PROTECTION OF CLINICAL DATA

Comparison of European with American Legislation

and Respective Technological Applicability

C. Pereira

1,2

, C. Oliveira

1,2

, C. Vilaça

1,2

and A. Ferreira

1,3

Faculty of Medicine of the University of Porto, Al. Prof. Hernâni Monteiro, 4200-319, Porto, Portugal

Faculty of Sciences of the University of Porto, Rua do Campo Alegre, s/n, 4169-007, Porto, Portugal

CINTESIS – Center for Research in Health Techonologies and Information Systems, University of Porto, Porto, Portugal

Keywords: Health legislation, Computer security, Health insurance portability and accountability act, Recommendation

No R (97)5, Privacy.

Abstract: The use of computer applications in health services is essential but difficult to make it right. The challenge is to

balance two values: the free access to patient sensitive and personal information and the protection of the

privacy and confidentiality of the patient. The European Union and the United States tried to solve this

challenge by implementing legislation on the protection of clinical data. The European legislation is

comprehensive and regulated by Supervisors and each Member State creates its own legislation in

accordance with the Recommendations. On the other hand, the American legislation is specific, the

organizations have a self-regulatory system and each state creates the State Law which is governed by

Federal Law. The aim of this paper is to compare the European legislation - “Recommendation No R

(97)5”with the American legislation – “Health Insurance Portability and Accountability Act” at the level of

information security in healthcare, regarding new security technologies and mechanisms applied in the area

of safety monitoring of clinical data. Both legislations are neutral concerning the selection of technology

that the State wants to use. These laws must be adaptive to the changing technology, to ensure patients’

privacy under any circumstance.

1 INTRODUCTION

One of the biggest challenges of the informatics’ era

arises from the use of computer applications in

health services while maintaining the same

traditional principles. This challenge involves

achieving a balance between: the free access to

patient sensitive and personal information and the

protection of the privacy and confidentiality of the

patient.

Currently healthcare services are supported by

new information and communication technologies

which includes hardware and software linked to

databases to register, manipulate and search data in

different formats. The amount of data and access to

it has increased against the spread of computer

networks within each institution but also between

different health institutions. The increase in the

availability of healthcare Information Systems (ISs),

coupled with the high sensitivity of clinical data

stresses the need for its proper regulation and

protection. These healthcare ISs must use protection

mechanisms to ensure compliance with the

legislation in force. Therefore, there is an urgent

need to develop new security mechanisms that can

be taken within the health organizations.

This article aims to compare the European and

American legislation on the security and protection

of clinical information and to identify the respective

technological applicability.

2 BACKGROUND

The concept of information security in the clinical

area has undergone a great development. From the

century BC that doctors comply with the

Hippocratic Oath, which is expressed to protect the

privacy of the patient.

Several authors agree that in the clinical area it

remains valid the decomposition of information

security into three dimensions: confidentiality,

567

Pereira C., Oliveira C., Vilaça C. and Ferreira A..

PROTECTION OF CLINICAL DATA - Comparison of European with American Legislation and Respective Technological Applicability .

DOI: 10.5220/0003165505670570

In Proceedings of the International Conference on Health Informatics (HEALTHINF-2011), pages 567-570

ISBN: 978-989-8425-34-8

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

integrity and availability. The Confidentiality is

necessary to ensure that patient data is protected and

cannot be accessed by unauthorized persons,

whether accidental or deliberately. The Availability

is necessary to preserve the resources and services of

healthcare ISs that must be accessible when needed,

particularly in emergency or intensive care

situations. The Integrity is necessary to ensure that

clinical information stored or in transit is not

corrupted or changed improperly by unauthorized

users or through operational errors (in the

introduction and manipulation of data), software

bugs, viruses or equipment malfunction (ISO, 2006).

Since 1997, European legislation regulates the

protection and treatment of confidentiality, integrity

and availability of medical data trough

“Recommendation No. R (97) 5 of the Committee

of Ministers to Member States on the Protection of

Medical Data”, which stated in Principle 3.1 that

“The respect of rights and fundamental freedoms,

and in particular of the right to privacy, shall be

guaranteed during the collection and processing of

medical data” (Rec, 1997). This European

recommendation was the basis for the creation of

specific legislation in each Member State.

Since 1996, American legislation, through

Federal Law 104-191, known as the “Health

Insurance Portability and Accountability Act of

1996” - HIPAA (HIPAA, 1996) rules privacy,

information security and standards of all entities

providing healthcare or having access to data from

healthcare units. For this legislation, two regulation

documents were created. They provide a set of best

practices that healthcare institutions must follow in

order to guarantee a minimum level of information

security. These documents are called Security Rule

(2003) and Privacy Rule (2002) that rules the

organizations in the use and disclosure of

confidential, personal and identifiable health

information about patients that is designated

“Protected Health Information” (PHI). The PHI

includes information such as demographic data that

is utilized for the user identification, data from their

past, present or future health status and data related

with the healthcare services.

