SECURITY ANALYSIS OF AUTHENTICATION SCHEMES IN

M-COMMERCE BASED ON FUZZY COMPREHENSIVE

EVALUATION*

Rui Hua, Runtong Zhang and Dandan Li

Institute of Information Systems, Beijing Jiaotong University, Beijing 100044, China

Keywords: Identity authentication, M-commerce, Fuzzy comprehensive evaluation, Security analysis.

Abstract: The openness and transformation mode of the mobile network poses a serious problem of information

security in mobile commerce applications, and identity authentication is one of the main methods to solve

the problem. Along with the development of mobile commerce, considerable attentions on various identity

authentication schemes have been paid. However, there is still lack of a systematic and practical evaluation

system to evaluate these schemes. In this paper, an indicators analysis system of mobile commerce by using

the fuzzy inference approach is proposed to evaluate different mobile commerce identity authentication

schemes. Comprehensive simulation and comparsion show that the proposed indicator analysis systesm is

quantified and efficient.

This work is partially supported by the Fundamental Research Funds for the Central Universities (with contract number

2009YJS034) and the Special Funds of Beijing Jiaotong Universities (with contract number 2009JBZ011)

1 INTRODUCTION

M-commerce activities depend on wireless Internet

and mobile terminal. Based on characteristics of

wireless network, security of mobile commerce

platform has become the key problem (Minglei S,

2009). Features such as small storage, low

computational power supply and limited battery of

mobile terminal increase the difficulty to solve the

security problem of mobile platform (Kwok-Yan L,

2003). Limited to wireless networks and

characteristics of mobile terminal, developed

security system in traditional electronic commerce

cannot be directly applied in mobile business, which

brings mobile commerce a lot of dangers. Security is

a primary issue in the development of mobile

commerce, and identity authentication is the core of

entire security problem (Neuman B and Ts’T, 1994).

Identity

authentication is the use of one or more

mechanisms to prove that you are who you claim to be

(

Aloul F, 2009). In the absence of user identity

authentication, confidentiality and integrity of user's

information is of no significance. Currently, some

researchers have improved some traditional identity

authentication models for mobile environment (Oh

HG, 2009 ; Soleymani B, 2009 and Xuefei C, 2009).

These models use different key agreement method

and encryption algorithm, and each of them have

different emphases and defects. But there are only a

few of methods to evaluate these models security,

such as formal analysis method and simple

comparison. The lack of a complete and effective

security evaluation system makes the security

performance of existing models cannot be

comprehensive evaluated objectively. It becomes

more difficult for researchers and users to choose

authentication models.

According to characteristics of mobile terminal

and wireless network, we establish a scientific and

reasonable security analysis system based on mobile

commerce environment. The fuzzy comprehensive

evaluation method is used for modeling. To meet the

demand of comparing different models’ security, the

quantitative and qualitative analysis method will be

used to evaluate identity authentication models.

2 A BRIEF REVIEW

There are two mainly methods to evaluate the

245

Hua R., Zhang R. and Li D.

SECURITY ANALYSIS OF AUTHENTICATION SCHEMES IN M-COMMERCE BASED ON FUZZY COMPREHENSIVE EVALUATION.

DOI: 10.5220/0003268402450251

In Proceedings of the Twelfth International Conference on Informatics and Semiotics in Organisations (ICISO 2010), page

ISBN: 978-989-8425-26-3

security of identity authentication models. One is

formal security analysis; another one is building

security evaluation system.

Formal security analysis is a kind of methods

based on Dolev-Yao model (Hai-yan Q, 2008). This

model hypothesizes encryption is "perfect", and

attacker can intercept any text. Formal security

analysis includes strand spacer method (Javier T,

1999), BAN method (Burrows M, 1990) and

inductive approach method (Lawrence, 1998). These

methods can prove whether the identity

authentication scheme is security in ideal condition.

But actual application environments of the identity

authentication are not in ideal condition, so these

methods can prove the security of identity

authentication schemes only theoretically.

Identity authentication evaluation system can be

divided into evaluation systems for similar models

which have same authentication factor (such as

having the same authentication encryption

algorithm

or having the same authentication technology, etc.)

and evaluation systems for new models.

Identity authentication evaluation systems for

similar models comprehensively compare models’

security and performance in particular network

environment. Wei Liang (2005) and other

researchers divide analysis indictors into security

indictors and quality of service (QoS) indictors.

Based on the identity authentication data encryption,

data integrity, privacy protection and

non-repudiation, challenges / response models are

divided into four security index. By using the

method above, although boundaries clear to divide

and easy to operate, it cannot effectively compare

highly similarity identity authentication models.

