EXPERIMENTAL EVIDENCE ON DATA WAREHOUSE

FRAGMENTATION AND ALLOCATION IN A DISTRIBUTED

CONTEXT

Tekaya Karima, Abdellaziz Abdelatif

Data-processing Department, Faculty of Sciences of Tunis, Rommana, El Manar 2, Tunisia

Habib Ounalli

Data-processing Department, Faculty of sciences of Tunis, Rommana, El Manar 2, Tunisia

Keywords: Distributed data warehouse, Fragment Evaluator, Fragmentation, Allocation, Primary and derived horizontal

fragmentation.

Abstract: Since a relational data warehouse has the same physical structure as a classical database, it can enjoy all the

benefits realized during the past in distributed databases such us data availability, simplicity, rapid local data

access and transparent access to remote sites. So, it would be interesting to test its decentralization by

adapting the most adequate fragmentation and allocation technique. In this paper, we present a data

warehouse fragmentation and allocation approach in a distributed context. We conduct first, computation

studies using a mathematical cost model. Then, we test our approach on a real data warehouse by using the

APB1 benchmark data set on Oracle11G.

1 INTRODUCTION

Data Warehouse (DW) decentralisation starts by

data fragmentation and then fragment allocation.

Obviously, fragmentation is considered today as an

important option in physical DW design. Its process

begins with the collection of the predefined queries

throughout the geographically dispersed company

sites. Then, it extracts from these queries all the join,

projection and selection operations. These

operations are used for logical tables partitioning.

The deployment of the fragmentation in a DW must

be quit founded with the specificities of the

multidimensional modelling. In fact, a relational

DW is modelled by a star schema which consists of

a fact table and several dimension tables. The former

is a huge table constituted by two attribute types:

key attribute (conjunction of foreign keys) and

measure attributes. The fact table is interconnected

to dimension table’s by links of cardinalities one to

many. The latter, around the fact table, are generally

small-sized, denormalized and contain two types of

attributes: descriptive and hierarchical ones. Despite

the fact that a relational DW has the same physical

structure as a relational database, it is distinguished

by its multidimensional aspects. In fact, each

measure in the fact table is determined according to

a number of dimension keys. Fragmentation must

respect the granularity level of the fact table. In

addition, analyses are done according to one or

many dimension(s). Each dimension has some

hierarchical attributes that support ascending (or

descending) analyses. Such a topology (star model)

is conceived to answer effectively the requirements

of the analysis queries. A well adapted

fragmentation technique, therefore guarantees a best

deployment of the fact table granularity level and

dimension hierarchical attributes. Otherwise, in a

distributed context, the fragmentation technique

aims to decentralize the DW. Fragmentation is based

on decision makers requests, their geographical

location and the number of partitions needed to

efficiently meet their needs. Fragmentation is no

longer limited to optimize data storage, but it

extends to the reorganization of the whole logical

model of the DW into several local models

according to local needs of the company sites. As in

to the centralized environment, local and remote

102

Karima T., Abdelatif A. and Ounalli H..

EXPERIMENTAL EVIDENCE ON DATA WAREHOUSE FRAGMENTATION AND ALLOCATION IN A DISTRIBUTED CONTEXT.

DOI: 10.5220/0003104801020110

In Proceedings of the International Conference on Knowledge Management and Information Sharing (KMIS-2010), pages 102-110

ISBN: 978-989-8425-30-0

 2010 SCITEPRESS (Science and Technology Publications, Lda.)

access to data in the decision support system must be

transparent to users, i.e., managed by the current

distributed data base management system.

Consequently, the DW can benefits from all the

advantages of distributed databases such as data

availability, simplicity, rapid local data access and

transparent access to remote sites.

The paper is organized as follows: in section 2, we

present related works. In section 3, we illustrate a

DW fragmentation and allocation strategy. In section

4, we use a mathematical cost model to evaluate the

fragment cost. In section 5, we apply some

experiments on a real DW to evaluate our approach.

Section 6 contains concluding remarks.

2 STATE OF THE ART

DW fragmentation has been recently a subject of

study in the literature. As it has a similar relational

physical structure like relational databases,

researches start by adapting classical fragmentation

techniques (vertical, horizontal and hybrid

fragmentation). These experiences demonstrate that

DW fragmentation task becomes very difficult

facing star model multidimensional aspect. In fact,

proposals can be classified according to the DW

architectures. In the following sections, we classify

works according to three different architectures:

centralized, parallel, and Distributed DW (DDW).

