A CONTINUOS LEARNING FOR A FACE RECOGNITION

SYSTEM

Aldo F. Dragoni, Germano Vallesi and Paola Baldassarri

Department of Ingegneria Informatica, Gestionale e dell’Automazione (DIIGA)

Università Politecnica delle Marche, Via Breccebianche, Ancona, Italy

Keywords: Hybrid system, Neural networks, Bayesian conditioning, Face recognition.

Abstract: A system of Multiple Neural Networks has been proposed to solve the face recognition problem. Our idea is

that a set of expert networks specialized to recognize specific parts of face are better than a single network.

This is because a single network could no longer be able to correctly recognize the subject when some

characteristics partially change. For this purpose we assume that each network has a reliability factor

defined as the probability that the network is giving the desired output. In case of conflicts between the

outputs of the networks the reliability factor can be dynamically re-evaluated on the base of the Bayes Rule.

The new reliabilities will be used to establish who is the subject. Moreover the network disagreed with the

group and specialized to recognize the changed characteristic of the subject will be retrained and then forced

to correctly recognize the subject. Then the system is subjected to continuous learning.

1 INTRODUCTION

Several researches indicate that some complex

recognition problems cannot be effectively solved

by a single neural network but by “Multiple Neural

Networks” systems (Shields, 2008). The idea is to

decompose a large problem into a number of

subproblems and then to combine the sub-solutions

into the global one. Normally independent modules

are domain specific and have specialized

computational architectures to recognize certain

subsets of the overall task (Li, 2007). In this work,

for a face recognition problem we use a system

consisted of multiple neural networks and then we

propose a model for detecting and solving eventual

contradictions into the global outcome. Each neural

network is trained to recognize a significant region

of the face and is assigned an arbitrary a-priori

degree of reliability. This reliability factor can be

dynamically re-evaluated on basis of the Bayesian

Rule after that contradictions eventually arise. The

conflicts depend on the fact that there may be no

global agreement about the recognized subject, may

be for s/he changed some features of her/his face.

The new vector of reliability obtained through the

Bayes Rule will be used for making the final choice,

by applying the “Inclusion based” algorithm or

another “Weighted” algorithm over all the

maximally consistent subsets of the global output.

Networks that do not agree with this choice are

required to retrain themselves automatically on the

basis of the recognized subject. In this way, the

system should be able to follow the changes of the

faces of the subjects, while continuing to recognize

them even after many years thanks to this

continuous process of self training.

2 BELIEF REVISION

In this section we introduce some theoretical

background from Belief Revision (BR) field. Belief

Revision occurs when a new piece of information

inconsistent with the present belief set is added in

order to produce a new consistent belief system

(Gärdenfors, 2003).

In Figure 1, we see a Knowledge Base (KB)

which contains two pieces of information: the

information α, which comes from source V, and the

rule “If α, then not β” that comes from source T.

Unfortunately, another piece of information β,

produced by the source U, is coming, causing a

conflict in KB. To solve it we find all the

“maximally consistent subsets”, called Goods, inside

the inconsistent KB, and we choose one of them as

the most believable one. In our case (Figure 1) there

541

Dragoni A., Vallesi G. and Baldassarri P..

A CONTINUOS LEARNING FOR A FACE RECOGNITION SYSTEM.

DOI: 10.5220/0003133805410544

In Proceedings of the 3rd International Conference on Agents and Artiﬁcial Intelligence (ICAART-2011), pages 541-544

ISBN: 978-989-8425-40-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

are three Goods: {α, β}; {β, α →¬β}; {α, α→¬β}.

Maximally consistent subsets (Goods) and

minimally inconsistent subsets (Nogoods) are dual

notions. Each source of information is associated

with an a-priori “degree of reliability”, which is

intended as the a-priori probability that the source

provides correct information.

Figure 1: Belief Revision mechanism.

In case of conflicts the “degree of reliability” of

the involved sources should decrease after

“Bayesian Conditioning” which is obtained as

follows. Let S = {s

, ..., s

} be the set of the sources,

each source s

is associated with an a-priori

reliability R(s

). Let



be an element of 2

. If the

sources are independent, the probability that only the

sources belonging to the subset



 S are reliable

is:

() ( )* (1 ( ))

Rs Rs











(1)

This combined reliability can be calculated for any



providing that:

() 1









(2)

Of course, if the sources belonging to a certain



give incompatible information, then R(



) must be

zero. Having already found all the Nogoods, what

we have to do is:

 Summing up into R

Contradictory

the a-priori reliability

 Putting at zero the reliabilities of all the

contradictory sets, which are the Nogoods and their

supersets

 Dividing the reliability of all the other (no-

contradictory) set of sources by 1 − R

Contradictory

The last step assures that the constrain (2) is still

satisfied and it is well known as “Bayesian

Conditioning”. The revised reliability NR(s

) of a

source s

is the sum of the reliabilities of the

elements of 2

that contain s

. If a source has been

involved in some contradictions, then NR(s

) ≤ R(s

otherwise NR(s

) = R(s

The new “degrees of reliability” will be used for

choosing the most credible Goods as the one

suggested by “the most reliable sources”. There are

three algorithms to perform this task

1. Inclusion based (IB) Algorithm select all the

Goods which contains information provided by the

most reliable source.

