DEVELOPMENT OF A SOFTWARE QUALITY PLAN

FOR HOSPITALS

Vispi Shroff, Louise Reid, Sajid Hashmi, Gerard Mulligan, Daniel Sheehy

Keyang Xiang and Ita Richardson

Department of Computer Science and Information Systems, University of Limerick, Limerick, Ireland

Keywords: Hospital software quality plan, Health care software quality.

Abstract: This paper describes research into the development of a quality plan for the management of software in an

Irish Hospital. It studies relevant standards, models and legal acts. Synergies between the Irish Health

Service Executive’s Quality and Risk Management Standard and the Capability Maturity Model Integration

are utilised to build and study a quality plan. While exploring the possibility of utilising software

engineering quality standards to improve the quality standards within health care, this has also led to a

greater understanding of the interlinked issues within a hospital.

1 INTRODUCTION

The development of high-quality software is an issue

of great and growing importance throughout the

software industry (Gillies 1992). Medical software

in particular, which includes medical devices with

embedded software, can have a major impact on the

delivery of patient care. A good quality software

system accompanied by poor managerial practices

cannot provide the required quality of service.

Hospitals face challenges in terms of managing

software due to size, complexity of practices,

parallel management and resistance to change.

Clinicians are heavily dependent on information

to inform decision making on the management of

patients. Of concern in the Irish setting is the lack of

an integrated electronic patient record system.

Without quality software in place, there is little hope

of patients benefiting “both directly and indirectly

from improved data quality since accurate clinical

data are a prerequisite for high standards of care and

monitoring.” (Forster et al. 2008).

The accuracy of data, and consequently, of

information, is determined by the quality of the

software systems which produce that data. Within

Irish Hospitals there are a number of major and

minor systems in place. Patients, clinicians, nursing,

information technology, administration, data entry

personnel, researchers, governing bodies, and

external auditors, have different expectations,

understanding and requirements. The increasing use

of fourth generation databases such as Microsoft

Access is allowing staff with little expertise or

knowledge of data quality techniques to gather data

that is used in the crucial decision making processes

along the patient journey.

Current research yields few solutions to the

software quality issue. On reviewing the many

papers assessing the quality of clinical data there

appears to be a lack of recognition of correctness

and accuracy of data – which can be provided

through the provision of quality software systems.

Our aim is to address these issues by means of

some practical solutions. This paper proposes to

deliver an implementation of a software quality plan

for Irish hospitals through the use of recognised

healthcare and software quality models and

standards.

1.1 Research Methodology

A literature review of the major databases of

journals from 2000 was performed. This gave us the

opportunity to investigate quality issues (Brooks

1987) (Fitzgerald et al. 1979) within hospitals.

Interviews with hospital clinicians were also carried

out to understand the processes involved in the

provision of various inpatient services. Also,

existing standards for medical devices and health

record collection were investigated.

587

Shroff V., Reid L., Hashmi S., Mulligan G., Sheehy D., Xiang K. and Richardson I..

DEVELOPMENT OF A SOFTWARE QUALITY PLAN FOR HOSPITALS .

DOI: 10.5220/0003172305870591

In Proceedings of the International Conference on Health Informatics (HEALTHINF-2011), pages 587-591

ISBN: 978-989-8425-34-8

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

Comparing this output with existing software

standards, we established which software

development processes and practices were relevant

to the hospital situation.

For the purposes of implementation, we utilised

the Quality and Risk Management Standard (HSE

2007) issued by the Irish Health Service Executive,

also known as the HSE. The HSE is an executive

body with a mandate to run all the public health

services in the Republic of Ireland. This standard

was mapped against the best practices in selected

processes areas in the Capability Maturity Model

Integration, also known as CMMI for Development

(SEI 2006). The Data Protection Act 1998 and 2003,

IEEE Std. 730-2002 - IEEE Standard for Software

Quality Assurance Plans, EUROSOCAP (The

European Standards on Confidentiality and Privacy

in Healthcare) and the Health Insurance Portability

and Accountability Act (HIPAA) of 1996 were also

taken into account.

1.2 Quality & Risk Management

Standard

The QRMS Standard includes a statement of

standard and supporting criteria supported by an

internal control model (See Figure 1). There are 3

levels to assess compliance with the standard.

 Level 1- The service has approved

documentation which describes the process for

managing quality and risk.

 Level 2- The service can demonstrate

implementation of the approved

documentation.

 Level 3- The service can demonstrate that

there are processes in place to monitor the overall

effectiveness of the approved documentation.

1.3 Capability Maturity Model

Integrated (CMMI)

CMMI is a model based on a collection of best

practices that assist organisations in the

improvement of their software processes. This

model was chosen as it is open and freely available

for use. It is widely adopted and validated by

numerous companies and across various different

industries. While it is heavily used in the software

industry, there are also case studies available on the

implementation of CMMI in the health care services

industry (Forrester 2008).

