CLUSTERING DOCUMENTS WITH LARGE OVERLAP OF
TERMS INTO DIFFERENT CLUSTERS BASED ON
SIMILARITY ROUGH SET MODEL
Nguyen Chi Thanh, Koichi Yamada and Muneyuki Unehara
Department of Management and Information System Science, Nagaoka University of Technology
Nagaoka-shi, Niigata-ken 940-2188 Japan
Keywords: Document clustering, Document representation, Rough sets, Text mining.
Abstract: Similarity rough set model for document clustering (SRSM) uses a generalized rough set model based on
similarity relation and term co-occurrence to group documents in the collection into clusters. The model is
extended from tolerance rough set model (TRSM) (Ho and Funakoshi, 1997). The SRSM methods have
been evaluated and the results showed that it perform better than TRSM. However, in document collections
where there are words overlapped in different document classes, the effect of SRSM is rather small. In this
paper we propose a method to improve the performance of SRSM method in such document collections.
1 INTRODUCTION
Document clustering is a process of grouping similar
documents into clusters so that they would exhibit
high intracluster similarity and low intercluster
similarity. Document clustering has become an
important text mining technique to explore useful
information from text collections.
In recent years various document clustering
methods have been proposed, including hierarchical
clustering algorithms using result from a k-way
partitional clustering solution (Zhao and Karypis,
2005), spherical k-means (Dhillon and Modha,
bisecting k-means (Steinbach, Karypis and Kumar,
2000), frequent word meaning sequences based
method (Li, Chung and Holt, 2008), k-means with
Harmony Search optimization (Mahdavi and
Abolhassani, 2008).
TRSM, a document presentation model based on
vector space model, was proposed by Ho and
Funakoshi (1997). The model extended the vector
space mode by using rough set theory. TRSM has
been successfully applied to document clustering.
We proposed a new presentation model for
document clustering which uses similarity relation
instead of tolerance relation in TRSM. The new
model is SRSM for documents (Nguyen, Yamada
and Unehara, 2010). The experiment results show
that the SRSM method performed better than TRSM
and other methods in two experiment data sets.
However, with the second data set which has
documents in near fields, the effect of improvement
by SRSM is rather small. The reason is that the
terms used in different classes of document are
overlapped. The upper approximation of a document
incorporates terms used in other fields, and as the
results, it is natural that the upper approximation is
not effective. To improve the performance of SRSM
when documents have a large overlap of terms
among document vectors, we propose a two pass
approach method. The objective of the proposed
method is to remove terms overlapped in document
classes before applying the SRSM algorithm.
The paper is organized as follows. Section 2
describes the SRSM document clustering algorithm
and results of our experiments on document
collections. Section 3 presents an approach trying to
improve the SRSM method by removing overlapped
terms. Finally, Section 4 concludes with a summary
and discussion about future research.
2 SRSM DOCUMENT
CLUSTERING ALGORITHM
TRSM is a model extended from Pawlak’s rough set
model (Pawlak, 1982) by using tolerance relation
396
Chi Thanh N., Yamada K. and Unehara M..
CLUSTERING DOCUMENTS WITH LARGE OVERLAP OF TERMS INTO DIFFERENT CLUSTERS BASED ON SIMILARITY ROUGH SET MODEL .
DOI: 10.5220/0003068803960399
In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2010), pages 396-399
ISBN: 978-989-8425-28-7
Copyright
c
2010 SCITEPRESS (Science and Technology Publications, Lda.)
instead of equivalence relation. TRSM is used as a
basis to model documents and terms for information
retrieval, text mining, etc (Ho and Funakoshi, 1997).
It was then applied to document clustering to
improve the quality of similarity measure between
documents (Ho and Nguyen, 2002). It is also applied
in clustering of web search results (Meng, Chen and
Wang, 2009). However, tolerance relation does not
reflect exactly the relationship between meanings of
words when there are large differences between
frequencies of words.
