PRACTICAL ONTOLOGY DEVELOPMENT

Some Lessons Learnt

Rolf Grütter, Bettina Waldvogel

Swiss Federal Research Institute WSL, Zürcherstrasse 111, CH-8903 Birmensdorf, Switzerland

Curdin Derungs

Department of Geography, University of Zurich-Irchel, Winterthurerstr. 190, CH-8057 Zurich, Switzerland

Keywords: Knowledge Representation, Ontology Engineering, Applications and Case Studies.

Abstract: Ontology engineering is a well travelled ground, at least from a theoretical point of view. Long before the

Semantic Web became popular, principles for the design of ontologies were established and, recently,

guidelines and methods for building ontologies were published. Despite this guidance, there are issues in

practical ontology development, which are not covered in the literature. This paper discusses some problems

that occurred during the manual construction of an OWL application ontology and that required design

decisions by the developers.

1 INTRODUCTION

Ontology engineering is a well travelled ground, at

least from a theoretical point of view [Gómez-Pérez

et al., 2004]. Long before the Semantic Web became

popular, principles for the design of ontologies were

established (Gruber, 1995) and, recently, guidelines

and methods for building ontologies were published

(Kovacs et al., 2006, Noy and McGuiness, 2001).

Despite this guidance, there are issues in practical

ontology development, which are not covered in the

literature.

This paper discusses some problems that

occurred during the manual construction of a

medium sized (690 concepts, 50 properties, 4486

individuals), formal (description logics ALCHI(D))

bilingual (German/French) application ontology and

that required design decisions by the developers. It

shows by examples how these problems were

solved. Based on the insights gained during ontology

development the paper comes up with lessons learnt

that may be helpful for other developers.

The paper is organized as follows: In Section 2

design decisions that were taken prior to the

development process are described. Section 3 reports

on design decisions that were taken during the

development process and which were not

anticipated. Section 4 discusses the described design

decisions and Section 5 concludes with a list of

lessons learnt.

2 A PRIORI DESIGN DECISIONS

A first design decision is related to the scope of the

ontology: What kind of knowledge shall be

represented? This decision depends on what the

ontology is intended for and on the conceptualiza-

tion underlying the data to be described.

In our case the ontology was intended to support

non-expert users in retrieving information from a

large database for national species management by

expanding queries semantically. Together with

former and future users of the system, we compiled

a number of use cases. Documents and data were

analyzed for the concepts that were assumed as

(implicit) models of the respective domains by their

authors as well as for the names of these concepts.

Based on the use cases and on the results of the

analysis, significant concept hierarchies were build

for authorities, legal acts, regions, inventories (i.e.

kinds of data collections), habitats, animal species,

plant species, political processes, legal entities and

documents.

467

Grütter R., Waldvogel B. and Derungs C..

PRACTICAL ONTOLOGY DEVELOPMENT - Some Lessons Learnt.

DOI: 10.5220/0003115004670470

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development (KEOD-2010), pages 467-470

ISBN: 978-989-8425-29-4

 2010 SCITEPRESS (Science and Technology Publications, Lda.)

Figure 1: Entities that share the same name are differentiated based on their spatial references.

A further design decision is related to the question

whether a formal or a non-formal ontology should

be build and, if formal, which framework should be

used. We decided to build a formal onto-logy using

Web Ontology Language (OWL) (Patel-Schneider et

al., 2004). The decision of adhering to the standard

technique was taken in order to make the ontology

(or parts thereof) reusable and also to take advantage

of existing editors and reasoners to process the

ontology (note that our ontology can be obtained

from the authors for research purposes).

Still a further design decision is whether

individuals should be asserted in the ontology. From

the use cases we learnt that users are not only

searching for (sets of) individuals (which can be

retrieved by checking the satisfiability of concepts)

but also for specific properties of a certain individual

(in the case of a spatial object, its geometry, for

instance). In order to support this kind of search we

decided to also assert individuals in the ontology.

3 AD HOC DESIGN DECISIONS

Most design decisions during ontology development

were related to the disambiguation of entity names

and to figure out their meaning in terms of concept

membership. The extent of this challenge depended

on the kinds of entities to be integrated.

