ROBUST AND UNBIASED FOREGROUND / BACKGROUND

ENERGY FOR MULTI-VIEW STEREO

Zhihu Chen and Kwan-Yee K. Wong

Department of Computer Science, The University of Hong Kong, Pokfulam Road, Hong Kong

Keywords:

Multi-view stereo, Photo-consistency Energy, Foreground / Background energy, Graph-cuts.

Abstract:

This paper revisits the graph-cuts based approach for solving the multi-view stereo problem, and proposes a

novel foreground / background energy which is shown to be unbiased and robust against noisy depth maps.

Unlike most existing works which focus on deriving a robust photo-consistency energy, this paper targets

at deriving a robust and unbiased foreground / background energy. By introducing a novel data-dependent

foreground / background energy, we show that it is possible to recover the object surface from noisy depth

maps even in the absence of the photo-consistency energy. This demonstrates that the foreground / background

energy is equally important as the photo-consistency energy in graph-cuts based methods. Experiments on real

data sequences further show that high quality reconstructions can be achieved using our proposed foreground

/ background energy with a very simple photo-consistency energy.

1 INTRODUCTION

Multi-view stereo (MVS) is a key technique in com-

puter vision for reconstructing a dense 3D geome-

try of an object from images taken around it. It has

many applications such as preservation of arts, ani-

mation, and augmented reality. Many research works

on MVS have therefore been carried out in the past

few decades. This results in a huge pool of sophisti-

cated algorithms (Seitz et al., 2006).

In this paper, we are going to revisit the graph-

cuts based approach for solving the multi-view stereo

problem. Being one of the most popular MVS algo-

rithms, the graph-cuts based approach has been re-

ceiving a lot of attentions in recent years (Vogiatzis

et al., 2005; Kolmogorov and Zabih, 2002; Lempitsky

et al., 2006; Tran and Davis, 2006; Sinha and Polle-

feys, 2005; Ladikos et al., 2008; Vogiatzis et al., 2007;

Hern

andez et al., 2007). Graph-cuts based methods

generally solve the problem by deﬁning a foreground /

background energy for each voxel in a discretized vol-

ume, and a photo-consistency energy between adja-

cent voxels. A specialized graph G is then constructed

with each voxel deﬁning a node in this graph. There

are also two additional nodes, namely the source s

and the sink t representing the foreground and back-

ground respectively, in G which are connected to all

other nodes. The photo-consistency energy is used

to deﬁne the weights for the links between adjacent

voxel nodes, whereas the foreground / background

energy is used to deﬁne the weights for the links be-

tween the voxel nodes and the sink t / source s. The

object surface is estimated by minimizing the photo-

consistency energy associated with the surface and the

foreground / background energy associated with the

(foreground / background) label of each voxel. This

corresponds to ﬁnding the s-t min-cut of G which par-

titions G into two parts, namely S and T , with a mini-

mal cost such that s ∈ S and t ∈ T .

Unlike most existing works which focus on de-

riving a robust photo-consistency energy, this paper

targets at deriving a robust and unbiased foreground

/ background energy. It has been noted in previ-

ous works that the foreground / background energy

is important in preserving both protrusions and con-

cavities in the reconstructed surface. By introducing

a novel data-dependent foreground / background en-

ergy, we show that it is possible to recover the object

surface from noisy depth maps even in the absence

of the photo-consistency energy. To the best of our

knowledge, this is the ﬁrst time that a reconstruction

is achieved without using a photo-consistency energy

in graph-cuts. This demonstrates that the foreground

/ background energy is as important as the photo-

consistency energy in graph-cuts based methods. Ex-

periments on real data sequences further show that

high quality reconstructions can be achieved using

our proposed foreground / background energy with a

451

Chen Z. and K. Wong K..

ROBUST AND UNBIASED FOREGROUND / BACKGROUND ENERGY FOR MULTI-VIEW STEREO.

DOI: 10.5220/0003308604510458

In Proceedings of the International Conference on Computer Vision Theory and Applications (VISAPP-2011), pages 451-458

ISBN: 978-989-8425-47-8

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

very simple photo-consistency energy.

The rest of the paper is organized as follows. Sec-

tion 2 gives a brief literature review on graph-cuts

based MVS methods. Section 3 describes our pro-

posed algorithm in detail. In particular, a novel unbi-

ased data-dependent foreground / background energy

is introduced. In Section 4, experimental results on

real data sequences as well as evaluation results are

presented. Finally, Section 5 concludes our main con-

tributions.

