BLOCKING UNDERHAND ATTACKS BY HIDDEN COALITIONS

Matteo Cristani, Erisa Karaﬁli and Luca Vigan`o

Dipartimento di Informatica, Universit`a degli Studi di Verona, Verona, Italy

Keywords:

Multi-agent systems, Coalitions, Security, Blocking attacks.

Abstract:

Similar to what happens between humans in the real world, in open multi-agent systems distributed over the

Internet, such as online social networks or wiki technologies, agents often form coalitions by agreeing to act

as a whole in order to achieve certain common goals. However, agent coalitions are not always a desirable

feature of a system, as malicious or corrupt agents may collaborate in order to subvert or attack the system.

In this paper, we consider the problem of hidden coalitions, whose existence and the purposes they aim to

achieve are not known to the system, and which carry out underhand attacks, a term that we borrow from

military terminology. We give a ﬁrst approach to hidden coalitions by introducing a deterministic method that

blocks the actions of potentially dangerous agents, i.e. possibly belonging to such coalitions. We also give

a non-deterministic version of this method that blocks the smallest set of potentially dangerous agents. We

calculate the computational cost of our two blocking methods, and prove their soundness and completeness.

1 INTRODUCTION

Context and Motivation. Similar to what hap-

pens between humans in the real world, in open multi-

agent systems (Davidsson, 2001) distributed over the

Internet, such as online social networks or wiki tech-

nologies, agents often form coalitions by agreeing to

act as a whole in order to achieve certain common

goals. For instance, agents may wish to collaborate in

order to jointly create and use a group cryptographic

key for ensuring the conﬁdentiality and/or integrity of

information shared within the group, e.g. (Rafaeli and

Hutchison, 2003), or to partake in a mix network or

some other anonymous remailer to achieve unobserv-

ability of communications, e.g. (Chaum, 1981), or to

create secret interest groups within online social net-

works, e.g. (Sorniotti and Molva, 2010). However,

agent coalitions are not always a desirable feature of

a system, as malicious or corrupt agents may collab-

orate in order to subvert or attack the system. For

instance, such agents may collaborate to attack the in-

formation in transit over different channels in a web

service architecture or in a distributed wired and/or

wireless computer network, e.g. (Wiehler, 2004), or

they might forge and spread false information within

the system, e.g. (Hahn et al., 2007).

In order to be able to rigorously formalize and

reason about such positive and negative properties of

agent coalitions, and thereby allow for the prevention

or, at least, the identiﬁcation of the entailed vulnera-

bilities, a number of different formal approaches have

been recently proposed, such as (

Agotnes et al.,

2008; Alur et al., 1998; van der Hoek et al., 2005;

Oravec and Fogel, 2006; Pauly, 2001; Troquard et al.,

2009; van der Hoek and Wooldridge, 2005).

In this paper, we consider the problem of hidden

coalitions: a coalition is hidden in a system when

its existence and the purposes it aims to achieve are

not known to the system. Hidden coalitions carry

out underhand attacks, a term that we borrow from

military terminology. These attacks are particularly

subtle since the agents that perform them are not out-

siders but rather members of the system whose se-

curity properties are posed under threat. Moreover,

the mere suspect that a group of individuals act as a

whole is typically insufﬁcient to come to a decision

about their permanence as members of the system;

this, of course, depends also on the nature of the sys-

tem and the information it contains, since in the pres-

ence of highly security-sensitive information, systems

may anyway opt for the exclusion of all suspected

agents. However, in general, systems, and even more

so open ones, will want to adopt a less restrictive pol-

icy, excluding only those agents whose malice has in-

deed been proved. Therefore, the defense against un-

derhand attacks by hidden coalitions is a fundamental

but complex matter.

Problems of a similar kind have been studied, for

instance, in Game Theory (Aumann and Hart, 1994;

Pauly and Parikh, 2003) in relation to the nature of

311

Cristani M., Karaﬁli E. and Viganò L..

BLOCKING UNDERHAND ATTACKS BY HIDDEN COALITIONS.

DOI: 10.5220/0003189203110320

In Proceedings of the 3rd International Conference on Agents and Artiﬁcial Intelligence (ICAART-2011), pages 311-320

ISBN: 978-989-8425-41-6

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

collaboration and competition, and from the view-

point of modeling group formation under the con-

straints of possible given goals. However, underhand

attacks by hidden coalitions pose security problems

that cannot be dealt with such traditional means. Nor

can they solved by a simple, monotonic, approach

based on Coalition Logic(s) such as (

Agotnes et al.,

2008; Oravec and Fogel, 2006; Pauly, 2001; van der

Hoek and Wooldridge, 2005).

To illustrate all this further, consider the following

concrete example from an online social network such

as Facebook, where abuse, misuse or compromise of

an account can be reported to the system administra-

tion. In particular, a group of agents (in this case,

Facebook users) can report a fake proﬁle:

You can report a proﬁle that violates Face-

book’s Statement of Rights and Responsibilities

by clicking the “Report/Block this Person” link

in the bottom left column of the proﬁle, select-

ing “Fake proﬁle” as the reason, and adding the

appropriate information. [...] (Excerpt from

http://www.facebook.com/help/?search=fake)

The administrator of the system gives an ultimatum to

the agent that uses the reported proﬁle and then may,

eventually, close it. An underhand coalition can ex-

ploit this report mechanism to attack an agent who

possesses a “lawful” original proﬁle: at ﬁrst they cre-

ate a fake proﬁle with personal information and pho-

tos of the agent under attack, and then they become

friends of her. After that, they report the original pro-

ﬁle so that the administrator closes it. The report is

a lawful action, and by creating the new proﬁle and

having a big enough number of agents who report the

same proﬁle no suspicion about the hidden coalition

is raised, so that the attack succeeds.