2.1 Centralized DW Fragmentation

Many research studies address the issue of

fragmenting relational DWs to efficiently process

analytical queries into centralized context.

(Datta et al., 1999) and (Golfarelli et al.,1999)

use vertical fragmentation of the fact table; While

(Datta et al., 1999) use vertical fragmentation

technique to build the Curio index and to improve

ad-hoc query performance, (Golfarelli et al.,1999)

use this technique on warehouse views optimization.

(Bellatreche & Boukhalfa, 2005) use the horizontal

fragmentation technique. According to Bellatreche,

the best way to fragment a star schema is by using

the primary and derived fragmentation technique.

The fact table fragmentation is based on the

partitioning schemas of dimension tables. (Wu &

Buchmaan, 1997) recommend combining horizontal

fragmentation technique and vertical fragmentation

technique for query optimization.

2.2 Parallel DW Fragmentation

Some research studies concentrate on the issue of

fragmenting relational DWs into a parallel context:

(Costa & Madeira, 2004) and (Furtado, 2004) focus

on the horizontal partitioning of the DW among a

cluster of computers. Their technique partitions the

fact table over all nodes and replicates small

dimension tables in each node. Authors exploit

existing database management system partitioning

techniques. While Costa and Madeira use a row-by-

row round-robin partitioning technique, Furtado uses

hash partitioning technique based on the analysis of

the workload. (Ciferri & Souza, 2002) introduce The

WebD2W System. The latter propose a DW

horizontal fragmentation algorithm. This algorithm

uses only one dimension table in the fragmentation

process but no considerations were given to

dimension attributes relationship hierarchies.

(Ciferri, 2007) extends the work done by (Ciferri &

Souza, 2002) and proposes the MHF-DHA

algorithm. In this work, the fragmentation process

uses multiple dimension tables as a basis to fragment

the fact table and addresses the treatment of

dimension attributes relationship hierarchies.

2.3 Distributed DW Fragmentation

Very few works concentrate on the issue of

fragmenting relational DWs to the decentralization

purpose. (Noaman & Barker, 1997) proposed a

specific architecture for a DDW. This one is based

on the ANSI/X3/SPARC architecture that has three

levels of schemas: internal, conceptual and external.

To distribute the DW, authors exploit a top-down

strategy that uses horizontal fragmentation (Noaman

et al., 1999). They proposed a horizontal

fragmentation algorithm for the fact table. This

algorithm is an adaptation of the work done by

(Ozsu & Valduriez, 1991). (Wehrle et al., 2005)

propose a data grid infrastructure to implement the

DW decentralization. Their data model is based on

"chunks" as atomic entities of a DW that can be

uniquely identified. Then, they build contiguous

blocks of these chunks to obtain suitable fragments

of the DW. The fragments stored on each grid node

must be indexed in a uniform way to effectively

interact with the existing grid services.

2.4 Discussion

The fundamental aspects of the DW fragmentation

have been studied by many works. But the most

important of them have limited its use in a

EXPERIMENTAL EVIDENCE ON DATA WAREHOUSE FRAGMENTATION AND ALLOCATION IN A

DISTRIBUTED CONTEXT

103

centralized environment. What distinguishes our

work from those works is that they aim to improve

the data storage organization and the parallel queries

execution by partitioning a table into multiple sub-

tables. Besides, data allocation process is not

considered as a problem since the DW is centralized.

In our context we intend to decentralize the data

storage of the whole DW according to the user’s

needs. Starting from a general model, we generate

several sub-models. Each sub-model is specified as a

future data mart. Works focused on the decentralized

context are in general theoretical and lack of

experimental evidence. Other studies have

investigated technical aspects of the DW

decentralization on a data grid. They proved

experimentally that we can use easily advanced

infrastructure; such as data grid to support DDW.

Therefore, it will be interesting to evaluate and

experiment a DW fragmentation and allocation

strategy for a decentralization purpose.

3 DW FRAGMENTATION AND

ALLOCATION STRATEGY

The DW decentralization has two main phases: data

fragmentation and fragment allocation. Data

fragmentation consists in generating several sub-

models from the general star model. To fragment the

star model tables we use predicates as criterion. We

apply the predicate construction technique (Ozsu &

Valduriez, 1991) to construct the minterm predicate

list. Then, we adapt the horizontal primary and

derived fragmentation technique to fragment

dimension and fact tables. Finally, we allocate each

fragment to the corresponding site. We use three

fragment allocation techniques: simple allocation,

allocation with replication and allocation with some

studied replications.

