CONTINGENT PLANNING AS BELIEF SPACE SEARCH

Incheol Kim and Hyunsik Kim

Department of Computer Science, Kyonggi University, San 94-6, Yiui-Dong, Youngtong-Gu, 443-760, Kyonggi, Korea

Keywords: Contingent planning, Partial initial condition, Nondeterministic actions, Belief states, Heuristic search.

Abstract: In this paper, we present a new heuristic search algorithm for solving contingent planning problems with the

partial initial condition and nondeterministic actions. The algorithm efficiently searches through a cyclic

AND-OR graph with dynamic updates of heuristic values, and generates a contingent plan that is guaranteed

to achieve the goal despite of the uncertainty in the initial state and the uncertain effects of actions. Through

several experiments, we demonstrate the efficiency of this algorithm.

1 INTRODUCTION

Classical AI planning has the assumption that the

entire initial state is known at planning time, and

each action should deterministically produce an

exact one outcome. A more realistic assumption is

that the planner only knows part of this information

at planning time, the rest must be acquired at plan-

execution time through observations, and each

action may nondeterministically produce any of

several outcomes. Several planning algorithms have

been formulated to address these partially

observable, nondeterministic planning problems

(Ghallab, et al., 2004). Contingent planning

algorithms construct a plan that includes both

sensing actions and conditional execution of the

actions in the plan. In general, contingent planning

can be considered as search in a belief space to find

a solution plan of which all possible different

execution paths beginning from the initial belief

state should end at one of goal belief states. In this

paper, we present a new heuristic search algorithm

for solving contingent planning problems with the

partial initial condition and nondeterministic actions.

The algorithm efficiently searches through a

possibly cyclic AND-OR graph with dynamic

updates of heuristic values, and generates a

contingent plan that is guaranteed to achieve the

goal despite of the uncertainty in the initial state and

the uncertain effects of actions. Through several

experiments, we demonstrate the efficiency of this

algorithm.

(:action sense_door_open

:parameters (?R – robot ?L1 ?L2 - location)

:precondition (and (robot_in ?R ?L1)

(unknown_door_open_between ?L1 ?L2))

:effect (or

(and (not (unknown_door_open_between ?L1 ?L2))

(door_open_between ?L1 ?L2))

(and (not (unknown_door_open_between ?L1 ?L2))

(door_closed_between ?L1 ?L2))))

(:action carry

:parameters (?R - robot ?L1 ?L2 - location ?O - object)

:precondition (and (robot_in ?R ?L1)

(door_open_between ?L1 ?L2)

(object_in ?O ?L1) )

:effect (or (and (not (robot_in ?R ?L1)) (robot_in ?R ?L2))

(grap_object ?R ?O) (not

(object_in ?O ?L1)))

(and (robot_in ?R ?L1))))

(:action move

:parameters (?R - robot ?L1 ?L2 - location)

:precondition (and (robot_in ?R ?L1)

(door_open_between ?L1 ?L2))

:effect (and (not (robot_in ?R ?L1)) (robot_in ?R ?L2)))

(:action put_down

:parameters (?R - robot ?L1 - location ?O - Object)

:precondition (and (robot_in ?R ?L1) (grap_object ?R ?O))

:effect (and (not (grap_object ?R ?O)) (object_in ?O ?L1)))

Figure 1: Domain actions.

2 CONTINGENT PROBLEMS

Planning with incomplete information can be

formulated as a problem of search in belief space,

where belief states can be sets of states.

In this paper, we use the corresponding meta-

predicate formula, (unknown_predicate term

, ..,

term

) to represent that we do not know whether the

694

Kim I. and Kim H..

CONTINGENT PLANNING AS BELIEF SPACE SEARCH.

DOI: 10.5220/0003288906940697

In Proceedings of the 3rd International Conference on Agents and Artiﬁcial Intelligence (ICAART-2011), pages 694-697

ISBN: 978-989-8425-40-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

fact (predicate term

, …, term

) is true or not. A

belief state b is represented as a set of literals,

including some unknown meta-predicate literals. A

deterministic action a

is described by a precondition

and an effect. However, a nondeterministic action

may have more than one effect. A sensing action

s-l

has at least one unknown literal l

unknown

in the

precondition and two different effects including l

true

and l

false

respectively. Figure 1 shows some action

descriptions of the Robot Navigation domain.

The contingent planning problem with both

partial initial condition and nondeterministic actions

is P

pond

= (D, b

, b

) and the domain is D = (L, B, A),

where L is the set of all known and unknown literals,

B is the set of all belief states, and A=A

∪A

the set of actions, that includes deterministic,

nondeterministic, and sensing actions. b

, b

are the

respective initial and goal belief states. Figure 2

shows an example of contingent planning problem

with partial initial condition.