Contributions. A formalism to deﬁne and reason

about such hidden coalitions is thus needed. Indeed,

Coalition Logic allows one to deﬁne coalitions that

are explicit (i.e. not hidden) and is characterized by

monotonic permissions to act in groups and individu-

ally. What is missing, however,is the notion of hidden

coalition and a method to block the underhand attacks

such coalitions carry out. The idea underlying our

approach is to circumscribe the problem in algebraic

terms, by deﬁning a system that can be represented by

a coalition logic, and then activate a non-monotonic

control on the system itself to block the underhand

attacks that hidden coalitions are attempting to carry

out.

More speciﬁcally, we consider multi-agent sys-

tems whose security properties depend on the val-

ues of sets of logical formulas of propositional logic,

which we call the critical (or security) formulas of the

systems: for concreteness, we say that a system is se-

cure if all the critical formulas are false, and is thus

insecure if one or more critical formula is true. (Of

course, we could also invert the deﬁnition and con-

sider a system secure when all critical formulas are

true.) The system agents control the critical formu-

las in that they control the propositional variables that

formulas are built from: we assume that every vari-

able of the system is controlled by an agent, where

the variables controlled by an agent are controlled

just by that agent without interference by any other

agent. The actions performed by each agent consist

thus in changing some of the truth values of the vari-

ables assigned to that agent, which means that the

values of the critical formulas can change due to ac-

tions performed by the agents, including in particular

malicious insider agents who form hidden coalitions

to attack the system by making critical formulas be-

come true. Returning to the Facebook example, this

is exactly what happens when agents report the origi-

nal proﬁle as fake by setting the ﬂag (clicking on the

link).

At each instant of time, agents ask the system to

carry out the actions they wish to perform, i.e. chang-

ing the truth value of the variables they control, and

the system has to decide whether to allow such ac-

tions, but without knowing of the existence of possi-

ble hidden coalitions and thus at the risk of the sys-

tem becoming insecure. To block such attacks, we

formalize here a deterministic blocking method, im-

plemented by a greedy algorithm, which blocks the

actions of potentially dangerous agents. We prove

that this method is sound and complete, in that it does

not allow a system to go in an insecure state when

it starts from a secure state and it ensures that ev-

ery secure state can be reached from any secure state.

However, this algorithm is not optimal as it does not

block the smallest set of potentially dangerous agents.

We thus introduce also a non-deterministic blocking

method, which we obtain by extending the determin-

istic method with an oracle to determine the minimum

set of agents to block so to ensure the security of the

system. We show that the soundness and complete-

ness result extends to this non-deterministic method.

We also calculate the computational cost of our

two blocking methods. This computational analysis

is completed by determining upper bound results for

the problem of ﬁnding a set of agents to be blocked

so to prevent system transitions into insecure states,

In this paper, we do not consider how the administra-

tor decides to close the proﬁle, nor do we consider in de-

tail the non-monotonic aspects of how agents enter/exit/are

banned from a system or enter/exit a hidden coalition, or

how members of a hidden coalition synchronize/organize

their actions. All this will be subject of future work.

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

312

and the problem of ﬁnding an optimal set of agents

satisfying the above condition.

Organization. In §2, we introduce our approach to

the problem of blocking underhand attacks by hidden

coalitions. §3 and §4 respectively introduce our de-

terministic and non-deterministic blocking methods,

giving concrete examples for their application. In

§5, we study the computational aspects of these two

methods, calculating in particular their computational

cost, and show that they are both sound and complete.

Finally, in §6, we summarize our main results, discuss

related work and sketch future work. Proofs of the

formal results are given in (Cristani et al., 2010).

2 AN APPROACH TO THE

PROBLEM OF BLOCKING

UNDERHAND ATTACKS

We introduce our approach to the problem of blocking

underhand attacks. We also recall some basic notions

and, in particular, the relevant notions of the Coalition

Logic of Propositional Control CL-PC (Oravec and

Fogel, 2006; van der Hoek and Wooldridge, 2005).

2.1 Syntax

We consider multi-agent systems S that are described

by a set of critical (or security) formulas Φ and by a

temporal sequence σ : T → Θ(Φ), with T the tempo-

ral axis and Θ(Φ) the propositional assignment in the

set of formulas. In this work, we focus only on the

formulas in Φ, which represent the security-critical

characteristics of a system (which depend on the ap-

plication and which we thus do not describe further

here, as our approach is independent of the particular

application). We say that a system is secure if all the

critical formulas are false, and it becomes insecure if

one or more φ ∈ Φ becomes true. Hence, the state of

a system is deﬁned by the value of the propositional

variables that occur in the critical formulas of Φ.

The agents of a system S control the set Φ and

hence the state of S . We require that there is no

formula in our systems that cannot change its truth

value. Moreover, the distribution of the variables to

the agents should be such that one formula cannot

be controlled by one single agent, but rather differ-

ent agents control one formula, and every formula is

controlled by some agents. In particular, for a set Ag

of system agents:

• every variable of the system is controlled by an

agent a ∈ Ag, and

• the variables controlled by an agent are controlled

just by that agent without interference by any

other agent.

