OFP CLASS: AN ALGORITHM TO GENERATE OPTIMIZED

FUZZY PARTITIONS TO CLASSIFICATION

Jos´e M. Cadenas, M. del Carmen Garrido, Raquel Mart´ınez and Enrique Mu˜noz

Dpto. de Ingenier´ıa de la Informaci´on y las Comunicaciones, Facultad de Inform´atica

Universidad de Murcia, Murcia, Spain

Keywords:

Fuzzy discretization, Fuzzy set, Genetic algorithm, Fuzzy decision tree.

Abstract:

The discretization of values is a important role in data mining and knowledge discovery. The representation

of information through intervals is more concise and easier to understand at certain levels of knowledge than

the representation by mean continuous values. In this paper, we propose a method for discretizing continuous

attributes by means a series of fuzzy sets which constitute a fuzzy partition of this attribute’s domain. We

present an algorithm, which carries out a fuzzy discretization of continuous attributes in two stages. In the ﬁrst

stage a fuzzy decision tree is used and the genetic algorithm is used in the second stage. In this second stage

the cardinality of the partition is deﬁned. After deﬁning the fuzzy partitions these are evaluated by a fuzzy

decision tree which is also detailed in this study.

1 INTRODUCTION

The selection, processing and data cleaning is one of

the phases making up the process of knowledge dis-

covery. This phase can be very important for some

algorithms of classiﬁcation, because the data must

be preprocessed so that the algorithm can work with

them. A possible change in the data may be the

discretization of continuous values. The discretiza-

tion continuous attributes can be carried out through

crisp partitions or fuzzy partitions. Crisp partitions

use classical logic, where each attribute is split into

several intervals, whereas fuzzy partitions use fuzzy

logic. On the one hand, we can ﬁnd techniques to dis-

cretize continuous attributes into crisp intervals, (Liu

et al., 2002), (Catlett, 1991), in which a domain value

can only belong to a partition or interval. On the

other hand we ﬁnd methods to discretize continuous

attributes into fuzzy intervals (Li, 2009), (Li et al.,

2009), in this case, a domain value can belong to more

than one element of the fuzzy partition.

In this study we present the OFP

CLASS Algo-

rithm to carry out a fuzzy discretization of continuous

attributes, which is divided in two stages. In the ﬁrst

stage, we carry out a search of split points for each

continuous attribute. In the second stage, based on

these split points, we use a genetic algorithm which

optimizes the fuzzy sets formed from the split points.

Having designed the fuzzy sets that make up the fuzzy

partition of each continuous attribute, they are evalu-

ated with a classiﬁer constituted by a fuzzy decision

tree.

The structure of this study is as follows. In Section

2, we are going to present a taxonomy of discretiza-

tion methods, as well a review various discretization

methods. Then, in Section 3, we are going to present

the OFP CLASS Algorithm, which is based on a deci-

sion tree and a genetic algorithm, as our proposal for

the problem of fuzzy discretization applied to clas-

siﬁcation. Next, in Section 4, we will show various

experimental results which evaluate our proposal in

comparison with previously existing ones and where

the results have been statistically validated. Finally, in

Section 5, we will show the conclusions of this study.

2 DISCRETIZATION METHODS

The classiﬁcation is one of the most important topics

in data mining area. There are many different classi-

ﬁcation methods which work with continuous values

and/or discrete values. However, not all classiﬁcation

algorithms can work with continuous data, hence dis-

cretization techniques are needed to these algorithms.

Although, there are algorithms which work with dis-

crete data by the fact that they can improve results in

classiﬁcation tasks.

M. Cadenas J., del Carmen Garrido M., Martínez R. and Muñoz E..

OFP_CLASS: AN ALGORITHM TO GENERATE OPTIMIZED FUZZY PARTITIONS TO CLASSIFICATION.

DOI: 10.5220/0003052700050013

In Proceedings of the International Conference on Fuzzy Computation and 2nd International Conference on Neural Computation (ICFC-2010), pages

5-13

ISBN: 978-989-8425-32-4

 2010 SCITEPRESS (Science and Technology Publications, Lda.)

When a discretization process is to be developed,

four iterative stages must be carried out, (Liu et al.,

2002):

1. The values in the database of the continuous at-

tributes to be discretized are ordered.

