SHARED UNDERSTANDING AND SYNCHRONY EMERGENCE

Synchrony as an Indice of the Exchange of Meaning between Dialog Partners

Ken Prepin and Catherine Pelachaud

LTCI/TSI, Telecom-ParisTech/CNRS, 37-39 rue Dareau, 75014, Paris, France

Keywords:

Synchrony, Shared understanding, Coupled oscillators, Dynamical systems, Inter-subjectivity.

Abstract:

Synchrony is claimed by psychology as a crucial parameter of any social interaction. In dialog interactions, the

synchrony between non-verbal behaviours of interactants is claimed to account for the quality of the interac-

tion: to give to human a feeling of natural interaction, an agent must be able to synchronise on appropriate time.

The synchronisation occurring during non-verbal iteractions has recently been modelised as a phenonomenon

emerging from the coupling between interactants. We propose here, and test in simulation, a dynamical model

of verbal communication which links the emergence of synchrony between non-verbal behaviours to the level

of meaning exchanged through words by interactants: if partners of a dyad understand each other, synchrony

emerges, whereas if they do not understand, synchrony is disrupted. In addition to retrieve the fact that syn-

chrony emergence within a dyad of agents depends on their level of shared understanding, our tests pointed

two noteworthy properties of synchronisation phenomenons: ﬁrst, as well as synchrony accounts for mutual

understanding and good interaction, di-synchrony accounts for misunderstanding; second, synchronisation

and di-synchronisation emerging from mutual understanding are very quick phenomenons.

1 INTRODUCTION

When we design agents capable of being involved in

verbal exchange, with humans or with other agents,

it is clear that the interaction cannot be reduced to

speech. When an interaction takes place between two

partners, it comes with many non-verbal behaviours

that are often described by their type such as smiles,

gaze at the other, speech pauses, head nod, head

shake, raise eyebrows, mimicry of posture and so on

(Kendon, 1990; Yngve, 1970). But another aspect of

these non-verbal behaviours is their timing according

to the partner’s behaviours.

In 1966, Condon and Ogston’s annotations of interac-

tions have suggested that there are temporal correla-

tions between the behaviours of two person engaged

in a discussion (Condon and Ogston, 1966): micro

analysis of discussion videotaped conduces Condon

to deﬁne in 1976 the notions of auto-synchrony (syn-

chrony between the different modalities of an individ-

ual) and hetero-synchrony (synchrony between part-

ners).

Since Condon et al.’s ﬁndings, synchronisationbe-

tween interactants has been investigated in both be-

havioural studies and cerebral activity studies. These

studies tend to show that when people interact to-

gether, their synchronisation is tightly linked to the

quality of their communication: they synchronise if

they managed to exchange and share information;

synchronisation is directly linked to their friendship,

afﬁliation and mutual satisfaction of expectations.

In developmental psychology, generations of pro-

tocols have been created, from the “still face” (Tron-

ick et al., 1978) to the “double video” (Murray

and Trevarthen, 1985; Nadel and Tremblay-Leveau,

1999), in order to stress the crucial role of synchroni-

sation during mother-infant interactions.

Behavioural and cerebral imaging studies show

that oblivious synchrony and mimics of facial expres-

sions (Chammat et al., 2010; Dubal et al., 2010) are

involved in the emergence of a shared emotion as in

emotion contagion (Hatﬁeld et al., 1993).

In social psychology, in teacher-student interac-

tion or in group interactions, synchrony between

behaviours occurring during verbal communication

has been shown to reﬂect the rapports (relationship

and intersubjectivity) within the groups or the dyads

(Bernieri, 1988; LaFrance, 1979).

The very same results have been found for human-

machine interactions: on one hand synchrony of non-

verbal behaviour improves the comfort of the human

and her/his feeling of sharing with the machine (ei-

Prepin K. and Pelachaud C..

SHARED UNDERSTANDING AND SYNCHRONY EMERGENCE - Synchrony as an Indice of the Exchange of Meaning between Dialog Partners.

DOI: 10.5220/0003140600250034

In Proceedings of the 3rd International Conference on Agents and Artiﬁcial Intelligence (ICAART-2011), pages 25-34

ISBN: 978-989-8425-41-6

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

ther a robot or a virtual agent) (Poggi and Pelachaud,

2000) and on the other hand, the human sponta-

neously synchronises during interaction with a ma-

chine when her/his expectations are satisﬁed by the

machine (Prepin and Gaussier, 2010).

In the case of non-verbal interactions, the phe-

nomenon of synchronisation between two partners

has recently been investigated as a phenomenon

emerging from the dynamical coupling of interac-

tants: that is to say a phenomenon whose description

and dynamics are not explicited in each of the partners

but appear when the interactants are put together and

when the new dynamical system they form is more

complex and richer than the simple sum of partners

dynamics.

In mother-infant interactions via the “double-

video” design cited above, synchrony is shown to

emerge from the mutual engagement of mother and

infant in the interaction (Mertan et al., 1993; Nadel

and Tremblay-Leveau, 1999). In adult-adult interac-

tions mediated by a technological device, synchrony

and coupling between partners has been shown to

emerge from the mutual attempt to interact with the

other in both behavioral studies (Auvray et al., 2009)

and cerebral activity studies (Dumas et al., 2010).