2 RELATED WORK

Kolmogorov and Zabih (Kolmogorov and Zabih,

2002) were amongst the ﬁrst to formulate the multi-

view stereo problem as an energy minimization prob-

lem, and reconstruct the 3D object by solving the min-

imization problem using graph-cuts. They proposed

an energy formulation which could handle the visi-

bility problem and impose spatial smoothness while

preserving discontinuity. In (Vogiatzis et al., 2005),

Vogiatzis et al. handled the visibility problem by ex-

ploiting the visual hull to approximate the visibility

of voxels. They also introduced a uniform ballooning

term to avoid the elimination of protrusions in the re-

construction. In (Sinha and Pollefeys, 2005), Sinha et

al. enforced the silhouette constraints while minimiz-

ing the photo-consistency energy and the smoothness

term. Lempitsky et al. (Lempitsky et al., 2006) es-

timated visibility based on the positions and orienta-

tions of local surface patches, and used graph-cuts to

minimize the photo-consistency energy and the uni-

form ballooning term on a CW-complex. In (Tran

and Davis, 2006), Tran and Davis added a set of pre-

deﬁned locations as constraints in graph-cuts to im-

prove the performance. In (Vogiatzis et al., 2007), Vo-

giatzis et al. used Parzen window method to compute

the depth maps robustly, and formulated the photo-

consistency energy using a voting scheme (Esteban

and Schmitt, 2004) based on these depth maps. In

(Hern

andez et al., 2007), Carlos et al. proposed a

data-dependent intelligent ballooning term based on

the probability of invisibility of a voxel. The use of

the intelligent ballooning can solve the over-inﬂated

problem caused by the use of a data-independent uni-

form ballooning term.

Most of the aforementioned methods focus on

tackling the visibility problem in the computation

of the photo-consistency energy (Kolmogorov and

Zabih, 2002; Lempitsky et al., 2006; Vogiatzis et al.,

2007). Only two (Vogiatzis et al., 2005; Hern

andez

et al., 2007) of them consider the foreground / back-

ground energy. In (Vogiatzis et al., 2005), Vogiatzis

et al. pointed out that the energy-minimizing surface

might suffer from a lack of protrusions present in the

object if only the photo-consistency energy is consid-

ered. They therefore introduced the uniform balloon-

ing term which favors a large volume inside the visual

hull. Such a ballooning term is in fact a special form

of the foreground / background energy. It only de-

ﬁnes a background energy inside the visual hull, and

the foreground energy is simply set to zero. Voxels in-

side the visual hull are therefore biased to be in fore-

ground. By including this term in the energy function,

protrusions in the object can then be reconstructed.

However, depending on the weights assigned to this

term, it may also result in an over-inﬂated reconstruc-

tion. Besides, the visual hull of the object may not

be always available, especially in a complex back-

ground. In (Hern

andez et al., 2007), Carlos et al.

formulated an intelligent ballooning term based on

the overall probability of invisibility of a voxel, and

their method can reconstruct both protrusions as well

as concavities in the object. However, as the overall

probability of invisibility of a voxel is computed as

the product of its probabilities of invisibility in indi-

vidual views, such a ballooning term is not robust. For

instance, if the probability of invisibility of a voxel

in one view is inaccurately calculated due to image

noise, its overall probability of invisibility will be se-

riously affected. Besides, such a ballooning term is

also biased. If the probability of invisibility of a voxel

is small in one view, its overall probability of invisi-

bility will become small, and therefore the voxel is

biased to be in the background.

In this paper, instead of proposing yet another ro-

bust photo-consistency energy, we target at deriving

a novel foreground / background energy that is both

unbiased and robust against noisy depth maps. We

believe that the foreground / background energy plays

an equally important role as the photo-consistency en-

ergy in graph-cuts based methods. In fact, by using

our proposed robust and unbiased foreground / back-

ground energy, we will demonstrate later in this pa-

per that it is possible to reconstruct an object without

even using the photo-consistency energy term. This

further strengthens our belief in the importance of the

foreground / background energy. This also means that

a robust foreground / background energy can actually

compensate the errors caused by the inaccuracy of the

photo-consistency energy.

