NUMBER THEORY-BASED INDUCTION OF DETERMINISTIC
CONTEXT-FREE L-SYSTEM GRAMMAR
Ryohei Nakano
Department of Computer Science, Chubu University, 1200 Matsumoto-cho, Kasugai 487-8501, Japan
Naoya Yamada
Department of Computer Science and Engineering, Nagoya Institute of Technology
Gokiso-cho Showa-ku, Nagoya 466-8555, Japan
Keywords:
Grammatical induction, L-system, Number theory, Plant model.
Abstract:
This paper addresses grammatical induction of deterministic context-free L(D0L)-system. Considering the
parallel feature of L-system production and the deterministic context-free feature of D0L-system, we take a
number theory-based approach. Here D0L-system grammar is limited to one or two production rules. Basic
equations for the methods are derived and utilized to narrow down the parameter value ranges. Our experi-
ments using plants models showed the proposed methods induced the original production rules very efficiently.
1 INTRODUCTION
L-systems were originally developed by Linden-
mayer as a mathematical theory of plant development
(Prusinkiewicz and Lindenmayer, 1990). The central
concept of L-systems is rewriting. In general, rewrit-
ing is a mechanism for generating complex objects
from a simple initial object using production rules.
The most extensively studied rewriting systems
operate on character strings, and Chomsky’s work on
formal grammars is well known. Formal grammars
and L-systems are both string rewriting systems, but
the essential difference between them is that in formal
grammars productions are applied sequentially while
in L-systems productions are applied in parallel.
The reverse process of rewriting is grammatical
induction, which infers a set of production rules given
a set of strings. Grammatical induction of formal
grammars has been studied for decades and induction
of context-free grammars is still an open problem.
Induction of L-system grammars is also an open
problem little explored so far. L-systems can be clas-
sified using two axes: (1) deterministic or stochastic,
and (2) context-free or context-sensitive.
(McCormack, 1993) addressed computer graph-
ics modeling through evolution of context-free L-
systems. (Nevill-Manning, 1996) proposed a sim-
ple algorithm called Sequitur, which reveals structure
like context-free grammars from a wide range of se-
quences, however, with small success for grammati-
cal induction of deterministic context-free L-system
grammar. (Schlecht, et al., 2007) proposed statis-
tical structural inference for microscopic 3D images
through learning stochastic L-system model. (Dama-
sevicius, 2010) addressed structural analysis of DNA
sequences through evolution of stochastic context-
free L-system grammars.
This paper addresses grammatical induction of de-
terministic context-free L(D0L)-system. Considering
the parallel feature of L-system production and the
deterministic context-free feature of D0L-system, we
take a number theory-based approach. Here D0L-
system grammar is limited to one or two production
rules. Our experiments using plants models showed
the proposed methods induced the original production
rules quite efficiently.
2 D0L-SYSTEMS
D0L-systems. The simplest class of L-systems are
called D0L-system (deterministic context-free L-
system). D0L-system is defined as G = (V, C, ω, P),
where V and C denote sets of variables and constants,
194
Nakano R. and Yamada N..
NUMBER THEORY-BASED INDUCTION OF DETERMINISTIC CONTEXT-FREE L-SYSTEM GRAMMAR.
DOI: 10.5220/0003088101940199
In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2010), pages 194-199
ISBN: 978-989-8425-28-7
Copyright
c
 2010 SCITEPRESS (Science and Technology Publications, Lda.)

ω is an initial string called axiom, and P is a set
of production rules. A variable is a symbol that is
replaced in rewriting, and a constant is a symbol that
remains fixed in rewriting and is used to control turtle
graphics.
Notation. Shown below is the notation employed in
the following sections. Here we assume the following
form of production rules.
rule A : A →????????
rule B : B →??????
Y: given string.
n: the number of rewritings.
Z
(n)
: string obtained after n times rewritings.
α
A
, α
B
, α
K
: the numbers of variables A, B and con-
stant K occurring in the right side of rule A.
β
A
, β
B
, β
K
: the numbers of variables A, B and con-
stant K occurring in the right side of rule B.
y
A
, y
B
, y
K
: the numbers of variables A, B and con-
stant K occurring in Y.
z
(n)
A
, z
(n)
B
, z
(n)
K
: the numbers of variables A, B and
constant K occurring in Z
(n)
.
3 INDUCTION OF L-SYSTEM
GRAMMAR HAVING ONE
RULE
When D0L-system has only one production rule, the
number theory-based induction is easy. The method
proposed below is called LGIN1 (L-system Grammar
Induction based on Number theory for 1 rule). Here
the following situation is assumed.
n =?, axiom : A
rule A : A →????????
Given string Y, we are asked to estimate the number
of rewritings n and to induce the rule A. Through sim-
ple observation we have the following.
z
(n)
A
= α
n
A
(1)
z
(n)
K
=



1− α
n
A
1− α
A
α
K
if α
A
6= 1
n α
K
if α
A
= 1
(2)
Then we obtain the following, which we call basic
equations of LGIN1.
y
A
= α
n
A
(3)
y
K
=



1− α
n
A
1− α
A
α
K
if α
A
6= 1
n α
K
if α
A
= 1
(4)
From eq.(3) we get candidate pairs (α
A
, n) by
factorizing y
A
into prime factors. For each candidate
pair we get α
K
using eq.(4) for each constant K.
Since given string Y includes the right side of rule
A as a substring, we exhaustively extract from Y a
substring having α
A
A’s and α
K
K’s to form rule A
candidate. Then we rewrite the axiom n times using
the rule A candidate, and check whether the obtained
string is equal to Y. If the equality holds, the rule A
candidate is a solution.
Example.
n = 3, axiom : A
rule A : A → A[+]A
Consider string Y shown below.
A[+A]A[+A[+A]A]A[+A]A[+A[+A]A[+A[+A]
A]A[+A]A]A[+A]A[+A[+A]A]A[+A]A
By scanning Y we get the following values.
y
A
= 27, y
+
= 13, y
[
= 13, y
]
= 13 (5)
Since y
A
= 3
3
, we have the following two sets.
(i) n = 1, α
A
= 27, α
+
= 13, α
[
= 13, α
]
= 13
(ii) n = 3, α
A
= 3, α
+
= 1, α
[
= 1, α
]
= 1
The case n=1 is always a trivial one; thus, discard it.
By scanning Y, we have the following two substrings
having 3 A’s, one +, one [, and one ]:
A → A[+A]A
A → A]A[+A
By rewriting each of them n(= 3) times and checking
the equality, we select the original rule A.
4 INDUCTION OF L-SYSTEM
GRAMMAR HAVING TWO
RULES
When D0L-system has two production rules, the in-
duction gets immensely complicated. The method ex-
plained below is called LGIN2 (L-system Grammar
Induction based on Number theory for 2 rules). In
this case the following is assumed.
n =?, axiom : A
rule A : A →????????
rule B : B →?????
Given string Y, we are asked to estimate the number
of rewritings n and to induce the rules A and B.
LGIN2 goes in the following order.
