PROVIDING DELIBERATION TO EMOTIONAL AGENTS

Daniel P

erez-Pinillos, Susana Fern

andez and Daniel Borrajo

Departamento de Inform

atica, Universidad Carlos III de Madrid, Avda. de la Universidad 30, Legan

es, Madrid, Spain

Keywords:

Planning, Agent, Emotion, Personality.

Abstract:

Modelling real persons or virtual agents motivations, personality and emotions is a key feature of many user-

oriented applications. Most of the previous work has deﬁned rich cognitive models of motivations, personality

and emotions, but have relied on some kind of reactive scheme of problem solving and execution. Instead,

this work proposes a deliberative emotional model for virtual agents based in their basic needs, preferences

and personality traits. More speciﬁcally, we advocate the integration of these comprehensive agents models

within deliberative automated planning techniques, so that plans to be executed by agents to achieve their

goals already incorporate reasoning at the emotional level.

1 INTRODUCTION

The work on reasoning about emotions is becom-

ing increasingly relevant, specially in contexts such

as assistive technology, user interfaces, or virtual

agents (Fellous and Arbib, 2005; Bates, 1994). Emo-

tions have been studied in psychology, neurology and

physiology from a wide variety of points of view

and each ﬁeld focuses the attention on different as-

pects (Damasio, 1994). It seems there is some agree-

ment to consider emotion as an inborn and subjective

reaction to the environment, with an adaptive func-

tion, and accompanied of several organic, physiolog-

ical and endocrine changes (Frijda, 1988). Another

point of agreement is that emotions are an outstanding

factor in humans, because they modify and adapt their

usual behavior. In the development of systems that

interact with persons, as human behavior simulators,

emotions can not be ignored, because, on one hand,

they may help on this interaction and, on the other

hand, they constitute a decisive part of human reason-

ing and behavior. This is specially true when reason-

ing about sequential decision-making, as in medium-

long term planning, where the sequence of decisions

can be inﬂuenced by the emotional state of agents.

During the last years, several emotion-oriented

systems have been developed, that normally follow

Frijda’s theory about emotions (Frijda, 1995). This

theory is based on the hypothesis that emotions are

functional most of the time. Thus, the use of emo-

tions in artiﬁcial systems is needed to achieve indivi-

dual objectives, and the design of social agents with

emotional characteristics is justiﬁed. Emotions also

cover the interaction of the individual with the envi-

ronment. For instance, individuals try to move away

objects that put in danger their survival, while they

approach objects that cater for their needs (Breazeal,

2003).

Emotions are also very related to characteristics

of human personality. In contemporary psychology,

there are ﬁve factors or dimensions of personality,

called the Big Five factors (Goldberg, 1993), which

have been scientiﬁcally deﬁned to describe human

personality at the highest level of organization. The

Big Five traits are also referred to as a purely de-

scriptive model of personality called the Five Factor

Model (Costa and McCrae, 1992; McCrae, 1992).

The Big Five factors are: openness to experience,

conscientiousness, extraversion, agreeableness and

neuroticism (opposite to emotional stability).

Examples of previous work on computa-

tional models of emotions is the work of

namero (Ca

namero, 1997; Ca

namero, 2003)

that proposes a homeostatic approach to the motiva-

tions model. She creates a self-regulatory system,

very close to natural homeostasis, that connects

each motivation to a physiological variable, which

is controlled within a given range. When the value

of that variable differs from the ideal one, an error

signal proportional to the deviation, called drive,

is sent, and activates some control mechanism that

adjusts the value in the right direction. There are

other architectures based on drives, as the Dorner’s

Pérez-Pinillos D., Fernández S. and Borrajo D..

PROVIDING DELIBERATION TO EMOTIONAL AGENTS.

DOI: 10.5220/0003167200980105

In Proceedings of the 3rd International Conference on Agents and Artiﬁcial Intelligence (ICAART-2011), pages 98-105

ISBN: 978-989-8425-40-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

PSI architecture used by Bach and Vuine (Bach and

Vuine, 2003) and also by Lim (Lim et al., 2005), that

offer a set of drives of different type, as certainty,

competence or afﬁliation.

