservation scenarios. The ﬁnal corpus is about 70 hours of dialogs transcribed

then conceptually annotated according to a semantic representation deﬁned within the

campaign. It is divided into a training part of 11000 utterances and an unseen test part

of 3000 utterances.

Four kinds of scores have been proposed according to the characteristics of the se-

mantic representation in which there are four modes (afﬁrmative, negative, interrogative

or optional) and a set of attributes (representing the meaning of a sequence of words)

more or less speciﬁed (by adding some speciﬁers taken from a limited list). The full

scoring uses the whole set of attributes whereas in the relax scoring, the speciﬁers are

no longer considered. Another distinction is done by taking into account either the 4

modes or only 2.

4.2 The MEDIA Semantic Representation

The MEDIA evaluation is based on a ﬂat semantic representation [5] which is based

on a list of attribute-value structures in which conceptual relationships are implicitly

represented by the names of the attributes. More precisely, the meaning of a segment

of words is represented by a triplet which contains the name of the attribute, the value

of the attribute, and a mode which can be afﬁrmative (+), negative (-) or interrogative

(?). For example, the utterances ”Je voudrais r

eserver un h

otel

a Paris pr

es de la gare

Saint-Lazare du quatorze au seize” (I’d like to book a hotel in Paris near the Gare

Saint-Lazare from the fourteenth to the sixteenth) is represented in Table 1.

This ﬂat representation is less expressive than ours, which is a hierarchical one,

but we must project it to this ﬂat one so as to be able to perform an evaluation using

the common evaluation tools. We have identiﬁed 3 major steps to project the granules

structures to triplets sequences:

1) The creating of incomplete triplets (attribute, value, +) from the granules: con-

cepts become values and categories become attributes. For example, the concept ”near”

which offers the category ”localization-relativeDistance” produces the attribute ”localization-

relativeDistance” with the value ”near”. The mode is set to + by default, unless it is

noted in the syntactic pattern.

2) The appending of missing speciﬁers to attributes on the basis of propagation

rules. For example, the speciﬁer ”-hotel” is appended to the attribute ”localization-

relativeDistance” because of the preceding triplet (BDobject, hotel, +).

3) The adding or the changing of some modes on the basis of inference rules. For

example, the mode of all the triplets of the second utterance are changed into an inter-

rogative one because of the interrogative marker ”Quels sont”. The latter is recognized

by our analyzer but does not produce any triplet because it does not correspond to any

attribute of the MEDIA semantic dictionary.

Table 1. An example of a MEDIA semantic representation.

Word sequence Attribute name Normalized value Mode

je voudrais r

eserver command-task reservation +

un h

otel BDobject hotel +

a Paris localization-town-hotel Paris +

es de localization-relativeDistance-hotel near +

la gare Saint-Lazare localization-relativeNamedPlace-hotel gare Saint-Lazare +

du quatorze time-day-month-from-reservation 14 +

au seize time-day-month-to-reservation 16 +

4.3 The Results

We present in Table 2 error rates calculated from comparisons of our results and ex-

pected ones. This rate is: (SUB + DEL + INS) / TOT where SUB is the number of

changed triplets, DEL is the number of deleted triplets, INS is the number of added

triplets, and TOT the number of triplets we have to identify. We obtain a pretty good

score in the most difﬁcult mode (full 4 modes). The deviations of 4.7% and 5% be-

tween the ”2 modes” rates and the ”4 modes” rates correspond to the identiﬁcation of

questions which are difﬁcult to identify without taking into account the context of the

application. Our system is more efﬁcient than others on this point. There is an average

deviation of 2.9% between the ”relax modes” rates and the ”full modes” rates. This

can be explained by the relative proximity between our semantic representation and the

MEDIA one, which avoids errors of projection of granules to triplets.

We obtain 5986 correct concepts, 1363 SUB, 1038 DEL and 499 INS. The major

problem is the very important number of substitutions. If we have a look on the align-

ment charts, we can see that this is a side effect of the Levenshtein algorithm. In fact, a

lot of substitutions are consequences of alignment errors, which are due to the deletions

and to the insertions. So to reduce the substitution errors rate, clearly we have to work

in order to reduce the deletions rate and the insertions rate. The important number of

substitutions comes also from a source of errors already identiﬁed in [7] related to the

projection of a hierarchical representation to a linear one. Indeed, the triplets follow the

order of words, while structures of granules are not dependent on that order. Whatever

the projection method, we observe inversions compared to the expected order, which

together increase the SUB rate and the INS rate.

If we sort the errors by category (cf. Table 3), we can notice that an important per-

centage of errors concern the recognition of the concept refLink-coRef (26.18% of the

deletions, and 16.35% of the insertions). In the annotated corpus, this concept corre-

sponds to some articles (le, la, les), to some pronouns (il, elle), and to some demon-

strative adjectives (ce, cet, cette), in anaphoric reference contexts. We tried to enhance

the recognition rate by working on syntactic patterns. We observed a communicating

vessels effect between the DEL rate and the INS rate, but no global signiﬁcant improve-

ment. Therefore we think that we can’t resolve this problem without introduce anaphora

resolution capabilities.

