SEMANTIC IDENTIFICATION AND VISUALIZATION

OF SIGNIFICANT WORDS WITHIN DOCUMENTS

Approach to Visualize Relevant Words within Documents to a Search Query by

Word Similarity Computation

Karolis Kleiza, Patrick Klein and Klaus-Dieter Thoben

BIBA - Bremer Institut für Produktion und Logistik GmbH, Hochschulring 20, 28359 Bremen, Germany

Keywords: Similarity Computation, Word Similarity, Probabilistic Topic Model, Latent Dirichlet Allocation, Word

Highlighting.

Abstract: This paper gives at first an introduction to similarity computation and text summarization of documents by

usage of a probabilistic topic model, especially Latent Dirichlet Allocation (LDA). Afterwards it provides a

discussion about the need of a better understanding for the reason and transparency at all for the end-user

why documents with a computed similarity actually are similar to a given search query. The authors

propose for that an approach to identify and highlight words with respect to their semantic relevance

directly within documents and provide a theoretical background as well as an adequate visual assignment

for that approach.

1 INTRODUCTION

Knowledge and information retrieval tasks have

become a time-consuming challenge in nowadays

business processes, such as the development process

of a complex product or system. Even though

contemporary search engines provide a quick access

to company’s specific databases, several studies has

shown that employees spent up to 35 percent of their

hours of work for searching for relevant documents

(Bahrs et al., 2007). Especially an extraction of

relevant and needed information within respective

documents is not yet supported adequately. To

optimally exploit the large amounts of engineering

information as fast as possible it is often not

sufficient to provide helpful documents. In practical

use many documents, reports or guidelines cover

diverse technological and methodical aspects and are

not focused on a single topic. Hence a simple

suggestion of such documents dissatisfies a user,

since he obviously dislikes scanning the whole

content just to identify only some interesting

paragraphs.

In order to identify such paragraphs conventional

keywords based document retrieval allows in

subsequence a search within a document by usage of

the same keywords. In contradiction to this the

proposed search approach of semantic similarity

between helpful documents and a given working

context abstains from user based keywords thus

making a subsequent internal search complicated or

impossible. There is a need for an enhancement by

providing functionalities to decide quickly, if a

suggested document is appropriate for the actual

work context, in terms of why is the specific

document highly ranked and which document parts

are interesting.

Hence the overarching vision addressed by the

presented approach is a practical solution, where a

result list of a (semantic) search is enhanced by a

direct preview of respective documents. This

preview has to come up with highlighted or marked

up keywords and text passages in a way, that a user

will be enabled to identify easily the most relevant

sections with respect to his/hers actual working-

context at a glance. Ideally by use of different colors

or color intensities additional information, such as

"importance to context" should be given to support a

quick and easy interpretation of the given results.

2 BACKGROUND

Several methods for generating semantics out of a

481

Kleiza K., Klein P. and Thoben K..

SEMANTIC IDENTIFICATION AND VISUALIZATION OF SIGNIFICANT WORDS WITHIN DOCUMENTS - Approach to Visualize Relevant Words within

Documents to a Search Query by Word Similarity Computation.

DOI: 10.5220/0003099004810486

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2010), pages 481-486

ISBN: 978-989-8425-28-7

 2010 SCITEPRESS (Science and Technology Publications, Lda.)

Table 1: Four selected topics with representative labels of the high lift device domain in the aviation industry.

Topic 4:

"aero design"

Topic 7:

"lessons learned"

Topic 13:

"components"

Topic 14:

"fly-by-wire"

aerodynamic test rib flap

shape stress spar airbus

design structure plane interconnection

domain load stringer manual

model lesson flap wire

aircraft learn slat drive

surface result panel system

set of documents have been developed in the past

few years, e.g. term frequency-inverse document

frequency weight (if-idf) (Salton and Bucklay,

1988), Latent Semantic Indexing (Deerwester et al,

1990) or probabilistic Latent Semantic Analysis

(Hoffmann, 1999). Several trials in that context and

in addition diverse publications (Wei and Croft,

2006) have shown that the Latent Dirichlet

Allocation (LDA) is feasible for Information

Retrieval tasks. The LDA uses a probabilistic topic

model to identify topics and associate words within

a set of documents to a topic, which is linked to a

discrete calculated probabilistic value.

Exemplarily for such results, table 1 shows four

topics (out of 20) and for each topic the belonging

seven top-ranked keywords. The topic model was

build with the Latent Dirichlet Allocation method

out of a set of documents referring to the aviation

domain.