Most of these works on emotional agents are

based on reactive behaviors as the work by Ca

namero.

When a drive is detected, it triggers a reactive compo-

nent that tries to compensate its deviation, taking into

account only the following one or two actions. Thus,

there is no inference being done on medium-long

term goals and the inﬂuence of emotions on how to

achieve those goals. Regarding deliberative models,

there are some works on emotions based on planning,

but mainly oriented to storytelling like emergent

narrative in FEARNOT! (Aylett et al., 2005) and the

interactive storytelling of Madame Bovary on the

Holodeck (Cavazza et al., 2007). The work of Gratch

and coauthors (Gratch, 1999; Gratch et al., 2002)

shows a relevant application of emotional models

to different research areas in artiﬁcial intelligence

and autonomous agents design, endowing them with

an ability to think and engage in socio-emotional

interactions with human users.

In the present work, a model of long term rea-

soning based on emotions and factors of personality

has been designed. It follows some ideas introduced

in (Avradinis et al., 2003) using concepts that already

appeared in Ca

namero’s works, like motivations

and the use of drives to represent basic needs. Our

model uses automated planning for providing long

term deliberation on effects of actions taking into

account not only the agents goals, but also the impact

of those actions in the emotional state of the agent.

Other models, as Rizzo’s works (Rizzo et al., 1997),

combine the use of emotions and personality to

assign preferences to the goals of a planning domain

model, but the changes in the emotional state happen

in another module. Thus, they are not really used

in the reasoning process. A similar integration of a

deliberative and a reactive model is the one in (Blythe

and Reilly, 1993) where the emotions reasoning is

performed again by the reactive component.

We have deﬁned a planning domain model that

constitutes the reasoning core of a client in a virtual

and multi-agent world (Fern

andez et al., 2008). It is a

client/server game oriented towards the intensive use

of Artiﬁcial Intelligence controlled Bots, and it was

designed as a test environment of several Artiﬁcial

Intelligence techniques. The game borrows the idea

from the popular video game THE SIMS. Each agent

controls a character that has autonomy, with its own

drives, goals, and strategies for satisfying those goals.

In this implementation, we introduce the concept

of how an agent prefers some actions and objects

depending on its preferences, its personality traits

and its emotional state, and the inﬂuence of those

actions on long term achievement of goals. Thus,

agents solved problems improving the quality of the

solution, achieving better emotional states.

The remainder of the paper describes the model

design, the description of the domain that implements

the model, the empirical results that validate the

model and the conclusions derived from the work,

together with future research lines.

2 MODEL DESIGN

Our aim in this work is to include emotions and hu-

man personality traits in a deliberative system, that

uses automated planning in order to obtain more re-

alistic and complex behavior of agents. These be-

haviors are necessary to implement a wide variety of

applications such as agents that help users to change

their way of life, systems related with marketing and

advertising, educational programs, systems that play

video games or automatically generate text. The goal

is to show that the use of emotional features, with the

establishment of preferences about certain actions and

objects in its environment, improves the performance

of a deliberative agent by generating better plans.

In the virtual world, an agent tries to cater for its

needs, its motivations, through speciﬁc actions and

interacting with different objects. Five basic needs

have been identiﬁed for the agent, which are easily

identiﬁable in human beings: hunger, thirst, tiredness,

boredom and dirtiness. Along with the ﬁrst three,

widely used in many systems, we have added dirti-

ness and boredom, which are more domain-speciﬁc

to add a wider variety of actions and get richer behav-

iors. These basic needs increase over time, so their

values increase as time goes by. Thus, the agent al-

ways needs to carry out actions to maintain its basic

needs values within reasonable limits.

To cater for each of these basic needs, the agent

must perform actions. For example, it can drink

to satisfy its thirst or sleep to recover from fatigue.

There are different actions to cater for the same need,

and the agent prefers some actions over others. Thus,

the agent may choose to read a book or play a game to

reduce boredom. Besides, the effects of those actions

can be different depending on its emotional state. It

will receive more beneﬁt from applying more active

actions when its emotional state is more aroused and

more passive or relaxed actions when it is calm.