These descriptionsof synchronyas emerging from

the coupling between interactants, are consistent with

the fact cited before, that synchrony reﬂects the qual-

ity of the interaction. Given interactants, both the

quality of their interaction and the degree of their cou-

pling are tightly linked to the amount of information

they exchange and share: high coupling involves both

synchrony and good quality interaction; synchrony

and quality of the interaction are covarying indices

of the interaction. That makes the synchrony parame-

ter particularly crucial: on one hand it carries dyadic

information, concerning the quality of the ongoing in-

teraction; on the other hand it can be retrieved by each

partner of the interaction, comparing its own actions

to its perceptions of the other (Prepin and Gaussier,

2010).

The emergence of synchrony during non-verbal

interaction has been modelled by both robotics imple-

mentation (Prepin and Revel, 2007) and virtual agent

coupling (Paolo et al., 2008).

In the robotic experiment, two robots controlled

by neural oscillators are coupled together by the way

of their mutual inﬂuence: turn-taking and synchrony

emerge (Prepin and Revel, 2007).

In the virtual agent experiment, Evolutionary

Robotics was used to design a dyad of agents able to

favour cross-perception situation; the result obtained

is a dyad of agents with oscillatory behaviours which

share a stable state of both cross perception and syn-

chrony (Paolo et al., 2008).

The stability of these states of cross-perception

and synchrony is a direct consequence of the recip-

rocal inﬂuence between the agents.

We have seen there that literature stresses two

main results concerning synchrony. First, synchrony

of non-verbal behaviours during verbal-interactions

is a necessary element for a good interaction to take

place: synchrony reﬂects the quality of the interac-

tion. Second, synchrony has been described and mod-

elled as a phenomenon emerging from the dynamical

coupling between agents during non-verbal interac-

tions. In this paper, we propose to conciliate these

two results in a model of synchrony emergence dur-

ing verbal interactions.

We propose and test in simulation a model of ver-

bal communication which links the emergence of syn-

chrony of non-verbal behaviours to the level of shared

information between interactants: if partners under-

stand each other, synchrony will arise, and conversely

if they do not understand each other enough, syn-

chrony could not arise. By constructing this model of

agents able to interact as humans do, on the basis of

psychology, neuro-imaging and modelisation results,

that are both the understanding of humans and the be-

lievability of artifacts (e.g. virtual humans) which are

assessed.

In Section 2 we describe the architecture principle

and show how a level of understanding can be linked

to non-verbal behaviours. In Section 3, we test this

architecture, i.e. we test in simulation a dyad of archi-

tectures which interact together. We characterise the

conditions of emergence of coupling and synchrony

between the two virtual agents. Finally, in Section 4,

we discuss these results and their outcomes.

2 MODEL PRINCIPLE

We propose a model accounting for the emergence of

synchrony depending directly on a shared level of un-

derstanding between agents. This model is based on

the four next properties of humans’ interactions:

P1. To emit or receive a discourse modify the internal

state of the agent (Scherer and Delplanque, 2009).

P2. Non-verbal behaviours reﬂect the internal states

(Matsumoto and Willingham, 2009).

P3. Humans are particularly sensitive to synchrony,

as a cue of the interaction quality and and the mu-

tual understanding between participants (Ducan,

1972; Poggi and Pelachaud, 2000; Prepin and

Gaussier, 2010).

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

P4. Synchrony can be modelled as a phenomenon

emerging from the dynamical coupling of agents

(Prepin and Revel, 2007; Paolo et al., 2008; Au-

vray et al., 2009)

The model of agent we propose in the present sec-

tion is implemented in Section 3 as a Neural Network

(NN). Groups of neurons are vectors of variables rep-

resented by capital letters (e.g. V

Input

∈ [−1,1]

and

S ∈ [−1, 1]

) and the weights matrices which mod-

ulate the links between these groups are represented

by lower case letters (e.g. u ∈ [−1,1]

m×n

): we ob-

tain equations such as u·V

Input

= S. For sake of sim-

plicity, in both the description of the model principle

(this section) and in its implementation and tests (Sec-

tion 3) groups of neurons and weights matrices are

reduced to single numerical variables (∈ [−1,1]).

In the next two subsections, we model the two ﬁrst

properties, P1 and P2. We describe how the non-

verbal behaviour can be linked to a level of mutual

understanding. Then, in the subsections 2.3 and 2.4,

we describe how this will give to a dyad of agents

coupling capabilities. That constitute the modelling

of the third and fourth properties, P3 and P4.

2.1 Speak and Listen Modiﬁes Internal

State

Let us consider a dyad of agents, Agent1 and Agent2.

Each agent’s state is represented by one single vari-

able, S

for Agent1 and S

for Agent2 (∈ [−1,1]).

Now, let us consider the speech produced by each

agent, the verbal signal V

Act i

(∈ {0,1}), and the

speech heard by each agent, the perceivedsignalV

Per i

(∈ {0,1}).

P1 claims that each agent, either listener or

speaker, has its internal state S

modiﬁed by verbal

signals: the listener’s internal state is modiﬁed by

what it hears, and the speaker’s internal state is mod-

iﬁed by what it says. Two “level of understanding”,

the weights u

and u

′

, are deﬁned for each agent of

the dyad. u

modulates the perceived verbal signal

Per i

, and u

′

modulates the produced verbal signal

Act i

(see ﬁg.1). To model interaction in more natural

settings these u

parameters should be inﬂuenced by

many variables, such as the context of the interaction

(discussion topic, relation-ship between interactants),

the agents moods and personalities. However in the

present model we combine all these parameters in the

single variable u

(∈ [−1,1]). The choice of the values

of u

and u

is arbitrary near 0.01: it enables a well

balanced sampling of the oscillators’ activations, the

period last around 100 time steps; the other parame-

ters of the architecture are chosen depending on this

one so as not to modify the whole systems dynamics.