To resolve the problem of TRSM, we use
similarity relation instead of tolerance relation to
define the model (Nguyen et al., 2010). We propose
a new function I
, which uses a relative value
of
word frequency instead of a constant threshold, to
define the similarity class of words. The new
function depends on a parameter
(0 <
< 1) as
I
(t
i
) = {t
j
| f
D
(t
i
, t
j
)
.f
D
(t
i
)} {t
i
}, (1)
where f
D
(t
i
, t
j
) is the number of documents in D in
which term t
i
and t
j
co-occur, f
D
(t
i
) is the number of
documents in D in which term t
i
occurs. I
(t
i
) is a set
of terms that co-occur with t
i
at a probability more
than or equal to
.
SRSM document clustering algorithm is
extended from spherical k-means algorithm (Dhillon
and Modha, 2001) using SRSM. In the algorithm,
we used a document vector with terms in the upper
approximation of terms in document instead of an
ordinary document vector.
We use tf×idf weighting scheme to calculate the
weights of terms in upper approximations of
document vectors. The term weighting method is
extended to define weights of terms in the upper
approximation. It ensures that each term in the upper
approximation, but not contained in the document,
has a weight smaller than the weight of any term in
the document. The weight a
ij
of term t
i
in the upper
approximation of document d
j
is defined as follows.
h
()
()
t
()
log if
log
min if ( ) \
1 log
0 if ( )
i
i
j
i
ij i j
Dt
Dt
ij
d hj i j j
Dt
ij
N
f t d
f
N
f
a
a t apr d d
N
f
t apr d














(1)
where
ij
f
is the frequency of term i in document j,
)(
i
tD
f
is the number of documents containing the
term i, N is number of documents and t
h
is the term
with the smallest weight in the document j. This
equation is derived from the TRSM algorithm (Ho
and Nguyen, 2002). Then normalization is applied to
the upper approximations of document vectors. The
cosine similarity measure is used to calculate the
similarity between two vectors.
The algorithm is described as follows (Nguyen
et al., 2010).
1. Preprocessing (word stemming, stopwords
removal).
2. Create document vectors.
2.a. Obtain sets of words appearing in
documents.
2.b. Create document vectors using tf×idf.
2.b. Generate similarity classes of words.
2.c. Create vectors of upper approximations of
documents and normalize the vectors.
3. Apply the clustering algorithm
The method was evaluated with two document
collections. The results showed that SRSM method
provide better results than TRSM and the clustering
quality with SRSM is less affected by the value of
parameter (
and
) than TRSM. With the second
document collection, the result with SRSM is
slightly better than the result when we used ordinary
document vector instead of upper approximation of
terms. The effect of improvement by SRSM is rather
small. The reason for the small effect of SRSM with
this data set is that the terms used in four classes are
overlapped, because the classes’ fields are rather
near fields. Therefore, the upper approximation of a
document X incorporates terms used in other classes,
and as a result the proposed approach is not so
effective.
Table 1: Evaluation of clustering results with SRSM for
the second data set (Nguyen et al., 2010).
SRSM
Mutual
information
F measure
0.30
0.312
0.825
0.35
0.321
0.853
0.40
0.328
0.859
0.45
0.337
0.877
0.50
0.345
0.892
0.55
0.352
0.900
0.60
0.352
0.905
0.65
0.353
0.907
0.70
0.353
0.908
0.75
0.351
0.907
0.80
0.352
0.908
CLUSTERING DOCUMENTS WITH LARGE OVERLAP OF TERMS INTO DIFFERENT CLUSTERS BASED ON
SIMILARITY ROUGH SET MODEL
397
3 EXPERIMENT OF
OVERLAPPED TERM
REMOVAL
As discussed in the previous section, there are cases
in real applications where documents that should be
classified into different clusters have a large overlap
of terms among document classes. The task of
classifying these documents into different clusters is
very challenging. It expands applicability of
documents clustering; i.e. classifying research
documents in near fields, classifying research papers
and instruction papers in the same field, etc.