CMMI was found to be the Model that mapped

most successfully to the Irish Health Service’s

Quality and Risk Management Standard.

Levels 1 and 2 in the QRMS map to the

Managed & Defined Levels in CMMI respectively.

Level 3 in the QRMS looks at the control and

monitoring of the effectiveness of the processes

involved. The Quantitatively Managed and

Optimising levels in CMMI facilitate that control

and drive towards continuous improvement and

optimisation.

This intuitive mapping demonstrates the

complimentary nature of standards and models and

creates a compelling argument for implementation

together.

2 QUALITY MANAGEMENT

PLAN

Based on the literature review and interviews of

clinicians within the hospitals, the following areas of

concern were identified. These areas of concern are

then addressed with the QRMS and CMMI models

guiding the activities to be carried out.

2.1 Project Planning

Within CMMI, the Project Planning and Project

Monitoring and Control process areas bring a degree

of structure to the hospital software quality plan.

(Cooke-Davies 2002) outlined the importance of

project and operations management working

together to as a critical factor to achieving project

success. When developing the hospital quality plan,

following a review of CMMI processes, we

developed goals, standards and practices. We also

developed a system to constantly review and action

the findings of the plan.

The HSE provided the following statement of

standard which was adopted for this quality plan

“Healthcare quality and risk are effectively managed

through the implementation of an integrated quality

and risk management system that ensures continuous

quality improvement” (HSE 2007, p.5).

Within a hospital quality plan, each software

system, its type, interfaces, stakeholders and

requirements must be defined. A communication

strategy for stakeholders must be developed. The

potential risks associated with each s system must be

identified and rated according to severity and

likelihood. A plan generated and implemented to test

each system for Integrity and Availability, the

use/under use and fit for use of each system must

continually be assessed and improved.

HEALTHINF 2011 - International Conference on Health Informatics

588

2.2 Risk Management

The use of medical devices and health information

systems in a hospital are an inherent risk to the

patient. Storing patient information on these systems

further exacerbates the level of this risk factor

(Sicotte et al. 2006). Failure of software in these

systems/devices can have potentially catastrophic

effects, leading to injury of patients or even death

(Burton et al. 2006).

The complexity of software has long been

considered a critical IT project risk factor (Sicotte et

al. 2006). Risk Management must be an integral part

of software project management processes and

include proactive risk assessment and reactive

incident management to avoid incidents recurring.

(Kavaler & Speigel 2003) define risk management

as “an organized effort to identify, assess and reduce

where appropriate, risk to patients, visitors, staff and

organizational assets”. These risks can be wide

ranging from scheduling and timing risks to

personnel management risks. The hospital’s

software development team can cope with these

classes of software risks by applying appropriate

systematic risk management activities to the

software development process (Galin 2004).

The CMMI divides Risk Management into three

main activities - defining a risk management

strategy, identify and analysing potential risks and

managing and mitigating risks which do take place.

Its purpose is to identify potential problems before

they occur so that risk-handling activities can be

planned and invoked as needed across the life of the

project to mitigate adverse impacts on achieving

objectives (Dhlamini et al. 2009).

Risk management for software and systems is

not just part of a software quality plan, but should be

an integral part of the overall risk management plan

for the services which hospitals provide.

2.3 Patient Data Security

Storing patient data in electronic form raises

concerns about Patient Privacy and Data Security

(Haak et al. 2003). To comply with regulations,

software systems and medical devices must

guarantee adequate protection of the confidentiality

integrity and availability of patient information. The

framework outlined in this paper assists a hospital to

adhere to the HIPAA Standard, EUROSOCAP and

the Data Protection Acts of 1998 and 2003.

However, having complete protection of patient data

in practice may not be feasible or plausible as it may

inhibit the doctor’s work (Anderson 1996).

There have been many published breaches of

patient information in the Irish press that highlight

some major security breaches with regard to medical

information (O'Hora 2010). These breaches include

unauthorized secondary use of patient records,

disclosure of patient records by hackers and

commercial vendors, and use of patient records by

employers (Baumer et al. 2000). Complying with

data security law and regulations is a difficult

challenge for hospital managers. Hospital workers

demand more and easier access to patient

information in order to provide the best care to their

patients. Also, vendors of healthcare software use

words like flexible, easy-to-use, accessible,

streamlined, and multidisciplinary to promote their

products. This is at odds with principles of data

security which talk about privacy and confidentiality

(Waldo 1999).