Agent2

Agent1

Per1

Act1

′

Per2

Act2

′

Figure 1: Verbal perception,V

Per i

, and verbal action,V

Act i

both inﬂuence the internal state S

. These inﬂuences depend

respectively on the level of understanding u

and u

′

If t is the time we have the following equations:



(t + 1) = S

(t) + u

Per1

(t + 1) + u

′

Act1

(t + 1)

(t + 1) = S

(t) + u

Per2

(t + 1) + u

′

Act2

(t + 1)

(1)

Assuming that communication is ideal, i.e. V

Peri

Act j

, and that Agent1 is the only one to speak, i.e.

Act2

= V

Per1

= 0,the system of equations 1 gives:



(t + 1) = S

(t) + u

′

Act1

(t + 1)

(t + 1) = S

(t) + u

Act1

(t + 1)

(2)

This ﬁrst property P1 is crucial in our model, as it

links together the agents’ internal states: each one is

modiﬁed by speech depending on its own parameter

. In the present model, we assume that for a given

agent, understanding of its productions and of its per-

ceptions are similar: for Agent i, u

= u

′

2.2 Non-verbal Behaviours Reﬂect

Internal State

The second property P2, claims that “non-verbal be-

haviours reﬂect internal state”. That is to say, agent’s

arousal, mood, satisfaction, awareness, are made

visible thanks to facial expressions, gaze, phatics,

backchannel, prosody, gestures, speech pauses. To

make visible the internal properties of Agent i, a non-

verbal signal, NV

Act i

, is triggered depending on its

internal state, S

. When S

reaches the threshold β,

the agent producesnon-verbal behaviours with th

the

threshold function (see ﬁg. 2):

Act i

(t) = th

(t)) (3)

We suggest here that pitch accents, pauses, head

nods, changes of facial expressions and other non-

verbal cues are, for a certain part, produced by agents

when a particularly important idea arises, when the

explanation reach a certain point, when an idea or a

SHARED UNDERSTANDING AND SYNCHRONY EMERGENCE - Synchrony as an Indice of the Exchange of

Meaning between Dialog Partners

Agent2

Agent1

Per1

Act1

′

Per2

Act2

′

Figure 2: Each agent produces non-verbal behaviours

Act i

when S

reaches the threshold β. NV

Act i

depends

on how much the internal state S

has been inﬂuenced by

what has been said.

concept starts to be outlined. We assume that the phe-

nomenon is similar in both speaker and listener, it is

driven by the evolution of what is wanted to be ex-

pressed in one case and it is driven by what is heard

in the other case. If speaker and listener understand

each other, these peaks of arousal and understanding

should co-occur: they appear to be temporally linked.

These peaks will be the bases of entrainment for in-

tentional coordination between partners. And then

this coordination could be seen as a marker of inter-

action quality.

Considering these two ﬁrst points, that is to say,

equations 2 and 3 we have the following system of

equations :



Act1

) = th

(

∑

Act1

(t))

Act2

) = th

(

∑

Act1

(t))

(4)

If an agent is enough inﬂuenced by what is said, it

produces non-verbal signals. And if u

= u

then

Act1

= NV

Act2

, agents’ non-verbal behaviours may

be synchronised, where as if u

and u

are too differ-

ent, agents will not be able to synchronise.

2.3 Sensitivity to Synchrony

To account for the property P3, “sensitivity of human

to synchrony”, we use the fact that sensitivity to syn-

chrony can be modelled by simple model of mutual

reinforcement of the perception-action coupling (Au-

vray et al., 2009; Paolo et al., 2008). In addition to

the inﬂuence from speech (either during its percep-

tion or its production), each agent’s internal state S

inﬂuenced by the non-verbal behaviour it perceives

from the other NV

Act j

, modulated by sensitivity to

non-verbal signal σ (see ﬁg.3).

The internal state of each agent is modiﬁed by

both what it understand of the speech and what it sees

Agent2

Agent1

Act1

Per1

Act1

Per2

Act2

Figure 3: Agent1’s internal state, S

, is inﬂuenced by both

its own understanding of what it is saying u

·V

Act1

and the

non-verbal behaviour of Agent2, σ · NV

Act2

. Agent2’s in-

ternal state,

, is inﬂuenced by its own understanding of

what Agent1 says u

·V

Act1

and the non-verbal behaviour

of Agent1, σ· NV

Act1

from the non-verbal behaviour of the other:



(t + 1) = S

(t) + u

Act1

(t + 1) + σNV

Act2

(t)

(t + 1) = S

(t) + u

Act1

(t + 1) + σNV

Act1

(t)

(5)

This last equation will favour the synchronisation by

increasing the reciprocal inﬂuence when agents’ in-

ternal state reach together a high level.

2.4 Coupling between Dynamical

Systems

How to enable agents involved in a verbal interaction,

to be as much synchronised as they share informa-

tion? To enable synchrony to emerge between the

two agents, we used the fact that synchronisation can

be modelled as a phenomenon emerging from the dy-

namical coupling within the dyad (Prepin and Revel,

2007): on one hand agents must have internal dynam-

ics which control their behaviour; on the other hand,

they must be inﬂuenced by the other’s behaviours.