Charlott E and other researchers propose identity

authentication evaluation system based on mobile

platform IP Multimedia Subsystem (IMS). The

system includes three basic parts: security,

user-friendly and simplicity and researchers point

out that three basic parts are interdependent. SWOT

analysis method, user ranking method and

simulation are used to compare different models

(Charlott E, 2009). Although this paper put forward

a complete and meticulous evaluation system, it does

not give a clear solution about how to use the system

to evaluation identity authentication models.

Patroklos G.A. (2004) and other three researchers

compare three security protocols (SSL, S/MINE and

IPSec) which are widely used in normal network

according to length of the key and time cost of

mutual authentication execution. The research closes

to reality application, but does not fit every model.

Evaluation systems for new models are

established to compare new models with similar

models, in order to indicate advantages of the new

one. Researcher Vipul Gupta (2002) proposes a new

SSL protocol based on ECC, and compares the

performance between the new protocol and SSL

protocol based on RSA. Yong-bin Zhou (2009) and

other researchers improve MAKAP protocol and

prove the security of the improved protocol as well

as compare the improved protocol with the old one

on calculate cost, communication cost and storage

cost. Zhi-qiang Xie (2009) and other researchers

propose new S/KEY authentication scheme and

compare the improved protocol with the old one on

mid-man-attack, decimal attack, secret key security

and so on. This kind of research focus on discussing

the model about it’s resistance to attack and unfit for

evaluation and comparison with other types of

authentication schemes. Most of this researches

limited in theoretical analysis and have no

quantitative evaluation results.

3 THE M-COMMERCE

SECURITY INDICATORS

EVALUATION SYSTEM

The evaluation system is established to meet mobile

commerce identity authentication schemes’

characteristics, which can reflect the characteristics

of mobile commerce properties and the effect of the

identity authentication.

Characteristics of mobile commerce mainly

embodies in three aspects: network environment,

terminal characteristics and service features. Small

bandwidth, high BER (bit error ratio) and the

opening of interface make mobile communication

network in numerous threats and these threats may

lead to different kinds of attacks. Mobile terminal

equipment has low storage capacity, battery power

specialty and its high secrecy request makes the

security of user information becoming more

important. At the same time, mobile commerce

customers generally require information immediately,

which means the immediacy of the service.

Evaluation system should be able to reflect the

characteristics of mobile commerce and make

mobile commerce identity authentication different

from identity authentication applications in common

net work environment.

Security is the most important part of identity

authentication effect. Researcher Mangipudi Kumar

V.K.N. (2005) proposes identity authentication

design framework based on the wireless network,

ICISO 2010 - International Conference on Informatics and Semiotics in Organisations

246

Table 1: M-commerce authentication security evaluation indicators system.

Target Level

First level

index

Second level index

Security

Analysis

Authentication

function

Mutual authentication U

Anonymity U

Non-repudiation U

Integrity U

Key agreement U

Multi-factor authentication U

Encryption

intensity

Theoretically decoding year U

Freshness of secret key U

Type of cryptograph U

Resistance of

attack

Type of cannot-resistance-attack U

Serious degree of cannot-resistance-attack U

and security is one of the most important factors,

which include security service and security

requirements. Security requirements indexes are

mainly about network attack, which must be satisfied

in identity authentication design. And security

services indexes, including mutual authentication,

non-repudiation etc, are optional functions in

identity authentication design.

To build a useable security evaluation system

should considerate a lot of factors. The evaluation

system can exert its effect only if the system is

established scientific and reasonable and each index

should reflect the evaluation objects. To establish a

set of perfect, rational and scientific identity

authentication model evaluation indicator system,

should follow the scientific, comprehensive,

feasibility and comparability principles. Indexes’

selection should cover all security requirements of

mobile commerce identity authentication. Besides,

indexes’ selection should avoid index correlate with

others at the same time, in order to keep eventually

evaluation result in a high quality. Otherwise,

identity authentication technology is an actual

operation process, so the evaluation index should be

convenient to get information and possible to

quantify information. This paper establishes mobile

commerce authentication security evaluation

indicators system shown in Table 1.

According to the traditional electronic commerce

security problems and mobile commerce’s

characteristics, mobile commerce security should

include mobile terminal security (Youqing G, 2005),

wireless network security, mutual authentication and

non-repudiation (Jiayuan L, 2006) four requirements.

According to the above requirements, evaluation

system is determined in Table 1. Authentication

function is an index set to assess schemes’ security

function, so indexes cannot be quantitative evaluated.

So a modeling method is introduced to quantization

the evaluation result.

