SUSTAINABILITY OF HADOOP CLUSTERS

Luis Bautista and Alain April

ETS, University of Quebec, Software Engineering Department, 1100 Notre-Dame, Montreal, Canada

Keywords: Cloud Computing, High Availability Cluster, Hadoop Distributed File System, ZooKeeper.

Abstract: Hadoop is a set of utilities and frameworks for the development and storage of distributed applications in

cloud computing, the core component of which is the Hadoop Distributed File System (HDFS). NameNode

is a key element of its architecture, and also its “single point of failure”. To address this issue, we propose a

replication mechanism that will protect the NameNode data in case of failure. The proposed solution

involves two distinct components: the creation of a BackupNode cluster that will use a leader election

function to replace the NameNode, and a mechanism to replicate and synchronize the file system namespace

that is used as a recovery point.

1 INTRODUCTION

Cloud computing is a new technology aimed at

processing and storing very large amounts of data. It

is an Internet-based technology, in which several

distributed computers work together to process

information in a more efficient way and deliver

results more quickly to the users who require them.

In general, cloud computing users don’t own the

physical infrastructure. Instead, they rent usage of

infrastructure, platform or software from a third-

party provider. The delivery of computer

infrastructure, platform of software or applications,

typically is known as Cloud Services (Jin, Ibrahim et

al. 2010).

There are several Cloud Service Providers (CSP)

for the different type of services, for example

Amazon EC2, SalesForce.com, 3tera Inc, and

Eucalyptus, among many others, making use of

distributed computing technologies. One of these

technologies is called the distributed file system

(DFS), which allows access to files from multiple

computers accessible via the Internet. The Google

File System (GFS) and the Hadoop Distributed File

System (HDFS) are two examples of DFS

implementations.

DFS, like the open source project HDFS, are

designed to store very large files, across multiple

computers, where exceptional reliability is provided

by its replication mechanisms. Replication across

multiple computers can replace the need for RAID

(redundant array of independent disk) storage

technology. Also, HDFS is designed to run on a

large number of commodity computers concurrently.

Commodity computers are computer systems

manufactured by multiple vendors, incorporating

components based on open standards. A governing

principle of commodity computing is that it is better

to have more lower performance and lower cost

hardware working in parallel than it is to have fewer,

but more expensive computers. The key to using

commodity computers in large numbers is a

replication mechanism that provides high fault

tolerance on low-cost hardware.

However, DFS must provide guaranteed high

availability. HDFS has been designed with a

master/slave architecture of clusters, which consists

of a single NameNode (NN), the master server that

manages the file system namespace and regulates

access to files by clients. In addition, a number of

DataNodes (DN) manage large amounts of storage

(Borthakur, 2008

). The existence of a unique

NameNode in an HDFS greatly simplifies the

architecture of this technology, however it is also its

weakness. We call this weakness a single point of

failure (SPoF). When an HDFS NameNode fails,

fixing it currently requires a manual recovery.

2 SINGLE POINT OF FAILURE IN

HDFS

We have stated that an HDFS cluster has two types

of nodes (computers): a master node called a

NameNode (NN) and a number of slaves nodes

called DataNodes (DN). The NN manages the file

587

Bautista L. and April A..

SUSTAINABILITY OF HADOOP CLUSTERS.

DOI: 10.5220/0003332705870590

In Proceedings of the 1st International Conference on Cloud Computing and Services Science (CLOSER-2011), pages 587-590

ISBN: 978-989-8425-52-2

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

system namespace, which is where we maintain the

file system tree and the metadata for all the files and

directories. This information is persistently stored on

the local disks in two files: the namespace image

and the edit log. The NN also keeps track of the DN

on which all the blocks for a given file are located.

However, it does not store block locations

persistently, since this information is reconstructed

from NNs when the system starts (White, 2009).

The single point of failure (SPoF) in an HDFS

cluster is the NN, while the loss of any other node

(intermittently or permanently) does not result in a

data loss. So, NN loss results in HDFS cluster

unavailability. The permanent loss of NN data

would render the HDFS cluster inoperable (Yahoo,

2010). For this reason, it is important to make the

NN resilient to failure, and HDFS provides a manual

mechanism for achieving this.