3 ALGORITHM DESCRIPTION

The input to our method is a sequence of images

I = {I

,··· , I

} taken around an object, together

VISAPP 2011 - International Conference on Computer Vision Theory and Applications

452

with a set of the corresponding camera projection ma-

trices P = {P

,· ·· , P

}, and a bounding box for

the object. Note that we also refer {I

,· ·· , I

} to

as different views. Like other graph-cuts based meth-

ods, we formulate the 3D surface as an energy func-

tion, and solve the reconstruction problem by mini-

mizing the energy function using graph-cuts. Our en-

ergy function E consists of three parts, namely the

photo-consistency energy E

sur f

, the foreground en-

ergy E

f ore

, and the background energy E

back

, and is

given by

E(S) = E

sur f

(S) + E

f ore

(V (S)) + E

back

(V (S)), (1)

where S denotes the object surface, V (S) the object

volume enclosed by S (also refers to as the foreground

volume), and V (S) the background volume. In the

following subsections, we will describe each of these

energy terms in detail.

3.1 Photo-consistency Energy

The photo-consistency energy for a given surface S is

deﬁned as

sur f

(S) =

ρ(x) dA, (2)

where ρ(x) is a dissimilarity measure used to deter-

mine the degree of dissimilarity of a point x as ob-

served in different views. The greatest challenge in

the computation of E

sur f

(S) is the problem of vis-

ibility. We need to determine the set of images

vis

⊆ I) in which a point x is visible. In (Vogiatzis

et al., 2005), this problem is tackled by utilizing the

visual hull of the object to approximate the visibil-

ity of nearby points. However, such an approxima-

tion will fail disgracefully in regions of concavities

on the object surface. Besides, this approach cannot

deal with self-occlusions and the visual hull might not

be always available.

In this paper, we adopt a robust voting scheme as

described in (Esteban and Schmitt, 2004) to compute

sur f

(S). Concretely, for each 3D point x inside the

bounding box of the object, each view I

will cast a

vote V OT E

(x) for x. All the VOTE

(x) are then com-

bined together using the formula

ρ(x) = e

−µ

∑

i=1

VOTE

(x)

. (3)

To compute VOTE

(x) for a 3D point x inside the

bounding box, we march along the corresponding op-

tic ray

(d) = c

x − c

kx − c

d (4)

inside the bounding box, where c

is the camera center

for view I

, and d is the depth value for a 3D point

along the optical ray in view I

(x corresponds to the

depth value d

). For each depth value d, we project

the corresponding 3D point o

(d) onto a set N (i) of

M closest views, and compute the NCC values using

a window of size m × m centered at the projections of

(d) on I

and I

j∈N (i)

with sub-pixel accuracy. We

then combine these M NCC values into a single score

C (d) and cast a vote to x using the following formula

VOT E

(x) =



C (d

) if C (d

) ≥ C (d) ∀d

0 otherwise

(5)

There are different methods for calculating C (d).

In (Esteban and Schmitt, 2004), C (d) is simply the

average of the M NCC values. In (Vogiatzis et al.,

2007), Vogiatzis et al. pointed out that the global

maximum may not be necessarily corresponding to

the correct depth, and they used a Parzen window

technique to combine all the local maxima of the NCC

values. As the focus of this paper is the foreground /

background energy, we simply deﬁne C (d) as the av-

erage value of the largest M/2 NCC values. Although

this strategy will result in noisy depth maps, experi-

mental results show that high quality reconstructions

can be achieved using the robust and unbiased fore-

ground / background energy introduced in the next

subsection.

3.2 Foreground/Background Energy

If the energy function only consists of the photo-

consistency energy, protrusions and concavities in the

object will be removed in the reconstructed surface.

In order to prevent this situation, the energy func-

tion must include the foreground / background en-

ergy. The foreground energy of a 3D point x is the

cost of assigning x to the foreground, and the back-

ground energy of x is the cost of assigning x to the

background. In (Vogiatzis et al., 2005), the fore-

ground / background energy is formulated as a uni-

form ballooning term in which E

f ore

(V (S)) = 0 and

back

(V (S)) = b

RRR

V (S)

dV , where b is a weight pa-

rameter. This can be considered as the shape prior

of the object which favors a large volume. However,

voxels inside the visual hull are biased to be in the

foreground with such a data-independent uniform bal-

looning term, and therefore it cannot deal with deep

concavities in the object.