4 MODELING BASED ON FUZZY

COMPREHENSIVE

EVALUATION

Fuzzy comprehensive evaluation method is an

important branch of the theory of fuzzy mathematics.

It has been widely used in economics, management,

environment, education and other fields. With the

social, economic development and complexity of

issues people consider, uncertainty and ambiguity of

the human mind has been strengthening, which

makes it very difficult for us to make an objective

evaluation. Fuzzy comprehensive evaluation method

as a solution of the problem is receiving more and

more attentions (Zeshui X, 2001).

Authentication technology is a very complex

issue. Variety of factors can impact the effect of

authentication and their impact on the way and size

are both different and vague. Fuzzy comprehensive

evaluation method is more objective on reflection

the ambiguity of the role of these effects and thus is

more scientific and feasible. Specific steps are as

follows:

The first step, determine the factor set

The factor set is divided into the target level

the first level evaluation factors

and the

second-level evaluation factors

Uim



0,,

) U... U, U,(UU

321

nmi

imiiii

SECURITY ANALYSIS OF AUTHENTICATION SCHEMES IN M-COMMERCE BASED ON FUZZY

COMPREHENSIVE EVALUATION

247

Table 2: M-commerce authentication security evaluation criterion.

Target level

First level

index

Second level index

Possible

result

Optimal

result

Security

analysis

Authentication

function

Mutual authentication U

Yes/No

Yes

Anonymity U

Yes/No

Yes

Non-repudiation U

Yes/No

Yes

Integrity U

Yes/No

Yes

Key agreement U

Yes/No

Yes

Multi-factor authentication U

Yes/No

Yes

Encryption

intensity

Theoretically decoding year U

∞

Freshness of secret key U

Fresh/not

fresh

Fresh

Type of cryptograph U

∞

Resistance of

attack

Type of cannot-resistance-attack U

∞

Serious degree of cannot-resistance-attack U

Serious/not

serious

Not serious

Determined three-level fuzzy comprehensive

evaluation criteria are shown in Table 2.

The second step, determine the reviews set

. By

reference to fuzzy comprehensive evaluation method

application examples in other areas, this paper

reviews set

}V ...V ,V ,{VV 321 n=

= (Excellent,

Good, General, Poor, Terrible). The optimal result or

the compared optimal result will be the criterion of

mark. Indexes which can not be quantitative

evaluated will be marked according to the number of

possible values and five levels as shown in Table 3.

Table 3: Evaluation set description.

Evaluation

level

Reference Note

Excellent

Fully in line with index for evaluation criteria

Good

In line with the vast majority of index,

criteria, only the individual projects failed to

meet the index

General

Basically in line with targets, criteria, does

not meet the requirements of the less

Poor

Basically does not meet the targets, criteria,

does not meet the requirements of the more

Terrible

The vast majority of judges do not meet

targets, and only be able to meet the

requirements of individual projects

The third step, determine the evaluation factors

known to the weight vector

. Weight vector,

which relative with factors set, is used to display the

weight of each factor's value. Weight vector can be

divided into three levels according to factor set. All

levels of the weight vector can be expressed as

∑

=≥

1w 0,w

) w... w, w,(wW

321

For the establishment of mobile commerce

authentication evaluation system, expert scoring

method is used to get the initial data. We invite 10

experts for this research. Each questionnaire has

been filled independently. Table 4 shows 10 experts’

scoring statistics result of factors’ weight.

The fourth step, determine fuzzy relationship

matrix R. According to the scoring result of 3rd level

factors of 10 experts, fuzzy relationship matrix

imR

will be calculated as follows.

)(

)

5,4,3,2,1

54321

imimimimim

rrrrr

kkkkk

Using the same method, a particular mobile

commerce authentication model’s final fuzzy

relationship matrix can be obtained.

The fifth step, determine fuzzy transformation

method. Obtained the results of comprehensive

evaluation through calculate

RW D



)b ,...,b ,b,(b

) w... w, w,(w

321

54321

2524232221

1514131211

321

mmmmm

rrrrr

⎟

⎠

⎞

⎜

⎝

⎛

#####

(1)

The sixth step, calculate the final evaluation

result.

∑

•==

xx cbCBT D

(2)

ICISO 2010 - International Conference on Informatics and Semiotics in Organisations

248

Table 4: Evaluation index weight result.

