A SEMANTIC SCRAPING MODEL FOR WEB RESOURCES

Applying Linked Data to Web Page Screen Scraping

Jos

e Ignacio Fern

andez-Villamor, Jacobo Blasco-Garc

ıa, Carlos

A. Iglesias and Mercedes Garijo

Departamento de Ingnier

ıa de Sistemas Telem

aticos, Universidad Polit

ecnica de Madrid, Madrid, Spain

Keywords:

Information extraction, Linked data, Screen scraping.

Abstract:

In spite of the increasing presence of Semantic Web Facilities, only a limited amount of the available resources

in the Internet provide a semantic access. Recent initiatives such as the emerging Linked Data Web are

providing semantic access to available data by porting existing resources to the semantic web using different

technologies, such as database-semantic mapping and scraping. Nevertheless, existing scraping solutions are

based on ad-hoc solutions complemented with graphical interfaces for speeding up the scraper development.

This article proposes a generic framework for web scraping based on semantic technologies. This framework

is structured in three levels: scraping services, semantic scraping model and syntactic scraping. The ﬁrst

level provides an interface to generic applications or intelligent agents for gathering information from the

web at a high level. The second level deﬁnes a semantic RDF model of the scraping process, in order to

provide a declarative approach to the scraping task. Finally, the third level provides an implementation of the

RDF scraping model for speciﬁc technologies. The work has been validated in a scenario that illustrates its

application to mashup technologies.

1 INTRODUCTION

A growing amount of data is available to users in the

web. Web users can enjoy plenty of services and in-

formation in e-commerce web sites, electronic news-

papers, blogs and social networks. Although this data

is available for its consumption by users, its format

is not suited for automated agents and computer pro-

grams. This has favoured the research in several ﬁelds

such as web content mining (Kosala and Blockeel,

2000) or Semantic Web (Berners-Lee et al., 2001),

that seek manners to build linked interoperable data

that can be automatically processed by software sys-

tems.

Several approaches such as Linked Data initiative

(Bizer et al., 2009) are favouring the publication of

annotated data in web resources, so that automatic

processes can actually consume this data and perform

other operations. Similarly, other research ﬁelds at-

tempt to take advantage of this amount of available

information, such as mashup applications. However,

ontologies and applications that expose their data are

not widespread, constraining the Linked Data initia-

tive, mashups and service composition.

The ﬁeld of Web Content Mining applies data

mining techniques to the discovery and extraction of

information available on the Web. Web Content Min-

ing comprises several research ﬁelds such as Infor-

mation Extraction or Natural Language Processing,

which research related techniques that are used to ex-

tract data from web documents (Chang et al., 2006).

Approaches to the problem of extracting informa-

tion out of HTML documents considers processing ei-

ther the DOM tree or the resulting rendering informa-

tion. The ﬁrst approach involves deﬁning an extractor

or wrapper (Kushmerick, 1997) (Kushmerick, 2000)

that selects the relevant information out of the DOM

tree. The latter is a vision-based approach that at-

tempts to provide a more general solution to the prob-

lem by assuming that similar content types have simi-

lar visual features (Wei et al., 2006) (Cai et al., 2003).

In this paper, we deﬁne a framework for web

scraping for the extraction of RDF graphs that rep-

resent content in HTML documents. This framework

allows deﬁning services based on screen scraping by

linking data from RDF graphs with contents deﬁned

in HTML documents. We have used this model to

build a semantic scraper that uses RDF-based extrac-

tors to select fragments and data from web documents

and build RDF graphs out of unstructured informa-

tion. The model enables to generate graphs in differ-

ent representations by keeping the original sources in

451

Ignacio Fernández-Villamor J., Blasco-García J., Á. Iglesias C. and Garijo M..

A SEMANTIC SCRAPING MODEL FOR WEB RESOURCES - Applying Linked Data to Web Page Screen Scraping.