In (Hern

andez et al., 2007), Hern

andez et al. pro-

posed a data-aware intelligent ballooning term based

on the overall probability of invisibility of a 3D

point. This formulation is theoretically correct, but

will be very sensitive to noise in practice. Theoret-

ically speaking, the overall probability of invisibil-

ity of a 3D point x inside the object should be close

ROBUST AND UNBIASED FOREGROUND / BACKGROUND ENERGY FOR MULTI-VIEW STEREO

453

to one. However, due to image noise, the “correct

depth” for the ray passing through x may be incor-

rectly estimated in some views. The probability of

invisibility of x in those views may become close to

zero, making its overall probability of invisibility also

close to zero. x will therefore be biased to be in

the background. For this reason, the intelligent bal-

looning term in (Hern

andez et al., 2007) is not robust

to noise and could only work in the case when the

depth maps computed from different views are very

accurate. This in turn implies a very robust photo-

consistency energy is needed. This, however, is very

difﬁcult to achieve in practice.

As voting scheme has been proven to be robust to

noise, we propose to use voting scheme to formulate

the foreground / background energy. Intuitively, if a

3D point V 1 is associated with a depth d

V 1

in view I

which is larger than the correct depth d

corr

, it is likely

that V 1 will be invisible in I

. Meanwhile, if a 3D

point V 2 is associated with a depth d

V 2

in I

which is

smaller than d

corr

, it is likely that it will be visible in I

(see Fig. 1). In this paper, we approximate the correct

depth by the estimated depth. In order to utilize the

visibility information, each view will cast a vote for

the 3D point x as follows:

B V OTE

(x) =



1 if d

< d

corr

0 otherwise

(6)

The foreground / background energy of a 3D point x

is then deﬁned as

energyForeground(x) = 1 − e

−λ

∑

i=1

B VOT E

(x)

(7)

energyBackground(x) = e

−λ

∑

i=1

B VOT E

(x)

(8)

Note that energyForeground(x) +

energyBackground(x) = 1. Finally, the foreground /

background energy for the surface is formulated as

f ore

(V (S)) = b

ZZZ

V (S)

energyForeground(x)dV

(9)

back

(V (S)) = b

ZZZ

V (S)

energyBackground(x)dV

(10)

where b is a weight parameter, and a value between

0.1 to 0.2 is suitable for all our experiments. λ is

also a constant value, and it mainly depends on the

number of views in the dataset. The proposed fore-

ground / background energy is unbiased. Whether x is

more probable to be in the foreground or background

depends on the values of energyForeground(x) and

energyBackground(x). If energyForeground(x) is

smaller, x is more probable to be in the foreground.

Otherwise, it is more probable to be in the back-

ground. Moreover, if the depths for x in some views

are incorrect, it will only inﬂuence the votings for

corr

Figure 1: Consider a ray originated from the camera center

of view I

that passes through the bounding box. Along

this ray, the score C(V

corr

) for voxel V

corr

is a maximum,

and hence the depth corresponding to V

corr

is the estimated

correct depth, denoted by d

corr

. Voxel V1 has a depth d

V 1

which is larger than d

corr

. V 1 is therefore deemed to be

invisible in view I

as it is occluded by the voxel V

corr

. On

the contrary, voxel V 2 has a depth d

V 2

which is smaller than

corr

. V 2 is therefore deemed to be visible in view I

. In this

case, B V OTE

(V 2) = 1 and B V OTE

(V 1) = 0.

x from those views. Therefore, the proposed fore-

ground / background energy is also more robust to

image noise.

4 EXPERIMENTAL RESULTS

In the following subsections, implementation details

of the proposed algorithm and experimental results

will be described in detail. Note that, unlike the

method presented in (Vogiatzis et al., 2005), the al-

gorithm proposed in this paper does not require using

the visual hull as an initialization.

4.1 Graph Structure

A 3D space slightly larger than the bounding box is

quantized into voxels of size h × h × h. As illustrated

in Fig. 2, a graph G is constructed with each voxel

deﬁning a node. Two nodes are connected if their

corresponding voxels are 6-neighbor of each other. G

also includes two additional nodes, namely the source

s which is ﬁxed in the foreground and the sink t

which is ﬁxed in the background. All voxel nodes

are connected to both s and t. The weight of the

link between a voxel node x

and s is deﬁned as b ×

energyBackground(x

) and the weight of the link be-

tween x

and t is deﬁned as b×energyForeground(x

If voxel node x

and voxel node x

are connected, the

weight of the link is deﬁned as

VISAPP 2011 - International Conference on Computer Vision Theory and Applications

454

i j

= ρ



+ x



. (11)

Moreover, if the center of a voxel is outside the

bounding box, the weight of the link between the cor-

respond node and t is reset to inﬁnity and the weight

of the link between the correspond node and s is reset

to zero.

source (foreground)

sink (background)

b×energyBackground(

)

b×energyForeground(

)

b×energyBackground(

)

b×energyForeground(

)

b×energyBackground(x

)

b×energyForeground(

)

Figure 2: Graph structure for MVS problem. Each node

in the graph represents a voxel. Two nodes are connected

if the corresponding voxels are 6-neighbor of each other.