3.1 Is it a Name or a Taxon?

Animal and plant species in our data collections are

named by well-defined Latin taxa. For these a

straightforward approach could be applied: For one

entity in the database one named individual was

asserted in the ontology. Still the choice of the

taxonomy required a decision. Domain experts do

not work with a single taxonomy; they choose the

most appropriate, depending on the project at hand.

Ontological design, therefore, has the choice of

either concentrating on a single taxonomy or

considering competing classifications.

We chose a pragmatic approach and decided in

favour of a single taxonomy, namely the taxonomy

which is most commonly used by the domain

experts working with the data.

3.2 What Kind is this Entity of?

In our data collection there are entities whose names

mean different things, depending on the context in

which they are used. Consider, for instance, the

name “Kanton Bern” (i.e. Canton of Berne), usually

as a shortcut “BE”. “Kanton Bern” can be the name

of a regional authority governing an administrative

unit or it can be the name of the administrative unit

governed by the regional authority.

In order to figure out the meaning of “Kanton

Bern” and to record it in terms of concept

membership in the ontology, we looked at how it is

used in documents and data in the database. “Kanton

Bern” is usually used to denote the regional autho-

rity. Accordingly, we asserted an individual Kanton_

Bern for a concept Kanton which is subsumed by a

concept Gebietskörperschaft (i.e. regional authority).

3.3 Is this the Same Entity?

In databases, entities are identified by keys, in

ontologies individuals are identified by names.

Entities in databases may also have names but these

are not necessarily unique. Consider the name

“Rotmoos”, for instance: Quite a number of entities

in our data collection share this name.

KEOD 2010 - International Conference on Knowledge Engineering and Ontology Development

468

Figure 2: Entities with different geometries share the same additional type.

In order to decide whether these entities refer to the

same object or not, the procedure described in

Section 3.2 does not work. All are of the same

(general) kind, that is, they are members of concepts

that are subsumed by the concept Lebensraum (i.e.

habitat). Instead, we took advantage of a special

feature of these entities: They all have a spatial

reference, both in terms of the administrative unit

they belong to and in terms of a geometry (namely,

the coordinates of a bounding box).

Using the administrative information, two of the

entities sharing the name “Rotmoos” could be

identified as different objects: They belong to the

cantons Fribourg (FR) and St. Gall (SG) (Figure 1).

In order to decide whether the two Bernese entities

“Rotmoos” refer to the same object or not, the

administrative information was not helpful. The

entities could be identified as different objects only

by comparing their geometries (Figure 1).

3.4 Is this a Different Entity?

There are eight entities with the name “Grèves du

lac” in the collection of fens, whose geometries are

different. According to the procedure described in

Section 3.3, each of them would have to be asserted

as a uniquely named individual in the ontology, for

instance as Grèves_du_lac_I, Grèves_du_lac_II, …

Grèves_du_lac_VIII. Would this be the right decision?

A closer look at the data in the database denies the

question: All eight entities correspond to a single

entity in the collection of moorlands (Figure 2). If

each entity was asserted as a named individual in the

ontology, which one would be the individual that is

both a fen and a moorland?

The solution we chose was to assert for all eight

equally named entities of the collection of fens a

single uniquely named individual Grèves_du_lac in

the ontology and to type it as both a Fen and a

Moorland.

4 DISCUSSION

4.1 A Priori Design Decisions

As mentioned in Section 2 the design of an

application ontology depends on its purpose and on

the conceptualization of the people who collected

the data and of those who are going to use the

ontology. The vocabulary provided by an

application ontology further depends on the mother

tongue of these people. Because of these

dependencies, it is very unlikely that an application

ontology can be reused in a different context.

The advantage of formal ontologies, such as

description logics ontologies, is that they allow

automatic consistency checking and reasoning. By

computing entailments, new knowledge is being

inferred from existing knowledge. However, formal

ontologies impose rigid restrictions on the structure

of the knowledge they represent. A part of the

knowledge expressible in natural language cannot

directly be modelled by such a formal framework:

vague concepts, fuzzy information, general rules

with exceptions. Whether the gain in knowledge

earned by sound and complete inference procedures

overweighs the loss of knowledge taken by the rigid

framework is an open question.