DOI: 10.5220/0003185704510456

In Proceedings of the 3rd International Conference on Agents and Artiﬁcial Intelligence (ICAART-2011), pages 451-456

ISBN: 978-989-8425-41-6

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

Figure 1: Semantic scraping framework.

the resulting graph.

The paper is organized as follows. First, the

framework for scraping of web resources is deﬁned

in section 2. The development of a scenario with se-

mantic scrapers that uses the model is described in

section 3. Finally, related work is compared with the

one presented in this paper, and the main conclusions

and future research lines are presented.

2 SEMANTIC SCRAPING

FRAMEWORK

In this paper, a framework for using semantic ex-

tracted data from the web is deﬁned, which is shown

in ﬁgure 1. The model considers three levels of ab-

straction in order to provide an integrated model for

semantic scraping:

• Scraping service level. This level comprises ser-

vices that make use of semantic data extracted

from unannotated web resources. Possible ser-

vices that beneﬁt from using this kind of data can

be opinion miners, recommenders, mashups that

index and ﬁlter pieces of news, etc.

• Semantic scraping level. This level deﬁnes a

model that maps HTML fragments to semantic

web resources. By using this model to deﬁne the

mapping of a set of web resources, the data from

the web is made available as knowledge base to

scraping services. This level provides semantics

to the syntactic scraping capabilities of the level

below.

• Syntactic scraping level. This level gives sup-

port to the interpretation to the semantic scraping

model. Wrapping and Extraction techniques such

as DOM selectors are deﬁned at this level for their

use by the semantic scraping level.

The framework is stacked on top of the REST archi-

tectural style (Fielding, 2000). This architectural style

is the one the World Wide Web is based on, and de-

ﬁnes a hypermedia distributed system. The additional

semantics and data mappings that are necessary to al-

low information scraping on a RESTful architecture

are deﬁned by the upper levels of our framework.

In this section, the levels deﬁned in the framework

are described in further detail.

2.1 Scraping Service Level

This level comprises all services and applications that

make use of the semantic scraping level by provid-

ing value to an end user. Services such as opinion

miners, recommenders, mashups, data mining appli-

cations or any agent-based service beneﬁt from an in-

creased level of knowledge. Other approaches that

make use of the semantic scraping facilities can be au-

tomatic service composition for automatic generation

of new applications out of existing services. Scraping

technologies allow getting wider access to data from

the web for these kinds of services.

The paradigm behind scraping services has sub-

tle differences from that behind traditional Seman-

tic Web applications or knowledge-based systems.

While annotated data in the Semantic Web allows au-

tomatic knowledge extraction and retrieval by auto-

matic agents, data in unstructured web documents re-

quire prior supervision of some kind to allow infor-

mation extraction. This implies that when designing

a scraping service some of the following steps might

be required:

• Scraping data identiﬁcation. Data that wants to be

scraped and merged with other knowledge is iden-

tiﬁed in this task. Target web sites and resources

are identiﬁed for fragment extraction.

• Data modelling. A model to represent the ex-

tracted data is deﬁned in this task. Either existing

ontologies might be available or new ones should

be deﬁned. The result from this step is an ontol-

ogy that ﬁts the data that needs to be extracted. A

bounded context, i.e. a conceptual context where

a domain model has a non-ambiguous meaning,

should be identiﬁed in order to separate domain

models of similar ﬁelds. Methodologies for the

deﬁnition of ontologies can be useful for this task.

• Extractor generalization. In order to perform mas-

sive extractions, enough samples need to be col-

lected to generalize an appropriate extractor. This

collection of samples needs to be provided to a

human administrator or an automated or semi-

automated module. Using this data set, one or

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

452

more extractors are deﬁned at the semantic scrap-

ing level and serve to provide additional knowl-

edge to the scraping service.