To carry out each of these actions, the agent needs

to use objects of speciﬁc types. Thus, it will need

food to eat, a ball to play or a book to read. There are

PROVIDING DELIBERATION TO EMOTIONAL AGENTS

different objects of each type in its environment and

the agent has preferences over them. When an agent

executes an action with an object, its emotional state

is modiﬁed depending on the agent personality, and

preferences and activations for this object.

We have chosen to implement a model widely-

accepted in psychology that represents the emotional

state of an agent as a two-dimensional space of two

qualities: valence and arousal (Duffy, 1941). Va-

lence ranges from highly positive to highly negative,

whereas arousal ranges from calming or soothing to

exciting or agitating. The ﬁrst one is a measure of

the pleasantness or hedonic value, and the second one

represents the bodily activation. Other models use a

set of independent emotions, which requires deﬁning

a group of basic emotions. However, not all combi-

nations of values for these emotions are a valid emo-

tional state (e.g. the combination of maximum val-

ues in the emotions of joy and anger is not a real-

istic emotional state). In general, the valence and

arousal model can be shown to be equivalent to the

explicit representation of the usual set of emotions of

other computational cognitive simulations, though it

requires a simpler representation and reasoning. For

instance, an emotion such as happiness can be repre-

sented as high valence and high arousal. Both models

are recognized and defended by experts in psychol-

ogy, but we prefer the second alternative because it

makes processing easier and prevent invalid states. In

our model, the valence and the arousal are modiﬁed

by the execution of actions, so both values are mod-

iﬁed when an agent executes an action with an ob-

ject, depending on the agent preference and activation

for this object, the personality traits and the emotional

state. Our goal is that the agent generates plans to sat-

isfy its needs and to achieve the most positive value

of valence.

3 DOMAIN DESCRIPTION

In order to use domain-independent planning tech-

niques, we have to deﬁne a domain model described

in the standard language PDDL (Fox and Long,

2003). This domain should contain all the actions

that the agent can perform in order to achieve the

goals. Automated planning can be described as a

search for a solution on a problem space where, the

states are represented using a set of predicates, func-

tions and types, and the actions are described with a

set of preconditions and effects that model the state

transitions. An action is applicable only if all its pre-

conditions hold in the current state and executing the

action changes the current state by adding and delet-

ing the action effects. A problem is speciﬁed as an

initial state (true literals in the starting state) and a set

of goals. Also, an optimization metric (as in our case

valence and/or arousal) can be deﬁned. Our domain

has been designed based on the previous concepts of

drive, emotion, preference, activation and personal-

ity traits to represent each agent of the virtual world.

Now, we will deﬁne the different concepts composing

the model, in automated planning terms.

3.1 Drives

As already said, we use ﬁve drives: hunger, thirst,

tiredness, dirtiness and boredom. Drives are repre-

sented in the domain through functions. The ideal

value for all drives is established at zero. So, when

a drive has a value of zero, its need is totally satisﬁed.

Any other value means the intensity of the need and

the distance to the ideal value. The value of each drive

is increased as time goes by to represent the need rise.

To reduce it, the agent has to carry out some action.

For instance, the agent must eat to reduce the drive

hunger. Given that the drives increase with time, ev-

ery time an action is executed, one or more drives will

be decreased, but the rest will be increased. Thus, the

planning task becomes hard if we want all drives to

be fulﬁlled (below a given threshold).

3.2 Objects

Objects describe the different elements of the virtual

world. Objects may be of two kinds: resources (or

physical objects) and rooms. Resources represent

objects needed to carry out the actions to cater for

needs; for instance, food, balls, books, etc. Rooms

describe physical spaces, where the agents may move

and where resources are placed. Both kinds of ob-

jects are represented as planning types and several in-

stances of them will be present in each problem. Also

resources may be of two kinds: fungible resources

and non-fungible resources.

3.3 Personality Traits

Personality traits describe the agents personality and

are based on the Big Five factors model (open-

ness to experience, conscientiousness, extraversion,

agreeableness and neuroticism). Openness to expe-

rience involves active imagination, aesthetic sensitiv-

ity, preference for variety and intellectual curiosity.