Target

level

First level

index

Score/

Weight

Second level index Score/Weight

Security

analysis

Authentication

function

(0.32)

Mutual authentication U

53 (0.26)

Anonymity U

32 (0.15)

Non-repudiation U

35 (0.17)

Integrity U

45 (0.21)

Key agreement U

32 (0.15)

Multi-factor authentication

13 (0.06)

Encryption

intensity

(0.32)

Theoretically decoding year

23 (0.38)

Freshness of secret key U

23 (0.38)

Type of cryptograph U

14 (0.24)

Resistance of

attack

(0.36)

Type of

cannot-resistance-attack U

17 (0.57)

Serious degree of

cannot-resistance-attack U

13 (0.43)

5 AN ILLUSTRATIVE EXAMPLE

In this paper, we will use mobile commerce

authentication scheme based on OTP as an example

to begin illustrative example.

In this paper, we will use mobile commerce

authentication scheme based on OTP as an example

to begin illustrative example.

The main idea of OTP is to add indefinite factors

during the course of logging in and compress it to a

length definite digest, and then make the digest viz.

password used each time different to improve

security. The OTP based schemes have two common

advantages. One is the password is different each

time when logging in and therefore the adversary

capture cannot guess the password. Second is that all

of the schemes are using of hash function to produce

OTP. If the input information changes a little, the

output information would change a lot. Therefore,

this character can resist the probability that the

password would be juggled.

Two-dimension bar code is a kind of high density

bar code. It can record much information limited in a

small districts and itself is an integrated data file.

There are two common used two-dimension bar

codes. One is the stack bar code, such as PDF417...

Code49. The other is matrix bar code, such as Maxi

Code... Code1, etc.

For the problems of existed schemes and the

features of two-dimension bar code, a new OTP

scheme based on two dimension bar code is

proposed (Mu Yang, 2008). This new scheme

absorbed the advantages of the existed schemes; it

adopts the high security function-hash function. The

password is changed every time. The secret

password does not transmit directly in the network

and it also does not preserve directly in the server's

database.

In the new scheme, we take IMEI (International

Mobile Equipment Identity Number, IMEI) , and the

specific identity of mobile equipment, as an

important factor of authentication. This new scheme

takes the indefinite factor-Counter and the mobile

identity-lMEI or the service identity-Serl to generate

OTP. And then take advantages of two-dimension

bar code to cipher the authentication information

twice. Details about the new mobile commerce

authentication scheme will be got from the paper

written by Mu Yang in the reference.

The evaluation system factor set, evaluation set

and weight of each factor have been confirmed

above, so here start illustrative example from Step 4.

10 experts’ scoring statistics results as shown in

Table 5.

According to the formula (1), security evaluation

process and the results are as follows.

According to the formula (2), calculate the final

evaluation result as follows.



()

8.382208.3

048.00384.035072.016928.03936.0

CBT

≈

⎥

⎦

⎤

⎢

⎣

⎡

The evaluation result is close to four,

so the security evaluation result of mobile

SECURITY ANALYSIS OF AUTHENTICATION SCHEMES IN M-COMMERCE BASED ON FUZZY

COMPREHENSIVE EVALUATION

249

Table 5: OTP authentication scheme security score.

Target

level

First level

index

Second level index

Membership grade

Security

analysis

Authentication

function

Mutual authentication U

1.00

Anonymity U

1.00

Non-repudiation U

1.00

Integrity U

1.00

Key agreement U

1.00

Multi-factor authentication U

1.00

Encryption

intensity

Theoretically decoding year U

0.80 0.20

Freshness of secret key U

1.00

Type of cryptograph U

0.50 0.50

Resistance of

attack

Type of cannot-resistance-attack U

0.20 0.80

Serious degree of cannot-resistance-attack U

0.20 0.80

()

048.00384.035072.016928.03936.0

0080.020.00

012.0196.0304.038.0

15.000085.0

36.032.032.0

RWB

0080.020.00

RWB

012.0196.0304.038.0

RWB

15.000085.0

00000.1

000000.1

00.10000

000000.1

06.015.021.017.015.026.0

333

222

111

⎥

⎦

⎤

⎢

⎣

⎡

⎥

⎦

⎤

⎢

⎣

⎡

commerce authentication scheme based on OTP is

close to "good" category.

6 CONCLUSIONS

According to the characteristics of mobile commerce,

this paper establishes mobile commerce

authentication security evaluation index system. This

system involves 11 specific indexes which basically

have no interrelated problems. On the basis of

evaluation index system, this paper use the method

of fuzzy comprehensive evaluation to build

evaluation model, and further to assess a mobile

commerce authentication scheme based on OTP as

an illustrative example.

Using the fuzzy comprehensive evaluation

method to study the authentication problem in

mobile commerce could theoretically consider all the

factors and make research more reasonable. Factors’

weights and membership adopts expert scoring.

Although each expert scoring also has certain

subjective, but from all the experts overall it can

reflect the objective and scientific.

