MANAGING MULTIMODAL AND MULTILINGUAL SEMANTIC

CONTENT

Michael Martin

, Daniel Gerber

, Norman Heino

, S

oren Auer

and Timofey Ermilov

AKSW/Computer Science Institut, University of Leipzig, Postfach 100920, 04009 Leipzig, Germany

Keywords:

Knowledge management, Semantic web, Multimodality, Multilinguality, Semantic Wiki.

Abstract:

With the advent and increasing popularity of Semantic Wikis and the Linked Data the management of se-

mantically represented knowledge became mainstream. However, certain categories of semantically enriched

content, such as multimodal documents as well as multilingual textual resources are still difﬁcult to handle.

In this paper, we present a comprehensive strategy for managing the life-cycle of both multimodal and mul-

tilingual semantically enriched content. The strategy is based on extending a number of semantic knowledge

management techniques such as authoring, versioning, evolution, access and exploration for semantically en-

riched multimodal and multilingual content. We showcase an implementation and user interface based on the

semantic wiki paradigm and present a use case from the e-tourism domain.

1 INTRODUCTION

With the advent and increasing popularity of Seman-

tic Wikis and Linked Data the management of seman-

tically represented knowledge became mainstream.

Oracle, for example, integrated support for semantic

knowledge management into their database product

(Lopez and Das, 2009), Google started to evaluate

annotations using Resource Description Framework

attributes (RDFa) and the W3C has lately launched

the second revision of the Web Ontology Language

(OWL) standard. However, despite this progress cer-

tain categories of semantically enriched content, such

as multimodal documents as well as multilingual tex-

tual resources are still difﬁcult to handle.

Currently knowledge bases primarily contain

typed data and a limited amount of textual content,

such as short labels, short descriptions or small hy-

pertext fragments. With the increasing maturity of se-

mantic technologies and their wider use in many dif-

ferent application scenarios the representation and in-

terlinking of metadata for multimodal content such as

audio, video, compound hypertext or multimedia doc-

uments is becoming paramount. Another crucial fea-

ture of semantic knowledge representation is the lan-

guage independence. Ontologies, taxonomies or sim-

ple resource descriptions can be easily equipped with

multilingual texts and labels. However, the transla-

tion and life-cycle of multilingual semantic content is

currently insufﬁciently supported. Examples for the

importance of supporting multimodal and multilin-

gual semantic content are in particular, bio-medical

semantic information systems and semantics based

Web Content Management.

In this paper, we present a comprehensive strat-

egy for managing the lifecycle of both multimodal

and multilingual semantically enriched content. The

strategy is based on extending a number of seman-

tic knowledge management techniques such as au-

thoring, versioning, evolution, access and exploration

for semantically enriched multimodal and multilin-

gual content. With regard to multimedia content we

devise a strategy for extracting, semantically repre-

senting and interlinking metadata of multimedia doc-

uments. For the management of multilingual knowl-

edge bases we developed techniques for supporting

the lifecycle of multilingual resources by enabling

an efﬁcient semi-automatic translation of individual

property values, resources or all textual content stored

within a knowledge base. For keeping textual con-

tent in a knowledge base in the preferred language in

sync with translations into other languages we devise

a strategy based on capitalizing the integrated version-

ing of the Semantic Data Wiki OntoWiki. We show-

case an implementation and user interface and present

a use case from the e-tourism domain.

The paper is structured as follows: We describe

a number of important aspects for managing seman-

tic content in Section 2. We outline our strategy for

dealing with large quantities of multimodal content

290

Martin M., Gerber D., Heino N., Auer S. and Ermilov T..

MANAGING MULTIMODAL AND MULTILINGUAL SEMANTIC CONTENT.