The input for LDA is a set of documents

(corpus), whereas each document is represented by a

"bag-of-words", that means the sequence of words

within a document is not considered for following

calculations. The output of LDA is a probabilistic

assignment

()

tdP

to a topic

for each document

and a probabilistic assignment

Pwt

(

)

for each

keyword

to a topic

The topic labels have been assigned manually to

provide in addition "human readable" headings for

each topic. Obviously headings are not of

importance for the LDA approach, but alleviate

remarkable a communication with externals and

"non-specialists". The latter is especially of

importance in the context of "evaluation" and

acceptance of the given results in a practical

environment. As it turned out in several of our field

studies, users (especially in a business environment,

such as product development) show distrust to

search results provided by a totally nebulous

knowledge retrieval approach.

In order to ensure practicability and usability of

the proposed solution, the respective documents

used for this test-bed refer to "real" document

repositories, which are in use as a knowledge

repository for the development of Wing High Lift

components.

2.1 Similarity Computation

Similarity, in sense of our approach, occurs by the

ability to compare the probabilistic assignment to

each topic between different documents. The

Kullback Leibner (KL) divergence is recommended

by (Steyvers and Griffiths, 2007) as an appropriate

function to calculate the similarity, whereas

and

is the topic distribution to a given topic

out of

the set of topics

()

∑

∈

⋅=

tqP

tpP

tpPqpKL

log,

(1)

With respect to an appropriate post-processing of the

computed results, in some cases (e.g. to generate a

symmetric distance matrix for a two-dimensional

result map) a symmetric measurement KL

sym

necessary:

sym

p,q

()

KL p,q

()

+ KL q, p

()

(

)

(2)

Such a similarity computation can be done among

different documents in a given repository or even

between a text paragraph (instead of a complete

document) and documents in a given repository. The

latter can be compared to a search query, e.g. to

provide similar documents to a selected text passage

of a document in progress or of interest.

KDIR 2010 - International Conference on Knowledge Discovery and Information Retrieval

482

Table 2: Top five results to a search query. Further a text summarization for each resulting document.

Document Relevance 1.word 2.word 3.word 4.word 5.word 6.word 7.word 8.word 9.word

Movable_flap

....pdf

91 %

flap fairing Aug investigation fair ll a340

modificati

ata

Fairing_Intefe

rence...pdf

89% flap fairing Aug investigation fair ll a340 modificati

ata

Flap_Track_F

airing...pdf

85%

flap fairing Aug investigation fair ll a340

modificati

ata

Flap_Track_

Actuator...pdf

84%

flap fairing Aug investigation fair ll a340 ata track

Movable_FT

F...pdf

83%

flap fairing Aug investigation fair ll a340 ata movable

Figure 2: An abstract of the annotated preview of “Sulak Sivaraksa” (84% relevance; left) and “Social Development

Theory” (91% relevance; right). Relevance was computed with KL divergence and visual assignment with function (4)

(k=0.05).

The calculated divergences can then be used to rank

the documents according to their similarities in e.g. a

table form or a two-dimensional map (Kleiza et al.,

2010).

Next to the above mentioned function the

Euclidean Distance or Cosine Similarity are also

possible distance functions for computing the

semantic similarity by use of a topic model.

2.2 Text Summarization

As mentioned above the authors claim to have

identified a need for an enhancement of the

described similarity computation approach by

addressing the traceablity of the KL based search

results (in terms of why is the specific document

highly ranked or which document parts are upmost

interesting).

In order to provide an overview for the user to

indicate, why those results are similar to each other

or to a given search query, several approaches have

been analysed. So far, all approaches base either on

a sentence (Wang et al., 2008) (Gong and Liu, 2001)

or on word summarization (Dredze et al., 2008) (Liu

et al., 2009) of the documents to give an insight

meaning of the similarity. In most cases a word

summarization is preferable, because of a shorter

overview and faster cognitive understanding and

filtering during a search process. Here the set of

words which is considered by the summarization

always comes out of the current document.

Remaining words of the whole dictionary, which

could be also meaningful for the summarization, are

so far not taken into consideration. (Dredze et al.,

2008) uses the following function to rank the words

within a document, whereas

is the word

(candidate) for the relevance computation and

the

related document or text paragraph:

(| ) (|)( |)(| )

Pc d Pc tPw tPt d

∈

∑

∏

(3)

For instance the ten words with the highest

probability could be visualized in a tag cloud or as

an addition to the search result list (table 2) to give a

better understanding, why the results are similar to a

given query (or a text paragraph respectively). The

search query input below comes up with a result list

mainly with documents of the Lessons Learned

section in the wing high lift device domain:

"Several cases of A340 movable flap

track fairing n°5 with one case on A330

have been reported with inner skin

cracked. Cracks lengths ranged from 180

to 2600 mm and are not related to

accidental damage."