3 EUROPEAN LEGISLATION VS

AMERICAN LEGISLATION

European legislation is a comprehensive law,

implemented by supervision, which creates

European directives and recommendations that are

followed by the Member States trough the creation

of national legislation. The right to privacy is

explicit in the Charter of Fundamental Rights. One

the other hand, American legislation is a specific

law, implemented by different mechanisms, which

creates the federal law that is followed by the United

States of America. The right to privacy is not

explicit in the Constitution.

Another relevant difference is concerned about

the regulation of the legislation. In Europe this

adjustment is made by authority Supervisors such as

the European Data Protection Supervisor (EDPS),

the Europol Joint Supervisory Body and the

Schengen Joint Supervisory Authority. Within each

Member State there is an authority for the data

protection that should create recommendations and

ensure its compliance. In American legislation, it is

assumed that organizations govern themselves

autonomously.

For this comparative analysis a selection

regarding the security issues of clinical data was

made of both legislations. In the European

legislation, it was selected the chapter 9.2 of the

“Recommendation No. R (1997) 5” and in relation

to American legislation this study focused on the

Security Rule document from HIPAA.

Table 1, presents the analysis of clinical data

security recommendations from both legislations and

some examples and their descriptions of

technologies or mechanisms that could have

applicability in the different types of control, at the

level of: the physical entrance to installations, data

media, memory, utilization, access, communication,

data introduction, transport and availability.

4 DISCUSSION

Regarding the security of personal information the

authors consider that the European legislation has

the advantage of being: (1) a good reference model

for the good practice with flexibility in the

recommendations to Member States; (2)

technologically neutral; and (3) with an increased

awareness and concern about the security of clinical

data. However, European legislation presents some

weaknesses, such as for instance: (1) the dubious

association between certain key concepts (“personal

data” and “real privacy”); (2) the difficulties in

practical implementation due to the inconsistent role

of data protection authorities; and (3) the outdated

rules in transferring information to other countries.

Moreover, most Member States are governed by

national rules of clinical data protection and the

harmonization remains more apparent than real. This

HEALTHINF 2011 - International Conference on Health Informatics

568

Table 1: Recommendation No. R (97) 5 vs HIPAA in terms of clinical data security and respective technological

applicability.

Recommendation

Nº R (97) 5

HIPAA

Technological

Applicability

Description

Control of the entrance to installations

To prevent any unauthorized person

from having access to installations

used for processing personal data.

To control and validate physical access to its facilities

containing information systems having electronical PHI

(ePHI) or software programs that can access ePHI.

1-Biometry

2-Smart card

3-Access code

1-Identification through a

physical characteristic.

2-Card with memory chip or

internal.

3-Access to systems through a

PIN (ISO, 2006).

Control of data media

To prevent data media from being

read, copied, altered or removed by

unauthorized persons.

To use encryption to protect the confidentiality, integrity,

and availability of its ePHI.

4-Passwords and

Automatic logoff

5-Encryption

6-Access control

7-User profiles

8- Policies and

security protocols

9-Digital

signatures and

certificate

-Login mechanisms with secret

asswords associated to user that

ould have an automatic logoff

ssociated.

-Process of converting text into

ipher text.

Memory control

To prevent the unauthorized entry of

data into the ISs and any

unauthorized consultation,

modification or deletion of

processed personal data.

o protect the integrity of its ePHI.

10- Audit

/Monitoring

4, 5, 8

8-Plan or course of action

dopted for providing computer

ecurit

(ISO, 2006).

Control of Utilization

To prevent automated data

processing systems from being used

by unauthorized persons by means of

data transmission equipment

o maintain an effective process for creating, changing,

and safeguarding passwords. To implement security

easures sufficient to reduce risks and vulnerabilities of

he wireless infrastructure. To establish management

irection, procedures, and requirements to ensure safe and

successful delivery of e-mail. To define standards to be

et by all equipment Internet firewalls.

11-Firewall

12- PKI

13-IDS

5, 8, 9, 10

11-Data traffic filter that

revents unauthorized access to a

rivate networ

12-Set of procedures, equipment,

eople and policies needed to

reate, manage, store, distribute

nd revoke public key

ertificates (ISO, 2006).

Access Control

To select access to data and to

maintain security of the medical

data, to ensure that the processing as

a general rule is so designed as to

enable the separation of:

- identifiers and data relating to the

identity of persons - administrative

data; medical data; social data;

genetic data.

o purchase and implement information systems that

omplies with its information access management policies.

o ensure that all persons or entities seeking access to its

ePHI are appropriately authenticated before access is

ranted.

6,7,8

-Assurance that the resources of

data can be accessed only by

uthorized entities in authorized

ays (ISO, 2006).

-Subset of privileges assigned

o a user groups with similar

unctions (ISO, 2006).

