CIS: CHANGE IDENTIFICATION SYSTEM

Parimala N. and Vinay Gautam

School of Computer & Systems Sciences, Jawaharlal Nehru University, New Delhi, India

Keywords: Change Identification, Data Warehouse, Multidimensional Schema, Goal-Information, Ontology.

Abstract: Change identification is one of the main challenges for Data Warehouse Schema evolution. Changes to the

schema are required, among other situations, when the data warehouse fails to provide information to the

decision maker. In this paper we address the issue of identification of changes when such a situation occurs.

Towards this, the decision maker is asked to specify the information he/she needs, in business terms, to

meet a goal. With the help of ontology and a set of rules we identify whether the information is present in

the warehouse or not. The absence of data could be because it is not directly stored or because it is actually

absent. In both these cases the changes needed to the data warehouse schema are suggested by the system,

called the Change Identification System (CIS).

1 INTRODUCTION

In this paper we are concerned with the

identification of potential changes to a data

warehouse system. Zohra Bellahsene (2005) has

addressed modification of the data warehouse

schema which is not necessarily dictated by the

modifications to the underlying data sources. The

fact that such a modification is required implies that

there is a gap between the information content of the

warehouse and the information that is needed by the

decision maker. This gap defines the change to be

incorporated in the warehouse schema. We are

concerned with identifying these gaps.

As an example, consider an Insurance Schema

represented as a star schema as given in Figure 1.

Let‟s say that the goal of the decision maker is to

“Increase the revenue”. In order to achieve this goal,

the decision maker may have to analyze “the

revenue within individual regions” and “the claim of

policies within individual cities”.

Figure 1: Multidimensional Schema for Insurance.

Consider the case where it is needed to get “the

revenue for each city”. If we look at the schema

there is clearly no dimensional attribute city and

revenue is defined as premium_dollar.

Two things can be observed. One, the warehouse is

not providing adequate information to the decision

maker. Second, the decision maker is expressing the

information using business terms which are not the

same as schema terms. In order to address the latter,

we maintain an ontology of business as well as

schema terms and a mapping between these. In order

to address the former, we identify the missing

information. Information could be missing because

it is altogether absent or that it is not directly

represented. In the above example, the attribute city

is not directly represented but is part of the attribute

address. Different cases arise when information is

not directly represented. These cases give rise to

different kinds of modifications. These have to be

identified. To accomplish this we have built the

Change Identification System (CIS) shown in Figure

1.1 Related Work

Conventional approaches for the management of

changes to a multidimensional schema and the

contents (which is the data warehouse) can be

broadly classified into two categories namely,

Schema evolution and Version extension. The

former is addressed by Body et al. (2003) and

347

N. P. and Gautam V..

CIS: CHANGE IDENTIFICATION SYSTEM.

DOI: 10.5220/0003069003470350

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development (KEOD-2010), pages 347-350

ISBN: 978-989-8425-29-4

 2010 SCITEPRESS (Science and Technology Publications, Lda.)

Bartosz Bebel et al. (2006) where the changes are

made to the multidimensional structure without

retaining the existing definition.

Figure 2: CIS Architecture.

In the version extension approach as given by

Shazad, M.K, et al. (2005) and Mathurine Body et

al. (2002) a new version is derived from the

previously existing one and all versions are

maintained. In all these techniques the changes in

underlying data sources have driven the

identification of data warehouse change. On the

other hand, we are looking at the definition of the

warehouse per se and analyzing its adequacies to

meet the needs.

Ontology has been widely addressed in literature.

Ontology specification is formally described by

W.L.Lacy (2005). Web Ontology Language (OWL

2008) which has been standardized by W3C has

been adopted by many. In particular, Ahlem nabli et

al. (2009) uses ontology to resolve semantic and

structural ambiguities across heterogeneous sources.

Guotong Xie (2008) has used the ontology to build

automatically a customized data mart. Ontology has

been used to update hierarchies by Fadila Bentayeb

et al. (2008). In our approach, the changes to be

made are determined by the system using the

ontology.

Goals are studied as an objective of the system.

Paolo Giorgini et al. (2008) suggest a data warehouse

schema based on TROPOS methodology and

Naveen Prakash & Anjana Gosain. (2008) study the

relationship between goal, decision and information.

Goals are used by the user to determine the required

information.

The layout of the paper is as follows. Section 2

deals with building the ontology. The Goal-

Information template and the rules are explained in

section 3. Section 4 is the concluding section.

2 BUILDING THE ONTOLOGY

As mentioned above we propose a generalized

structure of ontology for a data warehouse. The

ontology contains schema terms, domain terms

which are synonyms of schema terms, related terms,

terms which represent time and the relations

between these.