(:init

(robot_in robot l_corridor)

(object_in cup office1)

(unknown_door_open_between conf1 r_corridor)

(unknown_door_open_between lounge r_corridor)

(door_open_between l_corridor office1)

(door_open_between office1 conf1)

. . .

(door_open_between reception r_corridor))

(:goal

(and (robot_in robot reception) (object_in cup reception) ))

Figure 2: A planning problem.

A solution of the given contingent planning

problem P

pond

can be represented as a policy π, the

set of (belief state, actions) pairs, as shown in Table

Table 1: A solution policy.

Belief State Action

(robot_in robot l_corridor) (object_in

cup office1)

(unknown_door_open_between lounge

r_corridor) ...

(move robot l_corridor

office1)

(robot_in robot office1) (object_in cup

office1) (unknown_door_open_between

lounge r_corridor) ...

(carry robot office1

l_corridor cup)

. . . . . .

(robot_in robot lounge) (grap_object

robot cup)

(unknown_door_open_between lounge

r_corridor) ...

(sense_door_open

lounge r_corridor)

. . . . . .

3 HEURISTIC SEARCH

AND-OR-Search-Trial(b

)

Begin

stateStack.CLEAR();

policyTable.CLEAR();

localHistory.CLEAR();

stateStack.PUSH(b

);

While ￢stateStack.EMPTY() do

/* if there remain any unexplored branches */

b = stateStack.POP();

If b.GOAL() then

/* b is a goal state on the end of one branch */

solved = true;

b.VALUE = 0;

valueTable.UPDATE(b, b.VALUE);

localHistory.CLEAR();

continue;

If localHistory.CONTAINS(b) then

/* b is a cycle state, not be included in a solution */

solved = false;

break;

else

localHistory.PUT(b);

If policyTable.CONTAINS(b) then

/* b is already in a partial solution */

localHistory.CLEAR();

continue;

a = b.GREEDY_ACTION();

If a = NULL then

/* b is a dead-end state */

solved = false;

b.VALUE = MAX_VALUE

valueTable.UPDATE(b, b.VALUE);

break;

policyTable.PUT(b, a);

If a is one of sensing actions then

b' = b.P_NEXTSTATE(a); /*a positive state*/

b" = b.N_NEXTSTATE(a); /*a negative state*/

localHistory.CLEAR();

stateStack.PUSH(b');

stateStack.PUSH(b");

b.VALUE = cost(b,a) + 0.5*valueTable.GET(b')

+ 0.5*valueTable.GET(b")

valueTable.UPDATE(b, b.VALUE);

else if a is one of non-deterministic actions then

next_states = b.ND_NEXTSTATE(a);

localHistory.CLEAR();

For each b’ in next_states do

stateStack.PUSH(b’);

b.VALUE = cost(b,a) +

∑

b'∈next_states

valueTable.GET(b') / |next_states|

valueTable.UPDATE(b, b.VALUE);

else if a is one of deterministic actions then

b' = b.NEXTSTATE(a);

stateStack.PUSH(b');

b.VALUE = cost(b,a) + valueTable.GET(b')

valueTable.UPDATE(b, b.VALUE);

End

Figure 3: AND-OR-Search-Trial.

CONTINGENT PLANNING AS BELIEF SPACE SEARCH

695

We propose a heuristic search algorithm for solving

contingent planning problems, called HSCP

(Heuristic Search for Contingent Planning). It

repeats multiple AND-OR-search trials beginning

from the initial belief state until it obtains a complete

solution (i.e., until solved becomes true), as shown

in Figure 4.

HSCP(bs

: initial belief state)

Begin

valueTable.CLEAR();

solved = false;

While solved = false do

AND-OR-Search-Trial(bs

);

return (policyTable.GET_POLICY());

End

Figure 4: The HSCP algorithm.

Figure 3 summarizes the AND-OR search trial of

the HSCP algorithm. During AND-OR search trial,

just one candidate of solution subgraphs keeps to be

expanded until its every tip node successfully arrives

at one of goal belief states. Therefore, the AND-OR

search trial is like the heuristic depth-first search that

traverses along every AND branch of the solution

subgraph. The initial value of a belief state b is

assumed to be its heuristic value, h(b). Whenever a

node is selected to be expanded, the value of the

belief state in the node is updated with the values of

its successors. However, HSCP does not

backpropagate value updates over the entire

subgraph. So the AND-OR search trial proceeds fast.

When it meets a dead end state that has no

successors, it sets the value of the state to the infinite

number ∞. If the candidate subgraph is no longer

expanded to be a complete solution, the search trial

fails. And then a new search trial begins again with

the updated value table. With the help of updated

values of the states, the new search trial is able to

expand another part of the AND-OR graph. As the

number of search trials increases, the possibility to

obtain a complete solution also increases. In this

way, HSCP can find a suboptimal solution of the

given contingent planning problem very efficiently.