Openness is modeled as a higher preference for new

experiences, i.e., an agent with high openness (open-

minded) tends to use and prefer new objects to known

objects, while an agent with low openness will tend

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

100

to prefer known objects to new objects. Neuroti-

cism represents the degree of emotional stability of

the agent. The bigger the neuroticism is, the smaller

the emotional stability is. So, neuroticism is imple-

mented as the variation factor of the emotional state

and is represented by the use of a PDDL function.

Thus, the emotional state of a neurotic agent will vary

more suddenly than a stable one when actions are ap-

plied, as described later.

Conscientiousness includes elements such as self-

discipline, carefulness, thoroughness, organization,

deliberation and need for recognition. We imple-

ment conscientiousness as a factor in the decrements

of the drives due to action executions, representing

how meticulous the agent is in carrying out the ac-

tion. Thus, an agent with a high value of contien-

tiouness gets a bigger effect when applying actions (a

bigger decrease of the involved drive). But, similarly,

the other drives will also increase proportionately to

the contientiouness value as time passes.

The last two factors, extraversion and agreeable-

ness, are related to social interaction. Thus, they will

be used in future versions of the system that include

multiple agents and interactions among them.

3.4 Emotional State

The agents emotional state is determined by two com-

ponents: valence and arousal. Valence represents

whether the emotional state of the individual is pos-

itive or negative and to which degree. Arousal rep-

resents the bodily activation or agitation. We repre-

sent them in the domain as PDDL functions. Since

we want to obtain plans that maximize the valence,

we have to deﬁne the planning problems metric ac-

cordingly. Even if PDDL allows generic functions to

be deﬁned as metrics, most current planners can only

deal with metrics that are deﬁned over minimizing an

increasingly monotonous function (no action can have

an effect that decreases its value), since metrics are

considered in PDDL as costs and each action has an

associated cost.

In our model, objects used in the actions can cause

valence both to increase (when the agent likes the ob-

ject) or decrease (when it does not like it). Therefore,

it is not possible to use the valence directly as the

problem metric. Instead, we deﬁne an increasingly

monotonous function, v-valence, that the planner

tries to minimize. Its increment depends on two fac-

tors. The ﬁrst one refers to the neuroticism of the

agent, which is the reverse of the emotional stabil-

ity. It measures the impact of any action on the agent

emotional state. Thus, the greater the agent neuroti-

cism, the greater the changes in its emotional state.

The second factor represents the type of change pro-

duced by the preferences of the agent.The greater the

preference for the action and for the object, the lower

the value of this factor is, and, therefore, the lower

the increase in the v-valence function (that the plan-

ner tries to minimize). Thus, each action increases

v-valence, with positives values between 0 and a

threshold in the following amount:

∆v = (

max

) × (p

max

−

+ p

)

where v is the value of v-valence, n the agent

neuroticism, n

max

the maximum possible value for

neuroticism, p

max

the maximum possible value for a

preference, p

the agent preference for the executed

action and p

the agent preference for the used ob-

ject. In case the object is new to the agent, p

=-1 and

we replace p

for the value of the agent openness.

Thus, the metric used consists on minimizing that

value, so we add the following to the planning prob-

lems:

(:metric minimize (v-valence)).

3.5 Preferences

Preferences describe the agent personal likes for each

physical object of its environment. They are repre-

sented as PDDL functions of the form:

(= (preference apple) 5)

These values are not modiﬁed during the planning

process and they are between zero, for the detested

objects, and ten, for the favourite ones. Preferences

can also describe the agent personal likes for each ac-

tion. They are represented as PDDL functions of the

form:

(= (read-preference) 5)

Again, these values are not modiﬁed during the

planning process and they are between zero, for the

detested actions, and ten, for the favourite ones. Pref-

erences affect the direction and degree of changes on

the value of the valence, produced by the effects of

actions.