The data warehouse concepts which are Fact,

Dimension, Attribute, Level, and Hierarchy are

defined as classes in the Ontology. Three new

classes Time/DateExtension, Term and Synset are

introduced. Time/DateExtension class is defined

immaterial of whether a time or a date dimension is

defined in the multidimensional schema. This, we

believe will facilitate providing more meaningful

information to the user. Term Class contains related

terms to dimensional attribute. Synset class contains

the domain terms which have the same sense as the

terms in Fact, Dimension and Attribute class. All the

classes are derived from the root class Thing.

The relation between the classes in the ontology

is represented as OWL Property. Fact_Attribute and

Dim_Attribute are represented as object properties

which are relations between Fact & Attribute and

Dimension & Attribute respectively.

We introduce additional properties between classes.

 Fact_Synset: Fact_Synset is a relation between

the classes Synset and Fact..

 Dim_Synset: Dim_Synset is a relation (which

expresses synonyms) between the Classes

Synset and Dimension.

 Relation between the classes Sysnet and

Attributes..

 PartOf: PartOf is a relation between the

Attribute Class and Term Class.

 Derived_Attribute: Derived attributes are those

that can be derived from attributes defined in

multidimensional schema. Derived_Attribute is

introduced as functional property.

3 CHANGE IDENTIFICATION

As explained above, our system helps to identify the

changes needed in the schema. The first step is to

express the information needed by the decision

maker to satisfy a goal as described in section 3.1.

Next, the manner in which changes are identified is

explained in section 3.2.

KEOD 2010 - International Conference on Knowledge Engineering and Ontology Development

348

3.1 Goal-Information Analysis

The information that is required is referred to as the

Analysis Component. A goal can have more than

one analysis component associated with it. The

template consists of the Goal and the Analysis

Component (AC). The Analysis Component consists

of two parts which are „What is to be analyzed‟ and

„How is it to be analyzed‟‟. “What is to be

analyzed” describes the data to be analyzed. It refers

to the measures which represents the factual data.

„How is it to be analyzed‟‟ describes the business

perspective under which data analysis is to be

performed. “How or along which dimensional

attributes is it to be analyzed”. These two represent

the context of user information needs. For the sake

of brevity, „What is to be analyzed‟ will be referred

to as „What‟ and „How is it to be analyzed‟ will be

referred to as „How‟.

Consider an example with respect to Figure 1

where the goal is to increase the number of policy

holders. Here, Policy is to be analyzed and forms the

„What‟ component. The axis of analysis could be

age, quarter and address. These form the „How‟

component.

3.2 Identifying Changes

In this step, we search the ontology to know whether

the information is present or not. If the information

is not present then potential changes are suggested.

We have formulated rules to perform these actions.

We refer to the terms „What‟ and „How‟ of the

analysis component of section 3.1 as Item.

In the rules given below, IsEqual( ) is a Boolean

function which compares two terms and returns true

if they refer to the same term else it returns false.

The notation classname.Instancename refers to an

instance of a class. This could be a dimensional

attribute or a fact attribute. getName(Instance) is a

method which gives the name of the given

„Instance‟. If any rule fires, then the remaining rules

are skipped. If no rule fires then rule R0 given below

is executed.

R0: Message = Item + ‘is not

available’+ Change_Suggestion (add

(Item))

Rules :

R1: If IsEqual (What, Attribute

[Fact_Attribute].Instance)then Message

= What + ‘is available as

Fact_Attibute’.

R2: If IsEqual (How, Attribute

[Dim_Attribute].Instance)then Message =

How +’is available as Dimensional

Attribute’.

R3: If IsEqual

(What,Dimension.Instance) then Message

= What + ‘is available as Dimension. It

can’t be used as a measure of

analysis’.

R4: If IsEqual (What, Fact.Instance)

then Message = What + ‘is available as

Fact; Use its attributes for analysis’

R5: If IsEqual(How,Dimension.Instance)

then Message=How+‘is available as

Dimension; Use its attributes for

analysis’

R6: If IsEqual(How,Fact.Instance)then

Message=How+’is available as fact;

can’t be used as a dimension of

analysis’.

R7:If IsEqual(Item,Synset.Instance)then

Message= Item+‘is available as’+

getName

Synset.Instance[Relation].Class.Instanc

R8: If IsEqual (Item,

Derived_Attribute. Instance)then

Message = Item + ‘can be derived from

the attribute’+getName(

Derived.Instance.Attribute.Instance).

R9:If IsEqual (How, Term.Instance) then

Message = How + ‘is a part of

’+getName(

Term.Instance.PartOf.Attribute.Instance

)

R10:If IsEqual(How,Time/DateExtension.