In the previous subsections, we proposed a dyad

of agent which mutually inﬂuence. If we replace

the non-verbal behaviours of agents by their internal

states in the system of equations 5, it gives:



(t + 1) = S

(t) + u

Act1

(t + 1) + σth

(t))

(t + 1) = S

(t) + u

Act1

(t + 1) + σth

(t))

(6)

To enable coupling to occur, the agents should also

be dynamical systems: systems which state evolves

along time by themselves. The internal state of the

agents S

producesbehaviours and is inﬂuenced by the

other agent’s behaviour. To ensure internal dynam-

ics, we made this internal state a relaxation oscillator,

which increases linearly and decreases rapidly when

it reaches the threshold 0.95 (ﬁg. 5 shows an example

of the signals obtained). By oscillating , the internal

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

states agents will not only inﬂuence each other but

also be able to correlate one with the other (Prepin

and Revel, 2007).

Here, two cases are interesting.

When the internal states of both agents are under

the threshold triggering non-verbal behaviours, β, the

system of equation 6 becomes:



(t + 1) = S

(t) + u

Act1

(t + 1)

(t + 1) = S

(t) + u

Act1

(t + 1)

(7)

The two agents are almost independent, they are only

inﬂuenced by the speech of Agent1 and each one pro-

duces its own oscillating dynamic. That could be the

case if two tired people (high β) speak about a not so

interesting subject (u

are low): they are made apathic

by the conversation, they do not express anything.

The second interesting case is when both agents’

internal states are above the threshold β. The system

of equation 6 becomes:



(t + 1) = S

(t) + u

Act1

(t + 1) + σS

(t)

(t + 1) = S

(t) + u

Act1

(t + 1) + σS

(t)

(8)

In this case agents are not anymore independent, they

inﬂuence each other depending on the way they un-

derstand speech. If we push the recursivity of these

equations one step further we obtain:











(t + 1) = S

(t) + u

Act1

(t + 1)+

σ(S

(t − 1) + u

Act1

(t) + σS

(t − 1))

(t + 1) = S

(t) + u

Act1

(t + 1)+

σ(S

(t − 1) + u

Act1

(t) + σS

(t − 1))

(9)

And now we see the effect of coupling, that is to say

that agents are not only inﬂuenced by the state of the

other but they are inﬂuenced by their own state, me-

diated by the other: the non-verbal behaviours of the

other becomes their own biofeedback (Nadel, 2002).

When the threshold β is overtaken, the reciprocal in-

ﬂuence is recursive and becomes exponential: the dy-

namics of S

and S

are not any more independent,

they are inﬂuenced in their phases and frequencies

(Pikovsky et al., 2001; Prepin and Revel, 2007).

3 TEST OF THE MODEL

We tested this model by implementing a dyad of agent

as a neuronal network in the neuronal network sim-

ulator Leto/Prometheus (developed in the ETIS lab.

by Gaussier et al. (Gaussier and Cocquerez, 1992;

Gaussier and Zrehen, 1994)), and by studying its

emerging dynamics with different sets of parameters.

3.1 Implementation

We implemented the model on the neural networks

simulator Leto/Prometheus. Leto/Prometheus simu-

lates the dynamics of neural networks by an update of

the whole network at each time step. We use groups

of neurons with one neuron, and non-modiﬁable links

between groups. The schema of ﬁg. 4 show this im-

plementation.

The internal states of agents, S

, are relaxation os-

Agent2

Agent1

Act1

Act2

−1000

0.95

∆φ

ini

Recording

Relax1

Relax2

−1000

Figure 4: Implementation of the two agents. The couples

;Relax1) and (S

;Relax2) are relaxation oscillators. The

parameters which will be tested are the following: β, the

threshold which controls the non-verbal production; u

and

which control the agents’ level of sharing; ∆φ

ini

, the ini-

tial phase-shift between agents.

cillators: the re-entering link of weight 1 makes the

neuron behave as a capacity, and the Relax neuron

which ﬁres when a 0.95 threshold is reached, inhibits

and makes it relax (see ﬁg. 5 for an example of the

activation obtained).

Act1

, Agent1’s verbal production, is a neuron of

Figure 5: Activations of the internal state S

(t) for u

0.01.

constant activity 1. This neuron feeds the oscillators

of both agents, weighted by their level of understand-

ing u

and u

. The values of u

and u

are near 0.01:

it enables a well balanced sampling of the oscillators’

activations, the period last around 100 time steps.

In addition to agent understandingu

and u

, three

other parameters are modiﬁable in this implementa-

tion:

• The threshold β which controls the triggering of

non-verbal signal.

SHARED UNDERSTANDING AND SYNCHRONY EMERGENCE - Synchrony as an Indice of the Exchange of

Meaning between Dialog Partners

• The sensitivity of agent’s internal state to non-

verbal signal σ which weights NV

Act i

. These two

parameters β and σ directly control the amount

of non-verbal inﬂuence between the agents: they

must be high enough to enable coupling, for in-

stance reducing initial phase-shift between oscil-

lators or compensating phase deviation when u

• The initial phase shift ∆φ

ini

, which makes agents

start with a phase shift between S

ini

) and

ini

) at the beginning of each test of the archi-

tecture.

Finally, the variables recorded during these tests

are the internal states of both agents, S

(t) and S

(t)

(see ﬁg. 6 for an example).

Figure 6: Activations recorded for u

= 0.01, u

= 0.011,

β = 0.85, σ= 0.05 and ∆φ

ini

= 0.4. Despite the initial phase

shift and the phase deviation, the two agents synchronise.