3.6 Activations

Activations describe the effect over the agent arousal

for each physical object of its environment. They are

represented as PDDL functions of the form:

(= (activation apple) 5)

These values are not modiﬁed during the planning

process and they are between zero, for the objects that

relax, and ten, for the objects that agitate. Activations

can also describe the effect over the agent arousal for

PROVIDING DELIBERATION TO EMOTIONAL AGENTS

101

(:action READ

:parameters (?reading-object - reading-object)

:precondition (and (taken ?reading-object)

(not (time)))

:effect (and (time)

(decrease (boredom) (conscientiousness))

(when (and (< (boredom) 0))

(and (assign (boredom) 0)))

(when (and (< (preference ?reading-object) 0))

(and

(increase (valence) (* (/ (neuroticism) (max-neuroticism)) (- (/ (+ (preference ?reading-object) (read-preference))

(max-preference)) 1)))

(increase (v-valence) (* (/ (neuroticism) (max-neuroticism))(- (max-preference) (/ (+ (preference ?reading-object)

(read-preference)) 2))))))

(when (and (> (preference ?reading-object) 0))

(and

(increase (valence) (* (/ (neuroticism) (max-neuroticism)) (- (/ (+ (openness) (read-preference)) (max-preference)) 1)))

(increase (v-valence) (* (/ (neuroticism) (max-neuroticism))(- (max-preference) (/ (+ (openness) (read-preference)) 2))))))

(increase (arousal) (* (/ (neuroticism) (max-neuroticism)) (- (/ (+ (activation ?reading-object) (read-activation))

(max-activation)) 1)))

(increase (v-arousal) (* (/ (neuroticism) (max-neuroticism))(- (max-activation) (/ (+ (activation ?reading-object)

(read-activation)) 2))))))

Figure 1: Example of action (READ) to cater for the boredom need.

(:action EAT

:parameters (?food - food)

:precondition (and (taken ?food)

(not (time)))

:effect (and (time)

(decrease (hunger) (conscientiousness))

(when (and (< (hunger) 0))

(and (assign (hunger) 0)))

(when (and (< (preference ?food) 0))

(and

(increase (valence) (* (/ (neuroticism) (max-neuroticism)) (- (/ (+ (preference ?food) (eat-preference))

(max-preference)) 1)))

(increase (v-valence) (* (/ (neuroticism) (max-neuroticism))(- (max-preference) (/ (+ (preference ?food)

(eat-preference)) 2))))))

(when (and (> (preference ?food) 0))

(and

(increase (valence) (* (/ (neuroticism) (max-neuroticism)) (- (/ (+ (openness) (eat-preference)) (max-preference)) 1)))

(increase (v-valence) (* (/ (neuroticism) (max-neuroticism))(- (max-preference) (/ (+ (openness)

(eat-preference)) 2))))))

(increase (arousal) (* (/ (neuroticism) (max-neuroticism)) (- (/ (+ (activation ?food) (eat-activation)) (max-activation)) 1)))

(increase (v-arousal) (* (/ (neuroticism) (max-neuroticism))(- (max-activation) (/ (+ (activation ?food)

(eat-activation)) 2))))))

Figure 2: Example of an action (EAT) to cater for a need (hunger).

each action. They are represented as PDDL functions

of the form:

(= (read-activation) 5)

Again, these values are not modiﬁed during the

planning process and they are between zero, for the

actions that relax, and ten, for the actions that agitate.

3.7 Actions

Actions deﬁned in the domain describe activities that

the agent may carry out. There are ﬁve types of ac-

tions:

• Actions to cater for its needs: Each one

of these actions needs one object of a speciﬁc type

to decrease in one unit its corresponding drive

value. In this group of actions, we have deﬁned:

eat, drink, sleep, bath, shower, play, read,

watch and listen. Some of these actions require

that the agent has taken the object used, like eat,

drink or read. Others, however, only require

that the object is located in the same room of the

agent, like bath or sleep. In addition, some ac-

tions such as eat and drink decrease the avail-

able amount of the object used.

In Figures 1 and 2, we show two examples of

this type of action. We can see that the changes

in the agent emotional state (valence and arousal)

depend on the preferences, activations and per-

sonality traits, so we have an integrated model

of these concepts, that can affect how actions are

combined in order to solve the agents problems.

• TAKE and LEAVE actions: the agent uses them

to take and leave objects required to perform some

actions, like eat or drink.