PRACTICAL ONTOLOGY DEVELOPMENT - Some Lessons Learnt

469

4.2 Ad Hoc Design Decisions

As mentioned in Section 3.2 an entity name can

mean different things, depending on the context in

which it is used. There are different ways of dealing

with context. One way is to deal with it in terms of

the discourse that takes place (Kamlah and

Lorenzen, 1967). A discourse makes use of a

vocabulary, which can be specified by an ontology.

Still, a vocabulary does not make up a discourse.

Philosophy of science explains this by

differentiating between the communicative role and

the representative role of language (Kromrey, 2002).

According to this differentiation, the language in

which a discourse is expressed is different from the

language used to represent the vocabulary. Since the

design of a communication language is outside the

scope of ontology engineering, the context of the

discourse does not directly affect design decisions of

ontology developers.

Another way of dealing with context is to

consider the situation in which a discourse takes

place (Kamlah and Lorenzen, 1967). Using a theatre

metaphor, this kind of context is also referred to as

the play, which is performed, together with the

different scenes of that play (Laurel, 2003). What

the interaction that takes place is all about, can also

be referred to as a theme. Different from discourse,

themes directly influence decisions of ontology

developers. The consideration of context in ontology

development is, thus, closely related to the decision

on the scope of the ontology (cf. Section 2).

Differentiation of entities by analysing their

geometries (cf. Section 3.3) is an established method

in Geographic Information Science. The claim is

that two (or more) entities are the same if they share

the same (or a very similar) geometry (e.g. Sester et

al., 2007). Conversely, entities sharing the same

name can be differentiated according to the places

they refer to. As Section 3.4 suggests the application

of this method yields better results when it is

combined with type information. Note that

differentiation by using type information is a work-

around to uncover the case where shared names

point to the same broader place in the real world,

which is not recorded in a database.

5 CONCLUSIONS

The main lessons learnt from the development of an

application ontology as described in Section 1 are:

(i) The scope or theme of the ontology cannot be

copied from the available data and pasted in the

ontology; it rather has to be figured out by compiling

use cases together with future users and by

analyzing the data in view of the implicit conceptual

assumptions that were made by their authors; (ii)

entities in databases do not a priori correspond to

individuals in ontologies in an enumerative way; (iii)

differentiation of entities with a spatial reference by

analysing their geometries does not always work.

ACKNOWLEDGEMENTS

This research has been funded by the Swiss Federal

Office for the Environment (FOEN).

REFERENCES

Gómez-Pérez, A., Fernández-López M., Corcho, O., 2004.

Ontological Engineering, Springer London, pp. 403.

Gruber, T. R., November 1995. Toward principles for the

design of ontologies used for knowledge sharing.

International Journal of Human-Computer Studies,

Vol. 43, Issues 4-5, pp. 907-928.

Kamlah, W., Lorenzen, P., 1967. Logische Propädeutik.

Vorschule des vernünftigen Redens. Bibliographisches

Institut. Mannheim.

Kovacs, K., Dolbear, C., Hart, G., Goodwin, J., Mizen, H.,

June 2006. A Methodology for Building Conceptual

Domain Ontologies. Ordnance Survey Research.

Kromrey, H., 2002. Empirische Sozialforschung, Modelle

und Methoden der standardisierten Datenerhebung und

Datenauswertung. Leske + Budrich. Opladen, 10.,

vollst. überarb. Aufl.

Laurel, B., 2003. Computers as Theatre. Addison-Wesley.

Boston, 10th printing.

Noy, N. F., McGuinness, D. L., March 2001. Ontology

Development 101: A Guide to Creating Your First

Ontology. Stanford Knowledge Systems Laboratory

Technical Report KSL-01-05 and Stanford Medical

Informatics Technical Report SMI-2001-0880.

Patel-Schneider, P. F., Hayes, P., Horrocks, I., 2004. OWL

Web Ontology Language. Semantics and Abstract

Syntax. W3C Recommendation 10 February 2004.

Sester, M., von Gösseln, G., Kieler, B., 2007. Identifica-

tion and adjustment of corresponding objects in data

sets of different origin. In Proceedings of the 10th

AGILE International Conference on Geographic

Infor-mation Science 2007, Aalborg University,

Denmark.

KEOD 2010 - International Conference on Knowledge Engineering and Ontology Development

470