Figure 1: Sale activity star schema.

We choose, as an example, the sales activity

schema (Figure 1). It consists of one fact table

(Sales) and a set of dimension tables (Product,

Location, Date and Customer) connected by foreign

keys for all possible links. The fact table contains

business facts or measures and foreign keys which

refer to the primary keys in the dimension tables.

3.1 Predicate Construction Phase

In this phase, we start by extracting predicates from

the most used queries trough the company sites.

Then, we use the com_min algorithm (Ozsu &

Valduriez, 1991) to generate minterm predicate list.

According to the Com_min algorithm (Ozsu &

Valduriez, 1991), a relation, or a fragment, must be

partitioned "into at least two parts which are

accessed by at least one application differently". We

have chosen the Com_min algorithm because it

guarantees data completeness, table reconstruction

and fragment disjointness.

We take as an example the nine following queries

running on the DW tables. We can extract from each

query the used predicate list:

Q1. This application analyses sales turnover into site

1 according to the location ordered by products.

The predicates are {Id_P=1,2 & Id_L=1}

Q2. This application analyses sales quantities into

site 1 according to the location ordered by

customer categories. The predicates are

{Id_C=1,2,3 & Id_L=1}

Q3. This application analyses sales turnover

quantities into the sites: 1, 2 and 3 according to

the location ordered by customer categories and

products. The predicates are {Id_P=1,2,3,4 &

Id_C=1,2,3,4,5,6,7,8,9 & Id_L=1,2,3}

Q4. This application analyses sales turnover into site

2 according to the location ordered by products.

The predicates are { Id_P=2,3 & Id_L=2}

Q5. This application analyses sales quantities into

site 2 according to the location ordered by

customer categories. The predicates are {

Id_C=4,5,6 & Id_L=2}

Q6. This application analyses sales turnover

quantities into site 2 according to the location

ordered by customer categories and by products.

The predicates are { Id_P=2,3 , Id_C=4,5,6 &

Id_L=2}

Q7. This application analyses sales turnover into site

3 according to the location ordered by products.

The predicates are { Id_P=3,4 & Id_L=3}

Q8. This application analyses sales quantities into

site 3 according to the location ordered by

customer categories. The predicates are {

Id_C=7,8,9 & Id_L=3}

Q9. This application analyses sales turnover

quantities into sites 3 according to the location

KMIS 2010 - International Conference on Knowledge Management and Information Sharing

104

ordered by customer categories and by products.

The predicates are { Id_P=3,4 , Id_C=7,8,9 &

Id_L=3}

We suppose that:

 In the site 1: just the product Id_P=1 and

Id_P=2 are on sale, there is one location Id_L=1

and the corresponding customers are Id_C=1,

Id_C=2 & Id_C=3.

 In the site 2: just the product Id_P=2 & Id_P=3,

are on sale, there are two locations Id_L=2 &

Id_L=3 and the corresponding customers are

Id_C=4, Id_C=5 & Id_C=6.

 In the site 3: just the product Id_P=1, Id_P=2,

Id_P=3 & Id_P=4 are on sale, there are two

locations Id_L=4 & Id_L=5 and the

corresponding customers are Id_C=7, Id_C=8 &

Id_C=9.

We recapitulate the complete and minimal

dimension predicate list by site in the following lists:

Site1: Site 2: Site3:

Id_P=1,2

Id_L=1

Id_C=1,2,3

Id_P=2,3

Id_L=2, 3

Id_C=4,5,6

Id_P=1,2,3,4

Id_L=4,5

Id_C=7,8,9

After Appling the com_min algorithm to the

preliminary predicate list, the corresponding

complete and minimal predicate list is:

MP={P1:Id_P=1, P2: Id_P =2, P3:Id_P=3, P4:

Id_P=4, P5: Id_L=1, P6: Id_L=2, P7: Id_L=3, P8:

Id_L=4, P9: Id_L=5, P10: Id_C in [1,2,3], P11: Id_C

in [4,5,6], P12:Id_C in [7,8,9], P13: Id_R=1, P14:

Id_R=2, P15: Id_R=3}.