Consider a movie recommender that requires ex-

tracting data from the Internet Movie Database. Data

about reviews are added to the recommender’s knowl-

edge in order to enable collaborative ﬁltering of

movies. Reviews and user reviewers are therefore

the identiﬁed data to scrape. As long as an exist-

ing movie ontology is deﬁned, no new modelling

would be needed for this task. Also, in case extrac-

tors are built automatically using a machine learning

approach, data samples should belong to the bounded

context of cinema and movies. Therefore, considering

our framework, the movie recommender is a scraping

service that makes use of additional knowledge avail-

able in unstructured resources from the web.

2.2 Semantic Scraping Level

This level deﬁnes the mapping between web data and

semantic web resources. An RDF model that allows

formalizing this mapping has been deﬁned.

Applying the model to the deﬁnition of extractors

of web resources allows separating the declarative

from the procedural model in the web content extrac-

tion process. This enables implementing technology-

independent extractors or automating certain tasks

such as focused and personalized scraping, as will be

described in section 3.

The proposed model allows to reference HTML

fragments in RDF and deﬁne web content extractors,

being a basis for the programmatic deﬁnition of ex-

tractors for screen scraping. This requires bridging

the gap between both RDF and HTML’s data models.

HTML is a markup language for documents with a

tree-structured data model. On the other hand, RDF’s

data model is a collection of node triples, deﬁned by

a subject, a predicate, and an object. Each node can

be a text literal, a resource (identiﬁed by a URI) or a

blank node.

A model comprisen of a vocabulary of RDF terms

has been deﬁned to represent HTML fragments and

their mapping to RDF resources. This serves as a

model for the semantic scraping level. A summary

of the model is shown in ﬁgure 2. The basic classes

of the model are described next:

Scraper. A scraper is an automatic agent that is able

to extract particular fragments out of the web.

Fragment. Any element of an HTML document. It

serves to represent and traverse a whole subtree

of a document.

Figure 2: Semantic scraping RDF model.

Selector. A condition that indicates which this ele-

ment is. Different selector terms are deﬁned for

each selector type. Selectors can be XPath expres-

sions, CSS selectors, URI selectors, etc. Selectors

are means to identify a web document fragment.

Mapping. The mapping between a fragment and an

RDF resource or blank node. An identiﬁer is de-

ﬁned to map the fragment to a URI. A predicate

between the parent’s mapped fragment and this is

deﬁned to produce an RDF triple. Also, an RDF

class can be assigned to the mapped resource of

this fragment.

Presentation. The representation of a fragment. This

includes HTML attributes as well as visual param-

eters such as color, size or font.

The proposed vocabulary serves as link between

HTML document’s data and RDF data by deﬁning a

model for scraping agents. With this RDF model, it

is possible to build an RDF graph of HTML nodes

given an HTML document, and connects the top and

lowest levels in the scraping framework to the seman-

tic scraping level.

2.3 Syntactic Scraping Level

This level deﬁnes the required technologies to extract

data from web resources. It provides a basis for a

interpretation of the semantics deﬁned in the semantic

scraper level’s RDF model. Some of the considered

scraping techniques in this level are the following:

• Content Style Sheet selectors. Content Style

Sheets deﬁne the visual properties of HTML el-

ements. These visual properties are mapped to el-

ements through the use of CSS selectors, deﬁned

through a speciﬁc language. Therefore, CSS is

one technology that serves to select and extract

data.

• XPath selectors. Similarly to CSS selectors, the

XML Path Language

is a different language for

HTML node selection.

http://www.w3.org/TR/xpath/

A SEMANTIC SCRAPING MODEL FOR WEB RESOURCES - Applying Linked Data to Web Page Screen Scraping

453

• URI patterns. URI patterns allow to select web

resources according to a regular expression that

is applied on the resource’s URI. While XPath or

CSS selectors are able to select an element at doc-

ument level, URI patterns allow selecting docu-

ments, i.e. resources representations, according

to the resource’s URI.

• Visual selectors. Visual information can be used

to select nodes. HTML nodes are rendered with a

set of visual properties given by the used browser.