DOI: 10.5220/0003336202900295

In Proceedings of the 7th International Conference on Web Information Systems and Technologies (WEBIST-2011), pages 290-295

ISBN: 978-989-8425-51-5

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

Application Layer

OntoWiki API,

Access Interfaces

Zend Framework

Persistence Layer

RDF Store

Store Adapter

Authentication, ACL,

Versioning, …

User Interface Layer

CSS

Framework

OntoWiki UI

API

RDFauthor Templates

Extensions

(Evolution,

Multimedia, …)

Figure 1: OntoWiki framework architecture.

in Section 3. In Section 4 we present the strategy

for supporting the life-cycle of multilingual resources.

We showcase an application scenario in Section 5,

where both – multimodal and multilingual – strategies

for semantic content management are successfully ap-

plied.

2 MANAGEMENT OF SEMANTIC

CONTENT

Our approach for managing multimodal and multilin-

gual semantic content is based on OntoWiki (Auer

et al., 2006). It started as an RDF-based data wiki

with emphasis on collaboration but has meanwhile

evolved into a comprehensive framework for devel-

oping Semantic Web applications (Heino et al., 2009).

This involved not only the development of a sophis-

ticated extension interface allowing for a wide range

of customizations but also the addition of several ac-

cess and consumption interfaces allowing OntoWiki

installations to play both a provider and a consumer

role in the emerging Web of Data. In the sequel we

discuss OntoWiki extensions that particularly facil-

itate authoring and management of multimodal and

multilingual data.

Authoring. Semantic content in OntoWiki is repre-

sented as resource descriptions. Following the RDF

data model representing one of the foundations of the

Semantic Web vision, resource descriptions are repre-

sented (at the lowest level) in the form of statements.

Each of these statements (or triples) consist of a sub-

ject which identiﬁes a resource as well as a predicate

and an object which together represent data about said

resource in a fashion reminiscent of key-value pairs.

By means of RDFa, these statements are retained in

the HTML view (i.e. user interface) part and are thus

accessible to client-side techniques like JavaScript.

Authoring of such content is based on said client-

side representation by employing the RDFauthor ap-

proach (Tramp et al., 2010b): views are declared in

terms of the model language (RDF) which allows the

underlying model be restored. Based on this model,

a user interface can be generated with the model be-

ing providing all the domain knowledge required to

do so. The RDFauthor system provides an extensible

set of authoring widgets specialized for certain edit-

ing tasks. In the work at hand, we extended the sys-

tem by adding capabilities for automatically translat-

ing literal object values. Since the semantic context

is known to the system, these translation functionality

can be bound to arbitrary characteristics of the data

(e. g. to a certain property or a missing language).

Versioning. Keeping track of all changes is an im-

portant task in order to encourage user participation.

OntoWiki applies this concept to RDF-based knowl-

edge engineering in that all changes are tracked on the

statement level (Auer and Herre, 2006). These low-

level changes can be grouped to reﬂect application-

and domain-speciﬁc tasks involving modiﬁcations to

several statements as a single versioned item. Prove-

nance information as well as other metadata (such as

time, user or context) of a particular changeset can be

attached to each individual changeset. All changes on

the knowledge base can be easily reviewed and rolled-

back if needed.

Evolution. The loosely typed data model of RDF

encourages continuous evolution and reﬁnement of

knowledge bases. With EvoPat, OntoWiki supports

this in a declarative, pattern-based manner (Rieß

et al., 2010). Basic evolution patterns consist of three

components (1) a set of variables, (2) a SPARQL

select query selecting a number of resources under

evolution, (3) a SPARQL/Update query template that

is executed for each resulting resource of the select

query. In addition, basic patterns can be combined

to form compound patterns—suitable for more com-

plex evolution scenarios. In order to facilitate the

semi-automatic application of evolution patterns, bad

smells can be deﬁned that serve as a detection mecha-

nism for ontology design anti-patterns or data model-

ing problems. If certain conditions are met, this pro-

cess is even fully automatable.