SEMANTIC IDENTIFICATION AND VISUALIZATION OF SIGNIFICANT WORDS WITHIN DOCUMENTS -

Approach to Visualize Relevant Words within Documents to a Search Query by Word Similarity Computation

483

The relevance values are computed with the KL

divergence function followed by a normalization and

conversion to percentage values. Table 2 shows the

top five documents ranked with the highest

relevance and a word summarization computed with

function (3). The probabilistic evaluation

P(c|d)

the words in Table 2 varies between a range of 10

-76

and 10

-94

. Numerous multiplications of the terms

between 0 and 1 are responsible for such low values.

3 APPROACH

In many cases text summarization as shown in table

2 brings not the required usability to filter a sub-set

of relevant documents fast and easy according to

their importance for a given context. The equality of

text summarization is often attended by the

similarity computation of documents. The

characteristics are often not given by a text

summarization (as shown in table 2). Hence our

approach bases on the idea to mark up those words

directly in the resulting document, which are

semantic similar. This way a visual rendering of the

document with the highlighted text passages within a

preview pane can be archived. We assume, that a

user gets a better understanding of the deep insight

of the similarity between document and search query

with a highlighted preview. The semantic

highlighting goes further than a syntactic

highlighting of words which annotates matching

search keywords in the document, like known by

common search engines. Hence such an approach

for semantic highlighting on probabilistic topic

model needs a elaborated theoretical background.

3.1 Word Similarity

The underlying algorithm for word similarity has to

be equal for all documents in order to get

comparable previews of different documents.

Therefore highly ranked documents (in term of the

KL Divergence computation) should offer many

words with high similarity and lower ranked

documents should contain fewer words with high

similarity and a lower similarity on average

respectively.

(|,) .log (|)(|)(|)

wdq k PwtPt dPtq

∈

=−

∑

(4)

The importance / similarity of a word

in the

document

for the current query

is given by

function (4). The scalar

gives the ability to stretch

the values in order to refine the visualization for the

user.

3.2 Visual Assignment

Even though it is not in focus of the core research of

the semantic similarity approach, an appropriate

visualization of results is to be expected to be a key

issue for user acceptance in a practical environment.

Therefore a visual assignment of an arbitrary word

by its similarity calculated by function (4) to a

search query has been defined.

Figure 1: Visual assignment for highlighting identified

words.

Figure 1 shows an assignment of highlighted

keywords to a color spectrum in the style of an

"signal light". A green annotation indicates a strong,

yellow a middle and red low significance. The visual

assignment fades out to indicate no significance

arranged behind the colors. Alternative possible

annotation types could be e.g. underlining or

surrounding the words, but from initial user

feedback based on paper mockups it turned out, that

a simple color annotation (as also shown in fig. 2) is

easy to grasp and comes along with an outstanding

effect. The visual assignment can be justified by

modifying the scalar

to get a proper visualization.

However, a fine-tuning of

in consultation with

respective end users is foreseen to be part of the

planned field study.

4 RESULTS

During a test the number of topics was set to 100

and the topics have been computed out of a set of

about 1000 Wikipedia documents by usage of LDA

algorithms. Stopwords have been removed and a

lemmatization of the words has been done. The

identification of significant words was computed by

usage of function (4) and the following query input:

"People need a broad range of skills

in order to contribute to a modern

economy and take their place in the

technological society of the twenty-

first century. An ASTD study showed

that through technology, the workplace

is changing, and so are the skills that

employees must have to be able to

change with it."

KDIR 2010 - International Conference on Knowledge Discovery and Information Retrieval

484

Exemplarily for the computational output two

excerpts are shown in Figure 2. Both arbitrary

selected previews provide identified and highlighted

words. The left preview (Sulak Sivaraksa) highlights

in intensive green words in relation to three topics:

religion ("Buddhism"), social ("University",

"Social", "Interactual") and press ("Magazine",

"Journal", "Press"). On the other side the right

preview (Social Development Theory) highlights

intensive green words in relation to Technology

("Technology", "Knowledge", "Development",

"Effective") and Social ("Social", "Organization")

topics. As a conclusion it can be stated that different

words out of different topics have been identified,

which match the meaning of the given query-input

very well in any topic (social, technologic) or have

generally a significant meaning for the specific

document (e.g. press and religion).