The weight of the link between two connected nodes is

deﬁned by the dissimilarity measure ρ(x) computed at the

midpoint between the centers of the corresponding voxels.

All nodes are also connected to two special nodes, namely

the source and the sink, with weights of the links deﬁned as

b × energyBackground(x

) and b × energyForekground(x

)

respectively.

4.2 Results and Evaluations

The graph-cuts algorithm proposed in (Boykov and

Kolmogorov, 2004) is used to segment the graph into

two parts: source part (foreground) and sink part

(background). Marching cube algorithm (Lorensen

and Cline, 1987) is then used to generate a triangu-

lated mesh from the foreground voxels, and Taubin

smooth (Taubin, 1995) is used to smooth the resulting

mesh.

We have applied our algorithm to several datasets

on a system with Intel(R) Core(TM) 2 Duo CPU

E6750 @ 2.66GHZ 2.67GHZ and 8GM RAM. We

have also submitted our reconstruction results of two

standard datasets, namely the temple sequence and

dinosaur sequence, to the evaluation website (Seitz

et al., ) for comparison. The results are compared in

terms of accuracy and completeness. The accuracy

metric used is deﬁned as the distance d such that 90%

of the reconstruction is within d mm of the ground

truth, while the completeness metric used is deﬁned

as the percentage X such that X % of the ground truth

is within 1.25 mm of the reconstructed result. Table 1

shows the evaluation results. Details of the sequences

used and the reconstruction results are discussed in

the following subsections.

Temple. The temple sequence was captured in Stand-

ford Spherical Gantry and is available from the web-

site (Seitz et al., ). It consists of 312 images and the

image resolution is 640 × 480. The templeRing se-

quence is a sparse sequence sampled from the temple

sequence and consists of only 47 images. Both se-

quences were used in our experiments.

(a)

(b)

(c)

(d)

Figure 3: Comparison between the proposed foreground /

background energy and the intelligent ballooning term pro-

posed in (Hern

andez et al., 2007). From left to right: (a)

photo-consistency energy, (b) intelligent ballooning term,

ground energy. Blue color indicates a low energy value and

red color indicates a high energy value. Note that the fore-

ground energy values are lower inside the object and higher

outside the object. The background energy values, on the

other hand, are higher inside the object and lower outside

the object.

Fig. 3 compares our foreground / background en-

ergy with the intelligent ballooning term

proposed

in (Hern

andez et al., 2007). In this ﬁgure, blue color

indicates a low energy value and red color indicates

a high energy value. Fig. 3(a) shows a plot of the

photo-consistency energy for a particular cross sec-

tion, which reveals that the original depth maps are

quite noisy. Fig. 3(b) shows a plot of the intelligent

ballooning term for the same cross section. It can be

observed that, although still separable, energy values

inside the temple are very close to those in the back-

ground. Besides, the space in the upper right corner

as well as that between the pillars are contaminated

by noises. Fig. 3(c) and (d) show our proposed fore-

ground and background energy, respectively, for the

same cross section. It can be seen that energy val-

ues inside the temple are signiﬁcantly different from

In (Hern

andez et al., 2007), the probability den-

sity function of invisibility in each view is computed

by pd f (d) = α ∗ Uni f orm(d,dMin,dMax) + (1 − α) ∗

Gaussian(d, mean

,sigma

), where dMin,dMax are the

depths of intersections of the optic ray with the bounding

box, mean

is the measured depth, sigma

corresponds to

the length of 1 pixel back-projected in 3D, and α is a prede-

ﬁned constant outlier ratio.

ROBUST AND UNBIASED FOREGROUND / BACKGROUND ENERGY FOR MULTI-VIEW STEREO

455

Table 1: Evaluation results for our reconstructions of the templeRing sequence, temple sequence , and dinoRing sequence. The

accuracy value is the distance d such that 90% of the reconstruction is within d mm of the ground truth. The completeness

value is the percentage X such that X % of the ground truth is within 1.25 mm of the reconstructed result.