Control of Communication

To guarantee the possibility of

checking and ascertaining to which

persons or bodies personal data can

be communicated by data

transmission equipment.

he organization should appropriately protect the

onfidentiality, integrity, and availability of the ePHI it

ransmits over electronic communications network.

14-VPNs

5, 8, 9, 13

13-Software for detecting,

dentifying and responding to

nauthorized or abnormal

ctivities of the syste

Control of data introduction

To guarantee that it is possible to

check and establish a posteriori who

has had access to the system and

what personal data have been

introduced into the information

system, when and by whom.

he organization should appropriately track and log all

ovement of information systems and electronic media

ontaining ePHI to various organizational locations.

iscusses what the organization should do to implement

appropriate electronic mechanisms to confirm that its

ePHI has not been altered or destroyed in any

nauthorized manner.

6, 8, 9, 10

9-Certificate of PKI that consists

in data structure that associates a

public key to a specific agent

which are certified by authority.

10-Measures to verify the

existence of access control to

information (ISO, 2006).

Control of transport

To prevent the unauthorized reading,

copying, alteration or deletion of

personal data during the

communication of personal data and

the transport of data media.

Should document repairs and modifications to the

hysical components of its facilities related to the

rotection of its ePHI.

6, 8, 14

14-Private network that uses a

public telecommunication

infrastructure which uses

encryption to ensure privacy and

security of communications.

Availability control

To safeguard data by making

security copies.

Should be able to effectively respond to emergencie

isasters that impact its ePHI.

Organizational processes to regularly

ack up and securely store ePHI.

15-Backup

Software 16-

Redundancy of

equipment

15-Make copies of data to recover

(ISO, 2006).

16-e.g. power supplies, redundant

servers, etc.

PROTECTION OF CLINICAL DATA - Comparison of European with American Legislation and Respective

Technological Applicability

569

fact is due to the gap in the European Directive of

information protection that allows the Member

States to define their own exemptions and

simplifications to some constraints imposed.

As for the American legislation, the authors

consider that it has the strength to promote the

patient empowerment through greater control of

their PHI, because the patient has the right to access

and correct the information at any time and also the

power to decide who has access to their clinical data.

But this condition can also weaken the law because

of the problems associated with the excess of

freedom given to the patient in relation to access

their own clinical data may intervene in the lack of

preserving the “psychological integrity”. This could

happen when an individual has access to very

sensitive data that is published on the internet, which

isn’t protected by the actual law. More

disadvantages of this legislation are: the fact of

adding to the workload of healthcare providers with

the function of protects clinical information and the

countries due to the regulation differences.

Information security is a dynamic issue because

the pace of technological change continually

generates new challenges for global security policy,

so the effort to security must be continuous and

change accordingly by the development of new

security measures and mechanisms.

There is a great difficulty in controlling,

monitoring and ensuring that all procedures are what

they are meant to be and lives should not be exposed

by poor performance of healthcare ISs. Thus, great

efforts should be made to ensure that healthcare

legislation is properly applied and enforced.

The laws that under any circumstance. we have

referenced in this article must be adaptive to the

changing technology, to ensure patients’ privacy.

ACKNOWLEDGEMENTS

The authors acknowledge the help of Professor Luis

Filipe Antunes on initial discussion of this work.

REFERENCES

Cavalli E., M. A., Pinciroli F., Spaggiari P. 2004.

Information security concepts and practices: the case

of a provincial multi-specialty hospital. International

Journal of Medical Informatics, 73.

CEN/TC 2003. Health Informatics - Electronic Health

Record Communication. Part 4 - Security

requirements and distribution rules.

HIPAA 1996. Health Insurance Portability and

Accountability Act In: Congress, T. (ed.). USA.

ISO 2006. Health Informatics - Privilege management and

access control Part 2: Formal Models. Switzerland.

Joshi, J. B. D., Aref, W. G., et al. 2001. Security models

for web-based applications. Commun. ACM, 44, 38-

44.

Lumini, A. & Nanni, L. 2008. Over-complete feature

generation and feature selection for biometry. Expert

Syst. Appl., 35, 2049-2055.

Ravera L., Colombo I., et al. 2004. Security and privacy

at the private multispecialty hospital Instituto Clinico

Humanitas : strategy and reality. International Journal

of Medical Informatics, 73, 321-324.

Rec 1997. Recommendation No. R (97) 5 of the

Committee of Ministers to Member States on the

Protection of Medical Data. In: Europe, C. O. (ed.).

Tan, J. 2005. E-Health Care Information Systems: An

Introduction for Students and Professionals. Jossey-

Bass / Wiley.

Waldo, B. H. 1999. Managing Data Security: Developing

a Plan to Protect Patient Data. Nursing Economic$, 17,

49-52.

HEALTHINF 2011 - International Conference on Health Informatics

570