It has to be stated that the enhancement of a

semantic search engine by implementation of a word

similarity algorithm can be definitely used to

identify semantic relevant sections and text passages

within a document. Even though the current

implementation is still at the prototype stage,

benefits to be gained by its usage already become

clearly visible, especially with respect to the

implemented visual assignment.

5 OUTLOOK

As one of the next major milestones an evaluation of

the approach in a field study is planned to validate

the concept on operational level. This field study

will be conducted by potential key users belonging

to a product development department in the aviation

sector. By picking up the group of engineers,

designers and physicians for aerodynamics, working

in the area of Aircraft Design as target users on the

one hand and their document repositories as a test-

bed on the other, the authors want to ensure

practicability and usability of the proposed solution.

On a technical level several improvements are

foreseen either: Next to LDA, other topic models

will be tested and compared by each other in order

to receive an overview how well the proposed

approach works upon them. For instance the authors

expect to have even better results by usage of the

HMM-LDA (Griffiths et al., 2005) approach instead

of LDA, because the HMM-LDA not only considers

the unstructured "bag-of-words" input, but also

reflects the sequence of words within the respective

document. By using HMM-LDA the authors expect

to come up with a solution, where the intensive

highlighted words will be even more concentrated

on a specific text passage. Next to those

examinations further optimization and refinements

of the core algorithms for computation of the word

similarity are foreseen in order to continuously

improve the output quality.

ACKNOWLEDGEMENTS

This work has been done under the LuFo IV 2nd call

-HIGHER-TE- WP4200 research programme funded

by the Airbus S.A.S. We wish to acknowledge our

gratitude and appreciation to all the project partners

for their contribution during the development of

various ideas and concepts presented in this paper.

REFERENCES

Bahrs, J. et al., 2007. Wissensmanagement in der Praxis -

Ergebnisse einer empirischen Untersuchung:

Empirische Studien in der Wirtschaftsinformatik 1.

ed., Gito.

Blei, D.M., Ng, A.Y. & Jordan, M.I., 2003. Latent

dirichlet allocation. The Journal of Machine Learning

Research, 3, 993-1022.

Deerwester, S. et al., 1990. Indexing by latent semantic

analysis. Journal of the American Sociaty for

informations science, 41(6), 391-407.

Dredze, M. et al., 2008. Generating summary keywords

for emails using topics. In Proceedings of the 13th

international conference on Intelligent user interfaces.

Gran Canaria, Spain, pp. 199-206.

Gong, Y. & Liu, X., 2001. Generic text summarization

using relevance measure and latent semantic analysis.

In Proceedings of the 24th annual international ACM

SIGIR conference on Research and development in

information retrieval. New Orleans, United States, pp.

19-25.

Griffiths, T.L. et al., 2005. Integrating topics and syntax.

Advances in neural information Processing Systems,

17, 537-544.

Hofmann, T., 1999. Probabilistic Latent Semantic

Analysis. Proceedings of uncertainty in artificial

intelligence, 289-296.

Kleiza, K. et al., 2010. Integrated Semantic Search in the

Product Development Phase. to be published in

Proceedings of the 16th International Conference on

Concurrent Enterprising.

Liu, S. et al., 2009. Interactive, topic-based visual text

summarization and analysis. In Proceeding of the 18th

ACM conference on Information and knowledge

management. Hong Kong, China, pp. 543-552.

Salton, G. & Buckley, C., 1988. Term-weighting

approaches in automatic text retrieval. Information

Processing & Management, 24(5), 513-523.

SEMANTIC IDENTIFICATION AND VISUALIZATION OF SIGNIFICANT WORDS WITHIN DOCUMENTS -

Approach to Visualize Relevant Words within Documents to a Search Query by Word Similarity Computation

485

Steyvers, M. & Griffiths, T., 2007. Probabilistic topic

models. Handbook of Latent Semantic Analysis, 424–

440.

Wang, D. et al., 2008. Multi-document summarization via

sentence-level semantic analysis and symmetric matrix

factorization. In Proceedings of the 31st annual

international ACM SIGIR conference on Research and

development in information retrieval. Singapore, pp.

307-314.

Wei, X. & Croft, W.B., 2006. LDA-based document

models for ad-hoc retrieval. In Proceedings of the 29th

annual international ACM SIGIR conference on

Research and development in information retrieval.

Seattle, USA, pp. 178-185.

KDIR 2010 - International Conference on Knowledge Discovery and Information Retrieval

486