Access and Exploration Interfaces. In addition to

human-targeted graphical user interfaces, OntoWiki

supports a number of machine-accessible data inter-

faces: OntoWiki implements a SPARQL Endpoint,

allowing all resources managed in an OntoWiki be

queried over the Web. According to accepted Linked

MANAGING MULTIMODAL AND MULTILINGUAL SEMANTIC CONTENT

291

Data publication principles, OntoWiki makes all re-

sources accessible by its URI. Furthermore, for each

resource used in OntoWiki additional triples can be

fetched if the resource is dereferenceable. Pingback

is an established notiﬁcation system that gained wide

popularity in the blogsphere. OntoWiki adapts the

pingback idea known from the blogsphere to Linked

Data providing a notiﬁcation mechanism for resource

usage (Tramp et al., 2010a). If a Semantic Pingback-

enabled resource is mentioned (i. e. linked to) by an-

other party, its pingback server is notiﬁed of the us-

age.

For exploring semantic content, OntoWiki pro-

vides several exploration interfaces: The compromise

of, providing a generic user interface aiming at be-

ing as intuitive as possible is tackled by regarding

knowledge bases as information maps. Each node at

the information map, that is, RDF resource, is repre-

sented as a Web accessible page and interlinked to re-

lated digital resources. The full-text search makes use

of special indexes if the underlying knowledge store

provides this feature.The resulting SPARQL query is

stored as an object which can later be modiﬁed (e. g.

have its ﬁlter clauses reﬁned). For domain-speciﬁc

use cases, OntoWiki provides an easy-to-use exten-

sion interface. By providing such a custom view, it

is possible to hide the fact an RDF knowledge base is

being worked on. This permits OntoWiki to be used

as a data-entry frontend for users with a less profound

knowledge of semantic technologies. Via its facet-

based browsing, OntoWiki allows the construction of

complex concept deﬁnitions, with a pre-deﬁned class

as a starting point by means of property value restric-

tions.

3 MULTIMODAL SEMANTIC

CONTENT

For handling large amounts of multimedia data, au-

tomatic processes for managing this kind of content

have been developed and integrated into OntoWiki.

They allow to import arbitrary multimedia documents

(13 different ﬁle types are currently supported) or

even complete directory structures into a knowledge

base and manage them subsequently with OntoWiki,

using the techniques presented in Section 2. The

workﬂow for importing multimedia documents is pre-

sented in Figure 2 and described in the sequel.

Extracting Multimedia Metadata. We developed

a framework, which detects certain formats (from the

more than 1000 different registered MIME types).

Discogs, Flickr,

MusicBrainz...

literal value

literal value literal value

query

response

save

Multimedia

Vocabulary

deﬁne

Input Extraction Representation

Linking

Metadata

Figure 2: Multimedia metadata extraction, representation

and interlinking process.

The framework is highly conﬁgurable and easily ex-

tensible, thus allowing to easily integrate support for

new multimedia types and to conﬁgure the properties

and classes used to create the semantic metadata. The

extraction of multimedia metadata is realized as fol-

lows:

1. Extraction of Metadata Attributes. Infor-

mation about the ﬁle name, size or date of creation

is extracted. In addition to those information, many

multimedia formats already contain metadata speciﬁc

to their ﬁeld of use. Such information is most likely

arranged in key-values pairs in the ﬁle’s header. For

instance, music ﬁles usually contain ID3 tags, im-

ages taken by digital cameras include an EXIF header.

The MIME type of the ﬁle is determined and subse-

quently a specialized metadata extractor is initialized.

The framework is designed in a way that every meta-

data extractor manages a set of extensions, each one

being responsible for the extraction of a single meta-

data type on its own. These extensions are executed

consecutively, thus giving the opportunity to re-use

already extracted metadata and accelerate the extrac-

tion process.

Previews of PDF or video documents are created.

Other examples of metadata extraction extensions are

the number of pages of a PDF document or the geo-

coordinates of an image.