It is common that human users prefer uniform

web designs. Web designers thus make elements

of a same kind to be rendered with similar visual

properties to help identiﬁcation. A visual selector

is a condition that combines several visual proper-

ties of an element to identify the element’s class.

Other kinds of selectors that process HTML’s inner

text are available as well and ﬁt into the model. This

way, extractions from natural language parsing or text

tokenization are possible.

Selectors at the syntactic scraping level allow to

identify HTML nodes. Either a generic element or

an unambiguously identiﬁed element can be selected

using these techniques. Their semantics are deﬁned

in the upper semantic scraping level, allowing to map

data in HTML fragments to RDF resources.

An example of the usage of selectors for a news

scraper is shown in ﬁgure 3. In this case, a scraper is

deﬁned that is able to scrape a set of posts (by using

the SIOC ontology (Breslin et al., 2006)) from a spe-

ciﬁc URI. A sample mapped RDF graph is shown in

the ﬁgure, too.

The scraper can be retrieved by using the follow-

ing SPARQL

query at a scraper store:

SELECT ?scraper

WHERE { ?scraper rdf:type sc:Scraper

?scraper sc:extracts ?fragment

?fragment sc:mapping ?mapping

?mapping sc:type sioc:Post

}

With that, all the stored scrapers that extracts posts

will be retrieved, allowing further queries to them to

obtain the desired information.

3 VALIDATION

A semantic scraper that follows the deﬁned frame-

work has been developed

. The deﬁned RDF model is

used at the semantic scraping level. Open Source We-

bkit library

has been used to implement the scraper at

http://www.w3.org/TR/rdf-sparql-query/

http://github.com/josei/scrappy

http://webkit.org/

the syntactic scraping level. Both a scraping API and

an HTTP proxy pattern interface are supported by the

scraper.

The considered scenario points out some of the

beneﬁts of using a semantic scraper. The scenario has

the goal of showing the most commented sports news

on a map, according to the place they were taken. The

main techonological challenges behind this scenario

are (i) the lack of semantic annotations in the sports

news web sites, (ii) the potential semantic mismatch

among these sites and (iii) the potential structural mis-

match among these sites.

The rationale to use semantic scraping resides in

that many of the available sport news web sites do not

provide semantic annotations nor microformats, and

do not include some relevant information in their RSS

feeds, such as location, users’ comments or ratings.

The general approach to realise this scenario

would consist of (i) deﬁning the data schema to be ex-

tracted from selected sports news web sites, (ii) deﬁn-

ing and implementing these extractors and (iii) deﬁn-

ing the mashup by specifying the sources, mashup op-

erators and renderers. This paper is focused on the

ﬁrst two steps. First, the extracted data is modelled

using an ontology derived from SportsML

, a model

for representing sports data.

Then, the scraping rules are deﬁned. Our frame-

work allows the deﬁnition of these rules based on

structural or visual properties, according to the model

presented previously. In order to avoid massive scrap-

ing, semantic properties are used for deﬁning this

task. For example, scrape only web resources of this

news category which is obtained from the newspa-

pers’ home page. Some examples of the expressivity

of this approach are: identify the news title are the one

with big font and a link to a detail page, or select only

news with an associated image. Also, other types of

rules are possible, such as the ones shown in ﬁgure 3.

Also, when considering scraping, recursive access

to resources needs to be performed. For instance, a

piece of news may show up as a title and a brief sum-

mary in a newspaper’s homepage, but offers the whole

content (including location, authors, and more) in its

own URL. This can make scraping a time consuming

task. Our model allows focused scraping, i.e., scrap-

ing only the required resources, considering a given,

high-level goal.

In this scenario, focused scraping is performed by

limiting the scraping to sports news. Category infor-

mation in newspapers’ home pages is used to reduce

the number of recursive steps that need to be per-

formed in order to retrieve all the information.