This is a stable state of the dyad, it remains until the end of

the experiment (5000 time steps).

3.2 Test of Synchrony Emergence

For a given set of parameters, to determine if in-

phase synchronisation occurred between agents, we

used a procedure described by Pikovsky, Rosenblum

and Kurths in their reference book “Synchronisation”

(Pikovsky et al., 2001). This procedure consists in

comparing the phases of two signals to determine if

they are synchronous or not.

First we used the fact that relaxation oscillators

can be characterised by their peaks. There is a peak at

time t

when S

) ≥ 0.9β and S

+ 1) = 0 . Then,

we used the fact that phase can be rebuilt from these

peaks (Pikovsky et al., 2001). We assign to the time

the values of the phase φ(t

) = 2πk, and for every

instants of time t

< t < t

+ 1 determine the phase as

a linear interpolation between these values (see ﬁg.7):

φ(t) = 2πk+ 2π

t − t

k+1

− t

(10)

After that, when the phases of signals are obtained,

we consider their difference modulo 2π (see ﬁg.8).

Horizontal plateaus in this graph reﬂect periods of

constant phase-shift between signals, i.e. synchroni-

sation. Horizontal plate aux near zero reﬂect periods

of synchronisation and co-occurrence of non-verbal

signals.

Figure 7: Signal, Peaks and Phase. In the upper part of the

graph, there is the original signal S

(shown in ﬁg.6) and the

associated re-built phase (we can notice the change of phase

slope when synchronisation occurs). In the lower part of the

graph, there are the peaks extracted from S

in order to re-

build the phase.

Figure 8: Signals of two agents and their associated phase-

shift ∆

,φ

(t). When agents synchronise with each other,

their phase-shift remains constant and near zero.

Finally, for each 5000 time steps simulation, we de-

ﬁne that in-phase synchronisation occurs if the phase-

shift becomes near zero at a time t

synch

, smaller than

3000, and remains constant until the end. We deﬁned

the synchronisation speed as SynchSpeed = (3000−

synch

)/3000. If in-phase synchronisation is immedi-

ate SynchSpeed = 1; if in-phase synchronisation oc-

curs at time step 3000 SynchSpeed = 0; and if in-

phase synchronisation do not occurs SynchSpeed < 0.

3.3 Test of Architecture Parameters

We tested different parameters of this model, ﬁrst to

show the direct link existing between emergence of

synchrony and level of sharing between interactants,

and second to characterise the different properties of

this model.

To show the direct link existing between emer-

gence of synchrony and level of sharing between in-

teractants, we ﬁxed u

to 0.01 and made u

vary

between 0 and 0.02, that is to say the shared un-

derstanding of the two agents differs between 0 and

100%. Notice here the importance to test synchroni-

sation when u

= 0: if synchronisation occurs when

= 0, i.e. when Agent2 does not perceived the

speech of Agent1, that means that agents synchronise

every time just thank to non-verbal signal of Agent1;

in that case, synchrony is not any more an in dice

of the interaction quality, the inﬂuence of non-verbal

signals (linked to β and σ) is too high.

To evaluate the inﬂuence of the amount of non-

verbal signal exchanged, we made the threshold β

vary between 0 and 0.95.

To evaluate the inﬂuence of the sensitivity to non-

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

verbal signal, we made the sensitivity σ vary between

0 and 0.09.

Finally, to evaluate the abilities of such a dyad of

agents to re-synchronise after an induced phase-shift

or after a misunderstanding, we made the initial phase

shift ∆φ

ini

vary between 0 and π.

Shared Understanding Inﬂuence. When the two

agents are synchronousin phase (∆φ

ini

= 0), we tested

which of the u

values keep agents synchronised or

make them disynchronise. For ﬁxed β = 0.7, σ = 0.05

and ∆φ

ini

= 0, u

varies between 0 and 0.02. The fol-

lowing graph of ﬁg. 9 shows the associated disyn-

chronisation speed.

When the difference between u

and u

is to high,

Figure 9: Di-synchronisation speed of the dyad, depend-

ing on the Agent2 understanding u

. u

varies from left to

right between 0 and 0.02. A null disynchronisation speed

means that synchronisation has been maintained until the

end of the experiment. A disynchronisation speed 1 is for

a dis-synchronisation occurring at the very beginning of the

experiment.

no synchronisation can occur since even when syn-

chrony is forced at the beginning of the experiment,

agent disynchronise.

Inﬂuence of Amount of Non-verbal Signals. The

coupling and synchronisation capabilities of the dyad

of agents, may directly depend on the amount of non-

verbal signals they exchange: among other, the abil-

ity to compensate a difference of understanding may

be improved by an increase of non-verbal signals ex-

changed. We tested this effect by calculating disyn-

chronisation speeds as just above, making u

vary be-

tween 0 and 0.02 and the threshold β varying between

0 and 0.9 (σ = 0.05). We obtained the 3D graph of ﬁg.

10.