2.4 Integrity & Availability

Quality data can be defined as data which is fit for

use or purpose (Bertoni et al. 2009), (de Lusignan

2006). In addition, (Welzer et al. 2002) state that

quality data must be accurate, available, have

integrity, consistency, timeliness and completeness.

In some cases no data is better than inaccurate data.

(Welzer et al. 2002) found that data needs to be

modeled correctly first and then be correct, adequate

and available. It is then necessary to be quality

validated again.

(Bertoni et al. 2009) and (Berndt et al. 2001)

recognized the importance of placing emphasis on

data analysis when designing a database. This is also

backed up in the research by (Treweek & Flottorp

2001) pointing to the fact that it is natural that

stakeholders would like to make use of available

information but that “a major problem, however, is

simply getting at the data

2.5 Verification and Validation

Verification and Validation are the processes which

determine “whether or not products of a given

development or maintenance activity conform to the

requirement of that activity and whether or not the

final software product fulfils its intended purpose

and meets user requirements” (Abran et al. 2004).

Our research demonstrates that a software quality

plan for a hospital requires that each system is

audited regularly to ensure accurate and complete

data. It is inevitable that errors or misunderstandings

between data providers and database managers will

occur in a highly specialized area. Actions must be

DEVELOPMENT OF A SOFTWARE QUALITY PLAN FOR HOSPITALS

589

put in place to continually improve both the

timeliness and accuracy of the reports. The data

managers must receive feedback to ensure

continuous quality improvement.

Verification and validation are two distinct

process areas within the CMMI-Dev model. On a

reactive level, validation through CMMI processes

ensures that software and systems currently in use

actually do perform the activities they were

originally intended for. On a proactive level,

validation for new systems and software can take

place at all levels of creation of the software and

systems, be it at the time of design, implementation

or verification.

Verification is the other side of the coin. Having

ensured that the software or system being built is the

right system, verification ensures that what is being

built actually meets the requirements originally set

out for the software or system.

3 DISCUSSION

During the course of our research we found that

there are many problem areas within hospitals which

must be addressed to enhance the quality of service.

The root causes of many problems lie in the absence

or lack of enforcement of standards, legislation and

management processes. Additionally, software

systems are often not seen as being governed by the

existing health standards. For such use, health

standards need to be modified to take software

standards into account. Existing research on quality

in health care has focused on single issues - little has

been done to consider quality of service as a whole.

In this research, we have tried to address the overall

quality issues in hospitals by focusing on software

systems and the definition of relevant quality

processes. These ultimately will support guidelines

that hospitals may follow to improve their quality of

service and avoid many hazards. For future research,

we recognise that the validation of this approach is

very important and we aim to investigate the

advantages and disadvantages of using our proposed

plan. We are interested in understanding how quality

of service is improved through the implementation

and improvement of existing software processes.

4 CONCLUSIONS

This study investigated the problems in relation to

software quality, to uncover the root causes of

information and data which lacks quality, and to

propose the suitable strategies to address the issues.

Lack of processes and management of systems and

software within the hospital environment results in

poor quality of service and makes the goal of patient

safety more difficult. Different standards, models,

and published literature exist at the moment.

However, it is impossible to use any single one to

solve the existing diverse and complicated problem.

Through literature review and interviews with

clinicians, we have identified software process

requirements for a hospital quality plan and we have

proposed some guidelines based on existing health

care standards, quality standards and published

resources. We could not address all problem areas in

detail; instead we emphasized those issues which

were reported by existing literature to be the more

critical ones.

Quality assurance is an ongoing process which

must be monitored and controlled. Quality assurance

and improvement is the responsibility of all

stakeholders and these must be involved in all

iterations of the quality cycle.

ACKNOWLEDGEMENTS

This work is partially supported by Science

Foundation Ireland grant 3/CE2/I303_1 to Lero.

This work is also partially supported by

TRANSFoRm. TRANSFoRm is partially funded by

the European Commission – DG INSFO (FP7

247787).

REFERENCES

Abran, A. et al. eds., 2004. SWEBOK - Guide to the

Software Engineering Body of Knowledge, IEEE

Computer Society. Available at: http://www.computer.

org/portal/web/swebok/html/contents [Accessed July

23, 2010].

Anderson, R. J., 1996. Security in clinical information

systems. Available at: http://citeseerx.ist.psu.edu/

viewdoc/download?doi=10.1.1.31.4380&rep=rep1&t

ype=pdf [Accessed July 22, 2010].

Baumer, D., Earp, J. B. & Payton, F. C., 2000. Privacy of

medical records: IT implications of HIPAA. SIGCAS

Comput. Soc., 30(4), pp.40–47.

Berndt, D. J. et al., 2001. Healthcare Data Warehousing

and Quality Assurance. IEEE Xplore, pp.56-65.