The actions performed by each agent a ∈ Ag are thus

the changing of the truth values of the variables as-

signed to a. The agents we consider are intelli-

gent agents in the sense of (Wooldridge and Jen-

nings, 1995; Wooldridge and Jennings, 1998): they

are autonomous, have social ability, reactivity and

pro-activeness, and have mental attitudes, i.e. states

that classify the relation of the agents and the cogni-

tive environment. In our approach, we consider in-

telligent agents but do not make speciﬁc assumptions

about their mental attitudes, except for their collabo-

rative attitudes that constitute a threat to (the security

of) the system.

In Game Theory (van der Hoek et al., 2005),

strategies are often associated with a preference re-

lation for each agent that indicates which output the

agent is going to select in presence of alternatives.

In our approach, agents change the value of “their”

variablesaccording to their strategies and create coali-

tions with other agents so to be more expressive: by

collaborating, agents can change the values of differ-

ent variables and thus, ultimately, of the critical for-

mulas that comprise such variables. The novelty in

this work is that we don’t deal just with coalitions that

are known by the system but also with hidden coali-

tions, whose existence and purposes are unknown by

the system.

Let us now formalize the language of our ap-

proach. Following CL-PC, given a set Ag of agents, a

set Vars of propositional variables, the usual operators

¬ and ∨ of classic propositional logic, and the coop-

eration mode ♦, we consider formulas built using the

following grammar:

φ ::= ⊤ | p | ¬φ | φ ∨ φ | ♦

where p ∈ Vars, C ⊆ Ag, and ♦

φ is a cooperation

formula. Slightly abusing notation, we denote with

Vars(φ) the set of propositional variables that occur in

φ and with Ag(φ) the agents that control the variables

in Vars(φ). ♦

φ expresses that the coalition C has the

contingent ability to achieve φ; this means that the

members of C control some variables of φ and have

choices for φ such that if they make these choices and

nothing else changes, then φ will be true.

An extension of the work presented here with a detailed

formalization of the mental and collaborative attitudes of

the agents will be subject of future work.

BLOCKING UNDERHAND ATTACKS BY HIDDEN COALITIONS

313

2.2 Semantics

A model is a tuple M = hAg, Vars, Vars|

, ..., Vars|

θi, where: Ag = {1, ..., n} is a ﬁnite, non-empty set

of agents; Vars = {p, q, ...} is a ﬁnite, non-empty set

of propositional variables; Vars|

, ..., Vars|

is a parti-

tion of Vars among the members of Ag, with the in-

tended interpretation that Vars|

is the subset of Vars

representing those variables under the control of agent

i ∈ Ag; θ : Vars → {⊤, ⊥} is a propositional valua-

tion function that determines the truth value of each

propositional variable.

Since Vars|

, ..., Vars|

is a partition of Vars, we

have: Vars = Vars|

∪ ... ∪ Vars|

i.e. every vari-

able is controlled by some agent; and Vars|

∩

Vars|

0 for i 6= j ∈ Ag, i.e. no variable is

controlled by more than one agent. We denote

with Vars|

the variables controlled by the agents

that are part of the coalition C ⊆ Ag. Given

a model M = hAg,Vars, Vars|

, ..., Vars|

, θi and a

coalition C, a C-valuation function is θ

: Vars|

→

{⊤, ⊥}. Valuations θ extend from variables to for-

mulas in the usual way and for a model M =

hAg,Vars, Vars|

, ..., Vars|

, θi we write M |= φ if

θ(φ) = ⊤. We write |= φ if M |= φ for all M .

2.3 Secure and Insecure Systems

All the semantic notions introduced above actually

depend on the current time, and we will thus decorate

them with a superscript ·

denoting the system state

at time t, e.g. θ

and |=

. Time is discrete and natu-

ral, and is deﬁned with a non empty set of time points

T and a transitive and irreﬂexive relation ≺ such that

t ≺ u means that t comes before u for t, u ∈ T. In

our case, since t, t + 1 ∈ T it follows naturally that

t ≺ t + 1.

The passing of time is regulated by a general

clock, which ensures that the system can execute a

deﬁnite number of actions in an instant of time: at ev-

ery clock of time, the system changes its state, which

is thus deﬁned by the actions that the system executes.

Even if there are no actions to execute, the system

changes its state from S

to S

t+1

, which in this case

are equal.

We assume that each system S starts, at time t

from a secure state S

, i.e. a state in which all the

critical formulas of Φ are false, so that none of the

features of the system is violated. In general:

S is secure at a state S

iff 6|=

φ for all φ ∈ Φ

and S is secure iff it is secure at all S

At time t, the system is in state S

and goes to state

t+1

and executes all the actions of the agents that

want to change the value of their variables. Denoting

with Γ

t+1

the set of actions that the agents want to

execute at the time instant t, we can write

t+1

7−→ S

t+1

and the aim of our approach is to guarantee that each

reachable state S

t+1

is secure, where the differences

between S

and S

t+1

are in their respective Θ.