To improve the performance of SRSM in these
cases, we try to remove terms overlapped in
different classes before apply the SRSM algorithm.
We proposed a two pass approach for overlapped
term removal. The method is described as follows.
(1) At the first pass, the current approach with
upper approximation is applied.
(2) We check each word how many clusters each
word is related to. If a word is included in multiple
word vectors each of which represents a cluster, we
remove the word from word vectors.
(3) Then, we apply the current clustering again
as the second pass.
A word vector representing a cluster (cluster
vector) in (2) is just a word vector that consists of all
words in the cluster.
The idea of the approach is to remove
overlapped words between clusters. The overlapped
words make the upper approximation not effective
because it could incorporate words used in other
classes. After the first pass, we can determine which
words occurred in multiple clusters and remove
them in the step (2).
To implement the idea, first we have to obtain
the word vectors of clusters, then in each document,
we remove the words appear in multiple word
vectors representing clusters.
In the experiment, we try the two pass approach,
with step (2) remove all words included in more than
one word vector of clusters, which means words
simultaneously appear in two clusters. We call this
method as two pass appoach for two clusters. First,
we build a word vector representing a cluster which
is just a word vector that consists of all words in the
cluster. Then we calculate a word vector consist of
words appear in two cluster word vector, for
example, words appear in cluster 1 word vector and
cluster 2 word vector. For each document word
vector, we remove words appear in the calculated
vectors. The total number of words to be removed
when
= 50 is 4322 and when
= 60 is 4298.
Table 2 shows the result of the experiment with
two pass approach for two clusters.
Table 2: Results with two pass approach for two clusters.
Mutual
information
F measure
0.35
0.196
0.853
0.40
0.196
0.715
0.45
0.193
0. 720
0.50
0.195
0.721
0.55
0.131
0.645
0.60
0.124
0.635
0.65
0.126
0.637
As we can compare between original method
(Table 1) and the two pass approach for two clusters
(Table 2), the result of the two pass approach is
worse. This is can be explained by the large number
of words removed. We remove so many words from
document so the document vectors can not represent
the content of the document.
After the two pass approach for two clusters, we
do the experiment, with two pass appoach for three
clusters, which in step (2) removes all words
simultaneously appear in three clusters. Similar to
the two pass approach for two clusters, we calculate
a word vector consisting of words appear in three
cluster word vectors. Then for each document word
vector, we remove words appear in the calculated
vectors.
Table 3 shows the result of the experiment with
two pass approach for three clusters. This result is
better than the result in Table 2 but still worse than
the result of the original method.
Table 3: Results with two pass approach for three clusters.
Entropy
Mutual
Information
F measure
0.35
0.523
0.275
0.830
0.40
0.511
0.279
0.839
0.45
0.504
0.282
0.841
0.50
0.485
0.288
0.854
0.55
0.455
0.299
0.855
0.60
0.434
0.307
0.862
0.65
0.443
0.304
0.855
Table 4: Results with two pass approach for four clusters.
Entropy
Mutual
information
F measure
0.35
0.406
0.317
0.873
0.40
0.400
0.319
0.873
0.45
0.371
0.330
0.874
0.50
0.369
0.330
0.891
0.55
0.330
0.344
0.906
0.60
0.336
0.342
0.901
0.65
0.334
0.343
0.903
KDIR 2010 - International Conference on Knowledge Discovery and Information Retrieval
398
Next, we do the experiment with two pass
appoach for four clusters, which in step (2) removes
all words simultaneously appear in four clusters.
Table 4 shows the result of the experiment with
two pass approach for four clusters. This result is
better than the result in Table 2 and Table 3 but still
worse than the result in Table 1.
The proposed method is not good as the original
SRSM method. With the two pass approach for two
clusters, there are many words appear in two clusters
so when we remove them, many document vectors
only have few words, the result becomes worse. In
the case of removing words appearing in three and
four clusters, the results are better but still worse
than the original approach. The reason can be the
words removed are not the “right” words, which are
the words we try to remove. We try to remove the
words overlapped in “actual class” of documents,
but here we removed words overlapped in the
algorithm’s clustering results. These words may not
the same because our results are not exactly similar
to the “actual class” of documents.