Figure 5: Open and closed cycles.

Our HSCP algorithm can distinguish open cycles

from closed ones. The former has the possibility to

arrive one of goal belief states, but the latter does not.

(A) and (B) in Figure 5 show an open cycle and a

closed cycle, respectively.

Figure 6: Search space expanded by HSCP.

Figure 6 shows the part of search space expanded by

HSCP for solving the example problem of Figure 2.

4 RELATED WORK

There are several different algorithms for contingent

planning problems: LAO

, RTDP, CondFCP, and

ND-FCP. LAO

(Hansen and Zliberstein, 2001) is an

extended version of AO

, the heuristic AND-OR

search algorithm, so that it can find a solution

subgraph containing open cycles. This algorithm

obtains an optimal solution with just one search trial.

However, during the search trial, it evaluates and

expands multiple candidates of solution subgraphs

simultaneously, and backpropagates value updates

over the entire solution subgraph whenever it gets a

new heuristic value of a tip node. Moreover,

whenever it meets an open cycle, it continues tracing

and value updating along the cycle until every state

nodes in the cycle gets a converged value.

RTDP (Bonet and Geffner, 2003) is a well-

known dynamic programming algorithm for solving

nondeterministic contingent planning problems. It

has two key advantages comparing with other DP

algorithms: first, it obtains an optimal policy without

computing the whole space, second, it has a good

anytime behavior. However, RTDP usually requires a

lot of search trials and value updates, so its

convergence is slow

. CondFCP(Kuter, et al, 2007) is

an extended version of the classical forward-

chaining algorithm for solving planning problems

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

696

with partial initial condition. On the other hand, ND-

FCP(Kuter and Nau, 2004) is an extended one for

solving nondeterministic planning problems. Both

algorithms do just one search trial and expand only

one candidate of solution subgraph during the search

trial. They do not try to update heuristic values with

new information. Therefore, they do not guarantee to

find a solution and cannot be used for solving

contingent planning problems with both partial

observations and nondeterministic actions.

5 EXPERIMENTS

Figure 7: The number of search trials.

Figure 8: The number of value updates.

Figure 9: The number of generated states.

We implemented the HSCP algorithm, and

compared it with LAO

and RTDP on two partially-

observable, nondeterministic planning domains that

are well-known from previous experimental studies:

Robot Navigation and Blocks World. Three random

problems were generated from each domain for

experiments. We compared three different search

algorithms in terms of the number of search trials,

the number of value updates, and the number of

generated states. Figure 7 ~ Figure 9 show the

experimental results. While RTDP has performed

lots of search trials to get the optimal values of states,

our HSCP and LAO

have done just one or two trials

for each problem. Out of three search algorithms,

RTDP has tried value updates the most, but HSCP

has done the least. Considering the number of

generated states, we find out HSCP has explored

much smaller search space than the other two

algorithms.

6 CONCLUSIONS

We have presented a new heuristic search algorithm

for solving contingent planning problems with the

partial initial condition and nondeterministic actions.

Through several experiments, we have evaluated the

efficiency of this algorithm.

ACKNOWLEDGEMENTS

Industrial Strategic Technology Development

Program (10032108), funded by the Ministry of

Knowledge Economy(MKE, Korea).

REFERENCES

Bonet, B., Geffner, H., 2003. Labeled RTDP: Improving

the convergence of real-time dynamic programming.

In ICAPS’03, 13

International Conference on

Automated Planning and Scheduling. AAAI Press.

Ghallab, M., Nau, D., Traverso, P., 2004. Automated

planning: theory and practice, Morgan Kaufmann.

Hansen, E., Zilberstein, S., 2001. LAO*: A heuristic

search algorithm that finds solutions with loops.

Artificial Intelligence, vol. 129, No. 1-2, pp. 35-62.

Hoffmann, J., Brafman, R., 2005. Contingent planning via

heuristic forward search with implicit belief states. In

ICAPS’05, 15

International Conference on

Automated Planning and Scheduling. AAAI Press.

Kuter, U., Nau, D., Reisner, E., Goldman, R., 2007.

Conditionalization: Adapting forward-chaining

planners to partially observable environments. In

ICAPS’07, 17

International Conference on

Automated Planning and Scheduling. AAAI Press.

Kuter, U., Nau, D., 2004. Forward-chaining planning in

nondeterministic domains. In AAAI’04, 19

National

Conference on Artificial Intelligence. AAAI Press.

CONTINGENT PLANNING AS BELIEF SPACE SEARCH

697