• BUY action: the agent uses it to purchase new

resources. Agents must be in a shop and the re-

source must be available to be bought.

• GO action: allows the agents to move as Fig-

ure 3 shows.

• TIME action: It is a ﬁctitious action (Figure 4)

that represents the inﬂuence of the course of time

over the value of the drives. Its execution pro-

duces an increase on all drives, so that it simu-

lates the passing of time. The increment depends

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

102

(:action GO

:parameters (?place-from - place ?place-to - place)

:precondition (and (in ?place-from)(not (time)))

:effect (and (time)

(increase (valence) (* (/ (neuroticism) (max-neuroticism)) (- (/ (* (go-preference) 2) (max-preference)) 1)))

(increase (arousal) (* (/ (neuroticism) (max-neuroticism)) (- (/ (* (go-activation) 2) (max-activation)) 1)))

(increase (v-valence) (* (/ (neuroticism) (max-neuroticism)) (- (max-preference) (go-preference))))

(increase (v-arousal) (* (/ (neuroticism) (max-neuroticism)) (- (max-activation) (go-activation))))

(not (in ?place-from))

(in ?place-to)))

Figure 3: GO action.

on the agent’s conscientiousness. We also force

the planner to be executed after every other action

application (through the time predicate).

(:action TIME

:parameters ()

:precondition (and (time))

:effect (and

(increase (boredom) (* 0.1 (conscientiousness)))

(assign (boredom) (min (max-drive) (boredom)))

(increase (dirtiness) (* 0.1 (conscientiousness)))

(assign (dirtiness) (min (max-drive) (dirtiness)))

(increase (hunger) (* 0.1 (conscientiousness)))

(assign (hunger) (min (max-drive) (hunger)))

(increase (thirst) (* 0.1 (conscientiousness)))

(assign (thirst) (min (max-drive) (thirst)))

(increase (tiredness) (* 0.1 (conscientiousness)))

(assign (tiredness) (min (max-drive) (tiredness)))

(not (time))))

Figure 4: TIME action.

All actions (except for TIME) modify (in their ef-

fects) the emotional state that depend on the agent

preferences, activations and personality traits. Along

with the metric of the problem, this allows us to model

the agents behaviour. So, there are no hard constraints

on our model. All agents can perform all actions, but

they prefer (soft constraints) the ones that better suit

their preferences, personality and current emotional

state.

3.8 Goals

The agent motivation is to satisfy its basic needs, so

goals consist of a set of drives values that the agent

has to achieve. As an example, goals may consist

of the achievement of need values that are under a

given threshold. They could be very easily combined

with other kinds of standard planning goals, creating

other kinds of domains. For instance, we could deﬁne

strategy games where agents should accomplish some

tasks, taking into account also their needs.

4 EXPERIMENTS

We report here the results obtained with the proposed

model comparing its performance to a reactive model.

In the case of the deliberative model, we have used

an A

∗

search technique with the well-known domain-

independent heuristic of FF (Hoffmann, 2001). This

heuristic is not admissible, but even if it does not en-

sure optimality, it is good enough for our current ex-

perimentation. In the case of the reactive model, we

have used a function to choose the best action at each

step (to cover the drive with the higher value, i.e. the

worse drive). These search techniques have been im-

plemented in an FF-like planner, SAYPHI (De la Rosa

et al., 2007).

4.1 Experimental Setup

We have deﬁned several kinds of problems for this do-

main. In each problem, we have established a speciﬁc

initial need in one of the drives, which are called dom-

inant drives. Each of these dominant drives will have

a initial value higher than the rest of drives. Also, we

have deﬁned a problem where all ﬁve drives are domi-

nant drives. The goal is to fulﬁll all the agent needs, so

we have deﬁned it as having a value below a threshold

for all drives. Furthermore, for each action, the agent

has three objects to choose from, with varying degrees

of preference: preferred, indifferent and hated, and a

new object (the agents do not have an “a priori” pref-

erence for this object) for testing openness.

The experiments were performed with four differ-

ent personality models: (1) a standard personality (av-

erage values in all traits), (2) a neurotic personality

(high value of neuroticism and average values for the

rest), (3) an open-minded personality (high value of

openness and average values for the rest) and (4) a

meticulous personality (high value of conscientious-

ness and average values for the rest).