When β = 0.9, that is to say when very few non-

verbal signals are exchanged, synchrony maintains

only when the two agents have equal level of under-

standing, u

= u

= 0.01. For other values, the inﬂu-

ence of the threshold β is not so clear: the dyad does

not resist better to disynchronisation when β < 0.5

than when 6 ≤ β ≤ 8. This effect, or this absence

of effect, may be due to the fact that the more β de-

creases, the less accurate in time the non-verbal sig-

nals are: if β is low, non-verbal signals are emit earlier

Figure 10: Di-synchronisation speed of the dyad, depend-

ing on the Agent2 understanding u

and the threshold β

(σ = 0.5). u

varies between 0 and 0.02. β varies from 0.9

to 0, in the sens of non-verbal signals increase. When the

d i-synchronisation speed value is null, synchronisation has

been maintained until the end of the experiment. A disyn-

chronisation speed 1 is for a disynchronisation occurring at

very beginning of the experiment.

before the peaks of S

activation and on a larger time

window, they are not enough precise in time to main-

tain synchrony. We chosen β = 0.7, i.e. the mean of

its best performances values.

Sensitivity to Non-verbal Signals. Another way to

modify the inﬂuence of non-verbal signals on cou-

pling and synchronisation properties of the dyad, is

to modify the sensitivity to the perceived non-verbal

signal, σ. We tested this effect by calculating disyn-

chronisation speeds as previously, making u

vary be-

tween 0 and 0.02 and the sensitivity σ varying be-

tween 0 and 0.09 (β = 0.07). We obtained the 3D

graph of ﬁg. 11.

Sensitivity to non-verbal signal σ have a direct

Figure 11: Di-synchronisation speed of the dyad, depend-

ing on the Agent2 understanding u

and the sensitivity σ

(β = 0.7). u

varies between 0 and 0.02. σ varies from 0

to 0.09. When the d i-synchronisation speed value is null,

synchronisation has been maintained until the end of the ex-

periment. A disynchronisation speed 1 is for a disynchroni-

sation occurring at the very beginning of the experiment.

effect on agents to stay synchronous even with dif-

ferent understandings: the higher is sensitivity σ, the

SHARED UNDERSTANDING AND SYNCHRONY EMERGENCE - Synchrony as an Indice of the Exchange of

Meaning between Dialog Partners

more resistant to difference between u

the synchro-

nisation capability of the dyad is. The effect of σ is

important despite its low value (σ < 0.1) due to the

high number of non-verbal signal exchanged: when

Agent i’s internal state S

reaches the threshold β, it

produces the non-verbal signals NV

Act i

at every time

step until S

relaxes. That can last between 0 and 20

time steps for each oscillation period. The effect of σ

is multiplied by this number of steps.

It is important to notice here that the σ effect on

the dyad resistance to u

differences, has a counter-

part. This counter-part is the fact that when σ increase

and make the dyad more resistant to disynchronisa-

tion, it also makes the synchronisation of the dyad

less related to mutual understanding. For instance,

when σ ≥ 0.7, agents stay synchronous even when

Agent2 do not understand anything, u

= 0. To bal-

ance these two effects, facilitation of synchronisation

and decrease of synchrony signiﬁcance, we chosen a

default value of σ = 0.05.

Re-synchronisation Capability. Given a value of

Agent2 understanding u

, we tested the ability of the

dyad Agent1-Agent2 to re-synchronise after a phase

shift. We made the initial phase-shift ∆φ

ini

vary be-

tween 0 and π for every values of u

and calculated

the speed of synchronisation if any. The 3D graph of

ﬁg. 12 shows the synchronisation speed for each cou-

ple (u

;∆φ

ini

The initial phase-shift between S

and S

does

Figure 12: Synchronisation speed of the dyad, depending

on the Agent2 understanding u

and initial phase-shift ∆φ

ini

(σ = 0.05 and β = 0.7). u

varies between 0 and 0.02. ∆φ

ini

varies from 0 to π. When the synchronisation speed value

is null, the dyad did not synchronised until the end of the

experiment. A synchronisation speed 1 is for a synchroni-

sation occurring at the very beginning of the experiment.

not appear to affect the synchronisation capacities of

the dyad. With the chosen σ = 0.05 and β = 0.7,

when the agents’ levels of understanding u

and u

do not differ more than 15% of each other, they syn-

chronise systematically and very quickly: for instance

they synchronise even when they start in anti-phase

(∆φ

ini

= π). And conversely, when the levels of un-

derstanding u

and u

are more than 15% different,

synchronisation is no more immediate.

4 DISCUSSION

We proposed and tested a model which links emer-

gence of synchronybetween dialogue partners to their

level of shared understanding. This model assesses

both the understanding of humans and the believabil-

ity of artifacts (e.g. virtual humans). When two

interactants have similar understanding of what the

speaker says, their non-verbal behaviours appear syn-

chronous. Conversely, when the two partners have

different understanding of what is being said, they

disynchronise. This model is implemented as a dy-

namical coupling between two talking agents: on one

hand, each agent proposes its own dynamics; on the

other hand, each agent is inﬂuenced by its perception

of the other. These are the two minimal conditions

enabling coupling. What makes this model particular

is that the internal dynamics of agents are generated

by the meaning exchanged through speech. It links

the dynamical side of interaction to the formal side of

speech.

We tested this model in simulation, and showed

that synchrony effectively emerges between agents

when they have close level of understanding. We no-

ticed a clear effect of the level of understanding on

the capacity of the agents to both remain synchronous

and re-synchronise: agents disynchronise if the level

of shared understanding is lower than 85% (with our

parameters) and conversely agents synchronise if the

level of shared understanding is higher than 85%.

These results tend to prove that, considering that syn-

chrony between agents is an indice of good interaction

and shared understanding, the reciprocal property is

true too; that is disynchrony accounts for misunder-

standing.