Since a coalition can change the value of the vari-

ables it controls, it can attempt to change the value of

a critical formula to true; formally, for a coalition C

and a formula φ if ♦

φ is true then it means that C can

make φ true and thus the system insecure, which we

can write by negating the above deﬁnition or alterna-

tively, and basically equivalently, as:

S is insecure at a state S

iff |=

♦

φ for some

C ⊆ Ag and some φ ∈ Φ

To help the control of the system (but without loss

of generality), we can create a ﬁlter for the actions

that imposes a limit on the number of the actions that

can be executed in an instant of time. This can de-

crease the performance of the system, so we need a

trade-off between control and performance.

3 A DETERMINISTIC

BLOCKING METHOD

Our aim is to introduce a method that guarantees the

security of the system, which amounts to blocking

the actions of hidden coalitions. Indeed, in the case

of “normal” coalitions, the property ♦

φ allows us to

list the actions of the agents in C, while if the coali-

tion is hidden then we cannot block any action as we

cannot directly identify the participants of a coalition

we do not even know to exist. Since the actions of

participants of hidden coalitions are not predictable,

we cannot oppose these coalitions using ♦, so we in-

troduce a method that disregards the existence of this

property.

Our (main) method for the protection of the sys-

tem is a blocking method based on the greedy Algo-

rithm 1: the agents make a request to the system for

the actions Γ

t+1

they wish to execute at time t, and the

system then simulates (via a method Simulate we as-

sume to exist) the actions in order to control whether

the system after the execution of the actions is still

secure or not. The simulation says if the system can

proceed with the execution of the actions or not, in

which case it is given a list of the formulas Φ

′

that

became true along with the set of agents A

′

that made

them become true.

If the simulation says that the system can go in an

insecure state, the blocking method constructs a

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

314

Algorithm 1: A GREEDY, DETERMINISTIC BLOCKING

METHOD.

1: Simulate(Γ

t+1

) = [Φ

′

];

2: while (Φ

′

0) do

3: Create the matrix with Φ

′

and A

′

;

4: ∀a

∈ A

′

: a

→ c

, c

= count(φ

);

5: Quicksort(c

, ..c

) = (c

, ...);

6: B = B ∪ a

; {where a

is the agent associ-

ated to c

, that is the maximum counter of the

marked cells}

7: Simulate(Γ

t+1

\Γ|

) = [Φ

′

];

8: end while

matrix: in every column of the matrix there is one of

the agents given by the simulation and in every row

there is one of the formulas that became true dur-

ing the simulation. We mark each cell that has as

coordinates the agent that has variables in that for-

mula, and then we eliminate the column that has more

marked cells.

The corresponding agent is not elim-

inated, rather he is just blocked and his actions are

not executed (by subtracting Γ|

): the “dangerous”

agents found in this way are put in a set B of blocked

agents. The simulation is called again and so on, until

the output of the simulation is an empty set of for-

mulas, which means that by executing the remaining

actions the system does not go in an insecure state. It

is important to note that this method does not prevent

the creation of hidden coalitions but can guarantee the

system security from the attacks made by these coali-

tions.

The most important property of Algorithm 1 is

that it never brings the system in an insecure state,

as it blocks the actions of agents that can make the

system insecure. We do not commit to a speciﬁc way

that the blocking is actually done, as it depends on

the particular observed systems and on the particular

goals. For instance:

• Block the agent from changing the value of his

variables until a precise instant of time. During

this period, his variables are left unchanged or are

controlled by the superuser/system administrator.

• Block the agent for an interval of time, which can

be a default value or can be chosen in a random

way, e.g. so that a hidden coalition doesn’t know

It would be more efﬁcient to consider only the vari-

ables of the formulas that become true, but if we take only

these variables, we cannot prevent long-term strategies of

hidden coalitions, consisting in the progressive reduction of

the number of steps needed for making a security formula

true. An optimization of the choice of variables to be con-

sidered in order to reduce the effectiveness of such long-

term strategies will be subject of future work.

when the agent can be active and thus cannot or-

ganize another attack.

• Block the agent and remove his actions for that in-

stant of time. At the next instant, the agent has the

possibility to ask for his actions to be executed.

• Leave the variables unchanged, without making

known to the agent if the value of the variables

has been changed or not. This method can be

improved by blocking the agent if he attempts to

change the truth value of those variables again.

Other, more complex, blocking strategies can of

course be given, e.g. by combining some the above.

Note also that, depending on the system consid-

ered, it could be that not all the requests for execution

can be satisﬁed: the maximum number n of actions

that can be executed in an instant of time can be cho-

sen in different ways, with respect to the characteris-

tics of the system. Here, we choose n to be the car-

dinality |Φ| of the critical formulas. The order used

for taking these actions and executing them respects a

FIFO queue, so the ﬁrst n actions are executed.

Example 1. As a concrete example of the application

of the blocking method, consider a system S deﬁned

by the critical formulas

= v

∧ v

∧ (¬v

∨ v

∨ ¬v

)

= (¬v

∨ ¬v

) ∧ ¬v

= v

∧ (¬v

∨ ¬v

)

= (v

∨ v

∨ ¬v

) ∧ v

∧ v

so that number of the action to be executed in an

instant of time is n = 4 (the cardinality of the set

of critical formulas that deﬁne the system), and let

Ag = {a

, a

} and At = {v

, ..., v

}. Fur-

ther, consider the following distribution of the vari-

ables to the agents:

= {v

, v

} a

= {v

} a

= {v

, v

}

= {v

, v

} a

= {v

}

Let us assume that the state S

at time t is

) = θ

) = ⊥

) = θ

)

= θ

) = θ

) = ⊤

and that we have the following actions Γ

t+1

to be ex-

ecuted at time t in the FIFO queue:

t+1

) ←[ ⊤, θ

t+1

) ←[ ⊥,

t+1

) ←[ ⊥, θ

t+1

) ←[ ⊥, ·· ·

That is, v

should be set to ⊤ at state S

t+1

, and so

on. The algorithm simulates the ﬁrst n = 4 actions, so

that Φ

′

= {φ

, φ

} and A

′

= {a

, a

and the matrix of Table 1 is constructed, which the

BLOCKING UNDERHAND ATTACKS BY HIDDEN COALITIONS

315

Table 1: Matrix constructed by the blocking algorithm for

Example 1.