Following this approach, the data is extracted and

http://www.iptc.org/cms/site/index.html?channel=CH0105

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

454

Figure 3: Example of semantic scraper.

the news are placed on a map. This shows how the de-

ﬁned framework can be applied and how this research

work can be integrated with mashup technologies.

4 RELATED WORK

The related work in web scraping technology can be

classiﬁed attending to the targeted user, the end user

or the programmer.

In the ﬁrst category, we can point out the systems

Piggy Bank (Huynh et al., 2007), Reform (Toomim

et al., 2009), Thresher (Hogue, 2005) and Mar-

mite (Wong and Hong, 2007). Piggy Bank (Huynh

et al., 2007) provides also a web scraper that ex-

tracts RDF out of web pages. Nevertheless, their

approach is based on a browser plugin that provides

a visual interface for programming the scraper and

produces JavaScript as a result. Reform (Toomim

et al., 2009) proposes that scrapers can be attached

to web pages by non programmers. The system is

also integrated in Firefox web browser and allows

users to annotate which parts of the web page contains

a predeﬁned pattern, and includes machine learning

techniques for generalisating these annotations in the

scraper. Thresher (Hogue, 2005) provides an interface

where users can specify examples of semantic pat-

terns by highlighting and assigning relevant features

in the semantic web browser Haystack. The fact that

these tools cannot be compatible, since their scrapers

are based on JavaScript code, points out some of the

beneﬁts of our proposal. First, the deﬁnition of a gen-

eral model for scrapers allows separating its program-

ming model for its interface. In addition, our proposal

deﬁnes scraping task goals at the knowledge level in

RDF. In this way, scraping task goals can be queried,

analysed and composed in RDF, which is not feasible

if we specify these goals in an implementation lan-

guage such as JavaScript.

In the second category, we can point out Chicken-

foot (Bolin et al., 2005), Denodo (Pan et al., 2002).

Both deﬁne JavaScript libraries for scraping. This

work ﬁts in the implementation level of our frame-

work for implementing the scraping of a given RDF

scraping speciﬁcation, which enables interoperability

across scraping implementation libraries.

GRDDL (Haza

el-Massieux and Connolly, 2004)

is the standard technology for extracting RDF out

of HTML or XML documents. In order to ex-

tract the RDF semantic information, a GRDDL-aware

agent should read the GRDDL annotations of the

HTML/XML resources, which are usually provided

as XSLT annotations. Our approach goes one step

further than GRDDL, even though it is compatible

with it. Our approach can address both GRDDL-

annotated resources as well as non-annotated re-

sources. GRDDL proposes a syntactic approach that

can beneﬁt from the reuse of scrapers among web

sites. However, GRDDL speciﬁes an unidirectional

mapping between the implementation (XSLT scraper)

and the web resource. In contrast, our approach pro-

vides a semantic framework which enables to deref-

erence scraped data and reason about the scraping

process. This enables enhacements in the scraping

process, such as reasoning on visual aspects of the

web resource, distributed scraping using multiagent

systems, or focused scraping and reasoning on the

scraped resources (for example, search a piece of

sports news about Rafael Nadal taken in China).

5 CONCLUSIONS AND FUTURE

WORK

In this paper, the problem behind web information ex-

A SEMANTIC SCRAPING MODEL FOR WEB RESOURCES - Applying Linked Data to Web Page Screen Scraping

455

traction and screen scraping has been outlined, while

the main approaches to it have been summarized. The

lack of an integrated framework for scraping data

from the web has been identiﬁed as a problem, and

this paper presents a framework that tries to ﬁll this

gap.

An RDF model for web scraping has been de-

ﬁned at the semantic scraping level. The objective of

this RDF model should not be confused with that of

RDFa. RDFa deﬁnes a format for marking up HTML

elements to extract an RDF graph. Our model com-

plements RDFa by allowing RDF graphs to refer to

data that is present in HTML fragments in an unanno-

tated HTML document. This enables an open frame-

work for web scraping. The tasks of building an RDF

graph out of a web document has been shown. With

this, a semantic screen scraper has been developed.