2. Inclusion based weighted (IBW) is a variation of

IB: each Good is associated with a weight derived

from the sum of Euclidean distances between the

neurons of the networks. If IB select more than one

Good, then IBW selects as winner the Good with a

lower weight.

3. Weighted algorithm (WA) combines the a-

posteriori reliability of each network with the order

of the answers provided. Each answer has a weight

1n where





n1;N represents its position among

the N responses.

3 FACE RECOGNITION SYSTEM

To solve the face recognition problem (Tolba, 2006),

in the present work a number of independent

recognition modules, such as neural networks, are

specialized to respond to individual template of the

face. We apply the Belief Revision method to the

problem of recognizing faces by means of a

“Multiple Neural Networks” system. We use four

neural nets specialized to perform a specific task:

eyes (E), nose (N), mouth (M) and, finally, hair (H)

recognition. Their outputs are the recognized

subjects, and conflicts are simple disagreements

regarding the subject recognized. As an example,

let’s suppose that during the testing phase, the

system has to recognize the face of four persons:

Andrea (A), Franco (F), Lucia (L) and Paolo (P),

and that, after the testing phase, the outputs of the

networks are as follows: E gives as output “A or F”,

N gives “A or P”, M gives “L or P” and H gives “L

or A”, so the 4 networks do not globally agree.

Starting from an undifferentiated a-priori reliability

factor of 0.9, and applying the method described in

the previous section we get the following new

degrees of reliability for each network: NR(E) =

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

542

0.7684, NR(N) = 0.8375, NR(M) = 0.1459 and

NR(H)=0.8375. The networks N and H have the

same reliability, and by applying a selection

algorithm it turns out that the most credible Goods is

{E,N,H}, which corresponds to Andrea. So Andrea

is the response of the system.

Figure 2: Schematic representation of the Face

Recognition.

Figure 2 shows a schematic representation of this

Face Recognition System (FRS). Which is able to

recognize the most probable individual even in

presence of serious conflicts among the outputs of

the various nets.

4 A NEVER-ENDING LEARNING

Back to the example in Section III, let’s suppose that

the network M is not able to recognize Andrea from

is mouth. There can be two reasons for the fault of

M: either the task of recognizing any mouth is

objectively harder, or Andrea could have recently

changed the shape of his mouth (perhaps because of

the grown of a goatee or moustaches). The second

case is interesting because it shows how our FRS

could be useful for coping with dynamic changes in

the features of the subjects. In such a dynamic

environment, where the input pattern partially

changes, some neural networks could no longer be

able to recognize them. So, we force each faulting

network to re-train itself on the basis of the

recognition made by the overall group. On the basis

of the a-posteriori reliability and of the Goods, our

idea is to automatically re-train the networks that did

not agree with the others, in order to “correctly”

recognize the changed face. Each iteration of the

cycle applies Bayesian conditioning to the a-priori

“degrees of reliability” producing an a-posteriori

vector of reliability. To take into account the history

of the responses that came from each network, we

maintain an “average vectors of reliability”

produced at each recognition, always starting from

the a-priori degrees of reliability. This average

vector will be given as input to the two algorithms,

IBW and WA, instead of the a-posteriori vector of

reliability produced in the current recognition. In

other words, the difference with respect to the BR

mechanism described in Section II is that we do not

give an a-posteriori vector of reliability to the two

algorithms (IBW and WA), but the average vector of

reliability calculated since the FRS started to work

with that set of subjects to recognize. With this

feedback, our FRS performs a continuous learning

phase adapting itself to partial continuous changes of

the individuals in the population to be recognized.

5 EXPERIMENTAL RESULTS

This section shows only partial results: those

obtained without the feedback, discussed in the

previous section. In this work we compared two

groups of neural networks: the first consisting of

four networks and the second with five (the

additional network is obtained by separating the eyes

in two distinctive networks). All the networks are

LVQ 2.1, a variation of Kohonen’s LVQ (Kohonen,

1995), each one specialized to respond to individual

template of the face.