4 CONCLUSIONS
A Similarity Rough Set Model for document
clustering has been introduced and used in
representation of document in clustering process.
Experiment results (Nguyen et al., 2010) show that
the quality of the clustering with SRSM is better
than the one with TRSM. However, it has been
shown that the effectiveness of our approach is not
so large when terms used in different classes
overlap.
To improve the performance of SRSM clustering
when terms used in different classes are overlapped,
a two pass approach has been proposed. However, it
works not good as expected. The reason is that the
proposed method does not remove the overlapped
words in “actual class” of documents, it only
removes words overlapped in clusters generated
from the clustering method. In future work, we will
continue to improve the efficiency of the algorithm
by trying to remove the overlapped words using
different approaches. This is a challenging study and
it can be applied to real applications where
documents have a large overlap of terms among
classes such as research papers in near fields or
research papers and instruction papers in the same
field.
REFERENCES
Dhillon, I. S. and Modha, D. S. (2001). Concept
decompositions for large sparse text data using
clustering. Machine Learning, 42 (1-2), pp. 143-175.
Ho, T. B. and Funakoshi, K. (1997). Information retrieval
using rough sets. Journal of Japanese Society for
Aritificial Intelligence, 13 (3), pp. 424-433.
Ho, T. B. and Nguyen, N. B. (2002), Nonhierarchical
document clustering based on a tolerance rough set
model. International Journal of Intelligent Systems, 17
(2), pp. 199-212.
Li, Y., Chung, S. M. and Holt, J. D. (2008). Text
document clustering based on frequent word meaning
sequences. Data and Knowledge Engineering, 64 (1),
pp. 381-404.
Luce, R. D. (1956). Semiorders and a Theory of Utility
Discrimination. Econometrica, Vol. 24, No. 2, pp.
178-191.
Mahdavi, M. and Abolhassani, H. (2008). Harmony
K-means algorithm for document clustering. Data
Mining and Knowledge Discovery, pp. 1-22.
Meng, X.-J., Chen, Q.-C. and Wang, X.-L. (2009). A
tolerance rough set based semantic clustering method
for web search results. Information Technology
Journal, 8 (4), pp. 453-464.
Nguyen, C. T., Yamada, K. and Unehara, M. (2010), A
similarity rough set model for document
representation and document clustering. IEICE
Transactions on Information and Systems (submitted).
Pawlak, Z. (1982). Rough sets. Int. J. of Information and
Computer Sciences, 11 (5), pp. 341-356.
Salton, G. and McGill, M. J. (1983). Introduction to
modern information retrieval. MCGraw-Hill Book
Company.
Stefanowski, J. and Tsoukias, A. (2001). Incomplete
Information Tables and Rough Classification.
Computational Intelligence, 17(3), pp.545-566.
Steinbach, M., Karypis, G. and Kumar, V. (2000). A
comparison of document clustering techniques.
Proceedings of the KDD Workshop on Text Mining.
Strehl, A., Ghosh, J. and Mooney, R. (2000). Impact of
similarity measures on web-page clustering,
Proceedings of the 17th National Conference on
Artificial Intelligence: Workshop of Artificial
Intelligence for Web search (AAAI 2000), Austin, TX,
pp. 58–64.
Yao, Y. Y. Wong, S. K. M. and Lin, T. Y. (1997). A
review of rough set models. Rough Sets and Data
Mining: Analysis for Imprecise Data, pp. 47-73.
Zhao, Y. and Karypis, G. (2005). Hierarchical clustering
algorithms for document datasets. Data Mining and
Knowledge Discovery, 10 (2), pp. 141 - 168.
CLUSTERING DOCUMENTS WITH LARGE OVERLAP OF TERMS INTO DIFFERENT CLUSTERS BASED ON
SIMILARITY ROUGH SET MODEL
399