The semantic screen scraper produces RDF graphs

out of web documents and RDF-deﬁned extractors,

that offer interoperable scraping information.

Future works involve experimenting with the au-

tomatic construction of mappings out of incomplete

ones or unstructured HTML resources. While some

of the approaches to information extraction deal with

wrapper induction or vision-based approaches, the

modelling of web page fragments as web resources

changes the paradigm behind this task. Approaches

such as machine learning or graph analysis can be

combined and applied to this different scenario.

ACKNOWLEDGEMENTS

This research project is funded by the European Com-

mission under the R&D project OMELETTE (FP7-

ICT-2009-5), and by the Spanish Government un-

der the R&D projects Contenidos a la Carta (TSI-

020501-2008-114) and T2C2 (TIN2008-06739-C04-

01).

REFERENCES

Berners-Lee, T., Hendler, J., Lassila, O., et al. (2001). The

semantic web. Scientiﬁc american, 284(5):28–37.

Bizer, C., Heath, T., and Berners-Lee, T. (2009). Linked

data-the story so far. sbc, 14(w3c):9.

Bolin, M., Webber, M., Rha, P., Wilson, T., and Miller, R. C.

(2005). Automation and customization of rendered

web pages. Symposium on User Interface Software

and Technology, page 163.

Breslin, J., Decker, S., Harth, A., and Bojars, U. (2006).

SIOC: an approach to connect web-based communi-

ties. International Journal of Web Based Communi-

ties, 2(2):133–142.

Cai, D., Yu, S., Wen, J.-R., and Ma, W.-Y. (2003). Extract-

ing content structure for web pages based on visual

representation. In Proc.5 th Asia Paciﬁc Web Confer-

ence, pages 406–417.

Chang, C., Kayed, M., Girgis, M., and Shaalan, K. (2006).

A survey of web information extraction systems.

IEEE Transactions on Knowledge and Data Engineer-

ing, pages 1411–1428.

Fielding, R. T. (2000). Architectural Styles and the Design

of Network-based Software Architectures. PhD thesis,

University of California.

Haza

el-Massieux, D. and Connolly, D. (2004). Glean-

ing resource descriptions from dialects of languages

(grddl). World Wide Web Consortium, W3C Coordi-

nation Group Note NOTE-grddl-20040413.

Hogue, A. (2005). Thresher: Automating the unwrapping

of semantic content from the world wide web. In Pro-

ceedings of the Fourteenth International World Wide

Web Conference, pages 86–95. ACM Press.

Huynh, D., Mazzocchi, S., and Karger, D. (2007). Piggy

bank: Experience the semantic web inside your web

browser. Web Semantics: Science, Services and

Agents on the World Wide Web, 5(1):16–27.

Kosala, R. and Blockeel, H. (2000). Web mining research:

A survey. ACM SIGKDD Explorations Newsletter,

2(1):1–15.

Kushmerick, N. (1997). Wrapper induction for information

extraction.

Kushmerick, N. (2000). Wrapper induction: Efﬁciency and

expressiveness. Artiﬁcial Intelligence, 118:2000.

Pan, A., Raposo, J.,

Alvarez, M., Montoto, P., Orjales,

V., Hidalgo, J., Ardao, L., Molano, A., and Vi

na, A.

(2002). The denodo data integration platform. Very

Large Data Bases, page 986.

Toomim, M., Drucker, S. M., Dontcheva, M., Rahimi, A.,

Thomson, B., and Landay, J. A. (2009). Attaching

UI enhancements to websites with end users. Confer-

ence on Human Factors in Computing Systems, pages

1859–1868.

Wei, L., Meng, X., and Meng, W. (2006). Vision-based web

data records extraction. In WebDB.

Wong, J. and Hong, J. I. (2007). Making mashups with

marmite:towards end-user programming for the web.

Conference on Human Factors in Computing Systems,

page 1435.

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

456