Bertoni, M. et al., 2009. A Case Study on the Analysis of

the Data Quality of a Large Medical Database. In

DEXA '09: Proceedings of the 2009 20th International

Workshop on Database and Expert Systems

HEALTHINF 2011 - International Conference on Health Informatics

590

Application. Washington, DC, USA: IEEE Computer

Society, pp. 308–312.

Brooks, J., 1987. No Silver Bullet Essence and Accidents

of Software Engineering. Computer, 20(4), pp.10–19.

Burton, J., McCaffery, F. & Richardson, I., 2006. A risk

management capability model for use in medical

device companies. In WoSQ '06: Proceedings of the

2006 international workshop on Software quality.

New York, NY, USA: ACM, pp. 3–8.

Cooke-Davies, T., 2002. The "real" success factors on

projects. International Journal of Project

Management, 20(3), pp.185 - 190.

Dhlamini, J., Nhamu, I. & Kaihepa, A., 2009. Intelligent

risk management tools for software development. In

SACLA '09: Proceedings of the 2009 Annual

Conference of the Southern African Computer

Lecturers' Association. New York, NY, USA: ACM, pp.

33–40.

Fitzgerald, M., Hanna, F. & Taylor, D., 1979. The use of a

microprocessor in routine cardiac assessment. Journal

of Medical Engineering Technology, 3(4), pp.175-80.

Forrester, E., 2008. CMMI for Services - Overview

Presentation. Available at: https://bscw.sei.cmu.edu/

pub/bscw.cgi/d683162/CMMI-SVC%20Health%20Ca

re%20Example%20v3.ppt [Accessed July 22, 2010].

Forster, M. et al., 2008. Electronic medical record

systems, data quality and loss to follow-up: survey of

antiretroviral therapy programmes in resource-limited

settings. Bulletin of the World Health Organization,

86(12), pp.939-947.

Galin, D., 2004. Software quality assurance: From Theory

to Implementation 1st ed., Essex, UK: Pearson

Education Limited.

Gillies, A. C., 1992. Software Quality: Theory and

Management, London, UK, UK: Chapman & Hall,

Ltd.

Haak, M. V. D. et al., 2003. Data security and protection

in cross-institutional electronic patient records.

International Journal of Medical Informatics, 70(2-3),

pp.117 - 130.

HSE, 2007. Quality & Risk Management Standard.

Available at: http://www.hse.ie/eng/About/Who/

OQR009_20080221_v3_Quality_and_Risk_Managem

ent_Standard.pdf [Accessed July 22, 2010].

Kavaler, F. & Speigel, A. D., 2003. Risk Management in

Health Care Institutions: A Strategic Approach 2nd

ed., London: Jones and Bartlett Publishers, Inc.

Available at: http://books.google.com/books?hl=en&

lr=&id=5gwsBRhEd70C&oi=fnd&pg=PR19&dq=Ris

k+management+in+health+care+institutions:+a+str

ategic+approach&ots=_ypn09BqTP&sig=2lC0a7dJ2

UC_xbb-9y_ynzAIabk#v=onepage&q&f=false

[Accessed July 22, 2010].

de Lusignan, S., 2006. The optimum granularity for

coding diagnostic data in primary care: Report of a

workshop of the EFMI Primary Care Informatics

Working Group at MIE 2005. Informatics in Primary

Care, 14(2), pp.133-137.

O'Hora, A., 2010. Watchdog warns HSE for repeated

security breaches of patient data. Irish Independant.

Available at: http://www.independent.ie/health/watch

dog-warns-hse-for-repeated-security-breaches-of-

patient-data-2131144.html [Accessed July 22, 2010].

SEI, 2006. CMMI for Development : Version 1.2.

Available at: http://www.sei.cmu.edu/downloads/

cmmi/CMMI-DEV-v1.2.doc [Accessed July 22, 2010].

Sicotte, C. et al., 2006. A Risk Assessment of Two

Interorganizational Clinical Information Systems.

Journal of the American Medical Informatics

Association, 13(5), pp.557- 566.

Treweek, S. & Flottorp, S., 2001. Using electronic medical

records to evaluate healthcare interventions. Health

Informatics Journal, 7(2), pp.96 -102.

Waldo, B. H., 1999. Managing Data Security: Developing

a Plan to Protect Patient Data. Nursing Economic$,

17(1), pp.49 - 52.

Welzer, T. et al., 2002. Medical Diagnostic and Data

Quality. In Proceedings of the 15th IEEE Symposium

on Computer-Based Medical Systems. 15th IEEE

Symposium on Computer-Based Medical Systems.

IEEE Xplore.

DEVELOPMENT OF A SOFTWARE QUALITY PLAN FOR HOSPITALS

591