2. The best split point for partitioning attribute do-

mains in the case of top-down methods is found,

or the best combination of adjacent partitions for

bottom-up methods is found.

3. If the method is top-down, once the best split

point is found, the domain of each attribute is di-

vided into two partitions, and when the method is

bottom-up, both partitions are merged.

4. Finally, we check whether the stopping criterion

is fulﬁlled, and if so the process is terminated.

In this general discretization process we have dif-

ferentiated between top-down and bottom-up algo-

rithms. However, there are more complex taxonomies

for the different methods of discretization such as that

presented in (Liu et al., 2002) and which are shown

here:

• Supervised or non-supervised. Non-supervised

methods are those based solely on continuous at-

tribute value in order to carry out discretization,

whereas supervised ones use class value to dis-

cretize continuous attributes, so that they are more

or less uniform with regard to class value.

• Static or dynamic. In both types of methods it

is necessary to deﬁne a maximum number of in-

tervals and they differ in that static methods seek

to divide each attribute in partitions sequentially,

whereas dynamic ones discretize domains by di-

viding all the attributes into intervals simultane-

ously.

• Local or Global. Local methods of discretization

are those which use algorithms such as C4.5 or its

successor C5.0, (Quilan, 1993), and they are only

applied to speciﬁc regions in the database. On the

other hand, global methods are based on the whole

database to carry out discretization.

• Top-down or Bottom-up. Top-down methods

begin with an empty list of split points and add

them as the discretization process ﬁnds intervals.

On the other hand, bottom-up methods begin with

a list full of split points and eliminate points dur-

ing the discretization process.

• Direct or Incremental. Direct methods divide

the dataset directly into k intervals. Thereforethey

need an external input determined by the user to

indicate the number of intervals. Incrememental

methods begin with a simple discretization and

undergo an improvement process. For this rea-

son they need a criterion to indicate when to stop

discretizing.

In addition to the taxonomy exposed, from an-

other viewpoint we consider discretization methods

can also be classiﬁed according to the type of parti-

tions constructed, crisp or fuzzy partitions.

Thus, in the literature we ﬁnd some algorithms

that generate crisp partitions. Among these, in (Holte,

1993) describes a method that performs crisp intervals

taken as a measure the amplitude or frequency, which

need to ﬁx a k number of intervals. Also, (Holte,

1993) describes other method, called R1, which needs

to have a ﬁxed number of k intervals, but in this case,

the measure which used is the class label. Another

method that constructs crisp partitions, D2, is de-

scribed in (Catlett, 1991), where the measure used is

entropy.

On the other hand, we ﬁnd methods which dis-

cretize continuous values in fuzzy partitions, in this

case, these methods use decision trees, clustering al-

gorithms, genetic algorithms, etc. So, in (Kbir et al.,

2000) a hierarchical fuzzy partition based on 2

|A|

-tree

decomposition is carried out, where |A| is the num-

ber of attributes in the system. This decomposition

is controlled by the degree of certainty of the rules

generated for each fuzzy subspace and the deeper hi-

erarchical level allowed. The fuzzy partitions formed

for each domain are symmetric and triangular. Fur-

thermore, one of the most widely used algorithms for

fuzzy clustering is fuzzy c-means (FCM) (Bezdek,

1981). The algorithm assigns a set of examples, char-

acterized by their respective attributes, to a set number

of classes or clusters. Some methods developed for

fuzzy partitioning start from the FCM algorithm and

add some extension or heuristic to carry out an opti-

mization in the partitions. We can ﬁnd some examples

in (Li, 2009), (Li et al., 2009). Also, a method that

constructs fuzzy partition using a genetic algorithm

is proposed in (Piero et al., 2003), where fuzzy par-

titions are obtained through beta and triangular func-

tions. The construction process of fuzzy partitions is

divided into two stages. In the ﬁrst stage, fuzzy par-

titions with beta (Cox et al., 1998) or triangular func-

tions are constructed; and in the second stage these

partitions are adjusted with a genetic algorithm.