X X X X

X X X

X X

X X X

Table 2: Matrix of Table 1 sorted in a decreasing order of

counters.

X X X X

X X X

X X

X X X

algorithm sorts by the highest counter to produce the

matrix in Table 2. a

is thus put into B. The simu-

lation takes place again, taking into account that we

have blocked the value of the variables controlled by

at the truth value of the instant of time t. The

simulation gives as result the set Φ

′

= {φ

, φ

} e

′

= {φ

, φ

}. The matrix of Table 3 is created,

which is already ordered (so the sorting will return the

same matrix). So, we put in B the agent a

, block its

actions and make the simulation with the remaining

actions. This simulation gives Φ

′

0, and thus the

remaining actions can be executed without any risk

for the system S .

4 A NON-DETERMINISTIC

BLOCKING METHOD

As we will see in §5, the above deterministic block-

ing method based on a greedy algorithm is sound and

complete. However, this algorithm is not optimal as it

cannot block the smallest set of potentially danger-

ous agents. We now introduce a non-deterministic

method, which can be used for identifying optimal

solutions. The method, which is implemented in Al-

gorithms 2 and 3, is obtained by introducing an oracle

(to determine the minimum set of agents to block so

to ensure the security of the system) within the de-

terministic version, which makes the soundness and

completeness results directly applicable to the non-

deterministic version as well.

The idea is that the result given by the simulation

is passed to the method ScanOracle, which creates all

the subsets of the given set A

′

with cardinality |A

′

−1|

and ﬁnds the subsets with the maximum number of

critical formulas that remain false, using the simula-

tion. The simulation of all the subsets is done in par-

Table 3: Matrix of Table 2 after the block of agent a

X X

Algorithm 2: A NON-DETERMINISTIC BLOCKING

METHOD.

1: Simulate(Γ

) = [Φ

′

];

2: I = A

′

; j = 0;

3: while (Φ

′

0 & I 6=

0 & j < |A

′

|) do

4: I

′

= ScanOracle(I);

5: For a random I

∈ I

′

6: if |{φ

|6|= φ

at the current state }| = |Φ

′

| then

7: I =

8: else

9: I = I

′

;

10: end if

11: j + +

12: end while

13: Choose a subset I

∈ I

′

and put A

′

in B

Algorithm 3: SCANORACLE.

1: Generate the subset of I with cardinality |I| − 1

2: Execute the simulation in parallel for each subset

, where i ∈ {1, ..., |I|}

3: Take the I

with the maximum number of {φ

|6|=

} and put them in I

′

4: I

′

= I

′

∪ I

5: Eliminate the duplicates in I

′

6: Return I

′

allel; the ScanOracle is the non-deterministic part of

our algorithm. The result is passed to the main algo-

rithm: if we ﬁnd a subset of agents such that when

executing their actions all critical formulas are false,

then we have ﬁnished and we block the remaining

agents that are not part of this subset; if not all the

critical formulas remain false the result is passed re-

cursivelyto ScanOracle until it is given a set of agents

such that all the critical formulas stay false when sim-

ulating their actions. The rest of the agents in A

′

that

are not part of the given subset are blocked. Using

this method, we can have different best solutions but

we choose one in a random way, where with “best so-

lutions” we mean sets that have the same cardinality

and are the biggest sets that make the critical formulas

stay false, so that we block the smallest set of agents

that make the critical formulas true.

Example 2. As a concrete example of the applica-

tion of Algorithm 2 (and of Algorithm 3), consider

again the system of Example 1, with the same data.

The simulation of the ﬁrst 4 actions yields again

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

316

′

= {a

, a

}, which is passed to ScanOracle,

which in turn creates the subsets:

= {a

, a

} I

= {a

, a

}

= {a

, a

} I

= {a

, a

}

The oracle takes these subsets and gives as results at

the current state

: |= φ

, |= φ

: |= φ

, |= φ

: |= φ

, 6|= φ

, |= φ

: 6|= φ

, |= φ

, 6|= φ

The two subsets with maximum number of false criti-

cal formulas are I

and I

, so I

′

= I

∪ I

. Note that,

since I

and I

have the same number of false formu-

las, it is enough to test just one of them to see if all the

formulas are false or not; in this case, we have just

two formulas. The ScanOracle is then called again

with I

′

= I

∪ I

and it yields the subsets

= {a

, a

} I

= {a

, a

} I

= {a

, a

}

= {a

, a

} I

= {a

, a

} I

= {a

, a

}

and thus the following results

: |= φ

, 6|= φ

, |= φ

: 6|= φ

, 6|= φ

, |= φ

: 6|= φ

, 6|= φ

: 6|= φ

, |= φ

, 6|= φ

: 6|= φ

, 6|= φ

: 6|= φ

, |= φ

, 6|= φ

Then I

′

= I

∪ I

= I

as these two subsets are iden-

tical. Using I

′

, all the critical formulas are false,

so it is the maximum subset of agents with which

the system is secure. Hence, we block the remain-

ing agents in A

′

, which is the minimum set of agents

for the blocking of which the system remains secure:

, a

}\{a

, a

} = {a

, a

5 COMPUTATIONAL COST,

SOUNDNESS AND

COMPLETENESS

In this section, we list some results for the determinis-

tic and non-deterministic methods, which are proved

in (Cristani et al., 2010). Recall that the maximum

number n of actions that can be executed in an instant

of time corresponds to the cardinality of the formulas

in Φ. So, in the worst case, at each instant of time,

there are n different agents that want to change the

value of n different variables.