4.2 Results

Figures 5 to 8 show the end value of the (valence)

for each problem. In all cases, the value obtained by

the proposed deliberative model is signiﬁcantly better

than the reactive one. This is due to a better employ-

ment of the buy action and the reduction on go actions

of the deliberative model. The reactive model always

tries to satisfy the need associated to the most dom-

inant drive at each time. So, for instance, if reduc-

ing the current dominant drive requires drinking, and

there is no drink in the current agent room, then the

agent will move to another room where the drinking

PROVIDING DELIBERATION TO EMOTIONAL AGENTS

103

action can be accomplished. However, the delibera-

tive model reasons on a medium-long term, so if the

need in another drive, not being the dominant one, can

be satisﬁed in the current room, the plan will prefer to

reduce it now, even if the dominant drive increases a

bit. Most previous work on emotional agents would

mimic the reactive model, while our model is able to

take into account future recompenses in an integrated

way with other agents goals. We also see that if the

personality tends to be more neurotic, then the de-

liberative model is even better than the reactive one,

since actions effects are increased, and drives increase

more acutely.

Figure 5: Quality of the plans for the stable agent.

Figure 6: Quality of the plans for the neurotic agent.

Figure 7: Quality of the plans for the open-minded agent.

Figure 8: Quality of the plans for the meticulous agent.

5 CONCLUSIONS AND FUTURE

WORK

This work proposes a model of long term reasoning

integrating emotions, drives, preferences and person-

ality traits in autonomous agents, based on AI plan-

ning. The emotional state is modeled as two func-

tions: valence and arousal. This two-dimensional

model has been chosen because it is simpler and of-

fers the same representation capabilities as the rest of

emotional models. Anyhow, it is not difﬁcult now to

integrate any other emotional model. Thus, actions

produce variations in the valence depending on the

agent personality and agent preferences. The goal is

to generate plans that maximize the valence, while

satisfying the agent needs or drives. Given that cur-

rent planners only deal with monotonous functions as

metric functions, we converted the non-monotonous

valence into a monotonous one, v-valence. The re-

sults of the experiments show that the quality of the

solutions (measured as the value of the valence) im-

proves when the deliberative model is used compared

to the reactive one. Thus, the increase in the quality

of the solutions implies a more realistic behavior of

the agent.

The proposed model is the ﬁrst step in the devel-

opment of a richer and more complex architecture. In

the next future, we would like to include new actions

in the domain, especially those related to the pro-

cesses of social interaction, by including some com-

ponent that reasons about multi-agent interaction and

collaboration. Another future work is to model the

idea of well-being, which will focus the agent to keep

all its needs below a certain level along time. The

physiological well-being of the agent will inﬂuence

its emotional state altering the value of valence. This

idea is very related to the idea of continuous planning

to control the behaviour of virtual agents (Avradinis

et al., 2003).

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

104

REFERENCES

Avradinis, N., Aylett, R., and Panayiotopoulos, T. (2003).

Using Motivation-Driven Continuous Planning to

Control the Behaviour of Virtual Agents. In Interna-

tional Conference on Virtual Storytelling, pages 159–

162.

Aylett, R. S., Louchart, S., Dias, J., Paiva, A., and Vala, M.

(2005). Fearnot!: an experiment in emergent narra-

tive. Intelligent Virtual Agents, pages 305–316.

Bach, J. and Vuine, R. (2003). The AEP Toolkit for Agent

Design and Simulation. In MATES 2003, LNAI 2831,

pages 38–49. Springer.

Bates, J. (1994). The Role of Emotion in Believable Agents.

Communications of the ACM, 37:122–125.

Blythe, J. and Reilly, W. S. (1993). Integrating Reactive and

Deliberative Planning for Agents. Technical report,

Carnegie Mellon University, Pittsburgh, PA, USA.

Breazeal, C. (2003). Biological Inspired Intelligent Robots.