ICFC 2010 - International Conference on Fuzzy Computation

3 OFP CLASS: AN ALGORITHM

TO GENERATE OPTIMIZED

FUZZY PARTITIONS TO

CLASSIFICATION

In this section, the OFP CLASS Algorithm we pro-

pose for discretizing continuous attributes by means

of fuzzy partitions is presented and it is may be cat-

alogued as supervised and local. The OFP CLASS

Algorithm is made up of two stage. In the ﬁrst stage,

crisp intervals are deﬁned for each attribute. In the

second stage, these intervals obtained are used to form

an optimal fuzzy partition for classiﬁcation using a

genetic algorithm, but not all the crisp intervals ob-

tained are used, because the genetic algorithm is who

determines which intervals are the best. The partition

obtained for each attribute guarantees the:

• Completeness (no point in the domain is outside

the fuzzy partition), and

• Strong fuzzy partition (it veriﬁes that ∀x ∈ Ω

∑

f=1

(x) = 1, where B

, .., B

are the F

fuzzy

sets for the partition corresponding to the i contin-

uous attribute with Ω

domain).

The domain of each i continuous attribute is parti-

tioned in trapezoidal fuzzy sets, B

, B

.., B

, so that:

(x) =







1 b

≤ x ≤ b

−x)

−b

)

≤ x ≤ b

0 b

≤ x

;

(x) =











0 x ≤ b

(x−b

)

−b

)

≤ x ≤ b

1 b

≤ x ≤ b

−x)

−b

)

≤ x ≤ b

0 b

≤ x

;

··· ;

(x) =











0 x ≤ b

−1)3

(x−b

−1)3

)

−1)4

−b

−1)3

)

−1)3

≤ x ≤ b

−1)4

1 b

≤ x

Before going into a detailed description of

OFP CLASS Algorithm, we are going to introduce

the nomenclature we are going to use throughout the

section and then we will present the fuzzy decision

tree to be used in the evaluation of the fuzzy parti-

tions generated and which, with some modiﬁcation,

is used in the ﬁrst stage of OFP CLASS Algorithm.

3.1 Nomenclature and Basic

Expressions

• N: Node which is being explored at anygiven mo-

ment.

• C: Set of classes or possible values of the decision

attribute. |C| denotes the C set cardinal.

• E: Set of examples from the dataset.|E| denotes

the number of examples from the dataset.

• e

: j-th example from the dataset.

• A: Set of attributes which describe an example

from the dataset. |A| denotes the number of at-

tributes that describe an example.

• G

: information gain when node N is divided by

attribute i.

= I

− I

(1)

where:

– I

: Standard information associated with node

N. This information is calculated as follows:

1. For each class k = 1, ..., |C|, the value P

which is the number of examples in node N

belonging to class k is calculated:

|E|

∑

j=1

) · µ

) (2)

where:

· χ

) the degree of belonging of example

to node N.

· µ

) is the degree of belonging of example

to class k.

2. P

, which is the total number of examples in

node N, is calculated.

|C|

∑

k=1

3. Standard information is calculated as:

= −

|C|

∑

k=1

· log

– I

is the product of three factors and repre-

sents standard information obtained by divid-

ing node N using attribute i adjusted to the ex-

istence of missing values in this attribute.

= I

· I

where:

OFP_CLASS: AN ALGORITHM TO GENERATE OPTIMIZED FUZZY PARTITIONS TO CLASSIFICATION

∗ I

= 1 -

, where P

is the weight of

the examples in node N with missing value in

attribute i.

∗ I

∑

h=1

, H

being the number of descen-

dants associated with node N when we divide

this node by attribute i and P

the weight of

the examples associated with each one of the

descendants.

∗ I

∑

h=1

·I

, I

being the standard in-

formation of each descendant h of node N.

3.2 A Fuzzy Decision Tree

In this section, we describe the fuzzy decision tree

that we will use as a classiﬁer to evaluate fuzzy par-

titions generated and whose basic algorithm will be

modiﬁed for the ﬁrst stage of the OFP CLASS Algo-

rithm, as we will see later.