2. Integration of Additional Information. The

previously extracted metadata is now used to obtain

and integrate additional information, which is not ex-

plicitly contained in the processed ﬁles. For example,

an artists name extracted from the music’s ﬁle ID3

information may be used to look up a URI for this

artist on the Data Web. Likewise, traditional non-RDF

based web-services may be used to gather additional

information (e.g. the album cover for a song).

Representing Multimedia Metadata. To represent

the extracted metadata in RDF we reused well es-

tablished vocabularies (cf. Figure 3). The rationale

WEBIST 2011 - 7th International Conference on Web Information Systems and Technologies

292

http://purl.org/NET/

mediatype#MediaType

audio/mpeg

application/

pdf

nfo:FileDataObject

nfo:Folder

nfo:FileHash

nfo:Paginated

TextDocument

mo:AudioFile

mo:Track

mo:MusicArtist

mo:Genre

mo:Record

nfo:Image nfo:Video

nie:Information

Element

nie:hasPart

rdf:type

rdfs:subClassOf

rdf:type

mo:discogs

mo:track_number

mo:release_type

mo:image

dc:title

dc:creator

dc:subject

dc:created

dc:modiﬁed

pdf:Keywords

pdf:Producer

rdfs:label

rdfs:seeAlso

nfo:pageCount

vm:hasPreview

nfo:permissions

nfo:ﬁleLastAccessed

nfo:ﬁleLastModiﬁed

nfo:ﬁleName

dc:creator

mo:track

mo:genre

mo:available_as

nfo:Audio

rdfs:subClassOf

rdf:type

audio/ogg

rdf:type

image/jpeg image/png

rdf:type

video/

x-msvideo

video/

mpeg

nfo:duration

nfo:codec

nfo:frameRate

nfo:frameCount

nfo:height

nfo:width

nfo:channels

nfo:sampleRate

nexif:imageWidth

nexif:imageLength

nexif:ﬂash

nexif:isoSpeedRatings

nexif:exposureTime

nexif:gpsLatitude

nexif:gpsLongitude

nexif:model

nfo:horizontalResolution

nfo:verticalResolution

nfo:ﬁleSize

nfo:ﬁleUrl

nfo:isLogicalPartOf

nfo:hasHash

Figure 3: Vocabulary for representing multimedia metadata.

of this representation is the separation between the

actual data (nfo:FileDataObject) and its interpre-

tation (nie:InformationElement) borrowed from

the NEPOMUK information element ontology (NIE)

and the NEPOMUK ﬁle ontology (NFO)

. The large

number of subclasses of nie:InformationElement

makes it possible to classify most of the common

multimedia types. To interpret a DataObject, it

needs to be seen in the context of a corresponding

InformationElement or as one of its subclasses.

This is achieved with the properties nie:hasPart (or

its inverse nie:isPartOf). This approach ensures

that even complex data structures, like archives in the

attachment of emails are processed correctly.

In order to describe the individual

InformationElements further, the following

list of vocabularies has been chosen: For describing

audio documents the music ontology (Raimond

et al., 2007) is used (namespace preﬁx mo), since

it allows to represent all information available in

ID3, as well as concepts such as concert or festival.

For describing PDF documents elements of vari-

ous vocabularies such as Dublin Core (dc), NFO

and RDFS are used. For describing images the

NEPOMUK EXIF ontology is used. Currently, we

primarily extract low-level information from videos

(e. g. frame-rate or the used video codec) which

are represented using the NEPOMUK ﬁle ontology.

URIs used to describe the ﬁle’s MIME type are

provided by the mediatypes application

Interlinking Metadata. The extracted and RDF

represented metadata can now be used to ﬁnd and

create links to arbitrary other resources. We devel-

oped the OntoWiki Linking Module, which is able

to discover possible links between any sort of re-

sources, in particular multimedia documents. The

semi-automatic algorithm used to locate the resources

NIE, NOE and NEXIF are available from:

http://www.semanticdesktop.org/ontologies/

http://mediatypes.appspot.com

for linking can be divided in the following four parts,

taking into account that the starting point of this al-

gorithm is an arbitrary resource r: (1) Find all prop-

erties with the rdfs:range or rdfs:domain of the

type (rdf:type) of resource r. (2) Created a list of

all resources, which are accessible via those proper-

ties. (3) All resources found in step two are now com-

pared to r. The comparison takes place with the help

of string attributes (e. g. dc:title or rdfs:label).