Another problematic issue is the recognition of the concept object. A lot of terms

are both a concept name, and a possible value of the concept object (example: hotel,

room, equipment, localization, number, time, etc.). This ambiguity causes 15.74% of

the deletions, 6.21% of the substitution and 6% of the insertions. If we try to work on the

syntactic patterns, we observe a communicating vessels effect, like for the refLink-coRef

concept. We think that these problems denote one limit of the ”knowledge” approaches

that probabilistic approaches don’t have. However, we also show that our approach

gives good results in full mode, i.e. when we have to complete a triplet (concept, value,

mode).

Table 2. Results in terms of error rate.

Full Relax

4 modes 2 modes 4 modes 2 modes

LIMSI-1 (29.0) LIMSI-2 (23.2) LIMSI-1 (27.0) LIMSI-2 (19.6)

LIMSI-2 (30.3) LIMSI-1 (23.8) LIMSI-2 (27.2) LIMSI-1 (21.6)

LIUM (34.7) LORIA (28.9) LIA (29.8) LIA (24.1)

LORIA (36.3) LIUM (30.0) LIUM (31.9) LORIA (24.6)

VALORIA (37.8) VALORIA (30.6) LORIA (32.3) LIUM (26.9)

LIA (41.3) LIA (36.4) VALORIA (35.1) VALORIA (27.6)

5 Conclusions

This article presents a new dialog-oriented model of language: the Reversible Semantic

Grammar which uses the same knowledge for analysis as well as generation. Its orig-

inality comes from a high integration of syntactical and semantical aspects, which is

present in the lexical representation, but also in the algorithms. That’s why there is not

a real grammatical parser in our system, in opposition to other systems. This allows us

to focus on semantics: the lexicon is a collection of concepts which includes syntactic

patterns. Our approach can be compared with Gardent’s [8]. The common point is that

a non-deterministic algorithm is used for the generation. The differences come from the

linguistic model, and the way to enforce determinism. We use semantic/pragmatic con-

straints, whereas Gardent uses grammatical ones. The reason is that we work on spoken

dialog, with sentences that are mainly ungrammatical and not well-structured.

Table 3. The nine most important errors sorted by category.

Number Type Concept Percentage

266 DEL refLink-coRef 26.18 of 1016 DEL

160 DEL object 15.74 of 1016 DEL

123 INS connectProp 20.74 of 593 INS

97 INS refLink-coRef 16.35 of 593 INS

91 SUB hotel-name 6.98 of 1326 SUB

81 SUB object 6.21 of 1326 SUB

70 INS response 11.80 of 593 INS

64 SUB refLink-coRef 4.94 of 1326 SUB

58 DEL connectProp 5.70 of 1016 DEL

The results exposed in this article only concern the analyzer. The evaluation is based

on the MEDIA corpus which is the French reference dialog corpus with evaluation

tools. The linguistic model that we implement, which is a kind of context-free grammar,

is pretty simple. Since the scores we obtain are equivalent to those of other systems, this

proves that this approach is good enough in our dialog context.

References

1. Tesni

ere, L.:

ements de syntaxe structurale. Klincksiek, Paris (1959)

2. Katz, J., Fodor, J.: The structure of a semantic theory. Language 2 (1963) 170–210

3. Kay, M.: Algorithm shemata and data structures in syntactic processing. Technical Report

CSL-80-12, Xerox Corporation (1980)

4. Grosz, B., Jones, K., B., W., eds.: Readings in Natural Language Processing. Morgan Kauf-

mann Publishers Inc (1986)

5. Bonneau-Maynard, H., Rosset, S., Ayache, C., Kuhn, A., Mostefa, D., the MEDIA consor-

tium: Semantic annotation of the french media dialog corpus. In: Proceeding of INTER-

SPEECH 2005, Lisbon, Portugal (2005) 3457–3460

6. Bonneau-Maynard, H., Ayache, C., Bechet, F., Denis, A., Kuhn, A., Lefevre, F., Mostefa,

D., Quignard, M., Rosset, S., Sevran, C., Villaneau, J.: Results of the french evalda-media

evaluation campaign for literal understanding. In: Proceedings of LREC 2006, Genoa, Italy

(2006) 2054–2059

7. Villaneau, J., Lamprier, S.: Corpus de dialogue homme/machine: annotation s

emantique et

compr

ehension. In: Actes des Journ

ees Internationales de Linguistique de Corpus, Lorient,

France (2005) 221–229

8. Gardent, C., Kow, E.: A symbolic approach to near-deterministic surface realisation using tree

adjoining grammar. In: Proceeding of ACL 2007, Prague, Czech Republic (2007) 328–335