The set of examples E out of which the tree is

constructed is made up of examples described by at-

tributes which may be nominal, discrete and continu-

ous, and where there will be at least one nominal or

discrete attribute which will act as a class attribute.

The algorithm by means of which we construct the

fuzzy decision tree is based on the ID3 algorithm,

where all the continuous attributes have been dis-

cretized by means of a series of fuzzy sets.

An initial value equal to 1 (χ

root

) = 1) is as-

signed to each example e

used in the tree learning,

indicating that initially the example is only in the root

node of the tree. This value will continue to be 1 as

long as the example e

does not belong to more than

one node during the tree construction process. In a

classical tree, an example can only belong to one node

at each moment, so its initial value (if it exists) is not

modiﬁed throughout the construction process. In the

case of a fuzzy tree, this value is modiﬁed in two sit-

uations:

• When the example e

has a missing value in an

attribute i which is used as a test in a node N.

In this case, the example descends to each child

node N

, h = 1, ...,H

with a modiﬁed value as

) = χ

) ·

• According to e

’s degree of belonging to differ-

ent fuzzy partition sets when the test of a node

N is based on attribute i which is continuous. In

this case, the example descends to those child

nodes to which the example belongs with a de-

gree greater than 0 (µ

) > 0; f = 1, ..., F

Because of the characteristics of the partitions

we use, the example may descend to two child

nodes at most. In this case, χ

) = χ

) ·

); ∀ f| µ

) > 0; h = f.

We can say that the χ

) value indicates the de-

gree with which the example fulﬁlls the conditions

that lead to node N on the tree.

The stopping condition is deﬁned by the ﬁrst con-

dition reached out of the following: (a) pure node, (b)

there aren’t any more attributes to select, (c) reaching

the minimum number of examples allowed in a node.

Having constructed the fuzzy tree, we use it to infer

an unknown class of a new example:

Given the example e to be classiﬁed with the ini-

tial value χ

root

(e) = 1, go through the tree from the

root node. After obtain the leaf set reached by e. For

each leaf reached by e, calculate the support for each

class. The support for a class on a given leaf N is ob-

tained according to the expression (2). Finally, obtain

the tree’s decision, c, from the information provided

by the leaf set reached and the value χ with which

example e activates each one of the leaves reached.

In the following sections we describe the stages

which comprise the Algorithm of discretization

OFP CLASS.

3.3 First Stage: Looking for Crisp

Intervals

In this stage, a fuzzy decision tree is constructed

whose basic process is that described in subsection

3.2, except that now a procedure based on priority

tails is added and there are continuous attributes that

have not been discretized. The discretization of these

attributes is precisely the aim of this ﬁrst stage.

To deal with non-discretized continuous at-

tributes, the algorithm follows the basic process in

C4.5. The thresholds selected in each node of the tree

for these attributes will be the split points that delimit

the intervals. Thus, the algorithm that constitutes this

ﬁrst stage is based on a fuzzy decision tree that allows

nominal attributes, continuous attributes discretized

by means of a fuzzy partition, non-discretized con-

tinuous attributes, and furthermore it allows the exis-

tence of missing values in all of them. Algorithm 1

describes the whole process.

3.4 Second Stage: Constructing and

Optimizing Fuzzy Partitions

Genetic algorithms are very powerful and very robust,

as in most cases they can successfully deal with an in-

ﬁnity of problems from very diverse areas. These al-

gorithms are normally used in problems without spe-

cialized techniques or even in those problems where

ICFC 2010 - International Conference on Fuzzy Computation

Algorithm 1: Search of crisp intervals

SearchCrispIntervals(in : E, Fuzzy Partition;

out : Split points)

begin

1. Start at the root node, which is placed in the ini-

tially empty priority tail. Initially, the root node

is found in the set of examples E with an initial

weight of 1. The tail is a priority tail, ordered

from higher to lower according to the total weight

of the examples of nodes that form the tail. Thus

the domain is guaranteed to partition according to

the most relevant attributes.

2. Extract the ﬁrst node from the priority tail.

3. Select the best attribute to divide this node using

information gain expressed in (1) as the criterion.