As metric to calculate the probability of interlinking

we use the effectiveness measure, i. e. the weighted

harmonic mean between precision and recall. (4) The

found resources are now sorted by their probability

of linking to r and presented to the user (grouped by

the property). For linking multimedia documents with

arbitrary resources, we developed vocabularies which

are aligned to the different MIME type categories (i.e.

application, audio, video, text and image).

4 MULTILINGUAL SEMANTIC

CONTENT

The life-cycle of multilingual semantic content (cf.

Figure 4) usually starts with the creation and author-

ing of a semantic resource. Once created textual con-

tent can be translated. Subsequently, the original lan-

guage content attached to the resource might be re-

vised, which has to trigger a revision of the transla-

tions as well. The translation of properties of RDF

resources in multiple languages is realized with lan-

guage tags, which can be attached to the string lit-

eral property values. Most RDF resources contain

at least one label in a preferred language. For the

semi-automated translation of literal values we em-

ploy the Google Translation Service API

. It supports

the translation between more than 50 languages as

well as an automated language detection, which helps

if source RDF literal values are not annotated with a

language tag. Since not all properties contain trans-

latable content as well as not all literal values are suit-

able sources for translation, users are able to conﬁgure

translatable property URIs and possible source lan-

guages. In the sequel we sketch OntoWiki extensions

for language resource translation and management.

Figure 4: Life-cycle of multilingual resources.

http://code.google.com/apis/ajaxlanguage/

MANAGING MULTIMODAL AND MULTILINGUAL SEMANTIC CONTENT

293

Figure 5: Individual resource translation extension.

Single Resource Translation. To improve the

translation support of single resources we integrated

the RDFauthor extension and the Individual resource

translation extension in OntoWiki. The ﬁrst exten-

sion auto-suggest translations while editing single lit-

eral values. The second extension can be deployed to

translate conﬁgured parts of complete RDF resources

automatically (cf. Figure 5).

Massive Translation Component. In order to

translate RDF resources massively, we developed the

Massive translation component for OntoWiki, which

is operating similar to the Individual resource trans-

lation extension. By using SPARQL, this component

requests a set of resources with missing translations.

The result is fulﬁlled automatically by using the trans-

lation service and presented to the user as a HTML-

form in the GUI. All literal values in the generated

HTML-form are editable, due to improve translations

manually afterwards. After applying and saving the

new translations, this algorithm is looped until all re-

sources contain the speciﬁed amount of translated lit-

eral values.

Multi-lingual Resource Versioning and Revision.

Every change between its creation and deletion of

an RDF resource is tracked by OntoWikis version-

ing component described in Section 2. This version-

ing component is also used to store information about

the translation process. After changing one of the lit-

eral values, translations to other languages could be

affected. As a consequence, a special entry marking a

translation process is stored to the versioning reposi-

tory. As being depicted in Figure 4, every translation

might have to be revised. This ﬂag is used to notify

the content author for approving the correctness of all

other translated literal values of the particular prop-

erty of the selected RDF resource. After approving

the correctness a further ﬂag is stored to represent an

acceptable translation state of the RDF resource.

Figure 6: Excerpt of the Vakantieland user interface.

5 USE CASE: VAKANTIELAND

Both our semantic content management strategies

were applied and evaluated in the Semantic Web ap-

plication Vakantieland

. Vakantieland publishes com-

prehensive information about 20,000 touristic points-

of-interest (POI) in The Netherlands such as tex-

tual descriptions, location information and opening

hours. The information is stored in a knowledge

base containing almost 2 million triples. It is struc-

tured using approx. 1,250 properties as well as 400

classes. Vakantieland was designed according to the

model/view/controller principle and uses OntoWiki’s

Erfurt API as middleware. Almost all of the infor-

mation presented in Vakantieland is retrieved using

SPARQL.