We have shown that agents remain synchronous

depends on both their shared understanding (the ratio

between u

and u

) and their sensitivity to non-verbal

behaviour (σ in our implementation). The more sensi-

tive to non-verbal behaviours are the agents, the more

resistant to disynchronisation is the dyad and the eas-

ier is the synchronisation. An important counter-part

of this easier synchronisation is that it makes syn-

chrony less representative of shared understanding:

agents or people with very different levels of under-

standing will be able to synchronise; if sensitivity to

non-verbal behaviour is too high, the dyadic parame-

ter of synchrony is not a cue of shared understanding.

By contrast, the facility agents trigger non-verbal be-

haviours when their internal states are high (thresh-

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

Figure 13: Greta, Obadia, Poppy and Prudence. They are

four agents implemented on the open source system Greta.

Each one has its own personality and level of understanding.

When interacting together, different levels of non-verbal

synchrony should appear between the agents of this group.

old β) does not appear to change the synchronisa-

tion properties of the dyad: the higher number of ex-

changed non-verbal signals seems to be compensated

by their associated decrease of precision.

In addition to the effect of shared understanding

on the stability of synchrony between agents, we have

tested the effect of shared understanding on the capac-

ity of the dyad to re-synchronise. For instance, dur-

ing a dialogue, synchrony can be broken by the use of

new concept by the speaker. That may result in lower-

ing the level of shared understanding below the 85%

necessary for remaining synchronous. Synchrony can

also be disrupted by an external eventwhich can intro-

duce a phase-shift between interactants. Given ﬁxed

sensitivity to non-verbal behaviour (σ) and facility

to trigger non-verbal behaviours (β), we tested how

quickly the dyad can re-synchronise after a phase-

shift. The shared level of understanding necessary to

enable re-synchronisation appeared to be the same as

the one under which agents disynchronise.

Two crucial points must be noticed here. First,

when agents’ understanding do not differ more than

15% (shared understanding higher than 85%), agents

synchronise systematically whatever the phase-shift

is, and when agent’s understanding differ more than

15% they disynchronise. Second, both synchronisa-

tion and disynchronisation of agents are very quick,

lasting about one oscillation of the agents’ internal

states. Synchronisation and disynchronisation are

very quick effects of respectively misunderstanding

and shared understanding: agents involved in an in-

teraction do not have to wait to see synchrony appears

when they understand each other, they have a fast an-

swer to whether they understand each other or not.

The 5000 time steps length of our tests allowed us

to test the stability of synchrony or disynchrony after

their occurrence; however it is clearly not a natural

situation. Synchrony in natural interaction is a vary-

ing phenomenon involving multiple synchronisation

and disynchronisation phases: the level of shared un-

derstanding varies along the interaction. In fact disyn-

chrony may be quite informativefor the dyad as its de-

tection enables agents to adapt one another. In natural

interactions, synchrony occurring after disynchrony

shows that agents share understanding whereas they

did not before: they have beneﬁted from the interac-

tion and exchanged information.

As a consequence, the mean level of shared under-

standing necessary for good interaction to take place

between persons in natural context would be much

more reasonable: the 85% of shared understanding

occurs in phases of particularly good interaction and

its is not a hard constraint on the whole dialogue; this

very high level necessary for synchronisation should

be divided by the ratio of synchrony vs disynchrony

phases present in natural interaction. For instance

we can imagine that a level of shared understanding

higher than 85% would occur when people involved

in a discussion have just reached an agreement. By

contrast, when the level of shared understanding stays

all along the dialogue far under 85%, the dyad would

be more like two strangers trying to talk together, or

a professional talking with technical words to a naive

listener.

Our model has been tested and its principle has

been validated in agent-agent context. To go a step

farther, in “wild world” situations involving humans,

two elements must be added: Understanding of lan-

guage during interaction with human; Recognition of

non-verbal behaviours of human users. In the near

future, we will adapt the present neural architecture

to the open source virtual agent Greta (Pelachaud,

2009). The system Greta enables one to generate

multi-modal (verbal and non-verbal) behaviours on-

line and with accurate timing. The verbal signals

will be modelled as elements of “small-talk” and

the non-verbal signal will be modelled as, pitch ac-

cents, pauses, head nods, head shakes and facial ex-

pressions. To test the real impact of such a model

on human perception of interaction, we will per-

form perceptive evaluation: we aim to simulate a

group of virtual agents dialoguing with each other

(see ﬁg.13). Each agent will have its own personality

and level of understanding of what being said. This

will lead to pattern of synchronisation and disynchro-

nisation. Among other, agents which share under-

standing should display inter-synchronypattern (Con-

don, 1976). Finally, human observers should clearly

ﬁll which agent is sharing understanding with which

other agent.

SHARED UNDERSTANDING AND SYNCHRONY EMERGENCE - Synchrony as an Indice of the Exchange of

Meaning between Dialog Partners

In conclusion, we can notice that, in ad-

dition to the two main results of this study

−“disynchrony accounts for misunderstanding” and

“synchronisation and disynchronisation are very

quick phenomenons”− another result is the model it-

self. It proposes a link between synchrony and inter-

subjectivity by the use of dynamical system coupling:

synchrony and dynamical coupling emerge together

when agents mutually understand each other; as a

consequence synchrony account for good interaction.

We believe, this model is a start to answer the is-

sues of what is the part of dynamical coupling be-

tween agents involved in verbal interaction? What

is the part of emerging dynamics in the communica-

tion of meanings and intentions? And moreover, how

these two parts can co-exist and feed each other?