The next phase of the predicate construction

technique is the conjunction of simple predicates

which is called a minterm predicate. In fact, each

simple predicate can be produced in its natural form

or by negation. The number of minterm predicate is

z=2

; with m the number of simple predicate.

Minterm predicates are exponential on the number

of simple predicates; we can eliminate meaningless

minterm predicates by identifying those which

contradict to a set of implications.

We suppose as an example that we have the

following implication list:

i1: P10

Æ ¬P11 ٨ ¬P12

i2: P11 Æ ¬P12 ٨ ¬P10

i3: P12

Æ ¬P10 ٨ ¬P11

i4: P13 Æ ¬P14 ٨ ¬P15

i5: P14 Æ ¬P13 ٨ ¬P15

i6: P15

Æ ¬P13 ٨ ¬P14

i7: P5

Æ¬P6 ٨ ¬P7 ٨ ¬P8 ٨ ¬P9

i8: P6 Æ P7 ٨ ¬P5 ٨ ¬P8 ٨ ¬P9

i9: P7

Æ P6 ٨ ¬P5 ٨ ¬P8 ٨ ¬P9

i10: P8Æ P9 ٨ ¬P5 ٨ ¬P6 ٨ ¬P7

i11: P9

Æ P8 ٨ ¬P5 ٨ ¬P6 ٨ ¬P7

The implication list integrates fact implications, for

instance: site 1 contains one location: id_L1=1, two

product id_P=1, id_P=2 and id_C in [1, 2, and 3].

The implication list depends on the semantic of the

application.

If we have the following fact implication list:

 i12: P13

ÆP1 ٨ P2 ٨ P5 ٨ P10

 i13: P14 Æ P2 ٨ P3 ٨ P6 ٨ P7 ٨ P11

 i14: P15

Æ P1 ٨ P2 ٨ P3 ٨ P4 ٨ P8 ٨ P9

We will obtain the corresponding fact minterm

predicates list:

 m1: Id_P=1 ٨ Id_P=2 ٨ Id_L=1 ٨ Id_C IN

[1,2,3] ٨ Id_R=1

 m2: Id_P=2 ٨ Id_P=3 ٨ Id_L=2 ٨ Id_L=3 ٨

Id_C IN [4,5,6] ٨ Id_R=2

 m3: Id_P=1 ٨ Id_P=2 ٨ Id_P=3 ٨ Id_P= 4 ٨

Id_L= 4 ٨ Id_L=5 ٨ Id_C IN [7,8,9] ٨ Id_R=3

3.2 DW Fragmentation Phase

The fragmentation phase consists, first, in

fragmenting the dimension table according to the

minterm predicate list (Primary horizontal

fragments). Then, we use a semi-join (α) operation

between dimension primary horizontal fragments

and the fact table to generate horizontal derived

fragments. Table 1 contains the primary horizontal

fragments list of the previous example.

Table 1: Primary Horizontal fragments.

After applying derived horizontal fragmentation on

table Sales, we obtain the following derived

horizontal fragment list:

and



(Sales, R1) ∩ α(Sales,P1)

(Sales,P2)

∩ α(Sales,L1) ∩ α(Sales,V1).



(Sales,R2) ∩

(Sales,P2) ∩

α(Sales,P3) ∩ α(Sales,L2) ∩

α(Sales,V2).



(Sales,R3) ∩ α(Sales,P1) ∩

α(Sales,P2) ∩ α(Sales, P3) ∩

α(Sales,P4) ∩ α(Sales,L3)∩

α(Sales,V3).

3.3 Allocation Phase

There are three possible allocation strategies: simple

EXPERIMENTAL EVIDENCE ON DATA WAREHOUSE FRAGMENTATION AND ALLOCATION IN A

DISTRIBUTED CONTEXT

105

fragment allocation, allocation with fragment

replication and allocation with some studied

fragment replication.

We take as an example the fragments uses

frequency matrix. The columns present horizontal

fragments, rows represent the three sites of the

company, and each cell contains the frequency of a

fragment uses.

3.3.1 Simple Allocation Strategy

Each fragment is allocated into the site where it is

the most frequently used. This option is generally

chosen when the accesses cost between the

organization sites does not have negative impact on

the DW performance. The corresponding allocation

matrix is given bellow.