We can ﬁnd two cases. The ﬁrst case is where

the attribute with the highest information gain is

already discretized, either because it is nominal,

or else because it had already been discretized

earlier by the Fuzzy Partition. The second case

arises when the attribute is continuous and non-

discretized, in which case it is necessary to obtain

the corresponding split points.

(a) If the attribute is already discretized, node N is

expanded into as many children as possible val-

ues the selected attribute may have. In this case,

the tree’s behaviour is similar to that described

in the Subsection 3.2.

(b) If the continuous attribute is not previously dis-

cretized, its possible descendants are obtained.

To do this, as in C4.5, the examples are ordered

according to the value of the attribute in ques-

tion and the intermediate value between the

value of the attribute for example e

and for ex-

ample e

j+1

is obtained. The value obtained will

be that which provides two descendants for the

node and to which the criterion of information

gain is applied. This is repeated for each pair

of consecutive values of the attribute, search-

ing for the value that yields the greatest infor-

mation gain. The value that yields the greatest

information gain will be the one used to divide

the node and will be considered as a split point

for the discretization of this attribute.

4. Having selected the attribute to expand node N,

all the descendants generated are introduced in the

tail according to the established order.

5. Go back to step two to continue constructing the

tree until there are not nodes in the priority tail or

until another stopping condition occurs, such as

reaching nodes with a minimum number of exam-

ples allowed by the algorithm.

end

a technique does exist, but is combined with a genetic

algorithm to obtain hybrid algorithms that improvere-

sults (Cox, 2005).

In this second stage of the OFP CLASS Algo-

rithm, we are going to use a genetic algorithm to

obtain the fuzzy sets that make up the partitioning

of continuous attributes of the problem. Given the

− 1 split points of attribute i obtained in the prior

stage, we can deﬁne a maximum of F

fuzzy sets

that perform up the partition of i. The deﬁnition

of the different elements that make up this genetic

algorithm is as follows:

Encoding. An individual will consist of two array

and v

. The array v

has a real coding and its

size will be the sum of the number of split points that

the fuzzy tree will have provided for each attribute in

the ﬁrst stage. Each gene in array v

represents the

quantity to be added to and subtracted from each at-

tribute’s split point to form the partition fuzzy. On

the other hand, the array v

has a binary coding and

its size is the same that the array v

. Each gene in

array v

indicates whether the corresponding gene or

split point of v

is active or not. The array v

will

change the domain of each gene in array v

. The do-

main of each gene in array v

is an interval deﬁned

by [0, min(

−p

r−1

r+1

−p

)] where p

is the r-th split

point of attribute i represented by this gene except in

the ﬁrst (p

) and last (p

) split point of each attribute

whose domains are, respectively: [0, min(p

−p

]

and [0, min(

−p

u−1

, 1− p

When F

= 2, the domain of the single split point

is deﬁned by [0, min(p

, 1− p

]. The population size

will be 100 individuals.

Initialization. First the array v

in each individual

is randomly initialized, provided that the genes of

the array are not all zero value, since all the split

points would be deactivated and attributes would

not be discretized. Once initialized the array v

the domain of each gene in array v

is calculated,

considering what points are active and which not.

After calculating the domain of each gene of the

array v

, each gene is randomly initialized generating

a value within its domain.

Fitness Function. The ﬁtness function of each in-

dividual is deﬁned according to the information gain

deﬁned in (Au et al., 2006). Algorithm 2 implements

the ﬁtness function, where:

• µ

is the belonging function corresponding to

fuzzy set f of attribute i.

• E

is the subset of examples of E belonging to

class k.

OFP_CLASS: AN ALGORITHM TO GENERATE OPTIMIZED FUZZY PARTITIONS TO CLASSIFICATION

This ﬁtness function, based on the information

gain, indicates how dependent the attributes are

with regard to class, i.e., how discriminatory each

attribute’s partitions are. If the ﬁtness we obtain

for each individual is close to zero, it indicates

that the attributes are totally independent of the

classes, which means that the fuzzy sets obtained

do not discriminate classes. On the other hand, as

the ﬁtness value moves further away from zero,

it indicates that the partitions obtained are more

than acceptable and may discriminate classes

with good accuracy.