Theorem 1. The computational cost of the greedy

blocking method, Algorithm 1, and of the non-

deterministic blocking method, Algorithm 2, is O(n

We say that a blocking method, and thus the cor-

responding algorithm, is sound if it does not allow a

system to go in an insecure state when it starts from a

secure state S

. It is not difﬁcult to prove that:

Theorem 2. The greedy blocking method, Algo-

rithm 1, is sound.

Let us now deﬁne the notion of a state graph. Re-

call that every state of the system is deﬁned by an as-

signment of truth values to the variables, and a state is

secure if it falsiﬁes all security-related formulas. As

a very simple example, in Figure 1 we give the state

graph of a system with two variables {A, B}.

, , ¬

¬ , ¬ , ¬

Figure 1: A state graph for a system with two variables.

In general, to denote the transitions executed by a

system, we build a state graph as follows: every state

is represented as a vertex of the graph, and every pair

of vertices is connected by an edge when and only

when the two edges differ by the truth value of one

single variable, where the edge is labeled by the name

of the agent that controls that variable. The resulting

graph is indirected. In Figure 2, we give an example

of such a graph, where we omit to specify all the val-

ues of the variables for readability, but instead denote

with gray vertices the insecure states and with white

vertices the secure ones.

· · ·

· · ·· · ·

· · ·

Figure 2: A state graph with secure and insecure states.

We say that a blocking method, and thus the corre-

sponding algorithm, is complete if every secure state

BLOCKING UNDERHAND ATTACKS BY HIDDEN COALITIONS

317

can be reached from any secure state. To prove the

completeness of the greedy blocking method, we pur-

sue the following strategy:

1. First we prove that the state graph of the system is

connected.

2. We prove that the subgraph formed by the vertices

representing secure states is connected when the

security formulas can be written as a set of Horn

clauses.

3. We prove that every formula that we consider can

be written as a disjunction of Horn clauses.

4. We show that two secure states, whose security

formulas can be written as Horn clauses, are con-

nected if and only there is a path of secure states

in the above mentioned subgraph that can be tra-

versed by the algorithm.

5. We show that the set of agents that have to be

blocked, deﬁned by a rewriting into Horn clauses

of a security formula, is the union of agents that

control variables occurring in one single Horn

clause, and that can modify the value of the for-

mula.

6. We show that the set of agents blocked by the

greedy algorithm is a superset of the set of agents

that control variables occurring in one single Horn

clause in any rewriting of the formula.

In particular, we write H (Φ, Φ

′

) to denote the set

of the agents that control at least one variable of one

Horn clause in one rewritingΦ

′

of the security formula

Φ, in such a way that by changing the value of one of

these variables the value of the security formula can

pass from ⊥ to ⊤.

Let us observe a few simple facts that will be use-

ful in the following. First of all, every secure state

corresponds to a formula, obtained as the conjunction

of the literals representing the truth values of the vari-

ables in that state. Since the single elements of the set

of security formulas have to be false for the system to

be secure, we can describe this situation directly by

the set of secure states. Indeed, guaranteeing false-

ness of each security formula corresponds to falsify-

ing the disjunction of the logical expressions repre-

senting the secure states. By the deﬁnition of state

graph, we immediately have:

Lemma 1. The state graph is connected.

It would be tempting to presume that not only the

set of states is connected, but also the set of secure

states. However, this is untrue. Consider namely the

case in which the system has two variables, A and B,

so that there are four states as shown in Figure 1. Sup-

pose that the security formula is (¬A∧ B) ∨ (A∧¬B).

The set of secure states is formed by the state in which

both A and B are false and the state in which they are

both true. Clearly the set of secure states is then dis-

connected.

Conversely, if the set of secure states is connected,

the security formula can be written as a Horn clause

(or a set of clauses, which is equivalent). To do so,

we introduce the notion of Horn rewriting of a for-

mula: a propositional formula is a Horn clause iff it

can be written in Conjunctive Normal Form (i.e. as a

conjunction of disjunctions of literals) in which ev-

ery conjunct is formed by at most one positive literal

(This is the standard notion of Horn clause, which we

recall for preserving self-containedness.) It is well-

know that every propositional formula can be written

as a disjunction of Horn clauses.

A Horn labeling λ of the states of a system is an

assignment of the system variables to one of the cor-

responding literals. Whenever, in a Horn labeling,

λ(v) = v for a variable v, the literal v will be consid-

ered positive by that labeling, and consequently literal

¬v will be considered negative. If λ(v) = ¬v, then the

literal v will be considered negative, and consequently

literal ¬v will be considered positive. We henceforth

generalize the notion of Horn clause, by stating that

a formula is a Horn clause when there exists a Horn

labeling for it that makes it a Horn clause.