ACKNOWLEDGEMENTS

This work has been partially ﬁnanced by the Euro-

pean Project NoE SSPNet (Social Signal Processing

Network). Nothing could have been done without the

Leto/Prometheus NN simulator, lent by the Philippe

Gaussier’s team (ETIS lab, Cergy-Pontoise, France).

REFERENCES

Auvray, M., Lenay, C., and Stewart, J. (2009). Perceptual

interactions in a minimalist virtual environment. New

ideas in psychology, 27:32–47.

Bernieri, F. J. (1988). Coordinated movement and rapport

in teacher-student interactions. Journal of Nonverbal

Behavior, 12(2):120–138.

Chammat, M., Foucher, A., Nadel, J., and Dubal, S. (2010).

Reading sadness beyond human faces. Brain Re-

search, In Press, Accepted Manuscript:–.

Condon, W. S. (1976). An analysis of behavioral organisa-

tion. Sign Language Studies, 13:285–318.

Condon, W. S. and Ogston, W. D. (1966). Sound ﬁlm

analysis of normal and pathological behavior patterns.

Journal of Nervous and Mental Disease, 143:338–

347.

Dubal, S., Jouvent, A. F. R., and Nadel, J. (2010). Human

brain spots emotion in non humanoid robots. Social

Cognitive and Affective Neuroscience, in press:–.

Ducan, S. (1972). Some signals and rules for taking speak-

ing turns in conversations. Journal of Personality and

Social Psychology, 23(2):283–292.

Dumas, G., Nadel, J., Soussignan, R., Martinerie, J., and

Garnero, L. (2010). Inter-brain synchonization during

social interaction. PLoS One, 5(8):e12166.

Gaussier, P. and Cocquerez, J. (1992). Neural networks for

complex scene recognition : simulation of a visual

system with several cortical areas. In IJCNN Balti-

more, pages 233–259.

Gaussier, P. and Zrehen, S. (1994). Avoiding the world

model trap: An acting robot does not need to be so

smart! Journal of Robotics and Computer-Integrated

Manufacturing, 11(4):279–286.

Hatﬁeld, E., Cacioppo, J. L., and Rapson, R. L. (1993).

Emotional contagion. Current Directions in Psycho-

logical Sciences, 2:96–99.

Kendon, A. (1990). Conducting Interaction: Patterns of Be-

havior in Focused Encounters. Cambridge University

Press, Cambridge, UK.

LaFrance, M. (1979). Nonverbal synchrony and rapport:

Analysis by the cross-lag panel technique. Social Psy-

chology Quarterly, 42(1):66–70.

Matsumoto, D. and Willingham, B. (2009). Spontaneous

facial expressions of emotion in congenitally and non-

congenitally blind individuals. Journal of Personality

and Social Psychology, 96(1):1–10.

Mertan, B., Nadel, J., and Leveau, H. (1993). New perspec-

tive in early communicative development, chapter The

effect of adult presence on communicative behaviour

among toddlers. Routledge, London, UK.

Murray, L. and Trevarthen, C. (1985). Emotional regula-

tion of interactions vetween two-month-olds and their

mothers. Social perception in infants, pages 101–125.

Nadel, J. (2002). Imitation and imitation recognition: their

functional role in preverbal infants and nonverbal

children with autism, pages 42–62. UK: Cambridge

University Press.

Nadel, J. and Tremblay-Leveau, H. (1999). Early social

cognition, chapter Early perception of social contin-

gencies and interpersonal intentionality: dyadic and

triadic paradigms, pages 189–212. Lawrence Erlbaum

Associates.

Paolo, E. A. D., Rohde, M., and Iizuka, H. (2008). Sensi-

tivity to social contingency or stability of interaction?

modelling the dynamics of perceptual crossing. New

ideas in psychology, 26:278–294.

Pelachaud, C. (2009). Modelling multimodal expression of

emotion in a virtual agent. Philosophical Transactions

of Royal Society. Biological Science, 364:3539–3548.

Pikovsky, A., Rosenblum, M., and Kurths, J. (2001). Syn-

chronization: A Universal Concept in Nonlinear Sci-

ences. Cambridge University Press, Cambridge, UK.

Poggi, I. and Pelachaud, C. (2000). Emotional meaning

and expression in animated faces. Lecture Notes in

Computer Science, pages 182–195.

Prepin, K. and Gaussier, P. (2010). How an agent can de-

tect and use synchrony parameter of its own interac-

tion with a human? In et al., A. E., editor, COST

Action2102, Int. Traing School 2009, Active Listening

and Synchrony. LNCS 5967, pages 50–65. Springer-

Verlag, Berlin Heidelberg.

Prepin, K. and Revel, A. (2007). Human-machine interac-

tion as a model of machine-machine interaction: how

to make machines interact as humans do. Advanced

Robotics, 21(15):1709–1723.

Scherer, K. and Delplanque, S. (2009). Emotions, signal

processing, and behaviour. In Chemosensory Percep-

tion Symposium, Geneva. Firmenich.

Tronick, E., Als, H., Adamson, L., Wise, S., and Brazel-

ton, T. (1978). The infants’ response to entrapment

between contradictory messages in face-to-face inter-

actions. Journal of the American Academy of Child

Psychiatry (Psychiatrics)., 17:1–13.

Yngve, V. H. (1970). On getting a word in edgewise. In So-

ciety, C. L., editor, Papers from the 6th regional meet-

ing, pages 567–578.

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence
