TRAIN TIMETABLE GENERATION USING GENETIC

ALGORITHMS

C. J. Hinde, M. S. Withall, I. W. Phillips

Department of Computer Science, Loughborough University, Loughborough, U.K.

T. W. Jackson

Department of Information Science, Loughborough University, Loughborough, U.K.

S. Brown, R. Watson

RWA Rail, RWA-Rail, Epinal Way, Loughborough, Leicestershire, U.K.

Keywords:

Railway timetabling, Evolutionary systems, Multiobjective optimisation.

Abstract:

The scheduling of railway trains has been a research problem for many years. Many of the choices required are

not known a priori and require exploration of the problem to determine them. A modular Genetic system was

designedmake the evaluation function and preparation of the timetable tractable. The Genetic system consists

of a Genome, split into Chromosomes so the extra choices that become known throughout the evolution can be

added to the Chromosomes. A weighted ﬁtness function and a multiobjective non-dominated ﬁtness function

were tried, and then partial objective ranking was added. The system has tackled a mixture of problems has

produced promising results.

1 INTRODUCTION

Producing railway timetables has long been a dif-

ﬁcult problem and along with many scheduling

and timetabling problems is NP Complete (Ullman,

1975). There are many aspects to the problem and

typically they have been solvedas optimised subprob-

lems. Actual rail timetables take of the order of 18

months and many railway planners.

Train timetabling, which determines leaving and

arrival times along with other factors, has some in-

teresting characteristics. The constraints may deter-

mine that some trains will leave a station at a ﬁxed

time. The duration of journeys between Tiplocs (tim-

ing point locations — places on the rail network such

as stations and junctions) will be speciﬁed by a doc-

ument known as the “Rules of the Plan”, (ROTP).

These are exactly what they state and determine many

aspects of the emerging plan. For example it will

take 11 minutes for a high speed train to move from

Loughborough to Leicester.

There are decisions to make about train move-

ments, such as which platform to arrive at where there

are many possible platforms. There are also decisions

that are not known at the start of the planning process

and arise as a result of exploring the space of possible

plans. An example of this is a train leaving a station at

a set time and catching up with an earlier slower train,

this is known as a “headway clash”. There is now a

choice whether to delay the start of the faster train so

it does not interfere with the slower train, or delay the

train en-route.

Requirements

Platform

Allocation

Stock

Timetable

Rail Plan

Figure 1: The basic timetabling system. This also shows

that the subproblems are connected and cannot be optimised

separately. Platform allocation cannot be performed until

the train arrival and departure times are known.

170

J. Hinde C., S. Withall M., W. Phillips I., W. Jackson T., Brown S. and Watson R..

TRAIN TIMETABLE GENERATION USING GENETIC ALGORITHMS.

DOI: 10.5220/0003074801700175

In Proceedings of the International Conference on Evolutionary Computation (ICEC-2010), pages 170-175

ISBN: 978-989-8425-31-7

 2010 SCITEPRESS (Science and Technology Publications, Lda.)

2 BASIC SYSTEM

The problem of railway plan generation includes sev-

eral subproblems. Typically these have been solved

in order with feedback taking place if a subsequent

subproblem cannot be solved. This is due to the size

of the problem and not to any intrinsic property of

it. Figure 1 illustrates this, the three subproblems de-

noted are not exhaustive.

2.1 Subproblems

There are several subsystems. In order to test the

interdependency mechanisms and to allow a single

Genome to control the details of any plan produced.

The three illustrated involve:

• Timetable delivers the times of arrival and de-

parture, which parts of the track are to be used

and which platforms each train on each journey

at each station shall use. The tracks and platforms

used are determined by the relevant Chromosome.

• Stock Allocation delivers the particular arrange-

ment of rolling stock that make up a particular

train.

• Platform subsystem checks that there are no plat-

form clashes and that each platform used is able to

service the trains that arrive to it and depart from

it. The platform subsystem takes some of its input

from the Timetable subsystem.

Each subproblem has its own requirements either

from the speciﬁed requirements of the plan or be-

cause of the output from another subproblem further

speciﬁes the problem. For example, it is not possi-

ble to evaluate whether a platform clash exists until

the arrival and departure times of the various trains

have been determined. All the journeys required are

known at the outset so it is possible to determine a

stock allocation before timetabling, however it is not

possible to determine a good stock allocation with-

out knowledge of the train sequences and times. The

modules are connected in 2 main ways, they depend

on one another for some of their parameters; typically

a timetable will be formed, followed by allocation of

Rolling Stock and then a Crew will be allocated to

the train. However, a change in the Timetable will af-

fect which Rolling Stock are available, and also which

Crews are available.

Early work on our timetabling problem tackled

platform allocation in a major station using real ar-

rival times and a speciﬁed platform resource (Clarke

et al., 2009). Glasgow Central has nearly 1000 trains

a day and the system resolved the allocation problem

in under 30 seconds on a fairly modest PC.

This work was encouragingand similar exploratory

work on timetabling after attending a course on rail

timetabling was also encouraging. This resulted in

modules that could address single problems such as

the timetabling and platform allocation separately but

not together. The attraction of being able to build the

plan segments using modules which could be sepa-

rately included, omitted, extended or modiﬁed was

powerful. At this stage it was decided to separate the

modules so that this was possible.

Having produced a timetabling module that did

not encompass any Artiﬁcial Intelligence but which

just loaded the trains into a schedule, plus a platform

allocation module that applied a Genetic Algorithm

to the problem, the next step was to develop an over-

all architecture which would support the whole prob-

lem. The idea is that the problem speciﬁc modules

would have little or no intelligence but would be pa-

rameterised by the requirements ﬁle and a parame-

ters ﬁle generated by the AI module. The require-

ments ﬁle would specify such things as “Train 1F01

leaves Shefﬁeld at 10.00”, which would be part of the

ﬁxed requirements. The parameters would specify

that “Train 1F01 leaves Shefﬁeld from platform 1”;

and would not be part of the ﬁxed requirements but

would be decided by the AI module.

At this point an optimisation framework exists,

based currently on a GA that mixes ﬁxed require-

ments with choices based on a Genome so the plan

generation software responsible for allocating times,

platforms and rolling stock would become deter-

mined. All that would then be required would be to

feedback a utility measure so the AI module can im-

prove its decisions, Figure 2.

There are several difﬁculties with this, while many

of the decisions about the timetable are ﬁxed and so

may not be changed by the AI system, there are deci-

sions that are known a priori such as which platform a

train is to arrive on. It is relatively straightforward to

determine which decisions are required at this level.

However, it is possible that a train may leave at a time

that results in it catching up an earlier slower train and

as such violates the restrictions that determine howfar

apart trains on the same line must be; this is known as

Headway. A problem arises where a train that can

leave at any time, tries to leave at a time that results in

a headway clash. There are two choices, either change

the time the following train leaves, or change the time

the followed train leaves. So decisions are required

from the AI system that are not known a priori. The

modules therefore have to feed back a list of options

for the AI module to resolve, see Figure 2.

A simple example of this feedback is shown in

Figure 3, which is the initial choices ﬁle, with Fig-

TRAIN TIMETABLE GENERATION USING GENETIC ALGORITHMS

171

New Choices

Platform

Allocation

Stock

Timetable

Rail Plan

Evaluation

AI Module

Requirements and Parameters

Feedback

Choices

Figure 2: The modules feed back new choices required to

resolve problems.

8 /* number of Genes */

10 /* number of choices for this Gene */

startingtime_p(‘4B01’,

540

545

625

track_p(‘2C03’,warob_jn,down,llanbart,

ufl

Figure 3: A fragment of the initial choices ﬁle containing

the patterns to be fed to the timetabler based on the values

of the Genes.

ure 4 shows a typical fragment of a parameter ﬁle

aimed at the timetabling module. The timetabling

module is written in prolog and the control pro-

grams including the Genetic system are written in C.

whereas Figure 5 shows a fragment of the choices ﬁle

after a few generations.

startingtime_p(‘4B01’,600).

dwelltime_p(‘1F01’,staffrayner,2).

platform_p(‘1F01’,down,dfl,watergalley,1).

track_p(‘2C02’,llanbart_n_jn,up,llanbart,sl).

Figure 4: A fragment of the initial parameters ﬁle contain-

ing the actual values fed to the timetabler based on the val-

ues of the Genes.

14 /* extended from 8 Genes to 14 */

delaystartingtime_p(‘2C01’,

3.5

Figure 5: A fragment of the ﬁnal choices ﬁle containing the

patterns to be fed to the timetabler based on the values of

the Genes. Notice that there are now 14 Genes available to

control the timetabler.

startingtime_p(‘4B01’,600).

delaystartingtime_p(‘2C01’,0).

Figure 6: A fragment of the ﬁnal parameter ﬁle with the

choices resolved.

Figure 4 shows the parameter ﬁle after 1 gener-

ation, it contains no added Genes but the values are

in fact reasonable. Each Genome will have its own

parameter ﬁle and will return a ﬁtness vector appro-

priately based on the performance of the plan.

After a few generations the system has found

several possible delays required due to headway

clashes. Some of these headway clashes are resolv-

able through other means. The potential delay to

‘1F03’ is due to the freight train ‘4B01’ leaving at an

inappropriate time and would not normally be con-

sidered by a human timetabler; however the system

has tried to resolve this difﬁculty and come to the

conclusion that it was not necessary as ‘4B01’ could

be scheduled to leave at a different time. Although

this aspect of the problem was known by the hu-

man timetablers it may occur in any other timetabling

problem and so should be considered.

Figure 6 is the ﬁnal parameter ﬁle with the choices

resolved. The main “troublemaker” is the time of de-

parture of ‘4B01’, which is a freight train. Unhelp-

ful departure times have led the timetabler to request

possible delays to several trains, however the only de-

lay actually necessary if the freight train leaves at 600

(10.00AM) is a delay to ‘2C02’.

3 IMPLEMENTATION DETAILS

The system has been implemented in a variety of lan-

guages; whichever language seemed appropriate and

which made implementation as fast and easy as pos-

sible consistent with obtaining a correct working sys-

tem. The main AI system, a Chromosome based Ge-

ICEC 2010 - International Conference on Evolutionary Computation

172

netic Algorithm, was written in ‘C’, because one of

the main tasks is to control the execution of the sub-

programs and other services. The Timetable and Plat-

form subsystems are written in prolog.

4 EVOLUTIONARY SYSTEMS

The evolutionary system is responsible for making the

choices in the timetabling system. A series of strate-

gies were used in the experiments delivering various

beneﬁts. The structure and characteristics of the prob-

lem have inﬂuenced the design of the evolutionary

system as the Chromosomes need to be extensible,

and to inﬂuence different parts of the problem while

being part of a whole solution.

4.1 Genome Structure

Each Genome has as many Chromosomes as there are

subproblems. Each Chromosome may be any length

depending on the subproblem addressed, as each sub-

problem may require more decisions to be made the

separation into Chromosomes allows this to happen

without destroying the interpretation of that Chromo-

some’s Genes. The choices ﬁle determines how each

Gene value is to be interpreted and determines the

structure of the eventual parameters ﬁle that controls

the connected subsystem.

4.1.1 Reproduction

Crossover is implemented using Uniform

Crossover (Syswerda, 1989) and parent selec-

tion is by tournament. As Chromosomes may be

different lengths, Uniform Crossover is performed up

to the length of the shortest Chromosome followed by

copying up to the length of the longest Chromosome.

The choices ﬁle for that Chromosome has a maxi-

mum limit and the remainder of the Chromosome

is selected randomly. An alternative strategy would

be to terminate the child Chromosome, however this

would result in no extensions to the Chromosome.

Parents who are ﬁtter than offspring are kept to their

length and survive to the next generation. From a

population of N parents delivering N offspring the

new offspring are evaluated and the ﬁttest of the 2N

contenders are kept for the next generation.

4.2 Execution

Each member of the Genome population has a sub-

directory containing a run time execution image of

the relevant subproblem. The main control program

writes the parameter ﬁle based on the choices ﬁle

and the value of the Gene to the relevant directory

and initiates the appropriate sub program. There is

an order in which these subprograms need to be exe-

cuted, for example the Platform subprogram does not

have enough information until the Timetable has been

formed. The control program is aware of this order-

ing and will not initiate a subprogram until all its pre-

decessors have completed and provided the requisite

additional parameters needed.

After all the subprograms have executed in the

correct sequence, passing parameters between them-

selves as appropriate, the new required choices are

collected together and added to the choices ﬁle. This

is not quite straightforward as the choices may have

already been added, and furthermore there may be

additional options to an earlier choice. For example,

there may be a headway clash between two trains, re-

quiring the faster train to be delayed by 3 minutes.

Once all decisions have been made this delay may

be unnecessary so two options, 0 and 3 minutes, are

given to the Genetic system. After the 3 minute delay

is imposed, the faster train may catch up the slower

further on; requiring a further delay, say 2 minutes.

So the options would now be 0, 3 and 5 minutes.

5 FITNESS ASSESSMENT

These experiments are based on a tutorial example,

used in the training of real train planners and designed

to illustrate all major aspects of railway planning. The

example problem has several passenger trains and ﬁ-

nally a freight train that can leave at any time but does

not stop until it reaches its destination. All that is

required is that one Gene has sufﬁcient options that

it can represent all the potential departure times of

the freight train. The major concern in this project

is scalability and so times are relevant. As the even-

tual users of the system will not be experts in tuning

evolutionary systems guaranteed convergence is also

important. The experiments were run on a Macin-

tosh MacPro dual 3.2GHz quad core machine running

OSX 10.6. The software was written in a mixture of C

and SWIPL Prolog. The software was also organised

to be executed concurrently, as described above. All

experiments were conducted with 7 different random

number seeds and the results shown are the medians

of those runs. The overall measures for the strategies

are averages of the medians. All experiments were

terminated after generation 1000, starting at genera-

tion 0, as having not converged, hence the values of

1001 generations on some entries.

The ﬁtness strategies tested were as follows:

TRAIN TIMETABLE GENERATION USING GENETIC ALGORITHMS

173

• A weighted sum of the ﬁtness values.

• A ﬁtness vector using non-dominated selection.

• A layered ranked ﬁtness vector using non-

dominated selection.

5.1 Weighted Sum

In order to establish a base line for the tests a simple

weighted sum of the ﬁtness values was used. As ex-

pected the system worked reasonably well, converg-

ing in a few seconds.

Table 1: The results of some experiments on population size

with a weighted sum ﬁtness vector.

Population Time Generations Fitness

Seconds Tests

5 77 489 2445

10 112 558 5580

20 38 135 2700

30 18 45 1350

40 12 23 920

50 13 21 1050

60 52 71 4260

70 15 17 1190

80 19 19 1520

90 16 15 1350

100 15 13 1300

110 24 19 2090

120 19 13 1560

Average 32.9 111 2101

Average > 40 21.6 23.5 1790

5.1.1 Problems and Analysis

The system as described executes reasonably quickly

but is directed towards a weighted sum of ﬁtness val-

ues that does not capture the requirements adequately.

The major problem is that with a weighted ﬁtness

function there is a point where not delaying a train

results in a headway clash; and if the sum of de-

lays is sufﬁcient to match the weighted headway clash

we exchange a late train for a severely damaged one.

Typically signalling would just delay the train to avoid

a crash, but it is unwise to plan for a headway clash.

5.2 Multi Objective Non-dominated

Fitness

Deb’s (Deb et al., 2002) Non-Dominated Genetic al-

gorithm potentially avoids the problem of weighting

the undesirability of a headway clash against delayed

trains. The ﬁtness values used in these experiments

were based on Train delays, Headway Clashes and

Platform Clashes. The selection was based on non-

dominated ﬁtness vectors, duplicate solutions and ﬁ-

nally, to resolve potential ambiguities, the number of

other individuals in the population that were domi-

nated by an individual. The ﬁttest individuals would

be non dominated, non duplicates that dominated

other individuals. One individual in a set of dupli-

cates was marked as a nonduplicate.

One beneﬁt of this is that a set of pareto optimal

solutions are generated, see (Deb et al., 2005).

Table 2: The results of some experiments on population size

with a multi-objective non-dominated ﬁtness vector.

Population Time Generations Fitness

Seconds Tests

5 160 1001 5005

10 206 1001 10010

20 5 18 360

30 8 21 630

40 486 1001 40040

50 9 15 750

... .. . .. . .. .

Average 76 244 5128

Average > 40 15 15 1328

5.2.1 Problems and Analysis

This technique worked as far as described above.

However, for a station with several platforms, each

having equal access to the network, while there may

be only one distinct solution to the platform alloca-

tion the numbering of the platforms does not affect

the solution so given N platforms there are N! equiv-

alent solutions. The ﬁrst way in which this manifests

itself is that one solution is found very quickly which

has no delays but several headway clashes, there are

many that are equivalent but not duplicates and this

quickly exhausts the population.