In the above example, the formula can be rewrit-

ten, by applying the distributive property, as (A∨B)∧

(¬A∧¬B) and there exists a Horn labeling that makes

the formula a Horn clause: λ(A) = ¬A and λ(B) = B.

Lemma 2. If the set of states that correspond to a se-

curity formula is connected, then the security formula

is a Horn clause.

Let us now consider a generic set of states that is

not connected. As we show in Figure 1, this may any-

how correspond to a valid Horn labeling. This, how-

ever, does not occur for every security formula. Con-

versely, every set of states can be written as the inter-

section of connected sets of states. Therefore, given

any security formula, we can represent it as the dis-

junction of the Horn clauses that are obtained by the

sets of connected states.

The purpose of Algorithm 1 is to block the agents

that apply for changing variables so to make true a

critical formula. Since a critical formula can be made

true by making true one of its disjuncts, Lemma 2 can

be used directly to prove the following Lemma 3.

More speciﬁcally, the greedy blocking works by

blocking agents when they apply for the modiﬁca-

tion of the truth value of a variable, where the block-

ing condition is: an agent cannot perform an action

when this performance brings the system in an inse-

cure state. The synchronization proposed by the algo-

rithm is based on application time: the system simu-

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

318

lates the result of performing all (up to the maximum)

actions that agents applied for at that instant of time.

The system denies the execution to those agents that

modify variables involved in the transition of the sys-

tem into an insecure state. Since this may correspond

to more than one combination, the resulting blocked

agent set may be larger than needed. We can assume,

therefore, without loss of generality, that the algo-

rithm blocks all the agents that applied for modifying

variables that bring the system into an insecure state.

This assumption is sufﬁcient to employ fruitfully the

generalization of Lemma 2 to generic formulas. Re-

member that H (Φ, Φ

′

) denotes the set of the agents

that control variables of one Horn clause in the rewrit-

ing Φ

′

of Φ and bring the system into an insecure state.

Lemma 3. If no agent in H (Φ,Φ

′

) modiﬁes variables

occurring in Φ, and Φ is false, then Φ is false after the

modiﬁcations.

Since the agents blocked by the algorithm are all

those that bring the system into an insecure state, then

every agent controls variables that certainly occur in

at least one disjunct of Φ. If we rewrite Φ as a disjunc-

tion of Horn clauses (following the standard notion of

formula rewriting into disjunction of Horn clauses)

′

= Φ

′

∨ Φ

′

∨ ... ∨ Φ

′

, then, by deﬁnition of this

rewriting, every variable controlled by a that occurs

in Φ, occurs in at least one of these disjuncts. If an

agent that controls one variable is blocked by our al-

gorithm, then, by deﬁnition of the simulation, at least

one of the conjuncts in which the variable occurs in

′

is true. This means that given any pair of secure

states s and s

′

, the algorithm never blocks an agent

that brings the system directly from s to s

′

. The ex-

tension of this property to paths is proved in the fol-

lowing theorem.

Theorem 3. The greedy blocking method, Algo-

rithm 1, is complete.

Soundness and completeness of the deterministic al-

gorithm directly extend to the non-deterministic one.

Theorem 4. The non-deterministic blocking method,

Algorithm 2, is sound and complete.

Let us call optimal a method that blocks the small-

est sets of agents to ensure the security of the system.

The greedy blocking method guarantees just one of

the optimality properties, i.e. security, but it cannot

guarantee to block the smallest sets of agents. We

thus say that the greedy blocking method is a sub-

optimal solution. What can further be proved is that

the comparison of the solutions computed in the non-

deterministic method generates an optimal solution.

This is quite obvious, since the solutions computed

are all the possible combinations, and thus the best

solution is included in this set. What the algorithm

does is ﬁnd the smallest set of agents that need to be

blocked.

Theorem 5. Algorithm 2 computes an optimal solu-

tion.

We consider here the speciﬁc problem of blocking

underhand attacks as the problem of keeping the se-

curity formula false when agents apply for changing

variables. The computational complexity of a prob-

lem is deﬁned as the cost of the best solution. In this

case, we cannot claim that the solution is optimal and

therefore we only have an upper bound result.

Theorem 6. Blockage of underhand attacks is a poly-

nomially solvable problem on deterministic machines.

Analogously, the next result is a consequence of

the results about soundness, completeness and cost of

Algorithm 2, again in form of an upper bound.

Theorem 7. Optimal blockage of underhand at-

tacks is a polynomially solvable problem on non-

deterministic machines.

6 CONCLUSIONS

We have given a ﬁrst approach to hidden coalitions

by introducing a deterministic method that blocks the

actions of potentially dangerous agents, i.e. possibly

belonging to such coalitions. We have also given a

non-deterministic version of this method that blocks

the smallest set of potentially dangerous agents. Our

two blocking methods are sound and complete, and

we have calculated their computational cost.

The starting point of our approach to model multi-

agent systems is Coalition Logic (Pauly, 2001; Pauly

and Parikh, 2003), a cooperation Logic that imple-

ments ideas of Game Theory. Another cooperation

logic that works with coalitions is the Alternating-

time Temporal Logic, e.g. (Alur et al., 1998). A

widely used logic, speciﬁcally thought for dealing

with strategies and multi-agent systems, is the Quanti-

ﬁed Coalition Logic (

Agotnes et al., 2008). A speciﬁc

extension, also used for agents in multi-agent systems

is CL-PC (van der Hoek and Wooldridge, 2005; Tro-

quard et al., 2009), and this is indeed the version of

Coalition Logic that we started from.