SPIE Press.

namero, D. (1997). Modeling motivations and emo-

tions as a basis for intelligent behavior. In First

International Symposium on Autonomous Agents

(Agents’97), pages 148–155. New York, NY: The

ACM Press.

namero, D. (2003). Designing Emotions for Activity Se-

lection in Autonomous Agents. MIT Press.

Cavazza, M., Lugrin, J., Pizzi, D., and Charles, F. (2007).

Madame bovary on the holodeck: Immersive interac-

tive storytelling. In Proceedings of the ACM Multime-

dia 2007. Augsburg, Germany: The ACM Press.

Costa, P. and McCrae, R. (1992). Revised NEO Person-

ality Inventory (NEO-PI-R) and NEO Five-Factor In-

ventory (NEO-FFI) manual. Odessa, FL: Psychologi-

cal Assessment Resources.

Damasio, A. R. (1994). Descartes’ Error. New York: Gos-

set; Putnam Press.

De la Rosa, T., Olaya, A. G., and Borrajo, D. (2007). Us-

ing Cases Utility for Heuristic Planning Improvement.

In Weber, R. and Richter, M., editors, Case-Based

Reasoning Research and Development: Proceedings

of the 7th International Conference on Case-Based

Reasoning, pages 137–148, Belfast, Northern Ireland,

UK. Springer Verlag.

Duffy, E. (1941). An explanation of emotional phenomena

without the use of the concept of emotion. Journal of

General Psychology, 25:283–293.

Fellous, J.-M. and Arbib, M. A. (2005). Who needs emo-

tions? : the brain meets the robot, volume Series in.

Oxford University Press, Oxford ; New York. edited

by Jean-Marc Fellous and Michael A. Arbibill. ; 25

cm.

Fern

andez, S., Asensio, J., Jim

enez, M., and Borrajo, D.

(2008). A Social and Emotional Model for Obtaining

Believable Emergent Behavior. In Traverso, P. and

Pistore, M., editors, Proceedings of The 13th Interna-

tional Conference on Artiﬁcial Intelligence: Method-

ology, Systems, and Applications (AIMSA-08), vol-

ume 5253/2008 of Lecture Notes in Computer Sci-

ence, pages 395–399, Varna, Bulgaria. Springer Ver-

lag.

Fox, M. and Long, D. (2003). Pddl2.1: An extension to pddl

for expressing temporal planning domains. Journal of

Artiﬁcial Intelligence Research, 20:61–124.

Frijda, N. H. (1988). The laws of emotion. American Psy-

chologist, 43:349–358.

Frijda, N. H. (1995). Emotions in robots. In Compar-

ative Approaches to Cognitive Science., pages 501–

516. In H.L. Roitblat and J.-A. Meyer (Eds.), Cam-

bridge, MA: The MIT Press.

Goldberg, L. (1993). The structure of phenotypic personal-

ity traits. American Psychologist., 48:26–34.

Gratch, J. (1999). Why you should buy an emotional plan-

ner. In Proceedings of the Agents 1999 Workshop on

Emotion-based Agent Architectures (EBAA 1999) and

ISI Research Report, pages 99–465.

Gratch, J., Rickel, J., Andr

e, E., Badler, N., Cassell, J., and

Petajan, E. (2002). Creating interactive virtual hu-

mans: Some assembly required. IEEE INTELLIGENT

SYSTEMS, 17:54–63.

Hoffmann, J. (2001). FF: The fast-forward planning system.

AI magazine, 22:57–62.

Lim, M. Y., Aylett, R., and Jones, C. M. (2005). Emer-

gent affective and personality model. In In The 5th

International Working Conference on Intelligent Vir-

tual Agents, pages 371–380. Kos, Greece. September

2005. Springer.

McCrae, R.R.and John, O. (1992). An introduction to the

ﬁve-factor model and its applications. Journal of Per-

sonality, 2:175–215.

Rizzo, P., Veloso, M., Miceli, M., and Cesta, A.

(1997). Personality-driven social behaviors in believ-

able agents. In In Proceedings of the AAAI Fall Sym-

posium on Socially Intelligent Agents, pages 109–114.

AAAI Press.

PROVIDING DELIBERATION TO EMOTIONAL AGENTS

105