The columns present primary horizontal fragments

of dimension tables. The columns R1, R2 and R3

present primary horizontal fragments of the

dimension table Region. L1, L2 and L3 present

primary horizontal fragments of the dimension table

Location. P1, P2, P3 and P4 present primary

horizontal fragments of the table Product. F1, F2, F3

present derived horizontal fragments of the fact table

Sales. The matrix rows represent the three sites of

the company. Each cell contains the state of each

fragment on the corresponding site. A indicates that

a fragment is allocated on a site. O indicates that a

fragment is out or non-existing on a site. U indicates

that a fragment is used or accessed by a site but it’s

not replicated in it.

3.3.2 Allocation with Replication Strategy

In this strategy, each fragment is allocated where it

is used. We opt for the local data accesses rather

than the data remote accesses. The corresponding

allocation matrix is given bellow.

3.3.3 Allocation with some Studied

Replication Strategy

In this strategy, each fragment is allocated where it

is the most frequently used and replicated into sites

in which the data remote accesses cost is elevated.

The corresponding allocation matrix is given bellow.

To evaluate generated fragments, we conduct

numeric and experimental studies. Numeric studies

are based on the adaptation of the known objective

function developed in (Chakravarthy, 1992).

Experimental studies are based on distributing a real

DW by using the data set of the APB1 Benchmark

(OLAP Council, 1998).

4 DW FRAGMENT EVALUATOR

Our first strategy to evaluate DW fragments is to use

a cost model. Each fragment is evaluated by its local

processing cost and remote one on each site. It is

supposed that there are no data redundancies

between fragments. Fragments are allocated to sites

where they are the most used. DW Fragment

Evaluator (DWFE) computes the processing cost of

each fragment. The Fragment Evaluator (FE) is

given by:

EEFE +=

(1)

Where

is the local horizontal fragment access

cost and

is the remote one.

4.1 Local Fragment Access Cost

The local horizontal fragment access cost

is the

first component of the DWFE. As an adaptation of

the work presented by Chakravarthy in

(Chakravarthy, 1992),

is given by:

(2)

Where M is the total number of fragments; T is the

total number of transactions in the site c;

itc

is the

number of rows in F

accessed by a transaction t at a

site c;

is a frequency of an application t at a site

c and n

is the total number of rows contained in a

fragment F

. This component uses the square-error

criterion as given by Jain in (Jain, 1988) for data

clustering. The objective here is to obtain a fragment

which minimizes the square error for a fixed number

of fragments. This criterion assigns a penalty factor

whenever local rows are accessed in a particular

fragment. (Chakravarthy, 1992)

4.2 Remote Fragment Access Cost

The remote horizontal fragment access cost

)]n/S1(S*q[E

iitc

itc

∑∑

−=

KMIS 2010 - International Conference on Knowledge Management and Information Sharing

106

the second component of the DWFE. For each

transaction running on a fragment, we compute the

ratio between the number of remote rows to be

accessed by a transaction t and the total number of

rows in each remote fragment. The remote

horizontal fragment access cost which is an

adaptation of the work presented by Chakravarthy in

(Chakravarthy, 1992) is given in the following

equation:

(3)

Where: is the number of relevant remote row

access in fragment k accessed remotely with respect

to a fragment i by a transaction t at a site c; is

the total number of rows in fragment k accessed

remotely with respect to a fragment i by a

transaction t.

We use the DWFE to measure the performance

of a fragmentation schema. A lower DWFE value

means fewer penalties and thus; better performance.

We take as an example the following row numbers

(Table 2). We use this example to computes the

DWFE for each fragment.

Table 2: Row sets on each site.

To allocate each fragment, we test three cases: (1)

fragmentation with full copy resides on site 1; (2)

fragmentation with one copy resides on every site

and (3) fragmentation with some fragment

replication. We present in table 3, table 4 and table 5

the local access cost and a remote access cost of

each table.

Table 3: CASE 1: Fragmentation, full copy resides on

site 1.

Table 4: CASE 2: Fragmentation copy resides on each

site.

In case 1, the fact table is centralized in one site, the

remote access cost is very high. In case 2, each

fragment is replicated there where its frequency of

use is positive. The remote access cost is always

equal to 0, because the fragment is locally accessed

by the decision support system. The Local access

cost is very high for the sales table because this one

is generally characterized by a huge number of rows.

Consequently, replicating the fact table in each site

is not a good option.