The notion of hidden coalition is a novelty, and

more generally, to the best of our knowledge, no spe-

ciﬁc investigation exists that deals with security in

open systems by means of a notion of underhand at-

tack. The system presented here is a multi-agent one,

There may exist more than one solution with the small-

est number of agents blocked. The approach of Algorithm

2 is to compare everything with everything, so the chosen

solution is the last examined one.

BLOCKING UNDERHAND ATTACKS BY HIDDEN COALITIONS

319

where we did not discuss how these coalitions are

formed or the negotiations that can take place before

the creation of the coalitions (Sandholm, 2004; Kraus,

1997). For future work, it will be interesting to con-

sider in more detail the non-monotonic aspects un-

derlying the problem of underhand attacks by hidden

coalitions, e.g. to formalize: the mental attitudes and

properties of the intelligent agents that compose the

system, how agents enter/exit/are banned from a sys-

tem or enter/exit a hidden coalition, and the negotia-

tions between the agents for establishing the common

goal and synchronizing/organizing their actions. In

this work, we give a way to protect the system, with-

out making a distinction between the case in which

the agents that make the attack are actual members

of a coalition or not. If the system is equipped with

explicit/implicit coalition test methods, this can make

up a signiﬁcant difference in terms of usefulness of

our approach.

A speciﬁc analysis of the computationalproperties

of our blocking methods, in particular an analysis of

worst, average, and practical cases, will be subject of

future work. Results of lower bound for the blocking

problem and the optimal blocking problem, and the

computational cost of the optimal blocking problem

on deterministic machines are in particular important

aspects to be investigated.

ACKNOWLEDGEMENTS

The work presented in this paper was partially sup-

ported by the FP7-ICT-2007-1 Project no. 216471,

“AVANTSSAR: Automated Validation of Trust and

Security of Service-oriented Architectures”.

REFERENCES

Agotnes, T., van der Hoek, W., and Wooldridge, M. (2008).

Quantiﬁed coalition logic. Synthese, 165(2).

Alur, R., Henzinger, T. A., and Kupferman, O. (1998).

Alternating-time temporal logic. In Compositionality:

The Signiﬁcant Difference, pages 23–60. Springer.

Aumann, R. J. and Hart, S., editors (1994). Handbook of

Game Theory, volume 2. Elsevier.

Chaum, D. (1981). Untraceable electronic mail, return ad-

dresses and digital pseudonyms. Communications of

the ACM, 24(2).

Cristani, M., Karaﬁli, E., and Vigan`o, L. (2010). Blocking

Underhand Attacks by Hidden Coalitions (Extended

Version). http://arxiv.org/abs/1010.4786.

Davidsson, P. (2001). Multiagent based simulation: beyond

social simulation. In Multi-Agent-Based Simulation,

1979:97–107.

Hahn, C., Fley, B., Florian, M., Spresny, D., and Fischer,

K. (2007). Social reputation: a mechanism for ﬂexi-

ble self-regulation of multiagent systems. Journal of

Artiﬁcial Societies and Social Simulation, 10.

Kraus, S. (1997). Negotiation and cooperation in multi-

agent environments. Artiﬁcial Intelligence, 94:79–97.

Oravec, V. and Fogel, J. (2006). Coalition logic of propo-

sitional control based multi agent system modeling.

Proceedings of IEEE Conference on Mechatronics,

pages 288–291.

Pauly, M. (2001). Logic for social software. PhD thesis,

Institute for Logic Language and Computation, Uni-

versity of Amsterdam.

Pauly, M. and Parikh, R. (2003). Game logic - an overview.

Studia Logica, 75(2):165–182.

Rafaeli, S. and Hutchison, D. (2003). A survey of key man-

agement for secure group communication. ACM Com-

puting Surveys (CSUR), 35(3):309–329.

Sandholm, T. (2004). Agents in electronic commerce:

Component technologies for automated negotiation

and coalition formation. Autonomous Agents and

Multi-Agent Systems, pages 73–96.

Sorniotti, A. and Molva, R. (2010). Secret Interest Groups

(SIGs) in social networks with an implementation on

Facebook. In Proceedings of SAC 2010. ACM Press.

Troquard, N., van der Hoek, W., and Wooldridge, M.

(2009). A logic of games and propositional control.

In Proceedings of AAMAS’09, pages 961–968. ACM

Press.

van der Hoek, W., Jamroga, W., and Wooldridge, M. (2005).

A logic for strategic reasoning. In Proceedings of AA-

MAS’05, pages 701–708. ACM Press.

van der Hoek, W. and Wooldridge, M. (2005). On the logic

of cooperation and propositional control. Artiﬁcial In-

telligence, 164(1-2):81–119.

Wiehler, G. (2004). Mobility, Security and Web Services.

Publicis Corporate Publishing.

Wooldridge, M. and Jennings, N. (1995). Intelligent agents:

Theory and practice. Knowledge Engineering Review,

10(2).

Wooldridge, M. and Jennings, N. (1998). Pitfalls of agent-

oriented development. In Proceedings of Agents’98,

pages 385–391. ACM Press.

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

320