The Training Set is composed of 20 subjects

(taken from FERET database (Philips, 1998)), for

each one 4 pictures were taken for a total of 80.

Networks were trained, during the learning phase,

with three different epochs: 3000, 4000 and 5000.

To find Goods and Nogoods, from the networks

responses we use two methods:

1. Static method: the cardinality of the response

provided by each net is fixed a priori. We choose

values from 1 to 5, 1 meaning the most probable

individual, while 5 meaning the most five probable

subjects

2. Dynamic method: the cardinality of the response

provided by each net changes dynamically according

to the minimum number of “desired” Goods to be

searched among. In other words, we set the number

of desired Goods and reduce the cardinality of the

response (from 5 down to 1) till we eventually reach

that number (of course, if all the nets agree in their

first name there will be only one Goods).

In the next step we applied the Bayesian

conditioning (Dragoni, 1997), on the Nogoods

obtained with the two previous techniques, obtaining

an a-posteriori vector of reliability. These new

“degrees of reliability” will be used for choosing the

most credible Good (i.e. the name of subject). To

test our work, we have taken 488 different images of

the 20 subjects and with these images we have

created two Test Set. Figure 3 reports the rate of

correct recognition for the two Test Set, with the

Static and Dynamic methods. It shows also, how

WA is better than IBW for all four cases in both

A CONTINUOS LEARNING FOR A FACE RECOGNITION SYSTEM

543

tests. The best solution for WA is achieved with five

neural networks and 5000 epochs in both the

methods (Static and Dynamic) and the Test Set.

Figure 3: Rate of correct recognition with either Test Set.

Figure 4 shows the average values of correct

recognition in either Test Set of WA with 5000

epochs obtained by the two methods. These results

show how the union of the Dynamic method with

the WA and five neural networks gives the best

solution to reach a 79.39% correct recognition rate

of the subjects. The same Figure also shows as using

only one LVQ network for the entire face, we obtain

the worst result. In other words, if we consider a

single neural network to recognize the face, rather

one for the nose and so on, we have the lowest rate

of recognition equals to 66%. This is because a

single change in one part of the face makes the

whole image not recognizable to a single network,

unlike the hybrid system.

6 CONCLUSIONS

Our hybrid method integrates multiple neural

networks with a symbolic approach to Belief

Revision to deal with pattern recognition problems

that require the cooperation of multiple neural

networks specialized on different topics. We tested

this hybrid method with a face recognition problem,

training each net on a specific region of the face:

eyes, nose, mouth, and hair. Every output unit is

associated with one of the persons to be recognized.

Each net gives the same number of outputs. We

consider a constrained environment in which the

image of the face is always frontal, lighting

conditions, scaling and rotation of the face being the

same. We accommodated the test so that changes of

the faces are partial, for example the mouth and hair

do not change simultaneously, but one at a time.

Under this assumption of limited changes, our

hybrid system ensures great robustness to the

recognition. When the subject partially changes its

appearance, the network responsible for the

recognition of the modified region comes into

conflict with other networks and its degree of

reliability will suffer a sharp decrease. The networks

that do not agree with the choice made by the overall

group will be forced to re-train themselves on the

basis of the global output. So, the overall system is

engaged in a never ending loop of testing and re-

training that makes it able to cope with dynamic

partial changes in the features of the subjects.

Figure 4: Average rate of correct recognition with either

Test Set and the results obtained using only one network

for the entire face.

REFERENCES

Shields, M. W., Casey, M. C., 2008. A theoretical

framework for multiple neural network systems.

Neurocomputing, vol. 71, pp. 1462–1476.

Li, Y., Zhang, D., 2007. Modular neural networks and

their applications in biometrics. Trends in Neural

Computation, vol. 35, pp. 337–365.

Gärdenfors, P., 2003. Belief Revision, Cambridge Tracts

in Theoretical Computer Science, vol. 29.

Tolba, A. S., El-Baz, A. H., El-Harby, A. A., 2006. Face

recognition a literature review, International Journal

of Signal Processing, vol. 2, pp. 88–103.

Kohonen, T., 1995. Learning vector quantization, in Self-

Organising Maps, Springer Series in Information

Sciences. Berlin, Heidelberg, New York: Springer-

Verlag, 3rd ed.

Philips, P. J., Wechsler, H., Huang, J. Rauss, P., 1998. The

FERET Database and Evaluation Procedure for Face-

Recognition Algorithms. Image and Vision Computing

J., vol. 16, no. 5, pp: 295-306.

Dragoni, A. F., 1997. Belief revision: from theory to

practice. The Knowledge Engineering Review, vol. 12,

no. 2, pp:147-179.

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

544