The steps of the mechanism are as follows. First,

a backup up is made of the files that make up the

persistent state of the file system metadata, where

the usual configuration choice is to write to the local

disk as well as to a remote NFS mount. Then, a

secondary NameNode (SNN) must be run, which

will periodically merge the namespace image with

the edit log. This is necessary to prevent the edit log

from becoming too large. In HDFS, it is

recommended that the SNN run on a separate

physical computer, since this merge requires as

much CPU and memory as the NN (Apache, 2010).

However, when a failure occurs, a manual

intervention is necessary to copy the NN metadata

files, which are on the NFS, to the SNN that will

become the new NN.

There are currently some efforts planned to

convert the SNN to a standby node, which, besides

handling merging, could also maintain the up-to-date

state of the namespace, by processing constant edits

from the NN, and of the checkpoint node (which

creates the checkpoints of the namespace). This

standby node approach has been named a Backup

Node (BN) (Apache, 2008).

To resolve the SPoF, the BN would provide real-

time streaming of edits from an NN to a BN. This

would allow constant updating of the namespace

state. The BN would also conduct a checkpointing

function, ensuring the availability of the HDFS

namespace in memory and getting rid of the current

need to store the namespace on disk. Finally, the BN

proposal would offer the availability of a standby

node. This node, coupled with an automatic

switching (failover) function, would eliminate

potential data loss, unavailability, and manual

interventions into HDFS NN failures.

However, if the BN fails, what will take its

place?

3 PROPOSED SOLUTION

In this paper, we propose a distributed solution to

the problem of NN and BN failures, which makes

use of a coordination scheme and leader election

function within BN replicas. This can be achieved

using a service, such as ZooKeeper, for maintaining

configuration information, for naming, and for

distributed synchronization and group coordination.

3.1 Distributed Applications

with ZooKeeper

ZooKeeper is a service that allows distributed

processes to coordinate with each other through a

shared hierarchal namespace of data registers. It has

proven that it can be useful for large distributed

systems applications (Apache, 2008).

One of the main failure recovery problems with

distributed applications is partial failure. For

example, when a message is sent across the network

and it fails, the message will not be received, or

when the receiver’s process dies, the sender does not

know the reason for the failure. ZooKeeper provides

a set of tools to protect distributed applications when

this type of failure occurs.

Also of interest is that Zookeeper runs on a

cluster of computers called an ensemble, and is

designed to be highly available due to its replicated

mode. It has great potential to help solve the SPoF

problem of HDFS. We propose to use it to design

and manage a high availability BN cluster. With this

approach, if the Primary Backup Node (PBN) fails,

then an election mechanism for choosing a new PBN

is initiated. There could be a number of Replicated

Backup Nodes (RBN), as shown in Figure 1.

Figure 1: ZooKeeper Service for PBN Election.

CLOSER 2011 - International Conference on Cloud Computing and Services Science

588

3.2 Primary Backup Node Election

How would the PBN election mechanism work? It

would be based on the use of a protocol called Zab

(Red Junqueira, 2008). This protocol is already

implanted in ZooKeeper and runs in two phases,

(which may be repeated indefinitely):

Phase 1: Leader Election. The computers in an

ensemble (group of RBNs) go through a process of

electing a distinguished member, called a leader

(PBN). The other machines are termed followers.

This phase is finished once a majority (or quorum)

of followers has synchronized their state with that of

the leader.

Phase 2: Atomic Broadcast. All write requests

are forwarded to the leader (PBN), which broadcasts

the update to the followers (RBNs). When a majority

has processed the change, the leader commits to the

update, and the client receives a response to the

effect that the update has succeeded. The protocol

for achieving consensus is designed to be atomic, so

a change either succeeds or fails. It resembles a two-

phase commit.

Thus, if the NN fails, the PBN will take its place

and begin a leader election process within the group

of RBNs. This will result in the selection of a new

PBN that will take the place of the old PBN.

There are two important issues related to this

HDFS high availability proposal: replication and

synchronization of data. Replication is at the core of

our proposal, and would use an efficient and flexible

synchronization mechanism that must support

different workloads and offer optimal performance.

In our proposal, the file system namespace, which

must be replicated and which is included in the

fsimage file, is merged with the edit log to obtain a

persistent checkpoint of the file system.