Algorithm 2: Fitness Function.

Fitness(in : E, out : ValueFitness)

begin

1. For each attribute i = 1, ...,|A|:

1.1 For each set f = 1, ..., F

of attribute i

For each class k = 1, ..., |C| calculate the probabil-

ity

ifk

eεE

(e)

eεE

(e)

1.2 For each class k = 1, ..., |C| calculate the probabil-

ity

= Σ

f=1

ifk

1.3 For each f = 1, ..., F

calculate the probability

= Σ

|C|

k=1

ifk

1.4 For each f = 1, ...,F

calculate the information

gain of attribute i and set f

= Σ

|C|

k=1

ifk

· log

ifk

· P

1.5 For each f = 1, ..., F

calculate the entropy

= −Σ

|C|

k=1

ifk

· log

ifk

1.6 Calculate the I and H total of attribute i

∑

f=1

and H

∑

f=1

2. Calculate the ﬁtness as :

ValueFitness =

∑

|A|

i=1

∑

|A|

i=1

end

Selection. Individual selection is by means of

tournament, taking subsets with size 2.

Crossing. The crossing operator is applied with a

probability of 0.3, crossing two individuals through a

single point, which may be any one of the positions

on the vector. Not all crossings are valid, since one of

the restrictions imposed on an individual is that the

array v

should not has all its genes to zero. When

crossing two individuals and this situation occurs,

the crossing is invalid, and individuals remain in

the population without interbreeding. If instead the

crossing is valid, the domain for each gene of array

is updated in individuals generated.

Mutation. Mutation is carried out according to a cer-

tain probability at interval [0.01, 0.1], changing the

value of one gene to any other in the possible do-

main. First, the gene of the array v

is mutated and

then checked that there are still genes with value 1 in

. In this case, the gene in array v

is mutated and,

in addition, the domains of this one and its adjacent

genes are updated in the vector v

. Finally, the mu-

tation in this same gene is carried out in the vector

If when a gene is mutated in v

all genes are zero,

then the mutation process is not produced.

Stopping. The stopping condition is determined

by the number of generations situated at interval

[150, 200].

The genetic algorithm should ﬁnd the best possi-

ble solution in order to achieve a more efﬁcient classi-

ﬁcation. By way of an example, let us suppose that we

have a dataset that only consists of three attributes, for

which the fuzzy decision tree has indicated 2, 3 and

1 split points for each one respectively and which we

show in Table 1.

Table 1: Stage 1 of the OFP CLASS algorithm.

Attribute 1 0.3 0.5

Attribute 2 0.1 0.4 0.8

Attribute 3 0.7

Based on the split points, in the second stage, the

genetic algorithm will determine which of them will

form the fuzzy partition of each attribute. Following

the example, the domains of two possible individuals

are showed in the Figure 1, where for each individ-

ual, the v

array is showed and the array v

shows the

domain of the genes in which the corresponding gene

in the array v

is 1. As we have already commented

previously, the vector v

is made up of a set of values

that represent for each attribute and split point what

the distance to be added and subtracted to deﬁne the

straight lines that make up the fuzzy sets. Also, the

domain of each gene depends on previous and later

active split points.

ICFC 2010 - International Conference on Fuzzy Computation

a) Individual 1.

b) Individual 2.

Figure 1: Domains for each gene.

Following with the example given, Figure 2 shows

a possible valid crossing at point A. If the crossing

is realized at point B instead of A, it would not be

valid because the array v

would stay with all zero

values and all the split points would be deactivated

and attributes would not be discretized.

Figure 2: Crossing example allowed.

The mutation can generate invalid individuals too.

The Figure 3 shows an example of mutation invalid,

because the individual 2, after the crossing, only has

one active gene and whether this gene is turned off

all genes in array v

are zero. If the mutated gene

had been any other, the mutation would be valid. An

important aspect is that if an inactive gene is mutated,

then there are to calculate the domains of the mutated

gene and adjacent.