Name Images Image Size accuracy(mm) completeness(%)

templeRing 47 640×480 0.54 99.6

temple 312 640×480 0.47 99.3

dinoRing 48 640×480 0.46 95.1

(a)

(b) (c)

(e)

(f)

(g)

(d)

(h)

Figure 4: (a) Two images from the templeRing sequence. Reconstruction results using (b) photo-consistency energy with

a small uniform ballooning term, (c) photo-consistency energy with a large uniform ballooning term, (d) photo-consistency

energy with intelligent ballooning term, (e,f) photo-consistency energy with the proposed foreground / background energy,

and (g, h) only the proposed foreground / background energy.

those in the background, and this allows an excellent

segmentation of the foreground and background.

Fig. 4 shows the reconstruction results of the

templeRing sequence using photo-consistency energy

with a small uniform ballooning term (Fig. 4(b)),

photo-consistency energy with a large uniform bal-

looning term (Fig. 4(c)), photo-consistency energy

with intelligent ballooning term (Fig. 4(d)), photo-

consistency energy with the proposed foreground /

background energy (Fig. 4(e) and (f)), and only the

proposed foreground / background energy (Fig. 4(g)

and (h)), respectively. From Fig. 4(b) and (c), it can

be seen that a small uniform ballooning term would

result in an incomplete model, whereas a large uni-

form ballooning term would cause an over-inﬂated

model. Using the intelligent ballooning term in place

of the uniform ballooning term could alleviate this

problem, and the temple was reconstructed with de-

tails. Nonetheless, it can be seen in Fig. 4(d) that there

are some errors near the top and bottom of the recon-

struction, which can be explained by the plot of the

intelligent ballooning term shown in Fig. 3(b). The

best reconstruction result was obtained using photo-

consistency energy with the proposed foreground /

background energy (see Fig. 4(e) and (f)). The roof,

the stairs and the concavities at the bottom of the tem-

ple were all accurately reconstructed. The accuracy of

the reconstruction is 0.54 mm and the completeness is

99.6%. To further test the usefulness of the proposed

foreground / background energy, we have carried out

a reconstruction using only the proposed foreground /

background energy. Not surprisingly, good result was

achieved since the foreground / background energy

alone allows an excellent segmentation of the fore-

VISAPP 2011 - International Conference on Computer Vision Theory and Applications

456

Table 2: Comparison between the reconstruction results of the standard temple sequence and templeRing sequence obtained

by (Vogiatzis et al., 2005), (Vogiatzis et al., 2007) and the proposed method.

temple(312) templeRing(47)

Method

acc.[mm] comp.[%] acc.[mm] comp.[%]

Initialization

Proposed 0.47 99.3 0.54 99.6 Bounding Box

Vogiatzis (Vogiatzis et al., 2005) 1.07 90.7 0.76 96.2 Visual Hull

Vogiatzis (Vogiatzis et al., 2007) 0.5 98.4 0.64 99.2 Visual Hull

Figure 6: Reconstruction results of (a) girl sequence, and (b) bird sequence.

Figure 5: Two images from the dinoRing sequence and the

reconstruction result rendered in two different viewpoints.

ground and background (see Fig. 3(c) and (d)).

We have also carried out a reconstruction of the

temple sequence using photo-consistency energy with

the proposed foreground / background energy. Table 2

compares our reconstruction results of the temple se-

quence and templeRing sequence with that obtained

by (Vogiatzis et al., 2005) and (Vogiatzis et al., 2007),

both of which use a uniform ballooning term. Al-

though a bounding box instead of the visual hull is

used in our algorithm, our results are still better than

that obtained by (Vogiatzis et al., 2005) and (Vogiatzis

et al., 2007) in terms of accuracy and completeness.

Dinosaur. The dinoRing sequence consists of 48 im-

ages and the image resolution is 640 × 480. This se-

quence is relatively more difﬁcult than the temple se-

quence due to the lack of features on the body of the

dinosaur. Nonetheless, the proposed algorithm still

produced good result. Fig. 5 shows two images from

the sequence and the reconstruction result rendered in

two different viewpoints. The accuracy of the recon-

struction result is 0.46 mm and the completeness is

95.1%.