Table 5: CASE 3: Fragmentation with some replication.

In case 3, we remark that all local access costs are

fewer than the case 2 because just some fragments

are replicated.

We can deduce that if an organization is

distributed geographically and if its decision support

system is disseminated on several distant sites, it is

more interesting to adapt DDW architecture since it

gives better performance. In figure 2, we present the

FE values for the three cases. It is clear that

fragmentation with some fragment replication gives

lower costs than fragmentation with full copy resides

on site 1 and fragmentation with one copy resides on

every site.

Figure 2: Fragment allocation strategies comparison.

itk

∑∑

=≠

⎥

⎦

⎤

⎢

⎣

⎡

1tiK

itk

itkitk

R*R*qE

EXPERIMENTAL EVIDENCE ON DATA WAREHOUSE FRAGMENTATION AND ALLOCATION IN A

DISTRIBUTED CONTEXT

107

5 EXPERIMENTAL

EVALUATION

We have conducted an experimental study to

evaluate our proposal. We have used the dataset from

the APB1 benchmark (OLAP Council, 1998). The

star schema of this benchmark has one fact table

Actvars (33 323 400 tuples) and four dimension

tables (Figure 3): Prodlevel (9 900 tuples), Custlevel

(990 tuples), Timelevel (24tuples) and Chanlevel (10

tuples). We have considered a workload of 36

queries with 27 selection predicates. We have

conducted experiments using Oracle 11g. The data

set of APB1 benchmark is created and populated

using generator programs offered by APB1. We use

three machines having the same following

characteristics. Intel Core2Duo, 2 Gb of memory.

Figure 3: Star schema of the benchmark APB1 Sale

activity star schema.

5.1 APB1 Dataset Benchmark

Decentralization

We give bellow the complete and minimal predicate

list to the dimension table (We replace the attributes

Product_I and Customer_I by sequential numbers to

simplify the tasks of decentralization):

By applying the predicate construction technique,

we obtain the following fact minterm predicate list:

PM1: P7^P8^P9^P16^17^18^25^26^27

PM2: P1^P2^P3^P10^P11^P12^P19^P20^P21

PM3: P4^P5^P6^P13^P14^P15^P22^P23^P24

We take as an example the following fragment uses

frequencies matrix:

According to the fragment uses frequencies matrix,

we generate the fragment allocation matrix using the

simple allocation technique.

Finally, we allocate the various fragments into three

remote sites. The sites communicate through a

virtual Private Network using a tunneling protocol.

We use a workload of 36 queries that we execute to

a centralized APB1 benchmark. We see in figure 4

that remote access increases the execution time of

applications especially those whose users are

geographically distant. Then, we execute the same

workload into APB1 benchmark dataset distributed

using our DW fragmentation and allocation

approach.

5.2 Discussion

DDW architectures support multiple geographically-

distributed business divisions. It allows each

business division to have its own extraction,

transformation, loading tools and multiple data

marts. The central DW stores corporate-wide data

and all components are synchronized across the

DDW environment using a global metadata

repository.

Queries workload can be classified into two

categories: specific queries and general queries.

Specific queries describe local needs (example:

analyze sales amount by product of site 1). General

queries describe needs of the whole company sites

Figure 4: Specific queries execution time.

(example: compare sales amount by product of all

the company sites). In figure 4, we present specific

KMIS 2010 - International Conference on Knowledge Management and Information Sharing

108

queries execution time. Results show that DDW

gives better performance for all the specific queries

compared to the centralized context. Summed

specific queries execution time is reduced by 82%.

In figure 5, we present general queries execution

time. Results show that DDW gives better

performance for some general queries but not for

others. For query 1 (sales analysis by product by

year) and query 5 (sales analysis by quarter by year),

the execution times are elevated compared to the

centralized context. The specificity of those queries

is that they are based on JOIN operations between

all fragments localized at different distant

geographical sites. In this case, the execution time is

elevated compared to a CDW however the summed

general queries execution time is reduced by 76%.

Figure 5: General queries execution time.

6 CONCLUSIONS

The design of DDW is an optimization problem

requiring solutions to several interrelated problems

including: data fragmentation, fragment allocation,

and local optimization. Each problem can be solved

with several different techniques, thereby making

the distributed database design a very difficult task.