As mobile commerce authentication security

involving many factors, some indexes can not be

quantitative evaluated yet and the selection of index

will be further discussed. Each index’s weight need

ICISO 2010 - International Conference on Informatics and Semiotics in Organisations

250

to be further optimized and researched, in order to

meet objective requirement of evaluation.

REFERENCES

Minglei S, Chengxiang T, Haihang W. Mobile

authentication scheme using SMS.

2009 IITA

International Conference on Services Science,

Management and Engineering

, 2009: 161–164.

Kwok-Yan L, Siu-Leung C, Ming G, Jia-Guang S.

Lightweight security for mobile commerce

transactions.

Computer Communications, 2003, 26:

2052-2060.

Neuman B, Ts’T. Kerberos: Authentication service for

computer networks.

IEEE Communication Magazine,

1994, 32(9): 33-38.

Aloul F, Zahidi S, El-Hajj W. Two factor authentication

using mobile phones,

IEEE/ACS International

Conference on Computer Systems and Applications

2009, 5: 641-644.

Oh HG, Kang SY, Seo JT, Lee IY, Moon J. Study on a

safe and efficient mOTP (mobile-OTP) authentication

mechanism for the mobile environment.

Journal of

Internet Technology, 2009, 10(5): 521-531.

Soleymani B, Maheswaran M. Social Authentication

Protocol for Mobile Phones.

CSE’ 09 International

Conference on Computational Science and

Engineering

, 2009, 8: 436–441.

Xuefei C, Xingwen Z, Weidong K, Liangbing H.

Identity-based anonymous remote authentication for

value-added services in mobile networks.

Vehicular

Technology, IEEE Transactions, 2009, 58(7):

3508–3517.

Hai-yan Q. Compairing the inductive method and strand

spaces for security protocol.

Verification Journal of

Computer Research and Development, 2008,

45(Suppl.): 137-142 (in Chinese).

Javier Thayer Fdbrega F, Jonathan Hermg C, Joshua

Guttman D. Strand spacers: Proving security protocols

correct [J].

Journal of Computer Security, 1999, 7(2-3):

191-230.

Burrows M, Abadi M, Needham R. A Logic of

Authentication [J].

ACM Trans on Computer Systems,

1990, 8(1): 18-36.

Lawrence Paulson C. The inductive approach to verifying

cryptographic protocols.

Journal of Computer Security,

1998, 6(2): 85-128.

Wei L, Wenye W. On performance analysis of

challenge/response based authentication in wireless

networks.

Computer Networks, 2005, 48: 267-288.

Charlott E, Markus F, Ivar J. A criteria-based evaluation

framework for authentication schemes in IMS.

ARES

'09. International Conference on Availability,

Reliability and Security

, 2009, 3: 865-869.

Patroklos Argyroudis G, Raja V, Hitesh T, Donal

O’Mahony. Performance analysis of cryptographic

protocols on handheld devices.

Third IEEE

International Symposium on Network Computing and

Applications, 2004: 169 – 174.

Vipul G, Sumit G, Sheueling C, Douglas S. Performance

analysis of elliptic curve cryptography for SSL.

ACM

Workshop on Wireless Security, 2002: 87-94.

Yong-bin Z, Zhen-feng Z, Guo-deng D. Analysis and

Improvement of a Security-Provable Mutually

Authenticated Key Agreement Protocol.

Journal of

Software, 2006,4(17): 868-875 (in Chinese).

Zhi-qiang X, Jun G, Jing Y. Analysis and design of new

S/KEY authorization solution.

Computer engineering,

2009 35(5): 175-176, 193 (in Chinese).

Kumar V.K.N. Mangipudi. New authentication and key

agreement protocols for wireless applications

[Graduate],

North Dakota State University, 2005.

You-qing G, Xiao-jun W, Xiao-yan D. Electronic

commerce security technology.

Beijing: Beijing

university of posts an telecommunications press, 2005

(in Chinese).

Jia-yuan L. Enaluation model based on status

authentication system.

Computer knowledge and

technology

, 2006, 7: 51-52, 57 (in Chinese).

Ze-shui X, Zhen-jun Y. Tow algorithms for fuzzy

synthetic judgment.

Journal of PLA university of

science and technology (Natural science edition)

, 2001,

2(4):5-8 (in Chinese).

Yang M, Runtong Z, Qin W, New Authentication Scheme

for M-Commerce Based on Two Dimension Bar Code.

IEEE International Conference on Service Operations

and Logistics, and Informatics, 2008: 1029-1034.

SECURITY ANALYSIS OF AUTHENTICATION SCHEMES IN M-COMMERCE BASED ON FUZZY

COMPREHENSIVE EVALUATION

251