Girl and Bird. Both the girl sequence and the bird

sequence consist of 60 images taken around the object

The girl sequence contains specular reﬂections and

is lack of features, especially in the face, hands and

feet. The bird sequence, on the other hand, has many

protrusions and concavities at the bottom part of the

bird model. Our algorithm could recover both objects

with details (see Fig. 6).

5 CONCLUSIONS

This paper revisits the graph-cuts based approach

for solving the multi-view stereo problem. Unlike

most existing works which focus on deriving a photo-

consistency energy that is robust against invisibility,

this paper targets at deriving a robust and unbiased

foreground / background energy. A voting scheme is

adopted to derive a novel data-dependent foreground

/ background energy which is shown to be unbiased,

robust against noisy depth maps, and allows an excel-

lent segmentation of the foreground and background.

In fact, we have demonstrated that it is possible to re-

cover the object surface using only the proposed fore-

ground / background energy (i.e., without using the

photo-consistency energy term in graph-cuts). This

demonstrates that the foreground / background energy

ROBUST AND UNBIASED FOREGROUND / BACKGROUND ENERGY FOR MULTI-VIEW STEREO

457

is equally important as the photo-consistency energy

in graph-cuts based methods. Experiments on real

data sequences further show that high quality recon-

structions can be achieved using our proposed fore-

ground / background energy with a very simple photo-

consistency energy.

REFERENCES

Boykov, Y. and Kolmogorov, V. (2004). An experimental

comparison of min-cut/max-ﬂow algorithms for en-

ergy minimization in vision. IEEE Trans. on Pattern

Analysis and Machine Intelligence, pages 1124–1137.

Esteban, C. H. and Schmitt, F. (2004). Silhouette and stereo

fusion for 3d object modeling. Computer Vision and

Image Understanding, pages 367–392.

Hern

andez, C., Vogiatzis, G., and Cipolla, R. (2007). Prob-

abilistic visibility for multi-view stereo. In Proc. Conf.

Computer Vision and Pattern Recognition, pages 1–8.

Kolmogorov, V. and Zabih, R. (2002). Multi-camera scene

reconstruction via graph cuts. In Proc. European

Conf. on Computer Vision, pages 82–96.

Ladikos, A., Benhimane, S., and Navab, N. (2008). Multi-

view reconstruction using narrow-band graph-cuts

and surface normal optimization. In Proc. British Ma-

chine Vision Conference, pages 143–152.

Lempitsky, V. S., Boykov, Y., and Ivanov, D. V. (2006). Ori-

ented visibility for multiview reconstruction. In Proc.

European Conf. on Computer Vision, pages 226–238.

Lorensen, W. E. and Cline, H. E. (1987). Marching cubes:

A high resolution 3d surface construction algorithm.

SIGGRAPH Comput. Graph., pages 163–169.

Seitz, S. M., Curless, B., Diebel, J., Scharstein, D., and

Szeliski, R. Multi-view stereo evaluation web page.

http://vision.middlebury.edu/mview/.

Seitz, S. M., Curless, B., Diebel, J., Scharstein, D., and

Szeliski, R. (2006). A comparison and evaluation

of multi-view stereo reconstruction algorithms. In

Proc. Conf. Computer Vision and Pattern Recognition,

pages 519–528.

Sinha, S. N. and Pollefeys, M. (2005). Multi-view recon-

struction using photo-consistency and exact silhouette

constraints: A maximum-ﬂow formulation. Proc. Int.

Conf. on Computer Vision, pages 349–356.

Taubin, G. (1995). A signal processing approach to fair

surface design. In SIGGRAPH ’95: Proceedings of the

22nd annual conference on Computer graphics and

interactive techniques, pages 351–358.

Tran, S. and Davis, L. (2006). 3d surface reconstruction

using graph cuts with surface constraints. In Proc.

European Conf. on Computer Vision, pages 219–231.

Vogiatzis, G., Hern

andez Esteban, C., Torr, P. H. S., and

Cipolla, R. (2007). Multiview stereo via volumet-

ric graph-cuts and occlusion robust photo-consistency.

IEEE Trans. on Pattern Analysis and Machine Intelli-

gence, pages 2241–2246.

Vogiatzis, G., Torr, P. H. S., and Cipolla, R. (2005). Multi-

view stereo via volumetric graph-cuts. In Proc. Conf.

Computer Vision and Pattern Recognition, pages 391–

398.

VISAPP 2011 - International Conference on Computer Vision Theory and Applications

458