Although there are many researches on the design of

data fragmentation, most of them are focused on the

centralized context and no considerations are given

to the distributed allocation problem. Our work is

considered one of the few dealing with data

fragmentation and fragment allocation for the

decentralization purpose. In this paper, we adapt a

DW fragmentation approach using the predicate

construction technique to generate the predicate list

and the primary and derived horizontal technique to

fragment dimension and fact tables. Then, we study

three fragment allocation techniques into a

distributed environment. First, we allocate fragment

according to the simple allocation technique. Then,

we replicate fragment there were they are used

according to the fragment allocation with replication

technique. Finally, we revise some fragment

replication using the allocation with some fragment

replication technique. After that, we conduct

computing evaluation by using a DWFE and we

compare the three fragment allocation cases. Finally,

we implement our approach on a real DW. Results

demonstrate that DW decentralisation gives better

performance when data storage is distributed trough

the company sites. But, the execution time for

queries which are based on JOIN operations between

all distributed fragments is higher than in a

centralized context. As future work we intend to

study OLAP distant queries optimization in a DW

distributed context.

REFERENCES

Bellatreche, L., & Boukhalfa, K., 2005, An Evolutionary

Approach to Schema Partitioning Selection in a Data

Warehouse, In DAWAK’07, 7th International

Conference on Data Warehousing and Knowledge

Discovery. Volume 3589 of LNCS,

Chakravarthy S., et al., 1992. An objective function for

vertically partitioning relations in distributed databases

and its analysis, Distributed and Parallel Databases

journal.

Ciferri, C. D. A. & Souza, F., 2002, Focusing on Data

Distribution in the WebD2W System. In DAWAK’02,

4th International Conference on Data Warehousing

and Knowledge Discovery, Vol. 2454 of LNCS.

Ciferri, C. D. A., et al., 2007. Horizontal fragmentation as

a technique to improve the performance of drill-down

and roll-up queries. In SAC‘07, 22

ACM Symposium

on Applied Computing.

Costa, M. & Madeira, H., 2004. Handling Big Dimensions

in Distributed Data Warehouses using the DWS

Technique. In DOLAP’04, 7th ACM Eleventh

International Workshop on Data Warehousing and

OLAP.

Datta, A. & Ramamritham, K., & Thomas, H. M., 1999.

Curio: A Novel Solution for Efficient Storage and

Indexing in Data Warehouses. In VLDB’99, 25th

International Conference on Very Large Data Bases.

Furtado, P., 2004. Workload-based Placement and Join

Processing in Node-Partitioned Data Warehouses. In

DaWaK’04, 6

International Conference on Data

Warehousing and Knowledge Discovery., p. 38-47.

Golfarelli, M., Maio, D. & Rizzi, S., 1999. Vertical

fragmentation of views in relational data warehouses.

SEDB’99. In Settimo Convegno Nazionale su Sistemi

Evoluti Per Basi Di Dati.

Jain, A. & Dubes, R., 1988. Agorithms for clustering Data.

Prentice Hall Advanced Reference Series, Englewood

Cliffs, NJ.

EXPERIMENTAL EVIDENCE ON DATA WAREHOUSE FRAGMENTATION AND ALLOCATION IN A

DISTRIBUTED CONTEXT

109

Noaman, A. Y. & Barker, K., 1997. Distributed data

warehouse architectures. Journal of Data

Warehousing. Vol. 2.

Noaman, A. Y., Barker, K., 1999. A Horizontal

Fragmentation Algorithm for the fact relation in a

Distributed Data Warehouse. In ICKM’99, 8

International Conference on Information and

Knowledge Management.

OLAP Council, 1998. Apb-1 olap Benchmark, release 2.

http://www.olapcouncil.org/research/bmarkly.htm.

Ozsu, M. T. & Valduriez, P., 1991. Principles of

Distributed Database Systems. (pp. 657). Prentice-

Hall, Inc. Upper Saddle River, NJ, USA

Wehrle, P., Miquel, M. & Tchounikine, A., 2005. A

Model for Distributing and Querying a Data

Warehouse on a Computing Grid. In ICPADS’05, 11

International Conference on Parallel and Distributed

Systems. IEEE Computer Society.

Wu, M.-C. & Buchmann, A. P., 1997. Research Issues in

Data Warehousing. In Datenbanksysteme in Buro,

Technik und Wissenschaft, pages 61–82.

KMIS 2010 - International Conference on Knowledge Management and Information Sharing

110