Figure 3: Mutation example not allowed.

If we assume, in the example, that individuals are

not changed after the crossing shown in Figure 2 and

the algorithm reaches a stopping condition, the algo-

rithm only has discretized the second attribute in the

two individuals. Figure 4 shows the discretization that

each individual makes the second attribute.

a) Discretization of second attribute. Individual 1.

b) Discretization of second attribute. Individual 2.

Figure 4: Fuzzy partition of the example.

This example shows that although in the ﬁrst stage

many split points are obtained, the algorithm may

only use a subset of these to discretize.

4 EXPERIMENTS

In this section we show several computational re-

sults which measure the accuracy of the OFP CLASS

Algorithm proposed. In order to evaluate the

OFP CLASS Algorithm a comparison with the results

of (Li, 2009) and (Li et al., 2009) is carried out, in

which fuzzy partitions are constructed by means of a

combination of fuzzy clustering algorithms, using the

majority vote rule or the weighted majority vote rule,

respectively. To obtain these results we haveused sev-

eral datasets from the UCI repository (Asuncion and

Newman, 2007), whose characteristics are shown in

Table 2. It shows the number of examples (|E|), the

number of attributes (|A|), the number of continuous

attributes (Cont.) and the number of classes for each

dataset (CL). “Abbr” indicates the abbreviation of the

dataset used in the experiments.

In order to evaluate the partitions generated by

the OFP CLASS Algorithm, we classify the datasets

using the fuzzy decision tree presented in Subsec-

tion 3.2. We compare the results obtained in (Li,

OFP_CLASS: AN ALGORITHM TO GENERATE OPTIMIZED FUZZY PARTITIONS TO CLASSIFICATION

Table 2: Datasets description.

Dataset Abbr |E| |A| Cont. CL

Australian Cre. AUS 690 14 6 2

German Cre. GER 1000 24 24 2

Iris Plants IRP 150 4 4 3

Pima Ind. Dia. PIM 768 8 8 2

SPECTF heart SPE 267 44 44 2

Thyroid Dis. THY 215 5 5 3

Zoo ZOO 101 16 1 7

Table 3: Testing accuracies.

Dataset

Best result of

OFP CLASS

(Li, 2009) and (Li et al., 2009)

AUS 60.29% 85.50%±0.00

GER 66.80% 73.13%±0.21

IRP 92.00% 97.33%±0.00

PIM 65.10% 77.07%±0.12

SPE 64.79% 84.09%±0.18

THY 79.07% 95.83%±0.00

ZOO 68.32% 94.06%±0.00

2009) and (Li et al., 2009) with those obtained by

OFP CLASS Algorithm. The comparison is carried

out on the same datasets used in those two references.

For this experiment, a 3×5-fold cross validation was

carried out. In Table 3, the best average success per-

centages obtained in (Li, 2009) and (Li et al., 2009)

and those obtained with OFP CLASS Algorithm are

shown. Also, in the case of OFP CLASS Algorithm

the standard deviation for each dataset is shown.

After the experimental results have been shown,

we perform an analysis of them using statistical tech-

niques. Following the methodology of (Garca et

al., 2009) we use nonparametric tests. We use the

Wilcoxon signed-rank test to compare two methods.

This test is a non-parametric statistical procedure for

performing pairwise comparison between two meth-

ods. Under the null-hypothesis, it states that the meth-

ods are equivalent, so a rejection of this hypothe-

sis implies the existence of differences in the perfor-

mance of all the methods studied. In order to carry

out the statistical analysis we have used R packet.

Results obtained on comparing the OFP CLASS

Algorithm with the best result of (Li, 2009) and (Li

et al., 2009) for each dataset show that, with a 99.9%

conﬁdence level, there are signiﬁcant differences be-

tween the methods, with the OFP CLASS Algorithm

being the best.