Therefore, we must design a mechanism that

would create a reliable replication service for those

files. At the same time, this mechanism must

provide a recovery service during failures. There are

different ways to achieve this goal. We have

investigated ZooKeeper and BooKeeper as potential

solutions.

3.3 Log Stream of Records with

BooKeeper

The initial motivation for investigating BooKeeper

was that the NN of HDFS uses logs (edit logs) for

recovery in case of failure. BooKeeper was designed

as a replication service to reliably log streams of

records, where a BooKeeper Client (BC) receives

ledgers, which are entries of log streams from a

client application, and stores them to sets of

BooKeeper servers called bookies (Apache, 2010).

Besides providing high-availability services,

BooKeeper provides good performance by using

striping and scalability during quorums.

In our proposed solution, we intend to create

ledgers, which will contain the namespace image of

HDFS, and write them into bookies. This process

could be performed by the BooKeeper Client (BK),

which would run concurrently with a BooKeeper

Application (BA), as demonstrated in Figure 2. The

bookies would store the content of the ledgers in an

ensemble of bookies, storing into it the content of

different ledgers. To ensure good performance,

BooKeeper would store each bookie of an ensemble

as a fragment of a ledger. That is, each entry would

be written to sub-groups of bookies of the ensemble.

Figure 2: Log Stream of Records with BooKeeper.

With this proposal, the BN would maintain an in-

memory data structure. This data structure would

add entries from the NN, and, at the same time, the

BN can process one asyncAddEntry to queue up

changes. This would ensure a high change

throughput. Thus, our proposed solution to the

HDFS SPoF has the potential to create a reliable

mechanism of replicas and synchronization.

4 FUTURE WORK

In the next step of this research, we will conduct a

detailed design, based on the solution proposal

described here, of an amended HDFS. This will

allow us to assess the many possibilities of

embedding this solution within the distributed file

system (HFDS). Potential detailed solutions and

tradeoffs, will be investigated, and suitable families

of protocols to resolve this problem will be

SUSTAINABILITY OF HADOOP CLUSTERS

589

identified. Once the selected design has been

implemented, we will carry out a case study

assessing the feasibility of using a highly available

and reliable coordination system imbedded in HDFS

to address the SPoF problem.

5 CONCLUSIONS

This paper has presented a potential solution to the

problem of the “single point of failure” of HDFS

aimed at implementing a mechanism in HDFS

similar to BooKeeper. The proposed solution has

two distinct components: 1) a BackupNode cluster

which uses a leader election function and which can

replace the NameNode in case of failure; and 2) a

mechanism to replicate and synchronize the file

system namespace that is used as a recovery point.

REFERENCES

Apache Hadoop, 2010. http://hadoop.apache.org/

Apache Software Foundation, 2008. Streaming Edits to a

Backup Node, https://issues.apache.org/jira/browse

/HADOOP-4539 .

Apache Software Foundation, 2008. ZooKeeper Overview

http://hadoop.apache.org/zookeeper/docs/current/zook

eeperOver.html

Apache Software Foundation, 2010. BooKeeper

Overview.http://hadoop.apache.org/zookeeper/docs/

r3.3.0/bookkeeperOverview.html

Carolan, G., 2009. Introduction to Cloud Computing

Architecture. Sun Microsystems.

Dhruba, B., 2008. Hadooop Distributed File System

Architecture.

Jin, H., Ibrahim, S., Bell, T., Qi, L., Cao, H., Wu, S., and

Shi, X. (2010) Tools and Technologies for Building

Clouds, Cloud Computing: Principles, Systems and

Applications, Computer Communications and

Networks, Springer-Verlag.

Red, B., Junqueira, F. P., 2008. A Simple Totally Ordered

Broadcast Protocol. In proceedings of the 2nd

Workshop on Large-Scale Distributed Systems and

Middleware (LADIS), Yorktown Heights, New York,

September 15 - 17, vol. 341:2008).

White, T., 2009. Hadoop: The Definitive Guide, O´Reilly

Media, Inc.

Yahoo! Inc, 2010. Managing a Hadoop Cluster,

http://developer.yahoo.com/hadoop/tutorial/module7.h

tml#configs .

CLOSER 2011 - International Conference on Cloud Computing and Services Science

590