Instance) then Message = How + ‘is not

available but it can be added as a

level of Time dimension’

It may be noted that „How‟ has two additional rules

which are not present for „What‟ rules. Time/Date is

typically a dimensional attribute and hence is not

considered while designing the rules for measures.

Similarly, we believe that a constituent part of a

measure is not analyzed but constituents of a

composite dimensional attribute may be used as an

axis of analysis. Therefore, there is no rule

corresponding to PartOf relationship for the item

appearing as „What‟.

4 CONCLUSIONS

In this paper we have proposed the Change

Identification System which helps in finding out

whether the information required by the decision

maker is available in the data warehouse or not. For

doing so, in the first stage we build an Ontology.

CIS: CHANGE IDENTIFICATION SYSTEM

349

In the next stage the decision maker is asked to

identify the information he needs from the data

warehouse. This is expressed using a goal

information template using business terms.

In our system, the rules process the information

in the template and identify whether the information

is directly present or not. When the data is not

directly available in the warehouse, two situations

are handled by the system. If the data exists and is

not directly derivable then this information is

provided. Secondly, if the required information is

altogether missing, then changes to the

multidimensional schema are suggested.

We have defined a hierarchy for the time

dimension by which it is possible to suggest addition

of levels in the Time dimension. We propose to

extend this to other Dimensions by defining

„belongs to‟ relationship in the Ontology. We

propose to add aggregate functions to the Ontology

so that when these are specified by the decision

maker, a better analysis of his requirements can be

made.

It may be argued that there is no real need to

build ontology but business metadata that explains

the business context or existing ontology like

WordNet can be used. However, ontology not only

contains business terms and their taxonomy but also

includes relationships between attributes, synonyms,

word variants etc. (Guotong Xie, 2008; Matthias

Kehlenbeck, 2009). In this sense, an ontology

consists of rich domain information. Even though

industry standard ontology exists for common data

domains, for the not so common, the ontology has to

be built anyway.

We are currently building a graphical tool using

which the ontology can be defined.

The Change Identification System is

implemented using Java, Jena and OWL-API.

REFERENCES

Lacy W. L.(2005), Representing Information Using the

Web Ontology Language. Trafford Publishing.

Zohra Bellahsene (2002), Schema evolution in data

warehouses. Knowledge and Information System

Journal, Springer-Verlag Newyork, Vol. 4 issue 3,

pages 283-304.

Ahlem nabli, Jamel Feki and Farez Gargouri (2009), An

ontology based method for normalization

terminology. LNCS, Springer, Vol. 4870/2009, pages

235-246.

OWL (2008) http://www.w3.org/TR/2008/WD-owl2-xml-

serialization-20080411/

Matthias Kehlenbeck and Michael H. Breitner (2009),

Ontology-Based Exchange and Immediate

Application of Business Calculation Definitions for

Online Analytical Processing. DaWaK , pages 298-

311

Naveen Prakash and Anjana Gosain (2008), An approach

to engineering requirements of data warehouse,

Requirement Engineering Journal, Springer, Vol. 13,

No. 1.

Bartosz Bebel, Zbyszko Królikowski, and Robert

Wrembel (2006), Managing Evolution of Data

Warehouse System by Mean of Nested Transaction,

Springer Berlin / Heidelberg, Vol. 4243.

Fadila Bentayeb, Cecile Favre and Omar Boussaid (2008),

A User-driven data warehouse Evolution Approach

for Concurrent Personalized Analysis Needs,

Published in Integrated Computer-Aided

Engineering, Vol. 15 No. 1 , pages 21-36.

Paolo Giorgini, Stefano Rizzi and Maddalena Garzetti

(2008), GRAnD: A `goal-oriented approach to

requirement analysis in data `warehouses, Decision

Support Systems, Vol. 45 , Issue 1,Pages 4-21.

Shazad, M. K., J. A. Nasir and M. A. Pasa: Creation and

evolution versions in data warehouse, Asian journal

of IT, 910-917, 2005, Grace Publication.

Body, M., Miquel, M., Bedard, Y. and Tchounikine, A.

(2003), Handling Evolutions in Multidimensional

Structures, Proceedings of 19th International

Conference on Data Engineering, pages 581- 591

Mathurine Body, Marryvonne Miquel, Yvan Bedard and

Anne Tchounikie (2002), A multidimensional and

multi-version structure for OLAP Application, 5th

ACM international workshop on Data Warehousing

and OLAP, Pages: 1–6.

Guotong Xie, Yang Yang, Shengping Liu, Zhaoming Qiu,

Yue Pan and Xiongzhi Zhou (2008), EIAW: Towards

a Business-Friendly data warehouse using Semantic

Web Technology, LNCS, Springer, Vol. 4825.

KEOD 2010 - International Conference on Knowledge Engineering and Ontology Development

350