A solution that delays a train and eliminates the

headway clash would emerge as another pareto opti-

mal solution, however the headway clashes are not al-

ways eliminated in 1 generation and this solution gets

lost. Table 3 shows some of the times and generation

at which a solution appeared.

The situation that arises is that a headway clash is

detected requiring an X minutes delay to be applied.

If this is applied it can mean that although that head-

way clash is eliminated, the following train is still

travelling faster than the leading train and catches it

later on. Another headway clash is generated which

leaves the potentially optimal solution dominated by

the solutions with no delays. A much larger popu-

lation size in our test scenario allows the solution to

ICEC 2010 - International Conference on Evolutionary Computation

174

Table 3: Showing how the solution, once in the system, gets

lost in subsequent generations. The solution appears at the

nominated generation but then disappears.

Time Generations

Seconds

25 205

28 221

38 305

39 310

.. . ...

emerge, but smaller populations become locked into

a local minimum, see Table 2.

So the non-dominated multi-objective ﬁtness

function has some instabilities but once the popula-

tion size is sufﬁcient to avoid those it is much faster.

The instabilities in the system are undesirable and so

this solution does not meet the needs of the problem.

5.3 Ranked Multi Objective

Non-dominated Fitness

This solution was the fastest and gave the most sat-

isfactory set of solutions by ranking the ﬁtness func-

tions, also reﬂecting the actual requirements of the so-

lution. We care about delays, but not at the expense of

a headway clash. Clashes are very important and so

we search for solutions where the optimum is based

on the important characteristics, and within those the

less important characteristics. Our tests placed “head-

way clashes” and “platform clashes” at rank 1 and

“train delays” at rank 2.

Table 4: The results of some experiments on population size

using a ranked multi-objective non-dominated ﬁtness vec-

tor.

Population Time Generations Fitness

Seconds Tests

10 10 64 640

20 8 30 600

30 10 26 780

40 8 17 680

50 14 23 1150

.. . ... ... ...

Average 17.0 43.7 1341

Average > 40 19.1 19.6 1670

5.3.1 Problems and Analysis

This system is fast, the set of solutions are pareto op-

timal and the instabilities are eliminated, see Table 4.

6 CONCLUSIONS

The paper has described a Genetic System for

timetabling railway trains. The problem is such that

the Genome was split into Chromosomes to allow

more Genes to be added for each subproblem. The

system runs the subproblems in parallel on as many

processors as are available and runs quickly. The re-

sults are the optimum timetables for the problems and

constraints given and the requirements are designed to

cover most of the issues that occur in real timetabling.

The architecture is extensible and can support various

different problem breakdowns as appropriate. The

system has moved from a simple weighted sum of

the ﬁtness functions, through a non-dominated ﬁtness

vector, to a non-dominated system that uses ranks ﬁt-

ness functions. This extension to Deb’s system per-

forms better than others on the problem of railway

timetabling and reﬂects the objectives of the train

planning problem more accurately.

REFERENCES

Clarke, M., Hinde, C., Withall, M., Jackson, T., Phillips, I.,

Brown, S., and Watson, R. (2009). Allocating railway

platforms using a genetic algorithm. In Proceedings of

AI-2009, The Twenty-ninth SGAI International Con-

ference on Innovative Techniques and Applications of

Artiﬁcial Intelligence, pages 421–434. SGAI.

Deb, K., Mohan, M., and Mishra, S. (2005). Evaluating

the domination based multiobjective evolutionary al-

gorithm for a quick computation of pareto-optimal so-

lutions. IEEE Transactions on Evolutionary Compu-

tation, 13(4):501–525.

Deb, K., Pratap, A., Agarwal, S., and Meyarivan, T. (2002).

A fast and elitist multi-objective genetic algorithm:

NSGA-II. IEEE Transactions on Evolutionary Com-

putation, 6(2):181–197.

Syswerda, G. (1989). Uniform crossover in genetic algo-

rithms. In Schaffer, J., editor, Proceedings of Third In-

ternational Conference on Genetic Algorithms, pages

2–9, San Francisco, CA, USA. Morgan Kaufmann.

Ullman, J. (1975). NP-complete scheduling problems.

Journal of Computer and System Sciences, 10(3):384–

393.

TRAIN TIMETABLE GENERATION USING GENETIC ALGORITHMS

175