Multimedia Management in Vakantieland. In

this use case we applied the multimedia manage-

ment process, presented in Section 3, to create RDF

resources for about 850 PDF documents (i.e. info

brochures of POIs) and interlink them accordingly. In

particular, we extended the generic multimedia link-

ing vocabulary, in order to specify the rdfs:domain

to POIs and evaluated the OntoWiki Linking Module.

For 100 randomly chosen documents the suggestions

of this module have been compared to manually as-

signed links, created by a domain expert. This evalu-

ation has shown, that for 80% of the documents, the

correct suggestion – the POI with the highest proba-

bility – was found. The other way around (i.e. sug-

gesting documents for POIs) it was even possible to

ﬁnd the correct one in 90% of the cases. The cre-

ated links are then used to display those documents,

or any other document type for that matter, and addi-

tional information like the document’s title (translated

in various languages), on a POI’s details page.

Available at: http://staging.vakantieland.nl

WEBIST 2011 - 7th International Conference on Web Information Systems and Technologies

294

Multilinguality Management in Vakantieland. In

order to present the tourism content of Vakantieland

in multiple languages as depicted in Figure 6, we

translated rdfs:labels and rdfs:comments of classes,

properties and instances. At this time, the tourism

RDF content of Vakantieland contains information

encoded in different languages such as Dutch, En-

glish, French, German, Italian and Spanish. We mea-

sured our approach manually by using the Individ-

ual resource translation extension to translate 50 ran-

domly chosen property labels. In comparison to man-

ually translating these property labels from German to

English the usage of the translation extension reduced

the required time by more than 80%.

6 CONCLUSIONS

With the increasing maturation of semantic technolo-

gies the facilitation of multimodal and multilingual

semantic content management became a crucial re-

quirement. In this article we presented two comple-

mentary strategies for such content based on the se-

mantic wiki paradigm. Both strategies are based on

supporting the lifecycle of respective semantic con-

tent. With regard to future work we deem that work

with regard to the integration of automatic linking

techniques, ﬁne-grained provenance tracking, and fa-

cilitation of adaptive previews is promising.

REFERENCES

Auer, S., Dietzold, S., and Riechert, T. (2006). OntoWiki

– A Tool for Social, Semantic Collaboration. ISWC,

LNCS.

Auer, S. and Herre, H. (2006). A Versioning and Evolution

Framework for RDF Knowledge Bases. PSI.

Heino, N., Dietzold, S., Martin, M., and Auer, S. (2009).

Developing Semantic Web Applications with the On-

toWiki Framework. In Networked Knowledge - Net-

worked Media, Studies in Computational Intelligence.

Lopez, X. and Das, S. (2009). Oracle Database 11g Se-

mantic Technologies, Semantic Data Integration for

the Enterprise, White Paper. Technical report, Oracle

Semantic Technologies Center.

Raimond, Y., Abdallah, S. A., Sandler, M., and Giasson, F.

(2007). The music ontology. ISMIR.

Rieß, C., Heino, N., Tramp, S., and Auer, S. (2010). EvoPat

– Pattern-Based Evolution and Refactoring of RDF

Knowledge Bases. ISWC, LNCS.

Tramp, S., Frischmuth, P., Ermilov, T., and Auer, S.

(2010a). Weaving a Social Data Web with Semantic

Pingback. EKAW, LNAI.

Tramp, S., Heino, N., Auer, S., and Frischmuth, P. (2010b).

Rdfauthor: Employing RDFa for collaborative knowl-

edge engineering. EKAW, LNAI.

MANAGING MULTIMODAL AND MULTILINGUAL SEMANTIC CONTENT

295