5 CONCLUSIONS

In this study we have presented an algorithm for fuzzy

discretization of continuous attributes, which we have

called OFP CLASS Algorithm. The aim of this algo-

rithm is to ﬁnd a partition that allows good results to

be obtained when using it afterwards with fuzzy clas-

siﬁcation techniques. The algorithm makes use of two

techniques: a Fuzzy Decision Tree and a Genetic Al-

gorithm. Thus the proposed algorithm consists of two

stages, using in the ﬁrst of them the fuzzy decision

tree to ﬁnd divisions in the continuous attribute do-

main, and in the second, the genetic algorithm to ﬁnd,

on the basis of prior divisions, a fuzzy partition.

We have presented experimental results obtained

by applying the OFP CLASS Algorithm to vari-

ous datasets. On comparing the results of the

OFP CLASS Algorithm with those obtained by two

methods in the literature we conclude that the

OFP CLASS Algorithm is an effective algorithm and

it obtains the best results. Moreover, all these conclu-

sions have been validated by applying statistical tech-

niques to analyze the behaviour of the algorithm.

ACKNOWLEDGEMENTS

Supported by the project TIN2008-06872-C04-03 of

the MICINN of Spain and European Fund for Re-

gional Development. Thanks also to the Funding Pro-

gram for Research Groups of Excellence with code

04552/GERM/06 granted by the “Fundaci´on S´eneca”.

REFERENCES

Asuncion, A. and Newman, D. (2007). Uci ma-

chine learning repository. http://www.ics.uci.edu/

mlearn/MLRepository.html.

Au, W.-H., Chan, K. C. C., and Wong, A. K. C. (2006).

A fuzzy approach to partitioning continuous attributes

for classiﬁcation. IEEE Trans. on Knowl. and Data

Eng., 18(5):715–719.

Bezdek, J. C. (1981). Pattern Recognition with Fuzzy Ob-

jective Function Algorithms. Kluwer Academic Pub-

lishers, Norwell, MA, USA.

Catlett, J. (1991). On changing continuous attributes into

ordered discrete attributes. In EWSL-91: Proceedings

of the European working session on learning on Ma-

chine learning, pages 164–178, New York, NY, USA.

Springer-Verlag New York, Inc.

Cox, E. (2005). Fuzzy Modeling and Genetic Algorithms

for Data Mining and Exploration. Morgan Kaufmann

Publishers.

Cox, E., Taber, R., and OHagan, M. (1998). The Fuzzy

Systems Handbook. AP Professional, 2 edition.

Garca, S., Fernndez, A., Luengo, J., and Herrera, F. (2009).

A study of statistical techniques and performance

ICFC 2010 - International Conference on Fuzzy Computation

measures for genetics-based machine learning: accu-

racy and interpretability. Soft Comput., 13(10):959–

977.

Holte, R. C. (1993). Very simple classiﬁcation rules per-

form well on most commonly used datasets. In Ma-

chine Learning, pages 63–91.

Kbir, M. A., Maalmi, K., Benslimane, R., and Benkirane, H.

(2000). Hierarchical fuzzy partition for pattern classi-

ﬁcation with fuzzy if-then rules. Pattern Recogn. Lett.,

21(6-7):503–509.

Li, C. (2009). A combination scheme for fuzzy partitions

based on fuzzy majority voting rule. In NSWCTC

’09: Proceedings of the 2009 International Confer-

ence on Networks Security, Wireless Communications

and Trusted Computing, pages 675–678, Washington,

DC, USA. IEEE Computer Society.

Li, C., Wang, Y., and Dai, H. (2009). A combination scheme

for fuzzy partitions based on fuzzy weighted majority

voting rule. Digital Image Processing, International

Conference on, 0:3–7.

Liu, H., Hussain, F., Tan, C. L., and Dash, M. (2002). Dis-

cretization: An enabling technique. Data Min. Knowl.

Discov., 6(4):393–423.

Piero, P., Arco, L., Garca, M., and Acevedo, L. (2003). Al-

goritmos genticos en la construccion de funciones de

pertenencia borrosas. Revista Iberoamericana de In-

teligencia Artiﬁcial, 18:25–35.

Quilan, J. (1993). C4.5: Programs for Machine Learning.

Morgan Kaufmann Publishers.

OFP_CLASS: AN ALGORITHM TO GENERATE OPTIMIZED FUZZY PARTITIONS TO CLASSIFICATION
